RS232 Controller Command List
Table: RSX 1067 Waveform format expected:
Baud Rate Parity Valid Data Bits Stop Bit Value Handshaking Data Type
19200 N 8 1 None String
Table: RSX 1067 expected format of a request by RS 232 controller:
Start Count Device ID Type Key Checksum
0xFE 0x03 0xC4 0x10 0xXX 0xXX
Table 1: Type 10 Primary Command List
NOTE: The values in the table below show the exact byte sequence of all requests. The device
will expect the bytes only - no spaces, no delimiter, etc. The controlling device may implement its
own method to download each command sequence. The numerical values in the first column are
Hexadecimal.
RSX 1067 HEX Command Command Description
FE 03 C4 10 00 D7 RMC Vol+ Remote Volume Up
FE 03 C4 10 01 D8 RMC Vol- Remote Volume Down
FE 03 C4 10 02 D9 CD Source CD
FE 03 C4 10 03 DA Tuner Source Tuner
FE 03 C4 10 04 DB Tape Source Tape
FE 03 C4 10 05 DC Video 1 Source Video 1
FE 03 C4 10 06 DD Video 2 Source Video 2
FE 03 C4 10 07 DE Video 3 Source Video 3
FE 03 C4 10 08 DF Video 4 Source Video 4
FE 03 C4 10 09 E0 Video 5 Source Video 5
FE 03 C4 10 0A E1 Power Power Toggle
FE 03 C4 10 0B E2 Vol+ Volume Up
FE 03 C4 10 0C E3 Vol- Volume Down
FE 03 C4 10 0D E4 Treble+ Treble Up
FE 03 C4 10 0E E5 Treble- Treble Down
FE 03 C4 10 0F E6 Bass+ Bass Up
FE 03 C4 10 10 E7 Bass- Bass Down
FE 03 C4 10 11 E8 Stereo DSP Stereo
FE 03 C4 10 12 E9 3 Stereo DSP Dolby 3 Stereo
FE 03 C4 10 13 EA Pro Logic DSP Pro Logic
FE 03 C4 10 14 EB DSP DSP Music
FE 03 C4 10 15 EC Multi Multi Input
FE 03 C4 10 16 ED Dynamic Dynamic Range
FE 03 C4 10 17 EE Rec Record
FE 03 C4 10 18 EF OSD Menu OSD Menu
FE 03 C4 10 19 F0 OSD Enter OSD Enter
FE 03 C4 10 1A F1 OSD Right (+) OSD Right
FE 03 C4 10 1B F2 OSD Left (-) OSD Left
FE 03 C4 10 1C F3 OSD Up OSD Up

RSX 1067 HEX Command Command Description
FE 03 C4 10 1D F4 OSD Down / Dynamic OSD Down / Dynamic
FE 03 C4 10 1E F5 Mute Mute
FE 03 C4 10 1F F6 Digital In Select Digital Input Select
FE 03 C4 10 20 F7 Tune / Preset Tune / Preset Toggle
FE 03 C4 10 21 F8 Preset Scan Preset Scan
FE 03 C4 10 22 F9 Surround+ Next Surround Mode
FE 03 C4 10 23 FA Zone 2 / Main Zone
FE 03 C4 10 24 FB Band Tuner Band
FE 03 C4 10 25 FC Freq. Direct Tuner Frequency Direct
FE 03 C4 10 26 FD FM Mono Tuner FM Mono
FE 03 C4 10 27 FE Memory / Enter Tuner Memory Enter
FE 03 C4 10 28 FF Tuning+ Tuner Up
FE 03 C4 10 29 00 Tuning- Tuner Down
FE 03 C4 10 2A 01 1 1
FE 03 C4 10 2B 02 2 2
FE 03 C4 10 2C 03 3 3
FE 03 C4 10 2D 04 4 4
FE 03 C4 10 2E 05 5 5
FE 03 C4 10 2F 06 6 6
FE 03 C4 10 30 07 7 7
FE 03 C4 10 31 08 8 8
FE 03 C4 10 32 09 9 9
FE 03 C4 10 33 0A 0 0
FE 03 C4 10 44 1B Display Tuner Display
FE 03 C4 10 45 1C PTY RDS PTY
FE 03 C4 10 46 1D TP RDS TP
FE 03 C4 10 47 1E TA RDS TA
FE 03 C4 10 4A 21 Power Off Power Off
FE 03 C4 10 4B 22 Power On Power On
FE 03 C4 10 4C 23 C Center
