Samlexpower PST-3000-12 User manual

DC-AC Power
Inverter
Pure Sine Wave
PST-3000-12
PST-3000-24
Please read this
manual BEFORE
installing your
inverter
Owner's
Manual

2 | SAMLEX AMERICA INC.
OWNER'S MANUAL | Index
SECTION 1 Safety Instructions ........................................3
SECTION 2 General Information .....................................7
SECTION 3
Limiting Electromagnetic Interference (EMI) ....................... 14
SECTION 4
Powering Direct / Embedded Switch Mode
Power Supplies (SMPS) ....................................................... 15
SECTION 5 Principle of Operation ............................... 17
SECTION 6 Layout........................................................ 18
SECTION 7
General Information on Lead-Acid Batteries ....................... 19
SECTION 8 Installation ................................................. 30
SECTION 9 Operation ...................................................44
SECTION 10 Protections ............................................. 47
SECTION 11 Troubleshooting Guide ........................... 51
SECTION 12 Specications ......................................... 53
SECTION 13 Warranty ..................................................55
APPENDIX A
SECTION 8 Installation (French)
Disclaimer of Liability
UNLESS SPECIFICALLY AGREED TO IN WRITING, SAMLEX AMERICA INC.:
1. MAKES NO WARRANTY AS TO THE ACCURACY, SUFFICIENCY OR SUITABILITY OF ANY TECHNICAL OR OTHER INFORMATION
PROVIDED IN ITS MANUALS OR OTHER DOCUMENTATION.
2. ASSUMES NO RESPONSIBILITY OR LIABILITY FOR LOSSES, DAMAGES, COSTS OR EXPENSES, WHETHER SPECIAL, DIRECT,
INDIRECT, CONSEQUENTIAL OR INCIDENTAL, WHICH MIGHT ARISE OUT OF THE USE OF SUCH INFORMATION. THE USE OF
ANY SUCH INFORMATION WILL BE ENTIRELY AT THE USERS RISK.
Samlex America reserves the right to revise this document and to periodically make changes to the content
hereof without obligation or organization of such revisions or changes.
Copyright Notice/Notice of Copyright
Copyright © 2018 by Samlex America Inc. All rights reserved. Permission to copy, distribute and/or modify this
document is prohibited without express written permission by Samlex America Inc.

2 | SAMLEX AMERICA INC. SAMLEX AMERICA INC. | 3
SECTION 1 | Safety Instructions
1.1 IMPORTANT SAFETY INSTRUCTIONS AND SYMBOLS
SAVE THESE INSTRUCTIONS. This manual contains important instructions for models
PST-3000-12 and PST-3000-24 that shall be followed during installation, operation and
maintenance.
The following safety symbols will be used in this manual to highlight safety
and information:
WARNING!
Indicates possibility of physical harm to the user in case of non-compliance.
MISE EN GARDE!
L’utilisateur pourrait se blesser lorsque les consignes de sécurité ne sont pas
suivies.
!
CAUTION!
Indicates possibility of damage to the equipment in case of non-compliance.
!
ATTENTION!
Il y a un risque d’endommager l’équipement lorsque l'utilisateur ne suit pas
les instructions.
i
INFO
Indicates useful supplemental information.
Please read these instructions before installing or operating the unit to prevent personal
injury or damage to the unit.
1.2 SAFETY INSTRUCTIONS - GENERAL
Installation and wiring compliance
• Installation and wiring must comply with the Local and National Electrical Codes and
must be done by a certied electrician.
Preventing electrical shock
• Always connect the grounding connection on the unit to the appropriate grounding
system.

4 | SAMLEX AMERICA INC.
SECTION 1 | Safety Instructions
• Disassembly / repair should be carried out by qualied personnel only.
• Disconnect all AC and DC side connections before working on any circuits associated
with the unit. Turning the ON/OFF switch on the unit to OFF position may not entirely
remove dangerous voltages.
• Be careful when touching bare terminals of capacitors. Capacitors may retain high le-
thal voltages even after the power has been removed. Discharge the capacitors before
working on the circuits.
Installation environment
• The inverter should be installed indoor only in a well ventilated, cool, dry environment.
• Do not expose to moisture, rain, snow or liquids of any type.
• To reduce the risk of overheating and re, do not obstruct the suction and discharge
openings of the cooling fan.
• To ensure proper ventilation, do not install in a low clearance compartment.
Preventing re and explosion hazards
• Working with the unit may produce arcs or sparks. Thus, the unit should not be used
in areas where there are ammable materials or gases requiring ignition protected
equipment. These areas may include spaces containing gasoline-powered machinery,
fuel tanks, and battery compartments.
Precautions when working with batteries
• Batteries contain very corrosive diluted Sulphuric Acid as electrolyte. Precautions
should be taken to prevent contact with skin, eyes or clothing.
• Batteries generate Hydrogen and Oxygen during charging resulting in evolution of
explosive gas mixture. Care should be taken to ventilate the battery area and follow
the battery manufacturer’s recommendations.
• Never smoke or allow a spark or ame near the batteries.
• Use caution to reduce the risk of dropping a metal tool on the battery. It could spark
or short circuit the battery or other electrical parts and could cause an explosion.
• Remove metal items like rings, bracelets and watches when working with batteries.
The batteries can produce a short circuit current high enough to weld a ring or the
like to metal and, thus, cause a severe burn.
• If you need to remove a battery, always remove the ground terminal from the battery
rst. Make sure that all the accessories are off so that you do not cause a spark.
1.3 SAFETY INSTRUCTIONS - INVERTER RELATED
Preventing Paralleling of the AC Output
The AC output of the unit should never be connected directly to an Electrical Breaker
Panel / Load Centre which is also fed from the utility power / generator. Such a direct
connection may result in parallel operation of the different power sources and AC power
from the utility / generator will be fed back into the unit which will instantly damage

