Ruijie RG-SAP150-SP-W Installation and operating manual

Ruijie RG-SAP150-SP-W Access Point
Hardware Installation and Reference Guide
Document version: 1.1
Date: August 16, 2023
Copyright © 2023 Ruijie
Networks

Copyright
Copyright © 2023 Ruijie Networks
All rights are reserved in this document and this statement.
Any reproduction, excerption, backup, modification, transmission, translation or
commercial use of this document or any portion of this document, in any form or by any
means, without the prior written consent of Ruijie Networks is prohibited.
Trademark and are owned by Ruijie
Networks.
All other trademarks or registered trademarks mentioned in this document are owned by
their respective owners.
Disclaimer
The products, services, or features you purchase are subject to commercial contracts and
terms. Some or all of the products, services or features described in this document may
not be within the scope of your purchase or use. Unless otherwise agreed in the contract,
Ruijie Networks does not make any express or implied statement or guarantee for the
content of this document.
Due to product version upgrades or other reasons, the content of this document will be
updated from time to time. Ruijie Networks reserves the right to modify the content of
the document without any notice or prompt.
This manual is for reference only. Ruijie Networks endeavors to ensure content accuracy
and will not shoulder any responsibility for losses and damages caused due to content
omissions, inaccuracies or errors.

I
Preface
Intended Audience
This document is intended for:
Network engineers
Technical support and servicing engineers
Network administrators
Technical Support
Ruijie Networks website: https://www.ruijienetworks.com/
Technical support website: https://ruijienetworks.com/support
Case portal: https://caseportal.ruijienetworks.com
Community: https://community.ruijienetworks.com
Technical support email: [e-mail]
Live chat: https://www.ruijienetworks.com/rita
Conventions
1. Conventions
Convention
Description
Bold font
Commands, command options, and keywords are in
bold font.
Italic font
Arguments for which you supply values are in italic
font.
[ ]
Elements in square brackets are optional.
{ x | y | z }
Alternative keywords are grouped in braces and
separated by vertical bars.
[ x | y | z ]
Optional alternative keywords are grouped in brackets
and separated by vertical bars.

II
&<1-n>
The argument before the sign (&) can be input for
consecutive 1- n times.
//
Double slashes at the beginning of a line of code
indicate a comment line.
2. Signs
The signs used in this document are described as follows:
Warning
An alert that calls attention to important rules and information that if not understood or
followed can result in data loss or equipment damage.
Caution
An alert that calls attention to essential information that if not understood or followed
can result in function failure or performance degradation.
Note
An alert that contains additional or supplementary information that if not understood or
followed will not lead to serious consequences.
Specification
An alert that contains a description of product or version support.
3. Note
The manual offers configuration information (including model, port type and command
line interface) for indicative purpose only. In case of any discrepancy or inconsistency
between the manual and the actual version, the actual version prevails.

i
Contents
Preface...................................................................................................................................................I
1 Product Overview .............................................................................................................................1
1.1 About the RG-SAP150-SP-W Access Point ..............................................................................1
1.2 Product Appearance ................................................................................................................1
1.3 Package Contents.....................................................................................................................4
1.4 Technical Specifications...........................................................................................................4
1.4.1 Dimensions and Weight...............................................................................................4
1.4.2 Radio Specifications .....................................................................................................4
1.4.3 Port Specifications........................................................................................................6
1.4.4 Power Supply and Consumption ................................................................................6
1.4.5 Environment and Reliability ........................................................................................7
1.5 LED and Button.........................................................................................................................7
2 Preparing for Installation.................................................................................................................9
2.1 Safety Precautions....................................................................................................................9
2.1.1 General Safety Precautions .........................................................................................9
2.1.2 Handling Safety ..........................................................................................................10
2.1.3 Electric Safety..............................................................................................................10
2.1.4 Storage Security .........................................................................................................11
2.2 Installation Environment Requirements..............................................................................11
2.2.1 Bearing........................................................................................................................11

ii
2.2.2 Ventilation...................................................................................................................11
2.2.3 Clearance ....................................................................................................................11
2.2.4 Temperature and Humidity.......................................................................................11
2.2.5 Cleanliness..................................................................................................................12
2.2.6 Anti-interference ........................................................................................................13
2.2.7 Surge Protection.........................................................................................................13
2.3 Tools ........................................................................................................................................14
3 Installation ......................................................................................................................................15
3.1 Installation Procedure ...........................................................................................................15
3.2 Checking Before Installation.................................................................................................16
3.3 Precautions.............................................................................................................................16
3.4 Installing the AP .....................................................................................................................17
3.4.1 Mounting the AP on an 86 mm Junction Box...........................................................17
3.4.2 Removing the Device .................................................................................................19
3.5 Connecting Cables .................................................................................................................21
3.6 Bundling Cables......................................................................................................................21
3.6.1 Notes ...........................................................................................................................21
3.6.2 Bundling Steps............................................................................................................21
3.7 Verifying Installation..............................................................................................................21
3.7.1 Cable Connections......................................................................................................21
3.7.2 Power Supply..............................................................................................................22

