SANUS VuePoint F180c User manual

F180c INSTRUCTION MANUAL
Scan for easy install video
san.us/794
We’ll Make It Stress-Free
If you have any questions along the way, just give us a call.
1-888-333-9952. We’re ready to help!

2
Does your TV weigh more than 100 lb (45.4 kg) including accessories?
No — Perfect!
Yes
— This mount is NOT compatible. Visit vuepoint.sanus.com or call 1-888-333-9952 to find a compatible mount.
100 lb
(45.4 kg)
IMPORTANT SAFETY INSTRUCTIONS – SAVE THESE INSTRUCTIONS – PLEASE READ ENTIRE MANUAL PRIOR TO USE
1/2 in.
(13 mm)
Ready to begin?
Please read through these instructions completely to be sure you’re comfortable with this easy install process. Also check your TV
owner’s manual to see if there are any special requirements for mounting your TV.
If you do not understand these instructions or have doubts about the safety of the installation, assembly or use of this product, contact
Customer Service at 1-888-333-9952.
Do you have all of the tools needed?
Before getting started, let’s make sure this mount is perfect for you!
1
2
3
4
What is your wall made of?
CAUTION: Avoid potential personal injuries and property damage!
●This product is designed for use in wood stud, solid concrete, and concrete block walls - DO NOT install into drywall alone
●The wall must be capable of supporting five times the weight of the TV and mount combined
●Do not use this product for any purpose not explicitly specified by manufacturer
●Manufacturer is not responsible for damage or injury caused by incorrect assembly or use
7/32 in.
(5.5 mm)
Wood
Unsure? Call 1-888-333-9952
Drywall with
wood studs? Perfect! ?
Optional
3/8 in.
(10 mm)
Concrete
Solid concrete or concrete
block - call 1-888-333-9952

3
15.75
40.00
2.95
7.50
3.94
10.00
23.62
60.00
7.87
20.00
2.95
7.50
3.94
10.00
7.87
20.00
15.75
40.00
11.81
30.00
11.81
30.00
12.00
30.49
12°
11°
2.85
7.24
15.00
38.10
0.38
0.97
OFFSET
3.00
7.61
OFFSET
Dimensions
in.
[cm]
NOTE: TV shifts 3 in. (7.61 cm)
to the right or left when in the home
position. Consider this when select-
ing the location of your wall mount.

4
M5 x 12mm
M6 x 12mm M6 x 35mm
M5 x 35mm
M6 x 20mm
M8 x 16mm
M8 x 12mm M8 x 35mm
M8 x 20mm
NOTE: Not all hardware included will be used.
WARNING: This product contains small items that could be a choking hazard if swallowed.
Before starting assembly, verify all parts are included and undamaged. If any parts are missing or damaged, do not return the damaged item to
your dealer; contact Customer Service. Never use damaged parts!
Supplied Parts and Hardware
STEP 1 Parts and Hardware
01
TV Bracket
TV Screws
Washers Spacers
TV Bracket
Extenders
TV Bracket Interface Screws
04 x4 05 x4
07 x4
09 x4
06 x4
08 x4
10 x4 11 x4
12 x4 13 x4 14 x4
03 x8
x1 02 x4
M
5
M
6
/
M
8

5
1/4-20 x 3/4 in.
10-24 x 1 in.
5⁄16 in. x 2 3⁄4 in.
STEP 2 Parts and Hardware STEP 3 Parts and Hardware
Additional Hardware
Cable Ties
x5
22
.695 x .350 x.075 in.
16 x1
15 x1
19 x1
Wall Plate
Wall Plate Template
Lag Bolts
Lag Bolt Washers
18 x4
20 x1
21 x2
Safety Screw
Locking Screw
Arm Assembly
17 x4

6
Concrete Installation Kit CMK1 (NOT INCLUDED)
5/16 x 2¾ in.
.695 x .350 x .075 in.
.695 x .350 x.075 in.
5/16 x 2¾ in.
Contact Customer Service at 1-888-333-9952 to have these additional pieces shipped directly to you.
Fischer UX 10 x 60 Anchor
x4 x4
x4

7
STEP 1 Attach TV Bracket to TV
1-1 Measure Your TV Hole Pattern
cm
inches
inch dimensions are approximate
Measure the width and height of your TV hole pattern in cm.
Record your measurements:
Width__________cm x Height ________ cm
75 mm = 7.5 cm ≈ 3 in.
100 mm = 10 cm ≈ 4 in.
200 mm = 20 cm ≈ 7 7/8 in.
300 mm = 30 cm ≈ 11 3/4 in.
400 mm = 40 cm ≈ 15 3/4 in.

