Rotel RSX-1058 Installation manual

RSX 1058
RS232 Controller Command List
Table: RSX 1058 Waveform format expected:
Baud Rate Parity Valid Data Bits Stop Bit Value Handshaking Data Type
38400 N 8 1 None String
Table: RSX 1058 expected format of a request by RS 232 controller:
Start Count Device ID Type Key Checksum
0xFE 0x03 0xC8 0x10 0xXX 0xXX
Table 1: Type 10 Primary Command List
NOTE: The values in the table below show the exact byte sequence of all requests. The device
will expect the bytes only - no spaces, no delimiter, etc. The controlling device may implement its
own method to download each command sequence. The numerical values in the first column are
Hexadecimal.
RSX 1058 HEX Command Command Description
FE 03 C8 10 00 DB RMC Vol+ Remote Volume Up
FE 03 C8 10 01 DC RMC Vol- Remote Volume Down
FE 03 C8 10 02 DD CD Source CD
FE 03 C8 10 03 DE Tuner Source Tuner
FE 03 C8 10 04 DF Tape Source Tape
FE 03 C8 10 05 E0 Video 1 Source Video 1
FE 03 C8 10 06 E1 Video 2 Source Video 2
FE 03 C8 10 07 E2 Video 3 Source Video 3
FE 03 C8 10 08 E3 Video 4 Source Video 4
FE 03 C8 10 09 E4 Video 5 Source Video 5
FE 03 C8 10 0A E5 Power Power Toggle
FE 03 C8 10 0B E6 Vol+ Volume Up
FE 03 C8 10 0C E7 Vol- Volume Down
FE 03 C8 10 0D E8 Treble+ Treble Up
FE 03 C8 10 0E E9 Treble- Treble Down
FE 03 C8 10 0F EA Bass+ Bass Up
FE 03 C8 10 10 EB Bass- Bass Down
FE 03 C8 10 11 EC Stereo DSP Stereo
FE 03 C8 10 12 ED 3 Stereo DSP Dolby 3 Stereo
FE 03 C8 10 13 EE Pro Logic DSP Pro Logic
FE 03 C8 10 14 EF DSP DSP Music
FE 03 C8 10 15 E0 Multi Multi Input
FE 03 C8 10 16 F1 Dynamic Dynamic Range
FE 03 C8 10 17 F2 Rec Record
FE 03 C8 10 18 F3 OSD Menu OSD Menu
FE 03 C8 10 19 F4 OSD Enter OSD Enter
FE 03 C8 10 1A F5 OSD Right (+) OSD Right
FE 03 C8 10 1B F6 OSD Left (-) OSD Left
FE 03 C8 10 1C F7 OSD Up OSD Up

RSX 1058 HEX Command Command Description
FE 03 C8 10 1D F8 OSD Down / Dynamic OSD Down / Dynamic
FE 03 C8 10 1E F9 Mute Mute
FE 03 C8 10 1F FA Digital In Select Digital Input Select
FE 03 C8 10 20 FB Tune / Preset Tune / Preset Toggle
FE 03 C8 10 21 FC Preset Scan Preset Scan
FE 03 C8 10 22 FD Surround+ Next Surround Mode
FE 03 C8 10 23 FE Zone 2 / Main Zone
FE 03 C8 10 24 FF Band Tuner Band
FE 03 C8 10 25 00 Freq. Direct Tuner Frequency Direct
FE 03 C8 10 26 01 FM Mono Tuner FM Mono
FE 03 C8 10 27 02 Memory / Enter Tuner Memory Enter
FE 03 C8 10 28 03 Tuning+ Tuner Up
FE 03 C8 10 29 04 Tuning- Tuner Down
FE 03 C8 10 2A 05 1 1
FE 03 C8 10 2B 06 2 2
FE 03 C8 10 2C 07 3 3
FE 03 C8 10 2D 08 4 4
FE 03 C8 10 2E 09 5 5
FE 03 C8 10 2F 0A 6 6
FE 03 C8 10 30 0B 7 7
FE 03 C8 10 31 0C 8 8
FE 03 C8 10 32 0D 9 9
FE 03 C8 10 33 0E 0 0
