Rotel RSX-1055 User manual

Technical
Manual
SURROUND SOUND RECEIVER
RSX-1055
Table of Contents
Specification......................................1
Parts List...........................................2~13
Adjustment........................................14~16
Wiring................................................17
PCB Assembly..................................18~24
Schematic Diagram ..........................25~38
SHINSEN-BLD. 4F 10-10 SHINSEN-CHO, SHIBUYA-KU,
TOKYO 150-0045, JAPAN
Serial. NO.
Beginning
®
Quality Uncompromised
Y-366B-0207/pdf
THE ROTEL CO., LTD.
Specifications
Antenna Input
75 ohms unbalanced
AM Tuner
Sensitivity
500 mV/m
Signal to Noise Ratio
40 dBf
Output level
500 mV
Antenna Input
Loop Antenna
General
Power Consumption:
450 watts
Power Requirements (AC)
115 volts, 60Hz (USA version)
230 volts, 50Hz (CE version)
Weight
17 Kg/37.4 lb.
Dimensions (W x H x D)
432 x 162 x 442 mm
17.01" x 6.38" x 17.40"
Front Panel Height
(feet removed/for rack mount)
150 mm / 5.91"
Audio
Continuous Amplifier Power
(five channels driven)
75 watts/ch (20-20k Hz, <0.09% THD, 8 ohms)
Continuous Amplifier Power
(two channels driven)
100 watts/ch (1kHz, <1.0% THD, 8 ohms, DIN)
Total Harmonic Distor tion
<0.09%
Intermodulation Distor tion (60 Hz:7 kHz)
<0.05%
Frequency Response
10 Hz - 20 kHz, ±1 dB (analog input)
10 Hz - 20 kHz, ±0.3 dB (digital input)
Signal to Noise Ratio (IHF A-weighted)
92 dB (Stereo) Analog
90 dB (Dolby Digital, dts) 0dBFs
Input Sensitivity/Impedance
Line Level: 200 mV/47 kohms
Tone Contr ols (Bass/T reble)
±8 dB at 100 Hz/10 kHz
Preamp Output Level
1.2 V (200 mV Input)
Video
Frequency Response
3 Hz – 10 MHz, ± 3 dB
Signal to Noise Ratio
45 dB
Input Impedance
75 ohms
Output Impedance
75 ohms
Output Level
1 volt
FM Tuner
Usable Sensitivity
14.2 dBf
Signal to Noise Ratio (at 65 dBf)
70 dBf
Harmonic Distortion (at 65 dBf)
0.03%
Stereo Separation (1 kHz)
45 dB
Output level
1 V
V02
2341001 ~

SPEAKERS FRONT/CB
R/2
SURROUND
L
R
CENTER
L/1
SURROUND SOUND RECEIVER
MODEL NO. RSX-1055
POWER CONSUMPTION: 450 WATTS
IN OUT
MONITOR
OUT
COMPOSITE IN COMPOSITE OUT
VIDEO OUT
1 2 31 2 3 4 5
VIDEO INTAPECD
INPUT
L
R
PREOUT DIGITAL INPUT
DIGITAL
OUPUT
21
21 32 3 541
COAXIAL
COAXIAL OPTICAL
3
21OPTICAL
L
R
REARCB1FRONT CTR1SUB1
CB2 CTR2SUB2
COMPUTER
I/O S-VIDEO IN S-VIDEO OUT
1 2 3 4 5 21 3
12V TRIG
OUT
12
ZONE REM EXT REM
IR
OUT
12
L
R
ZONE
OUT
CB1
REAR LFRONT L CENTER
REAR R SUBFRONT R
MULTI INPUT
Y
C
R
C
B
21 IN
MONITOR
OUT
COMPONENT VIDEO
SOFTWARE
UPGRADABLE OFF
ON
S.C.
IR
ANTENNA
2CH DOLBY
PLII/3ST DTS NEO 6 DSP MULTI INPUT DYNAMIC RANGE RECZONE
CD TUNER TAPE
SURROUND SOUND RECEIVER RSX-1055
POWER
VIDEO1 VIDEO2 VIDEO3 VIDEO5VIDEO4
6 7 8 9 0 DIRECT MEMORYMONO
12345 TUNING
VOLUME
BAND
Appearance RSX-1055
2

Parts List 1/10
SYMBOL PARTS NO. DESCRIPTION
501 E-1337 PCB ASSY
L801 021 LAL02TB100M INDUCTOR 10uH
L802 021 LAL02TB101M INDUCTOR 100uH
X801 023 HC49U-001WR CRYSTAL 14.31818MHz
IC901-903 031 KIA7805P IC (REGULATOR +5V)
IC905 031 KIA7806PI IC (REGULATOR +6V)
IC907 031 KIA7815PI IC (REGULATOR +15V)
IC904 031 KIA7906PI IC (REGULATOR -6V)
IC906 031 KIA7915PI IC (REGULATOR -15V)
IC801 031 KS5520-1 IC (SCREEN DISPLAY)
IC205-209,302,303 031 NJM5532D IC (DUAL OPEAMP)
IC201,202,802 031 TC9163AN IC (SWITCH ARRAY)
IC301 031 TC9459N IC (VOLUME)
IC803 031 TSH94IN IC (QUAD OPEAMP)
Q902 032 D600-EF TRANSISTOR 2SD600K-EF
Q209-212,303 032 TA1564 TRANSISTOR 2SA1564AC
Q201-208,301,302 032 TDTC323TS TRANSISTOR
Q801,802,805,901 033 TA1450-ST TRANSISTOR 2SA1450AA-ST
Q213,304,803,804,903-905 033 TC3708-ST TRANSISTOR 2SC3708AA-ST
D901-914,918 034 1N4004 DIODE (1A 400V)
CP906 034 P43T7D200BW20 POSISTOR
D801-803,915-917,919,930 034 T1N4148-86 DIODE 1N4148TAP
D922 034 TRD12JST1 ZENER DIODE 12V (AB2)
D920 034 TRD27JST1 ZENER DIODE 27V (AB2)
D923 034 TRD4.3EST1 ZENER DIODE 4.3V (B2)
D932 034 TRD5.1JST1 ZENER DIODE 5.1V (AB2)
D921,924 034 TRD9.1JST1 ZENER DIODE 9.1V (AB2)
F903,904 036 LT5-020H AXIAL TYPE FUSE 2A
C805-808,812,813,816,817,827,833 041 TUTES1A101-TF ELECTROLYTIC CAPACITOR 10V100uF
C906 041 TUTES1C103-TS ELECTROLYTIC CAPACITOR 16V10000uF
C904,905 041 TUTES1C222-TS ELECTROLYTIC CAPACITOR 16V2200uF
C801-804,935 041 TUTES1C471-TF ELECTROLYTIC CAPACITOR 16V470uF
C901 041 TUTES1C472-TS ELECTROLYTIC CAPACITOR 16V4700uF
C909 041 TUTES1E101-TF ELECTROLYTIC CAPACITOR 25V100uF
C908 041 TUTES1E221-TF ELECTROLYTIC CAPACITOR 25V220uF
C249-264,351-354,368,369 041 TUTES1E470-TF ELECTROLYTIC CAPACITOR 25V47uF
C810,811,918 041 TUTES1E470-TF ELECTROLYTIC CAPACITOR 25V47uF
C821,822,910-916 041 TUTES1H010-TF ELECTROLYTIC CAPACITOR 50V1uF
C269,270,809,919 041 TUTES1H100-TF ELECTROLYTIC CAPACITOR 50V10uF
C920 041 TUTES1H220-TF ELECTROLYTIC CAPACITOR 50V22uF
C823 041 TUTES1H2R2-TF ELECTROLYTIC CAPACITOR 50V2.2uF
C921 041 TUTES1H470-TF ELECTROLYTIC CAPACITOR 50V47uF
C265,266,271,272,275-277,288 041 TUTES1H4R7-TF ELECTROLYTIC CAPACITOR 50V4.7uF
C291-294,297-300,303,304,355,356 041 TUTES1H4R7-TF ELECTROLYTIC CAPACITOR 50V4.7uF
C360,361,366,367 041 TUTES1H4R7-TF ELECTROLYTIC CAPACITOR 50V4.7uF
C826 041 TUTES1HR47-TF ELECTROLYTIC CAPACITOR 50V0.47uF
C902,903 041 TUTES1V332-TS ELECTROLYTIC CAPACITOR 35V3300uF
C922-934 043 TC500V103 CERAMIC CAPACITOR 500V103pF
C203-206,209-248,267,268,273,274 043 TC50V101 CERAMIC CAPACITOR 100pF
C289,290,295,296,301,302,357-359 043 TC50V101 CERAMIC CAPACITOR 100pF
C362-365,824,829 043 TC50V101 CERAMIC CAPACITOR 100pF
C825 043 TC50V103 CERAMIC CAPACITOR 0.01uF
C305-315,834-837 043 TC50V104 CERAMIC CAPACITOR 0.1uF
C814,815,828,832,917 043 TC50V104 CERAMIC CAPACITOR 0.1uF
C200 043 TC50V223 CERAMIC CAPACITOR 0.022uF
C830,831 043 TC50VCH330 CERAMIC CAPACITOR 33pF
C819,820 043 TC50VCH560 CERAMIC CAPACITOR 56pF
R901 054 1WS10J MOF RESISTOR 1W 10
RW901 054 1WS2.2JF MOF RESISTOR 1W 2.2
R907 054 2WS10JF MOF RESISTOR 2W 10
RW905 054 2WS1JF MOF RESISTOR 2W 1
RW902 054 2WS2.2JF MOF RESISTOR 2W 2.2
R203-206,209-218,802 054 TMF1000 METAL FILM RESISTOR 1/4W 100
016 E-1337A00 PCB ASSY (MAIN)
3
RSX-1055v02

