Rotel RSX-1057 Installation manual

RSX 1057
RS232 Controller Command List
Table: RSX 1057 Waveform format expected:
Baud Rate Parity Valid Data Bits Stop Bit Value Handshaking Data Type
19200 N 8 1 None String
Table: RSX 1057 expected format of a request by RS 232 controller:
Start Count Device ID Type Key Checksum
0xFE 0x03 0xC7 0x10 0xXX 0xXX
Table 1: Type 10 Primary Command List
NOTE: The values in the table below show the exact byte sequence of all requests. The device
will expect the bytes only - no spaces, no delimiter, etc. The controlling device may implement its
own method to download each command sequence. The numerical values in the first column are
Hexadecimal.
RSX 1057 HEX Command Command Description
FE 03 C7 10 00 DA RMC Vol+ Remote Volume Up
FE 03 C7 10 01 DB RMC Vol- Remote Volume Down
FE 03 C7 10 02 DC CD Source CD
FE 03 C7 10 03 DD Tuner Source Tuner
FE 03 C7 10 04 DE Tape Source Tape
FE 03 C7 10 05 DF Video 1 Source Video 1
FE 03 C7 10 06 E0 Video 2 Source Video 2
FE 03 C7 10 07 E1 Video 3 Source Video 3
FE 03 C7 10 08 E2 Video 4 Source Video 4
FE 03 C7 10 09 E3 Video 5 Source Video 5
FE 03 C7 10 0A E4 Power Power Toggle
FE 03 C7 10 0B E5 Vol+ Volume Up
FE 03 C7 10 0C E6 Vol- Volume Down
FE 03 C7 10 0D E7 Treble+ Treble Up
FE 03 C7 10 0E E8 Treble- Treble Down
FE 03 C7 10 0F E9 Bass+ Bass Up
FE 03 C7 10 10 EA Bass- Bass Down
FE 03 C7 10 11 EB Stereo DSP Stereo
FE 03 C7 10 12 EC 3 Stereo DSP Dolby 3 Stereo
FE 03 C7 10 13 ED Pro Logic DSP Pro Logic
FE 03 C7 10 14 EE DSP DSP Music
FE 03 C7 10 15 EF Multi Multi Input
FE 03 C7 10 16 F0 Dynamic Dynamic Range
FE 03 C7 10 17 F1 Rec Record
FE 03 C7 10 18 F2 OSD Menu OSD Menu
FE 03 C7 10 19 F3 OSD Enter OSD Enter
FE 03 C7 10 1A F4 OSD Right (+) OSD Right
FE 03 C7 10 1B F5 OSD Left (-) OSD Left
FE 03 C7 10 1C F6 OSD Up OSD Up

RSX 1057 HEX Command Command Description
FE 03 C7 10 1D F7 OSD Down / Dynamic OSD Down / Dynamic
FE 03 C7 10 1E F8 Mute Mute
FE 03 C7 10 1F F9 Digital In Select Digital Input Select
FE 03 C7 10 20 FA Tune / Preset Tune / Preset Toggle
FE 03 C7 10 21 FB Preset Scan Preset Scan
FE 03 C7 10 22 FC Surround+ Next Surround Mode
FE 03 C7 10 23 FD Zone 2 / Main Zone
FE 03 C7 10 24 FE Band Tuner Band
FE 03 C7 10 25 FF Freq. Direct Tuner Frequency Direct
FE 03 C7 10 26 00 FM Mono Tuner FM Mono
FE 03 C7 10 27 01 Memory / Enter Tuner Memory Enter
FE 03 C7 10 28 02 Tuning+ Tuner Up
FE 03 C7 10 29 03 Tuning- Tuner Down
FE 03 C7 10 2A 04 1 1
FE 03 C7 10 2B 05 2 2
FE 03 C7 10 2C 06 3 3
FE 03 C7 10 2D 07 4 4
FE 03 C7 10 2E 08 5 5
FE 03 C7 10 2F 09 6 6
FE 03 C7 10 30 0A 7 7
FE 03 C7 10 31 0B 8 8
FE 03 C7 10 32 0C 9 9
FE 03 C7 10 33 0D 0 0
FE 03 C7 10 44 1E Display Tuner Display
