Rotel RSDX-02 User manual

Technical
Manual
DVD AUDIO SURROUND RECEIVER
RSDX-02
Table of Contents
Specification......................................1
Parts List...........................................2~19
Trouble Reference, Update Procedure...20~24 PCB Assembly..................................25~29
Schematic Diagram ..........................30~43
SHINSEN-BLD. 4F 10-10 SHINSEN-CHO, SHIBUYA-KU,
TOKYO 150-0045, JAPAN
Serial. NO.
Beginning
®
Quality Uncompromised
Y-374A-0403/pdf
THE ROTEL CO., LTD.
Specifications
Amplifier
Output Power, Stero OIperation:
80 W per ch, min. RMS, 8 ohms, 40 Hz – 20 kHz
with no more than 0.8% total harmonic distortion.
Output Power, Surround operation:r
80 W per ch, min. RMS, 8 ohms at 1 kHz, with no
more than 0.8% total harmonic distortion.
Audio
Audio Input Sensitivity/Impedance (1 kHz):
TV, TAPE/CDR, DBS, VCR: 240mV/47kohm
Audio Input (DIGITAL IN):
Coaxial: 0.5 V(p-p)/75 ohms
Optical: –21 dBm to –15 dBm (660 nm ±30 nm)
Digital formats:
Linear PCM, Dolby Digital, and DTS (with sampling
frequency–32 kHz, 44.1 kHz, 48 kHz)
Signal-to-Noise Ratio (’66 IHF/’78 IHF):
TV, TAPE/CDR, DBS, VCR: 87dB/67dB
Frequency Response:
TV, TAPE/CDR, DBS, VCR: 20 Hz to 20 kHz (±1 dB)
Tone Control:
Bass (100 Hz): ±10 dB
Treble (10 kHz): ±10 dB
Video
Video Input Sensitivity / Impedance (1kHz):
Composite video: 1 V(p-p)/75 ohm
S-Video (Y:luminance): 1 V(p-p)/75 ohm
S-Video (C:chrominance): 0.286 V(p-p)/75 ohm
Video Output Level / Impedance (1 kHz):
Composite video:1 V(p-p)/75 ohm
S-video (Y:luminance):1 V(p-p)/75 ohm
S-video (C:chrominance): 0.286 V(p-p)/75 ohm
Component video (Y): 1.0 V(p-p)/75 ohm
Component video (PB/PR): 0.7 V(p-p)/75 ohm
Color System:
NTSC or PAL
Horizontal Resolution:
500 lines or more
Signal-to-Noise Ratio (S/N):
63 dB
Synchronize:
Negative
FM tuner (IHF)
Tuning Range:
87.5 MHz to 108.0 MHz
AM tuner
Tuning Range:
530 kHz to 1 710 kHz
General
Power Requirements:
US version : AC 120 V , 60 Hz
EU version : AC 230 V , 50 Hz
Power Consumption:
US version : 200 W
EU version : 180 W
2 W (in standby mode)
Dimensions (W x H x D):
435 mm x 118 mm x 415 mm
(17 3/16 in. x 4 5/8 in. x 16 3/8 in.)
Weight:
9.6 kg (21.2 lbs)
(EU)

VIDEO OUT SELECTOR
SUBWOOFER OUT
TV
OUT OUT
IN IN IN IN
DBSTAPE/CDR
LEFT
RIGHT
VCR
DBS
IN OUT VCR
S-VIDEO
IN MONITOR
OUT
YP B
DVD COMPONENT VIDEO OUT
P R
DBS
IN OUT VCR IN MONITOR OUT
VIDEO
AUDIO
AM LOOP
ANTENNA
AM EXT
FM 75
COAXIAL
PAL NTSC
DIGITAL IN
DIGITAL 1
(DBS) DIGITAL 2 (TV)
DIGITAL OUT
PCM/STREAM
FRONT SPEAKER
RIGHT LEFT
SURROUND SPEAKER
RIGHT LEFT
CENTER SPEAKER
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
DVD RECEIVER
MODEL NO. RSDX-02
POWER CONSUMPTION: 180W
Manufactured under license from Dolby Laboratories.
"Dolby", "Pro Logic", "MLP Lossless", and the double-D
symbol are trademarks of Dolby Laboratories.
SPEAKER IMPEDANCE: 8 ~ 16 OHMS
Apparatus Claims of U.S.
Patent Nos. 4,631,603,
4,577,216, 4,819,098, and
4,907,093, licensed for
limited viewing uses only.
THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. OPERATION IS SUBJECT
TO THE FOLLOWING TWO CONDITIONS: (1) THIS DEVICE MAY NOT CAUSE HARMFUL
INTERFERENCE, AND (2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED,
INCLUDING INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION.
PRODUCT COMPLIES WITH DHHS RULES 21 CFR
SUBCHAPTER JIN EFFECT AT DATE OF MANUFACTURE.
Manufactured under license from Digital
Theater Systems, Inc. US Pat. No. 5,451,942,
5,956674, 5,974,380, 5,978,762, and other
world-wide patents issued and pending.
"DTS" and "DTS Digital Surround" are
registered trademarks of Digital Theater
Systems, Inc. Copyright 1996, 2000 Digital
Theater Systems, Inc. All rights reserved.
AVIS:
RISQUE DE CHOC ELECTRIQUE –NE PAS OUVRIR
WARNING: SHOCK HAZARD DO NOT OPEN
RSDX-02
STANDBY
MODE
REC MODE
ON/OFFAG/DG
ATT.
AUDIO
DVD MEMORY
CONTROL
ADJUSTSETTING
FM/AMTAPE/CDR
SOURCE NAME
TVVCRDBSDVD
MASTER VOLUME
INPUT SURROUND
STOP PAUSEPLAYTRACKOPN/CLS
Appearance
RSDX-02 US version
SUBWOOFER OUT
OUT IN
TAPE/CDR
AV IN/OUT
LEFT
RIGHT
TV
ANTENNA
AV IN
AM LOOP
AM EXT
FM 75
COAXIAL
RGB Y/C
DIGITAL IN
DIGITAL 1
(STB) DIGITAL 2 (TV)
DIGITAL OUT
PCM/STREAM
FRONT SPEAKER
RIGHT LEFT
SURROUND SPEAKER
RIGHT LEFT
CENTER SPEAKER
VCR STB
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
DVD RECEIVER
MODEL NO. RSDX-02
POWER CONSUMPTION: 180W
Manufactured under license from Dolby Laboratories.
"Dolby", "Pro Logic", "MLP Lossless", and the double-D
symbol are trademarks of Dolby Laboratories.
SPEAKER IMPEDANCE: 8 ~ 16 OHMS
Apparatus Claims of U.S.
Patent Nos. 4,631,603,
4,577,216, 4,819,098, and
4,907,093, licensed for
limited viewing uses only.
THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. OPERATION IS SUBJECT
TO THE FOLLOWING TWO CONDITIONS: (1) THIS DEVICE MAY NOT CAUSE HARMFUL
INTERFERENCE, AND (2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED,
INCLUDING INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION.
PRODUCT COMPLIES WITH DHHS RULES 21 CFR
SUBCHAPTER JIN EFFECT AT DATE OF MANUFACTURE.
Manufactured under license from Digital
Theater Systems, Inc. US Pat. No. 5,451,942,
5,956674, 5,974,380, 5,978,762, and other
world-wide patents issued and pending.
"DTS" and "DTS Digital Surround" are
registered trademarks of Digital Theater
Systems, Inc. Copyright 1996, 2000 Digital
Theater Systems, Inc. All rights reserved.
AVIS:
RISQUE DE CHOC ELECTRIQUE –NE PAS OUVRIR
WARNING: SHOCK HAZARD DO NOT OPEN
RSDX-02
STANDBY
MODE
REC MODE
ON/OFFAG/DG
ATT.
AUDIO
DVD MEMORY
CONTROL
ADJUSTSETTING
FM/AM TV DIRECTTAPE/CDR
SOURCE NAME
TVVCRSTBDVD
MASTER VOLUME
INPUT SURROUND
STOP PAUSEPLAYTRACKOPN/CLS
RSDX-02 EU version
RSDX-02
2

Amp. board
 Symbol No. PartNo.Part Name Description
 PW101 QUB112-30PPPP SIN TWIST WIRE
 PW102 QUB111-32PPPP SIN TWIST WIRE
 PW103 QUB116-28PPPP SIN TWIST WIRE
PW201 QUB110-24PPDM SIN TWIST WIRE
 IC201 JCV8007 IC
 IC202 JCV8008 IC
Q101 KRC105M-T DIGI TRANSISTOR
 Q103 KTC3203/OY/-T TRANSISTOR
 Q121 KTA1046/Y/ TRANSISTOR
Q122 KTC3200/GL/-T TRANSISTOR
Q231 KTC3200/GL/-T TRANSISTOR
Q232 KTC3200/GL/-T TRANSISTOR
Q271 KTC3200/GL/-T TRANSISTOR
Q272 KTA1268/GL/-T TRANSISTOR
Q273 KTC3199/GL/-T TRANSISTOR
Q285 KTA1268/GL/-T TRANSISTOR
Q291 KTC3200/GL/-T TRANSISTOR
Q292 KTA1268/GL/-T TRANSISTOR
Q293 KTC3199/GL/-T TRANSISTOR
Q1231 KTC3200/GL/-T TRANSISTOR
Q1232 KTC3200/GL/-T TRANSISTOR
Q2231 KTC3200/GL/-T TRANSISTOR
 D101 11ES2-T4 DIODE
 D102 11ES2-T4 DIODE
 D103 11ES2-T4 DIODE
 D104 11ES2-T4 DIODE
D105 1SS119-041-T2 DIODE
D108 1SS119-041-T2 DIODE
D109 MTZJ6.8C-T2 Z DIODE
 D111 30DF2-FC DIODE
 D112 30DF2-FC DIODE
 D113 30DF2-FC DIODE
 D114 30DF2-FC DIODE
 D115 30DF2-FC DIODE
 D116 30DF2-FC DIODE
 D117 30DF2-FC DIODE
 D118 30DF2-FC DIODE
 D119 11ES2-T4 DIODE
 D120 11ES2-T4 DIODE
D121 MTZJ30C-T2 Z DIODE
D122 MTZJ6.2C-T2 Z DIODE
D123 1SS119-041-T2 DIODE
D124 1SS119-041-T2 DIODE
D221 MTZJ15C-T2 Z DIODE
D222 MTZJ15C-T2 Z DIODE
D229 1SS119-041-T2 DIODE
D230 1SS119-041-T2 DIODE
D261 1SS119-041-T2 DIODE
D262 1SS119-041-T2 DIODE
D271 1SS119-041-T2 DIODE
D293 1SS119-041-T2 DIODE
D1221 MTZJ15C-T2 Z DIODE
D1222 MTZJ15C-T2 Z DIODE
D1229 1SS119-041-T2 DIODE
D1230 1SS119-041-T2 DIODE
D1261 1SS119-041-T2 DIODE
D2229 1SS119-041-T2 DIODE
D2261 1SS119-041-T2 DIODE
C101 QFLC2AJ-472Z M CAPACITOR 4700pF 100V J
C102 QETN1EM-477Z E CAPACITOR 470uF 25V M
 C103 QCZ9104-472 C CAPACITOR 4700pF
C104 QETN1CM-477Z E CAPACITOR 470uF 16V M
C109 QFZ9076-104Z MM CAPACITOR 0.1uF
C110 QCE22HP-103 C CAPACITOR 0.01uF 500V P
C111 QFZ9076-104Z MM CAPACITOR 0.1uF
C112 QCE22HP-103 C CAPACITOR 0.01uF 500V P
C113 QCE22HP-103 C CAPACITOR 0.01uF 500V P
C115 QFZ9076-104Z MM CAPACITOR 0.1uF
C116 QCE22HP-103 C CAPACITOR 0.01uF 500V P
C117 QCE22HP-103 C CAPACITOR 0.01uF 500V P
C119 QFLC1HJ-473Z M CAPACITOR 0.047uF 50V J
C120 QFLC1HJ-473Z M CAPACITOR 0.047uF 50V J
C121 QETN2AM-107Z E CAPACITOR 100uF 100V M
C122 QETN1HM-476Z E CAPACITOR 47uF 50V M
C123 QEKC1HM-105Z E CAPACITOR 1uF 50V M
C200 QCZ0202-155Z C CAPACITOR 1.5uF 25V Z
C201 QFLC1HJ-471Z M CAPACITOR 470pF 50V J
C202 QFLC1HJ-471Z M CAPACITOR 470pF 50V J
C203 QTE1H06-475Z E CAPACITOR 4.7uF 50V
C204 QTE1H06-475Z E CAPACITOR 4.7uF 50V
C205 QEKC1AM-107Z E CAPACITOR 100uF 10V M
C206 QEKC1AM-107Z E CAPACITOR 100uF 10V M
C207 QCS31HJ-3R0Z C CAPACITOR 3pF 50V J
C208 QCS31HJ-3R0Z C CAPACITOR 3pF 50V J
C209 QDVB1EZ-103Y C CAPACITOR 0.01uF 25V Z
C210 QDVB1EZ-103Y C CAPACITOR 0.01uF 25V Z
C211 QEZ0588-688 E CAPACITOR 6800uF
C212 QEZ0588-688 E CAPACITOR 6800uF
C213 QEZ0589-478 E CAPACITER 4700uF
C214 QEZ0589-478 E CAPACITER 4700uF
C221 QETN2AM-107Z E CAPACITOR 100uF 100V M
C222 QETN2AM-107Z E CAPACITOR 100uF 100V M
C223 QCS31HJ-221Z C CAPACITOR 220pF 50V J
C224 QCS31HJ-221Z C CAPACITOR 220pF 50V J
C231 QCBB1HK-222Y C CAPACITOR 2200pF 50V K
C232 QCBB1HK-222Y C CAPACITOR 2200pF 50V K
C241 QFLC1HJ-473Z M CAPACITOR 0.047uF 50V J
C242 QFLC1HJ-473Z M CAPACITOR 0.047uF 50V J
C243 QFLC1HJ-473Z M CAPACITOR 0.047uF 50V J
C244 QFLC1HJ-473Z M CAPACITOR 0.047uF 50V J
C245 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J
C246 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J
C247 QCS32HJ-221Z C CAPACITOR 220pF 500V J
C248 QCS32HJ-221Z C CAPACITOR 220pF 500V J
C249 QCS32HJ-221Z C CAPACITOR 220pF 500V J
C250 QCS32HJ-221Z C CAPACITOR 220pF 500V J
C251 QCS32HJ-221Z C CAPACITOR 220pF 500V J
C252 QCS32HJ-221Z C CAPACITOR 220pF 500V J
C253 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J
C254 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J
C261 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J
C262 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J
C263 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J
C264 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J
C265 QCS32HJ-221Z C CAPACITOR 220pF 500V J
C266 QCS32HJ-221Z C CAPACITOR 220pF 500V J
C267 QCS32HJ-221Z C CAPACITOR 220pF 500V J
C268 QCS32HJ-221Z C CAPACITOR 220pF 500V J
C269 QCS32HJ-221Z C CAPACITOR 220pF 500V J
C270 QCS32HJ-221Z C CAPACITOR 220pF 500V J
C271 QEKC1EM-106Z E CAPACITOR 10uF 25V M
C272 QEKC1CM-476Z E CAPACITOR 47uF 16V M
C285 QETN2AM-106Z E CAPACITOR 10uF 100V M
C291 QEKC1EM-106Z E CAPACITOR 10uF 25V M
C292 QEKC1CM-476Z E CAPACITOR 47uF 16V M
C1201 QFLC1HJ-471Z M CAPACITOR 470pF 50V J
C1202 QFLC1HJ-471Z M CAPACITOR 470pF 50V J
C1203 QTE1H06-475Z E CAPACITOR 4.7uF 50V
C1204 QTE1H06-475Z E CAPACITOR 4.7uF 50V
C1205 QEKC1AM-107Z E CAPACITOR 100uF 10V M
C1206 QEKC1AM-107Z E CAPACITOR 100uF 10V M
C1207 QCS31HJ-3R0Z C CAPACITOR 3pF 50V J
C1208 QCS31HJ-3R0Z C CAPACITOR 3pF 50V J
C1221 QETN2AM-107Z E CAPACITOR 100uF 100V M
C1222 QETN2AM-107Z E CAPACITOR 100uF 100V M
C1223 QCS31HJ-221Z C CAPACITOR 220pF 50V J
C1224 QCS31HJ-221Z C CAPACITOR 220pF 50V J
C1241 QFLC1HJ-473Z M CAPACITOR 0.047uF 50V J
C1242 QFLC1HJ-473Z M CAPACITOR 0.047uF 50V J
C1243 QFLC1HJ-473Z M CAPACITOR 0.047uF 50V J
C1244 QFLC1HJ-473Z M CAPACITOR 0.047uF 50V J
C1245 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J
 Symbol No. Part No. Part Name Description
Parts List 1/15
LVA10431
RSDX-02E
3