Parts List 2/10
SYMBOL PARTS NO. DESCRIPTION
R207,208,219-224,232-236,247,248 054 TMF1001 METAL FILM RESISTOR 1/4W 1K
R255-258,267-270,279-282,291-294 054 TMF1001 METAL FILM RESISTOR 1/4W 1K
R303-305,355,356,361-363,366,367 054 TMF1001 METAL FILM RESISTOR 1/4W 1K
R370,371,376,377,820,923 054 TMF1001 METAL FILM RESISTOR 1/4W 1K
R249,250,253,254,259,260,265,266 054 TMF1003 METAL FILM RESISTOR 1/4W 100K
R271,272,277,278,283,284,289,290 054 TMF1003 METAL FILM RESISTOR 1/4W 100K
R295,296,301,302,357,358,368,369 054 TMF1003 METAL FILM RESISTOR 1/4W 100K
R374,375 054 TMF1003 METAL FILM RESISTOR 1/4W 100K
R924 054 TMF1501 METAL FILM RESISTOR 1/4W 1.5K
R808-810 054 TMF16-1000 METAL FILM RESISTOR 1/6W 100
R814-819,835-837,855-857 054 TMF16-1001 METAL FILM RESISTOR 1/6W 1K
R904,906,910 054 TMF16-1001 METAL FILM RESISTOR 1/6W 1K
R801,803,811-813,911 054 TMF16-1002 METAL FILM RESISTOR 1/6W 10K
R838 054 TMF16-1003 METAL FILM RESISTOR 1/6W 100K
R846 054 TMF16-1004 METAL FILM RESISTOR 1/6W 1M
R843 054 TMF16-10R0 METAL FILM RESISTOR 1/6W 10
R821 054 TMF16-1200 METAL FILM RESISTOR 1/6W 120
R845 054 TMF16-1201 METAL FILM RESISTOR 1/6W 1.2K
R800 054 TMF16-1202 METAL FILM RESISTOR 1/6W 1.2K
R834,847 054 TMF16-1800 METAL FILM RESISTOR 1/6W 180
R848,913,914 054 TMF16-1R00 METAL FILM RESISTOR 1/6W 1
R839 054 TMF16-2003 METAL FILM RESISTOR 1/6W 200K
R828,829,908 054 TMF16-2201 METAL FILM RESISTOR 1/6W 2.2K
R842 054 TMF16-2202 METAL FILM RESISTOR 1/6W 22K
R830,831 054 TMF16-22R0 METAL FILM RESISTOR 1/6W 22
R844 054 TMF16-3901 METAL FILM RESISTOR 1/6W 3.9K
R841,905 054 TMF16-4701 METAL FILM RESISTOR 1/6W 4.7K
R826,854,902,903,909,912 054 TMF16-47R0 METAL FILM RESISTOR 1/6W 47
R840 054 TMF16-5101 METAL FILM RESISTOR 1/6W 5.1K
R824,825 054 TMF16-5602 METAL FILM RESISTOR 1/6W 56K
R822,823 054 TMF16-6801 METAL FILM RESISTOR 1/6W 6.8K
R827 054 TMF16-68R0 METAL FILM RESISTOR 1/6W 68
R804-807,849-853 054 TMF16-75R0 METAL FILM RESISTOR 1/6W 75
R225-230,237-246,351-354 054 TMF2200 METAL FILM RESISTOR 1/4W 220
R364,365,832,833 054 TMF2200 METAL FILM RESISTOR 1/4W 220
R378 054 TMF3301 METAL FILM RESISTOR 1/4W 3.3K
R251,252,261,262,273,274,285,286 054 TMF4701 METAL FILM RESISTOR 1/4W 4.7K
R297,298,306,359,360,372,373,379 054 TMF4701 METAL FILM RESISTOR 1/4W 4.7K
R921 054 TMF4701 METAL FILM RESISTOR 1/4W 4.7K
JK801-803 066 4TR-2964#10 3P PIN JACK (YEL)
JK201 066 C-4784A01 4P PIN JACK (WHT/RED)
JK202-204 066 C-4792A01 6P PIN JACK (WHT/RED)
501 X-1338 PCB ASSY
X101 023 CST10.0MTW CERAMIC RESONATOR
IC100 031 CXP82832-338Q I C (CPU)
RMC101 031 SBX3010-52B I C (REMOTE EYE)
IC203,204 031 TC9163AN IC (SWITCH ARRAY)
Q101 032 TC3708-ST TRANSISTOR 2SC3708AA-ST
D101-104 034 T1N4148-86 DIODE 1N4148TAP-50
FIP1 035 HNR08MM31 FL TUBE
C114 041 TUTES1H010-TF ELECTROLYTIC CAPACITOR 50V1uF
C117 041 TUTES1H4R7-TF ELECTROLYTIC CAPACITOR 50V4.7uF
C101-104,106,107 043 TC50V101 CERAMIC CAPACITOR 100pF
C115,118 043 TC50V103 CERAMIC CAPACITOR 0.01uF
C100,112,113 043 TC50V473 CERAMIC CAPACITOR 0.047uF
C108-111 043 TC50V821 CERAMIC CAPACITOR 820pF
CS100 044 3549472109 AC CAPACITOR 400V0.0047uF
R101-104,124-126 053 CR14-102J-A CARBON RESISTOR 1/4W 1K
R109,114-119,123 053 CR14-103J-A CARBON RESISTOR 1/4W 10K
(R121) 053 CR14-181J-A CARBON RESISTOR 1/4W 180
R120 053 CR14-470J-A CARBON RESISTOR 1/4W 47
(R121) 053 CR14-471J-A CARBON RESISTOR 1/4W 470
R122 053 CR14-472J-A CARBON RESISTOR 1/4W 4.7K
016 X-1338A01-06 PCB ASSY (FRONT)
4

Parts List 3/10
SYMBOL PARTS NO. DESCRIPTION
R105-108,110-113 053 CR14-473J-A CARBON RESISTOR 1/4W 47K
ESW101 056 C-4678A01 ENCODER EC16B243040F(D25)
SW100 061 C-4176A08 POWER SWITCH PS3-22SPA-P7AZ TV-8
SW101-132 061 C-4679A03 TACT SWITCH SKHHAMA010
501 X-1339 PCB ASSY
IC861 031 ADG774BR I C (SWITCH ARRAY) SMD
IC862 031 LT1399CS IC (QUAD AMP) SMD
IC101,103 031 LTV817 I C (PHOTO COUPLER)
ICW151,152 031 NJM5532D I C (DUAL OPEAMP)
D181-183 034 T1N4148-86 DIODE 1N4148TAP-50
C861-863,867-872 041 TUTES1A101-TF ELECTROLYTIC CAPACITOR 10V100uF
C873,874 041 TUTES1A221-TF ELECTROLYTIC CAPACITOR 10V220uF
C875 041 TUTES1A471-TF ELECTROLYTIC CAPACITOR 10V470uF
CW163 041 TUTES1H100-TF ELECTROLYTIC CAPACITOR 50V10uF
CW151,152,155,156 041 TUTES1H470-TF ELECTROLYTIC CAPACITOR 50V47uF
CW160 042 TP50V333J MYLAR CAPACITOR 0.033uF
C161-167 043 TC50V101 CERAMIC CAPACITOR 100pF
CW153,154,157,158,C864-866 043 TC50V104 CERAMIC CAPACITOR 0.1uF
CW161,162 043 TC50V222 CERAMIC CAPACITOR 0.0022uF
C966-970 043 TC50V472 CERAMIC CAPACITOR 0.0047uF
C951-955 043 TC50V473 CERAMIC CAPACITOR 0.047uF
CW159 044 50MSAN224J STACKED FILM CAPACITOR 0.22uF
R185,186,879-881 053 CR16-100J-A CARBON RESISTOR 1/6W 10
R180,181 053 CR16-101J-A CARBON RESISTOR 1/6W 100
R166-172,873-878 053 CR16-102J-A CARBON RESISTOR 1/6W 1K
R882,RW155-160,165,167-170 053 CR16-103J-A CARBON RESISTOR 1/6W 10K
R157-163,870-872,RW171 053 CR16-104J-A CARBON RESISTOR 1/6W 100K
RW162,163 053 CR16-123J-A CARBON RESISTOR 1/6W 12K
RW161 053 CR16-152J-A CARBON RESISTOR 1/6W 1.5K
RW151-154 053 CR16-221J-A CARBON RESISTOR 1/6W 220
RW164 053 CR16-273J-A CARBON RESISTOR 1/6W 27K
R193,194,883-885 053 CR16-472J-A CARBON RESISTOR 1/6W 4.7K
R861-869 053 CR16-750J-A CARBON RESISTOR 1/6W 75
R951-955 054 2WS10JF MOF RESISTOR 2W 10
R183,184 054 2WS56JF MOF RESISTOR 2W 56
JAK961 064 KSP02H DIP SWITCH
JAK957-959 065 HSJ1002-01-1020 3.5ΦMINI JACK
JAK960 066 C-4721A02 9P PIN JACK (GR/BL/R)
JAK954 066 C-4792A01 6P PIN JACK (WHT/RED)
JAK955 066 C-4793A01 3P PIN JACK (BLK)
JAK951,952 067 C-4794A00 4P SPEAKER TERMINAL (RED/BLK)
JAK953 067 C-4795A00 2P SPEAKER TERMINAL (RED/BLK)
501 E-4002000200A PCB ASSY
QC,QL,QR,QSL,QSR210 032 C4137-V TRANSISTOR (2SC4137-V)
Q216 032 KRC107M TRANSISTOR KRC107M
QC.QL.QR.QSL.QSR208 033 A1360-OY TRANSISTOR 2SA1360-OY
QC,QL,QR,QSL,QSR214 033 A1386-OPY TRANSISTOR 2SA1386A-OPY
QC.QL.QR.QSL.QSR212 033 A1859-Y TRANSISTOR 2SA1859A-Y
QC.QL.QR.QSL.QSR209 033 C3423-OY TRANSISTOR 2SC3423-OY
QC,QL,QR,QSL,QSR213 033 C3519-OPY TRANSISTOR 2SC3519A-OPY
QC.QL.QR.QSL.QSR211 033 C4883-Y TRANSISTOR 2SC4883A-Y
Q217,QC201-204,207,QL.QR201-204,207 033 KTA1268-GRBL TRANSISTOR KTA1268-GRBL
QSL.QSR201-204,207 033 KTA1268-GRBL TRANSISTOR KTA1268-GRBL
QC.QL.QR.QSL.QSR205,206,215 033 KTC3200-GRBL TRANSISTOR KTC3200-GRBL
DC.DL.DR201 034 T1N4148-86 DIODE 1N4148TAP-50
DSR201 034 T1N4148-86 DIODE 1N4148TAP-50
DSL201,DC.DL.DR.DSL.DSR202 034 T1N4148-86 DIODE 1N4148TAP-50
ZD201 034 TRD12JST1 ZENER DIODE 12V (AB2)
CC.CL.CR.CSL.CSR206 041 TUTES1A221-TF ELECTROLYTIC CAPACITOR 10V220uF
C215,217,CC.CL.CR.CSL.CSR204 041 TUTES1H010-TF ELECTROLYTIC CAPACITOR 50V1uF
CC.CL.CR.CSL.CSR211,214 041 TUTES1H100-TF ELECTROLYTIC CAPACITOR 50V10uF
CC.CL.CR.CSL.CSR205 041 TUTES1H220-TF ELECTROLYTIC CAPACITOR 50V22uF
016 X-1339B01-04 PCB ASSY (TERMINAL)
016 E-4002000200APCB ASSY (AMP)
5

