Salamander D1/337A User manual

Salamander 3 Bay Low Prole Wall Mount Cabinet 1 of 10 503-246 [3.17]
TIP HAZARD WARNING!
Cabinet must be affixed to wall. For use to prevent tipping in compliance
with capacity of cabinet specified. Use with heavier equipment may result in
instability or detachment causing tip over resulting in death or serious injury.
3 BAY Low Profile WALL MOUNT CABINET
D1/337A ASSEMBLY INSTRUCTIONS

Salamander 3 Bay Low Prole Wall Mount Cabinet 2 of 10 503-246 [3.17]
hardware
E
A
D
B
C
H
F
I
ID PART # DESCRIPTION
A 300-485 1/4-20 x 1/2” Button Head Socket Screw
B 300-465 1/4-20 x 3/4” Head Socket Screw
C 301-730 5/16 x 2.5” Lag Bolt
D 301-745 Hollow Wall Anchors
E 300-565 Drop In Nut
F 300-470 5/16” Flat Washer
G 400-035 Leveler Wrench
H 303-855 Universal Wall Bracket
I 300-468 1/4” Flat Washer
J 300-518 1/4-20 x 3/8” Button Head Socket Screw
K 302-310 10-32 x 5/8” Button Head Socket Screw
L 300-835 Universal Shelf Peg
M 301-055 3/8 x 2” Alligator Wall Anchors
G
J
K
L
M

Salamander 3 Bay Low Prole Wall Mount Cabinet 3 of 10 503-246 [3.17]
warnings
IMPORTANT SAFETY INSTRUCTIONS
READ ALL INSTRUCTIONS BEFORE USING THIS FURNISHING
WARNING! Failure to comply with these instructions may result in accident involving serious personal
injury. Failing to follow these instructions can result in the product being damaged or being destroyed or
voiding of the warranty.
CAUTION!
• Close supervision is necessary when this furnishing is used by or near children, invalids,
or disabled persons
• Use this furnishing only for its intended use as described in these instructions.
Do not use attachments not recommended by the manufacturer.
• Do not use outdoors
• For Commercial Use Only
***** SAVE THESE INSTRUCTIONS *****
Accessories and Spare Parts
Please contact Salamander Designs 860.761.9500 or www.salamanderdesigns.com/commercial
Tools needed
Drill Driver
#2 Phillips Head Screw Driver
1/2 Drill Bit for Standard Installation
3/16” Drill Bit for Wood Stud Installation
3/8” Drill Bit for Masonry Installation
Pencil
Tape Measure
Level
TOOLS INCLUDED
PART # DESCRIPTION
P-400-030 Driver Bit 1/4” Hex Key
400-030 1/4” Hex Key
400-070 1/8” Hex Key
400-080 5/32” Hex Key
400-058 3/16” Hex Key- Short Arm

Salamander 3 Bay Low Prole Wall Mount Cabinet 4 of 10 503-246 [3.17]
1. install MOUNTING BRACKETS
TIP HAZARD WARNING! Cabinet MUST be affixed to wall.
ALoosely mount Bracket (H)
using Screw (A), Washer (I)
and Drop-In Nut (E) to rear
Horizontal Extrusion as shown.
A
H
E
I

Salamander 3 Bay Low Prole Wall Mount Cabinet 5 of 10 503-246 [3.17]
Prior to fastening to wall, it is important to level the cabinet
with the floor by verifying that feet are properly adjusted.
Check and level Length and Depth of cabinet.
NOTE:
Adjustments has been provided in the bracket
to mount the cabinet 0-1” of the wall to account
for baseboard trim or other obstacles.
Jam Nut
Loosen jam nut with supplied wrench
and tighten to the locked position.
Place cabinet in desired location and
mark bracket holes. Once holes have
been marked move cabinet.
2. Level cabinet & MARK WALL
A B
WARNING! This step requires two people.

Salamander 3 Bay Low Prole Wall Mount Cabinet 6 of 10 503-246 [3.17]
Drill 1/2” diameter hole. Hold metal
channel flat alongside plastic straps
and slide channel through hole.
Hold ends of straps between thumb
and forefinger and pull toward you
until channel rests flush behind wall.
Slide plastic cap along straps with either
hand with flange of cap is flush with wall.
Snap straps at wall by pushing side
to side,snapping of straps level with
flange of cap.
Move cabinet to wall and attach
bracket. Insert bolt through Bracket
and tighten until snug against wall.
Install wall fasteners to marked location on wall & fasten cabinet.
NOTE: Alternate fasteners (C & F) provided for wood studs.
3. install WALL FASTENERS (most applications)
A B
C D

Salamander 3 Bay Low Prole Wall Mount Cabinet 7 of 10 503-246 [3.17]
WOOD: Locate two framing studs using a stud finder device.
MASONRY: Place brackets in desired location.
Use a 3/16” [5mm] drill bit and drill holes 2.5” [64mm] deep.
3B. install WALL FASTENERS (ALTERNATE)
B
C D
Insert wall anchors (M) into hole. Place cabinet in place and fasten
with washers (F) and Lag Bolts (C).
A
M
C
F

Salamander 3 Bay Low Prole Wall Mount Cabinet 8 of 10 503-246 [3.17]
4. install Brush seal
Use with baseboard molding, trim work or gaps in uneven wall surfaces.
Brush Seal Holders should stay flush to surface so that ONLY brush is showing.
Cabinet Side
Peel off tape and install from inside
of cabinet by aligning and afxing
the brush seal to rear inside panel.
A

Salamander 3 Bay Low Prole Wall Mount Cabinet 9 of 10 503-246 [3.17]
6. install Shelves
A
B
Insert into post channel
and slide to desired height.
Level shelf by adjusting
shelf peg positions and
tighten screw using hex key.
Note: Drop-in nut must
make a 1/4 turn in post.
Assemble loosely as shown.
B
L
E
Drop-In Nut Option
Should you desire shelf placement in location other than
predrilled locations, use the drop-in nut option.
This option allows shelf to be placed at any height.
NOTE: Shelf pegs can be re-positioned if desired.
A. Place shelves on pegs.
B. Install shelf stops in front or back of shelf as desired.
C. Shelf placement can be adjusted if necessary to either pre-drilled.
locations or any location using Drop-In Nuts (E) supplied.
D. Install accessories (IR Repeater Kit, Power Conditioner, etc) and place components.
C

Salamander 3 Bay Low Prole Wall Mount Cabinet 10 of 10 503-246 [3.17]
ADJUSTMENT TIPS
3U Vertical Rack
Remove
Loosen screws on both sides.
Then tilt rack until the hook is
free and lift up until the rack is
free from bottom screw.
Re-Install
Slide the slotted ends of the
rack over the bottom screw and
hook the top screw as shown.
Tighten with provided
Hex Key.
AB
DOORS
NOTE: It is important that cabinet is level before adjusting doors, see step 2.
LIMITED WARRANTY FOR COMMERCIAL VIDEO DISPLAY STANDS AND MOUNTS
Salamander is proud to stand behind our products with industry-leading warranties. Should you ever encounter any problem with your
Salamander product, let us know. We are here to make it right. 1.860.761.9500
Full warranty including limitations and warranty claim information may be found at www.salamanderdesigns.com/commercial/warranty
Made in USA
Main Adjustment (Side to Side and Up/Down)
Adjustment is made by turning screw (A) in and out.
Dismount Hinge from Hinge Plate
With one hand holding the door open, pull
back on the hinge quick-release lever (B).
Door Front
Adjust the tops of the doors to be
parallel to the top of the cabinet.
A
A
A
A
B
