Royal MD100 Quick start guide

MD100IM1002HHrev2
ROYAL®
WARRANTY, REGISTRATION & TECHNICAL SUPPORT
PLEASE FILL OUT AND RETURN THE WARRANTY CARD INCLUDED WITH YOUR NEW ROYAL PRODUCT OR FILL OUT
THE WARRANTY REGISTRATION FORM ON THE ROYAL WEB PAGE AT WWW.ROYAL.COM. IT ENTITLES YOU TO PRODUCT
WARRANTY AND TECHNICAL SUPPORT UNDER THE TERMS AND CONDITIONS DESCRIBED HEREIN.
BE SURE TO KEEP A COPY OF YOUR SALES RECEIPT!
STANDARD WARRANTY
OLIVETTI OFFICE USA, Inc. d/b/a ROYAL CONSUMER BUSINESS PRODUCTS ("Royal"), 379 Campus Dr. Somerset, NJ, 08873-
1125 WARRANTS that your NEW Royal product is free of defects of workmanship and materials. If there is a defect or malfunction
of this product, Royal will repair it free of charge as follows:
PARTS: New or comparable rebuilt parts in exchange for defective parts for ONE YEAR from date of customer purchase.
LABOR: Royal provides labor warranty for 1year from date of end-user purchase. Product must be sent postage prepaid and
insured to Royal. At completion of the repair, the consumer will be responsible for return shipping charges from Royal, and for any
parts or services no longer covered under warranty. This warranty does not apply to persons who purchased this product second
hand or used.
This warranty does not include adjustments, parts and repair by circumstances beyond the control of Royal, including but not limited
to, fire, or other casualty, accident, neglect, abuse, abnormal use or battery leakage damage.
THERE ARE NO OTHER EXPRESSED WARRANTIES EXCEPT AS STATED HEREIN. AFTER THE PERIOD OF EXPRESSED
WARRANTY SET FORTH HEREIN, THERE ARE NO EXPRESSED OR IMPLIED WARRANTIES AND THOSE EXCLUDED
INCLUDE THOSE OF MERCHANTABILITY AND FITNESS FOR PARTICULAR PURPOSE. Royal shall NOT be held liable for
CONSEQUENTIAL DAMAGES resulting from any failure, defect or malfunction of this product. Some States do not allow limitations
on how long an implied warranty lasts and some States do not allow the exclusion or limitation of incidental or consequential
damages, so the above limitations may not apply to you.
WARRANTY PROCEDURES
Royal has taken great care to insure the product you have purchased will provide years of trouble-free service. Should the product
require service within the first 30 days after purchase, Royal strongly recommends you return the product to the
place of purchase for replacement. Please note this 30-day replacement period may be subject to the limitations of the return policy
that has been established by your retailer, may not be available at your retailer, or may be for a different period
of time as established by your retailer. Your retailer may allow exchanges past this 30-day period. Should this be the case, Royal
strongly recommends you return the product to the place of purchase for replacement.
TO OBTAIN SERVICE UNDER THE TERMS OF THIS WARRANTY:
In the event you are unable to obtain a replacement product from your retailer,
please do the following:
1. Send a copy of your original sales receipt showing original purchase date along with your mailing address and a note describing
the nature of the problem to:
Royal Consumer Warranty Processing
PO Box 161
Jaminson, PA 18929-0161
DO NOT RETURN THE PRODUCT TO THIS ADDRESS!
2. You will receive a return authorization number within 7-10 business days from the date your return request is received if it is
determined that there is a basis for a replacement product. The return authorization form you
receive will list the return procedures, applicable charges, if any, and the correct shipping address for the returned product.
PRODUCT SUPPORT HOTLINE:
For questions on use of this product call 732-563-9944 Monday through Friday between the hours of 8:30AM and 5:00PM EST.
You can also email Royal at [email protected]. Allow two to three weeks for email response.
ROYAL®
Consumer Business Products
A DIVISION OF OLIVETTI OFFICE USA
379 Campus Drive
Somerset, NJ 08875
ROYAL
MD100
POWER
FOWARD
REVERSE
MD100 paper shredder
and media destroyer
MD100 paper shredder
and media destroyer
OPERATIONAL
MANUAL

21
MD100 Shredder and Media Destroyer
Setup:
1. Remove all the packing material from the plastic bin. Place the shredder securely
on top of a flat level surface.