Parts List 4/10
SYMBOL PARTS NO. DESCRIPTION
C216 041 TUTES1H470-TF ELECTROLYTIC CAPACITOR 50V47uF
CC.CL.CR.CSL.CSR201 041 TUTES1H4R7-TF ELECTROLYTIC CAPACITOR 50V4.7uF
CC.CL.CR.CSL.CSR210,212 041 TUTES1J471-TS ELECTROLYTIC CAPACITOR 63V470uF
CC.CL.CR.CSL.CSR209 043 TC50V181-A CERAMIC CAPACITOR 180pF
CC.CL.CR.CSL.CSR202 043 TC50V271-A CERAMIC CAPACITOR 270pF
CC.CL.CR.CSL.CSR203 043 TC50V391-A CERAMIC CAPACITOR 390pF
CC.CL.CR.CSL.CSR207 043 TC50VCH5R6-A CERAMIC CAPACITOR 5.6pF
R244,245 054 1WS1.2KJF MOF RESISTOR 1W 1.2K
RC.RL.RR.RSL.RSR233 054 MPR5W0.27RJ METAL PLATE RESISTOR 5W 0.27
RC.RL.RR.RSL.RSR228,229 054 TMF1000 METAL FILM RESISTOR 1/4W 100
RC.RSL.RSR201 054 TMF16-1001 METAL FILM RESISTOR 1/6W 1K
RL201 054 TMF16-1001 METAL FILM RESISTOR 1/6W 1K
RR201,RC.RL.RR.RSL.RSR207 054 TMF16-1001 METAL FILM RESISTOR 1/6W 1K
RC.RL.RR.RSL.RSR210 054 TMF16-1002 METAL FILM RESISTOR 1/6W 10K
R237 054 TMF16-1003 METAL FILM RESISTOR 1/6W 100K
RC.RL.RR.RSL.RSR221 054 TMF16-1200 METAL FILM RESISTOR 1/6W 120
RC.RL.RR.RSL.RSR222 054 TMF16-1200 METAL FILM RESISTOR 1/6W 120
RC.RL.RR.RSL.RSR226 054 TMF16-1201 METAL FILM RESISTOR 1/6W 1.2K
RC.RL.RR.RSL.RSR212 054 TMF16-1201 METAL FILM RESISTOR 1/6W 1.2K
RC.RL.RSL.RSR209 054 TMF16-1500 METAL FILM RESISTOR 1/6W 150
RR209 054 TMF16-1500 METAL FILM RESISTOR 1/6W 150
R243 054 TMF16-1503 METAL FILM RESISTOR 1/6W 150K
RC.RL.RR.RSL.RSR203,204 054 TMF16-15R0 METAL FILM RESISTOR 1/6W 15
RC.RL.RR.RSL.RSR235 054 TMF16-1801 METAL FILM RESISTOR 1/6W 1.8K
RC.RL.RR.RSL.RSR236 054 TMF16-2001 METAL FILM RESISTOR 1/6W 2K
RC.RL.RR.RSL.RSR230 054 TMF16-2200 METAL FILM RESISTOR 1/6W 220
RC.RL.RR.RSL.RSR223,224 054 TMF16-2202 METAL FILM RESISTOR 1/6W 22K
RC.RL.RR.RSL245,RSR234 054 TMF16-2202 METAL FILM RESISTOR 1/6W 22K
R246 054 TMF16-3301 METAL FILM RESISTOR 1/6W 3.3K
RC.RL.RR.RSL.RSR202,213 054 TMF16-3302 METAL FILM RESISTOR 1/6W 33K
RC.RL.RR.RSL.RSR239-242 054 TMF16-39R0 METAL FILM RESISTOR 1/6W 39
RC.RR.RSR231,RL232 054 TMF16-3R30 METAL FILM RESISTOR 1/6W 3.3
RL.RSL231,RSL.RSR232 054 TMF16-3R30 METAL FILM RESISTOR 1/6W 3.3
RC232 054 TMF16-3R30 METAL FILM RESISTOR 1/6W 3.3
RR232 054 TMF16-3R30 METAL FILM RESISTOR 1/6W 3.3
RC.RL.RR.RSL.RSR227 054 TMF16-4300 METAL FILM RESISTOR 1/6W 430
RC.RR.RSL211 054 TMF16-4302 METAL FILM RESISTOR 1/6W 43K
RL.RSR211 054 TMF16-4302 METAL FILM RESISTOR 1/6W 43K
RC.RL.RR.RSL.RSR215,216,218-220 054 TMF16-5600 METAL FILM RESISTOR 1/6W 560
RC.RL.RR.RSL.RSR214,217 054 TMF16-5600 METAL FILM RESISTOR 1/6W 560
RC.RL.RR.RSR238 054 TMF16-6801 METAL FILM RESISTOR 1/6W 6.8K
RSL238 054 TMF16-6801 METAL FILM RESISTOR 1/6W 6.8K
R238 054 TMF16-6802 METAL FILM RESISTOR 1/6W 68K
RC.RL.RR.RSL.RSR208 054 TMF16-68R0 METAL FILM RESISTOR 1/6W 68
RC.RL.RR.RSL.RSR205,206 054 TMF16-7500 METAL FILM RESISTOR 1/6W 750
RC.RL.RR.RSL.RSR237 054 TMF16-9100 METAL FILM RESISTOR 1/6W 910
501 X-4002002700-B PCB ASSY
501 X-4002002710-B PCB ASSY
FIL901 021 2648701170 LINE FILTER
T901 022 2828000097 SUB TRANSFORMER
D901 034 1N4004 DIODE (1A 400V)
D551 034 KBPC2504W-F POWER DIODE 25A 400V
F902 036 5ST250 FUSE 250VT250MA for 230V
F902 036 5ST315 FUSE 250VT315MA for 115V
F901 036 5ST4 FUSE 250VT4A for 230V
F901 036 S51-7A FUSE 250V7A UL for 115V
C556-559 041 HC80V8200UF ELECTROLYTIC CAPACITOR 80V8200uF
C551-555 043 TC500V103 CERAMIC CAPACITOR 500V0.01uF
C901 044 3549472109 AC CAPACITOR 400V0.0047uF
R901 054 MOF12-3M3 MOF RESISTOR 1/2W 3.3M (USA only)
RLY901 063 G5PA-1 RELAY DC 12V (G5PA-1)
F901,902 069 CNT47-0007 FUSE CLIP
016 X-4002002700C, 016 X-4002002710CPCB ASSY (STANDBY, CAPACITOR)
016 E-1325B00 PCB ASSY (TUNER)
6