FE 03 C8 10 44 1F Display Tuner Display
FE 03 C8 10 45 20 PTY RDS PTY
FE 03 C8 10 46 21 TP RDS TP
FE 03 C8 10 47 22 TA RDS TA
FE 03 C8 10 4A 25 Power Off Power Off
FE 03 C8 10 4B 26 Power On Power On
FE 03 C8 10 4C 27 C Center
FE 03 C8 10 4D 28 S Subwoofer
FE 03 C8 10 4E 29 R Surround
FE 03 C8 10 4F 2A Filter (EQ) Cinema EQ
FE 03 C8 10 52 2D FL On / Off FL Display Toggle
FE 03 C8 10 53 2E Pro Logic / 3 Stereo Dolby 3 Stereo
FE 03 C8 10 54 2F dts Neo:6 dts Neo:6
FE 03 C8 10 55 30 FM FM
FE 03 C8 10 56 31 AM AM
FE 03 C8 10 57 32 Music 1 Music 1
FE 03 C8 10 58 33 Music 2 Music 2
FE 03 C8 10 59 34 Music 3 Music 3
FE 03 C8 10 5A 35 Music 4 Music 4
FE 03 C8 10 5B 36 5Ch Stereo 5Ch Stereo
FE 03 C8 10 5C 37 7Ch Stereo 7Ch Stereo
FE 03 C8 10 5D 38 PLII Cinema PLII Cinema
FE 03 C8 10 5E 39 PLII Music PLII Music
FE 03 C8 10 5F 3A PLII Emulation PLII Emulation
FE 03 C8 10 60 3B dts Neo:6 Music dts Neo:6 Music

RSX 1058 HEX Command Command Description
FE 03 C8 10 61 3C dts Neo:6 Cinema dts Neo:6 Cinema
FE 03 C8 10 62 3D PLII Panorama PLII Panorama
FE 03 C8 10 63 3E PLII Dimension Up PLII Dimension Up
FE 03 C8 10 64 3F PLII Dimension Down PLII Dimension Down
FE 03 C8 10 65 40 PLII Center Width Up PLII Center Width Up
FE 03 C8 10 66 41 PLII Center Width Down PLII Center Width Down
FE 03 C8 10 67 42 Shift (Treble Bass) Tone Controls
FE 03 C8 10 68 43 DD EX On/Off DD EX On/Off
FE 03 C8 10 69 44 Tuning Select Discrete Tune Select
FE 03 C8 10 6A 45 Preset Select Discrete Preset Select
FE 03 C8 10 6E 49 Party Mode Party Mode Toggle
FE 03 C8 10 6F 4A Preset Up Tuner Preset Up
FE 03 C8 10 70 4B Preset Down Tuner Preset Down
FE 03 C8 10 71 4C All Zones Off Power Off All Zones
FE 03 C8 10 72 4D Frequency Up Tuner Frequency Up
FE 03 C8 10 73 4E Frequency Down Tuner Frequency Down
FE 03 C8 10 74 4F PLII Game Dolby PLII Game
FE 03 C8 10 75 50 Output Resolution Output Resolution
FE 03 C8 10 FF DA Display Refresh Display Refresh
Table 2: Commands Sent with exceptions or modifications required
RSX 1058 HEX Command Expected Command
FE 03 C8 10 22 FD FE 03 C8 10 22 FD 00 Surround Mode
FE 03 C8 10 23 FE FE 03 C8 10 23 FD 01 Zone2 / Main
The table above list commands with exceptions. To keep the RSX 1058 from encountering the
start byte FE in any position other than as the start byte, any occurrence of the bytes FE or FD in
the command string must be converted to either FD 00 (for FD) or FD 01 (for FE). This will allow
the string to pass while masking any occurrence of the byte FE except as the start byte.
Table 3: Type 14 Main Zone Command List
NOTE: These commands are duplicate functions of the primary commands in the table above
bearing the same name.
