Rugged Computing Y200 Quick start guide

&
Assembly Instructions
OWNER’S MANUAL
Y200-121217
SKU# Y200
STRENGTH & FITNESS
WARRIOR
POWER RACK EXTENSION

Warning, Safety & Maintenance
2
Be sure that all users carefully read and understand all
warning, safety and maintenance labels on the machine
before each use. Failure to do so may result in death or
serious injury.
It is imperative that you retain this Owner’s Manual and be
sure all warning labels are legible and intact. Replacement
Owner’s Manuals and warning labels are available from
Rugged Fitness.
If you have any questions about the operation, set up or
maintenance of this machine please call our customer service
department at 1 (800) 556-3113.

Table of Contents
3
• SAFETYINSTRUCTIONS..............................PAGE4
• PREPARATION...............................................PAGE5
• HARDWAREILLUSTRATION.........................PAGE6
• PARTS/HARDWARELIST.............................PAGE8
• PARTSILLUSTRATION..................................PAGE9
• ASSEMBLYINSTRUCTIONS.........................PAGE10
• EXPLODEDVIEW..........................................PAGE15
• CONTACTPAGE............................................PAGE16

Important Safety Instructions
4
Beforebeginninganytnessprogram,youshouldobtainacompletephysicalexaminationfromyourphysician.
Il est conseille de subir un examen medical complet avant d’entreprendre tout programme d’exercise.
Si vous avez des etourdissements ou des faiblesses, arretez les exercices immediatement.
Antes de comenzar cualquier programma de ejercicios, deberias tener un examen sico con su doctor.
When using exercise equipment, you
should always take basic precautions,
including the following:
m Readallinstructionsbeforeusingthisequipment.
Theseinstructionsarewrittentoensureyoursafety
andtoprotecttheunit.
m Do not remove any safety labels from the
machine.
m Donotallowchildrenonorneartheequipment.
m Usetheequipmentonlyforitsintendedpurpose
asdescribedinthisguide.Donotuseaccessory
attachmentsthatarenotrecommendedbythe
manufacturer.Suchattachmentsmightcause
injuries.
m Wearproperexerciseclothingandshoesforyour
workout,nolooseclothing.
m Keephands,limbs,looseclothing,andlonghairwell
outofthewayofallmovingparts.
m Usecarewhengettingonorotheunit.
m Donotoverexertyourselforworktoexhaustion.
m Ifyoufeelanypainorabnormalsymptoms,stop
yourworkoutimmediatelyandconsultyour
physician.
m Neveroperateunitwhenithasbeendroppedor
damaged.Returntheequipmenttoaservice
centerforexaminationandrepair.
m Neverdroporinsertobjectsintoanyopeningin
theequipment.
m Ifthemachineisequippedwithcables,alwayscheck
itscablesbeforeeachuse.Makesurethatall
fastenersandcablesaresecureandingoodworking
condition.
m Donotusetheequipmentoutdoorsornearwater.
Personal Safety During Assembly
m Beforebeginningassembly,pleasetakethetime
toreadtheinstructionsthoroughly.
m Readeachstepintheassemblyinstructionsand
followthestepsinsequence.Donotskipahead.
Ifyouskipahead,youmaylearnlaterthatyou
havetodisassemblecomponentsandthatyou
mayhavedamagedtheequipment.
m Assembleandoperatetheequipmentonasolid,
levelsurface.Locatetheunitafewfeetfromthe
wallsorfurnituretoprovideeasyaccess.
Thisequipmentisdesignedforyourenjoyment.By
followingtheseprecautionsandusingcommonsense,
youwillhavemanysafeandpleasurablehoursof
healthfulexercisewithyourRUGGED FITNESS
POWER RACK EXTENSION.
Afterassembly,youshouldcheckallfunctionsto
ensurecorrectoperation.Ifyouexperienceproblems,
rstrechecktheassemblyinstructionstolocateany
possibleerrorsmadeduringassembly.Ifyouareunable
tocorrecttheproblem,call1-800-556-3113forcustomer
assistance.
Obtaining Service
PleaseusethisOwner’sManualtomakesurethatall
partshavebeenincludedinyourshipment.When
orderingparts,youmustusethepartnumberand
descriptionfromthisOwner’sManual.Useonly
RUGGEDFITNESSreplacementpartswhenservicing
thismachine.Failuretodosowillvoidyourwarrantyand
couldresultinpersonalinjury.
Forinformationaboutproductoperationorservice,
checkouttheocialRUGGEDFITNESSwebsiteat
www.ruggedtness.comorcontactRUGGEDFITNESS
customerserviceatoneofthefollowing:
Toll Free: 1-800-556-3113
Phone: 1-708-427-3555
Fax: 1-708-427-3556
Hours: M-F 8:30-5:00 CST
E-Mail: service@ruggedtness.com
Or write to: Rugged Fitness
Service Department
1900 S. Des Plaines Ave.
Forest Park, IL 60130 USA
Retain this Owner’s Manual for future
reference. If you need to order replacement
parts please be prepared to provide the
following information when contacting us so
that we can assist you better.
1. Model Number
2. Place of Purchase
3. Serial Number (S/N)
4. Part # and Description

