DUETTM POWER PAINT SYSTEM – MODEL NUMBER FPR300
The model number will be found on a label attached to the motor housing. Always mention the model number in all correspondence regarding your
DUETTM POWER PAINT SYSTEM or when ordering parts.
PARTS LIST
KEY PART
NO. NUMBER DESCRIPTION QTY
KEY PART
NO. NUMBER DESCRIPTION QTY
1 519416001 Handle ......................................................... 1
2 660259008 Screw (M4.5 x 35 mm).................................. 5
3 303298002 By-Pass Valve Assembly .............................. 1
4 560180002 Tube (460 mm) .............................................. 1
5 560181001 Tube (470 mm) .............................................. 1
6 519424001 Paint System Top.......................................... 1
7 940976573 Data Label ................................................... 1
8 940114158 Logo Label.................................................... 1
9 633188001 Quick Spring Clamp...................................... 2
10 633095001 Quick Spring Clamp.................................... 14
11 519474001 Connector (Import & Export)......................... 1
12 560177001 O-Ring (OD 19 x ID 15.6 mm)....................... 2
13 519423001 Rotation Support .......................................... 1
14 660208048 Screw (M4 x 16 mm)................................... 10
15 519420001 Paint Container Lid ....................................... 1
16 519419001 Container ...................................................... 1
17 940221119 Quick Start Label ......................................... 1
18 303454001 Motor Pump Assembly ................................. 1
19 520024001 Pump Tube.................................................... 1
20 519494001 Pump Roller ................................................. 2
21 520366001 Pump Shaft................................................... 1
22 519496001 Pump Body Cover ........................................ 1
23 519492001 Pump Housing Cover ................................... 1
24 660313004 Screw (8-16).................................................. 4
25 940221121 Finish Sprayer Label ..................................... 1
26 690331001 Terminal Block .............................................. 2
27 660206042 Screw (M3.5 x 16 mm).................................. 3
28 940221120 Power Direction Label................................... 1
29 550338004 Switch Cover ................................................ 1
30 760223002 Switch (On/Off) ............................................. 1
31 760223003 Rocker Switch............................................... 1
32 519421001 Main Housing................................................ 1
33 940221115 Graphic Label A ............................................ 1
34 940221116 Graphic Label B............................................ 1
35 290061213 Receptacle & Wire Assembly........................ 2
36 290061214 Receptacle & Wire Assembly ...................... 2
37 290086091 Receptacle & Power Cord Assembly............ 1
38 940221118 Warning Label............................................... 1
39 590501002 Cord Clamp .................................................. 1
40 519425001 Vent Window................................................. 1
41 902340001 Fiber Washer................................................. 1
42 519646001 Vent Window Filter.........................................1
43 560173001 Gasket (OD 109 x ID 102 x 8 mm) ................ 1
44 303455001 Motor Housing Cover Assembly................... 1
45 290061211 Receptacle & Wire Assembly........................ 1
46 290061212 Receptacle & Wire Assembly........................ 1
47 6799802 Spring (OD 5.2 x ID 4.0, Dia 0.6 x 21 mm).... 1
48 7622701 Switch .......................................................... 1
49 519472001 Activator........................................................ 1
50 520023001 Air Tube (250 mm)......................................... 1
51 660208038 Screw (M4 x 10 mm)..................................... 4
