Ryobi OWS1880 User manual

FRONT PAGE
OWS1880

2
Original Instructions
IMPORTANT!
It is essential that you read the instructions in this manual
before assembling, operating, and maintaining the
product.
Subject to technical modication.
Safety, performance, and dependability have been given top
priority in the design of your cordless weed sprayer.
INTENDED USE
The cordless weed sprayer is intended for outdoor use in a
well-ventilated area.
The product is designed for spraying consumer-grade home
and garden chemicals, such as insecticides, fungicides,
weed killers, and fertilizers. The product may also be used
to water plants.
The product is not to be used by children or by persons who
are not wearing adequate personal protective equipment
and clothing.
Do not use the product for any other purpose.
GENERAL PRODUCT SAFETY WARNINGS
WARNING! Read all safety warnings, instructions,
illustrations and specifications provided with this
power tool. Failure to follow all instructions listed below
may result in electric shock, re, and/or serious injury.
Save all warnings and instruction for future reference.
The term “power tool” in the warnings refers to your mains-
operated (corded) product or battery-operated (cordless)
product.
WORK AREA SAFETY
■Keep work area clean and well lit. Cluttered or dark
areas invite accidents.
■Do not operate power tools in explosive
atmospheres, such as in the presence of flammable
liquids, gases or dust. Power tools create sparks
which may ignite the dust or fumes.
■Keep children and bystanders away while operating
a power tool. Distractions can cause you to lose control.
ELECTRICAL SAFETY
■Power tool plugs must match the outlet. Never
modify the plug in any way. Do not use any adapter
plugs with earthed (grounded) power tools.
Unmodified plugs and matching outlets will reduce risk
of electric shock.
■Avoid body contact with earthed or grounded
surfaces, such as pipes, radiators, ranges and
refrigerators. There is an increased risk of electric
shock if your body is earthed or grounded.
■Do not expose power tools to rain or wet conditions.
Water entering a power tool will increase the risk of
electric shock.
■Do not abuse the cord. Never use the cord for
carrying, pulling or unplugging the power tool. Keep
cord away from heat, oil, sharp edges or moving
parts. Damaged or entangled cords increase the risk of
electric shock.
■When operating a power tool outdoors, use an
extension cord suitable for outdoor use. Use of a
cord suitable for outdoor use reduces the risk of electric
shock.
■If operating a power tool in a damp location is
unavoidable, use a residual current device (RCD)
protected supply. Use of an RCD reduces the risk of
electric shock.
PERSONAL SAFETY
■Stay alert, watch what you are doing and use
common sense when operating a power tool. Do not
use a power tool while you are tired or under the
influence of drugs, alcohol or medication. A moment
of inattention while operating power tools may result in
serious personal injury.
■Use personal protective equipment. Always wear
eye protection. Protective equipment such as a dust
mask, non-skid safety shoes, hard hat or hearing
protection used for appropriate conditions will reduce
personal injuries.
■Prevent unintentional starting. Ensure the switch
is in the off-position before connecting to power
source and/or battery pack, picking up or carrying
the tool. Carrying power tools with your finger on the
switch or energising power tools that have the switch on
invites accidents.
■Remove any adjusting key or wrench before turning
the power tool on. A wrench or a key left attached to
a rotating part of the power tool may result in personal
injury.
■Do not overreach. Keep proper footing and balance
at all times. This enables better control of the power tool
in unexpected situations.
■Dress properly. Do not wear loose clothing or
jewellery. Keep your hair and clothing away from
moving parts. Loose clothes, jewellery or long hair can
be caught in moving parts.
■If devices are provided for the connection of dust
extraction and collection facilities, ensure these are
connected and properly used. Use of dust collection
can reduce dust-related hazards.
■Do not let familiarity gained from frequent use of
tools allow you to become complacent and ignore
tool safety principles. A careless action can cause
severe injury within a fraction of a second.
POWER TOOL USE AND CARE
■Do not force the power tool. Use the correct power
tool for your application. The correct power tool will
do the job better and safer at the rate for which it was
designed.
■Do not use the power tool if the switch does not turn
it on and off. Any power tool that cannot be controlled
with switch is dangerous and must be repaired.
■Disconnect the plug from the power source and/
or remove the battery pack, if detachable, from
the power tool before making any adjustments,
changing accessories, or storing power tools. Such
preventive safety measures reduce the risk of starting
the power tool accidentally.
■Store idle power tools out of the reach of children
and do not allow persons unfamiliar with the power
tool or these instructions to operate the power tool.