FE 03 C4 10 4D 24 S Subwoofer
FE 03 C4 10 4E 25 R Surround
FE 03 C4 10 4F 26 Filter (EQ) Cinema EQ
FE 03 C4 10 52 29 FL On / Off FL Display Toggle
FE 03 C4 10 53 2A Pro Logic / 3 Stereo Dolby 3 Stereo
FE 03 C4 10 54 2B dts Neo:6 dts Neo:6
FE 03 C4 10 55 2C FM FM
FE 03 C4 10 56 2D AM AM
FE 03 C4 10 57 2E Music 1 Music 1
FE 03 C4 10 58 2F Music 2 Music 2
FE 03 C4 10 59 30 Music 3 Music 3
FE 03 C4 10 5A 31 Music 4 Music 4
FE 03 C4 10 5B 32 5Ch Stereo 5Ch Stereo
FE 03 C4 10 5C 33 7Ch Stereo 7Ch Stereo
FE 03 C4 10 5D 34 PLII Cinema Dolby PLII Cinema
FE 03 C4 10 5E 35 PLII Music Dolby PLII Music
FE 03 C4 10 5F 36 Pro Logic Dolby Pro Logic
FE 03 C4 10 60 37 dts Neo:6 Music dts Neo:6 Music

RSX 1067 HEX Command Command Description
FE 03 C4 10 61 38 dts Neo:6 Cinema dts Neo:6 Cinema
FE 03 C4 10 62 39 PLII Panorama PLII Panorama
FE 03 C4 10 63 3A PLII Dimension Up PLII Dimension Up
FE 03 C4 10 64 3B PLII Dimension Down PLII Dimension Down
FE 03 C4 10 65 3C PLII Center Width Up PLII Center Width Up
FE 03 C4 10 66 3D PLII Center Width Down PLII Center Width Down
FE 03 C4 10 67 3E Shift (Treble Bass) Tone Controls
FE 03 C4 10 68 3F DD EX On/Off DD EX On/Off
FE 03 C4 10 69 40 Tuning Select Discrete Tune Select
FE 03 C4 10 6A 41 Preset Select Discrete Preset Select
FE 03 C4 10 74 4B PLII Game Dolby PLII Game
FE 03 C4 10 FF D6 Display Refresh Display Refresh
Table 2: Commands Sent with exceptions or modifications required
RSX 1067 HEX Command Expected Command
FE 03 C4 10 26 FD FE 03 C4 10 26 FD 00 FM Mono
FE 03 C4 10 27 FE FE 03 C4 10 27 FD 01 Memory / Enter
The table above list commands with exceptions. To keep the RSX 1067 from encountering the
start byte FE in any position other than as the start byte, any occurrence of the bytes FE or FD in
the command string must be converted to either FD 00 (for FD) or FD 01 (for FE). This will allow
the string to pass while masking any occurrence of the byte FE except as the start byte.
Table 3: Type 14 Main Zone Command List
NOTE: These commands are duplicate functions of the primary commands in the table above
bearing the same name, but are discrete for the main zone only. For multi-zone installation
applications, it is recommended that the below commands be used rather than the type 10
commands to avoid zone conflicts.
RSX 1067 HEX Command Command Description
FE 03 C4 14 00 DB RMC Vol+ Remote Volume Up
FE 03 C4 14 01 DC RMC Vol- Remote Volume Down
FE 03 C4 14 02 DD Main CD Main Zone Source CD
FE 03 C4 14 03 DE Main Tuner Main Zone Source Tuner
FE 03 C4 14 04 DF Main Tape Main Zone Source Tape
FE 03 C4 14 05 E0 Main Video 1 Main Zone Source Video 1
FE 03 C4 14 06 E1 Main Video 2 Main Zone Source Video 2
FE 03 C4 14 07 E2 Main Video 3 Main Zone Source Video 3
FE 03 C4 14 08 E3 Main Video 4 Main Zone Source Video 4
