Samoa LARIUS OMEGA Operating instructions

www.larius.com
ED. 04 - 09/2021
Manuale Cod. 150150
OMEGA
23:1-30:1
II 2 G c IIB T6
OPERATING AND MAINTENANCE MANUAL
EN
PNEUMATIC PISTON PUMP
AIRLESS

www.larius.com
2
Omega 23:1-30:1
ED. 04 - 09/2021 - Cod. 150150
Due to a constant product improvement programme, the factory reserves the right to modify
technical details mentioned in this manual without prior notice.
This manual is to be considered as an English language translation of the original manual in Italian.
The manufacturer shall bear no responsibility for any damages or inconveniences that may arise due to
the incorrect translation of the instructions contained within the original manual in Italian.

www.larius.com
3
Omega 23:1-30:1
ED. 04 - 09/2021 - Cod. 150150
OMEGA 23:1-30:1
Pneumatic piston pump Airless
A
C
D
B
E
H
G
F
I
L
M
Q
R
N
O
P
S
T
U
V
W
X
Z
Y
WE ADVISE THE USE OF THIS EQUIPMENT ONLY BY PROFESSIONAL OPERATORS.
ONLY USE THIS MACHINE FOR USAGE SPECIFICALLY MENTIONED IN THIS MANUAL.
Thank you for choosing a LARIUS S.R.L. product.
As well as the product purchased, you will receive a range of support services
enabling you to achieve the results desired, quickly and professionally.
WARNINGS ............................................................................................................................................................ P. 4
WORKING PRINCIPLE ........................................................................................................................................... P. 5
TECHNICAL DATA .................................................................................................................................................. P. 5
DESCRIPTION OF THE EQUIPMENT .................................................................................................................... P. 7
TRANSPORT AND UNPACKING............................................................................................................................ P. 8
CONDITIONS OF GUARANTEE ............................................................................................................................. P. 8
SAFETY RULES...................................................................................................................................................... P. 8
SISTEMA ANTIGELO.............................................................................................................................................. P. 9
TYPICAL INSTALLATION........................................................................................................................................ P.10
SETTING-UP .......................................................................................................................................................... P.10
FORKING................................................................................................................................................................ P.11
CLEANING AT THE END OF THE WORK............................................................................................................... P.11
ROUTINE MAINTENANCE ..................................................................................................................................... P.12
PROBLEMS AND SOLUTIONS .............................................................................................................................. P.13
DISASSEMBLY OF THE PNEUMATIC MOTOR...................................................................................................... P.14
DISASSEMBLY OF THE PUMPING GROUP.......................................................................................................... P.19
EXPLODED VIEW FOR MOTOR GROUP............................................................................................................... P.22
EXPLODED VIEW FOR STAINLESS STEEL PUMPING GROUP............................................................................ P.24
EXPLODED VIEW FOR CARBON STEEL PUMPING GROUP ............................................................................... P.26
EXPLODED VIEW FOR HIGH PRESSURE LINE FILTER ........................................................................................ P.28
COMPLETE HANDTRUCK ..................................................................................................................................... P.30
AIR GROUP COMPLETE ....................................................................................................................................... P.31
ACCESSORIES....................................................................................................................................................... P.32
ATEX - DESCRIPTION FOR EXPLOSIVE AREAS................................................................................................... P.35
DECLARATION OF CONFORMITY......................................................................................................................... P.37
INDEX

www.larius.com
4
Omega 23:1-30:1
ED. 04 - 09/2021 - Cod. 150150
The table below provides the meaning of the symbols used in this manual in relation to using, earthing, operating, maintaining, and
repairing of this equipment.
WARNINGS
A










FIRE AND EXPLOSION HAZARD

To help prevent fire and explosion:
- Use equipment ONLY in well ventilated area.


- Use only grounded hoses.
               
                


must be stopped immediately.







-




 
regulations.




To help prevent injection, always:








If high pressure fluid pierces your skin, the injury might look like “just a cut”, but it is a serious wound!
Get immediate medical attention.