C1246 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J
C1247 QCS32HJ-221Z C CAPACITOR 220pF 500V J
C1248 QCS32HJ-221Z C CAPACITOR 220pF 500V J
C1249 QCS32HJ-221Z C CAPACITOR 220pF 500V J
C1250 QCS32HJ-221Z C CAPACITOR 220pF 500V J
C1250 QCS32HJ-470Z C CAPACITOR 47pF 500V J
C1251 QCS32HJ-221Z C CAPACITOR 220pF 500V J
C1252 QCS32HJ-221Z C CAPACITOR 220pF 500V J
C1252 QCS32HJ-470Z C CAPACITOR 47pF 500V J
C1253 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J
C1254 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J
C2201 QFLC1HJ-471Z M CAPACITOR 470pF 50V J
C2203 QTE1H06-475Z E CAPACITOR 4.7uF 50V
C2205 QEKC1AM-107Z E CAPACITOR 100uF 10V M
C2207 QCS31HJ-3R0Z C CAPACITOR 3pF 50V J
C2223 QCS31HJ-221Z C CAPACITOR 220pF 50V J
C2241 QFLC1HJ-473Z M CAPACITOR 0.047uF 50V J
C2243 QFLC1HJ-473Z M CAPACITOR 0.047uF 50V J
C2245 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J
C2247 QCS32HJ-221Z C CAPACITOR 220pF 500V J
C2249 QCS31HJ-331Z C CAPACITOR 330pF 50V J
C2251 QCS31HJ-331Z C CAPACITOR 330pF 50V J
C2253 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J
 R102 QRJ146J-100X UNF C RESISTOR 10 Ω 1/4W J
 R105 QRJ146J-821X UNF C RESISTOR 820 Ω 1/4W J
 R106 QRJ146J-100X UNF C RESISTOR 10 Ω 1/4W J
 R111 QRJ146J-2R7X UNF C RESISTOR 2.7 Ω 1/4W J
 R121 QRZ9005-100X FUSI RESISTOR 10 Ω
 R122 QRJ146J-682X UNF C RESISTOR 6.8k Ω 1/4W J
 R123 QRJ146J-100X UNF C RESISTOR 10 Ω 1/4W J
 R124 QRE141J-104Y C RESISTOR 100k Ω 1/4W J
 R125 QRJ146J-680X UNF C RESISTOR 68 Ω 1/4W J
 R126 QRJ146J-680X UNF C RESISTOR 68 Ω 1/4W J
R201 QRE141J-102Y C RESISTOR 1k
Ω 1/4W J
R202 QRE141J-102Y C RESISTOR 1k
Ω 1/4W J
R203 QRE141J-563Y C RESISTOR 56k
Ω 1/4W J
R204 QRE141J-563Y C RESISTOR 56k Ω 1/4W J
 R205 QRJ146J-471X UNF C RESISTOR 470 Ω 1/4W J
 R206 QRJ146J-471X UNF C RESISTOR 470 Ω 1/4W J
R207 QRE141J-563Y C RESISTOR 56k Ω 1/4W J
R208 QRE141J-563Y C RESISTOR 56k
Ω 1/4W J
R209 QRE141J-333Y C RESISTOR 33k Ω 1/4W J
 R221 QRJ146J-101X UNF C RESISTOR 100 Ω 1/4W J
 R222 QRJ146J-101X UNF C RESISTOR 100 Ω 1/4W J
 R223 QRL017J-152 OMF RESISTOR 1.5k Ω 1W J
 R224 QRL017J-152 OMF RESISTOR 1.5k Ω 1W J
 R225 QRZ0224-R22 EMIT RESISTOR 0.22 Ω
 R226 QRZ0224-R22 EMIT RESISTOR 0.22 Ω
R227 QRE141J-102Y C RESISTOR 1k Ω 1/4W J
R228 QRE141J-102Y C RESISTOR 1k
Ω 1/4W J
R229 QRE141J-183Y C RESISTOR 18k Ω 1/4W J
R230 QRE141J-183Y C RESISTOR 18k
Ω 1/4W J
R231 QRE141J-473Y C RESISTOR 47k
Ω 1/4W J
R232 QRE141J-473Y C RESISTOR 47k
Ω 1/4W J
 R233 QRJ146J-101X UNF C RESISTOR 100 Ω 1/4W J
 R234 QRJ146J-2R2X UNF C RESISTOR 2.2 Ω 1/4W J
 R235 QRJ146J-2R2X UNF C RESISTOR 2.2 Ω 1/4W J
 R236 QRJ146J-2R2X UNF C RESISTOR 2.2 Ω 1/4W J
 R237 QRJ146J-2R2X UNF C RESISTOR 2.2 Ω 1/4W J
R241 QRJ146J-330X UNF C RESISTOR 33
Ω 1/4W J
R242 QRJ146J-330X UNF C RESISTOR 33
Ω 1/4W J
 R243 QRL027J-100 OMF RESISTOR 10 Ω 2W J
 R244 QRL027J-100 OMF RESISTOR 10 Ω 2W J
 R245 QRJ146J-3R9X UNF C RESISTOR 3.9 Ω 1/4W J
 Symbol No. Part No. Part Name Description
 R246 QRJ146J-3R9X UNF C RESISTOR 3.9 Ω 1/4W J
 R261 QRJ146J-181X UNF C RESISTOR 180 Ω 1/4W J
 R262 QRJ146J-181X UNF C RESISTOR 180 Ω 1/4W J
 R263 QRJ146J-3R9X UNF C RESISTOR 3.9 Ω 1/4W J
 R264 QRJ146J-3R9X UNF C RESISTOR 3.9 Ω 1/4W J
R271 QRE141J-104Y C RESISTOR 100k
Ω 1/4W J
R272 QRE141J-823Y C RESISTOR 82k
Ω 1/4W J
R273 QRE141J-104Y C RESISTOR 100k Ω 1/4W J
R274 QRE141J-104Y C RESISTOR 100k Ω 1/4W J
R275 QRE141J-104Y C RESISTOR 100k Ω 1/4W J
R276 QRE141J-104Y C RESISTOR 100k Ω 1/4W J
R277 QRE141J-104Y C RESISTOR 100k Ω 1/4W J
R278 QRE141J-103Y C RESISTOR 10k Ω 1/4W J
R279 QRE141J-103Y C RESISTOR 10k Ω 1/4W J
R280 QRE141J-101Y C RESISTOR 100 Ω 1/4W J
 R281 QRL027J-471 OMF RESISTOR 470 Ω 2W J
 R282 QRL027J-471 OMF RESISTOR 470 Ω 2W J
R285 QRE141J-103Y C RESISTOR 10k Ω 1/4W J
R286 QRE141J-104Y C RESISTOR 100k Ω 1/4W J
R291 QRE141J-104Y C RESISTOR 100k Ω 1/4W J
R292 QRE141J-104Y C RESISTOR 100k
Ω 1/4W J
R293 QRE141J-103Y C RESISTOR 10k
Ω 1/4W J
R294 QRE141J-103Y C RESISTOR 10k Ω 1/4W J
R295 QRE141J-104Y C RESISTOR 100k Ω 1/4W J
R296 QRE141J-104Y C RESISTOR 100k Ω 1/4W J
R1201 QRE141J-102Y C RESISTOR 1k Ω 1/4W J
R1202 QRE141J-102Y C RESISTOR 1k Ω 1/4W J
R1203 QRE141J-563Y C RESISTOR 56k Ω 1/4W J
R1204 QRE141J-563Y C RESISTOR 56k Ω 1/4W J
 R1205 QRJ146J-391X UNF C RESISTOR 390 Ω 1/4W J
 R1206 QRJ146J-391X UNF C RESISTOR 390 Ω 1/4W J
R1207 QRE141J-563Y C RESISTOR 56k Ω 1/4W J
R1208 QRE141J-563Y C RESISTOR 56k Ω 1/4W J
R1209 QRE141J-333Y C RESISTOR 33k Ω 1/4W J
 R1221 QRJ146J-101X UNF C RESISTOR 100 Ω 1/4W J
 R1222 QRJ146J-101X UNF C RESISTOR 100 Ω 1/4W J
 R1223 QRL017J-152 OMF RESISTOR 1.5k Ω 1W J
 R1224 QRL017J-152 OMF RESISTOR 1.5k Ω 1W J
 R1225 QRZ0224-R22 EMIT RESISTOR 0.22 Ω
 R1226 QRZ0224-R22 EMIT RESISTOR 0.22 Ω
R1227 QRE141J-102Y C RESISTOR 1k Ω 1/4W J
R1228 QRE141J-102Y C RESISTOR 1k Ω 1/4W J
R1229 QRE141J-183Y C RESISTOR 18k Ω 1/4W J
R1230 QRE141J-183Y C RESISTOR 18k Ω 1/4W J
R1231 QRE141J-473Y C RESISTOR 47k Ω 1/4W J
R1232 QRE141J-473Y C RESISTOR 47k Ω 1/4W J
 R1233 QRJ146J-101X UNF C RESISTOR 100 Ω 1/4W J
 R1234 QRJ146J-2R2X UNF C RESISTOR 2.2 Ω 1/4W J
 R1235 QRJ146J-2R2X UNF C RESISTOR 2.2 Ω 1/4W J
 R1236 QRJ146J-2R2X UNF C RESISTOR 2.2 Ω 1/4W J
 R1237 QRJ146J-2R2X UNF C RESISTOR 2.2 Ω 1/4W J
R1241 QRJ146J-330X UNF C RESISTOR 33
Ω 1/4W J
R1242 QRJ146J-330X UNF C RESISTOR 33
Ω 1/4W J
 R1243 QRL027J-100 OMF RESISTOR 10 Ω 2W J
 R1244 QRL027J-100 OMF RESISTOR 10 Ω 2W J
 R1245 QRJ146J-3R9X UNF C RESISTOR 3.9 Ω 1/4W J
 R1246 QRJ146J-3R9X UNF C RESISTOR 3.9 Ω 1/4W J
 R1261 QRJ146J-181X UNF C RESISTOR 180 Ω 1/4W J
R2201 QRE141J-102Y C RESISTOR 1k Ω 1/4W J
R2203 QRE141J-563Y C RESISTOR 56k
Ω 1/4W J
 R2205 QRJ146J-391X UNF C RESISTOR 390 Ω 1/4W J
R2207 QRE141J-563Y C RESISTOR 56k Ω 1/4W J
 R2225 QRZ0224-R22 EMIT RESISTOR 0.22 Ω
R2227 QRE141J-102Y C RESISTOR 1k Ω 1/4W J
R2229 QRE141J-183Y C RESISTOR 18k Ω 1/4W J
R2231 QRE141J-473Y C RESISTOR 47k
Ω 1/4W J
R2241 QRJ146J-330X UNF C RESISTOR 33
Ω 1/4W J
 R2243 QRL027J-100 OMF RESISTOR 10 Ω 2W J
 R2245 QRJ146J-3R9X UNF C RESISTOR 3.9 Ω 1/4W J
 R2261 QRJ146J-181X UNF C RESISTOR 180 Ω 1/4W J
L241 QQLZ005-R45 COIL 0.45uH
L242 QQLZ005-R45 COIL 0.45uH
L243 QQLZ005-R45 COIL 0.45uH
L244 QQLZ005-R45 COIL 0.45uH
L1241 QQLZ005-R45 COIL 0.45uH
L1242 QQLZ005-R45 COIL 0.45uH
L1243 QQLZ005-R45 COIL 0.45uH
 Symbol No. Part No. Part Name Description
Parts List 2/15
RSDX-02E
4

Front board
L1244 QQLZ005-R45 COIL 0.45uH
L2241 QQLZ005-R45 COIL 0.45uH
L2243 QQLZ005-R45 COIL 0.45uH
 T102 QQT0281-002 POWER TRANSF
CN101 QGA7901C1-02 CONNECTOR W-B (1-2)
CN111 QGA3901C1-05 CONNECTOR W-B (1-5)
CN113 QJK012-051700 SIN CR C-B WIRE
CN115 QGF1205C1-10 CONNECTOR FFC/FPC (1-10)
CN201 QGA3901F2-05 CONNECTOR W-B (1-5)
CN202 QGB2510J1-11 CONNECTOR B-B (1-11)
CN203 QGB2510J1-05 CONNECTOR B-B (1-5)
CN204 QGB2510J1-07 CONNECTOR B-B (1-7)
CN213 QGB2510K1-05 CONNECTOR B-B (1-5)
CN214 QGB2510K1-07 CONNECTOR B-B (1-7)
CN222 WJP0040-001A E-SH C WIRE C-B
EP102 QNZ0136-001Z EARTH PLATE
FC100 QNG0020-001Z FUSE CLIP
FC101 QNG0020-001Z FUSE CLIP
FC102 QNG0020-001Z FUSE CLIP
FC103 QNG0020-001Z FUSE CLIP
J201 QNN0545-002 SURROUND JACK
 RY101 QSK0142-001 RELAY
 RY125 QSK0082-001 RELAY
 RY126 QSK0082-001 RELAY
 RY261 QSK0109-001 RELAY
 RY262 QSK0109-001 RELAY
 RY263 QSK0109-001 RELAY
 RY264 QSK0109-001 RELAY
TA101 QNZ0079-001Z TAB
TA102 QNZ0079-001Z TAB
 OT1 QRJ146J-3R9X UNF C RESISTOR 3.9 Ω 1/4W J(x2)
 Symbol No. PartNo.Part Name Description
PW701 QUB220-08HPDM SIN TWIST WIRE
IC701 MN101C35DKF PANEL MICOM
Q700 KRC107S-X DIGI TRANSISTOR
Q701 KRC107S-X DIGI TRANSISTOR
Q702 KRA107S-X DIGI TRANSISTOR
Q703 KRA114S-X TRANSISTOR
Q704 KRA107S-X DIGI TRANSISTOR
Q705 KRA114S-X TRANSISTOR
Q706 KRA107S-X DIGI TRANSISTOR
Q708 KRA107S-X DIGI TRANSISTOR
Q710 KRA107S-X DIGI TRANSISTOR
Q711 KRA107S-X DIGI TRANSISTOR
D703 SLR-342VC-T LED
D704 QLMP-KB49 LED
D705 SLR-342DC-T LED
D706 SLR-342DC-T LED
D708 SLR-342DC-T LED
D710 MA3082/H/-X Z DIODE
D711 MA3082/H/-X Z DIODE
C281 NCB31HK-331X C CAPACITOR 330pF 50V K
C282 NCB31HK-331X C CAPACITOR 330pF 50V K
C283 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C700 QFLC1HJ-124Z M CAPACITOR 0.12uF 50V J
C701 NCB31HK-471X C CAPACITOR 470pF 50V K
C702 NCB31HK-471X C CAPACITOR 470pF 50V K
C703 NCB31HK-471X C CAPACITOR 470pF 50V K
C704 NCB31HK-471X C CAPACITOR 470pF 50V K
C705 NCB31HK-471X C CAPACITOR 470pF 50V K
 Symbol No. PartNo.Part Name Description
C706 NCB31HK-471X C CAPACITOR 470pF 50V K
C708 NCB31HK-223X C CAPACITOR 0.022uF 50V K
C709 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C710 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C711 QEKC0JM-107Z E CAPACITOR 100uF 6.3V M
C712 QCZ0202-155Z C CAPACITOR 1.5uF 25V Z
C713 QEKC1HM-475Z E CAPACITOR 4.7uF 50V M
C714 QEKC1HM-475Z E CAPACITOR 4.7uF 50V M
C715 QEKC1HM-475Z E CAPACITOR 4.7uF 50V M
C717 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C718 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C720 NCB31EK-223X C CAPACITOR 0.022uF 25V K
R287 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R288 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R289 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R667 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R668 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R669 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R701 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R702 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R703 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R704 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R705 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R706 NRSA63J-122X MG RESISTOR 1.2k Ω 1/16W J
R707 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R708 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R709 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R710 NRSA63J-122X MG RESISTOR 1.2k Ω 1/16W J
R711 NRSA63J-152X MG RESISTOR 1.5k Ω 1/16W J
R712 NRSA63J-222X MG RESISTOR 2.2k Ω 1/16W J
R713 NRSA63J-272X MG RESISTOR 2.7k Ω 1/16W J
R714 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R715 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R716 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R717 NRSA63J-122X MG RESISTOR 1.2k Ω 1/16W J
R718 NRSA63J-152X MG RESISTOR 1.5k Ω 1/16W J
R719 NRSA63J-222X MG RESISTOR 2.2k Ω 1/16W J
R720 NRSA63J-272X MG RESISTOR 2.7k Ω 1/16W J
R721 NRSA63J-392X MG RESISTOR 3.9k Ω 1/16W J
R722 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R723 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R724 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R725 NRSA63J-122X MG RESISTOR 1.2k Ω 1/16W J
R726 NRSA63J-152X MG RESISTOR 1.5k Ω 1/16W J
R727 NRSA63J-222X MG RESISTOR 2.2k Ω 1/16W J
R728 NRSA63J-272X MG RESISTOR 2.7k Ω 1/16W J
R729 NRSA63J-392X MG RESISTOR 3.9k Ω 1/16W J
R730 NRSA63J-152X MG RESISTOR 1.5k Ω 1/16W J
R731 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R733 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R734 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R735 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R740 NRSA63J-222X MG RESISTOR 2.2k Ω 1/16W J
R741 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R743 NRSA63J-221X MG RESISTOR 220
Ω 1/16W J
R744 NRSA63J-222X MG RESISTOR 2.2k Ω 1/16W J
R745 NRSA63J-221X MG RESISTOR 220
Ω 1/16W J
R746 NRSA63J-751X MG RESISTOR 750 Ω 1/16W J
R747 NRSA63J-221X MG RESISTOR 220
Ω 1/16W J
R749 NRSA63J-221X MG RESISTOR 220
Ω 1/16W J
R750 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R751 NRSA63J-221X MG RESISTOR 220
Ω 1/16W J
R752 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R753 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R754 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R758 NRSA63J-221X MG RESISTOR 220
Ω 1/16W J
R759 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R1291 NRSA63J-471X MG RESISTOR 470
Ω 1/16W J
R1292 NRSA63J-471X MG RESISTOR 470 Ω 1/16W J
R1701 NRSA63J-221X MG RESISTOR 220
Ω 1/16W J
R1702 NRSA63J-221X MG RESISTOR 220
Ω 1/16W J
R1703 NRSA63J-221X MG RESISTOR 220 Ω 1/16W J
R1704 NRSA63J-221X MG RESISTOR 220
Ω 1/16W J
R1705 NRSA63J-221X MG RESISTOR 220
Ω 1/16W J
R1706 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R1710 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R1712 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
 Symbol No. Part No. Part Name Description
LVA10432
RSDX-02E
Parts List 3/15
5

