Santec Circ 3965CI91 User manual

PAGE 01
TOILET PAPER HOLDER
3965CI _ _
MODEL NUMBER
TOILET PAPER HOLDER
MOUNTING SCREWS (2)
DRY WALLANCHORS(2)
ALLEN KEY
SET SCREW
MOUNTING SCREW BRACKET

INSTALLATION INSTRUCTIONS
PAGE 02
1- Take the toilet paper holder out of the box.
Place the post against the assigned wall location.
Make sure that the holder is leveled and pointed
to the right.
Mark the holder post position and remove the trim.
2- Using the Allen key provided, remove the mounting screw bracket from the
holder post.
Press the mounting screw bracket against marked post position on the wall
and mark the screw hole positions.
2a- INSTALLING ON WOODEN SURFACE
- For wooden surface, the mounting screw bracket can be secured by
screwing the screws directly into the wall.
2b- INSTALLING ON A DRYWALL
- Using a drill, pre-drill holes for the anchors.
- Insert the anchors into the wall.
- The mounting screw bracket can be secured by screwing the
screws into the anchors.
2c- IF INSTALLING ON A SOLID/HARD SURFACE
- Measure the dimensions carefully.
- Using a drill, pre-drill the holes.
- Secure the mounting screw bracket by screwing the screws
into the wall.
3- Press the post against the mounting screw bracket. Align
the holder and secure it by tightening the set screw.
4- Check the holder post to make sure it is firmly secured. If
not, tighten the set screw with the Allen key.
Santec Inc.
3501 Challenger Street, Torrance, CA 90503
Tel: [phone] Fax [phone]
www.santecfaucet.com
WALL
WOODEN SURFACE
3965CI_ _
pointing right
post flange mark
mounting screw bracket
DRY WALL SURFACE
HARD SURFACE