A

www.larius.com
5
Omega 23:1-30:1
ED. 04 - 09/2021 - Cod. 150150
B
C
PRINCIPIO DI FUNZIONAMENTO
OMEGA pump 23:1 30:1)






Parts of the pump in contact with the material

steel AISI 303 and 420B
Sealing balls: stainless steel AISI 420B

Other parts of the pump

Covering: sheet FE37

TECHNICAL DATA
OMEGA 23:1 OMEGA 23:1
Pump feed air pressure 3-7 bar (40-90 psi) 3-7 bar (40-90 psi)
Masimum pressure of the product 161 bar (2300 psi) 210 bar (3050 psi)
Feed air inlet 3/4” GAS (M) 3/4” GAS (M)
Maximum delivery 14 l/min (3,7 gpm) 12 l/min (3,2 gpm)
Cycles per litre 4 5
Maximum cycles per minute 60 60
Material outlet 1” conico GAS (F) 1” conico GAS (F)
Weight 55 kg 55 kg
Noise pressure level <90 dB (A) <90 dB (A)
Total height 1110 mm 1110 mm
Always observe these instructions carefully
when evaluating the product compatibility and
in case of disposal of some parts of the pump
no more usable, in order to meet the envi-
ronmental regulations on recycling process.

www.larius.com
6
Omega 23:1-30:1
ED. 04 - 09/2021 - Cod. 150150
b
a
b
b
a
a
a
a
a
15 20
2345
GPM
L/MIN
0510 0510 15 20
01 01 2345
0
25
50
75
100
125
0
40
80
120
160
200
BAR BAR
250
500
750
1000
1250
1500
1750
2000
400
800
1200
1600
2000
2400
2800
3200
0
600
1200
1800
2400
3000
0
15
30
45
60
75
90
105
120
0
600
1200
1800
2400
3000
0
15
30
45
60
75
90
105
120
7 bar (100 psi)
5 bar (70 psi)
3 bar (40 psi)
PSI
L/MIN
CFMPSI
L/MIN
CFM
GPM
L/MIN
b
b
b
Fig. 1C
Curve "a": Material outlet pressure


the white zone. Out of this zone the speed must be intermittent.
OMEGA 23:1 OMEGA 30:1
PUMP DELIVERY
MATERIAL OUTLET PRESSURE
AIR CONSUMPTION
PUMP DELIVERY
MATERIAL OUTLET PRESSURE
AIR CONSUMPTION

www.larius.com
7
Omega 23:1-30:1
ED. 04 - 09/2021 - Cod. 150150
1
3
2
6
4
5
D
Fig. 1D
ANTIFREEZE SYSTYEM
DESCRIPTION OF THE EQUIPMENT
Pos. Description
1 Pump feed air inlet
2 Pneumatic motor
3 Material outlet
Pos. Description
4 Fluid inlet
5 Fluid pumping group
6 Eyebolt for pump transport

www.larius.com
8
Omega 23:1-30:1
ED. 04 - 09/2021 - Cod. 150150


          


     


         
  
suitable hoisting equipment for the weight of the installation
or its parts.
 
    

        



due to transportation.
 


the plant through Registered Letter to the Shipping Agent and
to LARIUS.
The conditions of guarantee do not apply in the
following situations:
- improper washing and cleaning of components
causing malfunction, wear or damage to the
equipment or any of its parts;
- improper use of the equipment;
- use that does not conform with applicable
national legislation;
- incorrect or faulty installation;
-modifications,interventionsandmaintenancethat
have not been authorised by the manufacturer;
- use of non-original spare parts or parts that do
not correspond to the specific model;
- total or partial non-compliance with the
instructions provided.
CONDITIONS OF GUARANTEE
The disposal of packaging materials is a customer’s
competence and must be performed in accordance
with the regulations in force in the country where
the plant is installed and used.It is nevertheless
sound practice to recycle packaging materials in an
environment-friendly manner as much as possible.
 