Main board
R1755 NRSA63J-222X MG RESISTOR 2.2k Ω 1/16W J
R1756 NRSA63J-222X MG RESISTOR 2.2k Ω 1/16W J
R1757 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
L751 NQL114K-470X COIL 47uH K
L752 NQL114K-470X COIL 47uH K
BK701 LV42882-001A FL HOLDER
BK702 LV42881-001A FL HOLDER
CN242 QGB2510K1-11 CONNECTOR B-B (1-11)
CN252 QGB2510K1-11 CONNECTOR B-B (1-11)
CN604 QGB2510K1-13 CONNECTOR B-B (1-13)
CN611 QGB2510K1-13 CONNECTOR B-B (1-13)
CN701 QGF1205F1-13 CONNECTOR FFC/FPC (1-13)
CN703 QGA2001F1-03 CONNECTOR W-B (1-3)
CN713 QJK021-030603 SIN CR C-B WIRE
DI701 QLF0115-001 FL TUBE
EP281 QNZ0136-001Z EARTH PLATE
FS700 E3400-431 SPACER
FW241 QUM214-15DGZ4 PARA RIBON WIRE
FW281 QUM213-18DGZ4 PARA RIBON WIRE
FW701 QUM214-05Z4Z4 PARA RIBON WIRE
FW702 QUM213-08Z4Z4 PARA RIBON WIRE
FW703 QUM212-05Z4Z4 RIBON WIRE
JS701 QSW1017-001 JOG VOLUME
K285 NQR0389-003X FERRITE BEADS
S703 QSW0683-001Z PUSH SW
S704 QSW0683-001Z PUSH SW
S705 QSW0683-001Z PUSH SW
S706 QSW0683-001Z PUSH SW
S707 QSW0683-001Z PUSH SW
S708 QSW0683-001Z PUSH SW
S709 QSW0683-001Z PUSH SW
S710 QSW0683-001Z PUSH SW
S711 QSW0683-001Z PUSH SW
S712 QSW0683-001Z PUSH SW
S713 QSW0683-001Z PUSH SW
S714 QSW0683-001Z PUSH SW
S715 QSW0683-001Z PUSH SW
S716 QSW0683-001Z PUSH SW
S717 QSW0683-001Z PUSH SW
S718 QSW0683-001Z PUSH SW
S719 QSW0683-001Z PUSH SW
S720 QSW0683-001Z PUSH SW
S721 QSW0683-001Z PUSH SW
S722 QSW0683-001Z PUSH SW
S723 QSW0683-001Z PUSH SW
S724 QSW0683-001Z PUSH SW
S725 QSW0683-001Z PUSH SW
 TH291 QAD0125-471 P THERMISTOR 110Åé 470 Ω 16V
X701 QAX0246-001Z C RESONATOR 8.00MHz
 Symbol No. Part No. Part Name Description
 IC191 SI-8033JF IC
 IC192 SI-8050JF-F1 IC
 IC193 SI-8090JF IC
IC301 M61516FP IC
IC302 SAA6588 IC(RDS)
IC303 HA17558AF-X IC
IC401 LA73054-X IC
IC761 MN101CF49K IC(MCU)106
IC761 MN101C49GMM1 IC
IC763 IC-PST9139-T IC
 Q141 2SD2395/EF/ TRANTRANSISTOR
Q142 KRA102S-X DIGI TRANSISTOR
 Symbol No. Part No. Part Name Description
Q143 KRC102S-X DIGI TRANSISTOR
 Q145 2SD2395/EF/ TRANTRANSISTOR
 Q151 2SD2395/EF/ TRANTRANSISTOR
 Q152 2SD2395/EF/ TRANTRANSISTOR
Q153 KRA102S-X DIGI TRANSISTOR
 Q154 2SD2395/EF/ TRANTRANSISTOR
Q155 KRA102S-X DIGI TRANSISTOR
Q156 KRC102S-X DIGI TRANSISTOR
Q157 KRC102S-X DIGI TRANSISTOR
Q158 KRC102S-X DIGI TRANSISTOR
Q159 KRC102S-X DIGI TRANSISTOR
 Q161 2SD2395/EF/ TRANTRANSISTOR
 Q162 KTA1046/Y/ TRANSISTOR
 Q163 KTC3203/OY/-T TRANSISTOR
 Q164 KTA1271/OY/-T TRANSISTOR
 Q165 2SD2395/EF/ TRANTRANSISTOR
 Q171 KTC3203/OY/-T TRANSISTOR
Q172 KRA102S-X DIGI TRANSISTOR
Q173 KRC102S-X DIGI TRANSISTOR
 Q181 2SD2395/EF/ TRANTRANSISTOR
 Q182 2SD2395/EF/ TRANTRANSISTOR
 Q183 2SD2395/EF/ TRANTRANSISTOR
Q191 KRC102S-X DIGI TRANSISTOR
Q192 KRC102S-X DIGI TRANSISTOR
Q193 KRC102S-X DIGI TRANSISTOR
 Q194 KTC3203/OY/-T TRANSISTOR
Q381 2SC3576-JVC-T TRANSISTOR
Q382 2SC3576-JVC-T TRANSISTOR
Q383 2SC3576-JVC-T TRANSISTOR
Q384 2SC3576-JVC-T TRANSISTOR
Q385 2SC3576-JVC-T TRANSISTOR
Q386 KRA104S-X DIGI TRANSISTOR
Q433 KRC107S-X DIGI TRANSISTOR
Q434 KRC102S-X DIGI TRANSISTOR
Q435 KRC102S-X DIGI TRANSISTOR
Q760 KRC105S-X CHIP D.TRANSISTOR
Q761 KTC3199/GL/-T TRANSISTOR
Q762 KTC3199/GL/-T TRANSISTOR
Q763 KTC3199/GL/-T TRANSISTOR
Q764 KTC3199/GL/-T TRANSISTOR
Q765 KRC102S-X DIGI TRANSISTOR
Q766 KRC105S-X CHIP D.TRANSISTOR
Q767 KRC105S-X CHIP D.TRANSISTOR
Q768 KRC105S-X CHIP D.TRANSISTOR
Q769 KRC105S-X CHIP D.TRANSISTOR
Q770 2SD1328/ST/-X TRANSISTOR
Q771 KRC107S-X DIGI TRANSISTOR
Q799 KRC102S-X DIGI TRANSISTOR
Q1381 2SC3576-JVC-T TRANSISTOR
Q1382 2SC3576-JVC-T TRANSISTOR
Q1383 KRA104S-X DIGI TRANSISTOR
D125 11ES2-T4 DIODE
D126 11ES2-T4 DIODE
D127 11ES2-T4 DIODE
D128 MA111-X SI DIODE
 D131 10E2-FD DIODE
 D132 10E2-FD DIODE
 D133 11ES2-T4 DIODE
 D134 11ES2-T4 DIODE
D141 MTZJ5.6C-T2 Z DIODE
D145 MTZJ6.2C-T2 Z DIODE
D151 MTZJ5.6C-T2 Z DIODE
D155 MA111-X SI DIODE
D156 MTZJ16C-T2 Z DIODE
D157 MTZJ13C-T2 Z DIODE
D158 MTZJ10C-T2 Z DIODE
D159 MTZJ7.5C-T2 Z DIODE
D161 MTZJ13C-T2 Z DIODE
D162 MTZJ13C-T2 Z DIODE
D163 MTZJ7.5C-T2 Z DIODE
D164 MTZJ7.5C-T2 Z DIODE
D171 MTZJ11C-T2 Z DIODE
D172 MA111-X SI DIODE
D181 MTZJ13C-T2 Z DIODE
D182 MTZJ5.6C-T2 Z DIODE
D187 MTZJ3.9B-T2 Z DIODE
D188 MTZJ5.6C-T2 Z DIODE
 Symbol No. Part No. Part Name Description
LVA10430
Parts List 4/15
RSDX-02E
6

D189 MTZJ10C-T2 Z DIODE
 D191 SFPB-54-W DIODE
 D192 SFPB-54-W DIODE
 D193 SFPB-54-W DIODE
D194 MTZJ5.6C-T2 Z DIODE
D195 MA111-X SI DIODE
D196 MA111-X SI DIODE
D197 MA111-X SI DIODE
D291 MA111-X SI DIODE
D761 MA111-X SI DIODE
D762 MA111-X SI DIODE
D791 MTZJ6.2C-T2 Z DIODE
D1391 MA111-X SI DIODE
D1392 MTZJ4.7C-T2 Z DIODE
C131 QFLC2AJ-104Z M CAPACITOR 0.1uF 100V J
C132 QFLC2AJ-104Z M CAPACITOR 0.1uF 100V J
C133 QFLC2AJ-104Z M CAPACITOR 0.1uF 100V J
C135 QETM1VM-338 E CAPACITOR 3300uF 35V M
C136 QETM1VM-108 E CAPACITOR 1000uF 35V M
C141 QETN1EM-107Z E CAPACITOR 100uF 25V M
C145 QETN1EM-107Z E CAPACITOR 100uF 25V M
C151 QETN1EM-107Z E CAPACITOR 100uF 25V M
C158 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C159 QETN1HM-106Z E CAPACITOR 10uF 50V M
C161 QETN1EM-107Z E CAPACITOR 100uF 25V M
C162 QEKC1EM-476Z E CAPACITOR 47uF 25V M
C163 QEKC1EM-476Z E CAPACITOR 47uF 25V M
C164 QEKC1EM-476Z E CAPACITOR 47uF 25V M
C171 QETN1EM-107Z E CAPACITOR 100uF 25V M
C181 QETN1CM-477Z E CAPACITOR 470uF 16V M
C182 QEKC1EM-476Z E CAPACITOR 47uF 25V M
C183 NCB31HK-122X C CAPACITOR 1200pF 50V K
C184 NCB31HK-122X C CAPACITOR 1200pF 50V K
C191 QETN1HM-227Z E CAPACITOR 220uF 50V M
C192 QETN1EM-477Z E CAPACITOR 470uF 25V M
C193 QETN1HM-227Z E CAPACITOR 220uF 50V M
C194 QETN1EM-477Z E CAPACITOR 470uF 25V M
C195 QETN1HM-227Z E CAPACITOR 220uF 50V M
C196 QETN1EM-477Z E CAPACITOR 470uF 25V M
C197 QEKC1EM-476Z E CAPACITOR 47uF 25V M
C301 NCB31HK-331X C CAPACITOR 330pF 50V K
C302 NCB31HK-331X C CAPACITOR 330pF 50V K
C305 NCB31HK-331X C CAPACITOR 330pF 50V K
C306 NCB31HK-331X C CAPACITOR 330pF 50V K
C323 NCB31HK-391X C CAPACITOR 390pF 50V K
C324 NCB31HK-391X C CAPACITOR 390pF 50V K
C329 NCB31HK-331X C CAPACITOR 330pF 50V K
C330 NCB31HK-331X C CAPACITOR 330pF 50V K
C341 NCS31HJ-101X C CAPACITOR 100pF 50V J
C343 NCB31HK-562X C CAPACITOR 5600pF 50V K
C344 NCB31HK-562X C CAPACITOR 5600pF 50V K
C351 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C352 NCS31HJ-820X C CAPACITOR 82pF 50V J
C353 NCS31HJ-470X C CAPACITOR 47pF 50V J
C354 QEKC1CM-106Z E CAPACITOR 10uF 16V M
C355 NCB31EK-473X C CAPACITOR 0.047uF 25V K
C356 NCS31HJ-331X C CAPACITOR 330pF 50V J
C357 QEKC1HM-225Z E CAPACITOR 2.2uF 50V M
C358 NCB31HK-561X C CAPACITOR 560pF 50V K
C361 NCB31AK-154X C CAPACITOR 0.15uF 10V K
C362 NCB31AK-154X C CAPACITOR 0.15uF 10V K
C363 NCB31AK-154X C CAPACITOR 0.15uF 10V K
C364 NCB31AK-154X C CAPACITOR 0.15uF 10V K
C365 NCB31HK-272X C CAPACITOR 2700pF 50V K
C366 NCB31HK-272X C CAPACITOR 2700pF 50V K
C367 QEKC1HM-106Z E CAPACITOR 10uF 50V M
C368 QEKC1HM-106Z E CAPACITOR 10uF 50V M
C369 QEKC1EM-476Z E CAPACITOR 47uF 25V M
C370 QEKC1EM-476Z E CAPACITOR 47uF 25V M
C371 NCB31HK-223X C CAPACITOR 0.022uF 50V K
C372 NCB31HK-223X C CAPACITOR 0.022uF 50V K
C373 QEKC1EM-476Z E CAPACITOR 47uF 25V M
C374 NCB31HK-223X C CAPACITOR 0.022uF 50V K
C375 NCB31HK-102X C CAPACITOR 1000pF 50V K
C376 NCS31HJ-101X C CAPACITOR 100pF 50V J
C381 QTE1H06-475Z E CAPACITOR 4.7uF 50V
C382 QTE1H06-475Z E CAPACITOR 4.7uF 50V
 Symbol No. PartNo.Part Name Description
C383 QTE1H06-475Z E CAPACITOR 4.7uF 50V
C384 QTE1H06-475Z E CAPACITOR 4.7uF 50V
C385 QTE1H06-475Z E CAPACITOR 4.7uF 50V
C386 QEKC1HM-106Z E CAPACITOR 10uF 50V M
C387 QCBB1HK-101Y C CAPACITOR 100pF 50V K
C400 NCS31HJ-101X C CAPACITOR 100pF 50V J
C401 QETN0JM-477Z E CAPACITOR 470uF 6.3V M
C402 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C403 QETN1CM-476Z E CAPACITOR 47uF 16V M
C404 QFVF1HJ-104Z MF CAPACITOR 0.1uF 50V J
C405 QFVF1HJ-104Z MF CAPACITOR 0.1uF 50V J
C406 QFVF1HJ-104Z MF CAPACITOR 0.1uF 50V J
C407 QFVF1HJ-104Z MF CAPACITOR 0.1uF 50V J
C408 QFVF1HJ-104Z MF CAPACITOR 0.1uF 50V J
C409 QETN0JM-477Z E CAPACITOR 470uF 6.3V M
C410 QETN0JM-477Z E CAPACITOR 470uF 6.3V M
C411 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C412 QETN0JM-477Z E CAPACITOR 470uF 6.3V M
C413 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C421 NCS31HJ-470X C CAPACITOR 47pF 50V J
C422 QETN0JM-477Z E CAPACITOR 470uF 6.3V M
C423 QETN0JM-477Z E CAPACITOR 470uF 6.3V M
C424 NCS31HJ-470X C CAPACITOR 47pF 50V J
C425 QETN0JM-477Z E CAPACITOR 470uF 6.3V M
C426 NCS31HJ-470X C CAPACITOR 47pF 50V J
C427 QETN0JM-477Z E CAPACITOR 470uF 6.3V M
C428 NCS31HJ-470X C CAPACITOR 47pF 50V J
C429 QEKC1HM-475Z E CAPACITOR 4.7uF 50V M
C760 QETN0JM-228Z E CAPACITOR 2200uF 6.3V M
C761 NCS31HJ-101X C CAPACITOR 100pF 50V J
C762 NCS31HJ-101X C CAPACITOR 100pF 50V J
C765 NCB31HK-223X C CAPACITOR 0.022uF 50V K
C766 QEKC1HM-225Z E CAPACITOR 2.2uF 50V M
C767 QEKC0JM-107Z E CAPACITOR 100uF 6.3V M
C768 QCZ0202-155Z C CAPACITOR 1.5uF 25V Z
C791 NCB31HK-221X C CAPACITOR 220pF 50V K
C792 QCZ0202-155Z C CAPACITOR 1.5uF 25V Z
C1101 NCS31HJ-101X C CAPACITOR 100pF 50V J
C1102 NCS31HJ-101X C CAPACITOR 100pF 50V J
C1103 NCS31HJ-101X C CAPACITOR 100pF 50V J
C1104 NCS31HJ-101X C CAPACITOR 100pF 50V J
C1105 QCFB1HZ-104Y C CAPACITOR 0.1uF 50V Z
C1191 QEKC0JM-107Z E CAPACITOR 100uF 6.3V M
C1192 QEKC0JM-107Z E CAPACITOR 100uF 6.3V M
C1193 QEKC0JM-107Z E CAPACITOR 100uF 6.3V M
C1194 QEKC0JM-107Z E CAPACITOR 100uF 6.3V M
C1195 QETN1CM-477Z E CAPACITOR 470uF 16V M
C1196 QETN0JM-228Z E CAPACITOR 2200uF 6.3V M
C1381 QEKC1HM-475Z E CAPACITOR 4.7uF 50V M
C1382 QEKC1HM-475Z E CAPACITOR 4.7uF 50V M
C1383 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C1384 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C1385 QEKC1HM-225Z E CAPACITOR 2.2uF 50V M
C1387 QETN1HM-106Z E CAPACITOR 10uF 50V M
C1388 QETN1HM-106Z E CAPACITOR 10uF 50V M
C1391 QEKC0JM-107Z E CAPACITOR 100uF 6.3V M
C1411 QETN0JM-477Z E CAPACITOR 470uF 6.3V M
C1412 QETN0JM-477Z E CAPACITOR 470uF 6.3V M
C1413 QETN0JM-477Z E CAPACITOR 470uF 6.3V M
C1414 QETN0JM-477Z E CAPACITOR 470uF 6.3V M
C1415 QETN0JM-477Z E CAPACITOR 470uF 6.3V M
C1416 QETN0JM-477Z E CAPACITOR 470uF 6.3V M
C1417 QETN0JM-477Z E CAPACITOR 470uF 6.3V M
C1418 QETN0JM-477Z E CAPACITOR 470uF 6.3V M
 R141 QRZ9005-120X FUSI RESISTOR 12 Ω
 R142 QRJ146J-682X UNF C RESISTOR 6.8k Ω 1/4W J
 R145 QRZ9005-120X FUSI RESISTOR 12 Ω
 R146 QRJ146J-332X UNF C RESISTOR 3.3k Ω 1/4W J
 R151 QRZ9006-4R7X F.RESISTOR 4.7 Ω 1/4W J
 R152 QRZ9006-4R7X F.RESISTOR 4.7 Ω 1/4W J
 R153 QRJ146J-332X UNF C RESISTOR 3.3k Ω 1/4W J
 R154 QRJ146J-2R2X UNF C RESISTOR 2.2 Ω 1/4W J
 R155 QRJ146J-2R2X UNF C RESISTOR 2.2 Ω 1/4W J
 R158 QRZ9005-100X FUSI RESISTOR 10 Ω
 R159 QRJ146J-182X UNF C RESISTOR 1.8k Ω 1/4W J
 R160 QRJ146J-182X UNF C RESISTOR 1.8k Ω 1/4W J
 R161 QRZ9006-4R7X F.RESISTOR 4.7 Ω 1/4W J
 Symbol No. Part No. Part Name Description
RSDX-02E
Parts List 5/15
7

