Ruijie RG-AP680(CD) Access Point
Hardware Installation and Reference Guide
Document Version: V1.2
Date: August 17, 2023
Copyright © 2023 Ruijie
Networks

Copyright
Copyright © 2023 Ruijie Networks
All rights are reserved in this document and this statement.
Any reproduction, excerption, backup, modification, transmission, translation or
commercial use of this document or any portion of this document, in any form or by any
means, without the prior written consent of Ruijie Networks is prohibited.
Trademark and are owned by Ruijie
Networks.
All other trademarks or registered trademarks mentioned in this document are owned by
their respective owners.
Disclaimer
The products, services, or features you purchase are subject to commercial contracts and
terms. Some or all of the products, services or features described in this document may
not be within the scope of your purchase or use. Unless otherwise agreed in the contract,
Ruijie Networks does not make any express or implied statement or guarantee for the
content of this document.
Due to product version upgrades or other reasons, the content of this document will be
updated from time to time. Ruijie Networks reserves the right to modify the content of
the document without any notice or prompt.
This manual is for reference only. Ruijie Networks endeavors to ensure content accuracy
and will not shoulder any responsibility for losses and damages caused due to content
omissions, inaccuracies or errors.

I
Preface
Intended Audience
This document is intended for:
Network engineers
Technical support and servicing engineers
Network administrators
Technical Support
Ruijie Networks website: https://www.ruijienetworks.com/
Technical support website: https://ruijienetworks.com/support
Case portal: https://caseportal.ruijienetworks.com
Community: https://community.ruijienetworks.com
Technical support Email: [e-mail]
Live Chat: https://www.ruijienetworks.com/rita
Conventions
1. Signs
The signs used in this document are described as follows:
Warning
An alert that calls attention to important rules and information that if not understood or
followed can result in data loss or equipment damage.
Caution
An alert that calls attention to essential information that if not understood or followed
can result in function failure or performance degradation.
Note
An alert that contains additional or supplementary information that if not understood or
followed will not lead to serious consequences.

II
Specification
An alert that contains a description of product or version support.
2. Note
This manual provides the device installation steps, hardware troubleshooting, module
technical specifications, and specifications and usage guidelines for cables and
connectors. It is intended for the users who have some experience in installing and
maintaining network hardware. At the same time, it is assumed that the users are
already familiar with the related terms and concepts.

i
Contents
Preface.................................................................................................................................................. I
1 Product Introduction....................................................................................................................... 1
1.1 Overview ...................................................................................................................................1
1.2 Product Appearance ................................................................................................................1
1.3 Technical Specifications...........................................................................................................2
1.3.1 Dimensions and Weight...............................................................................................2
1.3.2 Radio Specifications .....................................................................................................2
1.3.3 Port Specifications........................................................................................................4
1.3.4 Power Supply and Consumption ................................................................................5
1.3.5 Environment and Reliability ........................................................................................5
1.4 LED and Button.........................................................................................................................6
2 Preparing for Installation................................................................................................................ 8
2.1 Grounding and Lightning Protection Requirements ............................................................8
2.2 Installation Site Requirements................................................................................................9
2.2.1 Temperature and Humidity Requirements................................................................9
2.2.2 Installation Methods....................................................................................................9
2.2.3 Waterproof Requirements...........................................................................................9
2.2.4 EMI...............................................................................................................................10
2.3 Precautions for Fiber-Optic Cable Connection ....................................................................11

ii
2.4 Tools ........................................................................................................................................11
2.5 Checking Before Installtion...................................................................................................11
3 Installing the Access Point............................................................................................................ 12
3.1 Installation Flowchart ............................................................................................................12
3.2 Before You Begin....................................................................................................................12
3.3 Precautions.............................................................................................................................13
3.4 Installing the Access Point.....................................................................................................13
3.5 Connecting Cables .................................................................................................................16
3.6 Bundling Cables......................................................................................................................19
4 Appendix ........................................................................................................................................ 22
4.1 Connectors and Media...........................................................................................................22
4.2 Mini-GBIC Module Models and Specifications.....................................................................24
4.3 Package Contents...................................................................................................................26

Hardware Installation and Reference Guide Product Introduction
1
1 Product Introduction
1.1 Overview
The RG-AP680(CD) is a dual-radio and IEEE 802.11ax-compliant access point (AP) released
by Ruijie Networks for general education scenarios. The RG-AP680(CD) provides a
combined data rate of 1.775 Gbps, with up to 575 Mbps in the 2.4 GHz band and 1200
Mbps in the 5 GHz band. The RG-AP680(CD) AP provides one 1GE SFP port and one 1GE
Ethernet port, which can work at the same time.
1.2 Product Appearance
Figure 1-1Product Appearance of the RG-AP680(CD)
1. Console port and reset button
2. Port for 48 V DC power supply
3. 10/100/1000 Base-T Ethernet/PoE port with
auto-negotiation
4. SFP port