THOSE RISKS STEMMING FROM ACCIDENTS, ABOUT THE
USE OF SAFETY DEVICES FOR THEIR OWN SAFETY AND
ABOUT THE GENERAL RULES FOR ACCIDENT PREVENTION
IN COMPLIANCE WITH INTERNATIONAL REGULATIONS AND
WITH THE LAWS OF THE COUNTRY WHERE THE PLANT IS
USED.
       
COMPLY WITH THE ACCIDENT PREVENTION AND ALSO
ENVIRONMENTAL REGULATIONS IN FORCE IN THE COUNTRY
WHERE THE PLANT IS INSTALLED AND USED.
        
WHERE YOU ARE WORKING CREATES A POTENTIAL RISK
OF ACCIDENTS.
      
STANCE.
        
DAMAGED PARTS AND THE MACHINE CAN WORK PROPERLY.
 
THE REGULATIONS IN FORCE.
        
EQUIPMENT OUT OF THE WORK AREA.
 NEVER EXCEED THE MAXIMUM WORKING PRESSURE
INDICATED.
SAFETY RULES
Readcarefullyandentirelythefollowinginstructions
before using the product. Please save these
instructions in a safe place.
The unauthorised tampering/replacement of one
or more parts composing the machine, the use of
accessories, tools,expendable materialsother than
those recommended by the manufacturer can be a
danger of accident.
The manufacturer will be relieved from tort and
criminal liability.
D
TRANSPORT AND
UNPACKING
E
F

www.larius.com
9
Omega 23:1-30:1
ED. 04 - 09/2021 - Cod. 150150
         
OTHER PEOPLE. THE CONTACT WITH THE CASTING CAN
CAUSE SERIOUS INJURIES.
 
IMMEDIATE MEDICAL ADVICE SPECIFYING THE TYPE OF
THE PRODUCT INJECTED. NEVER UNDERVALUE A WOUND
CAUSED BY THE INJECTION OF A FLUID
       
PRESSURE IN THE CIRCUIT BEFORE PERFORMING ANY
CHECK OR PART REPLACEMENT OF THE EQUIPMENT.
        
REGULARLY THE COMPONENTS OF THE SYSTEM. REPLACE
THE PARTS DAMAGED OR WORN.
   TIGHTEN AND CHECK ALL THE FITTINGS
FOR CONNECTION BETWEEN PUMP, FLEXIBLE HOSE AND
SPRAY GUN BEFORE USING THE EQUIPMENT.
 THE FLUID CONTAINED IN THE FLEXIBLE HOSE CAN BE
VERY DANGEROUS. HANDLE THE FLEXIBLE HOSE CARE-
FULLY. DO NOT PULL THE FLEXIBLE HOSE TO MOVE THE
EQUIPMENT. NEVER USE A DAMAGED OR A REPAIRED
FLEXIBLE HOSE.
 NEVER SPRAY OVER FLAMMABLE PRODUCTS OR SOL-
VENTS IN CLOSED PLACES.
 NEVER USE THE TOOLING IN PRESENCE OF POTENTIALLY
EXPLOSIVE GAS.
The high speed of travel of the product in the hose
can create static electricity through discharges
and sparks. It is suggested to earth the equipment.
The pump is earthed through the earth cable of
the supply.
The gun is earthed through the high pressure
flexible hose.
All the conductors near the work area must be
earthed.
Avoid approaching too much to the pump piston
rod when the pump is working or under pressure.
A sudden movement of the piston rod can cause
wounds or finger squashing.
H
Fig. 1H
SISTEMA ANTIGELO
The machine is equipped with an anti-freeze
system that allows it to work even at very low
temperatures. However, after a few minutes of
operation, the upper metal outer surface cools
dramatically. Avoid touching the area indicated.
Contact of the skin with the low-temperature area
may cause frostbite. Common working clothes
and leather gloves provide adequate protection.
SIf the product to be used is toxic avoid inhalationa
and contact, by using protective gloves, goggles
and suitable face shiedls
Take proper safety measures for the protection
of hearing in case of work near the plant.

www.larius.com
10
Omega 23:1-30:1
ED. 04 - 09/2021 - Cod. 150150
F2 F1
*
The OMEGA pump is generally supplied on support for wall
fastening or on trolley or on double post ram.
     