8
01
1-2 Assemble Your TV Bracket
Determine which TV bracket configuration to use, A, B, C, or D
based on your TV hole pattern measurements.
A7.87
[20.0]
7.87
[20.0]
3.94
[10.0]
3.94
[10.0]
15.75
[40.0]
15.75
[40.0]
3.0
[7.5]
3.0
[7.5]
in.
[cm]
in.
[cm]
Assemble TV bracket extenders 02 onto TV bracket 01 as illustrated.
Secure using eight screws 03 in the corner holes shown.
40.0 x 40.0
01
B
03
02
11.81
[30.0]
11.81
[30.0]
11.81
[30.0]
15.75
[40.0]
40.0 x 30.0
These smaller hole patterns only use TV bracket 01 .
Do not use the four TV bracket extenders 02 and eight screws 03 .
7.5 x 7.5
10.0 x 10.0
20.0 X 20.0
02
03

9
Assemble TV bracket extenders 02 onto TV bracket 01 as illustrated.
Secure using eight screws 03 in the corner holes shown.
60.0 x 40.0
01
01
C40.0 x 20.0
20.0 x 40.0
D
in.
[cm] in.
[cm]
03
Assemble TV bracket extenders 02 onto TV bracket 01 as illustrated.
Secure using eight screws 03 in the corner holes shown.
03
02
02
15.75
[40.0]
15.75
[40.0]
15.75
[40.0]
7.87
[20.0]
7.87
[20.0]
23.62
[60.0]

10
M5 M6 M8
1-3 Select TV Screw Diameter 1-4 Select TV Screw Length
Hand thread screws into the threaded inserts
on the back of your TV to determine which
screw diameter (M5, M6, or M8) to use.
FLAT BACK ROUND BACK CABLESINSET HOLES
If your TV has a flat back AND you want your TV closer to the
wall, use the shorter screws.
Spacers and longer screws are supplied to accommodate:
●Round/irregular back TVs
●TVs with inset mounting holes
●Extra space needed for cables
Too Long
CAUTION:
Verify adequate thread
engagment with the screw or
screw/spacer combination.
-Too short will not hold the TV.
-Too long will damage the TV.
Too Short
Correct
Standard configurations
are shown. For special
applications, or if you
are uncertain about your
hardware selection, contact
Customer Service at 1-888-
333-9952.

11
1-5 Attach TV Bracket
TV Bracket
Configuration A
Illustrated
(with spacers)
TV Bracket
Configuration C
Illustrated
(with spacers)
Flat Back
Round Back / Extra Space
Position your TV bracket configuration (A, B, C, or D) over your TV hole pattern - making sure the bracket is centered over the TV hole pattern and
level. Secure bracket using your screw/washer (Flat Back) or spacer/screw/washer (Round Back / Extra Space) selection.
IMPORTANT: Ensure TV bracket is securely fastened before moving on to the next step.
06
04 05
07 09 10
08
12
11
13
14
04 05
Note
orientation
of hanging
and locking
tabs
Hanging
Locking

12
1 2
≤ 5/8 in.
(16 mm)
15
16 in.
(406 mm)
CAUTION: Avoid potential personal injuries and property damage!
●Drywall covering the wall must not exceed 5/8 in. (16 mm)
●Minimum wood stud size: common 2 x 4 in. (51 x 102 mm) nominal 1½ x 3½ in. (38 x 89 mm)
1. Locate your stud. Verify and mark the center of the stud by finding the stud edges using an awl, a thin nail, or an edge-to-edge stud finder.
2. Position the wall template 15 at your desired height and line up the holes with your stud center line. Level the template and tape in place.
STEP 2A Attach Wall Plate to Wall Wood Stud Option