4 | SAMLEX AMERICA INC. SAMLEX AMERICA INC. | 5
SECTION 1 | Safety Instructions
the output section of the unit and may also pose a re and safety hazard. If an Electrical
Breaker Panel / Load Center is fed from this unit and this panel is also required to be fed
from additional alternate AC sources, the AC power from all the AC sources (like the
utility / generator / this inverter) should rst be fed to an Automatic / Manual Selector
Switch and the output of the Selector Switch should be connected to the Electrical Breaker
Panel / Load Center. Samlex America, Inc. Automatic Transfer Switch Model No. STS-30 is
recommended for this application.
!
CAUTION!
To prevent possibility of paralleling and severe damage to the unit, never
use a simple jumper cable with a male plug on both ends to connect the
AC output of the unit to a handy wall receptacle in the home / RV.
!
ATTENTION!
Des dommages causés par un inversement des polarités ne sont pas
couverts par la garantie.
Preventing DC Input Over Voltage
It is to be ensured that the DC input voltage of this unit does not exceed 16.5 VDC for
the PST-3000-12 or 33.0 VDC for the PST-3000-24 to prevent permanent damage to the
unit. Please observe the following precautions:
• Ensure that the maximum charging voltage of the external battery charger / alterna-
tor / solar charge controller does not exceed 16.5 VDC for the PST-3000-12 or 33.0 VDC
for PST-3000-24
• Do not use unregulated solar panels to charge the battery connected to this unit.
Under cold ambient temperatures, the output of the solar panel may reach > 22 VDC
for 12V Battery System and > 44 VDC for the 24V Battery system. Always use a charge
controller between the solar panel and the battery.
• Do not connect this unit to a battery system with a voltage higher than the rated bat-
tery input voltage of the unit (e.g. do not connect PST-3000-12 to 24V or 48V battery
system or PST-3000-24 to the 48V Battery System)
Preventing Reverse Polarity on the Input Side
When making battery connections on the input side, make sure that the polarity of bat-
tery connections is correct (Connect the Positive of the battery to the Positive terminal
of the unit and the Negative of the battery to the Negative terminal of the unit). If the
input is connected in reverse polarity, the external DC fuse and theDC fuses inside the
inverter will blow and may also cause permanent damage to the inverter.
!
CAUTION!
Damage caused by reverse polarity is not covered by warranty.

6 | SAMLEX AMERICA INC.
SECTION 1 | Safety Instructions
!
ATTENTION!
Des dommages causés par un inversement des polarités ne sont pas
couverts par la garantie.
Use of External Fuse in DC Input Circuit
Use Class-T or equivalent fuse of appropriate capacity within 7" of the battery Positive ter-
minal. This fuse is required to protect DC input cable run from damage due to short circuit
along the length of the cable. Please read instructions under Section 8.4.5 - Installation.
Hard Wiring of AC Output to AC Panelboards in RVs / Motor Homes / Trailers /Campers
WARNING!
RISK OF ELECTRIC SHOCK
When this unit is installed in RV / Motor Homes / Trailers / Campers and hard-
wiring connection is used to feed the AC output of the inverter to the AC
Distribution Panelboard / Load Center in the vehicle, it is to be ensured that
Ground Fault Circuit Interrupter(s) [GFCI]are installed in the vehicle wiring
system to protect branch circuits.
The following GFCIs have been tested to operate satisfactorily and are accept-
able. Other types may fail to operate properly when connected to this inverter:
Manufacturer of GFCI Manufacturer's Model No. Description
Pass & Seymour 2095 Series NEMA5-20 Duplex, 20A
Leviton N7899 Series NEMA5-20 Duplex, 20A
Zhejiang Trimone TGM20 Series NEMA5-20 Duplex, 20A
MISE EN GARDE! RISQUE DE DÉCHARGE ÉLECTRIQUE
Si l'appareil est installé dans les véhicules récréatifs / camping-cars / caravanes
/ remorques et est une connexion de cablâge est utilisée pour alimenter la
puissance CA de l'onduleur au tableau électrique CA du véhicule, il faut
assurer qu'un(s) dispositif(s) différentiel(s) à courant résiduel soit installé
dans le système de cablâge pour protèger les circuits de dérivation.
Les DDR ci-dessous ont été tester, fonctionnent dans une manière satisfai-
sante. Des autres modèles pourraient échouer s'ils sont branchés à l'onduleur:
Fabricant
du DDR Fabricant's No. de Modèle Description
Pass & Seymour Série 2095 NEMA5-20 Duplex de 20A
Leviton Série N7899 NEMA5-20 Duplex de 20A
Zhejiang Trimone Série TGM20 NEMA5-20 Duplex de 20A

