VRI3-E-PM11 ASSEMBLY INSTRUCTIONS–PACKAGING CONTENTS
1—FBM3-0012 ...................................................... (Qty 1)
Channels with Hardware
CONTENTS OVERVIEW
2—Rear Crossbar Assembly.................................. (Qty 1)
3—Center Crossbar Assembly............................... (Qty 1)
4—Front Crossbar Assembly................................. (Qty 1)

PRIME DESIGN, A SAFE FLEET BRAND
▪Address: 1689 Oakdale Avenue #102, West St Paul, Minnesota 55118 ▪Phone: [phone] ▪Toll Free: 1.8.PRIME.RACK ▪Fax: [phone] ▪Email: in[email protected] ▪Website: www.primedesign.net
TM & © 2018 PRIME DESIGN. PROTECTED BY ONE OR MORE OF THE FOLLOWING PATENT NO.’s 6764268, 6971563, 2364879, 8857689, 8511525, 8991889, 2271515, 2364897, 9506292, 9481313, 9481314, 9796340, 6202807, 6427889, 9415726 AND OTHER PATENTS PENDING
3
VRI3-E-PM11 ASSEMBLY INSTRUCTIONS–PACKAGING CONTENTS
7—Front Drive Shaft .............................................. (Qty 1)
38.75”
9—Z Post ................................................................ (Qty 2)
Adjustable, 7.25”
10—L Post.............................................................. (Qty 2)
US3, Square Cap, 11.25”
11—Drive Shaft...................................................... (Qty 1)
Rear, Left Hand, 34.00”
6—Connecting Bar................................................. (Qty 1)
48.00”
5—Drive Shaft........................................................ (Qty 1)
Rear, Right Hand, 34.00”
14—HRR Removeable Handle Assembly ............. (Qty 1)
8—Drive Arm .......................................................... (Qty 1)
Incline Version with Bushing and Hardware
12—Connecting Bar .............................................. (Qty 1)
24.00”
13—Front Drive Shaft............................................ (Qty 1)
B Version, 11.75”
15—HKT-8163-Rotation Hardware Kit ................. (Qty 2)
(Not called out in Overview)
" Flat Washer (10X)
Anti-Seize (1X)
Lubricant (1X)
Clevis Pin (1X)
Cotter Pin (1X)
M8 x 50MM (4X) ⅜" x 2.25" (2X)
1.00" Sealing
Stickers (16X)
M8 Lock Nut (5X) ⅜" Lock Nut (2X) ⅜" Flat Washer (4X)
M8 x 25MM (1X)