3
Original Instructions
Power tools are dangerous in the hands of untrained
users.
■Maintain power tools and accessories. Check for
misalignment or binding of moving parts, breakage
of parts and any other condition that may affect the
power tool’s operation. If damaged, have the power
tool repaired before use. Many accidents are caused
by poorly maintained power tools.
■Keep cutting tools sharp and clean. Properly
maintained cutting tools with sharp cutting edges are
less likely to bind and are easier to control.
■Use the power tool, accessories and tool bits etc.
in accordance with these instructions, taking into
account the working conditions and the work to
be performed. Use of the power tool for operations
different from those intended could result in a hazardous
situation.
■Keep handles and grasping surfaces dry, clean
and free from oil and grease. Slippery handles and
grasping surfaces do not allow for safe handling and
control of the tool in unexpected situations.
BATTERY TOOL USE AND CARE
■Recharge only with the charger specified by the
manufacturer. A charger that is suitable for one type
of battery pack may create a risk of fire when used with
another battery pack.
■Use power tools only with specifically designated
battery packs. Use of any other battery packs may
create a risk of injury and fire.
■When battery pack is not in use, keep it away from
other metal objects, like paper clips, coins, keys,
nails, screws or other small metal objects, that can
make a connection from one terminal to another.
Shorting the battery terminals together may cause burns
or a fire.
■Under abusive conditions, liquid may be ejected from
the battery; avoid contact. If contact accidentally
occurs, flush with water. If liquid contacts eyes,
additionally seek medical help. Liquid ejected from
the battery may cause irritation or burns.
■Do not use a battery pack or tool that is damaged or
modified. Damaged or modified batteries may exhibit
unpredictable behaviour resulting in fire, explosion or
risk of injury.
■Do not expose a battery pack or tool to fire or
excessive temperature. Exposure to fire or temperature
above 130°C may cause explosion.
■Follow all charging instructions and do not charge
the battery pack or tool outside the temperature
range specified in the instructions. Charging
improperly or at temperatures outside the specified
range may damage the battery and increase the risk of
fire.
SERVICE
■Have your power tool serviced by a qualified repair
person using only identical replacement parts. This
will ensure that the safety of the power tool is maintained.
■Never service damaged battery packs. Service
of battery packs should only be performed by the
manufacturer or authorized service providers.
CORDLESS WEED SPRAYER SAFETY WARNINGS
■Always check for and repair leaks before using the
product.
■Do not spray in the direction of people or animals.
Always spray downwind.
■To reduce the risk of fire or explosion, do not use the
product with flammable liquids, such as gasoline or other
chemicals with a flashpoint below 55°C.
■Be aware of any hazard presented by the chemical
solutions. Always follow the chemical manufacturer’s
instructions on usage, handling, and storage.
■Do not use the product with any material where the
hazard is not known.
■To help reduce the risk of injury, wear personal protective
equipment, such as face mask, gloves, safety footwear,
and upper-body protection, when doing the following:
●operating the product
●handling chemicals
●performing maintenance
■Do not use flammable solvents or abrasive cleaning
agents to clean the product.
■Operate the product only in temperatures between 0°C
and 40°C.
■Store the product in a location where the ambient
temperature is between 0°C and 40°C.
■Injuries may be caused, or aggravated, by prolonged use
of the product. When using any product for prolonged
periods, ensure to take regular breaks.
MIXING THE SOLUTION
■Mix the chemicals strictly in accordance with the
manufacturer’s instructions. Incorrect mixtures may
produce toxic fumes or explosive solutions.
■Never use undiluted liquid plant control chemicals.
■Prepare the solution and fill the container outdoors or in
well-ventilated areas only.
■Prepare only sufficient solution for the job in hand so that
nothing is left over.
■Do not mix different chemicals unless such mixture is
approved by the manufacturer.
FILLING THE CONTAINER
■Before filling the container with solution, carry out a test
run with fresh water, and check all parts of the product
for leaks.
■Stand the product on a level surface, and do not fill the
container above the maximum mark.
■When filling from the tap, do not immerse the end of
the hose in the chemical solution. Sudden low pressure
in the system may cause the chemical solution to be
sucked back into the water supply.
■Make sure that the tank cap is properly closed after
filling.
■Hang a tag on the product to note the chemical solution
being used.
APPLICATION
■Work only in the open or in well-ventilated locations,
such as in open greenhouses.