 R162 QRZ9005-100X FUSI RESISTOR 10 Ω
 R163 QRZ9006-4R7X F.RESISTOR 4.7 Ω 1/4W J
 R164 QRJ146J-222X UNF C RESISTOR 2.2k Ω 1/4W J
 R165 QRZ9005-100X FUSI RESISTOR 10 Ω
 R166 QRZ9005-100X FUSI RESISTOR 10 Ω
 R167 QRJ146J-222X UNF C RESISTOR 2.2k Ω 1/4W J
 R168 QRJ146J-222X UNF C RESISTOR 2.2k Ω 1/4W J
 R169 QRJ146J-2R2X UNF C RESISTOR 2.2 Ω 1/4W J
 R170 QRJ146J-2R2X UNF C RESISTOR 2.2 Ω 1/4W J
 R171 QRZ9005-100X FUSI RESISTOR 10 Ω
 R172 QRJ146J-182X UNF C RESISTOR 1.8k Ω 1/4W J
 R181 QRZ9006-4R7X F.RESISTOR 4.7 Ω 1/4W J
 R182 QRZ9006-4R7X F.RESISTOR 4.7 Ω 1/4W J
 R183 QRJ146J-182X UNF C RESISTOR 1.8k Ω 1/4W J
 R184 QRJ146J-2R2X UNF C RESISTOR 2.2 Ω 1/4W J
 R185 QRJ146J-2R2X UNF C RESISTOR 2.2 Ω 1/4W J
 R186 QRZ9005-100X FUSI RESISTOR 10 Ω
 R187 QRJ146J-222X UNF C RESISTOR 2.2k Ω 1/4W J
 R191 QRK126J-100X UNF C RESISTOR 10 Ω 1/2W J
 R192 QRJ146J-222X UNF C RESISTOR 2.2k Ω 1/4W J
 R290 QRJ146J-181X UNF C RESISTOR 180 Ω 1/4W J
R301 NRSA63J-471X MG RESISTOR 470
Ω 1/16W J
R302 NRSA63J-471X MG RESISTOR 470 Ω 1/16W J
R303 NRSA63J-473X MG RESISTOR 47k Ω 1/16W J
R304 NRSA63J-473X MG RESISTOR 47k Ω 1/16W J
R307 NRSA63J-473X MG RESISTOR 47k Ω 1/16W J
R308 NRSA63J-473X MG RESISTOR 47k Ω 1/16W J
R309 NRSA63J-471X MG RESISTOR 470 Ω 1/16W J
R310 NRSA63J-471X MG RESISTOR 470 Ω 1/16W J
R311 NRSA63J-473X MG RESISTOR 47k Ω 1/16W J
R312 NRSA63J-473X MG RESISTOR 47k Ω 1/16W J
R315 NRSA63J-473X MG RESISTOR 47k Ω 1/16W J
R316 NRSA63J-473X MG RESISTOR 47k Ω 1/16W J
R321 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R322 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R325 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R326 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R341 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R342 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R343 NRSA63J-682X MG RESISTOR 6.8k Ω 1/16W J
R344 NRSA63J-682X MG RESISTOR 6.8k Ω 1/16W J
R345 NRSA63J-473X MG RESISTOR 47k Ω 1/16W J
R346 NRSA63J-473X MG RESISTOR 47k Ω 1/16W J
R351 NRSA63J-474X MG RESISTOR 470k Ω 1/16W J
R352 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R353 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R354 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R361 NRSA63J-752X MG RESISTOR 7.5k Ω 1/16W J
R362 NRSA63J-752X MG RESISTOR 7.5k Ω 1/16W J
R371 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R372 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R373 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R381 NRSA63J-104X MG RESISTOR 100k
Ω 1/16W J
R382 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R383 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R384 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R385 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R386 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R387 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R388 NRSA63J-104X MG RESISTOR 100k
Ω 1/16W J
R389 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R390 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R391 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R392 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R393 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R394 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R395 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R396 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R401 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R402 NRSA63J-360X MG RESISTOR 36 Ω 1/16W J
R403 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R404 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R405 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R406 NRSA63J-750X MG RESISTOR 75
Ω 1/16W J
R407 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R408 NRSA63J-360X MG RESISTOR 36 Ω 1/16W J
R409 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R410 NRSA63J-360X MG RESISTOR 36
Ω 1/16W J
 Symbol No. Part No. Part Name Description
R411 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R414 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R415 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R416 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R417 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R418 NRSA63J-104X MG RESISTOR 100k
Ω 1/16W J
R421 NRSA63J-750X MG RESISTOR 75
Ω 1/16W J
R422 NRSA63J-473X MG RESISTOR 47k Ω 1/16W J
R423 NRSA63J-750X MG RESISTOR 75 Ω 1/16W J
R424 NRSA63J-473X MG RESISTOR 47k Ω 1/16W J
R425 NRSA63J-750X MG RESISTOR 75 Ω 1/16W J
R426 NRSA63J-750X MG RESISTOR 75 Ω 1/16W J
R427 NRSA63J-473X MG RESISTOR 47k Ω 1/16W J
R428 NRSA63J-750X MG RESISTOR 75 Ω 1/16W J
R429 NRSA63J-473X MG RESISTOR 47k Ω 1/16W J
R430 NRSA63J-331X MG RESISTOR 330 Ω 1/16W J
R431 NRSA63J-750X MG RESISTOR 75 Ω 1/16W J
R452 NRSA63J-750X MG RESISTOR 75 Ω 1/16W J
R760 NRSA63J-331X MG RESISTOR 330 Ω 1/16W J
R761 NRSA63J-223X MG RESISTOR 22k Ω 1/16W J
R762 NRSA63J-473X MG RESISTOR 47k
Ω 1/16W J
R763 NRSA63J-683X MG RESISTOR 68k
Ω 1/16W J
R764 NRSA63J-473X MG RESISTOR 47k Ω 1/16W J
R765 NRSA63J-153X MG RESISTOR 15k Ω 1/16W J
R766 NRSA63J-273X MG RESISTOR 27k Ω 1/16W J
R767 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R768 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R769 NRSA63J-223X MG RESISTOR 22k Ω 1/16W J
R770 NRSA63J-473X MG RESISTOR 47k Ω 1/16W J
R771 NRSA63J-683X MG RESISTOR 68k Ω 1/16W J
R772 NRSA63J-473X MG RESISTOR 47k Ω 1/16W J
R773 NRSA63J-153X MG RESISTOR 15k Ω 1/16W J
R774 NRSA63J-273X MG RESISTOR 27k Ω 1/16W J
R775 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R776 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R777 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R778 NRSA63J-223X MG RESISTOR 22k Ω 1/16W J
R779 NRSA63J-472X MG RESISTOR 4.7k Ω 1/16W J
R780 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R783 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R784 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R785 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R786 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R787 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R788 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R789 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R791 NRSA63J-221X MG RESISTOR 220 Ω 1/16W J
R792 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R793 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R794 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R798 NRSA63J-153X MG RESISTOR 15k Ω 1/16W J
R799 NRSA63J-333X MG RESISTOR 33k
Ω 1/16W J
R1101 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R1102 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R1103 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R1104 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R1105 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R1106 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R1107 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R1108 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R1110 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R1111 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R1112 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R1113 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R1114 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R1115 NRSA63J-471X MG RESISTOR 470
Ω 1/16W J
R1116 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R1117 NRSA63J-471X MG RESISTOR 470
Ω 1/16W J
R1118 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R1119 NRSA63J-471X MG RESISTOR 470 Ω 1/16W J
R1120 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R1122 NRSA63J-221X MG RESISTOR 220
Ω 1/16W J
R1123 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R1124 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R1125 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R1126 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R1127 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R1128 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
 Symbol No. Part No. Part Name Description
Parts List 6/15
RSDX-02E
8

DSP board
R1129 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R1130 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R1131 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R1132 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R1134 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R1135 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R1136 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R1137 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R1138 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R1381 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R1382 NRSA63J-273X MG RESISTOR 27k Ω 1/16W J
R1383 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R1384 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R1385 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R1386 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R1387 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R1388 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R1389 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R1391 NRSA63J-822X MG RESISTOR 8.2k Ω 1/16W J
R1392 NRSA63J-822X MG RESISTOR 8.2k Ω 1/16W J
R1393 NRSA63J-822X MG RESISTOR 8.2k
Ω 1/16W J
R1394 NRSA63J-822X MG RESISTOR 8.2k
Ω 1/16W J
R1395 NRSA63J-822X MG RESISTOR 8.2k Ω 1/16W J
R1397 NRSA63J-124X MG RESISTOR 120k Ω 1/16W J
R1398 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R1399 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R1413 NRSA63J-750X MG RESISTOR 75 Ω 1/16W J
R1414 NRSA63J-750X MG RESISTOR 75 Ω 1/16W J
R1415 NRSA63J-750X MG RESISTOR 75 Ω 1/16W J
R1416 NRSA63J-750X MG RESISTOR 75 Ω 1/16W J
R1417 NRSA63J-750X MG RESISTOR 75 Ω 1/16W J
R1418 NRSA63J-750X MG RESISTOR 75 Ω 1/16W J
R1419 NRSA63J-750X MG RESISTOR 75 Ω 1/16W J
R1420 NRSA63J-750X MG RESISTOR 75 Ω 1/16W J
R1731 NRSA63J-562X MG RESISTOR 5.6k Ω 1/16W J
R1732 NRSA63J-562X MG RESISTOR 5.6k Ω 1/16W J
R1733 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R1734 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
L191 QQL28AK-101 CHOKE COIL 100uH K
L192 QQL28AK-101 CHOKE COIL 100uH K
L193 QQL28AK-101 CHOKE COIL 100uH K
L197 QQL244K-100Z COIL 10uH K
L198 QQL244K-100Z COIL 10uH K
L341 QQR0590-001 FILTER
L342 QQR0590-001 FILTER
CN114 QGF1205C1-13 CONNECTOR FFC/FPC (1-13)
CN121 QGA3901C1-08 CONNECTOR W-B (1-8)
CN122 QGA2501C1-02 CONNECTOR W-B (1-2)
CN125 QGF1205C1-10 CONNECTOR FFC/FPC (1-10)
CN212 QGB2510J1-11 CONNECTOR B-B (1-11)
CN231 QGA2501C1-08 CONNECTOR W-B (1-8)
CN241 QGD2501C1-04Z CONNECTOR (1-4)
CN291 QGD2501C1-03Z CONNECTOR (1-3)
CN301 QGF1205C1-11 CONNECTOR FFC/FPC (1-11)
CN411 QGF1205C1-17 CONNECTOR FFC/FPC (1-17)
CN412 QGF1205C1-16 CONNECTOR FFC/FPC (1-16)
CN512 QGB2027M9-26 CONNECTOR B-B (1-26)
CN513 QGB2027M9-26 CONNECTOR B-B (1-26)
CN612 QGB2510J1-13 CONNECTOR B-B (1-13)
CN614 QGF1205C1-12 CONNECTOR FFC/FPC (1-12)
CN761 QGF1205C1-06 CONNECTOR FFC/FPC (1-6)
CN911 QGB2016K1-15 CONNECTOR B-B (1-15)
CN912 QGB2016K1-13 CONNECTOR B-B (1-13)
EP101 QNZ0136-001Z EARTH PLATE
EP191 QNZ0136-001Z EARTH PLATE
FC130 QNG0020-001Z FUSE CLIP
FC131 QNG0020-001Z FUSE CLIP
FC132 QNG0020-001Z FUSE CLIP
FC133 QNG0020-001Z FUSE CLIP
FS387 E3400-431 SPACER
HS141 E70306-001 HEAT SINK
HS145 E70306-001 HEAT SINK
HS151 E70306-001 HEAT SINK
HS152 E70306-001 HEAT SINK
HS154 E70306-001 HEAT SINK
HS161 E70306-001 HEAT SINK
 Symbol No. PartNo.Part Name Description
HS162 E70306-001 HEAT SINK
HS165 E70306-001 HEAT SINK
HS181 E70306-001 HEAT SINK
HS182 E70306-001 HEAT SINK
J301 QNN0476-001 PIN JACK
J401 QNZ0516-001 RGB CONNECTOR
K401 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
K402 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
K403 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
K404 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
 RY291 QSK0109-001 RELAY
S401 QSW0454-001 SW
X301 QAX0263-001Z CRYSTAL 4.332MHz
X761 QAX0246-001Z C RESONATOR 8.00MHz
 Symbol No. Part No. Part Name Description
IC601 AK4527BVQP IC
IC602 BA15218F-XE IC
IC603 BA15218F-XE IC
IC611 TC74HC4072AF-X IC
IC612 MM74HC08SJ-X IC
 IC615 MM1563DF-X IC 3.3V Regulator
IC621 MM74HCU04SJ-X IC
IC631 TC9446F-025 IC
IC641 LP61L1024S-12-X IC
IC651 BA15218F-XE IC
IC652 BA15218F-XE IC
IC661 BA15218F-XE IC
IC671 BA15218F-XE IC
IC672 BA15218F-XE IC
IC681 UPD784215AGC167 IC(MICRO C ROM)
 IC682 MM1613DN-X IC
IC683 NC7ST32P5-X IC(DIGITAL)
Q631 UN9214J-X TRANSISTOR
Q632 KRA104S-X DIGI TRANSISTOR
Q671 2SD1048/6-7/-X TRANSISTOR
Q672 UN9214J-X TRANSISTOR
Q673 KRA104S-X DIGI TRANSISTOR
Q681 UN9214J-X TRANSISTOR
Q2501 KRA104S-X DIGI TRANSISTOR
Q2521 2SC3576-JVC-T TRANSISTOR
Q2522 2SC3576-JVC-T TRANSISTOR
Q2561 2SC3576-JVC-T TRANSISTOR
Q2562 2SC3576-JVC-T TRANSISTOR
Q2581 2SC3576-JVC-T TRANSISTOR
Q2582 2SC3576-JVC-T TRANSISTOR
D621 MA111-X SI DIODE
D622 MA111-X SI DIODE
D631 MA111-X SI DIODE
D632 MA111-X SI DIODE
C601 QETN0JM-107Z E CAPACITOR 100uF 6.3V M
C602 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C605 NCB31HK-102X C CAPACITOR 1000pF 50V K
C606 NCB31HK-102X C CAPACITOR 1000pF 50V K
C607 QETN0JM-107Z E CAPACITOR 100uF 6.3V M
C608 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C609 QETN0JM-107Z E CAPACITOR 100uF 6.3V M
C610 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C611 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C612 QETN0JM-107Z E CAPACITOR 100uF 6.3V M
C613 NCB31CK-103X C CAPACITOR 0.01uF 16V K
C615 NCB31CK-103X C CAPACITOR 0.01uF 16V K
C616 QEKC0JM-107Z E CAPACITOR 100uF 6.3V M
C617 QETN0JM-107Z E CAPACITOR 100uF 6.3V M
C618 NCB31CK-103X C CAPACITOR 0.01uF 16V K
C619 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C620 QETN1CM-107Z E CAPACITOR 100uF 16V M
 Symbol No. Part No. Part Name Description
LVA10334
RSDX-02E
Parts List 7/15
9

