DIGITAL AUDIO PLAYER YP-NDU
SERVICE
1. Precautions 2. Specifications 3. Location of Controls 4. Troubleshooting 5. Exploded View and Parts List 6. Block Diagram 7. PCB Diagrams 8. Schematic Diagrams
Manual
DIGITAL AUDIO PLAYER CONTENTS
ELECTRONICS
© Samsung Electronics Co., Ltd. JUN. 2001
Printed in Korea AH68-00759A
查询YP-NDUMP3供应商 捷多邦，专业PCB打样工厂，24小时加急出货

Samsung Electronics 1-1
1. Precautions
1. Some semiconductor (“solid state”)devices are easily damaged by static electricity.
Such components are called Electrostatically Sensitive Devices(ESDs); Examples included
integrated circuits and Some filed-effect transistors. The following techniques will reduce
the occurrence of component damage caused by static electricity.
2. Immediately before handling any semiconductor components or assemblies, drain the electrostatic change
from your body by touching a known earth ground.
Alternatively, wear a discharging wrist-strap device. (Be sure to remove it prior to applring
Power-this is an electric shock precaution.)
3. After removing an ESD-equipped assembly, place it on a conductive surface such as aluminum
foil to prevent accumulation of electrostatic charge.
4. Do not use freon-propelled chemicals. These can generage electrical charges that damage ESDs.
5. Use only a grounded-tip soldering iron when soldering ESDs.
6. Use only anti-static solder removal device. Many solder removal devices are not rated as
“anti-static”; these can accumulate sufficient electrical charge to damage ESDs.
7. Do not remove a replacement ESDs from its protective package until you are ready to install it.
Most replacement ESDs are packaged with leads that are electrically shorted together by conductive materials.
8. Immediately before removing the protective material from the leads of a replacement ESDs,
touch the protective material to the chassis or circuit or assembly into which the device will
be installed.
9. Minimize body motions when handling unpackaged replacement ESDs. Motions such as
brusing clothes togetherer or lifting a foot from a carpeted floor can generate enough static
electricity to damage an ESDs.

Precautions
1-2 Samsung Electronics
MEMO

Samsung Electronics 2-1
2. Specifications
YP-NDU
12MHz, 16bit CISC
Built-in Memory 32MB/64MB
3V
Two AAA-Size/8-hr or longer playing time (with alkaline batteries)
70x88x21mm(2.75”x3.46”x0.83”)/76g(2.68 Oz; without batteries)
Plastic /Aluminum
Up to 1.5Mbps
SmartMedia Card Socket
90dB(with A filter)
7mW
20Hz-20KHz
Model
Processor
Memory Capacity
Power
Battery
Dimensions (W x H x D)
Case
File Transmission Speed
Memory Socket
Noise Ratio
Earphone Output Power
Output Frequency Range

Specifications
2-2 Samsung Electronics
MEMO

Samsung Electronics 3-1
3. Location of Contols
3-1 Front Panel
3-2 Rear Panel
Stop/Power Off button
Volume control button
3D button
LCD
Voice Recorder button
Repeat button
Erase button
Mode/Section repeat
button
FF button
Equalizer button
REW button
Microphone
Connection cable
terminal
Power On
/Play
/Pause button
SmartMedia
Card Slot
Push open
button
Earphone jack
Eject
Hold switch
Battery case

Location of Controls
3-2 Samsung Electronics
3-3 Remote Controller
Volume control button
Power ON/Play/Pause
Stop/Power Off
button
Reverse
button
Forward
button EQ/REP button
Section repeat
button (A
Headphone/
Earphone port
B)
Hold
Switch
LCD
Panel
3-4 FM Remote Controller
Power ON/Play/Pause button
Hold switch
Belt Clip
Volume control button
FF button
Stop/Power OFF button
Mode button
EQ/REP button
LCD panel
REW button
Section repeat
button (A B)
Front Rear

