RYOBI
18 VOLT CORDLESS NAILER/STAPLER
MODEL NO. P300
REPAIR SHEET

RYOBI 18 VOLT CORDLESS NAILER/STAPLER – MODEL NUMBER P300
2
1
2
3
4
5
6
7
8
9
10
11
12 13
14
15
16
17
18
19
20
21
22
23 24
25
26
27
28
38
29
30
31
32
33
34
35
36
37
39
1
37
40
41
43
42 44
3
8
2
7

RYOBI 18 VOLT CORDLESS NAILER/STAPLER – MODEL NUMBER P300
3
1 010300001001 HOUSING ASSEMBLY .................................... 1
2 102334001002 SCREW (M4 X 10 mm) .................................... 4
3 102334001003 SCREW (M4 X 12 mm) .................................... 3
4 102334001004 SCREW (M4 X 24 mm) .................................... 3
5 102334001005 SCREW (M4 X 17 mm) .................................... 4
6 010300001013 METAL PLATE ................................................. 1
7 102334001007 RAIL ................................................................. 2
8 102334001008 SCREW (M5 X 12 mm) .................................... 2
9 010300001002 FORCE ADJUSTMENT KNOB
....................... 1
10 102334001010 FIXTURE (LEFT) ............................................ 1
11 102334001011 FIXTURE (RIGHT) .......................................... 1
12 102334001012 SWITCH FIXTURE .......................................... 1
13 102334001013 DAMPER ......................................................... 1
14 102334001014 SWITCH COVER ............................................. 1
15 010300001003 SWITCH TRIGGER ......................................... 1
16 102334001017 PUNCHER ....................................................... 1
17 102334001018 SPRING FOR SWITCH TRIGGER ................ 1
18 102334001019 SPRING ........................................................... 1
19 102334001021 HAMMER BLOCK ............................................ 1
20 102334001022 SAFETY ROD LINKAGE ................................. 1
21 102334001023 SPRING .......................................................... 1
22 010300001005 CONTACT PLATE HOLDER ASSEMBLY ........ 1
23 102334001025 GEAR BOX AND OUTPUT GEAR ASSEMBLY ... 1
24 102334001026 MOTOR MOUNT ............................................. 1
25 102334001027 SCREW (M4 X 12 mm) .................................... 2
26 102334001028 SPRING PIN .................................................... 2
27 102334001029 MOTOR ASSEMBLY WITH PINION ................ 1
28 010300001012 MAGAZINE ASSEMBLY ................................. 1
29 102334001035 CARTRIDGE ASSEMBLY ................................ 1
30 102334001036 PCB ASSEMBLY ............................................. 1
31 102334001037 TRIGGER SWITCH ASSEMBLY ..................... 1
32 102334001038 GEAR SENSING SWITCH ASSEMBLY .......... 1
33 102334001039 SAFETY SWITCH ASSEMBLY ........................ 1
34 102334001040 SPACER .......................................................... 1
35 102334001041 INTERNAL WIRE ............................................. 1
36 102334001042 FUSE ............................................................... 1
37 102334001043 SHRINK TUBE ................................................. 3
38 102334001044 SHRINK TUBE ................................................. 1
39 200292003 PLUG-IN LANYARD ......................................... 1
40 940114111 LOGO LABEL .................................................. 1
41 940301029 RATING LABEL ............................................... 1
42 940230095 WARNING LABEL - FRENCH ......................... 1
43 940230096 WARNING LABEL - SPANISH ......................... 1
44 000900139 NAIL & STAPLE ACCESSORY ASSEMBLY .... 1
983000561 OPERATOR’S MANUAL (960223414)
983000561R REPAIR SHEET (Rev: 00)
09-27-04
KEY PART
NO. NUMBER DESCRIPTION QTY
PARTS LIST
* Standard Hardware Item – May Be Purchased Locally
The model number will be found on a plate attached to the motor housing. Always mention the model number in all correspondence regarding your
CORDLESS NAILER/STAPLER or when ordering repair parts.
KEY PART
NO. NUMBER DESCRIPTION QTY

RYOBI 18 VOLT CORDLESS NAILER/STAPLER – MODEL NUMBER P300
4
RED
LEAD
WIRING DIAGRAM
RED
LEAD
RED
LEAD RED
LEAD
RED
LEAD
RED
LEAD
RED
LEAD
BLACK
LEAD
PCB
ASSEMBLY
BLACK
LEAD
BLUE
LEAD
SWITCH
MOTOR
SWITCH