C621 NCS31HJ-101X C CAPACITOR 100pF 50V J
C622 QETN1HM-105Z E CAPACITOR 1uF 50V M
C623 NCB31CK-103X C CAPACITOR 0.01uF 16V K
C624 NCF31AZ-105X C CAPACITOR 1uF 10V Z
C625 NCF31AZ-105X C CAPACITOR 1uF 10V Z
C626 NCF31AZ-105X C CAPACITOR 1uF 10V Z
C627 NCS31HJ-471X C CAPACITOR 470pF 50V J
C628 NCF31AZ-105X C CAPACITOR 1uF 10V Z
C629 NCS31HJ-101X C CAPACITOR 100pF 50V J
C631 QETN0JM-107Z E CAPACITOR 100uF 6.3V M
C632 NCB31CK-103X C CAPACITOR 0.01uF 16V K
C633 QETN0JM-107Z E CAPACITOR 100uF 6.3V M
C634 NCB31CK-103X C CAPACITOR 0.01uF 16V K
C635 NCB31AK-474X C CAPACITOR 0.47uF 10V K
C636 NCB31CK-103X C CAPACITOR 0.01uF 16V K
C637 NCS31HJ-101X C CAPACITOR 100pF 50V J
C638 NCS31HJ-121X C CAPACITOR 120pF 50V J
C639 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C640 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C641 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C642 NCB31CK-473X C CAPACITOR 0.047uF 16V K
C643 NCS31HJ-180X C CAPACITOR 18pF 50V J
C644 NCS31HJ-220X C CAPACITOR 22pF 50V J
C645 NCB31CK-103X C CAPACITOR 0.01uF 16V K
C646 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C647 QETN0JM-107Z E CAPACITOR 100uF 6.3V M
C648 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C680 NCF31AZ-105X C CAPACITOR 1uF 10V Z
C681 QETN0JM-107Z E CAPACITOR 100uF 6.3V M
C682 NCB31CK-103X C CAPACITOR 0.01uF 16V K
C683 NCS31HJ-101X C CAPACITOR 100pF 50V J
C684 NCS31HJ-101X C CAPACITOR 100pF 50V J
C685 NCB31CK-103X C CAPACITOR 0.01uF 16V K
C686 NCB31CK-103X C CAPACITOR 0.01uF 16V K
C687 NCB31CK-103X C CAPACITOR 0.01uF 16V K
C688 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C689 NCF31AZ-105X C CAPACITOR 1uF 10V Z
C690 NCB31CK-103X C CAPACITOR 0.01uF 16V K
C691 NCB31CK-103X C CAPACITOR 0.01uF 16V K
C692 QTE1C06-476Z E CAPACITOR 47uF 16V
C693 NCB31CK-103X C CAPACITOR 0.01uF 16V K
C694 QTE1C06-336Z E CAPACITOR 33uF 16V
C695 NCB31CK-103X C CAPACITOR 0.01uF 16V K
C696 QTE1C06-336Z E CAPACITOR 33uF 16V
C2500 QETN1HM-226Z E CAPACITOR 22uF 50V M
C2503 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C2504 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C2507 NCS31HJ-330X C CAPACITOR 33pF 50V J
C2508 NCS31HJ-330X C CAPACITOR 33pF 50V J
C2512 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C2513 NCB31HK-122X C CAPACITOR 1200pF 50V K
C2514 NCB31HK-122X C CAPACITOR 1200pF 50V K
C2515 NCS31HJ-121X C CAPACITOR 120pF 50V J
C2516 NCS31HJ-121X C CAPACITOR 120pF 50V J
C2525 NCB31HK-102X C CAPACITOR 1000pF 50V K
C2526 NCB31HK-102X C CAPACITOR 1000pF 50V K
C2527 QETN1HM-106Z E CAPACITOR 10uF 50V M
C2528 QETN1HM-106Z E CAPACITOR 10uF 50V M
C2531 NCS31HJ-560X C CAPACITOR 56pF 50V J
C2532 NCS31HJ-560X C CAPACITOR 56pF 50V J
C2533 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C2534 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C2539 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C2540 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C2551 NCS31HJ-560X C CAPACITOR 56pF 50V J
C2552 NCS31HJ-560X C CAPACITOR 56pF 50V J
C2555 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C2556 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C2561 QETN1HM-105Z E CAPACITOR 1uF 50V M
C2562 QETN1HM-105Z E CAPACITOR 1uF 50V M
C2563 NCS31HJ-560X C CAPACITOR 56pF 50V J
C2564 NCS31HJ-560X C CAPACITOR 56pF 50V J
C2569 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C2570 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C2575 NCB31HK-272X C CAPACITOR 2700pF 50V K
C2576 NCB31HK-272X C CAPACITOR 2700pF 50V K
C2577 QETN1HM-106Z E CAPACITOR 10uF 50V M
C2578 QETN1HM-106Z E CAPACITOR 10uF 50V M
 Symbol No. Part No. Part Name Description
C2581 QETN1HM-105Z E CAPACITOR 1uF 50V M
C2582 QETN1HM-106Z E CAPACITOR 10uF 50V M
C2583 NCS31HJ-560X C CAPACITOR 56pF 50V J
C2584 NCS31HJ-560X C CAPACITOR 56pF 50V J
C2585 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C2586 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C2587 NCS31HJ-560X C CAPACITOR 56pF 50V J
C2588 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C2589 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C2590 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C2592 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C2594 NCF31CZ-473X C CAPACITOR 0.047uF 16V Z
C2595 NCB31HK-272X C CAPACITOR 2700pF 50V K
C2597 QETN1HM-106Z E CAPACITOR 10uF 50V M
C2598 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
R601 NRSA63J-473X MG RESISTOR 47k Ω 1/16W J
R602 NRSA63J-473X MG RESISTOR 47k Ω 1/16W J
R603 NRSA63J-221X MG RESISTOR 220 Ω 1/16W J
R604 NRSA63J-473X MG RESISTOR 47k Ω 1/16W J
R605 NRSA63J-331X MG RESISTOR 330
Ω 1/16W J
R606 NRSA63J-221X MG RESISTOR 220
Ω 1/16W J
R607 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R608 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R611 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R613 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R615 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R619 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R620 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R621 NRSA63J-750X MG RESISTOR 75 Ω 1/16W J
R622 NRSA63J-221X MG RESISTOR 220 Ω 1/16W J
R623 NRSA63J-472X MG RESISTOR 4.7k Ω 1/16W J
R624 NRSA63J-333X MG RESISTOR 33k Ω 1/16W J
R631 NRSA63J-221X MG RESISTOR 220 Ω 1/16W J
R632 NRSA63J-472X MG RESISTOR 4.7k Ω 1/16W J
R633 NRSA63J-221X MG RESISTOR 220 Ω 1/16W J
R634 NRSA63J-221X MG RESISTOR 220 Ω 1/16W J
R635 NRSA63J-221X MG RESISTOR 220 Ω 1/16W J
R636 NRSA63J-221X MG RESISTOR 220 Ω 1/16W J
R637 NRSA63J-221X MG RESISTOR 220 Ω 1/16W J
R638 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R639 NRSA63F-102X MG RESISTOR 1k Ω 1/16W F
R640 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R641 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R642 NRSA63J-563X MG RESISTOR 56k Ω 1/16W J
R643 NRSA63F-103X MG RESISTOR 10k Ω 1/16W F
R644 NRSA63J-472X MG RESISTOR 4.7k Ω 1/16W J
R645 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R646 NRSA63J-225X MG RESISTOR 2.2M Ω 1/16W J
R651 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R653 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R661 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R662 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R663 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R671 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R672 NRSA63J-105X MG RESISTOR 1M
Ω 1/16W J
R676 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R679 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R680 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R681 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R682 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R683 NRSA63J-822X MG RESISTOR 8.2k Ω 1/16W J
R684 NRSA63J-432X MG RESISTOR 4.3k
Ω 1/16W J
R685 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R686 NRSA63J-822X MG RESISTOR 8.2k Ω 1/16W J
R687 NRSA63J-432X MG RESISTOR 4.3k
Ω 1/16W J
R688 NRSA63J-822X MG RESISTOR 8.2k
Ω 1/16W J
R689 NRSA63J-432X MG RESISTOR 4.3k
Ω 1/16W J
R690 NRSA63J-822X MG RESISTOR 8.2k
Ω 1/16W J
R691 NRSA63J-432X MG RESISTOR 4.3k Ω 1/16W J
R692 NRSA63J-221X MG RESISTOR 220
Ω 1/16W J
R693 NRSA63J-221X MG RESISTOR 220
Ω 1/16W J
R694 NRSA63J-221X MG RESISTOR 220 Ω 1/16W J
R695 NRSA63J-221X MG RESISTOR 220
Ω 1/16W J
R696 NRSA63J-221X MG RESISTOR 220
Ω 1/16W J
R697 NRSA63J-221X MG RESISTOR 220 Ω 1/16W J
R698 NRSA63J-221X MG RESISTOR 220
Ω 1/16W J
R699 NRSA63J-221X MG RESISTOR 220
Ω 1/16W J
 Symbol No. Part No. Part Name Description
Parts List 8/15
RSDX-02E
10

DAC board
R2500 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R2501 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R2502 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R2507 NRSA63J-223X MG RESISTOR 22k Ω 1/16W J
R2508 NRSA63J-223X MG RESISTOR 22k Ω 1/16W J
R2509 NRSA63J-223X MG RESISTOR 22k
Ω 1/16W J
R2510 NRSA63J-223X MG RESISTOR 22k
Ω 1/16W J
R2511 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R2512 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R2513 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R2514 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R2515 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R2516 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R2517 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R2518 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R2519 NRSA63J-331X MG RESISTOR 330 Ω 1/16W J
R2520 NRSA63J-331X MG RESISTOR 330 Ω 1/16W J
R2521 NRSA63J-331X MG RESISTOR 330 Ω 1/16W J
R2522 NRSA63J-331X MG RESISTOR 330 Ω 1/16W J
R2525 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R2526 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R2527 NRSA63J-104X MG RESISTOR 100k
Ω 1/16W J
R2528 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R2529 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R2530 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R2531 NRSA63J-752X MG RESISTOR 7.5k Ω 1/16W J
R2532 NRSA63J-752X MG RESISTOR 7.5k Ω 1/16W J
R2533 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R2534 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R2535 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R2536 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R2537 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R2538 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R2550 NRSA63J-272X MG RESISTOR 2.7k Ω 1/16W J
R2551 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R2552 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R2553 NRSA63J-153X MG RESISTOR 15k Ω 1/16W J
R2554 NRSA63J-153X MG RESISTOR 15k Ω 1/16W J
R2555 NRSA63J-752X MG RESISTOR 7.5k Ω 1/16W J
R2556 NRSA63J-752X MG RESISTOR 7.5k Ω 1/16W J
R2557 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R2558 NRSA63J-273X MG RESISTOR 27k Ω 1/16W J
R2560 NRSA63J-105X MG RESISTOR 1M Ω 1/16W J
R2561 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R2562 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R2563 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R2564 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R2565 NRSA63J-202X MG RESISTOR 2k Ω 1/16W J
R2566 NRSA63J-202X MG RESISTOR 2k Ω 1/16W J
R2567 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R2568 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R2575 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R2576 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R2577 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R2578 NRSA63J-104X MG RESISTOR 100k
Ω 1/16W J
R2581 NRSA63J-104X MG RESISTOR 100k
Ω 1/16W J
R2582 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R2583 NRSA63J-123X MG RESISTOR 12k
Ω 1/16W J
R2584 NRSA63J-223X MG RESISTOR 22k Ω 1/16W J
R2585 NRSA63J-302X MG RESISTOR 3k
Ω 1/16W J
R2586 NRSA63J-332X MG RESISTOR 3.3k
Ω 1/16W J
R2587 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R2588 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R2589 NRSA63J-104X MG RESISTOR 100k
Ω 1/16W J
R2590 NRSA63J-333X MG RESISTOR 33k Ω 1/16W J
R2592 NRSA63J-333X MG RESISTOR 33k
Ω 1/16W J
R2594 NRSA63J-333X MG RESISTOR 33k
Ω 1/16W J
R2595 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R2596 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R2597 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R2598 NRSA63J-104X MG RESISTOR 100k
Ω 1/16W J
CN601 QGB2510J1-13 CONNECTOR B-B (1-13)
CN602 QGF1205C1-12 CONNECTOR FFC/FPC (1-12)
EP601 E409182-001SM GRAND TERMINAL
J601 QNN0481-001 SURROUND JACK
K601 NQR0269-004X FERRITE BEADS
UN661 GP1FA352RZ OPT RECEIVER
 Symbol No. PartNo.Part Name Description
UN662 GP1FA352TZ OPT TRANSMITTER
X631 QAX0722-001Z CRYSTAL 24.576MHz
X681 QAX0719-001Z C RESONATOR 6.144MHz
 Symbol No. Part No. Part Name Description
IC901 MN35505-X IC
IC911 NJM4580E-W IC
IC921 NJM4580E-W IC
IC931 MN35505-X IC
IC941 NJM4580E-W IC
IC951 NJM4580E-W IC
IC961 MN35505-X IC
IC971 NJM4580E-W IC
IC981 NJM4580E-W IC
IC991 NJM4580E-W IC
IC992 NJM4580E-W IC
IC993 NJM4580E-W IC
IC994 NJM4580E-W IC
Q901 2SD1328/ST/-X TRANSISTOR
Q902 2SD1328/ST/-X TRANSISTOR
Q903 2SD1328/ST/-X TRANSISTOR
Q904 2SD1328/ST/-X TRANSISTOR
Q910 UN2113-X TRANSISTOR
Q911 UN2113-X TRANSISTOR
Q912 UN2113-X TRANSISTOR
Q1903 2SD1328/ST/-X TRANSISTOR
Q1904 2SD1328/ST/-X TRANSISTOR
Q2903 2SD1328/ST/-X TRANSISTOR
Q2904 2SD1328/ST/-X TRANSISTOR
Q2971 UN2213-X DIGI TRANSISTOR
Q2972 2SD1328/ST/-X TRANSISTOR
Q2993 UN2113-X TRANSISTOR
C900 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C901 NEA71CM-106X E CAPACITOR 10uF 16V M
C902 NCF31AZ-105X C CAPACITOR 1uF 10V Z
C903 NEA70JM-107X E CAPACITOR 100uF 6.3V M
C904 NCF31AZ-105X C CAPACITOR 1uF 10V Z
C905 NCF31AZ-105X C CAPACITOR 1uF 10V Z
C906 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C907 NCB31AK-224X C CAPACITOR 0.22uF 10V K
C908 NCF31AZ-105X C CAPACITOR 1uF 10V Z
C909 NEA70JM-107X E CAPACITOR 100uF 6.3V M
C910 NEA71CM-106X E CAPACITOR 10uF 16V M
C911 NCS31HJ-561X C CAPACITOR 560pF 50V J
C912 NCS31HJ-561X C CAPACITOR 560pF 50V J
C913 NCS31HJ-121X C CAPACITOR 120pF 50V J
C914 NCS31HJ-121X C CAPACITOR 120pF 50V J
C915 NCB31CK-333X C CAPACITOR 0.033uF 16V K
C916 NCB31CK-333X C CAPACITOR 0.033uF 16V K
C917 NEA71EM-475X E CAPACITOR 4.7uF 25V M
C918 NEA71EM-475X E CAPACITOR 4.7uF 25V M
C919 NCB31CK-103X C CAPACITOR 0.01uF 16V K
C920 NCB31CK-103X C CAPACITOR 0.01uF 16V K
C921 NCB31HK-272X C CAPACITOR 2700pF 50V K
C922 NCB31HK-272X C CAPACITOR 2700pF 50V K
C923 NCS31HJ-561X C CAPACITOR 560pF 50V J
C924 NCS31HJ-561X C CAPACITOR 560pF 50V J
C925 NEA71EM-475X E CAPACITOR 4.7uF 25V M
C926 NEA71EM-475X E CAPACITOR 4.7uF 25V M
C927 NEA71EM-475X E CAPACITOR 4.7uF 25V M
C928 NEA71EM-475X E CAPACITOR 4.7uF 25V M
C929 NCS31HJ-561X C CAPACITOR 560pF 50V J
C930 NCS31HJ-561X C CAPACITOR 560pF 50V J
C931 NCB31HK-152X C CAPACITOR 1500pF 50V K
C932 NCB31HK-152X C CAPACITOR 1500pF 50V K
C934 NCB31HK-102X C CAPACITOR 1000pF 50V K
C941 NEA71EM-475X E CAPACITOR 4.7uF 25V M
C942 NEA71EM-475X E CAPACITOR 4.7uF 25V M
 Symbol No. Part No. Part Name Description
LVA10405
RSDX-02E
Parts List 9/15
11

