Sailmon E4 User manual
1
Model | E4 Installation guide 1.0
copyright SAILMON BV 2016
16-11-2016
MODEL | E4
Installation guide version 1.0
November 2016
2
Contents
Contents 2
Before you get started 3
About this Manual 3
Disclaimer 3
Calibration 3
Electrical supply 4
Getting Started 5
Communication protocol 5
System examples 6
MODEL | E4 Tech specs 7
MODEL | E4 installation 8
Power on for the first time. 9
FAQ. 10
Model | E4 Installation guide 1.0
copyright SAILMON BV 2016
16-11-2016
3
Before you get started
About this Manual
As Sailmon is continuously improving their products, we retain the right to make changes to our products at any
time which may not be reflected in this version of the manual.
This manual is a guide to installing the Sailmon MODEL | E4. The Manual assumes that the
Installer has basic knowledge of DC electrical systems, wiring and common installation practices.
If in doubt always ask SAILMON or your dealer for assistance.
Disclaimer
It is the owner of the Sailmon product (s) sole responsibility to install and use the instruments in a responsible
manner that will not cause accidents, personal injury or property damage.The user of this product is solely
responsible for observing safe boating practices.
SAILMON BV DISCLAIMS ALL LIABILITIES FOR ANY USE OF THIS PRODUCT IN A WAY THAT MAY CAUSE
ACCIDENTS, DAMAGE OR THAT MAY VIOLATE THE LAW.
SAILMON INSTRUMENTS ARE AN AID TO NAVIGATION BUT DO NOT REPLACE CONVENTIONAL
NAVIGATION. ITS THE OWNERS RESPONSIBILITY TO PRACTICE SAFE BOATING PRACTICES AND
NAVIGATION. ALL PRECAUTIONS SHOULD BE TAKEN TO ENSURE THAT THE YACHT IS NOT PLACED INTO
DANGER.
Calibration
The Sailmon system is an electronic aid and is designed to assist in navigation and reading measurement
values. Incorrect calibration can lead to false and inaccurate readings placing the yacht into possible danger.!
Model | E4 Installation guide 1.0
copyright SAILMON BV 2016
16-11-2016
USED TO RAISE ATTENTION TO PREVENT RISK OF INJURY
AND OR DAMAGE TO EQUIPMENT OR PERSONAL.
Used to raise attention to a comment
4
Electrical supply
This equipment is designed for use with a power supply source of 12-24 Vdc. The application of any other
power supply may result in permanent damage to the equipment.
It’s the installers responsibility to ensure the diameter of the cables from the battery to the switching panel and
from the switching panel to the SAILMON products is sufficient.
•Avoid excessive voltage drop due to improper cable diameter.
•Cut the cable to the correct length.
•Do not make rings of excessive cable inside the switching panel or elsewhere.
Best efficiency and lowest battery consumption is achieved when optimizing cable length to a
minimum.
THE MINIMUM VOLTAGE ON THE MODEL | E4 CONNECTOR MUST NOT FALL BELOW 9.0 VOLTS. UNDER
VOLTAGE WILL CAUSE SYSTEM RESET AND SYSTEM INSTABILITY.!
Large currents due to switching of electrical winches or other high power devices will cause under voltages for a
short time. Model E4 will handle this short-term voltage drop if the voltage stays well above 6.5 Volts. A voltage
below 6.5 Volts will result in immediate reset and reboot.
Model | E4 Installation guide 1.0
copyright SAILMON BV 2016
16-11-2016
ALWAYS PUT A FUSE BETWEEN POWER SUPPLY AND SAILMON DEVICE
5
Getting Started
It’s time to get to business! At Sailmon we have tried very hard to make installation as easy as possible. So let’s
get started quickly.
In this installation guide we assume you have already planned your installation, and already have installed your
sensors.
This manual does not cover the installation of sensors.
Sailmon interfaces with the sensors you have installed and uses that data to crunch the numbers.
If you have any questions about planning your Sailmon equipment or where to place your sensors, don’t
Communication protocol
The Sailmon instruments communicate using standard 100Mbps ethernet allowing for very fast and
flexible integration.
Each device is a DHCP client which allows our system to be integrated in the ships network. All
system control is done using our Nav | desk application.
Model | E4 Installation guide 1.0
copyright SAILMON BV 2016
16-11-2016