Samsung Electronics 4-1
4. Troubleshooting
Symptoms Possible Causes Check Point Action
No LCD
No Recording
Faulty recognition
of memory
Faulty switch
operation
Faulty down load
Faulty switch
operation
Faulty remote
control button
No Power Replace Main &
Sub board
Replace LCD
Replace Z1
Check Vcc5
Check TP4 (High)
Replace (U14)
Replace Main & Sub
Soldering
Replace Flash Memory
Soldering
Replace Switch
Replace main board
Soldering
Soldering
Replace Switch
Replace remote control
Faulty LCD
Faulty Z1, U15, U14
- Open or Short PCB
- Faulty Flash Memory
- L3(3V)
- U1 Pin 3,13,35,80(3V)
- J1 PIn 1 (3V)
- U1 Pin 98 (Signal)
- C66 (Signal)
- U15 PIn 5(3V)
- U14 Pin 11,12,13 & TP3(Signal)
- Ports between U2 and memory
chip (smart media card socket)
- Mechanical parts
- Check TP1, TP2
- Open/Short test of switch
- Mechanical parts
- Check between U1 and U17
- Cold soldering on J6
- U14 Pin 6,16(3V)
- Cold soldering on switch
- Open PCB pattern
- Open or Short on switch
- Open PCB pattern - Open / Short test of switch - Mechanical parts
- U1 Pin 17
- Faulty Remote control
- Cold soldering
- Open or Short on switch
- Faulty J6

Troubleshooting
4-2 Samsung Electronics
Check
Vcc3, Vcc4, Vcc5
>2.8V
Check TP4>2.8V
if TP4<2.8V
Replace Main
Board
Check C66
Analog Signal Cold Soldering Z1
or
Replace Z1
Check TP6
Analog Signal Replace U15
NO
YES
NO
NO
NO NO
YES
YES
Check TP3, 3MHz Check U16 -9
6MHz
YES
YES
YES
Replace
Sub Board
Replace
U16
Check
U14 -11,12,13
Digital Signal Replace
Mainboard
U14
REC
No Recording

Troubleshooting
Samsung Electronics 4-3
Check D3-1
>2.8V
Check
Y1(12MHz)
YES
NO
NO
NO
YES
YES
Check
Power On Check LCD
Check KEY S1
Replace
Main Board
Check
between con7 and
U1-96,97,98,99
No LCD Display

Troubleshooting
4-4 Samsung Electronics
Check Y3
6MHz
Check
Signals on between
U1- and U17
NO
NO
NO
YES
YES
YES
YES
Check USB Cable
(Connect message)
Replace Main
Board(Y3)
Replace
Main Board(U17)
NO Replace
Main Board
Check
Cable &
Connector
U17 -15,16
<0.5V
Download
No USB controller when
USB cable connected

Troubleshooting
Samsung Electronics 4-5
Check U5-23,24,25
Digital Signal
Check U5 37, 41
Signal Signal
(1KHz)
Check
Phone Jack
Play
NO (Replace U5)
NO
(Replace U5)
NO(Replace Y2)
NO
YES
YES YES
YES
YES
Check
Y2, 14.725
NO
Replace Y2
Check Y2 and 14.725
Replace
Sub Board
Replace
Sub Board
Replace
Sub Board
Play check
(Play 1KHz 128Kbps)

Troubleshooting
4-6 Samsung Electronics
NO
NO
YES
YES
Check
U1 & J7 between
U1-51~58 and
J7-2~9 Replace
Main Board
Check
J9 & U9,U10
between J9,2~9
and U9,10-29~32,
41~44
Replace
Sub Board
Check
Cold soldering
J9, U9, U10
Display Invalid FLS

