Samsung SH09BWHA Series User manual

INDOOR UNIT
SH09BWHA
SH12BWHA
OUTDOOR UNIT
SH09BWHAX
SH12BWHAX
SERVICE Manual
CONTENTSAIR CONDITIONER
11. Product Specifications
12. Operating Instructions
13. Disassembly and Reassembly
14. Refrigerating Cycle Diagram
15. Set Up the Model Option
16. Troubleshooting
17. Exploded Views and Parts List
18. Block Diagram
19. PCB Diagram
10. Wiring Diagram
ROOM AIR CONDITIONER
DB98_19047A(1)_co 4/21/04 2:26 PM Page 3

1Samsung Electronics
1. Product Specifications
1-1 Table
Perfor-
mance
Power
Size
Model
Item
Type
Cooling kW
Heating kW
Dehumidifying |/h
Air Volume Cooling m3/min
Heating
Noise Cooling dB
Heating
Energy Efficiency Ratio Cooling W/W
Heating
Power V-Hz
Power Consumption Cooling W
Heating
Operating Current Cooling A
Heating
Power Factor Cooling %
Heating
Starting Current A
Length m
Power Cord Number of Core Wire
Capacity A
Outer Dimension Width x Height mm
x Depth inch
Weight(Net) kg
Refrigerant Pipe Liquid mm x L(m)
GAS mm x L(m)
Drain Hose D x L(mm)
Type
Compressor Motor Type
Rated Output
Oil Type
Type
Blower Motor Type
Rated Output W
Heat Exchanger
Refrigerant Control Unit
Freezer Oil Capacity cc
Refrigerant to Change(R410A) g
Protection Device(OLP)
Cooling Test Condition
Maximum Operation Condition
SH09BWHASH12BWHA
INDOOR UNIT : DB27˚C WB19˚C OUTDOOR UNIT : DB35˚C WB24˚C
INDOOR UNIT : DB32˚C WB23˚C OUTDOOR UNIT : DB43˚C WB26˚C
Indoor unit Outdoor unit
Wall-mounted
2.65(1.40~3.50)
3.60(1.40~4.40)
1.4
8.5 25
9.5 25
40 53
40 53
3.79
3.83
1, 220-240 / 50
700(315~1,070)
940(285~1,240)
3.3(1.7~5.0)
4.4(1.6~5.4)
94.4
97.3
10↓
-
-
250V, 15A
825x285x189 720x548x265
32.5x11.2 x7.44 28.4x21.6x10.4
8.4 33.2
ø6.35 x 7.5
ø9.52 x 7.5
ø18 x 550
Rotary(SAMSUNG)
3 PHASE DC MOTOR
860
PVE(FV50S)
Cross-flow Propeller
steel steel
16 20
2ROW 12STEP 2ROW 24STEP
EEV + CAPILLARY TUBE
320
1,000
204CTB
Indoor unit Outdoor unit
Wall-mounted
3.50(1.40~4.00)
4.20(1.40~5.10)
1.9
8.7 25
9.7 25
41 53
41 53
3.27
3.62
1, 220-240 / 50
1,070(315~1,350)
1,160(290~1,575)
5.0(1.7~6.0)
5.4(1.6~6.9)
98.6
98.6
10↓
-
-
250V, 15A
825x285x189 720x548x265
32.5x11.2x7.44 28.4x21.6x10.4
8.4 33.2
ø6.35 x 7.5
ø9.52 x 7.5
ø18 x 550
Rotary(SAMSUNG)
3 PHASE DC MOTOR
860
PVE(FV50S)
Cross-flow Propeller
steel resin
16 25
2ROW 12STEP 2ROW 24STEP
EEV + CAPILLARY TUBE
320
1,000
204CTB
DB98_19047A(1)_1 4/21/04 2:26 PM Page 1

Samsung Electronics2
1-2 Pressure Graph
■SH09BWHA
Outdoor Temp. (˚C)
Pressure (kgf/cm2G)
Indoor Temp. (˚C)
■SH12BWHA
Outdoor Temp. (˚C)
Pressure (kgf/cm2G)
Indoor Temp. (˚C)
DB98_19047A(1)_1 4/21/04 2:26 PM Page 2