Parts List 5/10
SYMBOL PARTS NO. DESCRIPTION
501 E-1325B00-B PCB ASSY
JE540-0210586N-POB ANT TERMINAL JACK SC0210586N
PKSTF404-VA00001-0 FM FRONT-END KST-F404VA-1
T3,T4 LKS75E00-5P07668-2 B.P.F 01011-101
R27 JE21A-4XX3300J-AOR CARBON FILM RESISTOR 1/4W 330
R42 JE21A-3XX0220J-AOS CARBON FILM RESISTOR 1/8W 22
R66 JE21A-6XX0220J-AOR CARBON FILM RESISTOR 1W 22
C28 JE313-K16G101J-ROS CERAMIC CAPACITOR C1608 COG 1H 100pF
C8,10 JE313-K16G200J-ROS CERAMIC CAPACITOR C1608 COG 1H 20pF
C12,35,36 JE313-K16G221J-ROS CERAMIC CAPACITOR C1608 COG 1H 220pF
C26,34 JE313-K16G331J-ROS CERAMIC CAPACITOR C1608 COG 1H 330pF
C37 JE313-K16G470J-ROS CERAMIC CAPACITOR C1608 COG 1H 47pF
C41 JE313-K16G561J-ROS CERAMIC CAPACITOR C1608 COG 1H 560pF
C38 JE313-K16G560J-ROS CERAMIC CAPACITOR C1608 COG 1H 56pF
C27 JE313-K16G820J-ROS CERAMIC CAPACITOR C1608 COG 1H 82pF
C7,13,14,17,18,19,20,21,22,23,29,31,33,39 JE313-G16X473K-ROS CERAMIC CAPACITOR C1608 X7R 1C 0.047uF
C2,9 JE313-K16X103K-ROS CERAMIC CAPACITOR C1608 X7R 1H 0.01uF
C1,3,4,5,32 JE313-K16X223K-ROS CERAMIC CAPACITOR C1608 X7R 1H 0.022uF
C30 JE313-G16X393K-ROS CERAMIC CAPACITOR C1608 X7R 1H 0.039uF
C6,16,24,25,40 JE313-K16X102K-ROS CERAMIC CAPACITOR C1608 X7R 1H 1000pF
C44,45 JE313-K16X272K-ROS CERAMIC CAPACITOR C1608 X7R 1H 2700pF
C42,43 JE313-K16X822K-ROS CERAMIC CAPACITOR C1608 X7R 1H 8200pF
CF01 JE41I-A7MA5AXX-BOC CERAMIC FILTER L10.7MA5A
CF02 JE41I-A7MS3AAA-BOC CERAMIC FILTER L10.7MS3A-10A
CF04 JE41I-456F11XX-BOC CERAMIC FILTER ZTB456F11
J04,J05,J06 JE24S-1160000X-ROS CHIP RESISTOR R1608 0R
R43 JE24S-1161501J-ROS CHIP RESISTOR R1608 1.5K
R40,54,57 JE24S-1161801J-ROS CHIP RESISTOR R1608 1.8K
R12,17 JE24S-1161000J-ROS CHIP RESISTOR R1608 100
R13 JE24S-1161003J-ROS CHIP RESISTOR R1608 100K
R10,24,25,26,34,39,48,68 JE24S-1161002J-ROS CHIP RESISTOR R1608 10K
R1,30,49 JE24S-1161502J-ROS CHIP RESISTOR R1608 15K
R18,20,21,22,23,46 JE24S-1161001J-ROS CHIP RESISTOR R1608 1K
R19,58 JE24S-1162201J-ROS CHIP RESISTOR R1608 2.2K
R41 JE24S-1162701J-ROS CHIP RESISTOR R1608 2.7K
R11,35,44 JE24S-1160220J-ROS CHIP RESISTOR R1608 22
R2 JE24S-1162200J-ROS CHIP RESISTOR R1608 220
R52,53,55,56 JE24S-1162203J-ROS CHIP RESISTOR R1608 220K
R3,33,62,64 JE24S-1162202J-ROS CHIP RESISTOR R1608 22K
R7,38,60 JE24S-1163301J-ROS CHIP RESISTOR R1608 3.3K
R9 JE24S-1163300J-ROS CHIP RESISTOR R1608 330
R59 JE24S-1163902J-ROS CHIP RESISTOR R1608 39K
R14,61,63 JE24S-1164701J-ROS CHIP RESISTOR R1608 4.7K
R8 JE24S-1164700J-ROS CHIP RESISTOR R1608 470
R28,29,45 JE24S-1164702J-ROS CHIP RESISTOR R1608 47K
R16,47 JE24S-1165601J-ROS CHIP RESISTOR R1608 5.6K
R5,6 JE24S-1165600J-ROS CHIP RESISTOR R1608 560
R50 JE24S-1168202J-ROS CHIP RESISTOR R1608 82K
J01,J08,J09,J10 JE24S-3320000X-ROS CHIP RESISTOR R3216 0R
R51 JE24S-3324700J-ROS CHIP RESISTOR R3216 470
R37 JE24S-3320680J-ROS CHIP RESISTOR R3216 68
Q1 JE13S-C3142J4X-ROS CHIP TR 2SC3142-J4
Q8 JE13S-C2814F4X-ROS CHIP TRANSISTOR 2SC 2814-F4
Q9,Q10 JE13S-KRC231SX-ROE CHIP TRANSISTOR 2SC 2814-F4
Q6,Q7 JE13S-DTA114EK-ROR CHIP TRANSISTOR DTA114EKA
Q5 JE13S-C143TKAX-ROR CHIP TRANSISTOR DTC143TKA(NPN)
CP100 068 B5B-PH-KS CONNECTOR POST
CP101 068 B9B-PH-KS CONNECTOR POST
X-TAL2 JE43S-43320327-BOS CRYSTAL 4.332MHz(2pF)/49S
X-TAL1 JE43U-72000312-BOS CRYSTAL 7.2MHz(12pF)/49U
D1,2,3,4,7 JE14I-1N4148XX-AOR DIODE 1N4148
D6 JE14I-MTZJ3R32-AOR DIODE ZENER MTZ 3.3V
D5 JE14I-MTZJ5R12-AOR DIODE ZENER MTZ 5.1V
EC05,17,18,19,20,21,22 JE32R-G5BA100M-BOL ELECTROLYTIC CAPACITOR 16V10uF
EC02,04,06,10,12 JE32R-G5BA470M-BOL ELECTROLYTIC CAPACITOR 16V47uF
7

Parts List 6/10
SYMBOL PARTS NO. DESCRIPTION
EC01,03,09,23 JE32R-J5BA2R2M-BOL ELECTROLYTIC CAPACITOR 35V2.2uF
EC08 JE32R-J5BA3R3M-BOL ELECTROLYTIC CAPACITOR 35V3.3uF
EC13 JE32R-K5BAR22M-BOL ELECTROLYTIC CAPACITOR 50V0.22uF
EC07,11,14,15,16 JE32R-K5BA010M-BOL ELECTROLYTIC CAPACITOR 50V1uF
FD1 LKSZ7310-X000266-1 FM DET COIL FD1 (266)
FD2 LKSZ7310-X000267-0 FM DET COIL FD2 (267)
IC04 JE11S-BU1924FX-ROR IC BU1924F (RDS)
IC01 JE11I-LA1266XX-SOS IC LA1266 (FM-IF, AM-RF)
IC03 JE11I-LA3401XX-SOS IC LA3401 (FM-MPX)
IC02 JE11I-LC72131X-SOS IC LC72131(PLL)
IF BLOCK LKSNT111-I000000-0 IF COIL BLOCK KSNT-111I
L1 LCH6700B-637601D-0 INDUCTOR COIL 637-601D(20.8mH)
R36 JE22A-3XX2502F-AOS METAL FILM RESISTOR 1/8W 25K
RF BLOCK LKSNT203-M000001-0 RF COIL BLOCK KSNT-203M-1
SVR1 JE27I-0001002P-BOY SVR EVN D8A A03 B14 (10K)
SVR3 JE27I-0001003P-BMA SVR EVN D8A A03 B15 (100K)
SVR2 JE27I-0005002P-BMA SVR EVN D8A A03 B54 (50K)
501 X-1331B00-B PCB ASSY
LD601 021 LAL02TB100M INDUCTOR 10uH
LD602 021 LAL02TB101M INDUCTOR 100uH
ICD601 031 KS5520-1 I C (SCREEN DISPLAY)
IC601,IC602 031 TC9163AF I C (SWITCH)
IC603,604 031 TSH94ID IC (QUAD OPEAMP)
Q608,610 032 KTA107M TRANSISTOR
Q602,603,QD601 032 KTA1271 TRANSISTOR
Q609 032 KTC107M TRANSISTOR
Q601,604,607,611 032 KTC3203 TRANSISTOR
D601,602 034 T1N4148-86 DIODE 1N4148TAP-50
ZD601 034 TRD5.1JST1 ZENER DIODE 5.1V
C601,602,605,606,613-620, 041 TUTES1A101-TF ELECTROLYTIC CAPACITOR 10V100uF
C625-631,CD601,602,616 041 TUTES1A101-TF ELECTROLYTIC CAPACITOR 10V100uF
C621-624 041 TUTES1A471-TF ELECTROLYTIC CAPACITOR 10V470uF
C609-612 041 TUTES1E470-TF ELECTROLYTIC CAPACITOR 25V47uF
CD603,608 041 TUTES1H010-TF ELECTROLYTIC CAPACITOR 50V1uF
C600 041 TUTES1H100-TF ELECTROLYTIC CAPACITOR 50V10uF
CD607 041 TUTES1H2R2-TF ELECTROLYTIC CAPACITOR 50V2.2uF
CD609 041 TUTES1HR47-TF ELECTROLYTIC CAPACITOR 50V0.47uF
CD614,615 043 TC50VCH330 CERAMIC CAPACITOR 33pF
CD604,605 043 TC50VCH560 CERAMIC CAPACITOR 56pF
CD610 047 ECJ2VB1H103K CERAMIC CAPACITOR CHIP 0.01uF
CD602,613 047 ECJ2VB1H223K CERAMIC CAPACITOR CHIP 0.022uF
C603,604,607,608 047 ECJ2VF1H104Z CERAMIC CAPACITOR CHIP 0.1uF
CD606,CD611 047 ECJ2VG1H101J CERAMIC CAPACITOR CHIP 100pF
RD610 055 ERJ6GEYJ100V RESISTOR CHIP 10
R641-648,RD614 055 ERJ6GEYJ101V RESISTOR CHIP 100
R657-672,675,RD602-604 055 ERJ6GEYJ102V RESISTOR CHIP 1K
R649-656,RD618 055 ERJ6GEYJ103V RESISTOR CHIP 10K
RD606 055 ERJ6GEYJ104V RESISTOR CHIP 100K
RD613 055 ERJ6GEYJ105V RESISTOR CHIP 1M
RD611 055 ERJ6GEYJ122V RESISTOR CHIP 1.2K
RD619 055 ERJ6GEYJ123V RESISTOR CHIP 12K
RD617 055 ERJ6GEYJ181V RESISTOR CHIP 180
RD605 055 ERJ6GEYJ204V RESISTOR CHIP 200K
R621-624 055 ERJ6GEYJ221V RESISTOR CHIP 220
R629,630 055 ERJ6GEYJ222V RESISTOR CHIP 2.2K
RD609 055 ERJ6GEYJ223V RESISTOR CHIP 22K
RD601 055 ERJ6GEYJ2R2V RESISTOR CHIP 2.2
RD612 055 ERJ6GEYJ392V RESISTOR CHIP 3.9K
R600,631-635,RD615,616 055 ERJ6GEYJ470V RESISTOR CHIP 47
R676,RD608 055 ERJ6GEYJ472V RESISTOR CHIP 4.7K
RD607 055 ERJ6GEYJ512V RESISTOR CHIP 5.1K
R627,628 055 ERJ6GEYJ563V RESISTOR CHIP 56K
R617,618,636 055 ERJ6GEYJ680V RESISTOR CHIP 68
016 X-1331B00 PCB ASSY (S-VIDEO B'D)
8