4
Original Instructions
■Never blow through nozzles or other components by
mouth.
■Avoid contact with chemicals. Immediately change
clothing that are contaminated with plant control
chemicals.
■Do not aim the nozzle towards persons, animals, and
electrical equipment.
■Do not operate the product in windy conditions. Always
aim downwind.
■Avoid using the product in freezing weather because the
solution may freeze.
■Too high or too low pressure or unfavorable weather
conditions can result in the wrong solution concentration.
Overdosing may damage plants and the environment.
Underdosing may result in unsuccessful plant treatment.
■To reduce the risk of damage to the environment and
plants, do not operate the product:
●if pressure is too high or too low
●in windy conditions
●in direct sunlight
■To reduce the risk of accidents and damage to the
product, never operate with:
●flammable liquids
●viscous or sticky liquids
●caustic or corrosive chemicals
●liquids hotter than 50°C
■Clean the product after each use.
The product may be subject to national requirements for
regular inspection by designated bodies, as provided for in
Directive 2009/127/EC of the European Parliament and of
the Council of 21 October 2009 establishing a framework
for Community action to achieve the sustainable use of
pesticides.
ADDITIONAL BATTERY SAFETY WARNINGS
■To reduce the risk of fire, personal injury, and product
damage due to a short circuit, never immerse the tool,
battery pack, or charger in fluid or allow fluid to flow
inside them. Corrosive or conductive fluids, such as
seawater, certain industrial chemicals, and bleach or
bleach-containing products, etc., can cause a short
circuit.
■Charge the battery pack in a location where the ambient
temperature is between 10°C and 38°C.
■Store the battery pack in a location where the ambient
temperature is between 0°C and 20°C.
MAINTENANCE
■Use only original manufacturer’s replacement parts,
accessories, and attachments. Failure to do so can cause
possible injury, can contribute to poor performance, and
may void your warranty.
■Servicing requires extreme care and knowledge
and should be performed only by a qualified service
technician. Have the product serviced by an authorised
service centre only.
■To avoid serious personal injury, always remove
the battery pack from the product when cleaning or
performing any maintenance.
■After each use, check all parts of the product for leaks.
Return the product to an authorised service centre for
repair if necessary.
■Drain and empty the spray tank before cleaning.
■Drain the spray materials through the fill area.
NOTE: Drain all of the spray materials from the spray
tank into a container approved for chemicals. Do not store
chemicals in the spray tank.
■Use clean water to clean and rinse the spray tank. A
small amount of mild household detergent may be
added.
■Wipe the product with a clean, dry cloth.
■It may be necessary to rinse the spray tank more than
once.
DISPOSAL
■Never dispose of residual chemicals or contaminated
rinsing solutions in waterways, drains, sewers, street
gutters, or manholes.
■Dispose of residual chemicals, contaminated rinse
water, and used containers in accordance with local
waste disposal regulations.
TRANSPORTATION AND STORAGE
■Turn off the product, remove the battery pack, and allow
both to cool down before storing or transporting.
■Drain all spray materials from the spray tank before
storing and transporting.
■After each use, check all parts of the product for leaks.
Return the product to an authorised service centre for
repair.
■Ensure that all parts of the product are clean and dry.
■Remove all foreign materials from the product.
■The spray wand can be stored in the cradle.
■For transportation, secure the product against movement
or falling to prevent injury to persons or damage to the
product.
■Store the product in a cool, dry, and well-ventilated place
that is inaccessible to children. Keep the product away
from corrosive agents, such as garden chemicals and
de-icing salts. Do not store the product outdoors.
TRANSPORTING LITHIUM BATTERIES
Transport the battery in accordance with local and national
provisions and regulations.
Follow all special requirements on packaging and labelling
when transporting batteries by a third party. Ensure that
no batteries can come in contact with other batteries
or conductive materials while in transport by protecting
exposed connectors with insulating, non-conductive caps or
tape. Do not transport batteries that are cracked or leaking.
Check with the forwarding company for further advice.
KNOW YOUR PRODUCT
See page 7.
1. Battery port
2. On/Off button
3. Spray tank cover / measuring cup
4. Motor housing
5. Latch (x2)