Samsung Electronics 5-1
5. Exploded View and Parts List
Œ
Ò ˜¯ ÚÆ ı
´
ˆ
”
Ø
’
˝
∏
ˇ
Ô
¨
Loca. No. Parts No. Description ; Specification Remark
ŒAH97-00477B ASSY-TOP;-,YP-NDU,USB
´AH72-00038A KNOB-4;YP-ND,ABS,-,-,-,1,-,Cr-PLATING
ˇAH97-00476B ASSY-BOTTOM;ASSY,YP-NDU,USB
¨AH72-00029A COVER-BATTERY;YP-ND,ABS,SILVER,-,-,1,-,C
ˆAH92-01010A ASSY PCB-MICOM;YP-NDU(EUROPE2.0), MIC(ENG2.0) EUROPE ONLY
AH92-00888A ASSY PCB-MICOM(CHA);YP-NDU(FM), MIC(CHA)
CHINA/TAIPEI/HONG KONG ONLY
AH92-00884A ASSY PCB-MICOM;YP-NDU(FM), MIC(ENG) OTHERS AREA
ØAH82-00079A A/S MATERIAL ASS'Y;YP-NDP/U,Samsung,24 Pa OTHERS AREA
AH07-00045A LCD;DCM-08B3FT-09,YP-MF64,-,30x60
CHINA/TAIPEI/HONG KONG ONLY
∏AH72-00044A HOLDER-LCD B;YP-ND,ABS,GRY,-,-,1,-,ENG OTHERS AREA
AH72-00045A HOLDER-LCD B;YP-ND,ABS,GRY,-,-,1,-,KOR
CHINA/TAIPEI/HONG KONG ONLY
”AH92-00882A ASSY PCB-SMC;YP-NDU(FM),SMC(64MB)
’AH72-00046A CHASSIS-FRAME;YP-ND,ABS,GRY,-,-,1,-,FRAM
˝6003-001174 SCREW-TAPTITE;PH,+,B,M1.7,L13,NI PLT,SWR
Ô6003-001173 SCREW-TAPTITE;PH,+,S,M1.7,L6,NI PLT,SWCH
AH59-00065A REMOCON;YP-NE/ND/MF,SAMSUNG,56*24*24mm
ÒAH59-00100A REMOCON;YR-10FS,SAMSUNG,FM Tuner,uPD75 EUROPE ONLY
AH59-00073A REMOCON-FM;YR-10FS,SAMSUNG,55mm,V850e,9e OTHERS AREA
ÚAH97-00645A ASSY-BELT CLIP;ASSY,YP-NDU,-
ÆAH69-00296A BAG ACCESSORY;YP-ND Series,PANDA SUEDE,3
ıAH39-00208A CABLE FORM;C17-004-6436E,YP-NDU,4P,1300m
˜AH59-00066A SPEAKER SYSTEM;YP-ND/NE,SB-900X,0.22V,0.
AH80-00003A INSTALL;YP-ND,Export,CD,Pa EUROPE ONLY
AH80-00011A INSTALL-CD EUROPE;YP-NDU,-,CD MASTER,EUR
FM REMOTE ONLY (Except U.S.A.)
¯AH80-00019A INSTALL-CD EUROPE;YP-NDU,-,CD MASTER,EUR (INSERT MAC VER.) FM REMOTE ONLY (Except U.S.A.)
AH80-00016A INSTALL-CD USA(128KBPS);YP-NDU,USA FULL U.S.A. ONLY
AH80-00010A INSTALL-CD JAPAN;YP-NDU,-,CD MASTER, JAPAN JAPAN ONLY

Exploded View and Parts List
5-2 Samsung Electronics
MEMO

Samsung Electronics 6-1
6. Block Diagram
REMOCON
LCD
Micom Controller (OKI MSM66Q573L) -12C control - Parallel & USB communication - Power control - Memory R/W - AD Key Control
MP3 decoder (MAS3507D) - MP3 decoding - digital volume control - DC/DC Converter
13-Key Including Button
PC USB
Interface
Clock
Generation
OSC
Power 1.5 x 2 (AAA) Battery
A/D Converter
UDA1360
Clock
Generation
OSC
D/A Converter (DAC 3550A) Earphone
Flash Memory Internal 16M/32M/64M (External : 16M/32M/ 64M Smart Card)
mic
I C
Key Interrupt Information
U17
Y1
U1
U6
Y2
U5
U14
U9, U10
2