Parts List 7/10
SYMBOL PARTS NO. DESCRIPTION
R625,626 055 ERJ6GEYJ682V RESISTOR CHIP 6.8K
R601-616 055 ERJ6GEYJ750V RESISTOR CHIP 75
501 E-1332C00-D PCB ASSY
T501,T502,T503,T504 2888000010 TRANS PULSE FP-110
XT502 023 12.288MHz CRYSTAL 12.288MHz
XT501 023 24.576MHz CRYSTAL 24.576MHz
IC519 031 32PIN-DIP-SOCKET IC SOCKET (DIP)
IC513 031 32PIN-PLCC IC SOCKET (PLCC)
IC513 031 39VF040 IC EPROM 39VF040 (V1.2) / (V2.0)
IC505,508 031 74HC157 IC
IC515 031 74HCT125 IC
IC516 031 74VHC244M IC
IC511,512 031 74VHC574M IC
IC510 031 AK4114 IC (DIR)
IC525-528 031 AK4324 IC (DAC)
IC524 031 AK5351 IC (ADC)
IC506 031 AME1117BCGT IC (REGULATOR 2.5V)
IC507 031 AME1117CCGT IC (REGULATOR 3.3V)
IC520 031 AT24C16PC2.7 IC (EEPROM)
IC514 031 CS493263-CL IC (DSP) G-VERSION
IC519 031 EN29F002NT-X55 IC (FLASH MEMORY)
IC521 031 HIN232CB IC (RS232)
IC518 031 IS62C256 IC (MEMORY)
IC522,523,529-533 031 NJM5532M IC (DUAL OPAMP)
IC534 031 NJU7311AM IC (ANALOG SWITCH)
IC517 031 TMP95C063F IC (CPU)
IC502,503 031 TORX179 IC (OPTO RECIEVER)
IC504 031 TOTX179 IC (OPTO TRANSMITTER)
Q501,Q502,Q503,Q504 032 KRC107S TRANSISTOR CHIP KRC107S
D504,D505 034 KDS184RTK DIODE CHIP KDS184RTK
D502,D503,501 034 KDS226RTK DIODE CHIP KDS226RTK
C566-569 041 TUTES1H010-TF ELECTROLYTIC CAPACITOR 50V1uF
C511,514,521-524,542,543,546,570,578 041 TUTES1H100-TF ELECTROLYTIC CAPACITOR 50V10uF
C597-612 041 TUTES1H100-TF ELECTROLYTIC CAPACITOR 50V10uF
CAL/R501,502,505,506 041 TUTES1H100-TF ELECTROLYTIC CAPACITOR 50V10uF
CFL/R504,CSL/R504,CBL/R504,CCT504,CSW504 041 TUTES1H100-TF ELECTROLYTIC CAPACITOR 50V10uF
C564 041 TUTES1H3R3-TF ELECTROLYTIC CAPACITOR 50V3.3uF
C565 041 TUTES1HR22-TF ELECTROLYTIC CAPACITOR 50V0.22uF
C547 041 TUTES1HR47-TF ELECTROLYTIC CAPACITOR 50V0.47uF
C525,526,579,580 041 UTES1A101-FB ELECTROLYTIC CAPACITOR 10V100uF
C615 041 UTES1A471-FB ELECTROLYTIC CAPACITOR 10V470uF
C537,538,581-584,589-592,613,614 041 UTES1E470-FB ELECTROLYTIC CAPACITOR 25V47uF
C539 041 UTES1H2R2-FB ELECTROLYTIC CAPACITOR 50V2.2uF
C627-634 047 ECJ2VG1H101J CERAMIC CAPACITOR CHIP 100pF
C541 047 ECJ2VG1H103K CERAMIC CAPACITOR CHIP 0.01uF
CSW502,503 047 ECJ2VG1H103K CERAMIC CAPACITOR CHIP 0.01uF
C501,515,516,527,530,531,549,550 047 ECJ2VG1H104Z CERAMIC CAPACITOR CHIP 0.1uF
C502,503,529,552,574,616-618,620-626 047 ECJ2VG1H104Z CERAMIC CAPACITOR CHIP 0.1uF
C504,506,508,510,512,513,517-520,528 047 ECJ2VG1H104Z CERAMIC CAPACITOR CHIP 0.1uF
C532-536,544,545,548,551,555-560,563 047 ECJ2VG1H104Z CERAMIC CAPACITOR CHIP 0.1uF
C561,562,571 047 ECJ2VG1H104Z CERAMIC CAPACITOR CHIP 0.1uF
C572,573,575-577,585-588,593-596 047 ECJ2VG1H104Z CERAMIC CAPACITOR CHIP 0.1uF
CAL/R503 047 ECJ2VG1H104Z CERAMIC CAPACITOR CHIP 0.1uF
CBL/R502,503,CCT502,503 047 ECJ2VG1H121J CERAMIC CAPACITOR CHIP 120pF
CFL/R502,503,CSL/R502,503 047 ECJ2VG1H121J CERAMIC CAPACITOR CHIP 120pF
C515 047 ECJ2VG1H221J CERAMIC CAPACITOR CHIP 220pF
CAL/R504 047 ECJ2VG1H222K CERAMIC CAPACITOR CHIP 0.0022uF
C553,554,619 047 ECJ2VG1H270J CERAMIC CAPACITOR CHIP 27pF
CFL/R501,CSL/R501,CBL/R501,CCT501,CSW501 047 ECJ2VG1H331J CERAMIC CAPACITOR CHIP 330pF
C540 047 ECJ2VG1H471J CERAMIC CAPACITOR CHIP 470pF
CFL/R505,CCT505 047 ECJ2VG1H473K CERAMIC CAPACITOR CHIP 0.047uF
JMP5,JMP7 055 ERJ6GEYJ000V RESISTOR CHIP 0R
R588,JMP1,JMP2,JMP4,R560 055 ERJ6GEYJ000V RESISTOR CHIP 0R
016 E-1332C00 PCB ASSY (DIGITAL-1)
9