5
Original Instructions
6. Hose retainer
7. Tank
8. Nozzle
9. Spray wand
10. Trigger with lock-on
11. Spray wand handle
12. Hose
13. Operator’s manual
14. Battery pack
15. Charger
16. Wire
17. Chemical solution
SYMBOLS ON THE PRODUCT
Safety alert
Read and understand all instructions
before operating the product. Follow all
warnings and safety instructions.
Wear eye protection.
Wear appropriate respiratory mask.
Wear non-slip, liquid-resistant gloves.
Wear non-slip safety footwear when
using the product.
Do not expose the product to rain or
damp conditions.
British Conformity Mark
European Conformity Mark
EurAsian Conformity Mark
Ukraine Conformity Mark
Do not dispose of waste batteries,
waste electrical and electronic
equipment as unsorted municipal
waste. Waste batteries and waste
electrical and electronic equipment
must be collected separately. Waste
batteries, waste accumulators, and
light sources have to be removed
from the equipment. Check with your
local authority or retailer for recycling
advice and collection point. According
to local regulations, retailers may
have an obligation to take back waste
batteries and waste electrical and
electronic equipment free of charge.
Your contribution to the reuse and
recycling of waste batteries and waste
electrical and electronic equipment
helps to reduce the demand of raw
materials. Waste batteries, in particular
containing lithium, and waste electrical
and electronic equipment contain
valuable and recyclable materials,
which can adversely impact the
environment and the human health if
not disposed of in an environmentally
compatible manner. Delete personal
data from waste equipment, if any.
SYMBOLS IN THIS MANUAL
Stop the product.
Lock
Unlock
Parts or accessories sold separately
Note
Warning