3Samsung Electronics
2. Operating Instructions
2-1 The Feature of Key in remote control
FUNCTIONBUTTONNo
1
2
3
4
5
6
7
8Sleep button.
The sleep timer can be used when you are cooling or heating your room to switch the air conditioner
off automatically after a period of 6 hours.
Fan speed adjustment button.
Each time you press this button, FAN SPEED is changed in the following order.
Temperature adjustment button(DOWN).
The temperature is decreased by the pressing the temperature button.
(DOWN)
On/Off button.
Press the button to stop or run the air conditioner.
Mode selection button.
Each time you press this button,
mode is changed in the following order
(UP)
Flap button.
It adjusts the airflow to upward and downward.
Temperature adjustment button(UP).
The temperature is increased by the pressing the temperature button.
Turbo button.
The air conditioner cools or heats the room as quickly as possible.
After 30minutes, the air conditioner is reset automatically to the previous mode.
Energy saving button.
If you wish to save energy when using your air conditioner, select the Energy saving
mode with the button.
√√In case of Heat pump model
√√In case of Cooling only model
: Auto Mode : Fan Mode
: Cool Mode : Heat Mode
: Dry Mode
Automatic(rotated : )
Low
Medium
High
DB98_19047A(1)_1 4/21/04 2:26 PM Page 3

Samsung Electronics4
Operating Instructions
FUNCTIONBUTTONNo
9
10
11
12
Timer Set/Cancel button.
After setting On Timer or Off Timer, press the button to set it completely.
And press the button again to cancel On Timer or Off Timer set.
Battery life indicator.
If you want to check the battery life, press the button.
The longer will remain the battery life.
If one battery life indicator remains, replace new batteries.
On Timer button.
The On Timer enables you to switch on the air conditioner automatically after
a given period of time that is from 1 hour to 24 hours.
To set the operating time, press the button one or more times until the required
time display.
Off Timer button.
The Off Timer enables you to switch off the air conditioner automatically after
a given period of time that is from 1 hour to 24 hours.
To set the operating time, press the button one or more times until the required
time display.
DB98_19047A(1)_1 4/21/04 2:26 PM Page 4

Operating Instructions
5Samsung Electronics
1. AUTO MODE : In this mode, operation mode(COOL,
HEAT) is selected automatically by the difference
between the setting and room temperature.
√√In case of Heat pump model.
√√Cooling or heating operation is selected based on
difference of Ts and Tr. Cooling and heating operation
is automatically interchanged during an operation.
√√In case of Cooling only model.
Ts : Setting temperature.
2. COOL MODE : The unit operates according to the
difference between the setting and room temperature.
(16°C~30°C)
3. HEAT MODE(In case of Heat pump model) :
The unit operates according to the difference between the
setting and room temperature.(16°C~30°C)
*Prevention against cold wind : In order to prevent the
cool air from flowing out at the heat mode, the indoor fan
does not operate or operates very slowly in the following
cases At this time, the indoor heat exchanger will be
preheating.
- For 3~5 minutes after the initial operation
- For deicing operation
- The operation of an indoor fan in accordance with the
temperature of an indoor heat exchanger
*High temperature release function : It is a function to
detect an outdoor overload by the sensor of an indoor
heat exchanger and to turn the outdoor fan or the
compressor ON/OFF for safety.
*Deice : Deicing operation is controlled by indoor unit's
heat exchanger temperature and accumulating time of
compressor's operation.
Deice ends by sensing of the processing time by deice
condition.
4. DRY MODE : Has 4 states, each determined by room
temperature.
The unit operates in DRY mode.
*Compressor ON/OFF time is controlled compulsorily
(can not set up the fan speed, always breeze).
*Protective function : Low temperature release.
(Prevention against freeze)
5. TURBO MODE : This mode is available in AUTO, COOL,
HEAT, DRY, FAN MODE.
When this button is pressed at first, the air conditioner is
operated "powerful" state for 30 minutes regardless of the
setting temperature, room temperature.
When this button is pressed again, or when the operating
time is 30 minutes, turbo operation mode is canceled and
returned to the previous mode.
*But, if you press the TURBO button in DRY or FAN
mode that is changed with AUTO mode automatically.
6. SLEEP MODE : Sleep mode is available only in COOL or
HEAT mode.
The operation will stop after 6 hours.
*In COOL mode : The setting temperature is automatical-
ly raised by 1°C each 1hour When the temperature has
been raised by total of 2°C, that temperature is
maintained.
*In HEAT mode : The setting temperature is automatically
dropped by 1°C each 1hour.
When the temperature has been dropped by total of
2°C, that temperature is maintained.
7. FAN SPEED : Manual (3 step), Auto (4 step)
Fan speed automatically varies depending on both the
difference between setting and the room temperature.
8. COMPULSORY OPERATION :
For operating the air conditioner without the remote
control.
*The operating is the same function that AUTO MODE in
the remote control.
2-1-1 Name & Function of key in remote control
below 28˚C
28˚C~below 34˚C
34˚C~below 40˚C
above 40˚C
The temperature of
indoor heat exchanger Indoor fan speed
off
LL Speed
L Speed
Setting Speed
Operation Type Room Temp.
Cool Operation Tr ≥Ts+1.0°C Compressor ON
Tr ≤Ts Compressor OFF
DB98_19047A(1)_1 4/21/04 2:26 PM Page 5