Parts List 8/10
SYMBOL PARTS NO. DESCRIPTION
R516,578 055 ERJ6GEYJ100V RESISTOR CHIP 10
R519,535,536,568-570 055 ERJ6GEYJ100V RESISTOR CHIP 10
R514,575,576 055 ERJ6GEYJ101V RESISTOR CHIP 100
R529,530,579 055 ERJ6GEYJ101V RESISTOR CHIP 100
R557,RAL/R513,RBL/R508,RCT508 055 ERJ6GEYJ102V RESISTOR CHIP 1K
R596,597,598 055 ERJ6GEYJ102V RESISTOR CHIP 1K
RFL/R508,RSL/R508,RSW508 055 ERJ6GEYJ102V RESISTOR CHIP 1K
R503,533,549-556,563-566,RAL/R501 055 ERJ6GEYJ103V RESISTOR CHIP 10K
R571,RAL/R502,RAL/R504 055 ERJ6GEYJ103V RESISTOR CHIP 10K
RAL/R510,511 055 ERJ6GEYJ104V RESISTOR CHIP 100K
RFL/R507,RSL/R507,RBL/R507,RCT507,RSW507 055 ERJ6GEYJ104V RESISTOR CHIP 100K
R562 055 ERJ6GEYJ105V RESISTOR CHIP 1M
R503,507,512 055 ERJ6GEYJ181V RESISTOR CHIP 180
R532 055 ERJ6GEYJ183V RESISTOR CHIP 18K
R584,586,588,590,594,595 055 ERJ6GEYJ221V RESISTOR CHIP 220
R585,587,589,591-593 055 ERJ6GEYJ221V RESISTOR CHIP 220
RAL/R508,509 055 ERJ6GEYJ331V RESISTOR CHIP 330
RAL/R505 055 ERJ6GEYJ332V RESISTOR CHIP 3.3K
R541 055 ERJ6GEYJ333V RESISTOR CHIP 33K
R517,518 055 ERJ6GEYJ471V RESISTOR CHIP 470
R520-525,540,542-545,547,548,567,RAL/R506 055 ERJ6GEYJ472V RESISTOR CHIP 4.7K
R538,539,546,573,RAL/R507 055 ERJ6GEYJ472V RESISTOR CHIP 4.7K
RAL/R503 055 ERJ6GEYJ473V RESISTOR CHIP 47K
R580-583 055 ERJ6GEYJ561V RESISTOR CHIP 560
RBL/R501-505,RCT501-505,RSW501-505 055 ERJ6GEYJ562V RESISTOR CHIP 5.6K
RFL/R501-505,RSL/R501-505 055 ERJ6GEYJ562V RESISTOR CHIP 5.6K
R501,506,511,513 055 ERJ6GEYJ750V RESISTOR CHIP 75
R505,510,515 055 ERJ6GEYJ750V RESISTOR CHIP 75
RFL/R506,RSL/R506,RBL/R506,RCT506,RSW506 055 ERJ6GEYJ912V RESISTOR CHIP 9.1K
RCA501,503 066 RCA 4P JACK RCA4P(BK)
RCA502 066 RCA 6P JACK RCA6P(WHT/RED)
JK501 066 SY010-8P/K JACK RJ-45
CN103 436303252124 CONNECTOR W/WIRE 3P 250mm
CN101 436309182124 CONNECTOR W/WIRE 9P 180mm
CP901 4428502486 CONNECTOR POST 2PZ
501 X-1333C00-B PCB ASSY
RLY701 5528001020 RELAY G5A-237P
IC701,702,703,704,705, 031 NJM5532M IC (DUAL OPEAMP)
IC710,711,712,714,716 031 NJM5532M IC (DUAL OPEAMP)
IC717 031 NJU7311AM IC (SWITCH)
IC709,713 031 TC9184P IC (TONE)
IC706,707,708,715 031 TC9459F IC (VOLUME)
QC701,QSW701 032 KRA107S TRANSISTOR
QF701,QS701,QSS701, 032 KRA107S TRANSISTOR
QC703,QSW702,703,QF702, 032 KRC231S TRANSISTOR
QF703,705,QS702,QSS702 032 KRC231S TRANSISTOR
QFL701,QFR701,QSL701,QSL702, 032 KRC231S TRANSISTOR
QSR701,702,QC702,QSW702 032 KRC231S TRANSISTOR
DF702 034 KDS184RTK DIODE CHIP KDS184RTK
DS701,DSS701 034 KDS184RTK DIODE CHIP KDS184RTK
DSW701,DF701,DC701, 034 KDS184RTK DIODE CHIP KDS184RTK
C701,702,CF701,702,703, 041 UTES1E470-TF ELECTROLYTIC CAPACITOR 25V47uF
CCW701,702,703,704,705, 041 UTES1E470-TF ELECTROLYTIC CAPACITOR 25V47uF
CCW707,709,710,CSW719, 041 UTES1E470-TF ELECTROLYTIC CAPACITOR 25V47uF
CF704,705,707,709,710,712, 041 UTES1E470-TF ELECTROLYTIC CAPACITOR 25V47uF
CF713,CS701,702,703,704, 041 UTES1E470-TF ELECTROLYTIC CAPACITOR 25V47uF
CS705,706,708,709,710,711, 041 UTES1E470-TF ELECTROLYTIC CAPACITOR 25V47uF
CSW720,CM701,702 041 UTES1E470-TF ELECTROLYTIC CAPACITOR 25V47uF
CFL709,CFR709,CC708 041 UTES1H010-TF ELECTROLYTIC CAPACITOR 50V1uF
CC709,CSW701,704,705,708, 041 UTES1H100-TF ELECTROLYTIC CAPACITOR 50V10uF
CFL701,702,705,706,710, 041 UTES1H100-TF ELECTROLYTIC CAPACITOR 50V10uF
CFR701,702,705,706,710, 041 UTES1H100-TF ELECTROLYTIC CAPACITOR 50V10uF
CML701,704,CMR701,704 041 UTES1H100-TF ELECTROLYTIC CAPACITOR 50V10uF
016 X-1333C00 PCB ASSY (DIGITAL2 B'D)
10

Parts List 9/10
SYMBOL PARTS NO. DESCRIPTION
CSL701,704,705,708,709, 041 UTES1H100-TF ELECTROLYTIC CAPACITOR 50V10uF
CSL712,713,716,CSR701, 041 UTES1H100-TF ELECTROLYTIC CAPACITOR 50V10uF
CSR704,705,708,709,712, 041 UTES1H100-TF ELECTROLYTIC CAPACITOR 50V10uF
CSR713,716,CC701,704,705, 041 UTES1H100-TF ELECTROLYTIC CAPACITOR 50V10uF
CSW709,712,713,714,717, 041 UTES1H100-TF ELECTROLYTIC CAPACITOR 50V10uF
CFL713,CFR713,CC712 042 TP50V123J MYLAR CAPACITOR 0.012uF
CFL715,CFR715,CC714 042 TP50V223J MYLAR CAPACITOR 0.022uF
CFL714,CFR714,CC713 042 TP50V272J MYLAR CAPACITOR 0.0027uF
CFL711,CFR711,CC710 042 TP50V563J MYLAR CAPACITOR 0.056uF
CFL712,CFR712,CC711 042 TP50V682J MYLAR CAPACITOR 0.0068uF
CC702,703,706,CSW703, 047 ECJ2VG1H101J CERAMIC CAPACITOR CHIP 100pF
CFL703,704,707,CFR703, 047 ECJ2VG1H101J CERAMIC CAPACITOR CHIP 100pF
CFR704,707,CSL702,703, 047 ECJ2VG1H101J CERAMIC CAPACITOR CHIP 100pF
CML702,CMR702 047 ECJ2VG1H101J CERAMIC CAPACITOR CHIP 100pF
CMR703 047 ECJ2VG1H101J CERAMIC CAPACITOR CHIP 100pF
CSL706,707,710,711,714, 047 ECJ2VG1H101J CERAMIC CAPACITOR CHIP 100pF
CSL715,CSR702,703,706, 047 ECJ2VG1H101J CERAMIC CAPACITOR CHIP 100pF
CSR707,710,711,714,715, 047 ECJ2VG1H101J CERAMIC CAPACITOR CHIP 100pF
CSW715,716,CML703, 047 ECJ2VG1H101J CERAMIC CAPACITOR CHIP 100pF
CF706,708,CCW702,706,708, 047 ECJ2VG1H104Z CERAMIC CAPACITOR CHIP 0.1uF
CF711,CS707,714,CC715, 047 ECJ2VG1H104Z CERAMIC CAPACITOR CHIP 0.1uF
CSW718 047 ECJ2VG1H104Z CERAMIC CAPACITOR CHIP 0.1uF
CSW707 047 ECJ2VG1H222K CERAMIC CAPACITOR CHIP 0.0022uF
CFL708,CFR708,CC707 047 ECJ2VG1H270J CERAMIC CAPACITOR CHIP 27pF
CSW706,710 047 ECJ2VG1H563K CERAMIC CAPACITOR CHIP 0.056uF
CSW711 047 ECJ2VG1H822K CERAMIC CAPACITOR CHIP 0.0082uF
J701,J702 055 ERJ6GEYJ000V RESISTOR CHIP 0R
RFL701,RFR701 055 ERJ6GEYJ000V RESISTOR CHIP 0R
RC707,RSW711,718, 055 ERJ6GEYJ101V RESISTOR CHIP 100
RFL707,708,RFR707,708, 055 ERJ6GEYJ101V RESISTOR CHIP 100
RML701,RMR701 055 ERJ6GEYJ101V RESISTOR CHIP 100
RSL707,719,RSR707,719, 055 ERJ6GEYJ101V RESISTOR CHIP 100
R703,704,705,RFL702,719, 055 ERJ6GEYJ102V RESISTOR CHIP 1K
RCW706,707,712,713,714, 055 ERJ6GEYJ102V RESISTOR CHIP 1K
RF703,704,705,710,711,712, 055 ERJ6GEYJ102V RESISTOR CHIP 1K
RF717,RS703,704,705,712, 055 ERJ6GEYJ102V RESISTOR CHIP 1K
RFL716,RFR716,RCW705, 055 ERJ6GEYJ102V RESISTOR CHIP 1K
RFR702,719,RSL701,712, 055 ERJ6GEYJ102V RESISTOR CHIP 1K
RS715,716,717,724,RC715, 055 ERJ6GEYJ102V RESISTOR CHIP 1K
RSL713,724,RSR701,712, 055 ERJ6GEYJ102V RESISTOR CHIP 1K
RSR713,724,RC701,RSW706, 055 ERJ6GEYJ102V RESISTOR CHIP 1K
RSW701 055 ERJ6GEYJ102V RESISTOR CHIP 1K
RSW723 055 ERJ6GEYJ102V RESISTOR CHIP 1K
RC703,RSW703,RML703, 055 ERJ6GEYJ103V RESISTOR CHIP 10K
RMR703 055 ERJ6GEYJ103V RESISTOR CHIP 10K
RSL703,709,715,721, 055 ERJ6GEYJ103V RESISTOR CHIP 10K
RSR703,709,715,721, 055 ERJ6GEYJ103V RESISTOR CHIP 10K
RSW714 055 ERJ6GEYJ103V RESISTOR CHIP 10K
RC717,720,721,RSW702,704, 055 ERJ6GEYJ104V RESISTOR CHIP 100K
RFL703,706,709,718, 055 ERJ6GEYJ104V RESISTOR CHIP 100K
RFR703,706,709,718, 055 ERJ6GEYJ104V RESISTOR CHIP 100K
RML704,RMR702,704 055 ERJ6GEYJ104V RESISTOR CHIP 100K
RS711,722,723 055 ERJ6GEYJ104V RESISTOR CHIP 100K
RSL702,705,708,711,714, 055 ERJ6GEYJ104V RESISTOR CHIP 100K
RSL717,720,723,RSR702, 055 ERJ6GEYJ104V RESISTOR CHIP 100K
RSR705,708,711,714,717, 055 ERJ6GEYJ104V RESISTOR CHIP 100K
RSR720,723,RC702,705,708, 055 ERJ6GEYJ104V RESISTOR CHIP 100K
RSW707,712,716,RML702, 055 ERJ6GEYJ104V RESISTOR CHIP 100K
RSW710,715,719,722,724, 055 ERJ6GEYJ104V RESISTOR CHIP 100K
RSW725,RF715,716,RS710, 055 ERJ6GEYJ104V RESISTOR CHIP 100K
RSL710,722,RSR710,722 055 ERJ6GEYJ182V RESISTOR CHIP 1.8K
RSW720 055 ERJ6GEYJ183V RESISTOR CHIP 18K
RF718,719,RC722,RSW726, 055 ERJ6GEYJ202V RESISTOR CHIP 2K
R701,702,RF701,702,706, 055 ERJ6GEYJ221V RESISTOR CHIP 220
RCW703,704,708,709,710, 055 ERJ6GEYJ221V RESISTOR CHIP 220
11