C951 NCS31HJ-560X C CAPACITOR 56pF 50V J
C952 NCS31HJ-560X C CAPACITOR 56pF 50V J
C953 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C954 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C961 NEA71CM-476X E CAPACITOR 47uF 16V M
C962 NEA71CM-476X E CAPACITOR 47uF 16V M
C1900 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C1901 NEA71CM-106X E CAPACITOR 10uF 16V M
C1902 NCF31AZ-105X C CAPACITOR 1uF 10V Z
C1903 NEA70JM-107X E CAPACITOR 100uF 6.3V M
C1904 NCF31AZ-105X C CAPACITOR 1uF 10V Z
C1905 NCF31AZ-105X C CAPACITOR 1uF 10V Z
C1906 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C1907 NCB31AK-224X C CAPACITOR 0.22uF 10V K
C1908 NCF31AZ-105X C CAPACITOR 1uF 10V Z
C1909 NEA70JM-107X E CAPACITOR 100uF 6.3V M
C1910 NEA71CM-106X E CAPACITOR 10uF 16V M
C1911 NCS31HJ-102X C CAPACITOR 1000pF 50V J
C1912 NCS31HJ-102X C CAPACITOR 1000pF 50V J
C1913 NCS31HJ-101X C CAPACITOR 100pF 50V J
C1914 NCS31HJ-101X C CAPACITOR 100pF 50V J
C1915 NCB31CK-333X C CAPACITOR 0.033uF 16V K
C1916 NCB31CK-333X C CAPACITOR 0.033uF 16V K
C1917 NEA71EM-475X E CAPACITOR 4.7uF 25V M
C1918 NEA71EM-475X E CAPACITOR 4.7uF 25V M
C1919 NCB31HK-123X C CAPACITOR 0.012uF 50V K
C1920 NCB31HK-123X C CAPACITOR 0.012uF 50V K
C1923 NCB31HK-152X C CAPACITOR 1500pF 50V K
C1924 NCB31HK-152X C CAPACITOR 1500pF 50V K
C1925 NEA71EM-475X E CAPACITOR 4.7uF 25V M
C1926 NEA71EM-475X E CAPACITOR 4.7uF 25V M
C1927 NEA71EM-475X E CAPACITOR 4.7uF 25V M
C1928 NEA71EM-475X E CAPACITOR 4.7uF 25V M
C1929 NCS31HJ-561X C CAPACITOR 560pF 50V J
C1930 NCS31HJ-561X C CAPACITOR 560pF 50V J
C1934 NCB31HK-102X C CAPACITOR 1000pF 50V K
C1941 NEA71EM-475X E CAPACITOR 4.7uF 25V M
C1942 NEA71EM-475X E CAPACITOR 4.7uF 25V M
C1951 NCS31HJ-560X C CAPACITOR 56pF 50V J
C1952 NCS31HJ-560X C CAPACITOR 56pF 50V J
C1953 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C1954 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C2900 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C2901 NEA71CM-106X E CAPACITOR 10uF 16V M
C2902 NCF31AZ-105X C CAPACITOR 1uF 10V Z
C2903 NEA70JM-107X E CAPACITOR 100uF 6.3V M
C2904 NCF31AZ-105X C CAPACITOR 1uF 10V Z
C2905 NCF31AZ-105X C CAPACITOR 1uF 10V Z
C2906 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C2907 NCB31AK-224X C CAPACITOR 0.22uF 10V K
C2908 NCF31AZ-105X C CAPACITOR 1uF 10V Z
C2909 NEA70JM-107X E CAPACITOR 100uF 6.3V M
C2910 NEA71CM-106X E CAPACITOR 10uF 16V M
C2911 NCS31HJ-102X C CAPACITOR 1000pF 50V J
C2912 NCS31HJ-102X C CAPACITOR 1000pF 50V J
C2913 NCS31HJ-101X C CAPACITOR 100pF 50V J
C2914 NCS31HJ-101X C CAPACITOR 100pF 50V J
C2915 NCB31CK-333X C CAPACITOR 0.033uF 16V K
C2916 NCB31CK-333X C CAPACITOR 0.033uF 16V K
C2917 NEA71EM-475X E CAPACITOR 4.7uF 25V M
C2918 NEA71EM-475X E CAPACITOR 4.7uF 25V M
C2919 NCB31HK-123X C CAPACITOR 0.012uF 50V K
C2920 NCB31HK-123X C CAPACITOR 0.012uF 50V K
C2923 NCB31HK-152X C CAPACITOR 1500pF 50V K
C2924 NCB31HK-152X C CAPACITOR 1500pF 50V K
C2925 NEA71EM-475X E CAPACITOR 4.7uF 25V M
C2926 NEA71EM-475X E CAPACITOR 4.7uF 25V M
C2927 NEA71EM-475X E CAPACITOR 4.7uF 25V M
C2928 NEA71EM-475X E CAPACITOR 4.7uF 25V M
C2929 NCS31HJ-561X C CAPACITOR 560pF 50V J
C2930 NCS31HJ-561X C CAPACITOR 560pF 50V J
C2932 NCB31HK-152X C CAPACITOR 1500pF 50V K
C2934 NCB31HK-102X C CAPACITOR 1000pF 50V K
C2941 NEA71EM-475X E CAPACITOR 4.7uF 25V M
C2942 NEA71EM-475X E CAPACITOR 4.7uF 25V M
C2951 NCS31HJ-560X C CAPACITOR 56pF 50V J
C2952 NCS31HJ-560X C CAPACITOR 56pF 50V J
C2953 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
 Symbol No. Part No. Part Name Description
C2954 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C2971 NCS31HJ-560X C CAPACITOR 56pF 50V J
C2972 NEA71EM-475X E CAPACITOR 4.7uF 25V M
C2973 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C2974 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
R900 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R901 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R902 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R903 NRSA63J-471X MG RESISTOR 470 Ω 1/16W J
R904 NRSA63J-471X MG RESISTOR 470 Ω 1/16W J
R905 NRSA63J-332X MG RESISTOR 3.3k Ω 1/16W J
R906 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R907 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R908 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R909 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R910 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R911 NRSA63J-273X MG RESISTOR 27k Ω 1/16W J
R912 NRSA63J-273X MG RESISTOR 27k Ω 1/16W J
R913 NRSA63J-273X MG RESISTOR 27k Ω 1/16W J
R914 NRSA63J-273X MG RESISTOR 27k
Ω 1/16W J
R915 NRSA63F-183X MG RESISTOR 18k
Ω 1/16W F
R916 NRSA63F-183X MG RESISTOR 18k Ω 1/16W F
R917 NRSA63F-183X MG RESISTOR 18k Ω 1/16W F
R918 NRSA63F-183X MG RESISTOR 18k Ω 1/16W F
R919 NRSA63J-362X MG RESISTOR 3.6k Ω 1/16W J
R920 NRSA63J-362X MG RESISTOR 3.6k Ω 1/16W J
R921 NRSA63J-362X MG RESISTOR 3.6k Ω 1/16W J
R922 NRSA63J-362X MG RESISTOR 3.6k Ω 1/16W J
R923 NRSA63F-183X MG RESISTOR 18k Ω 1/16W F
R924 NRSA63F-183X MG RESISTOR 18k Ω 1/16W F
R925 NRSA63F-332X MG RESISTOR 3.3k Ω 1/16W F
R926 NRSA63F-332X MG RESISTOR 3.3k Ω 1/16W F
R927 NRSA63J-362X MG RESISTOR 3.6k Ω 1/16W J
R928 NRSA63J-362X MG RESISTOR 3.6k Ω 1/16W J
R929 NRSA63F-681X MG RESISTOR 680 Ω 1/16W F
R930 NRSA63F-681X MG RESISTOR 680 Ω 1/16W F
R931 NRSA63F-821X MG RESISTOR 820 Ω 1/16W F
R932 NRSA63F-821X MG RESISTOR 820 Ω 1/16W F
R933 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R934 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R935 NRSA63J-105X MG RESISTOR 1M Ω 1/16W J
R936 NRSA63J-105X MG RESISTOR 1M Ω 1/16W J
R937 NRSA63J-821X MG RESISTOR 820 Ω 1/16W J
R938 NRSA63J-821X MG RESISTOR 820 Ω 1/16W J
R939 NRSA63J-183X MG RESISTOR 18k Ω 1/16W J
R940 NRSA63J-183X MG RESISTOR 18k Ω 1/16W J
R941 NRSA63J-273X MG RESISTOR 27k Ω 1/16W J
R942 NRSA63J-273X MG RESISTOR 27k Ω 1/16W J
R943 NRSA63J-561X MG RESISTOR 560
Ω 1/16W J
R944 NRSA63J-561X MG RESISTOR 560 Ω 1/16W J
R947 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R948 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R949 NRSA63J-473X MG RESISTOR 47k Ω 1/16W J
R950 NRSA63J-473X MG RESISTOR 47k
Ω 1/16W J
R951 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R952 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R953 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R954 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R955 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R956 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R959 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R960 NRSA63J-104X MG RESISTOR 100k
Ω 1/16W J
R1900 NRSA63J-101X MG RESISTOR 100
Ω 1/16W J
R1901 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R1902 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R1903 NRSA63J-471X MG RESISTOR 470
Ω 1/16W J
R1904 NRSA63J-471X MG RESISTOR 470
Ω 1/16W J
R1905 NRSA63J-332X MG RESISTOR 3.3k
Ω 1/16W J
R1906 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R1907 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R1908 NRSA63J-101X MG RESISTOR 100
Ω 1/16W J
R1909 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R1910 NRSA63J-101X MG RESISTOR 100
Ω 1/16W J
R1911 NRSA63J-303X MG RESISTOR 30k
Ω 1/16W J
R1912 NRSA63J-303X MG RESISTOR 30k Ω 1/16W J
R1913 NRSA63J-303X MG RESISTOR 30k
Ω 1/16W J
R1914 NRSA63J-303X MG RESISTOR 30k
Ω 1/16W J
 Symbol No. Part No. Part Name Description
Parts List 10/15
RSDX-02E
12

Scart board
R1915 NRSA63F-183X MG RESISTOR 18k Ω 1/16W F
R1916 NRSA63F-183X MG RESISTOR 18k Ω 1/16W F
R1917 NRSA63F-183X MG RESISTOR 18k Ω 1/16W F
R1918 NRSA63F-183X MG RESISTOR 18k Ω 1/16W F
R1919 NRSA63J-272X MG RESISTOR 2.7k Ω 1/16W J
R1920 NRSA63J-272X MG RESISTOR 2.7k
Ω 1/16W J
R1921 NRSA63J-272X MG RESISTOR 2.7k
Ω 1/16W J
R1922 NRSA63J-272X MG RESISTOR 2.7k Ω 1/16W J
R1923 NRSA63F-183X MG RESISTOR 18k Ω 1/16W F
R1924 NRSA63F-183X MG RESISTOR 18k Ω 1/16W F
R1925 NRSA63F-102X MG RESISTOR 1k Ω 1/16W F
R1926 NRSA63F-102X MG RESISTOR 1k Ω 1/16W F
R1927 NRSA63J-362X MG RESISTOR 3.6k Ω 1/16W J
R1928 NRSA63J-362X MG RESISTOR 3.6k Ω 1/16W J
R1929 NRSA63F-681X MG RESISTOR 680 Ω 1/16W F
R1930 NRSA63F-681X MG RESISTOR 680 Ω 1/16W F
R1931 NRSA63F-511X MG RESISTOR 510 Ω 1/16W F
R1932 NRSA63F-511X MG RESISTOR 510 Ω 1/16W F
R1937 NRSA63J-821X MG RESISTOR 820 Ω 1/16W J
R1938 NRSA63J-821X MG RESISTOR 820 Ω 1/16W J
R1939 NRSA63J-183X MG RESISTOR 18k
Ω 1/16W J
R1940 NRSA63J-183X MG RESISTOR 18k
Ω 1/16W J
R1941 NRSA63J-273X MG RESISTOR 27k Ω 1/16W J
R1942 NRSA63J-273X MG RESISTOR 27k Ω 1/16W J
R1943 NRSA63J-561X MG RESISTOR 560 Ω 1/16W J
R1944 NRSA63J-561X MG RESISTOR 560 Ω 1/16W J
R1947 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R1948 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R1951 NRSA63J-682X MG RESISTOR 6.8k Ω 1/16W J
R1952 NRSA63J-682X MG RESISTOR 6.8k Ω 1/16W J
R1953 NRSA63J-153X MG RESISTOR 15k Ω 1/16W J
R1954 NRSA63J-153X MG RESISTOR 15k Ω 1/16W J
R1959 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R1960 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R2900 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R2901 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R2902 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R2903 NRSA63J-471X MG RESISTOR 470 Ω 1/16W J
R2904 NRSA63J-471X MG RESISTOR 470 Ω 1/16W J
R2905 NRSA63J-332X MG RESISTOR 3.3k Ω 1/16W J
R2906 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R2907 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R2908 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R2909 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R2910 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R2911 NRSA63J-303X MG RESISTOR 30k Ω 1/16W J
R2912 NRSA63J-303X MG RESISTOR 30k Ω 1/16W J
R2913 NRSA63J-303X MG RESISTOR 30k Ω 1/16W J
R2914 NRSA63J-303X MG RESISTOR 30k Ω 1/16W J
R2915 NRSA63F-183X MG RESISTOR 18k
Ω 1/16W F
R2916 NRSA63F-183X MG RESISTOR 18k Ω 1/16W F
R2917 NRSA63F-183X MG RESISTOR 18k
Ω 1/16W F
R2918 NRSA63F-183X MG RESISTOR 18k
Ω 1/16W F
R2919 NRSA63J-272X MG RESISTOR 2.7k Ω 1/16W J
R2920 NRSA63J-272X MG RESISTOR 2.7k
Ω 1/16W J
R2921 NRSA63J-272X MG RESISTOR 2.7k
Ω 1/16W J
R2922 NRSA63J-272X MG RESISTOR 2.7k Ω 1/16W J
R2923 NRSA63F-183X MG RESISTOR 18k
Ω 1/16W F
R2924 NRSA63F-183X MG RESISTOR 18k Ω 1/16W F
R2925 NRSA63F-102X MG RESISTOR 1k
Ω 1/16W F
R2926 NRSA63F-102X MG RESISTOR 1k
Ω 1/16W F
R2927 NRSA63J-362X MG RESISTOR 3.6k Ω 1/16W J
R2928 NRSA63J-362X MG RESISTOR 3.6k
Ω 1/16W J
R2929 NRSA63F-681X MG RESISTOR 680
Ω 1/16W F
R2930 NRSA63F-681X MG RESISTOR 680 Ω 1/16W F
R2931 NRSA63F-511X MG RESISTOR 510
Ω 1/16W F
R2932 NRSA63F-511X MG RESISTOR 510
Ω 1/16W F
R2937 NRSA63J-821X MG RESISTOR 820
Ω 1/16W J
R2938 NRSA63J-821X MG RESISTOR 820
Ω 1/16W J
R2939 NRSA63J-183X MG RESISTOR 18k Ω 1/16W J
R2940 NRSA63J-183X MG RESISTOR 18k
Ω 1/16W J
R2941 NRSA63J-273X MG RESISTOR 27k
Ω 1/16W J
R2942 NRSA63J-273X MG RESISTOR 27k Ω 1/16W J
R2943 NRSA63J-561X MG RESISTOR 560
Ω 1/16W J
R2944 NRSA63J-561X MG RESISTOR 560
Ω 1/16W J
R2947 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R2948 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R2949 NRSA63J-473X MG RESISTOR 47k
Ω 1/16W J
 Symbol No. PartNo.Part Name Description
R2951 NRSA63J-123X MG RESISTOR 12k Ω 1/16W J
R2952 NRSA63J-682X MG RESISTOR 6.8k Ω 1/16W J
R2953 NRSA63J-153X MG RESISTOR 15k Ω 1/16W J
R2954 NRSA63J-153X MG RESISTOR 15k Ω 1/16W J
R2959 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R2960 NRSA63J-104X MG RESISTOR 100k
Ω 1/16W J
R2971 NRSA63J-562X MG RESISTOR 5.6k
Ω 1/16W J
R2972 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R2973 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R2974 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R2977 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R2978 NRSA63J-105X MG RESISTOR 1M Ω 1/16W J
R2979 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
CN901 QGB2016J1-15 CONNECTOR B-B (1-15)
CN902 QGB2016J1-13 CONNECTOR B-B (1-13)
K901 NQR0007-003X FERRITE BEADS
K902 NQR0007-003X FERRITE BEADS
K903 NQR0007-003X FERRITE BEADS
K904 NQR0007-003X FERRITE BEADS
K1901 NQR0007-003X FERRITE BEADS
K1902 NQR0007-003X FERRITE BEADS
K1903 NQR0007-003X FERRITE BEADS
K1904 NQR0007-003X FERRITE BEADS
K2901 NQR0007-003X FERRITE BEADS
K2902 NQR0007-003X FERRITE BEADS
K2903 NQR0007-003X FERRITE BEADS
K2904 NQR0007-003X FERRITE BEADS
 Symbol No. Part No. Part Name Description
IC402 NJM2246M-X IC
IC403 NJM2246M-X IC
IC404 NJM2246M-X IC
IC405 BA7625 IC
IC406 MM74HC4053SJ-X IC
Q1441 KTC3199/GL/-T TRANSISTOR
Q1442 KRC111S-X TRANSISTOR
Q1443 KTC3199/GL/-T TRANSISTOR
Q1444 KRC111S-X TRANSISTOR
Q1445 KTC3199/GL/-T TRANSISTOR
Q1446 KRC111S-X TRANSISTOR
Q1447 KTA1267/YG/-T TRANSISTOR
Q1448 KTA1267/YG/-T TRANSISTOR
Q1481 KTC3199/GL/-T TRANSISTOR
Q1482 KTC3199/GL/-T TRANSISTOR
Q1483 KTC3199/GL/-T TRANSISTOR
D1401 MTZJ13C-T2 Z DIODE
D1402 MTZJ13C-T2 Z DIODE
D1403 MTZJ13C-T2 Z DIODE
D1404 MTZJ13C-T2 Z DIODE
D1421 MTZJ13C-T2 Z DIODE
D1422 MTZJ13C-T2 Z DIODE
D1423 MTZJ13C-T2 Z DIODE
D1424 MTZJ13C-T2 Z DIODE
C303 NCS31HJ-331X C CAPACITOR 330pF 50V J
C304 NCS31HJ-331X C CAPACITOR 330pF 50V J
C307 NCS31HJ-331X C CAPACITOR 330pF 50V J
C308 NCS31HJ-331X C CAPACITOR 330pF 50V J
C325 NCS31HJ-331X C CAPACITOR 330pF 50V J
C326 NCS31HJ-331X C CAPACITOR 330pF 50V J
C327 NCS31HJ-331X C CAPACITOR 330pF 50V J
C328 NCS31HJ-331X C CAPACITOR 330pF 50V J
C1401 QEKC1HM-475Z E CAPACITOR 4.7uF 50V M
C1402 QEKC1HM-475Z E CAPACITOR 4.7uF 50V M
C1403 QEKC1HM-475Z E CAPACITOR 4.7uF 50V M
C1404 QETN0JM-477Z E CAPACITOR 470uF 6.3V M
C1405 NCS31HJ-470X C CAPACITOR 47pF 50V J
 Symbol No. Part No. Part Name Description
LVA10359
RSDX-02E
Parts LIst 11/15
13