6 | SAMLEX AMERICA INC. SAMLEX AMERICA INC. | 7
2.1. DEFINITIONS
The following denitions are used in this manual for explaining various electrical
concepts, specications and operations:
Peak Value: It is the maximum value of electrical parameter like voltage / current.
RMS (Root Mean Square) Value: It is a statistical average value of a quantity that varies
in value with respect to time. For example, a pure sine wave that alternates between
peak values of Positive 169.68V and Negative 169.68V has an RMS value of 120 VAC.
Also, for a pure sine wave, the RMS value = Peak value ÷ 1.414.
Voltage (V), Volts: It is denoted by “V” and the unit is “Volts”. It is the electrical force
that drives electrical current (I) when connected to a load. It can be DC (Direct Current
– ow in one direction only) or AC (Alternating Current – direction of ow changes peri-
odically). The AC value shown in the specications is the RMS (Root Mean Square) value.
Current (I), Amps, A: It is denoted by “I” and the unit is Amperes – shown as “A”. It is
the ow of electrons through a conductor when a voltage (V) is applied across it.
Frequency (F), Hz: It is a measure of the number of occurrences of a repeating event per
unit time. For example, cycles per second (or Hertz) in a sinusoidal voltage.
Efciency, (η): This is the ratio of Power Output ÷ Power Input.
Phase Angle, (φ): It is denoted by “φ” and species the angle in degrees by which the
current vector leads or lags the voltage vector in a sinusoidal voltage. In a purely induc-
tive load, the current vector lags the voltage vector by Phase Angle (φ) = 90°. In a purely
capacitive load, the current vector leads the voltage vector by Phase Angle, (φ) = 90°. In
a purely resistive load, the current vector is in phase with the voltage vector and hence,
the Phase Angle, (φ) = 0°. In a load consisting of a combination of resistances, induct-
ances and capacitances, the Phase Angle (φ) of the net current vector will be > 0° < 90°
and may lag or lead the voltage vector.
Resistance (R), Ohm, Ω:It is the property of a conductor that opposes the ow of cur-
rent when a voltage is applied across it. In a resistance, the current is in phase with the
voltage. It is denoted by "R" and its unit is "Ohm" - also denoted as "Ω".
Inductive Reactance (XL), Capacitive Reactance (XC) and Reactance (X): Reactance is the
opposition of a circuit element to a change of electric current or voltage due to that
element's inductance or capacitance. Inductive Reactance (XL) is the property of a coil
of wire in resisting any change of electric current through the coil. It is proportional to
frequency and inductance and causes the current vector to lag the voltage vector by
Phase Angle (φ) = 90°. Capacitive reactance (XC) is the property of capacitive elements to
oppose changes in voltage. XCis inversely proportional to the frequency and capacitance
and causes the current vector to lead the voltage vector by Phase Angle (φ) = 90°. The
unit of both XLand XCis "Ohm" - also denoted as "Ω". The effects of inductive reac-
SECTION 2 | General Information

8 | SAMLEX AMERICA INC.
tance XLto cause the current to lag the voltage by 90° and that of the capacitive reac-
tance XCto cause the current to lead the voltage by 90° are exactly opposite and the net
effect is a tendency to cancel each other. Hence, in a circuit containing both inductances
and capacitances, the net Reactance (X) will be equal to the difference between the
values of the inductive and capacitive reactances. The net Reactance (X) will be inductive
if XL> XCand capacitive if XC> XL.
Impedance, Z: It is the vectorial sum of Resistance and Reactance vectors in a circuit.
Active Power (P), Watts: It is denoted as “P” and the unit is “Watt”. It is the power that
is consumed in the resistive elements of the load. A load will require additional Reactive
Power for powering the inductive and capacitive elements. The effective power re-
quired would be the Apparent Power that is a vectorial sum of the Active and Reactive
Powers.
Reactive Power (Q), VAR: Is denoted as “Q” and the unit is VAR. Over a cycle, this
power is alternatively stored and returned by the inductive and capacitive elements of
the load. It is not consumed by the inductive and capacitive elements in the load but a
certain value travels from the AC source to these elements in the (+) half cycle of the si-
nusoidal voltage (Positive value) and the same value is returned back to the AC source in
the (-) half cycle of the sinusoidal voltage (Negative value). Hence, when averaged over
a span of one cycle, the net value of this power is 0. However, on an instantaneous basis,
this power has to be provided by the AC source. Hence, the inverter, AC wiring and over
current protection devices have to be sized based on the combined effect of the Active
and Reactive Powers that is called the Apparent Power.
Apparent (S) Power, VA: This power, denoted by "S", is the vectorial sum of the Active
Power in Watts and the Reactive Power in “VAR”. In magnitude, it is equal to the RMS
value of voltage “V” X the RMS value of current “A”. The Unit is VA. Please note that
Apparent Power VA is more than the Active Power in Watts. Hence, the inverter, AC wir-
ing and over current protection devices have to be sized based on the Apparent Power.
Maximum Continuous Running AC Power Rating: This rating may be specied as “Ac-
tive Power” in Watts (W) or “Apparent Power” in Volt Amps (VA). It is normally speci-
ed in “Active Power (P)” in Watts for Resistive type of loads that have Power Factor
=1. Reactive types of loads will draw higher value of “Apparent Power” that is the sum
of “Active and Reactive Powers”. Thus, AC power source should be sized based on the
higher “Apparent Power” Rating in (VA) for all Reactive Types of AC loads. If the AC
power source is sized based on the lower “Active Power” Rating in Watts (W), the AC
power source may be subjected to overload conditions when powering Reactive Type of
loads.
Surge Power Rating: During start up, certain loads require considerably higher surge of power
for short duration (lasting from tens of millisecs to few seconds) as compared to their Maxi-
mum Continuous Running Power Rating. Some examples of such loads are given below:
SECTION 2 | General Information