Parts List 10/10
SYMBOL PARTS NO. DESCRIPTION
RCW711,RSW727,728, 055 ERJ6GEYJ221V RESISTOR CHIP 220
RF707,708,709,713,714, 055 ERJ6GEYJ221V RESISTOR CHIP 220
RM701,702,RCW701,702, 055 ERJ6GEYJ221V RESISTOR CHIP 220
RS701,702,706,707,708,709, 055 ERJ6GEYJ221V RESISTOR CHIP 220
RS713,714,718,719,720,721, 055 ERJ6GEYJ221V RESISTOR CHIP 220
RC718 055 ERJ6GEYJ222V RESISTOR CHIP 2.2K
RFL714,RFR714,RC713 055 ERJ6GEYJ273V RESISTOR CHIP 27K
RSW709 055 ERJ6GEYJ392V RESISTOR CHIP 3.9K
RFL712,RFR712,RC711 055 ERJ6GEYJ393V RESISTOR CHIP 39K
RC704,716 055 ERJ6GEYJ472V RESISTOR CHIP 4.7K
RFL704,RFR704 055 ERJ6GEYJ472V RESISTOR CHIP 4.7K
RFL705,717,RFR705,717, 055 ERJ6GEYJ472V RESISTOR CHIP 4.7K
RSL704,716,RSR704,716, 055 ERJ6GEYJ472V RESISTOR CHIP 4.7K
RFL710,RFR710,RC709 055 ERJ6GEYJ474V RESISTOR CHIP 470K
RFL715,RFR715,RC714 055 ERJ6GEYJ562V RESISTOR CHIP 5.6K
RFL713,RFR713,RC712 055 ERJ6GEYJ564V RESISTOR CHIP 560K
RSW713 055 ERJ6GEYJ682V RESISTOR CHIP 6.8K
RF720,721,722,723 055 ERJ6GEYJ821V RESISTOR CHIP 820
RSW721 055 ERJ6GEYJ821V RESISTOR CHIP 820
RFL711,RFR711,RC710 055 ERJ6GEYJ823V RESISTOR CHIP 82K
RSW708 055 ERJ6GEYJ912V RESISTOR CHIP 9.1K
CN201 436310357724 CONNECTOR W/WIRE 10P 350mm
011 FP-551C-B BLACK PANEL ASSY
011 FP-551C-S SILVER PANEL ASSY
011 UF3-01B00 H/S PANEL H150
012 C-4711A03 KNOB 43ΦNO MARK (BLACK)
012 C-4711A03S KNOB 43ΦNO MARK (SILVER)
012 RV4-09A00 PUSH BUTTON 14Φ(BLACK)
012 RV4-09A01 PUSH BUTTON 14Φ(SILVER)
012 TB3-18A00 TACT BUTTON 16 KEY (BLACK)
012 TB3-18A01 TACT BUTTON 16 KEY (SILVER)
014 UF3-06A00 UPPER COVER
019 4TSH-19#2 PLASTIC FOOT 50Φ
019 C-4714A00 POWER KNOB RING 14Φ(BLACK)
019 C-4714A01 POWER KNOB RING 14Φ(SILVER)
022 2828000107 MAIN POWER TRANSFORMER
034 SEL1124R LED (RED) SEL1124R 1X5
034 SEL1E24W LED (BLU) SEL1E24W 1X5
069 C-4629A01 AC 2P INLET 6102.3100 (WIRING)
072 C-4621A01 AC CORD SET SJT AWG16/2C for USA
072 C-4622A01 AC CORD SET for AUSTRALIA
072 C-4623A01 AC CORD SET for U.K
072 C-4624A01 AC CORD SET for EUROPE
072 C-4786A00 COMPUTER I/O CABLE (UPGRADE CABLE)
081 UF3-09A00 INSIDE CARTON
081 UF3-10A00 SHIPPING CARTON
081 Z-208 STYROL MOULDING
092 RR-1050 REMOTE CONTROL UNIT
082 OMRSX-1055 OWNER'S MANUAL
O T H E R S
12

RSX1055
SYMBOL PARTS DESCRIPTION
011 FP-551C-B BLACK PANEL ASSY
011 FP-551C-S SILVER PANEL ASSY
011 TH3-01B00 H/S PANEL H109
012 C-4711A03 KNOB 43F NO MARK (BLK)
012 C-4711A03S KNOB 43F NO MARK (SLV)
012 RV4-09A00 PUSH BUTTON 14F (BLK)
012 RV4-09A01 PUSH BUTTON 14F (SLV)
012 TB3-18A00 TACT BUTTON 16 KEY (BLK)
012 TB3-18A01 TACT BUTTON 16 KEY (SLV)
034 SEL1124R LED (RED) 1X5
034 SEL1E24W LED (BLU) 1X5
Addendum List for Black and Silver
3
1
2
13

Tuner Adjustment Method
FM Section
* Necessary measurement equipment
RDS/STEREO Multiplexer, FM/AM Signal Generator, Audio Analyzer, Oscilloscope, Digital Volt Meter (DVM)
(A) Center adjust
RDS/STEREO Multiplexer Setting
- MODE : MONO - Audio Frequency : 1KHz
FM Signal Generator Setting
- Deviation : 75KHz - Radio Frequency : 98.1MHz - Output Level : 66dB
RSX1055 Setting
- FM Frequency : 97.9MHz - FM MODE : MONO
1. Turn FM Signal Generator Modulation on
2. Connect DVM (+)(-) terminals to the each lead of the resistor R36 and measure the volt.
3. If measured voltage is not adjusted within ±10mV, Make this measured volt '0' by adjusting FD1 (FM-DET-A Coil).
: The adjustment should be within ± 10mV
4. After this adjustment, measure THD(Total Harmonic Distortion) with Audio Signal Generator
5. Adjust THD to minimum point with FD2(FM-DET-B Coil). : THD shuold be within 0.5%
(B) Channel Separation adjust
RDS/STEREO Multiplexer Setting
- MODE : STEREO ( ONLY L-CH Signal OUT ) - Audio Frequency : 1KHz
FM Signal Generator Setting
- Deviation : 75KHz - Radio Frequency : 98.1MHz - Output Level : 66dB
RSX1055 Setting
- FM Frequency : 97.9MHz - FM MODE : STEREO
1. Turn FM Signal Generator Modulation on after modulating only L-CH (or only R-CH) at STEREO Multiplexer.
2. Confirm if 'STEREO'indicator is turned 'ON' on the display
3. Measure output level via Audio Signal Analyzer and make the level as standard.
4. Turn FM Signal Generator Modulation on after modulating only R-CH (or only L-CH) at STEREO Multiplexer.
5. Measure output level via Audio Signal Analyzer (measure per a dB)
6. If meaured output level is not lower than -40dB, Adjust output level to minimum position with SVR3 ( CH-SEPA. ADJ.).
: lower than -40dB
(C) TUNED Level adjust
RDS/STEREO Multiplexer Setting
- MODE : STEREO - Audio Frequency : 1KHz
FM Signal Generator Setting
- Deviation : 75KHz - Radio Frequency : 97.9MHz - Output Level : 26dB
RSX1055 Setting
- FM Frequency : 97.9MHz - FM MODE : STEREO
1. Turn FM Signal Generator Modulation 'ON' (confirm if output level is 26dB)
2. Change the output level of the Generator from 20dB to 30dB
and Confirm if 'STEREO' & 'TUNED' indicator of the DISPLAY turns on at 26db(±5 dB)
3. If these indicators do not turn on at higher than 26dB(±5dB) or do not turn off at lower than 26(±5dB) ,
Adjust SVR2 ( FM-ADJ ) up to the moment where 'STEREO' & 'TUNED' indicator turns OFF & ON at 26dB.
4. Confirm if 'STEREO' & 'TUNED' turns OFF when decreasing the output level slowly from 26dB to 25dB, 24dB ~~~.
(Repeat the above 3. if not OFF in lower than 24dB.)
5. Push RSX-1055's TUNE UP or DOWN button "long" at Signal Generator Output Level 26dB and start Auto search.
Confirm if search stops at FM Frequency 97.9MHz.
(Examine both of High Freq. -> 97.9MHz search , Low Freq. -> 97.9MHz search)
6. (Optinal Setting of Center frequency) : Shift the Generator frequency +/- 50kHz and adjust the TRIMMER C11 to keep
the tuning center point.
14