DVD loading main board
C1406 QEKC1HM-475Z E CAPACITOR 4.7uF 50V M
C1421 QEKC1HM-475Z E CAPACITOR 4.7uF 50V M
C1422 QEKC1HM-475Z E CAPACITOR 4.7uF 50V M
C1423 QEKC1HM-475Z E CAPACITOR 4.7uF 50V M
C1424 QEKC1HM-475Z E CAPACITOR 4.7uF 50V M
C1461 QETN1CM-477Z E CAPACITOR 470uF 16V M
C1462 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C1463 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C1464 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C1481 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C1493 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C1494 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C1495 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
R305 NRSA63J-471X MG RESISTOR 470 Ω 1/16W J
R306 NRSA63J-471X MG RESISTOR 470 Ω 1/16W J
R313 NRSA63J-471X MG RESISTOR 470 Ω 1/16W J
R314 NRSA63J-471X MG RESISTOR 470 Ω 1/16W J
R323 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R324 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R1401 NRSA63J-331X MG RESISTOR 330
Ω 1/16W J
R1402 NRSA63J-750X MG RESISTOR 75
Ω 1/16W J
R1403 NRSA63J-331X MG RESISTOR 330 Ω 1/16W J
R1404 NRSA63J-750X MG RESISTOR 75 Ω 1/16W J
R1405 NRSA63J-750X MG RESISTOR 75 Ω 1/16W J
R1406 NRSA63J-331X MG RESISTOR 330 Ω 1/16W J
R1407 NRSA63J-750X MG RESISTOR 75 Ω 1/16W J
R1408 NRSA63J-473X MG RESISTOR 47k Ω 1/16W J
R1409 NRSA63J-750X MG RESISTOR 75 Ω 1/16W J
R1410 NRSA63J-331X MG RESISTOR 330 Ω 1/16W J
R1411 NRSA63J-750X MG RESISTOR 75 Ω 1/16W J
R1421 NRSA63J-331X MG RESISTOR 330 Ω 1/16W J
R1422 NRSA63J-750X MG RESISTOR 75 Ω 1/16W J
R1423 NRSA63J-331X MG RESISTOR 330 Ω 1/16W J
R1424 NRSA63J-750X MG RESISTOR 75 Ω 1/16W J
R1425 NRSA63J-750X MG RESISTOR 75 Ω 1/16W J
R1426 NRSA63J-331X MG RESISTOR 330 Ω 1/16W J
R1427 NRSA63J-750X MG RESISTOR 75 Ω 1/16W J
R1428 NRSA63J-331X MG RESISTOR 330 Ω 1/16W J
R1429 NRSA63J-750X MG RESISTOR 75 Ω 1/16W J
R1441 NRSA63J-301X MG RESISTOR 300 Ω 1/16W J
R1442 NRSA63J-391X MG RESISTOR 390 Ω 1/16W J
R1443 NRSA63J-301X MG RESISTOR 300 Ω 1/16W J
R1444 NRSA63J-391X MG RESISTOR 390 Ω 1/16W J
R1445 NRSA63J-301X MG RESISTOR 300 Ω 1/16W J
R1446 NRSA63J-391X MG RESISTOR 390 Ω 1/16W J
R1447 NRSA63J-301X MG RESISTOR 300 Ω 1/16W J
R1448 QRE141J-681Y C RESISTOR 680 Ω 1/4W J
R1449 NRSA63J-301X MG RESISTOR 300 Ω 1/16W J
R1450 QRE141J-681Y C RESISTOR 680
Ω 1/4W J
 R1461 QRJ146J-2R2X UNF C RESISTOR 2.2 Ω 1/4W J
R1481 NRSA63J-391X MG RESISTOR 390
Ω 1/16W J
R1482 NRSA63J-301X MG RESISTOR 300
Ω 1/16W J
R1483 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R1484 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R1485 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R1486 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R1487 NRSA63J-473X MG RESISTOR 47k
Ω 1/16W J
R1488 NRSA63J-473X MG RESISTOR 47k Ω 1/16W J
R1495 NRSA63J-222X MG RESISTOR 2.2k
Ω 1/16W J
R1496 NRSA63J-222X MG RESISTOR 2.2k
Ω 1/16W J
R1497 NRSA63J-222X MG RESISTOR 2.2k Ω 1/16W J
R1498 NRSA63J-222X MG RESISTOR 2.2k
Ω 1/16W J
CN401 QGF1205F1-17 CONNECTOR FFC/FPC (1-17)
CN402 QGF1205F1-16 CONNECTOR FFC/FPC (1-16)
J403 QNZ0516-001 RGB CONNECTOR
 Symbol No. Part No. Part Name Description
IC101 AN8703FH-V IC
 Symbol No. Part No. Part Name Description
IC201 BA5983FM-X IC
IC251 BA6664FM-X IC
IC301 MN103S26EGA IC
IC401 MN102L62GLF3 IC
IC451 S-93C66AFJ-X IC
IC501 NDV8611VWA IC
IC505 W986432DH-7 IC
IC509 SST39VF160-7CEK IC (FLASH)
IC510 AK93C65AF-X IC
IC511 LM1117MP1.8-X IC
IC512 74LCX373MTC-X IC(DIGITAL)
IC513 74LCX373MTC-X IC(DIGITAL)
IC521 MM74HCT32MTC-X IC
IC522 74LCX32MTC-X IC(DIGITAL)
IC523 NC7SZ125P5-X IC(DIGITAL)
Q101 KTA1001/Y/-X TRANSISTOR
Q102 KTA1001/Y/-X TRANSISTOR
Q103 DTA144EE-X DIGI TRANSISTOR
Q501 2SB1424/QR/-W TRANSISTOR
Q502 2SC2412K/RS/-X TRANSISTOR
Q801 2SC4617/R/-X TRANSISTOR
Q802 2SA1774/R/-X TRANSISTOR
Q803 2SC4617/R/-X TRANSISTOR
Q804 2SC4617/R/-X TRANSISTOR
Q805 2SC4617/R/-X TRANSISTOR
Q806 2SC4617/R/-X TRANSISTOR
Q807 DTC114EE-X DIGI TRANSISTOR
Q808 2SC4617/R/-X TRANSISTOR
D101 RB521S-30-X SB DIODE
D202 1SS355-X SI DIODE
C105 NEA70JM-476X E CAPACITOR 47uF 6.3V M
C106 NEA70JM-476X E CAPACITOR 47uF 6.3V M
C109 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C110 NCS31HJ-221X C CAPACITOR 220pF 50V J
C111 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C112 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C113 NEA70JM-226X E CAPACITOR 22uF 6.3V M
C115 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C116 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C117 NCB31CK-473X C CAPACITOR 0.047uF 16V K
C118 NCB31CK-273X C CAPACITOR 0.027uF 16V K
C119 NCB31HK-561X C CAPACITOR 560pF 50V K
C120 NCB31HK-561X C CAPACITOR 560pF 50V K
C121 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C122 NCS31HJ-120X C CAPACITOR 12pF 50V J
C123 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C124 NCS31HJ-470X C CAPACITOR 47pF 50V J
C125 NCB31HK-271X C CAPACITOR 270pF 50V K
C126 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C127 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C128 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C129 NCB31HK-472X C CAPACITOR 4700pF 50V K
C135 NEA70JM-476X E CAPACITOR 47uF 6.3V M
C137 NEA70GM-476X E CAPACITOR 47uF 4V M
C138 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C139 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C141 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C142 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C143 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C144 NCB31CK-103X C CAPACITOR 0.01uF 16V K
C146 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C201 NEA70JM-226X E CAPACITOR 22uF 6.3V M
C203 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C204 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C205 NCS31HJ-121X C CAPACITOR 120pF 50V J
C207 NCB31HK-391X C CAPACITOR 390pF 50V K
C208 NCB31HK-391X C CAPACITOR 390pF 50V K
C211 NCB31HK-223X C CAPACITOR 0.022uF 50V K
C212 NCB31CK-103X C CAPACITOR 0.01uF 16V K
C215 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C216 NCB30JK-105X C CAPACITOR 1uF 6.3V K
C217 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C218 NCB30JK-105X C CAPACITOR 1uF 6.3V K
C251 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C252 NEA71AM-336X E CAPACITOR 33uF 10V M
 Symbol No. Part No. Part Name Description
LVA10298
Parts List 12/15
RSDX-02E
14

C253 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C255 NCB31CK-153X C CAPACITOR 0.015uF 16V K
C256 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C257 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C258 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C259 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C260 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C261 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C262 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C263 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C264 NCB31CK-103X C CAPACITOR 0.01uF 16V K
C301 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C302 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C303 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C304 NEA70GM-107X E CAPACITOR 100uF 4V M
C306 NEA70GM-107X E CAPACITOR 100uF 4V M
C308 NEA70GM-107X E CAPACITOR 100uF 4V M
C310 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C311 NCB31HK-561X C CAPACITOR 560pF 50V K
C312 NCB31HK-561X C CAPACITOR 560pF 50V K
C313 NCB31HK-561X C CAPACITOR 560pF 50V K
C314 NCB31HK-331X C CAPACITOR 330pF 50V K
C315 NCB31HK-471X C CAPACITOR 470pF 50V K
C316 NCB31HK-271X C CAPACITOR 270pF 50V K
C317 NCS31HJ-121X C CAPACITOR 120pF 50V J
C318 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C319 NCB31HK-102X C CAPACITOR 1000pF 50V K
C320 NCB31HK-102X C CAPACITOR 1000pF 50V K
C321 NCB31HK-102X C CAPACITOR 1000pF 50V K
C322 NCB31HK-562X C CAPACITOR 5600pF 50V K
C323 NCB31HK-102X C CAPACITOR 1000pF 50V K
C324 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C325 NCS31HJ-470X C CAPACITOR 47pF 50V J
C326 NCB31CK-183X C CAPACITOR 0.018uF 16V K
C327 NCB31HK-102X C CAPACITOR 1000pF 50V K
C328 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C329 NCB31CK-103X C CAPACITOR 0.01uF 16V K
C330 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C331 NCB31CK-103X C CAPACITOR 0.01uF 16V K
C332 NCB21CK-105X C CAPACITOR 1uF 16V K
C333 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C334 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C337 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C338 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C339 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C340 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C341 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C342 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C343 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C344 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C345 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C346 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C347 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C348 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C349 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C350 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C401 NEA70GM-476X E CAPACITOR 47uF 4V M
C402 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C403 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C404 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C405 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C406 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C407 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C450 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C501 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C502 NCS31HJ-471X C CAPACITOR 470pF 50V J
C503 NCS31HJ-471X C CAPACITOR 470pF 50V J
C506 NCS31HJ-150X C CAPACITOR 15pF 50V J
C507 NCS31HJ-180X C CAPACITOR 18pF 50V J
C509 NCS31HJ-471X C CAPACITOR 470pF 50V J
C510 NCS31HJ-471X C CAPACITOR 470pF 50V J
C511 NEA70GM-476X E CAPACITOR 47uF 4V M
C512 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C513 NCS31HJ-471X C CAPACITOR 470pF 50V J
C514 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C515 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C516 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C517 NCB31CK-104X C CAPACITOR 0.1uF 16V K
 Symbol No. PartNo.Part Name Description
C518 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C519 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C520 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C523 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C524 NEA70GM-476X E CAPACITOR 47uF 4V M
C527 NEA70GM-476X E CAPACITOR 47uF 4V M
C528 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C529 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C531 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C532 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C533 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C534 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C535 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C536 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C539 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C540 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C541 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C542 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C543 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C544 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C545 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C547 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C548 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C549 NEA70GM-476X E CAPACITOR 47uF 4V M
C550 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C554 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C555 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C557 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C558 NCB11CK-105X C CAPACITOR 1uF 16V K
C569 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C571 NEA70GM-476X E CAPACITOR 47uF 4V M
C572 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C573 NEA70GM-227X E CAPACITOR 220uF 4V M
C578 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C580 NEA70GM-476X E CAPACITOR 47uF 4V M
C581 NEA70GM-227X E CAPACITOR 220uF 4V M
C582 NEA70GM-476X E CAPACITOR 47uF 4V M
C601 NEA70GM-476X E CAPACITOR 47uF 4V M
C602 NEA70GM-476X E CAPACITOR 47uF 4V M
C618 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C619 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C801 NCS31HJ-680X C CAPACITOR 68pF 50V J
C802 NCS31HJ-680X C CAPACITOR 68pF 50V J
C803 NCS31HJ-120X C CAPACITOR 12pF 50V J
C804 NCS31HJ-102X C CAPACITOR 1000pF 50V J
C805 NCS31HJ-820X C CAPACITOR 82pF 50V J
C806 NCS31HJ-221X C CAPACITOR 220pF 50V J
C807 NCS31HJ-180X C CAPACITOR 18pF 50V J
C808 NCS31HJ-181X C CAPACITOR 180pF 50V J
C809 NCB31HK-392X C CAPACITOR 3900pF 50V K
C810 NCB31CK-183X C CAPACITOR 0.018uF 16V K
C902 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C904 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C906 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C908 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C992 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C993 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C994 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C995 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C996 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C997 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C998 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C1000 NCS31HJ-471X C CAPACITOR 470pF 50V J
C1001 NCS31HJ-471X C CAPACITOR 470pF 50V J
C1002 NCS31HJ-471X C CAPACITOR 470pF 50V J
C1003 NCS31HJ-471X C CAPACITOR 470pF 50V J
C1004 NCS31HJ-471X C CAPACITOR 470pF 50V J
C1005 NCS31HJ-471X C CAPACITOR 470pF 50V J
R101 NRSA63J-333X MG RESISTOR 33k Ω 1/16W J
R102 NRSA63J-223X MG RESISTOR 22k
Ω 1/16W J
R103 NRSA63J-223X MG RESISTOR 22k
Ω 1/16W J
R104 NRS125J-270X MG RESISTOR 27 Ω 1/2W J
R105 NRS125J-270X MG RESISTOR 27
Ω 1/2W J
R106 NRSA63J-273X MG RESISTOR 27k
Ω 1/16W J
R107 NRSA63J-273X MG RESISTOR 27k Ω 1/16W J
R108 NRSA63J-222X MG RESISTOR 2.2k
Ω 1/16W J
R109 NRSA63J-182X MG RESISTOR 1.8k
Ω 1/16W J
 Symbol No. Part No. Part Name Description
RSDX-02E
Parts List 13/15
15