FE 03 C7 10 45 1F PTY RDS PTY
FE 03 C7 10 46 20 TP RDS TP
FE 03 C7 10 47 21 TA RDS TA
FE 03 C7 10 4A 24 Power Off Power Off
FE 03 C7 10 4B 25 Power On Power On
FE 03 C7 10 4C 26 C Center
FE 03 C7 10 4D 27 S Subwoofer
FE 03 C7 10 4E 28 R Surround
FE 03 C7 10 4F 29 Filter (EQ) Cinema EQ
FE 03 C7 10 52 2C FL On / Off FL Display Toggle
FE 03 C7 10 53 2D Pro Logic / 3 Stereo Dolby 3 Stereo
FE 03 C7 10 54 2E dts Neo:6 dts Neo:6
FE 03 C7 10 55 2F FM FM
FE 03 C7 10 56 30 AM AM
FE 03 C7 10 57 31 Music 1 Music 1
FE 03 C7 10 58 32 Music 2 Music 2
FE 03 C7 10 59 33 Music 3 Music 3
FE 03 C7 10 5A 34 Music 4 Music 4
FE 03 C7 10 5B 35 5Ch Stereo 5Ch Stereo
FE 03 C7 10 5C 36 7Ch Stereo 7Ch Stereo
FE 03 C7 10 5D 37 PLII Cinema Dolby PLII Cinema
FE 03 C7 10 5E 38 PLII Music Dolby PLII Music
FE 03 C7 10 5F 39 Pro Logic Dolby Pro Logic
FE 03 C7 10 60 3A dts Neo:6 Music dts Neo:6 Music

RSX 1057 HEX Command Command Description
FE 03 C7 10 61 3B dts Neo:6 Cinema dts Neo:6 Cinema
FE 03 C7 10 62 3C PLII Panorama PLII Panorama
FE 03 C7 10 63 3D PLII Dimension Up PLII Dimension Up
FE 03 C7 10 64 3E PLII Dimension Down PLII Dimension Down
FE 03 C7 10 65 3F PLII Center Width Up PLII Center Width Up
FE 03 C7 10 66 40 PLII Center Width Down PLII Center Width Down
FE 03 C7 10 67 41 Shift (Treble Bass) Tone Controls
FE 03 C7 10 68 42 DD EX On/Off DD EX On/Off
FE 03 C7 10 69 43 Tuning Select Discrete Tune Select
FE 03 C7 10 6A 44 Preset Select Discrete Preset Select
FE 03 C7 10 6F 49 Preset Up Tuner Preset Up
FE 03 C7 10 70 4A Preset Down Tuner Preset Down
FE 03 C7 10 72 4C Frequency Up Tuner Frequency Up
FE 03 C7 10 73 4D Frequency Down Tuner Frequency Down
FE 03 C7 10 74 4E PLII Game Dolby PLII Game
FE 03 C7 10 FF D9 Display Refresh Display Refresh
Table 2: Commands sent with exceptions or modifications required
RSX 1057 HEX Command Expected Command
FE 03 C7 10 23 FD FE 03 C7 10 23 FD 00 Zone 2 / Main
FE 03 C7 10 24 FE FE 03 C7 10 24 FD 01 Band
The table above list commands with exceptions. To keep the RSX 1057 from encountering the
start byte FE in any position other than as the start byte, any occurrence of the bytes FE or FD in
the command string must be converted to either FD 00 (for FD) or FD 01 (for FE). This will allow
the string to pass while masking any occurrence of the byte FE except as the start byte.
Table 3: Type 14 Main Zone Command List
NOTE: These commands are duplicate functions of the primary commands in the table above
bearing the same name, but are discrete for the main zone only. For multi-zone installation
applications, it is recommended that the below commands be used rather than the type 10
commands to avoid zone conflicts.
