SAFAVIEH COUTURE Devyn SFV4113-Q User manual

CARE AND MAINTENANCE
Spot clean using a mild water-free solvent. Only a professional cleaner
should undertake a complete overall cleaning.
The use of steam or water-based cleaners may cause excessive shrinking
or staining.
NOTICE
* Please make sure that you have all parts indicated before you begin
assembly of this item
* This item should be assembled on a soft surface to prevent scratching the
finish during assembly
* This item may require periodic tightening
Part List and Hardware List
PIECE
DESCRIPTION
QUANTITY
A
HEADBOARD
1X
B
FOOTBOARD
1X
C
SIDE RAILS
(LEFT)
1X
D
SIDE RAILS
(RIGHT)
1X
E
FRONT LEGS
2X
F
BACK LEGS
2X
G
CENTRE
SUPPORT
RAIL
2X
H
CENTRER
LEGS
6X
I
SLATS
5X
HW1
WOODEN
DOWEL
20X
HW2
METAL
THREAD
M8x70mm
10X
HW3
SEMICIRCLE
WASHER
10X
HW4
SPRING
WASHER
14X
HW5
NUT
M8
10X
HW6
SPANNER
M13
1X
HW7
SCREW
4x30mm
10X
Model #: SFV4113-K
Product Dimensions: 94”W x 85 5/8” D x 32 2/3”H

HW8
SMALL
CROSS BOLT
M6x40mm
6X
HW9
ALLEN KEY
1X
HW10
BIG CROSS
BOLT
M8x90mm
4X
HW11
FLAT
WASHER
4X
HW12
MEDIUM
CROSS BOLT
M8x40mm
6X
PREPARETION
Before beginning assembly of product, make sure all parts are present. Compare parts with package contents list and
hardware contents list.
If any part is missing or damaged, do not attempt to assemble the product.
Estimated Assembly Time: 10 minutes
Tools Required for Assembly (Not included): Phillips Screwdriver
c
WARNING
Weight capacity: 400lbs
Warning: DO NOT STAND ON TABLE
Warning: DO NOT OVER TORQUE BOLTS
HW1 x 20
STEP 1
HW1
HW1
HW1
HW1
HW1
A
B
D
C
H

STEP 2
HW8
HW8 x 6
HW2
HW8
HW9
STEP 3
H
G
A
D
C
B
HW2 x 8

STEP 4
HW3 x 8
HW4 x 8
HW5 x 8
HW4
HW5
HW3
HW6

F
F
E
E
STEP 5
HW2 x 2
HW4 x 4
HW10 x 4
HW11 x 4
HW12 x 6
HW10
HW11
HW4
HW2
HW9
HW9
HW12
HW12
HW9

STEP 6
HW3
HW5
HW4
HW6
HW3 x 8
HW4 x 8
HW5 x 8

STEP 7
HW7 x 10
HW7
L

CARE AND MAINTENANCE
Spot clean using a mild water-free solvent. Only a professional cleaner
should undertake a complete overall cleaning.
The use of steam or water-based cleaners may cause excessive shrinking
or staining.
NOTICE
* Please make sure that you have all parts indicated before you begin
assembly of this item
* This item should be assembled on a soft surface to prevent scratching the
finish during assembly
* This item may require periodic tightening
Part List and Hardware List
PIECE
DESCRIPTION
QUANTITY
A
HEADBOARD
1X
B
FOOTBOARD
1X
C
SIDE RAILS
(LEFT)
1X
D
SIDE RAILS
(RIGHT)
1X
E
FRONT LEGS
2X
F
BACK LEGS
2X
G
CENTRE
SUPPORT
RAIL
1X
H
CENTRER
LEGS
3X
I
SLATS
5X
HW1
WOODEN
DOWEL
17X
HW2
METAL
THREAD
M8x70mm
10X
HW3
SEMICIRCLE
WASHER
10X
HW4
SPRING
WASHER
14X
HW5
NUT
M8
10X
HW6
SPANNER
M13
1X
HW7
SCREW
4x30mm
10X
Model #: SFV4113-Q
Product Dimensions: 94”W x 69 2/3” D x 32 2/3”H

HW8
SMALL
CROSS BOLT
M6x40mm
3X
HW9
ALLEN KEY
1X
HW10
BIG CROSS
BOLT
M8x90mm
4X
HW11
FLAT
WASHER
4X
HW12
MEDIUM
CROSS BOLT
M8x40mm
6X
PREPARETION
Before beginning assembly of product, make sure all parts are present. Compare parts with package contents list and
hardware contents list.
If any part is missing or damaged, do not attempt to assemble the product.
Estimated Assembly Time: 10 minutes
Tools Required for Assembly (Not included): Phillips Screwdriver
c
WARNING
Weight capacity: 400lbs
Warning: DO NOT STAND ON TABLE
Warning: DO NOT OVER TORQUE BOLTS
HW1 x 17
STEP 1
HW1
HW1
HW1
HW1
HW1
A
B
D
C
H

STEP 2
HW8
HW8 x 3
HW2
HW8
HW9
STEP 3
H
G
A
D
C
B
HW2 x 8

STEP 4
HW3 x 8
HW4 x 8
HW5 x 8
HW4
HW5
HW3
HW6

F
F
E
E
STEP 5
HW2 x 2
HW4 x 4
HW10 x 4
HW11 x 4
HW12 x 6
HW10
HW11
HW4
HW2
HW9
HW9
HW12
HW12
HW9

STEP 6
HW3
HW5
HW4
HW6
HW3 x 8
HW4 x 8
HW5 x 8

STEP 7
HW7 x 10
HW7
L