Operating Instructions
Samsung Electronics6
9. FLAP : BLADE-H is rotated vertically by the stepping
motor.
*Flap Set : Press the button under the remote control
is displayed on LCD the and the blades move up and
down. If the button press one more time, blades
rotation is stop.
10. SETTING THE ON/OFF TIMER. :
*ON TIMER : The On Timer enables you to switch on the
air conditioner automatically after a given period of time.
You can set the period of time from 1 hour to 24 hours.
*OFF TIMER : The Off Timer enables you to switch off
the air conditioner automatically after a given period of
time. You can set the period of time from 1 hour to 24
hours.
11. BUZZER SOUND : Whenever the On/Off button is
pressed or whenever change occurs to the condition
which is set up or select, the compulsory operation mode,
buzzer is sounded "beep".
DB98_19047A(1)_1 4/21/04 2:26 PM Page 6

7Samsung Electronics
2-2 Replace PCB Model option
2-2-1 Replace PCB model option
No
Yes
Remove power cord
Replace the PCB module
Check the connection and plug in
Refer to set up the Model option(14~17page)
Replace another PCB
Does all display lamp blink?
DB98_19047A(1)_1 4/21/04 2:26 PM Page 7

Samsung Electronics8
3. Disassembly and Reassembly
3-1 Indoor Unit
Stop operation of the air conditioner and remove the power cord before repairing the unit.
No Parts Procedure Remark
1 Front Grille 1) Stop the air conditioner operation and
block the main power.
2) Open the Front Grille by pulling right and
left sides of the hook.
3) Loosen 1 of the right screw and detach
the Terminal Cover.
4) Detach the thermistor from the Front
Grille.
5) Loosen 2 fixing screws of Front Grille.
DB98_19047A(1)_1 4/21/04 2:26 PM Page 8

Disassembly and Reassembly
9Samsung Electronics
No Parts Procedure Remark
2
3
Control-In
(Main PCB)
Tray Drain
6) Unlock 2 hooks to fix Panel Front and
Tray Drain.
7) Unlock 3 hooks to fix Panel Front and
Back-Body.
1) Take all the connector of PCB upper side
out. (Inclusion Power Cord)
2) Detach the outdoor unit connection wire
from the Terminal Block.
3) Loosen 4 fixing screws of Ass'y Control-In.
1) Pull Tray Drain out from the Back Body.
DB98_19047A(1)_1 4/21/04 2:26 PM Page 9

Disassembly and Reassembly
Samsung Electronics10
No Parts Procedure Remark
4
5
Heat Exchanger
Fan Motor
&
Cross Fan
1) Loosen 2 fixing earth screws of right side.
2) Detach the Connection Pipe.
3) Detach the Holder Pipe at the rear side.
4) Loosen the 3 fixing screws of right and left
side.
5) Lifting the Heat Exchanger up a little to
push the up side for separation from the
indoor unit.
1) Loosen the fixing screw and detach the
Motor Holder.
2) Detach the Fan Motor from the Fan.
3) Detach the Fan From the left Holder
Bearing.
DB98_19047A(1)_1 4/21/04 2:26 PM Page 10

11Samsung Electronics
3-2 Outdoor Unit
No Parts Procedure Remark
1 Common Work 1) Loosen each 3 fixing screws on both right
and left Cabinet-Side edge and a fixing
screw on the Cabinet-Front lower to detach
the Cabinet-Front.
2) Loosen 1 fixing screws of the
Cover-Valve.
3) Loosen 6 fixing screws of the Cabinet-Side
RH.
4) Loosen 2 fixing screws of the Cabinet-Side
LF.
DB98_19047A(1)_1 4/21/04 2:26 PM Page 11