RSX 1058 HEX Command Command Description
FE 03 C8 14 00 DF RMC Vol+ Remote Volume Up
FE 03 C8 14 01 E0 RMC Vol- Remote Volume Down
FE 03 C8 14 02 E1 Main CD Main Zone Source CD
FE 03 C8 14 03 E2 Main Tuner Main Zone Source Tuner
FE 03 C8 14 04 E3 Main Tape Main Zone Source Tape
FE 03 C8 14 05 E4 Main Video 1 Main Zone Source Video 1
FE 03 C8 14 06 E5 Main Video 2 Main Zone Source Video 2
FE 03 C8 14 07 E6 Main Video 3 Main Zone Source Video 3
FE 03 C8 14 08 E7 Main Video 4 Main Zone Source Video 4
FE 03 C8 14 09 E8 Main Video 5 Main Zone Source Video 5

RSX 1058 HEX Command Command Description
FE 03 C8 14 0A E9 Main Power Main Zone Power Toggle
FE 03 C8 14 1E FD Main Mute Main Zone Mute
FE 03 C8 14 6C 4B Main Mute On Main Zone Mute On
FE 03 C8 14 6D 4C Main Mute Off Main Zone Mute Off
Table 4: Type 15 Record Source Command List
RSX 1058 HEX Command Command Description
FE 03 C8 15 02 E2 Record CD Record Source CD
FE 03 C8 15 03 E3 Record Tuner Record Source Tuner
FE 03 C8 15 04 E4 Record Tape Record Source Tape
FE 03 C8 15 05 E5 Record Video 1 Record Source Video 1
FE 03 C8 15 06 E6 Record Video 2 Record Source Video 2
FE 03 C8 15 07 E7 Record Video 3 Record Source Video 3
FE 03 C8 15 08 E8 Record Video 4 Record Source Video 4
FE 03 C8 15 09 E9 Record Video 5 Record Source Video 5
FE 03 C8 15 6B 4B Record Source Record Source
Table 5: Type 16 Zone 2 Command List
RSX 1058 HEX Command Command Description
FE 03 C8 16 00 E1 Vol+ Zone 2 Volume Up
FE 03 C8 16 01 E2 Vol- Zone 2 Volume Down
FE 03 C8 16 02 E3 Zone 2 CD Zone 2 Source CD
FE 03 C8 16 03 E4 Zone 2 Tuner Zone 2 Source Tuner
FE 03 C8 16 04 E5 Zone 2 Tape Zone 2 Source Tape
FE 03 C8 16 05 E6 Zone 2 Video 1 Zone 2 Source Video 1
FE 03 C8 16 06 E7 Zone 2 Video 2 Zone 2 Source Video 2
FE 03 C8 16 07 E8 Zone 2 Video 3 Zone 2 Source Video 3
FE 03 C8 16 08 E9 Zone 2 Video 4 Zone 2 Source Video 4
FE 03 C8 16 09 EA Zone 2 Video 5 Zone 2 Source Video 5
FE 03 C8 16 0A EB Zone 2 Power Zone 2 Power Toggle
FE 03 C8 16 1E FF Zone 2 Mute Zone 2 Mute Toggle
FE 03 C8 16 20 01 Zone 2 Tune / Preset Zone 2 Tune / Preset Toggle
FE 03 C8 16 21 02 Zone 2 Preset Scan Zone 2 Preset Scan
FE 03 C8 16 24 05 Zone 2 Band Zone 2 Band
FE 03 C8 16 26 07 Zone 2 FM Mono Zone 2 FM Mono
FE 03 C8 16 28 09 Zone 2 Tune Up Zone 2 Tune Up
FE 03 C8 16 29 0A Zone 2 Tune Down Zone 2 Tune Down
FE 03 C8 16 2A 0B Zone 2 Preset 1 Zone 2 Preset 1