Hardware Installation and Reference Guide Product Introduction
2
1.3 Technical Specifications
1.3.1 Dimensions and Weight
Table 1-1 Dimensions and Weight
Dimensions and
Weight
RG-AP680(CD)
Dimensions (W × D
× H)
251 mm × 168 mm × 64 mm (9.88 in. x 6.61 in. x 2.52 in.)
Weight
1.5 kg (3.31 lbs.)
Installation
Wall mounting and pole mounting
Mounting bracket
dimensions (W × D
× H)
115 mm × 115 mm × 126 mm (4.53 in. x 4.53 in. x 4.96 in.)
Mounting hole
pattern
90 mm × 43.32 mm (3.54 in. x 1.71 in.)
Mounting hole
diameter
8 mm (0.31 in.)
Pole diameter
40 mm to 70 mm (1.57 in. x 2.76 in.)
1.3.2 Radio Specifications
Table 1-2 Radio Specifications
Radio
Specifications
RG-AP680(CD)
Radio design
Dual-radio
Up to four spatial streams
Radio 1: 2.4 GHz/5 GHz, two spatial streams: 2 x 2, MU-MIMO

Hardware Installation and Reference Guide Product Introduction
3
Radio
Specifications
RG-AP680(CD)
Radio 2: 5 GHz, two spatial streams: 2 x 2, MU-MIMO
Operating
frequencies
Radio 1: 802.11b/g/n/ax, 2.400 GHz to 2.4835 GHz
Radio 2: 802.11a/n/ac/ax, 5.150 GHz to 5.350 GHz, 5.725 GHz to
5.850 GHz
Note: The operating frequencies is country-specific.
Data rate
Radio 1: 2.4 GHz, 575 Mbps/5 GHz, 1.2 Gbps
Radio 2: 5 GHz, 1.2 Gbps
Combined:
2.4 GHz + 5 GHz: 1.775 Gbps
5 GHz + 5 GHz, 2.4 Gbps
Antenna type
Built-in smart antenna
Antenna gain
2.4 GHz: 9 dBi
5 GHz: 9 dBi
Max. transmit
power
28 dBm
Note: The transmit power is limited by local regulatory
requirements.
Power increment
1 dBm
Modulation
OFDM: BPSK @ 6/9 Mbps, QPSK @ 12/18 Mbps, 16-QAM @ 24
Mbps, and 64-QAM @ 48/54 Mbps
DSSS: DBPSK @ 1 Mbps, DQPSK @ 2 Mbps, and CCK @ 5.5/11 Mbps
MIMO-OFDM: BPSK, QPSK, 16-QAM, 64-QAM, 256-QAM, and 1024-
QAM
Receive sensitivity
802.11b: –91 dBm (1 Mbps), –88 dBm (5 Mbps), –85 dBm(11 Mbps)
802.11a/g: –89 dBm (6Mbps), –80 dBm (24Mbps), –76 dBm (36Mbps),
–71 dBm (54Mbps)

Hardware Installation and Reference Guide Product Introduction
4
Radio
Specifications
RG-AP680(CD)
802.11n: –83 dBm @ MCS0, –65 dBm @ MCS7, –83 dBm @ MCS8, –65
dBm @ MCS15
802.11ac HT20: –83 dBm (MCS0), –57 dBm (MCS9)
802.11ac HT40: –79 dBm (MCS0), –57 dBm (MCS9)
802.11ac HT80: –76 dBm (MCS0), –51 dBm (MCS9)
802.11ax HE80: –76 dBm (MCS0), –49 dBm (MCS11)
1.3.3 Port Specifications
Table 1-3 Port Specifications
Port Specifications
RG-AP680(CD)
Bluetooth
Bluetooth 5.0
Fixed service port
One 10/100/1000Base-T Ethernet port with auto-negotiation,
powered by powered devices (PDs)
One 1GE SFP port
Fixed management
port
One RJ45 console port
Status LED
One system status (SYS) LED
Three Received Signal Strength Indicator (RSSI) LEDs
Button
One reset button