Fig. 2H
L
I
Fig. 3I
*Int. holes
  
F1F2
          
dilution shown in the table.
DILUITION RECOMMENDED FOR PURE PRODUCT
% water diluition
°C, environmental temperature
10% -5
20% -10
30% -20
40% -25
50% -37
60% -50
NOTE
When the pump is used in places with higher
temperatures, the phenomenon indicated
above may not occur and therefore it is not
necessary to use antifreeze.
SETTING UP
TYPICAL INSTALLATION
CONNECTION TO THE FEED AIR
 For pump feed use a hose with an internal diameter no
lower than 20 mm.
Install at the pump inlet an air pressure regulator
(it is suggested complete with condensate filter
and lubricator). The outlet pressure of the material
is 23 times (OMEGA 23:1) or 30 times (omega 30:1)
the inlet pressure of the pump feed air. Therefore,
it is extremely important to adjust the value of the
feed air pressure.
COLLEGAMENTO DEL TUBO USCITA MATERIALE
 

PUMP FASTENING ON THE HOIST
 

of the double post ram.

www.larius.com
11
Omega 23:1-30:1
ED. 04 - 09/2021 - Cod. 150150
M1
M2
M4
M3
M
Fig. 1M
Fig. 2M
N
WORKING
M1M2



Check all the fittings for connection of the different
components (pump, flexible hose, spray gun, etc.)
before using the equipment.
Store possible dangerous fluids in proper
containers. Their disposal must be performed in
accordance with the regulations in force about
the industrial waste goods.





the spray gun is pressed or the delivery valve is open.


M4M3


           



the air supply to the pump and drain the residual pressure in

valve.
Always avoid pump idling: this operation could
damage the pneumatic motor and the seals.
Always avoid pump idling: this operation could
damage the pneumatic motor and the seals.
PULIZIA DI FINE LAVORO



Stop the air supply to the pump.


           


 

 
pressure.
 
light mineral oil inside the pumping element are suggested.

www.larius.com
12
Omega 23:1-30:1
ED. 04 - 09/2021 - Cod. 150150
Oil ring
Wet cup
Key
Rif. 11504
O
Fig. 1O
MANUTENZIONE ORDINARIA
Always close the compressed air supply and release the pressure in the plant before performing any check or
maintenance of the pump.
 



 
 
.

www.larius.com
13
Omega 23:1-30:1
ED. 04 - 09/2021 - Cod. 150150
P
PROBLEMS AND SOLUTIONS
Inconveniente Causa Soluzione
The pump does not start;  

 


 
 
     


 
Accelerated working and no
pressure of the pump;
 
 
Open the bleeder valve. For ram version,

 
 

 

 
 
     


The pump works, but not
sufficient flow of product;
 


 
 
 
 
       


Leakage of product from the
wet cup
 

of the pumping element.
Always close the compressed air supply and release the pressure in the plant before performing any check or
replacement of parts of the pump.

www.larius.com
14
Omega 23:1-30:1
ED. 04 - 09/2021 - Cod. 150150
Q8
Q9
Q6
Q12
Q13
Q14
Q7
Q14
Q13
Q12
Q6
Q15
Q16
Q10
Q11
Q11
Q10
Q3
Q2
Q1
Q4
Q5
Q
Fig. 1Q
Coupling sleeve
 
group from the motor.