FE 03 C8 16 2B 0C Zone 2 Preset 2 Zone 2 Preset 2
FE 03 C8 16 2C 0D Zone 2 Preset 3 Zone 2 Preset 3
FE 03 C8 16 2D 0E Zone 2 Preset 4 Zone 2 Preset 4
FE 03 C8 16 2E 0F Zone 2 Preset 5 Zone 2 Preset 5
FE 03 C8 16 2F 10 Zone 2 Preset 6 Zone 2 Preset 6
FE 03 C8 16 30 11 Zone 2 Preset 7 Zone 2 Preset 7

RSX 1058 HEX Command Command Description
FE 03 C8 16 31 12 Zone 2 Preset 8 Zone 2 Preset 8
FE 03 C8 16 32 13 Zone 2 Preset 9 Zone 2 Preset 9
FE 03 C8 16 33 14 Zone 2 Preset 0 Zone 2 Preset 0
FE 03 C8 16 4A 2B Zone 2 Power Off Zone 2 Power Off
FE 03 C8 16 4B 2C Zone 2 Power On Zone 2 Power On
FE 03 C8 16 55 36 Zone 2 FM Zone 2 FM
FE 03 C8 16 56 37 Zone 2 AM Zone 2 AM
FE 03 C8 16 6B 4C Zone 2 Source Zone 2 Source
FE 03 C8 16 6C 4D Zone 2 Mute On Zone 2 Mute On
FE 03 C8 16 6D 4E Zone 2 Mute Off Zone 2 Mute Off
FE 03 C8 16 6E 4F Party Mode Party Mode Toggle
FE 03 C8 16 6F 50 Zone 2 Preset Up Zone 2 Tuner Preset Up
FE 03 C8 16 70 51 Zone 2 Preset Down Zone 2 Tuner Preset Down
FE 03 C8 16 71 52 All Zones Off Power Off All Zones
FE 03 C8 16 72 53 Zone 2 Frequency Up Zone 2 Tuner Frequency Up
FE 03 C8 16 73 54 Zone 2 Frequency Down Zone 2 Tuner Frequency Down
Table 6: Type 17 Zone 3 Command List
RSX 1058 HEX Command Command Description
FE 03 C8 17 00 E2 Vol+ Zone 3 Volume Up
FE 03 C8 17 01 E3 Vol- Zone 3 Volume Down
FE 03 C8 17 02 E4 Zone 3 CD Zone 3 Source CD
FE 03 C8 17 03 E5 Zone 3 Tuner Zone 3 Source Tuner
FE 03 C8 17 04 E6 Zone 3 Tape Zone 3 Source Tape
FE 03 C8 17 05 E7 Zone 3 Video 1 Zone 3 Source Video 1
FE 03 C8 17 06 E8 Zone 3 Video 2 Zone 3 Source Video 2
FE 03 C8 17 07 E9 Zone 3 Video 3 Zone 3 Source Video 3
FE 03 C8 17 08 EA Zone 3 Video 4 Zone 3 Source Video 4
FE 03 C8 17 09 EB Zone 3 Video 5 Zone 3 Source Video 5
FE 03 C8 17 0A EC Zone 3 Power Zone 3 Power Toggle
FE 03 C8 17 1E 00 Zone 3 Mute Zone 3 Mute Toggle
FE 03 C8 17 20 02 Zone 3 Tune / Preset Zone 3 Tune / Preset Toggle
FE 03 C8 17 21 03 Zone 3 Preset Scan Zone 3 Preset Scan
FE 03 C8 17 24 06 Zone 3 Band Zone 3 Band
FE 03 C8 17 26 08 Zone 3 FM Mono Zone 3 FM Mono
FE 03 C8 17 28 0A Zone 3 Tune Up Zone 3 Tune Up
FE 03 C8 17 29 0B Zone 3 Tune Down Zone 3 Tune Down
FE 03 C8 17 2A 0C Zone 3 Preset 1 Zone 3 Preset 1
FE 03 C8 17 2B 0D Zone 3 Preset 2 Zone 3 Preset 2
FE 03 C8 17 2C 0E Zone 3 Preset 3 Zone 3 Preset 3
FE 03 C8 17 2D 0F Zone 3 Preset 4 Zone 3 Preset 4
