Salamander 4 Bay AV Credenza 503-228 [7.18] page 1 of 7
4 BAY AV CREDENZA
D2/347AASSEMBLY INSTRUCTIONS

Salamander 4 Bay AV Credenza 503-228 [7.18] page 2 of 7
hardware
C
I
G
H
B
J
A
E
ID PART # DESCRIPTION
A 300-835x Universal Shelf Peg
B 300-518x 1/4-20 x 3/8” Button Head Socket Screw
C 300-485x 1/4-20 x 1/2” Button Head Socket Screw
D 300-455x 1/4-20 x 1” Head Socket Cap Screw
E 300-465x 1/4-20 x 3/4” Head Socket Screw
F 302-315x 10-32 x 5/8” Flanged Button Head
Socket Screw
G 300-468x 1/4” Flat Washer
H 300-532x 1/4-20 Lock Nut
I 300-565x Drop In Nut
J 300-560x 1/4-20 Flat Nut
K 300-520x 1/4-20 Small Flat Nut
L 301-470x 5/16” Flat Washer
L
D
F
K

Salamander 4 Bay AV Credenza 503-228 [7.18] page 3 of 7
warnings
IMPORTANT SAFETY INSTRUCTIONS
READ ALL INSTRUCTIONS BEFORE USING THIS FURNISHING
WARNING! Failure to comply with these instructions may result in accident involving serious personal
injury. Failing to follow these instructions can result in the product being damaged or being destroyed or
voiding of the warranty.
CAUTION!
• Closesupervisionisnecessarywhenthisfurnishingisusedbyornearchildren,invalids,
or disabled persons
• Usethisfurnishingonlyforitsintendeduseasdescribedintheseinstructions.
Do not use attachments not recommended by the manufacturer.
• Donotuseoutdoors
• ForCommercialUseOnly
***** SAVE THESE INSTRUCTIONS *****
Accessories and Spare Parts
Please contact Salamander Designs 860.761.9500 or www.salamanderdesigns.com/commercial
Tools needed
#2 Phillips Head Screw Driver
1/2 Drill Bit for Standard Installation
Pencil
Tape Measure
Level
TOOLS INCLUDED
PART # DESCRIPTION
P-400-030 Driver Bit 1/4” Hex Key
400-035 Leveler Wrench
400-030 1/4” Hex Key
400-080 5/32” Hex Key
400-058 3/16” Hex Key- Short Arm

Salamander 4 Bay AV Credenza 503-228 [7.18] page 4 of 7
WARNING! This step requires two people.
1. LEVEL CABINET
Wood Block Foot
Lift cabinet and adjust leveler by hand.
Leveler
Jam Nut
Leveler Foot
Loosen jam nut with supplied wrench
and tighten to the locked position.

Salamander 4 Bay AV Credenza 503-228 [7.18] page 5 of 7
2. install Shelves
Insert into post channel
and slide to desired height.
Level shelf by adjusting
shelf peg positions and
tighten screw using hex key.
Note: Drop-in nut must
make a 1/4 turn in post.
Assemble loosely as shown.
E
A
I
Drop-In Nut Option
Should you desire shelf placement in location other
thanpredrilledlocations,usethedrop-innutoption.
This option allows shelf to be placed at any height.
NOTE: Shelf pegs can be re-positioned if desired.
A. Shelf placement can be adjusted if necessary to either predrilled
locations or any location using Drop-In Nuts (I) Shelf Peg
assembly (see diagram below).
B. Place shelves on pegs.
B
A

Salamander 4 Bay AV Credenza 503-228 [7.18] page 6 of 7
Plug in Power Supply
Plug in Ac adaptor bottom center
behind fan grill.
Attach Thermistor
3. Install Rear cooling panel
Install Rear Cooling Panel
Squeeze in the provided handled slots and
pull outward until panel is free.
NOTE: Reverse step for re-installation.
Upon removal, carefully place rear panel in
the up right position so not to damage the
fan assembly.
Alternativeconnection,connectthe
thermistor directly to the component.
Loosen screw and slip the thermistor
wire under the screw head and tighten.
Use supplied magnetic cube to
hold thermistor in place on top of
the hottest piece of equipment
closest to the heat source.
A
B C

Salamander 4 Bay AV Credenza 503-228 [7.18] page 7 of 7
ADJUSTMENT TIPS
Main Adjustment (Side to Side and Up/Down)
Adjustment is made by turning screw (A) in and out.
Dismount Hinge from Hinge Plate
With one hand holdingthedooropen,pull
back on the hinge quick-release lever (B).
Door Front
Adjust the tops of the doors to be
parallel to the top of the cabinet.
A
A
A
DOORS
NOTE: It is important that cabinet is level before adjusting doors, see step 1.
A
B