iii
4 System Commissioning..................................................................................................................23
4.1 Setting Up the Configuration Environment .........................................................................23
4.2 Powering on the Device.........................................................................................................23
4.2.1 Checklist Before Power-on ........................................................................................23
4.2.2 Checklist After Power-on ...........................................................................................23
5 Monitoring and Maintenance........................................................................................................24
5.1 Monitoring ..............................................................................................................................24
5.1.1 LED...............................................................................................................................24
5.1.2 CLI Commands ...........................................................................................................24
5.2 Remote Maintenance.............................................................................................................24
5.3 Hardware Maintenance .........................................................................................................24
6 Troubleshooting .............................................................................................................................25
6.1 Troubleshooting Flowchart ...................................................................................................25
6.2 Common Faults ......................................................................................................................25
6.2.1 Ethernet Port Is Not Working After the Ethernet Cable Is Plugged In..................25
6.2.2 LED Is Off for a Long Time.........................................................................................25
6.2.3 LED Is Solid Red..........................................................................................................26
6.2.4 LED Is Solid Green ......................................................................................................26
6.2.5 The LED Keeps Fast Blinking Green (in Fit Mode)....................................................26
6.2.6 LED Is Slow Blinking Red............................................................................................26
6.2.7 No Wireless Signal Is Found......................................................................................26

iv
7 Appendix .........................................................................................................................................27
7.1 Connectors and Media...........................................................................................................27
7.2 Cabling Recommendations ...................................................................................................29

Hardware Installation and Reference Guide Product Overview
1
1 Product Overview
1.1 About the RG-SAP150-SP-W Access Point
The RG-SAP150-SP-W is a dual-radio 802.11ac wireless access point (AP) launched by
Ruijie. The AP delivers a combined data rate of 733 Mbps, with up to 300 Mbps in the 2.4
GHz band and 433 Mbps in the 5 GHz band. It can be applied in indoor scenarios,
including higher education, government, general education, finance, and business.
1.2 Product Appearance
The RG-SAP150-SP-W provides two 10/100Base-T Ethernet ports with auto-negotiation,
and one micro USB console port. The AP can be powered by PoE. It is shown as below.
Figure 1-1Front View

Hardware Installation and Reference Guide Product Overview
2
Figure 1-2Side View
Table 1-1 Side View
No.
Item
Description
1
LAN port
Service port for data transmission
2
Console port
Micro USB port, used to connect to a USB cable to manage
the AP
3
Reset button
Used to restart the device or restore the device to factory
settings
4
LED
Used to indicate the working status of the system
2
1
3 4

Hardware Installation and Reference Guide Product Overview
3
Figure 1-3Side View
Table 1-2 Button and Ports
No.
Item
Description
1
WAN/PoE port
Uplink service port for data transmission, supporting IEEE
802.3af-compliant PoE
Note
The nameplate is at the bottom of the access point.
1

Hardware Installation and Reference Guide Product Overview
4
1.3 Package Contents
Table 1-3 Package Contents
No.
Item
Quantity
1
Main unit
1
2
Phillips pan head screws (M4 x 25 mm)
2
3
Warranty Card and Hazardous Substance Table
1
1.4 Technical Specifications
1.4.1 Dimensions and Weight
Table 1-4 Dimensions and Weight
Dimensions and
Weight
RG-SAP150-SP-W
Dimensions (W x D x
H)
86 mm x 86 mm x 40 mm (3.39 in. x 3.39 in. x 1.57 in.)
Weight
Main unit: 0.1 kg (0.66 lbs)
Mounting
In-wall mount (86 mm junction box)
Color
White
1.4.2 Radio Specifications
Table 1-5 Radio Specifications
Radio Specifications
RG-SAP150-SP-W
Radio design
Dual-radio, two wireless RF connectors, and up to three