FE 03 C8 17 2E 10 Zone 3 Preset 5 Zone 3 Preset 5
FE 03 C8 17 2F 11 Zone 3 Preset 6 Zone 3 Preset 6
FE 03 C8 17 30 12 Zone 3 Preset 7 Zone 3 Preset 7
FE 03 C8 17 31 13 Zone 3 Preset 8 Zone 3 Preset 8
FE 03 C8 17 32 14 Zone 3 Preset 9 Zone 3 Preset 9

RSX 1058 HEX Command Command Description
FE 03 C8 17 33 15 Zone 3 Preset 0 Zone 3 Preset 0
FE 03 C8 17 4A 2C Zone 3 Power Off Zone 3 Power Off
FE 03 C8 17 4B 2D Zone 3 Power On Zone 3 Power On
FE 03 C8 17 55 37 Zone 3 FM Zone 3 FM
FE 03 C8 17 56 38 Zone 3 AM Zone 3 AM
FE 03 C8 17 6B 4D Zone 3 Source Zone 3 Source
FE 03 C8 17 6C 4E Zone 3 Mute On Zone 3 Mute On
FE 03 C8 17 6D 4F Zone 3 Mute Off Zone 3 Mute Off
FE 03 C8 17 6E 50 Party Mode Party Mode Toggle
FE 03 C8 17 6F 51 Zone 3 Preset Up Zone 3 Tuner Preset Up
FE 03 C8 17 70 52 Zone 3 Preset Down Zone 3 Tuner Preset Down
FE 03 C8 17 71 53 All Zones Off Power Off All Zones
FE 03 C8 17 72 54 Zone 3 Frequency Up Zone 3 Tuner Frequency Up
FE 03 C8 17 73 55 Zone 3 Frequency Down Zone 3 Tuner Frequency Down
Table 7: Type 18 Zone 4 Command List
RSX 1058 HEX Command Command Description
FE 03 C8 18 00 E3 Vol+ Zone 4 Volume Up
FE 03 C8 18 01 E4 Vol- Zone 4 Volume Down
FE 03 C8 18 02 E5 Zone 4 CD Zone 4 Source CD
FE 03 C8 18 03 E6 Zone 4 Tuner Zone 4 Source Tuner
FE 03 C8 18 04 E7 Zone 4 Tape Zone 4 Source Tape
FE 03 C8 18 05 E8 Zone 4 Video 1 Zone 4 Source Video 1
FE 03 C8 18 06 E9 Zone 4 Video 2 Zone 4 Source Video 2
FE 03 C8 18 07 EA Zone 4 Video 3 Zone 4 Source Video 3
FE 03 C8 18 08 EB Zone 4 Video 4 Zone 4 Source Video 4
FE 03 C8 18 09 EC Zone 4 Video 5 Zone 4 Source Video 5
FE 03 C8 18 0A ED Zone 4 Power Zone 4 Power Toggle
FE 03 C8 18 1E 01 Zone 4 Mute Zone 4 Mute Toggle
FE 03 C8 18 20 03 Zone 4 Tune / Preset Zone 4 Tune / Preset Toggle
FE 03 C8 18 21 04 Zone 4 Preset Scan Zone 4 Preset Scan
FE 03 C8 18 24 07 Zone 4 Band Zone 4 Band
FE 03 C8 18 26 09 Zone 4 FM Mono Zone 4 FM Mono
FE 03 C8 18 28 0B Zone 4 Tune Up Zone 4 Tune Up
FE 03 C8 18 29 0C Zone 4 Tune Down Zone 4 Tune Down
FE 03 C8 18 2A 0D Zone 4 Preset 1 Zone 4 Preset 1
FE 03 C8 18 2B 0E Zone 4 Preset 2 Zone 4 Preset 2
FE 03 C8 18 2C 0F Zone 4 Preset 3 Zone 4 Preset 3
FE 03 C8 18 2D 10 Zone 4 Preset 4 Zone 4 Preset 4
FE 03 C8 18 2E 11 Zone 4 Preset 5 Zone 4 Preset 5
FE 03 C8 18 2F 12 Zone 4 Preset 6 Zone 4 Preset 6
FE 03 C8 18 30 13 Zone 4 Preset 7 Zone 4 Preset 7
