RRS TFA-01 User manual

Specifications
Leg Positions (3) ...........1 angle stop, 2 angle stop, fully splayed
Load Capacity.............................................................. 15 lbs / 6.8kg
Platform Diameter.........................................................1.3” / 34mm
Stud ........................................................¼”-20 with ⅜”-16 Adapter
Folded Length with Stud .............................................5.8” / 147mm
Height at 1 Angle Stop...............................................4.7” / 119mm
Height at 2 Angle Stop ................................................3.3” / 84mm
Height Fully Splayed......................................................1.5” / 37mm
Weight .......................................................................... 4.8 oz / 135g
TFA-01 ULTRA POCKET ‘POD
1146 Farmhouse Lane, San Luis Obispo, CA 93401 USA
1-805-528-6321 | 1-888-777-5557
www.ReallyRightStu.com
IN USEKEY FEATURES
Rubberized foot
is secured with
stainless pin.
Wrap around rubberized
foot design assures positive
contact, even on curved
surfaces.
Pocket friendly size
when folded.
¼”- 20 stainless stud accepts
tripod head or camera. Use
included adapter if head has
larger 3/8”socket.
Black anodized apex is machined
from 6061-T6 aluminum. Internal
hardware is stainless steel.
Black anodized legs are
machined from 6061-T6
aluminum.
Maximum stability is
achieved when legs are
fully splayed.
Use Torx keys
(included) to adjust leg
tension.
Stainless steel adapter
(included)
4
2
3
3
SET LEG TENSION
Optimal leg tension is set at the
factory. For tighter leg tension,
seat T10 Torx keys (included)
into leg bolts and rotate
clockwise to tighten.
SET ANGLE STOPS
Open tripod to 1st
position.
1Swing leg inwards slightly. 2
Slide angle
stop button
down.
3
Swing leg out.
4
Specifications
Leg Positions (3) ...........1 angle stop, 2 angle stop, fully splayed
Load Capacity.............................................................. 15 lbs / 6.8kg
Platform Diameter.........................................................1.3” / 34mm
Stud ........................................................¼”-20 with ⅜”-16 Adapter
Folded Length with Stud .............................................5.8” / 147mm
Height at 1 Angle Stop ...............................................4.7” / 119mm
Height at 2 Angle Stop ................................................3.3” / 84mm
Height Fully Splayed......................................................1.5” / 37mm
Weight .......................................................................... 4.8 oz / 135g
TFA-01 ULTRA POCKET ‘POD
1146 Farmhouse Lane, San Luis Obispo, CA 93401 USA
1-805-528-6321 | 1-888-777-5557
www.ReallyRightStu.com
IN USEKEY FEATURES
Rubberized foot
is secured with
stainless pin.
Wrap around rubberized
foot design assures positive
contact, even on curved
surfaces.
Pocket friendly size
when folded.
¼”- 20 stainless stud accepts
tripod head or camera. Use
included adapter if head has
larger 3/8”socket.
Black anodized apex is machined
from 6061-T6 aluminum. Internal
hardware is stainless steel.
Black anodized legs are
machined from 6061-T6
aluminum.
Maximum stability is
achieved when legs are
fully splayed.
Use Torx keys
(included) to adjust leg
tension.
Stainless steel adapter
(included)
4
2
SET LEG TENSION
Optimal leg tension is set at the
factory. For tighter leg tension,
seat T10 Torx keys (included)
into leg bolts and rotate
clockwise to tighten.
SET ANGLE STOPS
Open tripod to 1st
position.
1Swing leg inwards slightly. 2
Slide angle
stop button
down.
3
Swing leg out.
4

GUARANTEE
ALL REALLY RIGHT STUFF BRAND PRODUCTS ARE
GUARANTEED TO THE ORIGINAL PURCHASER TO BE FREE
OF DEFECTS IN MATERIALS OR WORKMANSHIP FOR FIVE
(5) YEARS FROM THE DATE OF PURCHASE. PRODUCTS WILL
BE REPAIRED OR REPLACED AT OUR OPTION.