Hardware Installation and Reference Guide Product Overview
5
Radio Specifications
RG-SAP150-SP-W
spatial streams
Radio 1: 2.4 GHz, two spatial streams: 2 × 2 MIMO
Radio 2: 5 GHz, one spatial stream: 1 × 1 MIMO
Operating frequency
bands
Radio 1: 802.11b/g/n, 2.400 GHz to 2.4835 GHz
Radio 2: 802.11a/n/ac, 5.150 GHz to 5.350 GHz, 5.470 GHz to
5.725 GHz, 5.725 GHz to 5.850 GHz
Note: The operating frequency bands vary in different
countries.
Data rate
Radio 1: 2.4 GHz, 300 Mbps
Radio2: 5 GHz, 433 Mbps
Combined:
2.4 GHz + 5 GHz, 733 Mbps
Antenna type
Built-in omnidirectional antennas
Antenna gain
2.4 GHz: 3 dBi
5 GHz: 5 dBi
Max. transmit power
20 dBm
Note: The actual transmit power is limited by local regulatory
requirements.
Power increment
1 dBm
Modulation types
802.11b: BPSK, QPSK and CCK
802.11a/g/n: BPSK, QPSK, 16-QAM, and 64-QAM
802.11ac: BPSK, QPSK, 16-QAM, 64-QAM, and 256-QAM
Receiver sensitivity
802.11b: –91 dBm (1 Mbps), –90 dBm (5 Mbps), and –87 dBm
(11 Mbps)
802.11a/g: –89 dBm (6 Mbps), –82 dBm (24 Mbps), –78 dBm
(36 Mbps), and –72 dBm (54 Mbps)

Hardware Installation and Reference Guide Product Overview
6
Radio Specifications
RG-SAP150-SP-W
802.11n: –85 dBm (MCS 0), –67 dBm (MCS 7), –85 dBm (MCS 8),
and –67 dBm (MCS 15)
802.11ac HT20: –85 dBm (MCS0), –57 dBm (MCS9)
802.11ac HT40: –82 dBm (MCS0), –57 dBm (MCS9)
802.11ac HT80: –79 dBm (MCS0), –53 dBm (MCS9)
1.4.3 Port Specifications
Table 1-6 Port Specifications
Port Specifications
RG-SAP150-SP-W
Fixed service port
Uplink: 1 x 10/100Base-T Ethernet port with auto-negotiation,
supporting IEEE 802.3af-compliant PoE
Downlink: 1 x 10/100Base-T Ethernet port with auto-negotiation
Fixed management
port
1 x micro USB console port
Status LED
1 x system status LED
Button
1 x reset button
1.4.4 Power Supply and Consumption
Port Specifications
RG-SAP150-SP-W
Power input
IEEE 802.3af-compliant PoE power supply
Max. power
consumption
8 W

Hardware Installation and Reference Guide Product Overview
7
Caution
Before using PoE power supply, make sure that the PSE device is 802.3af-compliant.
The access point features a fanless design, and can be mounted on an 86mm
junction box.
1.4.5 Environment and Reliability
Table 1-7 Environment and Reliability
Environment and
Reliability
RG-SAP150-SP-W
Temperature
Operating temperature: –10°C to +40°C (14°F to 104°F)
Storage temperature: –40°C to +70°C (–40°F to +158°F)
Note: At a height between 3000 m (9842.52 ft.) and 5000 m
(16404.2 ft.), every time the altitude increases by 166 m (546 ft.),
the maximum temperature decreases by 1°C (1.8°F).
Humidity
Operating humidity: 5% RH to 95% RH (non-condensing)
Storage humidity: 5% RH to 95% RH (non-condensing)
Regulatory
compliance
EN 55032, EN 55035, EN 61000-3-3, EN IEC 61000-3-2, IEC 62368-
1, EN 62368-1, EN 301 489-1, EN 301 489-3, EN 301 489-17, EN
300 328, EN 301 893, EN 300 440, FCC Part 15, and EN IEC 62311
1.5 LED and Button
Note
The LED description applies to both Fit and Fat modes unless otherwise specified.

Hardware Installation and Reference Guide Product Overview
8
Table 1-8 System LED
LED Status
Blinking
Frequency
Description
Off
N/A
The AP is not powered on.
The AP is powered on, but the LED is manually turned off.
Solid green
N/A
The software system of the AP is being initialized.
Solid red
N/A
The software system operates normally but the uplink port
of the AP is in linkdown state.
Slow
blinking
red
On for 3
seconds
Off for 1
second
In Fit mode, the CAPWAP tunnel between the AP and AC
timed out.
Fast
blinking
green
On for 0.2
seconds
Off for 0.2
seconds
In Fit or Cloud mode, the software system of the AP is
being upgraded.
Slow
blinking
green
On for 3
seconds
Off for 1
second
The software system runs properly, the AP works properly,
and the CAPWAP tunnel status is normal.
Fast
blinking
red
On for 0.2
seconds
Off for 0.2
seconds
In Fit mode, the AP is being located.