FE 03 C8 18 31 14 Zone 4 Preset 8 Zone 4 Preset 8
FE 03 C8 18 32 15 Zone 4 Preset 9 Zone 4 Preset 9
FE 03 C8 18 33 16 Zone 4 Preset 0 Zone 4 Preset 0
FE 03 C8 18 4A 2D Zone 4 Power Off Zone 4 Power Off
FE 03 C8 18 4B 2E Zone 4 Power On Zone 4 Power On

RSX 1058 HEX Command Command Description
FE 03 C8 18 55 38 Zone 4 FM Zone 4 FM
FE 03 C8 18 56 39 Zone 4 AM Zone 4 AM
FE 03 C8 18 6B 4E Zone 4 Source Zone 4 Source
FE 03 C8 18 6C 4F Zone 4 Mute On Zone 4 Mute On
FE 03 C8 18 6D 50 Zone 4 Mute Off Zone 4 Mute Off
FE 03 C8 18 6E 51 Party Mode Party Mode Toggle
FE 03 C8 18 6F 52 Zone 4 Preset Up Zone 4 Tuner Preset Up
FE 03 C8 18 70 53 Zone 4 Preset Down Zone 4 Tuner Preset Down
FE 03 C8 18 71 54 All Zones Off Power Off All Zones
FE 03 C8 18 72 55 Zone 4 Frequency Up Zone 4 Tuner Frequency Up
FE 03 C8 18 73 56 Zone 4 Frequency Down Zone 4 Tuner Frequency Down
Table 8: Type 30 Volume Direct Command List
RSX 1058 HEX Command Command Description
FE 03 C8 30 00 FB Volume Min Volume Min
FE 03 C8 30 01 FC Volume 1 Volume 1
FE 03 C8 30 02 FD Volume 2 Volume 2
FE 03 C8 30 03 FE Volume 3 Volume 3
FE 03 C8 30 04 FF Volume 4 Volume 4
FE 03 C8 30 05 00 Volume 5 Volume 5
FE 03 C8 30 06 01 Volume 6 Volume 6
FE 03 C8 30 07 02 Volume 7 Volume 7
FE 03 C8 30 08 03 Volume 8 Volume 8
FE 03 C8 30 09 04 Volume 9 Volume 9
FE 03 C8 30 0A 05 Volume 10 Volume 10
FE 03 C8 30 0B 06 Volume 11 Volume 11
FE 03 C8 30 0C 07 Volume 12 Volume 12
FE 03 C8 30 0D 08 Volume 13 Volume 13
FE 03 C8 30 0E 09 Volume 14 Volume 14
FE 03 C8 30 0F 0A Volume 15 Volume 15
FE 03 C8 30 10 0B Volume 16 Volume 16
FE 03 C8 30 20 1B Volume 32 Volume 32
FE 03 C8 30 30 2B Volume 48 Volume 48
FE 03 C8 30 40 3B Volume 64 Volume 64
FE 03 C8 30 50 4B Volume 80 Volume 80
FE 03 C8 30 5F 5A Volume 95 Volume 95
FE 03 C8 30 60 5B Volume Max Volume Max
Table 9: Commands Sent with exceptions or modifications required
RSX 1058 HEX Command Expected Command
FE 03 C8 30 02 FD FE 03 C8 30 02 FD 00 Volume 2
FE 03 C8 30 03 FE FE 03 C8 30 03 FD 01 Volume 3
The table above list commands with exceptions. To keep the RSX 1058 from encountering the
start byte FE in any position other than as the start byte, any occurrence of the bytes FE or FD in
the command string must be converted to either FD 00 (for FD) or FD 01 (for FE). This will allow
the string to pass while masking any occurrence of the byte FE except as the start byte.