2. Plug the power cord into any standard 115 volt AC outlet.
3. Depress the Power Button to turn on the Shredder. The Power Button will
illuminate. The Shredder and Media Destroyer are now ready to start shredding.
Operating the shredder:
The model MD100 Power Button is located on the top of the shredder. To turn on the
shredder, depress the Power Button. To turn off the shredder, depress the Power Button
again. The Reverse and Forward Buttons work as follows:
1. When the fwd Button is depressed, the shredding process will start. However, the
forward shred cycle last 2 seconds. This will allow the feed opening to be cleared
in the event excess paper is left in the shredder after normal shredding operations.
2. The rev Button is used to assist in the removal of a paper jam, which reverses the
shredding process prior to a completed forward cycle, thus clearing the cutters.
The reverse cycle will last for 2 seconds. This should be enough time to remove
any excess paper from the cutters and limit any paper from the wastebasket being
fed back into the shredder cutters. To access the Reverse Button use the point of a
pencil or ball point pen to depress the small button inside the round hole.
3. The MD100 is equipped with an auto start/stop photo sensor. When paper, CD,
Floppy Disk or Credit Card is inserted into the feed opening, the shredding process
will start automatically and stop when the item has completed its travel through the
feed opening
Shredder capacity:
The MD100 will shred up to seven (7) folded sheets of 20 lb. bond paper and will
accept paper widths up to 5". The shredding of Cds, Floppy Disk, or Credit Card
should be inserted one at a time. When shredding small material like credit card or
receipts, insert them through the middle of the feed opening.
Cautions:
1. Keep all loose articles of clothing, ties, jewelry, hair or other small items away from
the feed opening to prevent injury.
2. Keep in the OFF position when the shredder is not in use for prolong periods of
time.
3. When shredding CDs and Floppy Disk keep eyes and fingers away from feed
opening to avoid possible injury.
4. Do not place hands or fingers into the shredder throat as serious injury could result.
5. Continuous shredding of computer paper should not exceed 2 minutes. If continuous
use is required at the maximum sheet capacity (7 folded sheets), it is recommend
that shredding time should be 2 minute on and 4 minute off to allow for proper
cooling of the motor.
6. Always turn off or unplug the shredder prior to moving, cleaning or emptying the
wastebasket.
7. Empty wastebasket frequently.
MD100 Paper Shredder and Media Destroyer
Paper jams and motor overload situations:
The MD100 is equipped with a motor overload protection device. The normal short
duty cycle for continuous shredding at maximum capacity is 2 minutes on and 4 minutes
off. The power may terminate automatically in case of the following abnormal situations:
1. Operating the shredder at the maximum 7 folded sheet capacity continuously for a
prolonged period of time, eg. more than 2 minutes without stopping.
2. Exceeding the shredding capacity, eg. inserting more than seven (7) sheets of 20
lbs. paper at one pass, or if the paper is not fed squarely into the feed opening.
Both abnormal operations may result in the activation of the thermal motor overload
protection which terminates the power to the shredder. A major paper jam could cause
the thermal motor overload protection to terminate AC power to the motor. Never allow
the shredder to remain in a jammed condition with the AC power turned on. If this
occurs you should:
In case of a major paper jam:
1. Set the power switch to the OFF position or unplug the power cord from the AC
outlet and wait at least 20 minutes for the thermal overload protection to reset then
place the Power Switch back in the ON position.
2. Grasp the excess paper from the top and pull it out as you place the power switch
in the REV position. Be careful not to place your fingers near the feed opening or
else serious harm could result.
3. Set the power switch back to the AUTO position.
4. You are now ready to resume normal shredding.
Specifications:
Shred Type: Cross-Cut
Shred Width: 5/32" X 1.25"
Shredding Capacity: 7 Folded Sheets per pass
1 CD per pass
1 Floppy Disk per pass
1 Credit Card per pass
Feed Opening: 5.125"
Dimension: 10.25"(H) x 9.75(W) x 8(D)"
Weight: 10 lbs.
Input: 115 volt AC, 2.5 amp.