Hardware Installation and Reference Guide Product Introduction
5
1.3.4 Power Supply and Consumption
Table 1-4 Power Supply and Consumption
Power Supply and
Consumption
RG-AP680(CD)
Input power supply
1. DC power supply (44 V to 57 V/0.35 A)
2. PoE/PoE+ (IEEE 802.3af/at-compliant)
Max. power
consumption
12.95 W
Caution
To power the AP by PoE, ensure that the device at the other end of the Ethernet
cable supports IEEE 802.3af/at-compliant power supply.
The direct current should be 0.35 A at least. The power port and power cords should
meet the working environment requirements. For example, the temperature is
between –40°C and +65°C (–40°C°F to +149°F). The power cords should be
waterproof and sun-resistant.
1.3.5 Environment and Reliability
Table 1-5 Standard Compliance
Environment and
Reliability
RG-AP680(CD)
Temperature
Working temperature: –40°C to +65°C (–40°F to +149°F)
Storage temperature: –40°C to +85°C (–40°F to +185°F)
Note: At an altitude between 3000 m (9842.52 ft) and 5000 m
(16404.20 ft), every time the altitude increases by 220 m (721.78
ft.), the maximum temperature decreases by 1°C (1.8°F).
Humidity
Working humidity: 0% RH to 100% RH (non-condensing)
Storage humidity: 0% RH to 100% RH (non-condensing)

Hardware Installation and Reference Guide Product Introduction
6
Environment and
Reliability
RG-AP680(CD)
IP rating
IP68
Anti-corrosion rating
Salt spray test: 48 hours
Safety standard
GB 4943.1, IEC 60950-1
EMC standard
EN 301 489, EN 55022
1.4 LED and Button
The RG-AP680(CD) has multiple LEDs, including one SYS LED and RSSI LEDs. The status of
LEDs is described as follows.
Table 1-6 LEDs of the RG-AP680(CD)
LED
Status
Description
System status
LED
Blinking green
The AP is booting.
Solid green
The AP is booting and works properly.
Blinking orange
The AP is working properly but no CAPWAP
connection is established.
Blinking red
The uplink wired port is disconnected.
RSSI (3 LEDs in
total; available
when bridging is
enabled)
1 solid on
< –70 dBm
2 solid on
–70 dBm to –50 dBm
3 solid on
> –50 dBm

Hardware Installation and Reference Guide Product Introduction
7
Table 1-7 Reset Button of the RG-AP680(CD)
Button
Function
Result
Reset button
To reboot the AP
Press the button for less than 2s to reboot the
device.
To restore to factory
settings
Press and hold the button for over 3s to
restore factory settings.

Hardware Installation and Reference Guide Preparing for
Installation
8
2 Preparing for Installation
Note
To avoid personal injury and device damage, carefully read the safety precautions
before you install the device.
The following safety precautions may not cover all possible dangers.
2.1 Grounding and Lightning Protection Requirements
Ensure that both the power-receiving end and the power-supplying end are well-
grounded.
The grounding cable is shorter than 30 m (98.43 ft), and use a 40 mm (1.57 in.) x 4 mm
(0.16 in.) or 50 mm (1.97 in.) x 5 mm (0.20 in.) hot-dip galvanized steel flat bar as the
grounding bar.
When the connection cable between the main grounding conductor and local
equipotential earthing terminal board (LEB) on each floor is short, use a stranded
copper wire with a sectional area not less than 1.318 mm2 (16 AWG) for the
connection cable.
Use a shielded network cable if possible, ensure that the devices connected to both
ends of the shielded network cable are reliably grounded, and make sure that the
sheath of the shielded network cable is also grounded if possible. If no shielded
network cable is available, wire the network cable through a steel pipe and bury the
steel pipe for lead-in, and properly ground both ends of the steel pipe.
No additional lightning protector is required as a high-profile lightning protector is
built in the RG-AP680(CD), and the power port support 6 kV lightning protection. If a
lightning protector of a higher profile is available, configure the lightning protector as
required. Before the configuration, connect the lightning protector to the grounding
cable.
Use a power cord with the protective earthing (PE) connector to ground the AC power
supply. Ensure that the PE connector is properly grounded, with a ground resistance
less than 5 ohms. Do not use a two-wire power cable with only the live (L) wire and
naught (N) wire. Do not connect the N wire to the protection grounding cable of other
communication devices, and ensure that the L wire and N wire are properly

Hardware Installation and Reference Guide Preparing for
Installation
9
connected.
Ensure that the ground resistance is less than 5 ohms. In areas with high soil
resistivity, reduce the soil resistivity by measures such as spreading resistivity
reduction mixture around the grounding conductor.
2.2 Installation Site Requirements
Do not expose the AP to high temperature, dusts, or harmful gases. Do not install the AP
in an inflammable or explosive environment. Keep the AP away from EMI sources such as
large radar stations, radio stations, and substations. Do not subject the AP to unstable
voltage, vibration, and strong noises. The installation site should be dry. You are not
advised to install the AP in a place near the sea. Keep the device at least 500 m (1640.42
in.) away from the sea and do not face it towards the sea breeze. The installation site
should be free from water flooding, seepage, dripping, or condensation. The installation
site should be selected according to network planning, communications equipment
features, and considerations such as climate, hydrology, geology, earthquake, electrical
power, and transportation.
2.2.1 Temperature and Humidity Requirements
Table 2-1 Required Temperature and Humidity for the RG-AP680(CD)
Working
Temperature
–40°C to +65°C (–40°F to +149°F)
Working Humidity
0% to 100% (non-condensing)
2.2.2 Installation Methods
The RG-AP680(CD) can be mounted on a wall or pole.
2.2.3 Waterproof Requirements
Cap unused ports using dust caps to ensure waterproof.