Table 10: Type 32 Zone 2 Volume Direct Command List
RSX 1058 HEX Command Command Description
FE 03 C8 32 00 FD Zone 2 Volume Min Zone 2 Volume Min
FE 03 C8 32 01 FE Zone 2 Volume 1 Zone 2 Volume 1
FE 03 C8 32 02 FF Zone 2 Volume 2 Zone 2 Volume 2
FE 03 C8 32 03 00 Zone 2 Volume 3 Zone 2 Volume 3
FE 03 C8 32 04 01 Zone 2 Volume 4 Zone 2 Volume 4
FE 03 C8 32 05 02 Zone 2 Volume 5 Zone 2 Volume 5
FE 03 C8 32 06 03 Zone 2 Volume 6 Zone 2 Volume 6
FE 03 C8 32 07 04 Zone 2 Volume 7 Zone 2 Volume 7
FE 03 C8 32 08 05 Zone 2 Volume 8 Zone 2 Volume 8
FE 03 C8 32 09 06 Zone 2 Volume 9 Zone 2 Volume 9
FE 03 C8 32 0A 07 Zone 2 Volume 10 Zone 2 Volume 10
FE 03 C8 32 0B 08 Zone 2 Volume 11 Zone 2 Volume 11
FE 03 C8 32 0C 09 Zone 2 Volume 12 Zone 2 Volume 12
FE 03 C8 32 0D 0A Zone 2 Volume 13 Zone 2 Volume 13
FE 03 C8 32 0E 0B Zone 2 Volume 14 Zone 2 Volume 14
FE 03 C8 32 0F 0C Zone 2 Volume 15 Zone 2 Volume 15
FE 03 C8 32 10 0D Zone 2 Volume 16 Zone 2 Volume 16
FE 03 C8 32 20 1D Zone 2 Volume 32 Zone 2 Volume 32
FE 03 C8 32 30 2D Zone 2 Volume 48 Zone 2 Volume 48
FE 03 C8 32 40 3D Zone 2 Volume 64 Zone 2 Volume 64
FE 03 C8 32 50 4D Zone 2 Volume 80 Zone 2 Volume 80
FE 03 C8 32 5F 56 Zone 2 Volume 95 Zone 2 Volume 95
FE 03 C8 32 60 57 Zone 2 Volume Max Zone 2 Volume Max
Table 11: Commands Sent with exceptions or modifications required
RSX 1058 HEX Command Expected Command
FE 03 C8 32 00 FD FE 03 C8 32 01 FD 00 Zone 2 Volume MIN
FE 03 C8 32 01 FE FE 03 C8 32 02 FD 01 Zone 2 Volume 1
The table above list commands with exceptions. To keep the RSX 1058 from encountering the
start byte FE in any position other than as the start byte, any occurrence of the bytes FE or FD in
the command string must be converted to either FD 00 (for FD) or FD 01 (for FE). This will allow
the string to pass while masking any occurrence of the byte FE except as the start byte.