Disassembly and Reassembly
Samsung Electronics12
No Parts Procedure Remark
2
3
4
Fan & Motor
Heat Exchanger
Compressor
1) Detach the Nut Flange.(Turn counterclock-
wise because the screw is right-handed)
2) Detach the Fan.
3) Loosen 4 fixing screws to detach
the Motor.
1) Loosen 2 fixing screws on both sides.
2) Disassemble the pipe in both inlet and
outlet with welding torch.
3) Detach the Heat Exchanger.
1) Loosen the Terminal Cover nut to open the
Terminal Cover.
2) Disassemble the cloth sound felt.
3) Disassemble the pipe in both inlet and
outlet of the Compressor with welding
torch.
4) Disassemble the pipe in both inlet and
outlet of the Condenser with welding torch.
5) Loosen the 3 bolts at the bottom.
6) Detach the Compressor.
DB98_19047A(1)_1 4/21/04 2:26 PM Page 12

13Samsung Electronics
4. Refrigerating Cycle Diagram
Indoor Unit Outdoor Unit
T1
T2
2-Way valve
EEV
3-Way valve
Gas side
Heat
Exchanger
(Evaporator)
Heat
Exchanger
(Evaporator)
Liquid side
Capillary tube
4-Way valveCooling
Heating
Gas leak check point
Compressor
Cross fan
Propeller fan
DB98_19047A(1)_1 4/21/04 2:26 PM Page 13

Samsung Electronics14
Feature Display
5. Set Up the Model Option
5-1 Setting Option Setup Method
ex) Option No. :
Step 1 : Enter the Option Setup mode.
1st Take out the batteries of remote control.
2nd Press the temperature button simultaneously and
insert the battery again.
3rd Make sure the remote control display shown as .
Step 2 : Enter the Option Setup mode and select your option according to the following procedure.
3
1,4 2,5
Setting Option SEG1.
Push the button to set the display panel to .
Every time you push the button, the display panel reads
. . . repeatedly.
2
Setting Option SEG2.
Push the button to set the display panel to .
Every time you push the button, the display panel reads
. . . repeatedly.
4
Setting Option SEG3.
Push the button to set the display panel to .
Every time you push the button, the display panel reads
. . . repeatedly.
3
Change it into the set display of Option SEG3 and SEG4
with the button.
5
Setting Option SEG4.
Push the button to set the display panel to .
Every time you push the button, the display panel reads
. . . repeatedly.
1
DB98_19047A(1)_1 4/21/04 2:26 PM Page 14

15Samsung Electronics
Set Up the Model Option
Feature Display
7
Setting Option SEG5.
Push the button to set the display panel to .
Every time you push the button, the display panel reads
. . . repeatedly.
6
Change it into the set display of Option SEG5 and SEG6
with the button.
8
Setting Option SEG6.
Push the button to set the display panel to .
Every time you push the button, the display panel reads
. . . repeatedly.
10
Setting Option SEG7.
Push the button to set the display panel to .
Every time you push the button, the display panel reads
. . . repeatedly.
9
Change it into the set display of Option SEG7 and SEG8
with the button.
11
Setting Option SEG8.
Push the button to set the display panel to .
Every time you push the button, the display panel reads
. . . repeatedly.
13
Setting Option SEG9.
Push the button to set the display panel to .
Every time you push the button, the display panel reads
. . . repeatedly.
12
Change it into the set display of Option SEG9 and SEG10
with the button.
14
Setting Option SEG10.
Push the button to set the display panel to .
Every time you push the button, the display panel reads
. . . repeatedly.
6,9
7,10 8,11
12
13 14
DB98_19047A(1)_1 4/21/04 2:27 PM Page 15

Samsung Electronics16
Set Up the Model Option
Step 3 : Upon completion of the selection, check you made right selections.
Whenever you press the button, the set Option will be displayed.
Step 4 : Pressing the ON/OFF button ( )
When pressing the operation ON/OFF key with the direction of remote control for unit, the sound "Ding" is heard and the
OPERATION LED lamp is flickering at the same time, then the input of option is completed. (If the "ding" sound isn't heard,
try again pressing the ON/OFF button.)
Step 5 : Unit operation test-run
First, Remove the battery from the remote control.
Second, Re-insert the battery into the remote control.
Third, Press ON/OFF ( ) key with the direction of remote control for set.
• Error Mode
1st If all lamps of indoor unit are flickering, Plug out, plug in power plug again and press ON/OFF key to retry.
2nd If the unit is not working properly or all lamps are continuously flickering after setting the option code, see if the
correct option code is set up for its model.
DB98_19047A(1)_1 4/21/04 2:27 PM Page 16