13
3. Drill pilot holes using a 7/32 in. (5.5 mm) diameter drill bit. Remove wall plate template 15 .
IMPORTANT: Be sure to drill into the center of the stud.
IMPORTANT: Pilot holes must be drilled to a depth of 3 in. (75 mm).
4. Install wall plate 16 using lag bolts 18 . Tighten the lag bolts 18 only until the washers 17 are pulled firmly against the wall plate 16 .
CAUTION: Improper use could reduce the holding power of the lag bolt. DO NOT over-tighten the lag bolts.
3
15
3 in.
(75 mm)
4
16
18 17
7/32 in.
(5.5 mm)

14
STEP 2B Attach Wall Plate to Wall Solid Concrete or Concrete Block Option
CAUTION: Avoid potential personal injuries and property damage!
• Mount the wall plate 16 directly onto the concrete surface
• Minimum solid concrete thickness: 8 in. (203 mm)
• Minimum concrete block size: 8 x 8x 16 in. (203 x 203 x 406 mm)
• Minimum horizontal space between fasteners: 16 in. (406 mm)
1. Position the wall plate template 15 on the wall at your desired height. Level the wall plate template and mark the hole locations.
2. Drill three pilot holes using a 3/8 in. (10 mm) diameter masonry drill bit.
IMPORTANT: Pilot holes must be drilled to a depth of 3 in. (75 mm). Never drill into the mortar between blocks.
21
Concrete Installation Kit CMK1 is not included
(see page 6) Contact Customer Service
at 1-888-333-9952 to have the additional
hardware shipped directly to you.
Min.
16 in.
(406 mm)
3/8 in.
(10 mm)
3 in.
(75 mm)
15
15

15
3. Remove the wall plate template 15 and insert four anchors (Fischer UX 10 x 60 - included in the Concrete Installation Kit*).
CAUTION: Be sure the anchors are seated flush with the concrete surface.
4. Install wall plate 16 using four lag bolts and four washers (use only the lag bolts and washers from the Concrete Installation Kit*).
Tighten the lag bolts only until the washers are pulled firmly against the wall plate.
CAUTION: Improper use could reduce the holding power of the lag bolt. DO NOT over-tighten the lag bolts.
*Contact Customer Service at 1-888-333-9952 to have the Concrete Installation Kit shipped directly to you.
4
3
16
*
*

16
HEAVY! You may need assistance with this step.
STEP 3 Attach TV to Wall Plate
1. Hang the arm
19
onto the wall plate
16
by first hooking the top support, then resting the arm
19
into place.
2. Install locking screws
21
to secure arm to wall plate
16
.
NOTE: Arm
19
can slide side-to-side along the wall plate
16
for perfect positioning.
21
19 19
16
16
16
19
21
19

17
HEAVY! You may need assistance with this step.
3 4
3. Fold first section of the arm 19 against the wall plate 16 to provide stability.
4. Hang the TV bracket 01 onto the arm 19 by first hooking the top support, then resting the TV into place.
16
19
01
19
16

18
5
5. Lock the TV bracket 01 to the arm 19 with safety screw 20 .
IMPORTANT: This safety screw 20 must be installed to secure the TV bracket 01 onto the arm 19 .
19
01
19
20
20
01

19
Manage Cables
Cables can be routed through the cable channels on the top and bottom of the arm 19 and secured to the arm with zip ties 22 for a cleaner look.
19 19
01
16
16
22

20
L
o
o
s
e
n
T
i
g
h
t
e
n
TV Adjustments
TILT ADJUSTMENT
Your TV should adjust easily when moved, then stay in place.
If your TV is too loose or too tight, adjust the tilt tension knob by hand.
NOTE: Once your TV is in place, tighten the tilt tension knob to
prevent unwanted movement.
LEVEL ADJUSTMENT
To adjust the leveling of your TV, loosen the safety screw 20 , level
your TV, then tighten safety screw 20 .
IMPORTANT: This safety screw 20 must be installed to secure
the TV onto the arm 19 .
Tilt Tension Knob
19
L
o
o
s
e
n
T
i
g
h
t
e
n
20