FE 03 C4 14 09 E4 Main Video 5 Main Zone Source Video 5
FE 03 C4 14 0A E5 Main Power Main Zone Power Toggle
FE 03 C4 14 1E F9 Main Mute Main Zone Mute
FE 03 C4 14 6C 47 Main Mute On Main Zone Mute On
FE 03 C4 14 6D 48 Main Mute Off Main Zone Mute Off

Table 4: Type 15 Record Source Command List
RSX 1067 HEX Command Command Description
FE 03 C4 15 02 DE Record CD Record Source CD
FE 03 C4 15 03 DF Record Tuner Record Source Tuner
FE 03 C4 15 04 E0 Record Tape Record Source Tape
FE 03 C4 15 05 E1 Record Video 1 Record Source Video 1
FE 03 C4 15 06 E2 Record Video 2 Record Source Video 2
FE 03 C4 15 07 E3 Record Video 3 Record Source Video 3
FE 03 C4 15 08 E4 Record Video 4 Record Source Video 4
FE 03 C4 15 09 E5 Record Video 5 Record Source Video 5
FE 03 C4 15 6B E6 Record Source Record Follow Main Source
Table 5: Type 16 Zone 2 Command List
RSX 1067 HEX Command Command Description
FE 03 C4 16 00 DD Vol+ Zone 2 Volume Up
FE 03 C4 16 01 DE Vol- Zone 2 Volume Down
FE 03 C4 16 02 DF Zone 2 CD Zone 2 Source CD
FE 03 C4 16 03 E0 Zone 2 Tuner Zone 2 Source Tuner
FE 03 C4 16 04 E1 Zone 2 Tape Zone 2 Source Tape
FE 03 C4 16 05 E2 Zone 2 Video 1 Zone 2 Source Video 1
FE 03 C4 16 06 E3 Zone 2 Video 2 Zone 2 Source Video 2
FE 03 C4 16 07 E4 Zone 2 Video 3 Zone 2 Source Video 3
FE 03 C4 16 08 E5 Zone 2 Video 4 Zone 2 Source Video 4
FE 03 C4 16 09 E6 Zone 2 Video 5 Zone 2 Source Video 5
FE 03 C4 16 0A E7 Zone 2 Power Zone 2 Power Toggle
FE 03 C4 16 1E FB Zone 2 Mute Zone 2 Mute
FE 03 C4 16 20 FD Zone 2 Tune / Preset Zone 2 Tune / Preset Toggle
FE 03 C4 16 21 FE Zone 2 Preset Scan Zone 2 Preset Scan
FE 03 C4 16 24 01 Zone 2 Band Zone 2 Band
FE 03 C4 16 26 03 Zone 2 FM Mono Zone 2 FM Mono
FE 03 C4 16 28 05 Zone 2 Tune Up Zone 2 Tune Up
FE 03 C4 16 29 06 Zone 2 Tune Down Zone 2 Tune Down
FE 03 C4 16 2A 07 Zone 2 Preset 1 Zone 2 Preset 1
FE 03 C4 16 2B 08 Zone 2 Preset 2 Zone 2 Preset 2
FE 03 C4 16 2C 09 Zone 2 Preset 3 Zone 2 Preset 3
FE 03 C4 16 2D 0A Zone 2 Preset 4 Zone 2 Preset 4
FE 03 C4 16 2E 0B Zone 2 Preset 5 Zone 2 Preset 5
FE 03 C4 16 2F 0C Zone 2 Preset 6 Zone 2 Preset 6
FE 03 C4 16 30 0D Zone 2 Preset 7 Zone 2 Preset 7
FE 03 C4 16 31 0E Zone 2 Preset 8 Zone 2 Preset 8
FE 03 C4 16 32 0F Zone 2 Preset 9 Zone 2 Preset 9
FE 03 C4 16 33 10 Zone 2 Preset 0 Zone 2 Preset 0
FE 03 C4 16 4A 27 Zone 2 Power Off Zone 2 Power Off
FE 03 C4 16 4B 28 Zone 2 Power On Zone 2 Power On
FE 03 C4 16 55 32 Zone 2 FM Zone 2 Tuner FM
FE 03 C4 16 56 33 Zone 2 AM Zone 2 Tuner AM
FE 03 C4 16 69 46 Zone 2 Tune Zone 2 Tuner Manual Tune Mode

RSX 1067 HEX Command Expected Command
FE 03 C4 16 6A 47 Zone 2 Preset Zone 2 Tuner Preset Mode
FE 03 C4 16 6B 48 Zone 2 Source Zone 2 Follow Main Source
FE 03 C4 16 6C 49 Zone 2 Mute On Zone 2 Mute On
FE 03 C4 16 6D 4A Zone 2 Mute Off Zone 2 Mute Off
Table 6: Commands Sent with exceptions or modifications required
