Santec KRISS 2220CN User manual

Installation Instruction
Widespread Lavatory Set
KRISS COLLECTIONS
Please read the instructions completely before beginning the installation.
Kriss I Collection
Model Number: 2220CN Kriss III Collection Model Number: 2220AN
Kriss Luna Collection
Model Number: 2220JP
Kriss V Collection
Model Number: 2220JZ
Kriss Crystal I Collection
Model Number: 2220JC
Flush both supply lines before installation, then shut off both supply lines.
Minimum hole size for the spout and handle trim is 1-1/4” and maximum of 1-1/2”
Rubber washer
1
Rev 06/2016
SPOUT INSTALLATION
The measurements shown are for reference only. Products and specifications shown are subject to change without notice.
www.santecfaucet.com | P: 310.542.0063 F: 310.542.5681
1/8
- Remove the tee connector, spout mounting hardware and tee
connector washer from the bottom of the spout assembly. Apply
a ring of silicon caulking around the center hole on the top of the sink.
Do not use plumbers' putty which can damage the finish of the faucet.
- From the top of the deck, insert the spout's threaded shank through
the center hole of the sink. Make sure the spout flange washer is
properly placed underneath of the flange and gently pressed against
the sink top.

2
Rubber washer
Rubber washer
Metal washer
Brass lock nut
HANDLE TRIM INSTALLATION
DO NOT DISASSEMBLE HANDLE ASSEMBLY - DROP-IN VALVES
The measurements shown are for reference only. Products and specifications shown are subject to change without notice.
www.santecfaucet.com | P: 310.542.0063 F: 310.542.5681
2/8
- Slip the spout mounting hardware back onto the spout. First the
notched rubber washer, then the notched metal washer and lastly
the brass lock nut. Hand tighten the lock nut.
- Place the pop-up lift rod with the knob through the back hole in the
spout and rotate the notched washers until the lift rod passes through
the notch.
- Tighten the lock nut. Make sure the lift rod operates smoothly. Adjust
it if necessary.
- Place the tee connector washer into the tee connector and thread
the tee connector onto the end of the spout shank. Tighten to seal.
- Align the spout and tighten the shank lock nut firmly.
Notched rubber washer
Notched metal washer
Spout stabilizer
Brass lock nut
Tee connector
Tee connector washer
- Both hot and cold side handle trims are pre-assmbled for faster
installation.
- For proper handle turning direction, install the handle with the “cold”
blue label at the right side of the spout (looking from the front) and
the handle with “hot” red label at the left side of the spout.
- Remove the valve body mounting hardware from the valve body.
Slip the valve body’s flexible hoses from the top of the sink or counter
through the appropriate hole next to the spout. Make sure the handle
flange washer is properly placed underneath of the flange and gently
pressed against the sink top. Aim the tee connecting hoses toward
the tee connector.
1
- From beneath of the basin or counter, screw the valve body
mounting hardware back to the valve body. First the rubber
washer, then the nylon washer and lastly the brass lock nut.
- Align the handle lever or cross handle properly against the spout.
Tighten the lock nut until it secures the valve body firmly.
2
- connect the flexible hoses to the tee. Tighten to avoid the
leakage.
- Connect and tighten the Inlet hoses to the supply lines.
- After the connections have been made, turn on the water supply
and check for leakages at all joints. If water leaks from any of the
connections tighten the connection until the leakage stops.
- If no leakage, turn the handles to the full open position and let the
water flush for about 45 seconds. This can prevent damages to the
ceramic cartridges caused by debris in the supply line.
- During the flushing, check for leakage at the connecting joints and
repeat step 3 if necessary.
3
Water supply
INLET HOSE
line

COMPLETE ASSEMBLY
The measurements shown are for reference only. Products and specifications shown are subject to change without notice.
www.santecfaucet.com | P: 310.542.0063 F: 310.542.5681
3/8
TO THE HOT SUPPLY LINE TO THE COLD SUPPLY LINE
INLET HOSE INLET HOSE