 Q1Q2).
 Q3
Q4Q5
 Q6Q7).
 Q8
Q9Q7Q10
Q11
 Q12Q13
Q14
guide rod, the guide rod slides into the roller pushing piston and

parts.
 Q10Q11
them if damaged.
 Q15Q16.
Always close the compressed air supply
and release the pressure in the plant before
disassembling the pneumatic motor of the pump.
DISASSEMBLY OF THE
PNEUMATIC MOTOR

www.larius.com
15
Omega 23:1-30:1
ED. 04 - 09/2021 - Cod. 150150
Q18 Q19 Q17 Q19 Q18
Q24
Q25
Q26
Q27
Q28
Q29
Q20
Q21
Q17
Q22
Q23
Fig. 2Q
Fig. 3Q Fig. 4Q
 Pull upwards the seatQ17Q18
Q19
 Q20Q20
Q22
 Q23Q17.
 Q22Q23-

.
 Q24Q25
Q26Q27
Handle with care the manifold. The edges of its
plate are very sharp.
Important: do not remove the other manifold if
not necessary (it will facilitate the fastening of
the manifold removed).
 Q28
Q29

www.larius.com
16
Omega 23:1-30:1
ED. 04 - 09/2021 - Cod. 150150
Q30
Q31
Q32
Q33
Q34
Q36
Q35
Q38
Q37
Fig. 5Q
Fig. 6Q
Warning: tighten here
  Q30
to the washer Q31 Q30
is undamaged.
     Q32     Q33
 Q34(do not bend it during
extraction in order to avoid that motor piston may damage the
internal surface of the cylinder).
  Q35.
  Q38is undamaged.
           (see
illustration)Q37
  Q38.
  Q38with vaseline grease before inserting
it into the housing of the piston rod.
 
 Q37(application of a sealant on the thread
is advisable).

www.larius.com
17
Omega 23:1-30:1
ED. 04 - 09/2021 - Cod. 150150
Q52
Q48
Q43
Q41
Q42
Q40
Q39
Q47
Q46
Q45
Q44
Q51
Q50
Q49
Q44
Controllare l'anello di tenuta
  Q39is undamaged.
  Q40.
  Q41with a thin layer of
vaseline grease.
  Q42 Q41
  Q41on the support Q39(respect the
position) and at the same time insert the piston rod into the
support.
  Q43
Fig. 7Q
Fig. 8Q
 Insert into the motor rod Q44the washer Q45.
  Q46
(turn it slowly following the direction of the thread)
 Q41.
     Q47and the washer Q48  
support.
  Q44on the motor rod Q49. Insert the seat
Q50, the washer Q51 Q52
Adjust bush and lock nut so as the rod (Q44)
just out of about 1 mm from the lock nut (see
illustration).

www.larius.com
18
Omega 23:1-30:1
ED. 04 - 09/2021 - Cod. 150150
Q68
Q63
Q60
Q58
Q56 Q57
Q64
Q65
Q66
Q59
Q61
Q62
Q67
Q66
Q69
Q53 Q54 Q55
Q56
Q53
 Insert the springs Q53 Q54Q55
Position the seat on the pump support and lay the manifold
Q56Q57
         
         
       

of the seat must be about 0,8 mm.
 Rub the rollersQ58Q59
Q60
 Q61Q62
Q60.
 Grease the roller pushing pistonsQ63
Q64Q65Q60
 Fasten without tightening the ring nutsQ66   
Q60.
          
Q68Q67
 Q66Q69).
 
line:
Fig. 9Q
Fig. 10Q

www.larius.com
19
Omega 23:1-30:1
ED. 04 - 09/2021 - Cod. 150150
R1
R2
R
Fig. 1R

 
 R1
 R2
Coupling sleeve
SMONTAGGIO DEL GRUPPO POMPANTE
Chiudere la fornitura di aria compressa e scaricare la pressione nell’impianto prima di procedere allo smontaggio
del gruppo pompante. Se il prodotto che si sta utilizzando è tossico si consiglia di seguire la procedura di pulizia
di pag. 8, onde evitare il contatto con il prodotto durante lo smontaggio del pompante.
Always close the compressed air supply and release the pressure in the plant before disassembling the pumping
group. If the product being used is toxic, it is suggested to follow the cleaning procedure on page 8 to avoid the
contact with the product during the disassembling of the pumping element.

www.larius.com
20
Omega 23:1-30:1
ED. 04 - 09/2021 - Cod. 150150
R4
R3
R5

 R3R4
 R5.
Tie rod
Fig. 3R
Fig. 2R