RSX 1067 HEX Command Expected Command
FE 03 C4 16 20 FD FE 03 C4 16 20 FD 00 Zone 2 Tune / Preset
FE 03 C4 16 21 FE FE 03 C4 16 21 FD 01 Zone 2 Preset Scan
Table 7: Type 30 Volume Direct Command List
RSX 1067 HEX Command Command Description
FE 03 C4 30 00 F7 Volume Min Volume Min
FE 03 C4 30 01 F8 Volume 1 Volume 1
FE 03 C4 30 02 F9 Volume 2 Volume 2
FE 03 C4 30 03 FA Volume 3 Volume 3
FE 03 C4 30 04 FB Volume 4 Volume 4
FE 03 C4 30 05 FC Volume 5 Volume 5
FE 03 C4 30 06 FD Volume 6 Volume 6
FE 03 C4 30 07 FE Volume 7 Volume 7
FE 03 C4 30 08 FF Volume 8 Volume 8
FE 03 C4 30 09 00 Volume 9 Volume 9
FE 03 C4 30 0A 01 Volume 10 Volume 10
FE 03 C4 30 0B 02 Volume 11 Volume 11
FE 03 C4 30 0C 03 Volume 12 Volume 12
FE 03 C4 30 0D 04 Volume 13 Volume 13
FE 03 C4 30 0E 05 Volume 14 Volume 14
FE 03 C4 30 0F 06 Volume 15 Volume 15
FE 03 C4 30 10 07 Volume 16 Volume 16
FE 03 C4 30 20 17 Volume 32 Volume 32
FE 03 C4 30 30 27 Volume 48 Volume 48
FE 03 C4 30 40 37 Volume 64 Volume 64
FE 03 C4 30 50 47 Volume 80 Volume 80
FE 03 C4 30 5F 56 Volume 95 Volume 95
FE 03 C4 30 60 57 Volume Max Volume Max
Table 8: Commands Sent with exceptions or modifications required
RSX 1067 HEX Command Expected Command
FE 03 C4 30 06 FD FE 03 C4 30 06 FD 00 Volume 6
FE 03 C4 30 07 FE FE 03 C4 30 07 FD 01 Volume 7

Table 9: Type 32 Zone 2 Volume Direct Command List
RSX 1067 HEX Command Command Description
FE 03 C4 32 00 F9 Zone 2 Volume Min Zone 2 Volume Min
FE 03 C4 32 01 FA Zone 2 Volume 1 Zone 2 Volume 1
FE 03 C4 32 02 FB Zone 2 Volume 2 Zone 2 Volume 2
FE 03 C4 32 03 FC Zone 2 Volume 3 Zone 2 Volume 3
FE 03 C4 32 04 FD Zone 2 Volume 4 Zone 2 Volume 4
FE 03 C4 32 05 FE Zone 2 Volume 5 Zone 2 Volume 5
FE 03 C4 32 06 FF Zone 2 Volume 6 Zone 2 Volume 6
FE 03 C4 32 07 00 Zone 2 Volume 7 Zone 2 Volume 7
FE 03 C4 32 08 01 Zone 2 Volume 8 Zone 2 Volume 8
FE 03 C4 32 09 02 Zone 2 Volume 9 Zone 2 Volume 9
FE 03 C4 32 0A 03 Zone 2 Volume 10 Zone 2 Volume 10
FE 03 C4 32 0B 04 Zone 2 Volume 11 Zone 2 Volume 11
FE 03 C4 32 0C 05 Zone 2 Volume 12 Zone 2 Volume 12
FE 03 C4 32 0D 06 Zone 2 Volume 13 Zone 2 Volume 13
FE 03 C4 32 0E 07 Zone 2 Volume 14 Zone 2 Volume 14
FE 03 C4 32 0F 08 Zone 2 Volume 15 Zone 2 Volume 15
FE 03 C4 32 10 09 Zone 2 Volume 16 Zone 2 Volume 16
FE 03 C4 32 20 19 Zone 2 Volume 32 Zone 2 Volume 32
FE 03 C4 32 30 29 Zone 2 Volume 48 Zone 2 Volume 48
FE 03 C4 32 40 39 Zone 2 Volume 64 Zone 2 Volume 64
FE 03 C4 32 50 49 Zone 2 Volume 80 Zone 2 Volume 80
FE 03 C4 32 5F 52 Zone 2 Volume 89 Zone 2 Volume 89
FE 03 C4 32 60 53 Zone 2 Volume Max Zone 2 Volume Max
Table 10: Commands Sent with exceptions or modifications required
RSX 1067 HEX Command Expected Command
FE 03 C4 32 04 FD FE 03 C4 32 04 FD 00 Zone 2 Volume 4
FE 03 C4 32 05 FE FE 03 C4 32 05 FD 01 Zone 2 Volume 5