8 | SAMLEX AMERICA INC. SAMLEX AMERICA INC. | 9
SECTION 2 | General Information
• Electric Motors: At the moment when an electric motor is powered ON, the rotor is
stationary (equivalent to being “Locked”), there is no “Back EMF” and the windings
draw a very heavy surge of starting current (Amperes) called “Locked Rotor Am-
peres” (LRA) due to low DC resistance of the windings. For example, in motor driven
loads like Air-conditioning and Refrigeration Compressors and in Well Pumps (using
Pressure Tank), the Starting Surge Current / LRA may be as high as 10 times its rated
Full Load Amps (FLA) / Maximum Continuous Running Power Rating. The value and
duration of the Starting Surge Current / LRA of the motor depends upon the wind-
ing design of the motor and the inertia / resistance to movement of mechanical load
being driven by the motor. As the motor speed rises to its rated RPM, “Back EMF”
proportional to the RPM is generated in the windings and the current draw reduces
proportionately till it draws the running FLA / Maximum Continuous Running Power
Rating at the rated RPM.
• Transformers (e.g. Isolation Transformers, Step-up / Step-down Transformers, Power Trans-
former in Microwave Oven etc.): At the moment when AC power is supplied to a transformer,
the transformer draws very heavy surge of “Magnetization Inrush Current” for a few millisecs
that can reach up to 10 times the Maximum Continuous Rating of the Transformer.
• Devices like Infrared Quartz Halogen Heaters (also used in Laser Printers) / Quartz
Halogen Lights / Incandescent Light Bulbs using Tungsten heating elements: Tungsten
has a very high Positive Temperature Coefcient of Resistance i.e. it has lower resist-
ance when cold and higher resistance when hot. As Tungsten heating element will be
cold at the time of powering ON, its resistance will be low and hence, the device will
draw very heavy surge of current with consequent very heavy surge of power with a
value of up to 8 times the Maximum Continuous Running AC Power.
• AC to DC Switched Mode Power Supplies (SMPS): This type of power supply is used as
stand-alone power supply or as front end in all electronic devices powered from Util-
ity / Grid e.g. in audio/video/ computing devices and battery chargers (Please see Sec-
tion 4 for more details on SMPS). When this power supply is switched ON, its internal
input side capacitors start charging resulting in very high surge of Inrush Current for a
few millisecs (Please see Fig 4.1). This surge of inrush current / power may reach up to
15 times the Continuous Maximum Running Power Rating. The surge of inrush current
/ power will, however, be limited by the Surge Power Rating of the AC source.
Power Factor, (PF): It is denoted by “PF” and is equal to the ratio of the Active Power
(P) in Watts to the Apparent Power (S) in VA. The maximum value is 1 for resistive types
of loads where the Active Power (P) in Watts = the Apparent Power (S) in VA. It is 0 for
purely inductive or purely capacitive loads. Practically, the loads will be a combination of
resistive, inductive and capacitive elements and hence, its value will be > 0 <1. Normally
it ranges from 0.5 to 0.8 e.g. (i) AC motors (0.4 to 0.8), (ii) Transformers (0.8) (iii) AC to
DC Switch Mode Power Supplies (0.5 to 0.6) etc.
Load: Electrical appliance or device to which an electrical voltage is fed.
Linear Load: A load that draws sinusoidal current when a sinusoidal voltage is fed to it.
Examples are, incandescent lamp, heater, electric motor, etc.

10 | SAMLEX AMERICA INC.
Non-Linear Load: A load that does not draw a sinusoidal current when a sinusoidal volt-
age is fed to it. For example, non-power factor corrected Switched Mode Power Supplies
(SMPS) used in computers, audio video equipment, battery chargers, etc.
Resistive Load: A device or appliance that consists of pure resistance (like lament
lamps, cook tops, toaster, coffee maker etc.) and draws only Active Power (Watts) from
the inverter. The inverter can be sized based on the Active Power rating (Watts) of
resistive type of loads without creating overload (except for resistive type of loads with
Tungsten based heating element like in Incandescent Light Bulbs, Quartz Halogen Lights
and Quartz Halogen Infrared Heaters. These require higher starting surge power due to
lower resistance value when the heating element is cold).
Reactive Load: A device or appliance that consists of a combination of resistive, inductive
and capacitive elements (like motor driven tools, refrigeration compressors, microwaves,
computers, audio/ video etc.). The Power Factor of this type of load is <1 e.g. AC motors
(PF=0.4 to 0.8), Transformers (PF=0.8), AC to DC Switch Mode Power Supplies (PF=0.5
to 0.6) etc. These devices require Apparent Power (VA) from the AC power source. The
Apparent Power is a vectorial sum of Active Power (Watts) and Reactive Power (VAR).
The AC power source has to be sized based on the higher Apparent Power (VA) and also
based on the Starting Surge Power.
2.2 OUTPUT VOLTAGE WAVEFORMS
TIME
180
160
140
120
100
80
60
40
20
0
20
40
60
80
100
120
140
160
180
Modied Sine
Wave sits at
ZERO for some
time and then
rises or falls
VPEAK = 169.68V
Modied Sine Wave
Sine Wave
Pure Sine Wave
crosses Zero Volt
instantaneously
VPEAK = 140 to 160V
VRMS = 120 VAC
VOLTS (+)VOLTS (–)
16.66 ms
Fig. 2.1: Pure and Modied Sine Waveforms for 120 VAC, 60 Hz
The output waveform of the Samlex PST series inverters is a Pure Sine Wave like the
waveform of Utility / Grid Power. Please see Sine Wave represented in the Fig. 2.1 that
also shows Modied Sine Waveform for comparison.
SECTION 2 | General Information