® , ™, © 1990-2016 Really Right Stuff, LLC. All rights reserved.
INSTALL BC-18
The RRS BC-18 Ball Clamp comes pre-
threaded with ”-20 stud. Therefore the
stud that normally comes installed in the
TFA-01 Ultra is not needed. Thread BC-18 directly
into the platform of the TFA-01 Ultra.
INSTALL BALLHEAD
1. If tripod head has Panning Base, tighten prior to installing. If
mounting the BH-25, tighten the Main Lock T-Lever.
2. Install adapter if needed,
then screw head onto the
threaded stud on the top
of the tripod. Tighten head onto
the tripod snugly, but do not
over-torque or it will be diicult
to remove.
MAINTENANCE
General Care
The TFA-01 Ultra tripod is finished with a protective anodize plating
that protects the aluminum from corrosion and mild abrasion. It will
not protect it from scraping against or dropping on rocks/concrete/
etc. Do NOT attempt to remove the legs from the apex.
Cleaning
Take precautions to prevent your TFA-01 Ultra from getting
fouled. Remember that sand and saltwater are your tripod’s worst
environmental enemies. Always clean your tripod after exposure.
Dry dust and dirt can be blown off and/or wiped off with a soft cloth.
Lightly rinse off mud or salt water with fresh water then wipe dry. Thread into TFA-01
Ultra without tripod
stud. For a more
secure connection,
use non-permanent
threadlocker fluid*.
If tripod head socket is bigger
than tripod stud, thread
included adapter onto stud.
Secure adapter to stud with
non-permanent threadlocker
fluid* (recommended).
*
*
Available in single
application tubes
from RRS.
Available in single application
tubes from RRS.
GUARANTEE
ALL REALLY RIGHT STUFF BRAND PRODUCTS ARE
GUARANTEED TO THE ORIGINAL PURCHASER TO BE FREE
OF DEFECTS IN MATERIALS OR WORKMANSHIP FOR FIVE
(5) YEARS FROM THE DATE OF PURCHASE. PRODUCTS WILL
BE REPAIRED OR REPLACED AT OUR OPTION.
® , ™, © 1990-2016 Really Right Stuff, LLC. All rights reserved.
INSTALL BC-18
The RRS BC-18 Ball Clamp comes pre-
threaded with ”-20 stud. Therefore the
stud that normally comes installed in the
TFA-01 Ultra is not needed. Thread BC-18 directly
into the platform of the TFA-01 Ultra.
INSTALL BALLHEAD
1. If tripod head has Panning Base, tighten prior to installing. If
mounting the BH-25, tighten the Main Lock T-Lever.
2. Install adapter if needed,
then screw head onto the
threaded stud on the top
of the tripod. Tighten head onto
the tripod snugly, but do not
over-torque or it will be diicult
to remove.
MAINTENANCE
General Care
The TFA-01 Ultra tripod is finished with a protective anodize plating
that protects the aluminum from corrosion and mild abrasion. It will
not protect it from scraping against or dropping on rocks/concrete/
etc. Do NOT attempt to remove the legs from the apex.
Cleaning
Take precautions to prevent your TFA-01 Ultra from getting
fouled. Remember that sand and saltwater are your tripod’s worst
environmental enemies. Always clean your tripod after exposure.
Dry dust and dirt can be blown off and/or wiped off with a soft cloth.
Lightly rinse off mud or salt water with fresh water then wipe dry. Thread into TFA-01
Ultra without tripod
stud. For a more
secure connection,
use non-permanent
threadlocker fluid*.
If tripod head socket is bigger
than tripod stud, thread
included adapter onto stud.
Secure adapter to stud with
non-permanent threadlocker
fluid* (recommended).
*
*
Available in single
application tubes
from RRS.
Available in single application
tubes from RRS.
¼”-20
¼”-20