R110 NRSA63J-333X MG RESISTOR 33k Ω 1/16W J
R111 NRVA63D-243X CMF RESISTOR 24k Ω 1/16W D
R112 NRSA63J-822X MG RESISTOR 8.2k Ω 1/16W J
R113 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R114 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R115 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R116 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R117 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R119 NRSA63J-2R2X MG RESISTOR 2.2 Ω 1/16W J
R120 NRSA63J-2R2X MG RESISTOR 2.2 Ω 1/16W J
R125 NRSA63J-105X MG RESISTOR 1M Ω 1/16W J
R126 NRSA63J-105X MG RESISTOR 1M Ω 1/16W J
R127 NRSA63J-222X MG RESISTOR 2.2k Ω 1/16W J
R128 NRS125J-1R0X MG RESISTOR 1 Ω 1/2W J
R129 NRS125J-1R0X MG RESISTOR 1 Ω 1/2W J
R130 NRSA63J-182X MG RESISTOR 1.8k Ω 1/16W J
R201 NRSA63J-470X MG RESISTOR 47 Ω 1/16W J
R202 NRS125J-1R0X MG RESISTOR 1 Ω 1/2W J
R203 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R204 NRSA63J-273X MG RESISTOR 27k Ω 1/16W J
R205 NRSA63J-273X MG RESISTOR 27k
Ω 1/16W J
R206 NRSA63J-303X MG RESISTOR 30k
Ω 1/16W J
R207 NRSA63J-473X MG RESISTOR 47k Ω 1/16W J
R208 NRSA63J-223X MG RESISTOR 22k Ω 1/16W J
R209 NRSA63J-223X MG RESISTOR 22k Ω 1/16W J
R210 NRSA63J-242X MG RESISTOR 2.4k Ω 1/16W J
R211 NRSA63J-242X MG RESISTOR 2.4k Ω 1/16W J
R212 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R213 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R214 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R215 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R216 NRSA63J-912X MG RESISTOR 9.1k Ω 1/16W J
R217 NRSA63J-201X MG RESISTOR 200 Ω 1/16W J
R218 NRSA63J-221X MG RESISTOR 220 Ω 1/16W J
R219 NRSA63J-183X MG RESISTOR 18k Ω 1/16W J
R220 NRSA63J-243X MG RESISTOR 24k Ω 1/16W J
R221 NRSA63J-682X MG RESISTOR 6.8k Ω 1/16W J
R222 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R223 NRSA63J-912X MG RESISTOR 9.1k Ω 1/16W J
R224 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R251 NRS125J-R47X MG RESISTOR 0.47 Ω 1/2W J
R252 NRSA63J-2R2X MG RESISTOR 2.2 Ω 1/16W J
R253 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R254 NRSA63J-203X MG RESISTOR 20k Ω 1/16W J
R255 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R256 NRSA63J-470X MG RESISTOR 47 Ω 1/16W J
R258 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R259 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R301 NRSA63J-473X MG RESISTOR 47k Ω 1/16W J
R302 NRSA63J-473X MG RESISTOR 47k
Ω 1/16W J
R303 NRSA63J-473X MG RESISTOR 47k Ω 1/16W J
R304 NRSA63J-473X MG RESISTOR 47k
Ω 1/16W J
R305 NRSA63J-473X MG RESISTOR 47k
Ω 1/16W J
R306 NRSA63J-473X MG RESISTOR 47k Ω 1/16W J
R307 NRSA63J-473X MG RESISTOR 47k
Ω 1/16W J
R308 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R309 NRSA63J-473X MG RESISTOR 47k Ω 1/16W J
R313 NRSA63J-473X MG RESISTOR 47k
Ω 1/16W J
R317 NRSA63J-473X MG RESISTOR 47k Ω 1/16W J
R319 NRSA63J-473X MG RESISTOR 47k
Ω 1/16W J
R320 NRSA63J-105X MG RESISTOR 1M
Ω 1/16W J
R321 NRSA63J-473X MG RESISTOR 47k Ω 1/16W J
R323 NRSA63J-473X MG RESISTOR 47k
Ω 1/16W J
R324 NRSA63J-473X MG RESISTOR 47k
Ω 1/16W J
R325 NRSA63J-123X MG RESISTOR 12k Ω 1/16W J
R326 NRSA63J-473X MG RESISTOR 47k
Ω 1/16W J
R327 NRSA63J-105X MG RESISTOR 1M
Ω 1/16W J
R328 NRSA63J-183X MG RESISTOR 18k
Ω 1/16W J
R329 NRSA63J-473X MG RESISTOR 47k
Ω 1/16W J
R332 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R333 NRSA63J-183X MG RESISTOR 18k
Ω 1/16W J
R334 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R336 NRSA63J-273X MG RESISTOR 27k Ω 1/16W J
R337 NRSA63J-273X MG RESISTOR 27k
Ω 1/16W J
R338 NRSA63J-472X MG RESISTOR 4.7k
Ω 1/16W J
R339 NRSA63J-472X MG RESISTOR 4.7k Ω 1/16W J
R340 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R341 NRSA63J-562X MG RESISTOR 5.6k
Ω 1/16W J
 Symbol No. Part No. Part Name Description
R402 NRSA63J-472X MG RESISTOR 4.7k Ω 1/16W J
R403 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R405 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R411 NRSA63J-472X MG RESISTOR 4.7k Ω 1/16W J
R413 NRSA63J-472X MG RESISTOR 4.7k Ω 1/16W J
R414 NRSA63J-472X MG RESISTOR 4.7k
Ω 1/16W J
R421 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R422 NRSA63J-472X MG RESISTOR 4.7k Ω 1/16W J
R423 NRSA63J-472X MG RESISTOR 4.7k Ω 1/16W J
R424 NRSA63J-472X MG RESISTOR 4.7k Ω 1/16W J
R427 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R428 NRSA63J-472X MG RESISTOR 4.7k Ω 1/16W J
R501 NRSA63J-470X MG RESISTOR 47 Ω 1/16W J
R512 NRSA63J-332X MG RESISTOR 3.3k Ω 1/16W J
R521 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R531 NRSA63J-562X MG RESISTOR 5.6k Ω 1/16W J
R532 NRSA63J-392X MG RESISTOR 3.9k Ω 1/16W J
R533 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R534 NRSA63J-561X MG RESISTOR 560 Ω 1/16W J
R535 NRSA63J-333X MG RESISTOR 33k Ω 1/16W J
R536 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R541 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R542 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R543 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R544 NRSA63J-471X MG RESISTOR 470 Ω 1/16W J
R547 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R548 NRSA63J-471X MG RESISTOR 470 Ω 1/16W J
R549 NRSA63J-471X MG RESISTOR 470 Ω 1/16W J
R550 NRSA63J-471X MG RESISTOR 470 Ω 1/16W J
R551 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R552 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R553 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R565 NRVA63D-622X CMF RESISTOR 6.2k Ω 1/16W D
R566 NRVA63D-132X CMF RESISTOR 1.3k Ω 1/16W D
R570 NRSA63J-100X MG RESISTOR 10 Ω 1/16W J
R573 NRSA63J-162X MG RESISTOR 1.6k Ω 1/16W J
R574 NRSA63J-162X MG RESISTOR 1.6k Ω 1/16W J
R575 NRSA63J-471X MG RESISTOR 470 Ω 1/16W J
R576 NRSA63J-471X MG RESISTOR 470 Ω 1/16W J
R578 NRSA63J-471X MG RESISTOR 470 Ω 1/16W J
R579 NRSA63J-471X MG RESISTOR 470 Ω 1/16W J
R580 NRSA63J-471X MG RESISTOR 470 Ω 1/16W J
R583 NRSA63J-471X MG RESISTOR 470 Ω 1/16W J
R584 NRSA63J-332X MG RESISTOR 3.3k Ω 1/16W J
R608 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R655 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R738 NRSA63J-152X MG RESISTOR 1.5k Ω 1/16W J
R739 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R740 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R801 NRSA63J-123X MG RESISTOR 12k
Ω 1/16W J
R802 NRSA63J-223X MG RESISTOR 22k Ω 1/16W J
R803 NRSA63J-122X MG RESISTOR 1.2k
Ω 1/16W J
R804 NRSA63J-821X MG RESISTOR 820
Ω 1/16W J
R805 NRSA63J-242X MG RESISTOR 2.4k Ω 1/16W J
R806 NRSA63J-821X MG RESISTOR 820
Ω 1/16W J
R807 NRSA63J-222X MG RESISTOR 2.2k
Ω 1/16W J
R808 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R809 NRSA63J-223X MG RESISTOR 22k
Ω 1/16W J
R810 NRSA63J-222X MG RESISTOR 2.2k Ω 1/16W J
R811 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R812 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R813 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R814 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R815 NRSA63J-821X MG RESISTOR 820
Ω 1/16W J
R816 NRSA63J-820X MG RESISTOR 82 Ω 1/16W J
R817 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R818 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R991 NRSA63J-220X MG RESISTOR 22
Ω 1/16W J
L501 NQL044K-100X COIL 10uH K
CN101 QGF0522F1-30W CONNECTOR FFC/FPC (1-30)
CN201 QGF1016F2-15W CONNECTOR FFC/FPC (1-15)
CN202 QGF1016F2-06W CONNECTOR FFC/FPC (1-6)
CN502 QGB2027L1-26X CONNECTOR B-B (1-26)
CN503 QGB2027L1-26X CONNECTOR B-B (1-26)
K101 NQR0007-002X FERRITE BEADS
K301 NQR0007-002X FERRITE BEADS
 Symbol No. Part No. Part Name Description
Parts List 14/15
RSDX-02E
16

DVD Spindle Motor board
K302 NQR0007-002X FERRITE BEADS
K303 NQR0007-002X FERRITE BEADS
K304 NQR0007-002X FERRITE BEADS
K401 NQR0007-002X FERRITE BEADS
K501 NQR0007-002X FERRITE BEADS
K504 NQR0007-002X FERRITE BEADS
K505 NQR0007-002X FERRITE BEADS
K507 NQR0007-002X FERRITE BEADS
K508 NQR0007-002X FERRITE BEADS
K509 NQR0007-002X FERRITE BEADS
K510 NQR0007-002X FERRITE BEADS
K513 NQR0007-002X FERRITE BEADS
K515 NRSA02J-0R0X MG RESISTOR 0 1/10W J
K518 NRSA02J-0R0X MG RESISTOR 0 1/10W J
K519 NQR0007-002X FERRITE BEADS
K520 NQR0007-002X FERRITE BEADS
K556 NQR0129-002X FERRITE BEADS
K557 NQR0129-002X FERRITE BEADS
K558 NQR0129-002X FERRITE BEADS
K559 NQR0129-002X FERRITE BEADS
K560 NRSA02J-0R0X MG RESISTOR 0 1/10W J
K561 NRSA02J-0R0X MG RESISTOR 0 1/10W J
K562 NRSA02J-0R0X MG RESISTOR 0 1/10W J
K563 NRSA02J-0R0X MG RESISTOR 0 1/10W J
K564 NRSA02J-0R0X MG RESISTOR 0 1/10W J
K565 NRSA02J-0R0X MG RESISTOR 0 1/10W J
K566 NRSA02J-0R0X MG RESISTOR 0 1/10W J
K567 NQR0007-002X FERRITE BEADS
K568 NRSA02J-0R0X MG RESISTOR 0 1/10W J
K569 NQR0007-002X FERRITE BEADS
K570 NRSA02J-0R0X MG RESISTOR 0 1/10W J
K571 NQR0007-002X FERRITE BEADS
K572 NRSA02J-0R0X MG RESISTOR 0 1/10W J
K573 NQR0007-002X FERRITE BEADS
K574 NRSA02J-0R0X MG RESISTOR 0 1/10W J
K575 NRSA02J-0R0X MG RESISTOR 0 1/10W J
K576 NRSA02J-0R0X MG RESISTOR 0 1/10W J
K577 NQR0007-002X FERRITE BEADS
K578 NRSA02J-0R0X MG RESISTOR 0 1/10W J
K579 NRSA02J-0R0X MG RESISTOR 0 1/10W J
K582 NRSA02J-0R0X MG RESISTOR 0 1/10W J
K586 NRSA02J-0R0X MG RESISTOR 0 1/10W J
X301 NAX0542-001X C RESONATOR 16.93MHz
X401 NAX0543-001X C RESONATOR 13.50MHz
X571 NAX0513-001X CRYSTAL 27.000MHz
Symbol No. Part No. Part Name Description
CN1 QGF1016F3-06 CONNECTOR FFC/FPC (1-6)
S1 QSW0910-002 SWITCH
S2 QSW0910-002 SWITCH
Symbol No. Part No. Part Name Description
LVB10242
Parts List 15/15 RSDX-02E
LVB10242
17

PARTS LIST 1/1 RSDX-02E
SYMBOL PART No. DESCRIPTION
011 FP-569-B FRONT PANEL ASSY (BLACK)
011 FP-569-S FRONT PANEL ASSY (SILVER)
012 RV4-09A00 PUSH BUTTON 14F (BLK)
012 RV4-09A01 PUSH BUTTON 14F (SLV)
012 TB3-16A00 KNOB 44F BLK(NO MARK)
012 TB3-16A00S KNOB 44F SLV(NO MARK)
012 UX3-09A00 TACT BUTTON 13KEY(SLV)
012 UX3-09A01 TACT BUTTON 13KEY(BLK)
012 UX3-10A00 TACT BUTTON 3KEY(SLV)
012 UX3-10A01 TACT BUTTON 3KEY(BLK)
012 UX3-13A00 TACT BUTTON 4KEY(SLV)
012 UX3-13A01 TACT BUTTON 4KEY(BLK)
014 C-4854A00 ORNAMENT SIDE BOARD 109MM SILVER
014 C-4854A01 ORNAMENT SIDE BOARD 109MM BLACK
014 FP-570-B DVD DOOR (BLACK)
014 FP-570-S DVD DOOR (SILVER)
014 UX3-08A00 UPPER COVER(SLV)
014 UX3-08A01 UPPER COVER(BLK)
016 X-1410A00 SWITCH PCB RSDX-02
X2 019 4TR-2823#2 PLASTIC FOOT (24Φ)
X2 019 4TSH-19#2 PLASTIC FOOT (50Φ)
019 C-4714A00 POWER KNOB RING 14F (BLK)
019 C-4714A01 POWER KNOB RING 14F (SLV)
019 PR4-12B00 KNOB RING(RED) 46F
019 PR4-12B01 KNOB RING(BLU) 46F
019 UD4-04A00 TACT BUTTON 3KEY RING(SLV)
019 UD4-04A01 TACT BUTTON 3KEY RING(BLK)
021 RLA172A00 AM LOOP ANT
034 SEL1E24W LED (BLU) 1X5
061 4TR-2947 PUSH SWITCH SPUN12K007
062 C-2629A01 AC 2P INLET 6102.3100 (WIRING)
065 C-4858A00 3.5ΦMINI JACK
X2 067 C-4761A01 SPEAKER TERMINAL (4P)
067 C-4762A01 SPEAKER TERMINAL (2P)
072 4TR-3228 T TYPE ANTENNA
072 C-4623A01 AC CORD SET BS
072 C-4624A01 AC CORD SET EC
072 C-4741A01 AC CORD SET EC (2.5A)
072 C-4743A01 AC CORD SET BS (2.5A)
081 UX3-15A01 INSIDE CARTON RSDX-02E
081 UX3-16A01 SHIPPING CARTON RSDX-02E
081 Z-211 STYROL MOULDING
082 OMRR-1070-1 OWNER'S MANUAL (EFS)
082 OMRR-1070-2 OWNER'S MANUAL (GIDSw)
082 OMRSDX-02E OWNER'S MANUAL
090 RX-DV31-MECH DVD MECH ASSY
092 RR-1070 REMOTE UNIT
QAR0244-001 FAN MOTOR
QAU0278-003 FRONTEND
QQT0371-004 POWER TRANSFORMER (230V)
SUB TRANS (94) QUQ412-1015CJ FFC WIRE
FRONTEND (98) QUQ412-1106CJ FFC WIRE
DSP PCB (99) QUQ412-1217CJ FFC WIRE
MAIN - FL PCB (95) QUQ412-1328CJ FFC WIRE
SCART PCB (97) QUQ412-1606CJ FFC WIRE
SCART PCB (96) QUQ412-1706CJ FFC WIRE
OTHERS
18

RSDX02
SYMBOL PARTS DESCRIPTION
011 FP-568-B FRONT PANEL ASSY (BLK) RSDX-02
011 FP-568-S FRONT PANEL ASSY (SLV) RSDX-02
011 FP-569-B FRONT PANEL ASSY (BLK) RSDX-02E
011 FP-569-S FRONT PANEL ASSY (SLV) RSDX-02E
012 RV4-09A00 PUSH BUTTON 14F
(
BLK
)
012 RV4-09A01 PUSH BUTTON 14F
(
SLV
)
012 TB3-16A00 KNOB 44F BLK
(
NO MARK
)
012 TB3-16A00S KNOB 44F SLV
(
NO MARK
)
012 UX3-09A00 TACT BUTTON 13KEY
(
SLV
)
012 UX3-09A01 TACT BUTTON 13KEY
(
BLK
)
012 UX3-10A00 TACT BUTTON 3KEY
(
SLV
)
012 UX3-10A01 TACT BUTTON 3KEY
(
BLK
)
012 UX3-13A00 TACT BUTTON 4KEY
(
SLV
)
012 UX3-13A01 TACT BUTTON 4KEY
(
BLK
)
014 C-4854A00 ORNAMENT SIDE BOARD H=109MM SLV
014 C-4854A01 ORNAMENT SIDE BOARD H=109MM BLK
014 FP-570-B TRAY FITTING
(
BLK
)
014 FP-570-S TRAY FITTING
(
SLV
)
014 UX3-08A00 UPPER COVER
(
SLV
)
014 UX3-08A01 UPPER COVER
(
BLK
)
034 SEL1124R LED (RED) 1X5
034 SEL1E24W LED (BLU) 1X5
Addendum List for Black and Silve
r
19

Troubleshooting
Use this chart to help you solve daily operational problems.
PROBLEM
The power does not come on.
No sound from speakers.
Sound from one speaker only.
“OVERLOAD” starts flashing on the
display.
The STANDBY lamp lights up after
turning on the power, but soon the
unit turns off (into standby mode).
Remote control does not operate as
you intend.
Remote control does not work.
SOLUTION
Plug the power cord into an AC outlet.
Check speaker wiring and reconnect if
necessary.
Connect the cord properly
Select the correct source.
Press MUTING on the remote control to
cancel the muting.
Select the correct input mode (analog or
digital).
Check connections.
Adjust the balance properly.
1. Press STANDBY/ON on the front panel
to turn off the unit.
2. Stop the playback source.
3. Turn on the unit again, and adjust the
volume.
Press STANDBY/ON on the front panel to
turn off the unit, then check the speaker
wiring.
If “OVERLOAD” does not disappear, unplug
the AC power cord, then plug it back again.
If speaker wiring is not short-circuited, contact
your dealer.
Press STANDBY/ON on the front panel to
turn off the unit. After unplugging the power
cord, consult your dealer.
Press a source selecting button first, then
press the buttons you want to use.
Come closer to the unit. Operate the remote
control within 7 m (23 ft) from the unit.
Remove the obstruction.
Aim the remote control at the remote sensor
on each component you want to operate.
Insert the batteries correctly.
Replace batteries.
POSSIBLE CAUSE
The power cord is not plugged in.
Speaker signal cables are not
connected.
The audio cable is not connected
properly.
An incorrect source is selected.
Muting is activated.
An incorrect input mode (analog or
digital) is selected.
Connections are incorrect.
The balance is set to one extreme.
Speakers are overloaded because
of high volume.
Speakers are overloaded because
of short circuit of speaker terminals.
The unit is overloaded because of a
high voltage.
The remote control is not ready for
your intended operation.
It is too far from the unit, or is not
facing the unit.
There is an obstruction hiding the
remote sensor on the unit.
The remote control is not aimed at
the remote sensor on the unit or
components.
The batteries have been inserted
into the wrong way round (+/–).
Batteries are weak.
7General
61-72_RX-DV31SL[J]f.p65 03.2.28, 14:3169
20