10 | SAMLEX AMERICA INC. SAMLEX AMERICA INC. | 11
SECTION 2 | General Information
In a Sine Wave, the voltage rises and falls smoothly with a smoothly changing phase
angle and also changes its polarity instantly when it crosses 0 Volts. In a Modied Sine
Wave, the voltage rises and falls abruptly, the phase angle also changes abruptly and
it sits at zero V for some time before changing its polarity. Thus, any device that uses a
control circuitry that senses the phase (for voltage / speed control) or instantaneous zero
voltage crossing (for timing control) will not work properly from a voltage that has a
Modied Sine Waveform.
Also, as the Modied Sine Wave is a form of Square Wave, it is comprised of multiple
Sine Waves of odd harmonics (multiples) of the fundamental frequency of the Modied
Sine Wave. For example, a 60 Hz Modied Sine Wave will consist of Sine Waves with
odd harmonic frequencies of 3rd (180 Hz), 5th (300 Hz), 7th (420 Hz) and so on. The high
frequency harmonic content in a Modied Sine Wave produces enhanced radio interfer-
ence, higher heating effect in inductive loads like microwaves and motor driven devices
like hand tools, refrigeration / air-conditioning compressors, pumps etc. The higher
frequency harmonics also produce overloading effect in low frequency capacitors due to
lowering of their capacitive reactance by the higher harmonic frequencies. These capaci-
tors are used in ballasts for uorescent lighting for Power Factor improvement and in
single-phase induction motors as Start and Run Capacitors. Thus, Modied and Square
Wave inverters may shut down due to overload when powering these devices.
2.3 ADVANTAGES OF PURE SINE WAVE INVERTERS
• The output waveform is a Sine Wave with very low harmonic distortion and cleaner
power like Utility / Grid supplied electricity.
• Inductive loads like microwaves, motors, transformers etc. run faster, quieter
and cooler.
• More suitable for powering uorescent lighting xtures containing Power Factor
Improvement Capacitors and single phase motors containing Start and Run Capacitors
• Reduces audible and electrical noise in fans, uorescent lights, audio ampliers, TV,
fax and answering machines, etc.
• Does not contribute to the possibility of crashes in computers, weird print outs and
glitches in monitors.
2.4 SOME EXAMPLES OF DEVICES THAT MAY NOT WORK PROPERLY WITH
MODIFIED SINE WAVE AND MAY ALSO GET DAMAGED ARE GIVEN BELOW:
• Laser printers, photocopiers, and magneto-optical hard drives.
• Built-in clocks in devices such as clock radios, alarm clocks, coffee makers, bread-mak-
ers, VCR, microwave ovens etc. may not keep time correctly.
• Output voltage control devices like dimmers, ceiling fan / motor speed control may
not work properly (dimming / speed control may not function).
• Sewing machines with speed / microprocessor control.

12 | SAMLEX AMERICA INC.
• Transformer-less capacitive input powered devices like (i) Razors, ashlights, night-
lights, smoke detectors etc. (ii) Some re-chargers for battery packs used in hand power
tools. These may get damaged. Please check with the manufacturer of these types of
devices for suitability.
• Devices that use radio frequency signals carried by the AC distribution wiring.
• Some new furnaces with microprocessor control / Oil burner primary controls.
• High intensity discharge (HID) lamps like Metal Halide Lamps. These may get dam-
aged. Please check with the manufacturer of these types of devices for suitability.
• Some uorescent lamps / light xtures that have Power Factor Correction Capacitors.
The inverter may shut down indicating overload.
• Induction Cooktops
2.5 POWER RATING OF INVERTERS
i
INFO
For proper understanding of explanations given below, please refer to deni-
tions of Active / Reactive / Apparent / Continuous / Surge Powers, Power Factor,
and Resistive / Reactive Loads at Section 2.1 under “DEFINITIONS”.
The power rating of inverters is specied as follows:
• Maximum Continuous Running Power Rating
• Surge Power Rating to accommodate high, short duration surge of power required
during start up of certain AC appliances and devices.
Please read details of the above two types of power ratings in Section 2.1 under
“DEFINITIONS”
i
INFO
The manufacturers’ specication for power rating of AC appliances and devices
indicates only the Maximum Continuous Running Power Rating. The high,
short duration surge of power required during start up of some specic types
of devices has to be determined by actual testing or by checking with the
manufacturer. This may not be possible in all cases and hence, can be guessed
at best, based on some general Rules of Thumb.
SECTION 2 | General Information