Hardware Installation and Reference Guide Preparing for
Installation
10
Figure 2-1Dust Cap
Connect the network cable, optical fiber jumper, and DC power cord to the AP after they
pass through the corresponding waterproof plugs to ensure waterproof. For details, see
3.4 Installing the Access Point.
2.2.4 EMI
All interference sources (from outside or inside of the device or application system) affect
the device by capacitive coupling, inductive coupling, or electromagnetic waves.
Electromagnetic interference (EMI) occurs due to electromagnetic radiation or
conduction, depending on the transmission path.
Radiation interference occurs when energy (usually radio frequency energy) is emitted
from a device and propagated through space to disrupt other devices. The interference
source can be part of disrupted system or a fully electrically isolated unit. Conduction
interference occurs when interference is transferred from one unit to another through
cables, which are usually electromagnetic wires or signal cables connected between the
source and the devices experiencing interference. Conduction interference often affects
the power supply of the device. It is eliminated by using filters. Radiation interference
can influence the path of any signal from the device and is difficult to shield.
Take effective measures against interference from the power grid.
Keep the AP far away from the grounding or lightning protection devices for power
equipment.
Keep the AP away from high-power radio stations, radar stations, and high-frequency
high-current devices.
Take electrostatic shielding measures.

Hardware Installation and Reference Guide Preparing for
Installation
11
2.3 Precautions for Fiber-Optic Cable Connection
Before connecting fiber-optic cables, make sure the model of the optical connector and
fiber type match the optical port. The transmit port on the local device should be
connected to the receive port on the peer device and vice versa.
2.4 Tools
Table 2-2 Tools
Tools
Marker, Phillips screwdriver, flat-blade screwdriver, drill, paper knife,
crimping pliers, diagonal pliers, network cable pliers, wire stripper,
network cable tester, related electric and fiber-optic cables, wrench,
hammer, cable ties, ESD tools, multimeter, waterproof duct tape, and
waterproof plaster
Note
The RG-AP680(CD) is not delivered with a tool kit. The tool kit is customer-supplied.
2.5 Checking Before Installtion
Note
Please check your goods carefully against the package contents in this document. If you
have any questions, please contact the supplier or agent.

Hardware Installation and Reference Guide Installing the Access Point
12
3 Installing the Access Point
Note
Before installing the AP, make sure you have carefully read the requirements described
in Chapter 2.
3.1 Installation Flowchart
3.2 Before You Begin
Carefully plan and arrange the installation location, networking mode, power supply, and
cabling before installing the device.
Confirm the following requirements before installation:
The installation location meets the temperature and humidity requirements of the

Hardware Installation and Reference Guide Installing the Access Point
13
device.
The power supply and required current are available in the installation location.
The network cables have been deployed in the installation location.
3.3 Precautions
The RG-AP680(CD) can be mounted on a wall or a pole with a diameter ranging from 50
mm to 140 mm (1.97 in. to 5.51 in.). Use the 304 stainless steel hose clamp delivered with
the AP. If the diameter of the pole is out of this range, purchase the SUS304 hose clamp
with a proper size for installation. The thickness of the hose clamp should be at least 2.5
mm (0.10 in.). Otherwise, the AP could fall down and cause injuries. The installation site
should be determined by the technical personnel who conducts a site survey.
To ensure the normal operation of the AP and lengthen the service life of the AP, observe
the following precautions before installing the AP.
Before connecting the power supply, make sure the external power supply matches
the power module inside the AP.
Before connecting the power cord, make sure the power switch is in the OFF position.
When connecting a wire to a grounding stud, make sure their colors are the same.
Make sure the power supply is properly connected.
3.4 Installing the Access Point
(1) Use four M5 screws to secure the AP to the mounting plate.

Hardware Installation and Reference Guide Installing the Access Point
14
Figure 3-1Securing the Access Point to the Mounting Plate
(2) Install the mounting bracket to a pole or wall.
Pole mounting
As shown in Figure 3-2, attach the mounting bracket to a pole by threading two hose
clamps through openings of the mounting bracket.
Figure 3-2Attaching the Mounting Bracket to a Pole
Wall mounting
As shown in Figure 3-3, install the mounting bracket on a wall using four M6
expansion anchors.