7
OWS1880
3
4
5
7
6
8
9
10
11
12
13
14
15
16
17
2
1

8
1
2
7
1
2
1
2
5
2
6
1
11 1210

9
1
2
8 9
4
5
10
1
2
3

10
p.11 p.13
p.16 p.17

11
1
2
3

12
2
1
1
2
4a
4b

13
1
2
1
1
2
3
4
2
3
5

14
6
1
2
3
4
7
8
3
2
1
4
H2O
H2O H2O
12
3
5

15
9
1
2
10
11

16
1
2
1
1
2
2
2
3
1
3
1
2
4

17
1
2
1
2
1
2
3
4
20230327v3

PRODUCT SPECIFICATIONS
Cordless weed sprayer
Model OWS1880
Pump type: Diaphragm pump
Tank capacity 3.5 L
Spray valve: Integral grip lever
Dimensions (w x l x h) 18 x 24 x 30 cm
Pressure 310 kPa
Flow rate 500 ml/min
Net weight 1.45 kg
Noise emission level (in accordance with EN 62841-1 and EN 50580)
A-weighted sound pressure
level at the operator’s position
LpA = 72.0 dB(A)
Uncertainty of measurement K= 3.0 dB
A-weighted sound power level LWA = 83.0 dB(A)
Uncertainty of measurement K= 3.0 dB
Vibration level (in accordance with EN 62841-1 and EN 50580)
Vibration total value ah = 0.1 m/s2
Uncertainty of measurement K = 1.5 m/s2
BATTERY AND CHARGER
Model OWS1880
Battery pack -
Charger -
Compatible battery packs RB18..
Compatible chargers BCL1418..H, BCS618, RC18..
NOTE: Visit your local special orders desk or contact RYOBI
customer service for replacement parts.
WARNING! The declared vibration total values and the
declared noise emission values given in this instruction
manual have been measured in accordance with a
standardised test and may be used to compare one tool with
another. They may be used for a preliminary assessment
of exposure.
The declared vibration and noise emission values represent
the main applications of the tool. However, if the tool is used
for di󰀨erent applications, used with di󰀨erent accessories,
or poorly maintained, the vibration and noise emission
may di󰀨er. These conditions may signicantly increase the
exposure levels over the total working period. An estimation
of the level of exposure to vibration and noise should take
into account the times when the tool is turned o󰀨 or when
it is running idle. These conditions may signicantly reduce
the exposure level over the total working period.
Identify additional safety measures to protect the operator
from the e󰀨ects of vibration and noise, such as maintaining
the tool and the accessories, keeping the hands warm (in
case of vibration), and organising work patterns.