Block Diagram
6-2 Samsung Electronics
MEMO

Samsung Electronics 7-1 7. PCB Diagrams 7-1 Micom
COMPONENT SIDE SOLDER SIDE

PCB Diagrams 7-2 Samsung Electronics 7-2 SMC
COMPONENT SIDE SOLDER SIDE

Samsung Electronics 8-1 8. Schematic Diagrams
LCD
USB
EMULATOR USE ONLY
SYS_CLK
/ADC_ON
SYS_CLK
MEM_CE /MEM_WR /MEM_RD /ECC_CE
PWR_HOLD RMT PLAY
D- D+ +5V
EE_CLK
USB_RD
AD2 PD2
PLAY_KEY
AD1 PD4
HOLD
/DSK_CHK
/SM_INSRT
/ADC_ON
/ADC_ON
AD7 PD6
EE_CS EE_DI
AD3
RMT_DATA
EE_WP
AD4 PD3
/USB_WR
G
PD0
AD4
AD5
LCD_CLK
AD2
SM_INSRT
AD0
USB_RESET
AD3 AD7
HOST_CLK
ECC_MODE
PWR_HOLD
PD5 PD7
/MEM_RD
MEM_CE SM_INSRT
USB_RESET
AD6
VCCP_ON
DEC_WSEN
AD1
EE_DO
USB_A0
PD1
AD5
M PLAY
/DSK_CHK
AD0
/ECC_CE
LCD_DATA LCD_CS LCD_RES
/SM_INSRT
RMT_PLAY AD6PLAY_KEY
MEM_WR
VCC
VCC
VCC
AVCC
VBAT
VCC
VCC
VCC
VBAT
VCC_R
VCC5
VCC5
VCC5
VCC3
VCC4
VCC4
VCC3
VCC3
VCC VCC3
VCC4 VCC5
VCC3
VCC1
VCC1
VCC1
VCC_R
VCC VCC
VCC
VCC
VCC
VCC
VCC_R
VCC0
AVCCVCCVCC1
VCC0
VCC
VCC
VBAT
VCC
VCC
R15 6.2K
R16 1K
R17 3K
R18 1.5k
R19 820
R20 6.2K
R21 3k
R22 1.5k
R23 820
R24 1K
S2 FWD
S3 RWD
S4 REC
S5 +
S6 -
R25 240
S7 EQ
S8
ERASE
S9
MODE
S10
REPT
S11
STOP
R59 47K
J3 CON1
1
R57 47K
J4 CON1
1
R68 680K
C38
100nF
TP2 TP
1
R5 10K
Y1
12MHz
C39 100nF
TP1 TP
1
U7
93C56
1 2 3 4 5
6 7 8
CS SK DI DO GND
ORG
WP
VCC
L2 22uH D2
RB161
R128 240 R26
470
S13 3D
D5 MA729 D6 MA729
+
C96 220uF
R90 1OK
R13 100K
C64 330pF
C65 100nF
+ -
Z1 MIC
+
C66 10uF
C67 100nF
+
C68 47uF
C69
100nF
R91 220 C70 1nF
+
C71 47uF
+
C72 47uF
U14
UDA1360
1 2 3 4 5 6 7 89
10 11 12 13 14 15 16 VINL
VREF
VINR
VREFN VREFP
SFOR
PWON
SYSCLKVDDD
VSSD BCK WS DATAO FSEL VSSA VDDA
R92 47K R93 1
R94
47
R95
47K
+
C75 47uF C76
100nF
R96 1
+
C77 47uF C78
100nF
R97
47K
R98 1
C79 100nF
+
C80 47uF
U15 TC75S51F
1 3
5
4
2
R102
1K
R103 200K
R104 47K
R105
47K
TP3 TP
1
TP6 TP
1
Q2 KRC414
R99 24K
R100 47K
Q3
KTA1298 L5
10uH L6 10uH
+
C81 10uF
+
C82 10uF
R101 47
TP4 TP
1
R106 47K
C83 100nF
TP5 TP
1
J7 CON40 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40
U11
ECC48
1
2
3
4
5
6
7
8
9
10
11
12
13 14 15 16 17 18 19 20 21 22 23 24
25
26
27
28
29
30
31
32
33
34
35
36
37 38 39 40 41 42 43 44 45 46 47 48
MODE
NC
NC
GND
SM_RESET
SM_RESET
NC
NC
NC
NC
CARD_IN
SM_IN
NC NC NC NC
GND
NC NC NC NC NC NC
D0
D1
D2
D3
D4
D5
D6
D7
NC
NC
NC
NC
NC
ECCDCE NC WE RW ECCRCE TEST NC VCC NC NC NC VCC
C44 100n R71
47k
R72
47k
D7 MA729
R58 47K R67
47K
R137 47K
R132 47K
C120 100nF
D8 MA729
+
C37
220uF/6.3V
Q8 KRC414
Q9
IRLML6401
R144 10K
R9
47K
D3 MA729 R10
100K
S1 PLAY
R14 10
L3 10uH
+
C104 10uF