RSX 1057 HEX Command Command Description
FE 03 C7 14 00 DE RMC Vol+ Remote Volume Up
FE 03 C7 14 01 DF RMC Vol- Remote Volume Down
FE 03 C7 14 02 E0 Main CD Main Zone Source CD
FE 03 C7 14 03 E1 Main Tuner Main Zone Source Tuner
FE 03 C7 14 04 E2 Main Tape Main Zone Source Tape
FE 03 C7 14 05 E3 Main Video 1 Main Zone Source Video 1
FE 03 C7 14 06 E4 Main Video 2 Main Zone Source Video 2
FE 03 C7 14 07 E5 Main Video 3 Main Zone Source Video 3
FE 03 C7 14 08 E6 Main Video 4 Main Zone Source Video 4
FE 03 C7 14 09 E7 Main Video 5 Main Zone Source Video 5
FE 03 C7 14 0A E8 Main Power Main Zone Power Toggle
FE 03 C7 14 1E FC Main Mute Main Zone Mute
FE 03 C7 14 6C 4A Main Mute On Main Zone Mute On
FE 03 C7 14 6D 4B Main Mute Off Main Zone Mute Off

Table 4: Type 15 Record Source Command List
RSX 1057 HEX Command Command Description
FE 03 C7 15 02 E1 Record CD Record Source CD
FE 03 C7 15 03 E2 Record Tuner Record Source Tuner
FE 03 C7 15 04 E3 Record Tape Record Source Tape
FE 03 C7 15 05 E4 Record Video 1 Record Source Video 1
FE 03 C7 15 06 E5 Record Video 2 Record Source Video 2
FE 03 C7 15 07 E6 Record Video 3 Record Source Video 3
FE 03 C7 15 08 E7 Record Video 4 Record Source Video 4
FE 03 C7 15 09 E8 Record Video 5 Record Source Video 5
FE 03 C7 15 6B 4A Record Source Record Source
Table 5: Type 16 Zone 2 Command List
RSX 1057 HEX Command Command Description
FE 03 C7 16 00 E0 Vol+ Zone 2 Volume Up
FE 03 C7 16 01 E1 Vol- Zone 2 Volume Down
FE 03 C7 16 02 E2 Zone 2 CD Zone 2 Source CD
FE 03 C7 16 03 E3 Zone 2 Tuner Zone 2 Source Tuner
FE 03 C7 16 04 E4 Zone 2 Tape Zone 2 Source Tape
FE 03 C7 16 05 E5 Zone 2 Video 1 Zone 2 Source Video 1
FE 03 C7 16 06 E6 Zone 2 Video 2 Zone 2 Source Video 2
FE 03 C7 16 07 E7 Zone 2 Video 3 Zone 2 Source Video 3
FE 03 C7 16 08 E8 Zone 2 Video 4 Zone 2 Source Video 4
FE 03 C7 16 09 E9 Zone 2 Video 5 Zone 2 Source Video 5
FE 03 C7 16 0A EA Zone 2 Power Zone 2 Power Toggle
FE 03 C7 16 1E FE Zone 2 Mute Zone 2 Mute
FE 03 C7 16 20 00 Zone 2 Tune / Preset Zone 2 Tune / Preset Toggle
FE 03 C7 16 21 01 Zone 2 Preset Scan Zone 2 Preset Scan
FE 03 C4 16 24 04 Zone 2 Band Zone 2 Band
FE 03 C4 16 26 06 Zone 2 FM Mono Zone 2 FM Mono
FE 03 C7 16 28 08 Zone 2 Tune Up Zone 2 Tune Up
FE 03 C7 16 29 09 Zone 2 Tune Down Zone 2 Tune Down
FE 03 C7 16 2A 0A Zone 2 Preset 1 Zone 2 Preset 1
FE 03 C7 16 2B 0B Zone 2 Preset 2 Zone 2 Preset 2
FE 03 C7 16 2C 0C Zone 2 Preset 3 Zone 2 Preset 3
FE 03 C7 16 2D 0D Zone 2 Preset 4 Zone 2 Preset 4
FE 03 C7 16 2E 0E Zone 2 Preset 5 Zone 2 Preset 5
FE 03 C7 16 2F 0F Zone 2 Preset 6 Zone 2 Preset 6
FE 03 C7 16 30 10 Zone 2 Preset 7 Zone 2 Preset 7
FE 03 C7 16 31 11 Zone 2 Preset 8 Zone 2 Preset 8
FE 03 C7 16 32 12 Zone 2 Preset 9 Zone 2 Preset 9
FE 03 C7 16 33 13 Zone 2 Preset 0 Zone 2 Preset 0
FE 03 C7 16 4A 2A Zone 2 Power Off Zone 2 Power Off
FE 03 C7 16 4B 2B Zone 2 Power On Zone 2 Power On
FE 03 C7 16 55 35 Zone 2 FM Zone 2 Tuner FM
FE 03 C7 16 56 36 Zone 2 AM Zone 2 Tuner AM

RSX 1057 HEX Command Expected Command