AM Section
* Necessary measurement equipment :
AM Signal Generator, Audio Signal Analyzer, Dummy Load, Oscilloscope, Digital Volt Meter (DVM)
(A) VT adjust
AM Signal Generator Setting
1. Adjust AM Frequency of RSX-1055 to 522KHz. (or 520KHz)
2. Connect (-) terminal of DVM with GND ( or chassis ) and connect (+) terminal
with Jumper JW14 ( VT CHECK ) and mesaure voltage. ( Low Freq. VT)
3. IF not 1.1V~1.3V, Adjust VT to 1.2V with RF BLOCK RED COIL (AM-OSC Coil).
* In case of USA version, AM freq. range is 520KHz ~ 1710KHz. So, adjust as below.
at 520KHz, VT = 1.2V ( Low Freq. VT)
(B) Output Level adjust
AM Signal Generator Setting
- Modulation : 30% - Audio Frequency : 400Hz - Radio Frequency : 603KHz (or 600KHz )
- Output Level : 100dB
RSX-1055 Setting
- AM Frequency : 603KHz (or 600KHz)
1. Turn AM Signal Generator Modulation ON
2. Adjust RSX-1055 AM Freq. to 603KHz (or 600KHz) and measure output level with Audio Signal analyzer.
3. If it is lower than 200mV , Adjust output level to maximum point with RF BLOCK BLACK COIL ( AM-ANT ).
( recommand higher than 250mV )
4. Set Generator' RF & RSX1055's RF to 999kHz(or 1000kHz) and measure output level with Audio Signal analyzer.
Adjust output level to maximum point with IF BLOCK YELLOW COIL
(C) TUNED Level adjust
AM Signal Generator Setting
- Modulation : 30% - Audio Frequency : 400Hz - Radio Frequency : 999KHz (or 1000KHZ)
- Output Level : 84dB
RSX-1055 Setting
- AM Frequency : 999KHz (or 1000KHz)
1. Turn AM Signal Generator Modulation ON ( Make sure if Output level is 84dB )
2. If 'TUNED' indicator does not turn on at higher than 80~86dB(Generator output),
Adjust SVR01 ( AM-ADJ ) up to the moment where 'TUNED' indicator tunrs OFF & ON again
3. Confirm if 'TUNED' turns OFF when decreasing the output level of AM Signal Generator slowly from 84dB to 80dB.
4. Push RSX-1055 TUNE UP or DOWN button "long" at AM Signal Generator Output Level 84dB and start AUTO search.
Confirm if search stops at AM Frequency 999KHz (or 1000KHz).
< Check with both of High Freq. -> 999KHz(or 1000KHz) search , Low Freq. -> 999KHz(or 1000KHz) search >
Conversion Method of the Destimation
< STANDBY B'D VERSION OPTION>
FOR 01 VERSION (USA)
016 X-4002002700 PCB
- INSERT FOLLOWING PARTS
115V JUMPER 3POINT(435502042147)
F901 FUSE (7A/250V)
F902 FUSE (315mA/250V)
FOR 24 VERSION (EUROPE)
- INSERT FOLLOWING PARTS
230V JUMPER 2POINT (435502042147)
F901FUSE (T4A/250V)
F902FUSE (T250mAL/250V)
230
V
FIL901 T901
R901
115
V
115
V
230
V
115
V
15

Procedure of RSX-1055 software upgrade
*Note : This procedure is made by translation of Windows 98 version. So some of menu or option
name may not be matched with some versions of Windows 98.
First of all, User should have the new software file (ROTEL supply) before proceeding the
software up-grade process.
1. Power RSX-1055 off.
2. Remove all of connections between RSX-1055 and other equipments.
3. Connect RSX-1055 and PC with RJ45/DB9 cable. RJ45 jack should be connected to
COMOUTER I/O port in RSX-1055 rear panel. DB9 jack will be connected to PC serial port (ex.
COM1 or COM2,,,).
4. Switch down the SOFTWARE UPGRADABLE key to ON in RSX-1055 rear panel.
5. Open HyperTerminal program in Windows 98 (Program / Supplement Program /
Communication / HyperTerminal)
6. Input name and select icon to use for connection in connection explanation dialogue box and
click O.K.
7. Connection object dialogue box appears. Select modem(N) to use for connection. For example,
if DB9 cable is connected to COM1 serial port of PC, select COM1.
8. Selected serial port registration dialogue box appears. Select value or option per item as
follows.
*Bit per second (B) : 19200
*Data Bit (D) : 8
*Parity (P) : None
*Stop Bit (S) : 1
*Flow Control (F) : None
*And click O.K.
9. Click File (F) and click Property (R) in file menu of HyperTerminal.
10. Select setup.
11. In set up dialogue box, select options per item as follows.
*Function Key : Terminal Key(T)
*Backspace function: Ctr+H(C)
*Emulation: VT100
*Telnet Terminal: VT100
*Back scroll buffer line : 500
*And click ASCII Setup (A)
*Select (A) & (W) at ASCII receiving section, Click O.K
*Click O.K
12. Power RSX-1055 on and then options message appears in HyperTerminal screen. In the
message, select number 1. Erase of current software begins.
13. When erasing finishes, download file message appears. Select Text file sending (T) in
Transmission menu (T)of HyperTerminal and text file sending dialogue box appears.
14. Change the finding file format from (*.TXT) to (*.*) format, and find the new software which is
for up-date.( *. Bin) format.
15. Double-click new software file. The extension of software file name is bin (ex. xxx.bin). Then
software upgrade begins.
16. When the upgrade finishes, check message appears. In the message, compare received data
checksum with rom checksum. If they are same, the upgrade is done correctly.
17. Power RSX-1055 off and switch up the SOFTWARE UPGRADABLE key to Off in the rear
panel.
18. Disconnect the cable between PC and the RSX-1055
19. Power RSX-1055 on and set the default setting on the OSD screen menu with connecting
a TV monitor. And confirm if the software version is upgraded.
16

12V-TRIG B'D
X-1339-04
CAPACITOR B'D
X4002002710
X-4002002700
POWER
TRANS SPKR B'D
AMP B'D
E-4002000200
TERMINAL B D'
X-1339-02
FRONT B'D
X1338-02
X-1338-01
X-1338-03 MAIN
VOLUME B'D
TUNER B'D
MAIN B'D
016E-1337
016X-1338-04 016X-1331
STAND-BY B'D CENT-SPKR B'D
S-VIDEO B'D
DIGITAL I B'D
DIGITAL II B'D
016E-1332
016E-1325
016X-1333
016X-1339-02
016X-1339-03
POWER-SW
B'D
RMC SENSOR
B'D
Wiring Diagram RSX-1055
CP101(9P)
CN407(14P)
CP100(5P)
CN100(5P)
CN505(14P) CP505(14P)
CN109(2P)
CN204(2P)
CN202(2P)
GP802
CN203(3P)
CN954(3P)
CT911(3P)
CT910(2P)
CP903(3P)
CP904(7P)
CP905(4P)
CP106(7P) CN107(5P)
CN402(12P)
CN405(4P)
CN401(15P)
CN601(10P)
G802
GP803
CP906(2P)
CP908(3P)
CN108(3P)CN602(8P)
CP
900
CN901(2P)
G803
CP951(3P)
AC
DC-OUT
ANALOG Signal
GND GND
CP952(2P) CN953(3P)
CT202(2P)
CT203(2P)
CNT951(2P)
CT951(2P)
CN205(3P)
CP201(10P)
AC INLET
CP906
(2p)
CP905
(2P)
CP901(9P (5P)
CN907(4P)
CP107(4P) CP103(3P)
CP109(2P)
CP108(3P) CP407(14P)CP602(8P)
CP601(10P) CN404(12P)
CP402(12P)
CP404(12P)
CP401(15P)
CP405(4P)
CP501(6P)
CN101(9P)
CP503(7P)
CP502(15P)
CN201(10P)
CN502(15P)
CP504(15P)
CN504(15P)
CN503(7P)
CP901(2P)
CN103(3P)
CNT105(2P)
CP110(3P)
CN106(7P) CN501(5P)
CP1050(2P) CP102(4P)
CN110(3P)
CN102(4P)
POSISTOR
LED
POWER TRANS
17

PCB Assembly -1 Front PCB 016 X-1338A01 - 06
18
RSX-1055

PCB Assembly -2 RSX-1055
Main PCB 016 E-1337A00
19

PCB Assembly - 4
Top Side View Bottom Side View
DIGITAL1 PCB 016E-1332C00 RSX-1055
20