J8
CON8
1 2 3 4 5 6 7 8
+
C74 47uF
U16 74LVX74
1 2 3 4 5 6 7 8
9 10 11 12 13 14
1CLR
1D 1CLK 1PRE 1Q 1Q GND 2Q
2Q
2PRE
2CLK
2D
2CLR
VCC
C73 100nF
R55
47K
R61 100K
R151 100K
R153 3K
C112
100n
C111 100n
R161
1M
U17
PDIUSBD12
1 2 3 4 5 6 7 8 9
10 11 12 13 14 15
16 17 18 19 20 21 22 23 24 25 26 27 28
DATA0 DATA1 DATA2 DATA3 GND DATA4 DATA5 DATA6 DATA7 ALE CS_N SUSPEND CLKOUT INT_N RD_N
WR_N
DMREQ
DMACK_N
EOT_N
RESET_N
GL_N
XTAL1 XTAL2
VDD
D-
D+
VOUT3
A0 J6
CON4 1 2 3 4
R108 22 R109 22
TP7 TP
1
C84
1uF
Y3 6MHz
C85 68pF
C86 22pF
R164 47K
B1 300
R162
100K
R110
1K
R163
100K
R136 100K R165
100K
C2 100nF
+
C3 10uF
C1 100nF
C4
100nF
U1
MSM66573-TQFP
1 2 3 4 5 6 7 8 9
10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51 52 53 54 55 56 57 58 59 60 61 62 63 64 65 66 67 68 69 70 71 72 73 74 75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96
97
98
99
100
P10-4 P10-5 P10-7 RXD1/P8-0 TXD1/P8-1 RXC1/P8-2 TXC1/P8-3 TM4OUT/P8-4 PWM2OUT/P8-6 PWM3OUT/P8-7 PWM0OUT/P7-6 PWM1OUT/P7-7 VDD GND HLDACK/P9-7 EXINT4/P9-0 EXINT5/P9-1 P9-2 P9-3 EXINT0/P6-0 EXINT1/P6-1 EXINT2/P6-2 EXINT3/P6-3 P6-4 P6-5
P6-6
P6-7
P5-4/CPCM0
P5-5/CPCM1
P5-6/TM0OUT
P5-7/TM0EVT
RES
NM1
EA
VDD
XT0
XT1
GND
OSC0
OSC1
VDD
P11-0/WAIT
P11-1/HOLD
P11-2/CLKOUT
P11-3/XOUT
P11-6/TM9OUT
P11-7/TM9EVT
P3-1/PSEN
P3-2/RD
P3-3/WR
P0-0/D0 P0-1/D1 P0-2/D2 P0-3/D3 P0-4/D4 P0-5/D5 P0-6/D6 P0-7/D7
GND
P4-0/A0 P4-1/A1 P4-2/A2 P4-3/A3 P4-4/A4 P4-5/A5 P4-6/A6 P4-7/A7 P1-0/A8 P1-1/A9
P1-2/A10 P1-3/A11 P1-4/A12 P1-5/A13 P1-6/A14 P1-7/A15
A16/P2-0
A17/P2-1
A18/P2-2
A19/P2-3
VDD
VREF
AI0/P12-0
AI1/P12-1
AI2/P12-2
AI3/P12-3
AI4/P12-4
AI5/P12-5
AI6/P12-6
AI7/P12-7
AGND
RXD0/P7-0
TXD0/P7-1
GND
RXC0/P7-2
TM3OUT/P7-4
TM3EVT/P7-5
SIOCK3/P10-0
SIO3/P10-1
SIOO3/P10-2
P10-3
R2 10K
C6
100nF
J1 CON7
1 2 3 4 5 6 7
R1 1M
R6
47K
C5
100nF
U2 S-808
1 3
2 4
OUT
NC
VDD GND
R11 22K
+
C7 1uF C8
47pF C9
27pF
C10 100pF
R12 100K
/DSK_CHK
ECC_MODE
AD5 AD6 AD7
MEM_AL E MEM_CLE /MEM_RD
/MEM_CE0 /MEM_CE1 /SM_CE
MEM_R/B WR_PROT
A B
ADC_DATA
DAC_LRCLK
DAC_BCK
DEC_DATA
DEC_DMD
/DEC_RTW
/DEC_PCS
I2C_CLK
I2C_DATA
/DEC_RST AD7
AD6 AD5 AD4 AD3 AD2 AD1 AD0
/MEM_CE1
/SM_CE
/MEM_CE0
WR_PROT
MEM_R/B
DEC_WSEN
MEM_CLE
MEM_AL E /MEM_RD
/MEM_WR
DEC_DATA
DEC_CLK
DEC_DMD
/DEC_RTW
I2C_CLK
I2C_DATA
CLK_2
ADC_DATA
DAC_LRCLK
DAC_BCK
/SM_IN
/SM_IN
RMT_PLAY RMT_DATA
CLK_2
DCSO /DSK_CHK
/DEC_RST /DEC_PCS/ADC_ON
CRC_ERR
DCSO
HOLDA
B
PD0 PD1 PD2 PD3 PD4 PD5 PD6 PD7
USB_A0
/USB_INT /USB_WR
/USB_RD
HOST_CLK
/USB_INT
AD0 AD4
HOLD
AD3
CRC_ERR
DEC_CLK
AD2 AD1
8-1 Micom
