Samsung AC100JN4CEH User manual

4 Way Cassette Type
AC071JN4CEH
AC100JN4CEH
AC125JN4CEH
Air Conditioner
user manual
imagine the possibilities
Thank you for purchasing this Samsung product.

2
Contents
Safety precautions......................................................................................................... 4
Checking before use ......................................................................................................12
Viewing the parts.........................................................................................................14
Cleaning and maintaining the air conditioner .............................................................................15
Troubleshooting..........................................................................................................18
Appendix.................................................................................................................21
For information on Samsung’s environmental commitments and product-specic regulatory obligations, e.g. REACH,
WEEE, Batteries, visit : samsung.com/uk/aboutsamsung/samsungelectronics/corporatecitizenship/data_corner.html
Correct Disposal of This Product
(Waste Electrical & Electronic Equipment)
(Applicable in countries with separate collection systems)
This marking on the product, accessories or literature indicates that the product and its electronic accessories (e.g.
charger, headset, USB cable) should not be disposed of with other household waste at the end of their working life.
To prevent possible harm to the environment or human health from uncontrolled waste disposal, please separate
these items from other types of waste and recycle them responsibly to promote the sustainable reuse of material
resources.
Household users should contact either the retailer where they purchased this product, or their local government
oce, for details of where and how they can take these items for environmentally safe recycling.
Business users should contact their supplier and check the terms and conditions of the purchase contract. This
product and its electronic accessories should not be mixed with other commercial wastes for disposal.

3
ENGLISH
Safety precautions
Before using your new air conditioner, please read this manual thoroughly to ensure that you know
how to safely and eciently operate the extensive features and functions of your new appliance.
Because the following operating instructions cover various models, the characteristics of your air
conditioner may dier slightly from those described in this manual. If you have any questions, call
your nearest contact center or nd help and information online at www.samsung.com.
These warning signs are here to prevent injury to you and others. Please follow them carefully.
Important safety symbols and precautions :
WARNING Hazards or unsafe practices that may result in severe personal injury
or death.
CAUTION Hazards or unsafe practices that may result in minor personal injury
or property damage.
Follow directions.
Do NOT attempt.
Make sure the machine is grounded to prevent electric shock.
Unplug the power plug from the wall socket.
Do NOT disassemble.
FOR INSTALLATION WARNING
Use the power line with the power specications of the product or higher and use
the power line for this appliance only. In addition, do not use an extension line.
f Extending the power line may result in electric shock or re.
f Do not use an electric transformer. It may result in electric shock or re.
f If the voltage/frequency/rated current condition is dierent, it may cause re.
The installation of this appliance must be performed by a qualied technician or
service company.
f Failing to do so may result in electric shock, re, explosion, problems with the
product, or injury.
Install a switch and circuit breaker dedicated to the air conditioner.
f Failing to do so may result in electric shock or re.
Fix the outdoor unit rmly so that the electric part of the outdoor unit is not
exposed.
f Failing to do so may result in electric shock or re.

4
Safety precautions
FOR INSTALLATION WARNING
Do not install this appliance near a heater, inammable material. Do not install this
appliance in a humid, oily or dusty location, in a location exposed to direct sunlight
and water (rain drops). Do not install this appliance in a location where gas may
leak.
f This may result in electric shock or re.
Never install the outdoor unit in a location such as on a high external wall where it
could fall.
f If the outdoor unit falls, it may result in injury, death or property damage.
This appliance must be properly grounded. Do not ground the appliance to a gas
pipe, plastic water pipe, or telephone line.
f Failure to do so may result in electric shock, re, an explosion, or other problems
with the product.
f Never plug the power cord into a socket that is not grounded correctly and make
sure that it is in accordance with local and national codes.
FOR INSTALLATION CAUTION
Install your appliance on a level and hard oor that can support its weight.
f Failing to do so may result in abnormal vibrations, noise, or problems with the
product.
Install the draining hose properly so that water is drained correctly.
f Failing to do so may result in water overowing and property damage.
When installing the outdoor unit, make sure to connect the draining hose so that
draining is performed correctly.
f The water generated during the heating operation by the outdoor unit may
overow and result in property damage. In particular, in winter, if a block of ice falls,
it may result in injury, death or property damage.