Table 12: Type 33 Zone 3 Volume Direct Command List
RSX 1058 HEX Command Command Description
FE 03 C8 33 00 FE Zone 3 Volume Min Zone 3 Volume Min
FE 03 C8 33 01 FF Zone 3 Volume 1 Zone 3 Volume 1
FE 03 C8 33 02 00 Zone 3 Volume 2 Zone 3 Volume 2
FE 03 C8 33 03 01 Zone 3 Volume 3 Zone 3 Volume 3
FE 03 C8 33 04 02 Zone 3 Volume 4 Zone 3 Volume 4
FE 03 C8 33 05 03 Zone 3 Volume 5 Zone 3 Volume 5
FE 03 C8 33 06 04 Zone 3 Volume 6 Zone 3 Volume 6
FE 03 C8 33 07 05 Zone 3 Volume 7 Zone 3 Volume 7
FE 03 C8 33 08 06 Zone 3 Volume 8 Zone 3 Volume 8

RSX 1058 HEX Command Expected Command
FE 03 C8 33 09 07 Zone 3 Volume 9 Zone 3 Volume 9
FE 03 C8 33 0A 08 Zone 3 Volume 10 Zone 3 Volume 10
FE 03 C8 33 0B 09 Zone 3 Volume 11 Zone 3 Volume 11
FE 03 C8 33 0C 0A Zone 3 Volume 12 Zone 3 Volume 12
FE 03 C8 33 0D 0B Zone 3 Volume 13 Zone 3 Volume 13
FE 03 C8 33 0E 0C Zone 3 Volume 14 Zone 3 Volume 14
FE 03 C8 33 0F 0D Zone 3 Volume 15 Zone 3 Volume 15
FE 03 C8 33 10 0E Zone 3 Volume 16 Zone 3 Volume 16
FE 03 C8 33 20 1E Zone 3 Volume 32 Zone 3 Volume 32
FE 03 C8 33 30 2E Zone 3 Volume 48 Zone 3 Volume 48
FE 03 C8 33 40 3E Zone 3 Volume 64 Zone 3 Volume 64
FE 03 C8 33 50 4E Zone 3 Volume 80 Zone 3 Volume 80
FE 03 C8 33 5F 57 Zone 3 Volume 95 Zone 3 Volume 95
FE 03 C8 33 60 58 Zone 3 Volume Max Zone 3 Volume Max
Table 13: Commands Sent with exceptions or modifications required
RSX 1058 HEX Command Expected Command
FE 03 C8 33 00 FE FE 03 C8 33 01 FD 01 Zone 3 Volume MIN
The table above list commands with exceptions. To keep the RSX 1058 from encountering the
start byte FE in any position other than as the start byte, any occurrence of the bytes FE or FD in
the command string must be converted to either FD 00 (for FD) or FD 01 (for FE). This will allow
the string to pass while masking any occurrence of the byte FE except as the start byte.
Table 14: Type 34 Zone 4 Volume Direct Command List
RSX 1058 HEX Command Command Description
FE 03 C8 34 00 FF Zone 4 Volume Min Zone 4 Volume Min
FE 03 C8 34 01 00 Zone 4 Volume 1 Zone 4 Volume 1
FE 03 C8 34 02 01 Zone 4 Volume 2 Zone 4 Volume 2
FE 03 C8 34 03 02 Zone 4 Volume 3 Zone 4 Volume 3
FE 03 C8 34 04 03 Zone 4 Volume 4 Zone 4 Volume 4
FE 03 C8 34 05 04 Zone 4 Volume 5 Zone 4 Volume 5
FE 03 C8 34 06 05 Zone 4 Volume 6 Zone 4 Volume 6
FE 03 C8 34 07 06 Zone 4 Volume 7 Zone 4 Volume 7
FE 03 C8 34 08 07 Zone 4 Volume 8 Zone 4 Volume 8
FE 03 C8 34 09 08 Zone 4 Volume 9 Zone 4 Volume 9
FE 03 C8 34 0A 09 Zone 4 Volume 10 Zone 4 Volume 10
FE 03 C8 34 0B 0A Zone 4 Volume 11 Zone 4 Volume 11
FE 03 C8 34 0C 0B Zone 4 Volume 12 Zone 4 Volume 12
FE 03 C8 34 0D 0C Zone 4 Volume 13 Zone 4 Volume 13
FE 03 C8 34 0E 0D Zone 4 Volume 14 Zone 4 Volume 14
FE 03 C8 34 0F 0E Zone 4 Volume 15 Zone 4 Volume 15
FE 03 C8 34 10 0F Zone 4 Volume 16 Zone 4 Volume 16
FE 03 C8 34 20 1F Zone 4 Volume 32 Zone 4 Volume 32
FE 03 C8 34 30 2F Zone 4 Volume 48 Zone 4 Volume 48
FE 03 C8 34 40 3F Zone 4 Volume 64 Zone 4 Volume 64
FE 03 C8 34 50 4F Zone 4 Volume 80 Zone 4 Volume 80