12 | SAMLEX AMERICA INC. SAMLEX AMERICA INC. | 13
Table 2.1 provides a list of some common AC appliances / devices that require high, short
duration surge of power during start up. An “Inverter Sizing Factor” has been recom-
mended against each which is a Multiplication Factor to be applied to the Maximum
Continuous Running Power Rating (Active Power Rating in Watts) of the AC appliance
/ device to arrive at the Maximum Continuous Running Power Rating of the inverter
(Multiply the Maximum Continuous Running Power Rating (Active Power Rating in
Watts) of the appliance / device by recommended Sizing Factor to arrive at the Maxi-
mum Continuous Running Power Rating of the inverter.
TABLE 2.1: INVERTER SIZING FACTOR
Type of Device or Appliance
Inverter
Sizing Factor
(See note 1)
Air Conditioner / Refrigerator / Freezer (Compressor based) 5
Air Compressor 4
Sump Pump / Well Pump / Submersible Pump 3
Dishwasher / Clothes Washer 3
Microwave (where rated output power is the cooking power) 2
Furnace Fan 3
Industrial Motor 3
Portable Kerosene / Diesel Fuel Heater 3
Circular Saw / Bench Grinder 3
Incandescent / Halogen / Quartz Lamps 3
Laser Printer / Other Devices using Infrared Quartz Halogen Heaters 4
Switch Mode Power Supplies (SMPS): no Power Factor correction 2
Photographic Strobe / Flash Lights 4 (See Note 2)
NOTES FOR TABLE 2.1
1. Multiply the Maximum Continuous Running Power Rating (Active Power Rating in
Watts) of the appliance / device by the recommended Sizing Factor to arrive at the
Maximum Continuous Running Power Rating of the inverter.
2. For photographic strobe / ash unit, the Surge Power Rating of the inverter should be
> 4 times the Watt Sec rating of photographic strobe / ash unit.
SECTION 2 | General Information

14 | SAMLEX AMERICA INC.
3.1 EMI AND FCC COMPLIANCE
These inverters contain internal switching devices that generate conducted and radiated
electromagnetic interference (EMI). The EMI is unintentional and cannot be entirely
eliminated. The magnitude of EMI is, however, limited by circuit design to acceptable
levels as per limits laid down in North American FCC Standard FCC Part 15(B), Class A.
These limits are designed to provide reasonable protection against harmful interference
when the equipment is operated in business / commercial / industrial environments.
These inverters can conduct and radiate radio frequency energy and, if not installed
and used in accordance with the instruction manual, may cause harmful interference to
radio communications.
3.2 REDUCING EMI THROUGH PROPER INSTALLATION
The effects of EMI will also depend upon a number of factors external to the inverter
like proximity of the inverter to the EMI receptors, types and quality of connecting wires
and cables etc. EMI due to factors external to the inverter may be reduced as follows:
- Ensure that the inverter is rmly grounded to the ground system of the building or
the vehicle
- Locate the inverter as far away from the EMI receptors like radio, audio and video
devices as possible
- Keep the DC side wires between the battery and the inverter as short as possible.
- Do NOT keep the battery wires far apart. Keep them taped together to reduce their
inductance and induced voltages. This reduces ripple in the battery wires and im-
proves performance and efciency.
- Shield the DC side wires with metal sheathing / copper foil / braiding:
- Use coaxial shielded cable for all antenna inputs (instead of 300 ohm twin leads)
- Use high quality shielded cables to attach audio and video devices to one another
- Limit operation of other high power loads when operating audio / video equipment
SECTION 3 | Limiting Electro-Magnetic
Interference (EMI)

14 | SAMLEX AMERICA INC. SAMLEX AMERICA INC. | 15
4.1 CHARACTERISTICS OF SWITCHED MODE POWER SUPPLIES (SMPS)
Switch Mode Power Supplies (SMPS) are extensively used to convert the incoming AC
power into various voltages like 3.3V, 5V, 12V, 24V etc. that are used to power vari-
ous devices and circuits used in electronic equipment like battery chargers, computers,
audio and video devices, radios etc. SMPS use large capacitors in their input section for
ltration. When the power supply is rst turned on, there is a very large inrush cur-
rent drawn by the power supply as the input capacitors are charged (The capacitors act
almost like a short circuit at the instant the power is turned on). The inrush current at
turn-on is several to tens of times larger than the rated RMS input current and lasts for
a few milliseconds. An example of the input voltage versus input current waveforms is
given in Fig. 4.1. It will be seen that the initial input current pulse just after turn-on is >
15 times larger than the steady state RMS current. The inrush dissipates in around 2 or 3
cycles i.e. in around 33 to 50 milliseconds for 60 Hz sine wave.
Further, due to the presence of high value of input lter capacitors, the current drawn
by an SMPS (With no Power Factor correction) is not sinusoidal but non-linear as shown
in Fig 4.2. The steady state input current of SMPS is a train of non-linear pulses instead
of a sinusoidal wave. These pulses are two to four milliseconds duration each with a very
high Crest Factor of around 3 (Crest Factor = Peak value ÷ RMS value).
Many SMPS units incorporate “Inrush Current Limiting”. The most common method is
the NTC (Negative Temperature Coefcient) resistor. The NTC resistor has a high resist-
ance when cold and a low resistance when hot. The NTC resistor is placed in series with
the input to the power supply. The cold resistance limits the input current as the input
capacitors charge up. The input current heats up the NTC and the resistance drops
during normal operation. However, if the power supply is quickly turned off and back
on, the NTC resistor will be hot so its low resistance state will not prevent an inrush
current event.
The inverter should, therefore, be sized adequately to withstand the high inrush current
and the high Crest Factor of the current drawn by the SMPS. Normally, inverters have
short duration Surge Power Rating of 2 times their Maximum Continuous Power Rating.
Hence, it is recommended that for purposes of sizing the inverter to accommodate
Crest Factor of 3, the Maximum Continuous Power Rating of the inverter should be > 2
times the Maximum Continuous Power Rating of the SMPS. For example, an SMPS rated
at 100 Watts should be powered from an inverter that has Maximum Continuous Power
Rating of > 200 Watts.
SECTION 4 | Powering Direct / Embedded Switch
Mode Power Supplies (SMPS)

