Ryonet Riley Hopkins Junior User manual

Jr. 1-Color, 1-Station
Assembly Instructions

1
Tools Required:
What’s in the box
• Two 9/16” wrenches
• One Phillipps screwdriver
Tag
11 per unitMain Press core assembly
Mounting feet
Screen Clamp assembly
16” x 16” MDF platens with neck
Hardware kit
2 per unit
1 per unit
1 per unit
1 per unit
2
3
4
5
Item Q.
1
2
5
3
4

2
1
2
3
4
Tag
14
8
4
1
PRHD-HC3/8NC1GR5ZC
PRHD-LNYN3/8NCGR5ZC
PRCO-JR41MTGHDWKIT
3/8-16 X 1 Hex Cap Screw Grade 5 Zinc
3/8 PFC9 Yellow Zinc USS Flat Washer
3/8-16 Lowpro Nyloc Zinc
Mounting Hardware pack perforated bag (qty. 4
screws)
PRHD-WA3/8USSPFC9ZY
2
3
4
Name/ID Description Q.
PRCO-JRFTMTHDWPK
Riley Junior Foot Mounting Hardware Kit

3
Step 1
Install the Mounting feet (4) to the main press core with the supplied
hardware. Two 9/16” wrenches are required for this step.
Note: Refer to Page 2 for hardware detail.
1
2
3
4

4
1
2
Step 2
Mount the press base to a sturdy table top with supplied mounting
screws. Press is shown mounted on a Riley Hopkins 1-station press cart
(sold separately). A Phillips screwdriver is required for this step.
Note: Refer to Page 2 for hardware detail.

5
Step 3
Install the screen clamp assembly with the supplied hardware into the
slots of the o-contact brackets. One 9/16” wrench is required for this
step.
3
Tag
11
2
2
PRSA-JRCLAMP
PRHD-HN3/8NCGR5ZC
Riley Junior Press Clamping Head assy.
3/8 PFC9 Yellow Zinc USS Flat Washer
3/8-16Hex Nut Zinc
PRHD-WA3/8USSPFC9ZY
2
3
Name/ID Description Q.
2
1

6
Step 4
Install the platen assembly (1) onto the tubular arm of the press. When
platen is in desired location, first lock down the side knob (2). Lastly,
tighten down the lower locking knobs (3). The platen can be adjusted
front-to-back to help position the image onto the desired location of
the substrate.
1
32

7
Step 5
Set up screen. First lock the screen in place with the screen clamping
knobs (1). It is ideal to fully seat the screen into the back of the screen
clamp as shown.
Next, loosen the o-contact nuts (2) with a 9/16” wrench. Set the
desired o-contact position and retighten the nuts.
Lastly, set the tilt angle of the screen by loosening the tilt locking nuts
(3). Make sure to fully lock down the tilt hardware to avoid movement
during printing.
1
1
2
3

8
13
4
5
6
7
PRTB-JNR1X1
Riley Hopkins Junior 1 color, 1 station screen printing press
1
Tag
1
4
1
1
1
2
2
2
2
PLWD-WIN16X16N-LOW
PRSA-JR1STNPNTHED
PRCO-KNBFLT3/8NC4ML
PRHD-HC3/8NC1-1/2NYBLK
MFPD-JR1X1MTGFT
Riley Junior Press Platen assy. w/Lowpro bracket
1-station Junior Series Printhead, No Micro
Riley Junior Press Clamping Head assy.
Riley Hopkins Press Mesh Covered Spring
Riley Hopkins Screen Clamp Head Knob
3/8”-16 x 1-1/2 Nylon bolt Black
Mounting Foot for Riley Junior 1 Station-Matte Black
PRSA-JRCLAMP
PRSA-SPRINGKIT
2
5
3
6
7
Name/ID Description Q.
2

9
PRSA-JRCLAMP
Riley Hopkins Junior Screen Clamp assembly
1
Tag
1
4
2
2
2
2
4
2
4
1
1
PRCO-KNBFLT3/8NC4ML
PRHD-WA3/8USSPFC9ZY
PRHD-HN3/8NCGR5ZC
PRHD-LNYN3/8NCGR5ZC
PRHD-WA3/8SAE-SS
MFMS-JRCPHEADM
MFMS-CLMPBR1/2X1
Riley Hopkins Replacement Clamp Head Knob
3/8 PFC9 Yellow Zinc USS Flat Washer
3/8-16 Hex Finish Jam Nut
3/8-16 x 1 Button Head Allen Bolt Black Oxide
3/8-16 Hex Finish Nut
3/8-16 Lowpro Nyloc Zinc
3/8 SAE Flat Washer Stainless Steel
Machined universal Clamping head, Riley Junior
Universal clamping bar for Riley clamp heads
PRHD-JN3/8NCGR5ZC
PRHD-BTN3/8NC1BLK
2
5
3
6
7
8
9
Name/ID Description Q.
1
23
4
5
6
7
8
9