5
ENGLISH
FOR POWER SUPPLY WARNING
When the circuit breaker is damaged, contact your nearest service center.
Do not pull or excessively bend the power line. Do not twist or tie the power line. Do
not hook the power line over a metal object, place a heavy object on the power line,
insert the power line between objects, or push the power line into the space behind
the appliance.
f This may result in electric shock or re.
FOR POWER SUPPLY CAUTION
When not using the air conditioner for a long period of time or during a thunder/
lightning storm, cut the power at the circuit breaker.
f Failing to do so may result in electric shock or re.
FOR USING WARNING
If the appliance is ooded, please contact your nearest service center.
f Failing to do so may result in electric shock or re.
If the appliance generates a strange noise, a burning smell or smoke, unplug the
power plug immediately and contact your nearest service center.
f Failing to do so may result in electric shock or re.
In the event of a gas leak (such as propane gas, LP gas, etc.), ventilate immediately
without touching the power line. Do not touch the appliance or power line.
f Do not use a ventilating fan.
f A spark may result in an explosion or re.
To reinstall the air conditioner, please contact your nearest service center.
f Failing to do so may result in problems with the product, water leakage, electric
shock, or re.
f A delivery service for the product is not provided. If you reinstall the product in
another location, additional construction expenses and an installation fee will be
charged.
f Especially, when you wish to install the product in an unusual location such as in an
industrial area or near the seaside where it is exposed to the salt in the air, please
contact your nearest service center.

6
Safety precautions
FOR USING WARNING
Do not touch the circuit breaker with wet hands.
f This may result in electric shock.
Do not strike or pull the air conditioner with excessive force.
f This may result in re, injury, or problems with the product.
Do not place an object near the outdoor unit that allows children to climb onto the
machine.
f This may result in children seriously injuring themselves.
Do not turn the air conditioner o with the circuit breaker while it is operating.
f Turning the air conditioner o and then on again with the circuit breaker may cause
a spark and result in electric shock or re.
After unpacking the air conditioner, keep all packaging materials well out of the
reach of children, as packaging materials can be dangerous to children.
f If a child places a bag over its head, it may result in suocation.
Do not insert your ngers or foreign substances into the outlet when the air
conditioner is operating or the front panel is closing.
f Take special care that children do not injure themselves by inserting their ngers
into the product.
Do not touch the front panel with your hands or ngers during the heating
operation.
f This may result in electric shock or burns.
Do not insert your ngers or foreign substances into the air inlet/outlet of the air
conditioner.
f Take special care that children do not injure themselves by inserting their ngers
into the product.
Do not use this air conditioner for long periods of time in badly ventilated locations
or near inrm people.
f Since this may be dangerous due to a lack of oxygen, Open a window at least once
an hour.
If any foreign substance such as water has entered the appliance, cut the power by
unplugging the power plug and turning the circuit breaker o and then contact
your nearest service center.
f Failing to do so may result in electric shock or re.

7
ENGLISH
FOR USING WARNING
Do not attempt to repair, disassemble, or modify the appliance yourself.
f Do not use any fuse (such as copper, steel wire, etc.) other than the standard fuse.
f Failing to do so may result in electric shock, re, problems with the product, or
injury.
FOR USING CAUTION
Do not place objects or devices under the indoor unit.
f Water dripping from the indoor unit may result in re or property damage.
Check that the installation frame of the outdoor unit is not broken at least once a
year.
f Failing to do so may result in injury, death or property damage.
Max current is measured according to IEC standard for safety and current is
measured according to ISO standard for energy eciency.
Do not stand on top of the appliance or place objects (such as laundry, lighted
candles, lighted cigarettes, dishes, chemicals, metal objects, etc.) on the appliance.
f This may result in electric shock, re, problems with the product, or injury.
Do not operate the appliance with wet hands.
f This may result in electric shock.
Do not spray volatile material such as insecticide onto the surface of the appliance.
f As well as being harmful to humans, it may also result in electric shock, re or
problems with the product.
Do not drink the water from the air conditioner.
f The water may be harmful to humans.
Do not apply a strong impact to the remote controller and do not disassemble the
remote controller.
Do not touch the pipes connected with the product.
f This may result in burns or injury.
Do not use this air conditioner to preserve precision equipment, food, animals,
plants or cosmetics, or for any other unusual purposes.
f This may result in property damage.
Avoid directly exposing humans, animals or plants from the air ow from the air
conditioner for long periods of time.
f This may result in harm to humans, animals or plants.