Hardware Installation and Reference Guide Preparing for Installation
9
Table 1-9 Reset Button
Button
Action
Result
Reset
button
Press the
button for
shorter than
2s.
Restart the AP.
Press the
button for
longer than
5s.
Restore the AP to factory settings.
2 Preparing for Installation
2.1 Safety Precautions
Note
To avoid personal injury and device damage, carefully read the safety precautions
before you install the device.
The following safety precautions do not cover all possible dangers.
2.1.1 General Safety Precautions
Do not expose the AP to high temperature, dusts, or harmful gases. Do not install the
AP in an inflammable or explosive environment. Keep the AP away from Electro-
Magnetic Interference (EMI) sources such as large radar stations, radio stations, and
substations. Do not subject the AP to unstable voltage, vibration, and noises.
The installation site should be free from water flooding, seepage, dripping, or
condensation. The installation site should be selected according to communication
network planning and technical requirements for communication equipment, and
considerations such as climate, hydrology, geology, earthquake, electrical power, and
transportation.

Hardware Installation and Reference Guide Preparing for Installation
10
The installation site should be dry. You are not advised to install the AP in a place near
the sea. Keep the device at least 500 meters (1640.42 ft.) away from the ocean. You are
advised not to orient the device toward the direction of sea breeze.
Do not place the device in walking areas.
During installation and maintenance, do not wear loose clothes, ornaments, or any
other things that may be hooked by the chassis.
Keep tools and components away from the walking area.
2.1.2 Handling Safety
Avoid handling the device frequently.
Cut off all power supplies and unplug all power cords and cables before handling the
AP.
2.1.3 Electric Safety
Warning
Improper or incorrect electric operations may cause a fire, electric shock, and other
accidents, and lead to severe and fatal personal injury and device damage.
Direct or indirect touch through a wet object on high-voltage and mains supply can
bring a fatal danger.
Observe local regulations and specifications during electric operations. Only personnel
with relevant qualifications can perform such operations.
Check potential risks in the work area, such as wet floor.
Find out the position of the indoor emergency power switch before installation. Cut off
the power switch in the case of accidents.
Make sure that the device is powered off when you cut off the power supply.
Do not place the AP in a wet position, and keep it away from liquid.
Keep the AP far away from grounding or lightning protection devices for power
equipment.
Keep the AP away from radio stations, radar stations, high-frequency high-current
devices, microwave ovens, and other high-power wireless devices.

Hardware Installation and Reference Guide Preparing for Installation
11
2.1.4 Storage Security
To ensure proper working of the device, store the device in an environment based on the
storage temperature or humidity requirements in specifications.
Caution
If the device has been powered off for more than 18 months, power on the device and
run it for consecutive 24 hours to activate the device.
2.2 Installation Environment Requirements
The AP must be installed and used indoors. For normal operation and prolonged service
life of the AP, the installation site must meet the following requirements.
2.2.1 Bearing
Evaluate the weight of the device and its accessories, and ensure that the installation site
can bear the weight.
2.2.2 Ventilation
Reserve sufficient space in front of air vents to ensure normal heat dissipation. After
various cables are connected, bundle the cables or place them in the cable management
arm to avoid blocking air inlets.
2.2.3 Clearance
Maintain sufficient clearance around the device for heat dissipation and device
maintenance.
2.2.4 Temperature and Humidity
To ensure the normal operation and prolonged service life of the device, maintain an
appropriate temperature and humidity in the machine room.
The machine room with too high or too low temperature and humidity for a long period
may damage the AP.
In an environment with high relative humidity, the insulating material may have poor
insulation or even leak electricity.
In an environment with low relative humidity, the insulating strip may dry and shrink,

Hardware Installation and Reference Guide Preparing for Installation
12
resulting in screw loosening.
In a dry environment, internal circuits are prone to static electricity.
A high temperature can accelerate the aging process of insulation materials, greatly
reducing the reliability of the AP and severely affecting its service life.
Note
The ambient temperature and humidity of the device are measured at the point that is
1.5 m (4.92 ft.) above the floor and 0.4 m (1.31 ft.) before the device when there is no
protective plate in front or at the back of the device.
2.2.5 Cleanliness
Dust poses a major threat to the switch. The indoor dust takes on a positive or negative
static electric charge when falling on the switch, causing poor contact of the metallic
joint. Such electrostatic adhesion may occur more easily when the relative humidity is
low, not only affecting the service life of the switch, but also causing communication
faults. The following table describes the requirements for the dust content and
granularity in the machine room.
Table 2-1 Requirements for Dust
Dust
Unit
Maximum Quantity
Dust particles (diameter ≤0.5
μm)
Particles/m3
≤1.4 × 10^7
Dust particles (0.5 μm < diameter
≤ 1 μm)
Particles/m3
≤7 × 10^5
Dust particles (1 μm < diameter ≤
3 μm)
Particles/m3
≤2.4 × 10^5
Dust particles (3 μm < diameter ≤
5 μm)
Particles/m3
≤1.3 × 10^5
Apart from dust, the salt, acid, and sulfide in the air in the machine room must meet
strict requirements. These harmful substances will accelerate metal corrosion and
component aging. Therefore, the machine room should be properly protected against