17Samsung Electronics
5-2 Table of the option Code
Model Option Code
SEG1 SEG2 SEG3 SEG4 SEG5 SEG6 SEG7 SEG8 SEG9 SEG10
SH09BWHA
SH12BWHA
0500001340
0501001351
DB98_19047A(1)_1 4/21/04 2:27 PM Page 17

Samsung Electronics18
6. Troubleshooting
6-1 Basic items for trouble shooting
Since the inverter air conditioner is equipped with Electrical control circuits at both Indoor & outdoor unit, the trouble shooting shall
be performed according to the error mode.
Inside the controller of the outdoor unit (inverter), the large capacity of electrolytic condenser so that it takes the time to discharge
after the power off since the electrical charge remains(the charging voltage DC 340V).
Take care of the electrical shock by contact on the charging part before the discharge after the power off. (It takes approximately
2 minutes to discharge).
1. Is the power source proper?
The power source shall be in the range of the rated voltage ±10%. If it is out of this range, it may cause the abnormal operation.
2. Is the connection made between the indoor and outdoor unit?
The connection between indoor and outdoor unit shall be performed with 4 wire. (connection cable of indoor and outdoor unit +
ground wire).
3. The phenomena as follows are not out of order.
PhenomenaNo
1
2
3
4
5
6
7
The operation is not done.
The wind comes out but the
heating/cooling is not performed.
The remote control does not
operate.
The wind volume is not adjusted.
The temperature is not set.
The operation lamp continues to be
flickering.
The immediate operation starts
without control of remote control
when plugged
Cause and reason
• Is the power off or the power unplugged?
• Does it stop because it is the completion time?
• Unplug and plug again the power source for 2 minutes.
• Is the filter clogged with dust or dirty?
• Is there any direct light on the outdoor unit or any obstacle against it?
• Is the selected temperature too high?
Lower the selected temperature lower than the current one (during cooling).
• Is the selected temperature too low?
Raise the desired temperature than the current one? (during heating)
• Is the "Fan only Mode" operation?
• Is the battery run out?
• Is the battery inserted in the wrong way(+, -)?
• Is the detection part of the indoor unit blocked?
• Does it interfered with the radio of neon sign?
• Is the operation selected among one of Auto / Dry / Turbo / Sleeping?
• The temperature setting is not required since the wind volume set automatically.
• Check again at the state of Cooling / Fan only / Heating.
• Is the operation selected among the Dry / Turbo / Sleeping / Fan only Mode.
Since the temperature is automatically set, the temperature setting is not required.
• Check again at the cooling / heating state.
• The standard temperature ±2˚C during the automatic operation.
• Push the Operation / Stop button.
• Unplug and plug the power source.
• It is the case that the auto restart function works.
✳Auto restart function is the convenient function where the operation state is
memorized in the Memory IC during the blackout and the operation restarts when
the power comes back.
DB98_19047A(1)_1 4/21/04 2:27 PM Page 18

19Samsung Electronics
6-2 The first determination method of troubled part
6-2-1 Error mode display of indoor unit
Indoor unit room temperature sensor error (open / short) Temp.-Sensor
Indoor unit heat exchanger temperature sensor error (open / short) Temp.-Sensor
Indoor fan motor malfunction Fan and cable
EEPROM error PCB
Option error Option code
Abnormal communication error (Indoor - Outdoor unit)
Outdoor unit temperature sensor error
- Outdoor temp.-sensor Temp.-Sensor
- Deice temp.-sensor Temp.-Sensor
- OLP temp.-sensor Temp.-Sensor
- Discharge temp.-sensor Temp.-Sensor
- Heatsink temp.-sensor PCB
LAMP
OPERATION
TIMER TURBO
Description Check point
INDOOR OUTDOOR
PCB, Cable between
Indoor and outdoor unit
X
X
X
X
X
X
X
X
: Lamp off : Lamp flickering
DB98_19047A(1)_1 4/21/04 2:27 PM Page 19