8
Safety precautions
FOR USING CAUTION
This appliance is not intended for use by persons (including children) with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge,
unless they have been given supervision or instruction concerning use of the
appliance by a person responsible for their safety. Children should be supervised to
ensure that they do not play with the appliance.
For use in Europe: This appliance can be used by children aged from 8 years and
above and persons with reduced physical, sensory or mental capabilities or lack
of experience and knowledge if they have been given supervision or instruction
concerning use of the appliance in a safe way and understand the hazards involved.
Children shall not play with the appliance. Cleaning and user maintenance shall not
be made by children without supervision.
FOR CLEANING WARNING
Do not clean the appliance by spraying water directly onto it. Do not use benzene,
thinner, alcohol or acetone to clean the appliance.
f This may result in discoloration, deformation, damage, electric shock or re.
Before cleaning or performing maintenance, unplug the air conditioner from the
wall socket and wait until the fan stops.
f Failing to do so may result in electric shock or re.
FOR CLEANING CAUTION
Take care when cleaning the surface of the heat exchanger of the outdoor unit since
it has sharp edges.
f To avoid cutting your ngers, wear thick cotton gloves when cleaning it.
Do not clean the inside of the air conditioner by yourself.
f For cleaning inside the appliance, contact your nearest service center.
f When cleaning the internal lter, refer to the descriptions in the‘Cleaning and
maintaining the air conditioner’section.
f Failure to do may result in damage, electric shock or re.

9
ENGLISH
Checking before use
Operation ranges
The table below indicates the temperature and humidity ranges the air conditioner can be
operated within. Refer to the table for ecient use.
MODE OPERATIONAL TEMPERATURE INDOOR HUMIDITY IF OUT OF CONDITIONS
INDOOR OUTDOOR
COOLING 18˚C to 32˚C -20˚C to 50˚C 80% or less Condensation may occur on the indoor unit
with risk to have either water blow o or
drops on the oor.
Internal protection triggers and the air
conditioner will stop.
DRYING 18˚C to 32˚C -20˚C to 50˚C -
HEATING 27˚C or less -25˚C to 24˚C - Internal protection triggers and the air
conditioner will stop.
• Be sure to install the unit under circumstances within the allowable range of
temperature. (Extended operation range down to -25 °C in heating.)
CAUTION
• The standardized temperature for heating is 7˚C. If the outdoor temperature drops to 0˚C or below, the heating
capacity can be reduced depending on the temperature condition.
• If the cooling operation is used at over 32˚C(indoor temperature), it does not cool at its full capacity.
NOTE
• The use of the air conditioner at a relative humidity above the expected one (80%)
may cause the formation of condensate and the leakage of water drops on the
oor.
CAUTION
Maintaining your air conditioner
Internal protections via the unit control system
f This internal protection operates if an internal fault occurs in the air conditioner.
Type Description
Against cold air The internal fan will be o to block cold air when the heat pump is heating.
Defrost cycle The internal fan will be o to block cold air when the heat pump is heating.
Anti-Freezing of Indoor Heat
Exchanger
The compressor will be o if the heat exchanger temp of indoor unit decrease to 0°C or
more to protect the ice on the heat exchanger.
Protect compressor The air conditioner does not start operating immediately to protect the compressor of the
outdoor unit after it has been started.
• If the heat pump is operating in Heat mode, Defrost cycle is actuated to remove frost from an outdoor unit that
may have deposited at low temperatures. The internal fan is switched o automatically and restarted only after
the Defrost cycle is completed.
NOTE

10
Checking before use
Tips on using air conditioner
Here are some tips that you would follow when using your air conditioner.
TOPIC RECOMMENDATION
Cooling
• If current outside temperatures are much higher than the selected
indoor temperature, it may take time to bring the inner temperature to
the desired coolness.
• Avoid drastically turning down the temperature. Energy is wasted and
the room does not cool faster.
Heating
• Since the air conditioner heats the room by taking heat energy
from outdoor air, the heating capacity may decrease when outdoor
temperatures are extremely low. If you feel the air conditioner
insuciently heats, using an additional heating appliance in
combination with the air conditioner is recommended.
Frost
• When the air conditioner runs in Heat mode, due to temperature
dierence between the unit and the outside air, frost will form.
If this happens:
- The air conditioner stops heating.
- The air conditioner will operate automatically in Defrost mode for
10minutes.
- The steam produced on the outdoor unit in Defrost mode is safe.
No intervention is required; after about 10 minutes, the air conditioner
operates again normally.
❈The unit will not operate when it starts to de-ice.
Fan • Fan may not operate for about 3~5 minutes at the beginning to
prevent any cold blasts while the air conditioner is warming up.
High indoor/
outdoor
temperatures
• If both indoor and outdoor temperatures are high and the air
conditioner is running in Heat mode, the outdoor unit’s fan and
compressor may stop at times. This is normal; wait until the air
conditioner turns on again.