Preparation
5
RUGGEDFITNESScontinuallyseekswaystoimprovetheperformance,specicationsandproductmanualsinordertoensurethat
onlysuperiorproductsarereleasedfromourfactories.Pleasetakethetimetocarefullyreadthroughthismanualthoroughly.In-
structionscontainedinthisdocumentarenotintendedtocoveralldetailsorvariationspossiblewithRUGGEDFITNESSequipment,
ortocovereverycontingencythatmaybemetinconjunctionwithinstallation,operation,maintenanceortroubleshootingofthe
equipment.Eventhoughwehavepreparedthismanualwithextremecare,neitherthepublishernortheauthorcanacceptrespon-
sibilityforanyerrorsin,oromissionfrom,theinformationgiven.Shouldadditionalinformationberequired,orshouldsituationsarise
thatarenotcoveredbythismanual,themattershouldbedirectedtoServiceDepartmentatRUGGEDFITNESSInc.inForestPark,
Illinois.
Required Tools
Thebasictoolsthatyoumustobtainbeforeassembling
theY200includebutarenotlimitedto:
m StandardWrenchSet
m MetricWrenchSet
m AdjustableWrench
Installation Requirements
Followtheseinstallationrequirementswhenassembling
theY200.SetuptheY200onasolid,atsurface.A
smooth,atsurfaceunderthemachinehelpskeepit
level.Alevelmachinehasfewermalfunctions.
Provideamplespacearoundthemachine.Open
spacearoundthemachineallowsforeasieraccess.
Foraestheticpurposes,insertallboltsinthesame
directionunlessspecied(intextorillustrations)todo
otherwise.
Leaveroomforadjustments.Tightenfastenerssuchas
bolts,nuts,andscrewssotheunitisstable,butleave
roomforadjustments.Donotfullytightenfasteners
untilinstructedintheassemblystepstodoso.
Fill out and mail the warranty card.
Assembly Tips
Readall“Notes”oneachpagebeforebeginningeach
step.
WhileyoumaybeabletoassembletheY200usingthe
illustrationsonly,importantsafetynotesandothertips
areincludedinthetext.
Somepiecesmayhaveextraholesthatyouwillnotuse.
Useonlythoseholesindicatedintheinstructionsand
illustrations.
NOTE: Withsomanyassembledparts,proper
alignmentandadjustmentiscritical.While
tighteningthenutsandbolts,besuretoleave
roomforadjustments.
CAUTION: Obtainassistance!Donotattemptto
assembletheequipmentaloneas
thiscouldresultininjury.Reviewthe
installationrequirementsbeforeproceeding
withthefollowingsteps.
YourS/N#can
befoundhere
↑

45
6
Y200 Hardware Illustration
Part#2 HEXHEADBOLTM16x110mm QTY.4
Part#1 HEXHEADBOLTM16x120mm QTY.4
Part#3 HEXHEADBOLTM16x90mm QTY.4

7
Y200 Hardware Illustration
Part#4 REGULARFLATWASHERM16 QTY.24
7
Part#5 NYLONLOCKNUTM16 QTY.12

8
Y200 Parts & Hardware List
Part# Qty Description
A 1 RIGHTEXTENSIONFRAME
B 1 LEFTEXTENSIONFRAME
C 4 STEELBRACKET
D 2 UPRIGHT
1 4 M16x120mmHEXHEADBOLT
2 4 M16x110mmHEXHEADBOLT
3 4 M16x90mmHEXHEADBOLT
4 24 M16REGULARFLATWASHER
5 12 M16NYLONLOCKNUT

45
9
Parts Illustration
PartA-RIGHTEXTENSIONFRAME,
QTY1
PartB-LEFTEXTENSIONFRAME,
QTY1
PartC-RIGHTSTEELBRACKET,QTY4 PartD-UPRIGHT,QTY2

10
STEP
1
Be careful to assemble all components
in the sequence they are presented.
NOTE:
Finger tighten all hardware in this step. DO NOT wrench tighten until instructed.
Some components may be pre-assembled. Nylon lock nuts will not fully screw onto
bolts, they must be wrench tightened to fully go on.
1A. InsertExtensionFrames(A & B) intotheopenendsofBaseFrames
ofthePowerRack.
1B. AttachSteelBrackets(C),ExtensionFrames(A & B) and
BaseFramesofthePowerRacktogetherusing:
(#2) M16x110mm Hex Head Bolt, QTY 4
(#4) M16 Regular O.D. Washer, QTY 8
(#5) M16 Nylon Lock Nut, QTY 4

STEP
1
AboveshowsStep1assembledandcompleted.
11

12
STEP
2
Be careful to assemble all components
in the sequence they are presented.
NOTE:
Finger tighten all hardware rst in this step. Wrench tighten ALL hardware at the end of
STEP 2B. Some components may be pre-assembled. Nylon lock nuts will not fully screw
onto bolts, they must be wrench tightened to fully go on.
2A. AttachUprights(D)toSteelBrackets(C) using:
(#3) M16x90mm Hex Head Bolt, QTY 4
(#4) M16 Regular O.D. Washer, QTY 8
(#5) M16 Nylon Lock Nut, QTY 4
2B. AttachUprights(D)totheUprightsofthePowerRackusing:
(#1) M16x120mm Hex Head Bolt, QTY 4
(#4) M16 Regular O.D. Washer, QTY 8
(#5) M16 Nylon Lock Nut, QTY 4

STEP
2
AboveshowsStep2assembledandcompleted.
13

45
14
Notes

15
Y200 Exploded View

1900S.DesPlainesAve.
ForestPark,IL60130
Phone:(708)427-3555
Fax:(708)427-3556
Hours:M-F8:30-5:00CST
www.ruggedtness.com
PLEASEWRITEYOURSERIALNUMBERINTHEBOXESBELOW
S/N#013483-��-��-����-����
Y200