16 | SAMLEX AMERICA INC.
Input voltage
Inrush current
Peak inrush
current Rated steady state
input RMS current
NOTE: Voltage
and current scales
are dierent
Fig 4.1: Inrush current in an SMPS
TIME
Peak Current
RMS Current
Non-linear
Input Current
Pulse
Input Sine
Wave Voltage
Crest Factor = Peak Current = 3
RMS Current
Voltage (+)Voltage (–) Current (+)Current (–)
NOTE: Voltage
and current scales
are dierent
Fig. 4.2: High Crest Factor of current drawn by SMPS
SECTION 4 | Powering Direct / Embedded Switch
Mode Power Supplies (SMPS)

16 | SAMLEX AMERICA INC. SAMLEX AMERICA INC. | 17
5.1 GENERAL
These inverters convert DC battery voltage to AC voltage with an RMS (Root Mean
Square) value of 120 VAC, 60 Hz RMS.
5.2 PURE SINE WAVE OUTPUT WAVEFORM
The waveform of the AC voltage is a pure Sine Waveform that is same as the waveform
of Grid / Utility power (Supplementary information on pure Sine Waveform and its
advantages are discussed in Sections 2.2 to 2.4).
Fig. 5.1 below species the characteristics of 120 VAC, 60 Hz pure Sine Waveform. The
instantaneous value and polarity of the voltage varies cyclically with respect to time. For
example, in one cycle in a 120 VAC, 60 Hz system, it slowly rises in the Positive direction
from 0V to a peak Positive value “Vpeak” = + 169.68V, slowly drops to 0V, changes the
polarity to Negative direction and slowly increases in the Negative direction to a peak
Negative value “Vpeak” = - 169.68V and then slowly drops back to 0V. There are 60 such
cycles in 1 sec. Cycles per second is called the “Frequency” and is also termed “Hertz (Hz)”.
The Time Period of 1 Cycle is 16.66 ms.
TIME
0V
Peak Negative Voltage
- VPEAK = - 169.68V
VRMS = 120 VAC
Peak Positive Voltage
+ VPEAK = + 169.68V
Voltage (+)Voltage (–)
16.66 ms
Fig. 5.1: 120 VAC, 60 Hz Pure Sine Waveform
5.3 PRINCIPLE OF OPERATION
The voltage conversion takes place in two stages. In the rst stage, the DC voltage
of the battery is converted to a high voltage DC using high frequency switching and
Pulse Width Modulation (PWM) technique. In the second stage, the high voltage DC is
converted to 120 VAC, 60 Hz sine wave AC again using PWM technique. This is done by
using a special wave shaping technique where the high voltage DC is switched at a high
frequency and the pulse width of this switching is modulated with respect to a refer-
ence sine wave.
SECTION 5 | Principle of Operation

18 | SAMLEX AMERICA INC.
SECTION 6 | Layout
Fig. 6.1: Layout of PST-3000
Fig 6.1 (a) PST-3000, Front
Fig 6.1 (b) PST-3000, Front - Showing compartment
with terminals for hardwiring
Fig 6.1 (c) PST-3000, Back
1. Three Position Rocker Switch
• – ON - Push top end to switch ON locally
• 0 OFF – Centered to switch OFF locally
• = EXT Switch - Push bottom end to
enable switching ON and OFF by
external switching control
2. Green LED marked “POWER”
3. Red LED marked “OVER LOAD”
4. RED LED marked “OVER TEMP”
5. Air inlet slots for cooling fan
6. NEMA5-20R GFCI Duplex AC Outlet, 20A
maximum
7. Metal strain relief clamp for AC output cable
(for hardwiring)
• Size: Trade Size: ¾”
• Wire size accommodated: 3- Conductor
“Loomex” cable - AWG #14/3 to AWG #8/3
8. Cover plate for compartment containing
L, N and G terminals for hardwiring of AC
output to 120VAC Panelboard
9. Modular Jack RJ-50 (10P10C) marked
“Remote” for connecting optional wired
Remote Control Model RC-300
10. Terminal Block marked “EXT Switch” with
4 terminals for ON / OFF switching using
external control signals
11. Compartment containing L, N and G
terminals for hardwiring of AC output to
120VAC Panelboard
12. Nut and bolt terminal (size 6x32) for
Ground “G” for hardwiring of AC output
to 120VAC Panelboard
13. Terminal Block for Line “L” and Neutral
“N” terminals for hardwiring of AC output
to 120VAC Panelboard
• Terminal hole diameter: 4.15 mm
• Terminal set screw size: M3.5
14. Black Negative (-) DC input terminal – Nut
and bolt: 5/16 in, 18 TPI
15. Black removable plastic cover for Negative
(-) DC input terminal
16. Red Positive (+) DC input terminal – Nut
and bolt: 5/16 in, 18 TPI
17. Red removable plastic cover for Positive (+)
DC input terminal
18. Opening for air outlet from internal fan (fan
is located behind the opening)
19. Chassis Grounding Terminal
• Hole Diameter: 5/16”
• Set screw size: 5/16 x 24TPI
15,17