11
ENGLISH
TOPIC RECOMMENDATION
Power failure
• If a power failure occurs during the operation of the air conditioner, the
operating immediately stops and unit will be o. When power returns,
the air conditioner will run automatically.
Protection
mechanism
• If the air conditioner has just been turned on after operation stops or
being plugged in, cool/ warm air does not come out for 3 minutes to
protect the compressor of the outdoor unit.
Automatic air
ow blade
control
• If the air conditioner is operating in abnormal conditions (such as
operating the air conditioner with windows open or when small
capacity indoor unit is installed and operating in a room that is too
large) indoor can become very humid when the angle of the air ow
blade is small and performance of the product may decrease. When
indoor humidity increases, indoor unit will automatically detect it and
open the air ow blade in wider angle to make sure that performance
of the product is stable.

12
Viewing the parts
Main parts
Display
Air ow blade
Air lter (under the grille)
Air intake
Indicator
Remote control sensor
Timer indicator
Removing frost indicator
On/O operation indicator
Filter reset indicator
• Your air conditioner and display may look slightly dierent from the illustration shown above depending on
your model.
NOTE
Cleaning and maintaining the air conditioner
Cleaning the exterior
Wipe the surface of the unit with a slightly wet or dry cloth when needed.
Wipe o dirt of odd-shaped area by using a soft brush.
• Do not use Benzene or Thinner.
They may damage the surface of the air
conditioner and can create a risk of re.
CAUTION

13
ENGLISH
Cleaning air lter and grille
Pull out the Air lter.
Detach the front grille.
f Remove the safety clip rst and then remove the
hinge. Pull the green switch on the hinge part
down and then press and pull the hinge part to
remove the grille. (There are two hinges on the
grille and you must apply this step on both of
them to remove the grille.)
❋ If you want to clean the lter only, you do not
have to detach the grille. Follow step 4 and 5
Open the front grille.
f Open the blades on the left and right side of the
Samsung logo. Press both of the levers and pull the
grille downward. Two safety clips are mounted to the
front grille to prevent it from dropping.
Insert the Air lter back in its original position.
f You will hear a click sound when the Air lter is
properly placed.
Attach the front grille.
f Reverse the above steps to attach the front grille.
Clean the grille and Air lter with a vacuum cleaner
or soft brush. If dust is too heavy, then rinse it with
running water and dry it in a ventilated area.
f For best conditions, repeat every two weeks.
f If the Air lter dries in a conned (or humid) area,
odors may generate. If it occurs, re-clean and dry it
in a well-ventilated area.
the
Air
lter
.
• The illustration shown above may dier from yours depending on your model.
• After cleaning the lter, press the Filter Reset button on the remote control for 2 seconds to reset the lter
schedule. Filter sign indicator will be on for cleaning time.
• If the angle on the air ow blades has been changed by user due to opening the front grille for installation or
maintenance, you must turn o the circuit breaker and turn it on again before using the air conditioner.
Otherwise, angles of the each angle can be dierent or some of the blade may not close when the product is o.
NOTE

14
Cleaning and maintaining the air conditioner
If the air conditioner will not be used for an extended period of time, dry the air conditioner to maintain it in best condition.
1. Dry the air conditioner thoroughly by operating in Fan mode for 3 to 4 hours and
disconnect the power plug.
There may be internal damage if moisture is left in components.
2. Before using the air conditioner again, dry the inner components of the air conditioner
again by running in Fan mode for 3 to 4 hours. This helps remove odors which may have
generated from dampness.
Periodical checks
Refer to the following chart to maintain the air conditioner properly.
Type Description Monthly Every 4
months Once a year
Indoor unit
Clean the air lter (1) ●
Clean the condensate drain pan (2) ●
Thoroughly clean the heat exchanger (2) ●
Clean the condensate drain pipe (2) ●
Replace the remote control batteries (1) ●
Outdoor unit
Clean the heat exchanger on the outside of the unit (2) ●
Clean the heat exchanger on the inside of the unit (2) ●
Clean the electric components with jets of air (2) ●
Verify that all the electric components are rmly tightened (2) ●
Clean the fan (2) ●
Verify that all the fan assembly is rmly tightened (2) ●
Clean the condensate drain pan (2) ●
●: This check mark requires checking the indoor/outdoor unit periodically, following to the description to maintain the air
conditioner properly.
1) The described operations should be performed more frequently if the area of installation is very dusty.
2) These operations must always be performed by qualied personnel. For more
detailed information, see the installation part in the manual.
CAUTION