RYOBI WARRANTY APPLICATION CONDITIONS
In addition to any statutory rights resulting from the purchase, this product is covered
by a warranty as stated below.
1. The warranty period is 24 months for consumers and commences on the date
when the product was purchased. This date has to be documented by an
invoice or other proof of purchase. The product is designed and dedicated to
consumer and private use only. So there is no warranty provided in case of
professional or commercial use. This warranty applies only on new products.
2. There is a possibility to extend for a part of the range of power tools (AC/DC)
the warranty period over the period described above using the registration on
the www.ryobitools.eu website. The eligibility of products for extended warranty
is clearly displayed in stores and / or on packaging and is contained within the
product documentation. The end user is required to register his/her newly-
acquired products online within 30 days from the date of purchase. The end user
may register for the extended warranty in his/her country of residence if listed
on the online registration form where this option is valid. Furthermore, end users
must give their consent to the storage of their personal data that is required to be
entered online. They must also accept the terms and conditions. The registration
confirmation receipt, which is sent out by e-mail, and the original invoice
showing the date of purchase will serve as proof of the extended warranty.
3. The warranty covers all defects of the product during the warranty period due to
faults in workmanship or material at the purchase date. The warranty is limited to
repair and/or replacement and does not include any other obligations including
but not limited to incidental or consequential damages. The warranty is not valid
if the product has been misused, used contrary to the instruction manual, or has
been incorrectly connected to a power supply. This warranty does not apply to:
– any damage to the product that is the result of improper or lack of maintenance
– any product that has been altered or modified
– any product where original identification (trade mark, serial number) markings
have been defaced, altered or removed
– any damage caused by non-observance of the instruction manual
– any product not displaying the CE approval mark on the rating plate
– any product that has been attempted to be repaired by a non-authorised
warranty service centre or without prior authorisation by Techtronic Industries
– any product connected to improper power supply (amps, voltage, frequency)
– any product used with inappropriate fuel mixture (fuel, oil, ratio of oil/ fuel
mixture)
– any damage caused by external influences (water, chemical, physical,
shocks) or foreign substances
– normal wear and tear spare parts
– inappropriate use, overloading of the tool
– use of non-approved accessories or parts
– Accessories provided with the tool or purchased separately including but not
limited to blades, saw chains, cutting lines, etc.
– Any periodic adjustments to or maintenance cleaning of carburettors
– Components (parts and accessories) subject to natural wear and tear,
including but not limited to bump knobs, drive belts, clutch, blades of hedge
trimmers or lawn mowers, harness, cable throttle, carbon brushes, power
cord, tines, felt washers, hitch pins, blower fans, blower and vacuum tubes,
vacuum bag and straps, guide bars, saw chains, hoses, connector fittings,
spray nozzles, wheels, spray wands, inner reels, outer spools, cutting lines,
spark plugs, air filters, gas filters, mulching blades, etc.
4. For servicing, the product must be sent or presented to a RYOBI
authorised service station listed for each country in the following list of
service station addresses. In some countries your local RYOBI dealer
undertakes to send the product to the RYOBI service organisation. When
sending a product to a RYOBI service station, the product should be
safely packed without any dangerous contents such as petrol, marked
with sender’s address and accompanied by a short description of the fault.
5. A repair / replacement under this warranty is free of charge. It does not
constitute an extension or a new start of the warranty period. Exchanged
parts or products become our property. In some countries delivery
charges or postage will have to be paid by the sender. Your statutory
rights arising from the purchase of the product remain unaffected.
6. This warranty is valid in the European Community, Switzerland, Iceland, Norway,
Liechtenstein, Turkey, Russia, and the United Kingdom. Outside these areas,
please contact your authorised RYOBI dealer to determine if another warranty
applies.
AUTHORISED SERVICE CENTRE
Any request or issue with the product can be addressed to your local authorised
service centres (visit www.ryobitools.eu) or directly to: Techtronic Industries GmbH,
Max Eyth Straße 10, 71364 Winnenden, Germany. Please state the serial number
and product type printed on the label.
GB-DECLARATION OF CONFORMITY
Manufacturer: Techtronic Industries GmbH
Max-Eyth-Straße 10, 71364 Winnenden, Germany
We declare as the manufacturer under our sole responsibility that the product
mentioned below
Cordless weed sprayer
Brand: RYOBI
Model number: OWS1880
Serial number range: 44484902000001 - 44484902999999
fulfills all the relevant provisions of the following Regulations: S.I. 2008/1597 (as
amended), S.I. 2016/1091 (as amended), S.I. 2012/3032 (as amended) and that the
following designated standards have been used:
BS EN 62841-1:2015+A11:2022, BS EN 50580:2012+A1:2013,
BS EN IEC 55014-1:2021, BS EN IEC 55014-2:2021,
BS EN IEC 63000:2018
Todd Chipner
Vice President, Quality – Asia
Winnenden, March 7, 2023
Authorised to compile the technical file:
Techtronic Industries (UK) Ltd
Parkway
Marlow Bucks SL7 1YL
UK
EC DECLARATION OF CONFORMITY
Manufacturer: Techtronic Industries GmbH
Max-Eyth-Straße 10, 71364 Winnenden, Germany
We declare as the manufacturer under our sole responsibility that the product
mentioned below
Cordless weed sprayer
Brand: RYOBI
Model number: OWS1880
Serial number range: 44484902000001 - 44484902999999
fulfills all the relevant provisions of the following European Directives, European
Regulations and harmonised standards:
2006/42/EC, 2014/30/EU, 2011/65/EU,
EN 62841-1:2015+A11:2022, EN 50580:2012+A1:2013,
EN IEC 55014-1:2021, EN IEC 55014-2:2021, EN IEC 63000:2018
Todd Chipner
Vice President, Quality – Asia
Winnenden, March 7, 2023
Authorised to compile the technical file:
Alexander Krug, Managing Director
Techtronic Industries GmbH
Max-Eyth-Straße 10, 71364 Winnenden, Germany
RYOBI is a trade mark of Ryobi Limited,
and is used under license.

BACK PAGE
961480172-02
Techtronic Industries GmbH
Max-Eyth-Straße 10,
71364 Winnenden, Germany
Techtronic Industries (UK) Ltd
Parkway
Marlow Bucks SL7 1YL
UK