18 | SAMLEX AMERICA INC. SAMLEX AMERICA INC. | 19
7.1 GENERAL
i
INFO
For complete background information on Lead Acid Batteries and charging
process, please visit www.samlexamerica.com > support > white papers >
White Paper - Batteries, Chargers and Alternators.
Lead-acid batteries can be categorized by the type of application:
1. Automotive service - Starting/Lighting/Ignition (SLI, a.k.a. cranking), and
2. Deep cycle service.
Deep Cycle Lead Acid Batteries of appropriate capacity are recommended for powering
of inverters.
7.2 DEEP CYCLE LEAD ACID BATTERIES
Deep cycle batteries are designed with thick-plate electrodes to serve as primary power
sources, to have a constant discharge rate, to have the capability to be deeply dis-
charged up to 80 % capacity and to repeatedly accept recharging. They are marketed
for use in recreation vehicles (RV), boats and electric golf carts – so they may be referred
to as RV batteries, marine batteries or golf cart batteries. Use Deep Cycle batteries for
powering these inverters.
7.3 RATED CAPACITY SPECIFIED IN AMPERE-HOUR (Ah)
Battery capacity “C” is specied in Ampere-hours (Ah). An Ampere is the unit of measure-
ment for electrical current and is dened as a Coulomb of charge passing through an electri-
cal conductor in one second. The Capacity “C” in Ah relates to the ability of the battery to
provide a constant specied value of discharge current (also called “C-Rate”: See Section 7.6)
over a specied time in hours before the battery reaches a specied discharged terminal
voltage (Also called “End Point Voltage”) at a specied temperature of the electrolyte. As a
benchmark, the automotive battery industry rates batteries at a discharge current or C-Rate
of C/20 Amperes corresponding to 20 Hour discharge period. The rated capacity “C” in Ah
in this case will be the number of Amperes of current the battery can deliver for 20 Hours at
80ºF (26.7ºC) till the voltage drops to 1.75V / Cell. i.e. 10.5V for 12V battery, 21V for 24V bat-
tery and 42V for a 48V battery. For example, a 100 Ah battery will deliver 5A for 20 Hours.
7.4 RATED CAPACITY SPECIFIED IN RESERVE CAPACITY (RC)
Battery capacity may also be expressed as Reserve Capacity (RC) in minutes typically for
automotive SLI (Starting, Lighting and Ignition) batteries. It is the time in minutes a
vehicle can be driven after the charging system fails. This is roughly equivalent to the
conditions after the alternator fails while the vehicle is being driven at night with the
headlights on. The battery alone must supply current to the headlights and the com-
puter/ignition system. The assumed battery load is a constant discharge current of 25A.
SECTION 7 | General Information on Lead Acid
Batteries

20 | SAMLEX AMERICA INC.
SECTION 7 | General Information on Lead Acid
Batteries
Reserve capacity is the time in minutes for which the battery can deliver 25 Amperes at
80ºF (26.7ºC) till the voltage drops to 1.75V / Cell i.e. 10.5V for 12V battery, 21V for 24V
battery and 42V for 48V battery.
Approximate relationship between the two units is:
Capacity “C” in Ah = Reserve Capacity in RC minutes x 0.6
7.5 TYPICAL BATTERY SIZES
The Table 7.1 below shows details of some popular battery sizes:
TABLE 7.1: POPULAR BATTERY SIZES
BCI* Group Battery Voltage, V Battery Capacity, Ah
27 / 31 12 105
4D 12 160
8D 12 225
GC2** 6220
* Battery Council International; ** Golf Cart
7.6 SPECIFYING CHARGING / DISCHARGING CURRENTS: C-RATE
Electrical energy is stored in a cell / battery in the form of DC power. The value of the
stored energy is related to the amount of the active materials pasted on the battery
plates, the surface area of the plates and the amount of electrolyte covering the plates.
As explained above, the amount of stored electrical energy is also called the Capacity of
the battery and is designated by the symbol “C”.
The time in Hours over which the battery is discharged to the “End Point Voltage” for
purposes of specifying Ah capacity depends upon the type of application. Let us denote
this discharge time in hours by “T”. Let us denote the discharge current of the battery
as the “C-Rate”. If the battery delivers a very high discharge current, the battery will be
discharged to the “End Point Voltage” in a shorter period of time. On the other hand,
if the battery delivers a lower discharge current, the battery will be discharged to the
“End Point Voltage” after a longer period of time. Mathematically:
EQUATION 1: Discharge current “C-Rate” = Capacity “C” in Ah ÷ Discharge Time “T”
Table 7.2 below gives some examples of C-Rate specications and applications:
TABLE 7.2: DISCHARGE CURRENT RATES - “C-RATES”
Hours of discharge time “T” till
the “End Point Voltage”
"C-Rate" Discharge Current in Amps =
Capacity "C" in Ah ÷ Discharge Time
"T" in Hrs.
Example of C-Rate
Discharge Currents
for 100 Ah battery
0.5 Hrs. 2C 200A
1 Hrs. 1C 100A
5 Hrs. (Inverter application) C/5 or 0.2C 20A
Table Continues Next Page }