POP-UP INSTALLATION
1Remove the decorative drain flange, drain plug and gasket from
pop-up assembly. Do not remove the washer and lock nut.
2
Place the flange gasket onto the drain tube beveled side upward
and on top of the washer. Apply a ring of silicon caulking around
the top of sink drain opening. Do not use plumbers' putty.
3
Insert the threaded end of the assembly up from the under the sink
so that the top of the drain tube is through the drain opening.
Make sure the bottom of the drain tube is in the p-trap.
4Completely thread the drain flange onto the top of the drain tube.
Hand tighten the locknut from under the sink.
5
Position the drain tube so the side hole in the pop-up faces you.
Place the drain plug into the drain tube so its bottom hole is in
line with the side hole of the drain tube. Place the short end of the
ball rod into the side hole of the drain tube and through the hole in
the drain plug and tighten the ball rod nut so the ball rod moves freely.
NOTE: Do not over tighten.
6
Rotate the pop-up so the ball rod faces the back wall and tighten
the lock nut giving it an extra 1/4 turn. Hand tighten the nut at the
connection with P-trap. Test the rod and pop-up plug by pushing the
ball rod up and down to see if it raises and lowers the pop-up.
If not reinstall the ball rod.
7
Slip your faucet's pop-up lift rod through
the holes at the top of the lift rod strap
and hand tighten the thumb screw. Push
the ball rod down so the drain plug is in the
up position. Slip the one leg of the ball rod clip
onto the ball rod and then slide the lift rod strap
onto the ball rod using the nearest hole. Then
slide the second leg of the clip onto the rod.
Test the pop-up for smooth operation and adjust
the strap if necessary.
The measurements shown are for reference only. Products and specifications shown are subject to change without notice.
www.santecfaucet.com | P: 310.542.0063 F: 310.542.5681
4/8

PARTS DRAWING
* Please specify the finish when ordering the part.
# PART DESCRIPTION PART #
1 Complete Spout Assembly * PS-2K00S
2 Complete CN Lever Handle Assembly 00CN-R - right
00CN-L - left
3 Spout Flange * P0227
4 Hot Cartridge Only P0418
5 Cold Cartridge Only P0419
6 Complete Hot Valve P0466
7 Complete Cold Valve P0467
8 Connecting Hose to the Tee P0441
9 Connecting Hose to the Supply Line P0440
10 Tee Connector P0427
11 Spout Mounting Hardware P0431
12 Washer for the Tee Connector
13 Washers for Spout & Handle Flanges PM-400
14 Valve Body Mounting Hardware
15 Lift Knob and Lift Rod *
16 Complete Pop-Up * 9002PP
17 Aerator Washer PM-306
18 Aerator Basket with Restrictor PM-1069
19 Aerator Housing * P0952-00
The measurements shown are for reference only. Products and specifications shown are subject to change without notice.
www.santecfaucet.com | P: 310.542.0063 F: 310.542.5681
5/8

SPECIFICATION SHEETS
The measurements shown are for reference only. Products and specifications shown are subject to change without notice.
www.santecfaucet.com | P: 310.542.0063 F: 310.542.5681
6/8
Ø 2
14
"
1
116
"3
516
"
12"
Ø 1
14
"
POP-UP
34
"
19 78
"
21
76
12
"
14
2"
52
478
"
123
2"
3"
50
1312
"
343

We recommend that all faucets, drains, etc., be gently wiped dry with a soft cloth after use to avoid water
spotting and water deposit build-up. A mild liquid hand soap may be used occasionally if desired. Use of a
non-abrasive carnauba wax will add protection to the finish and should be used if the faucets will not be dried
after use. For clear coated finishes, it is recommended to clean your product weekly with a soft moist cloth.
WARNING: Do not clean your SANTEC product with ammonia (Window cleaner), bleach, soap, acids,
abrasives, harsh polish, harsh cleaners, a coarse surfaced cloth, coarse sponge, or any type of scouring pad.
Doing so may ruin your faucet finish and/or void the warranty.
Thank you for making SANTEC a part of your lifestyle and luxury spa experience. Our products have been
created as works of enduring quality and sophisticated design.
Luxurious finishes need proper care and attention, so in order to understand how to properly clean your
distinctive luxury finish, please refer to the finish care information below:
Your SANTEC product can be identified in one of two categories: clear coated finishes or non-clear coated
finishes. Clear coated finishes are more scratch-sensitive and are more reactant to harsh cleaning chemicals
than non-clear coated finishes. Once you have identified the specific luxury finish of your SANTEC product,
please follow the important corresponding care instructions.
We recommend that all faucets, drains, etc., be gently wiped dry with a soft cloth after use to avoid water
spotting and water deposit build-up. A mild liquid hand soap may be used occasionally if desired. Use of a
non-abrasive carnauba wax is occasionally required and will add protection to the finish if the faucets will not
be dried after use.
FINISH CARE INFORMATION
CLEAR COATED FINISHES
NON-CLEAR COATED FINISHES
TO OBTAIN WARRANTY SERVICE
Please read ‘WHAT IS COVERED BY OUR WARRANTY’ and ‘EXCLUSIONS AND LIMITATIONS OF
WARRANTY’ sections to understand what is and what is not covered. Please have ready the proof of
purchase (original sales receipt), description of the problem, and carefully package the product or defective
part with postage prepaid. Then, please contact your local SANTEC Showroom or write to SANTEC Technical
Services.