FE 03 C7 16 69 49 Zone 2 Tune Zone 2 Tuner Manual Tune Mode
FE 03 C7 16 6A 4A Zone 2 Preset Zone 2 Tuner Preset Mode
FE 03 C7 16 6B 4B Zone 2 Source Zone 2 Follow Main Source
FE 03 C7 16 6C 4C Zone 2 Mute On Zone 2 Mute On
FE 03 C7 16 6D 4D Zone 2 Mute Off Zone 2 Mute Off
Table 6: Commands sent with exceptions or modifications required
RSX 1057 HEX Command Expected Command
FE 03 C7 16 1E FE FE 03 C7 16 1E FD 01 Zone 2 Mute
Table 7: Type 30 Volume Direct Command List
RSX 1057 HEX Command Command Description
FE 03 C7 30 00 FA Volume Min Volume Min
FE 03 C7 30 01 FB Volume 1 Volume 1
FE 03 C7 30 02 FC Volume 2 Volume 2
FE 03 C7 30 03 FD Volume 3 Volume 3
FE 03 C7 30 04 FE Volume 4 Volume 4
FE 03 C7 30 05 FF Volume 5 Volume 5
FE 03 C7 30 06 00 Volume 6 Volume 6
FE 03 C7 30 07 01 Volume 7 Volume 7
FE 03 C7 30 08 02 Volume 8 Volume 8
FE 03 C7 30 09 03 Volume 9 Volume 9
FE 03 C7 30 0A 04 Volume 10 Volume 10
FE 03 C7 30 0B 05 Volume 11 Volume 11
FE 03 C7 30 0C 06 Volume 12 Volume 12
FE 03 C7 30 0D 07 Volume 13 Volume 13
FE 03 C7 30 0E 08 Volume 14 Volume 14
FE 03 C7 30 0F 09 Volume 15 Volume 15
FE 03 C7 30 10 0A Volume 16 Volume 16
FE 03 C7 30 20 1A Volume 32 Volume 32
FE 03 C7 30 30 2A Volume 48 Volume 48
FE 03 C7 30 40 3A Volume 64 Volume 64
FE 03 C7 30 50 4A Volume 80 Volume 80
FE 03 C7 30 5F 59 Volume 95 Volume 95
FE 03 C7 30 60 5A Volume Max Volume Max
Table 8: Commands Sent with exceptions or modifications required
RSX 1057 HEX Command Expected Command
FE 03 C7 30 03 FD FE 03 C7 30 03 FD 00 Volume 3
FE 03 C7 30 04 FE FE 03 C7 30 03 FD 01 Volume 4

Table 9: Type 32 Zone 2 Volume Direct Command List
RSX 1057 HEX Command Command Description
FE 03 C7 32 00 FC Zone 2 Volume Min Zone 2 Volume Min
FE 03 C7 32 01 FD Zone 2 Volume 1 Zone 2 Volume 1
FE 03 C7 32 02 FE Zone 2 Volume 2 Zone 2 Volume 2
FE 03 C7 32 03 FF Zone 2 Volume 3 Zone 2 Volume 3
FE 03 C7 32 04 00 Zone 2 Volume 4 Zone 2 Volume 4
FE 03 C7 32 05 01 Zone 2 Volume 5 Zone 2 Volume 5
FE 03 C7 32 06 02 Zone 2 Volume 6 Zone 2 Volume 6
FE 03 C7 32 07 03 Zone 2 Volume 7 Zone 2 Volume 7
FE 03 C7 32 08 04 Zone 2 Volume 8 Zone 2 Volume 8
FE 03 C7 32 09 05 Zone 2 Volume 9 Zone 2 Volume 9
FE 03 C7 32 0A 06 Zone 2 Volume 10 Zone 2 Volume 10
FE 03 C7 32 0B 07 Zone 2 Volume 11 Zone 2 Volume 11
FE 03 C7 32 0C 08 Zone 2 Volume 12 Zone 2 Volume 12
FE 03 C7 32 0D 09 Zone 2 Volume 13 Zone 2 Volume 13
FE 03 C7 32 0E 0A Zone 2 Volume 14 Zone 2 Volume 14
FE 03 C7 32 0F 0B Zone 2 Volume 15 Zone 2 Volume 15
FE 03 C7 32 10 0C Zone 2 Volume 16 Zone 2 Volume 16
FE 03 C7 32 20 1C Zone 2 Volume 32 Zone 2 Volume 32
FE 03 C7 32 30 2C Zone 2 Volume 48 Zone 2 Volume 48
FE 03 C7 32 40 3C Zone 2 Volume 64 Zone 2 Volume 64
FE 03 C7 32 50 4C Zone 2 Volume 80 Zone 2 Volume 80
FE 03 C7 32 5F 55 Zone 2 Volume 89 Zone 2 Volume 89
FE 03 C7 32 60 56 Zone 2 Volume Max Zone 2 Volume Max
Table 10: Commands Sent with exceptions or modifications required
RSX 1057 HEX Command Expected Command
FE 03 C7 32 01 FD FE 03 C7 32 01 FD 00 Zone 2 Volume 1
FE 03 C7 32 02 FE FE 03 C7 03 01 FD 01 Zone 2 Volume 2