15
ENGLISH
Troubleshooting
Refer to the following chart if the air conditioner operates abnormally. This may save time and
unnecessary expenses.
PROBLEM SOLUTION
The air conditioner
does not operate
immediately after it has
been restarted.
• Because of the protective mechanism, the appliance does not
start operating immediately to keep the unit from overloading.
The air conditioner will start in 3 minutes.
The air conditioner does
not work at all.
• Check that the power plug is properly connected. Insert the
power plug into the wall socket correctly.
• Check if the circuit breaker is switched o.
• Check if there is a power failure.
• Check your fuse. Make sure it is not blown out.
The temperature does
not change.
• Check if you selected Fan mode.
Press the Mode button on the remote control to select another
mode.
The cool air does not
come out of the air
conditioner.
• Check if the set temperature is higher (lower) than the current
temperature. Press the Temperature button on the remote
control to change the set temperature. Press the Temperature
button to decrease or increase the temperature.
• Check if the air lter is blocked by dirt. Clean the air lter every
two weeks.
• Check if the air conditioner has just been turned on. If so, wait 3
minutes. Cool air does not come out to protect the compressor
of the outdoor unit.
• Check if the air conditioner is installed in a place with a direct
exposure to sunlight. Hang curtains on windows to boost
cooling eciency.
• Check if the cover or any obstacle is not near the outdoor unit.
• Check if the refrigerant pipe is too long.
• Check if the air conditioner is only available in Cool mode.
• Check if the remote control is only available for cooling model.
The fan speed does not
change.
• Check if you selected Auto or Dry mode.
The air conditioner automatically adjusts the fan speed to Auto
in Auto/Dry mode.
Timer function does not
set.
• Check if you press the Power button on the remote control after
you have set the time.

16
PROBLEM SOLUTION
Odors permeate in the
room during operation.
• Check if the appliance is running in a smoky area or if there is a
smell entering from outside. Operate the air conditioner in Fan
mode or open the windows to air out the room.
The air conditioner
makes a bubbling
sound.
• A bubbling sound may be heard when the refrigerant is
circulating through the compressor. Let the air conditioner
operate in a selected mode.
• When you press the Power button on the remote control, noise
may be heard from the drain pump inside the air conditioner.
Water is dripping from
the air ow blades.
• Check if the air conditioner has been cooling for an extended
period of time with the air ow blades pointed downwards.
Condensation may generate due to the dierence in
temperature.
Remote control is not
working.
• Check if your batteries are depleted.
• Make sure batteries are correctly installed.
• Make sure nothing is blocking your remote control sensor.
• Check that there are strong lighting apparatus near the air
conditioner. Strong light which comes from uorescent bulbs or
neon signs may interrupt the electric waves.
The air conditioner
does not turn on or o
with the wired remote
control.
• Check if you set the wired remote control for group control.
The wired remote
control does not
operate.
• Check if TEST indicator is displayed on the wired remote control.
If so, turn o the unit and switch o the circuit breaker. Call your
nearest contact center.
The indicators of the
digital display ashes.
• Press the Power button on the remote control to turn the unit
o and switch the circuit breaker o. Then, switch it on again.
Troubleshooting

17
ENGLISH
Appendix
Model specication (Weight and dimension)
Type Model Net weight (kg) Net dimension [W*D*H(mm)]
Indoor unit
AC071JN4CEH 18 840*840*288
AC100JN4CEH 20 840*840*288
AC125JN4CEH 20 840*840*288

QUESTIONS OR COMMENTS?
COUNTRY CALL OR VISIT US ONLINE AT
UK 0330 SAMSUNG (7267864) www.samsung.com/uk/support
IRELAND (EIRE) 0818 717100 www.samsung.com/ie/support
GERMANY 06196 77 555 77 *OTH www.samsung.com/de/support
