SATO CL408e/412e Instruction Manual

SATO EUROPE
CL408e/412ePrinter
Frequently Asked Questions

CL408e/412eFAQs
SATO EUROPE i
Contents
1. General .......................................................................................... 1
What do I receive when I buy a SATO CL408e/412e Printer? ....... 1
What options are available with my CL408e/412e? ....................... 1
Do I receive a driver with my CL408e/412e? ................................. 1
What type of software do I need for my printer? ............................ 1
Which languages does my SATO printer support? ........................ 1
Which interfaces can I use? ........................................................... 1
Can I work from my Windows ™ environment? ............................. 2
Can I work from my SAP™ environment? ..................................... 2
Can I work from AS400™? ............................................................ 2
Can I print graphics? ...................................................................... 2
Can I store label formats or True-Type™fonts and graphics in
the CL408e/412e? ......................................................................... 2
Can I print out dates and times? .................................................... 2
Can I connect weighing scales and print out the weight
of my goods? ................................................................................. 2
What is the correct carbon ribbon for the SATO CL408e/412e? .... 2
How often should I clean my SATO CL408e/412e? ....................... 3
What is a memory card? ................................................................ 3
Why do I need a memory card? ..................................................... 3
Can memory cards be used with the CL408e/412e? ..................... 3
How do I put information on to the memory card? ......................... 3
What is FLASH ROM? ................................................................... 3
2. Set-up and Use .............................................................................. 4
How do I connect my printer to my computer? .............................. 4
How do I set up my printer? ........................................................... 4
How do I load the labels? .............................................................. 4
How do I load the carbon ribbon? .................................................. 4
How do I select the label sensing method? ................................... 4
How do I change the darkness setting? ......................................... 5
How do I change the print speed? ................................................. 5
Does the CL408e/412e have a last label reprint feature? ............. 5
How do I feed a blank label? ......................................................... 5
How do I cancel my print job? ........................................................ 5

ii SATO EUROPE
FAQs CL408e/412e
3. Troubleshooting ............................................................................. 6
The display is blank. What is wrong? ............................................. 6
A label is fed but nothing is printed on it. What should I do? ......... 6
I sent a print job but nothing has happened. What do I do? .......... 6
The print quality is poor or the barcodes are not readable.
What do I do? ................................................................................ 6
My CL408e/412e does not feed out one label at a time but
feeds 20 inches of blank labels instead. What is wrong? .............. 7
My printer will not go online. Why not? .......................................... 7
My CL408e/412e will not print and beeps. What's wrong? ............ 7
The LCD displays "SENSOR ERROR".
How do I solve the problem? ......................................................... 7
The LCD displays "FRAMING ERROR". What should I do? ......... 8
The LCD displays "PAPER END". What's wrong? ......................... 8
The LCD displays "RIBBON END". What should I do? .................. 8
How do I get rid of ribbon wrinkles? ............................................... 8

CL408e/412eFAQs
SATO EUROPE 1
TOC
1. General
What do I receive when I buy a SATO CL408e/412e Printer?
Along side your SATO CL408e/412e printer you will receive a
power cable, an operation manual, an empty core for carbon ribbon
and lapping paper
What options are available with my CL408e/412e?
A guillotine cutter, a label rewinder, a dispenser including internal
backing paper rewinder, interface cards, a stand alone terminal
memory module, a keyboard, a real time clock, a separate daugh-
ter board for a PCMCIA card (16MB) and an internal SIM memory
card (4MB).
Do I receive a driver with my CL408e/412e?
Yes, the Windows™driver is available for download on the Internet
under:
www.sato-europe.com/software/download.html
What type of software do I need for my printer?
In principle, because the printer operates with a Windows driver it
can be used with any Windows ™ application. However, only SATO
software addresses all the functions of the printer, thus we recom-
mend you work with SATO's Dynamic Xtra, Dynamic Publisher or
Dynamic Aviator.
Which languages does my SATO printer support?
Display: The SATO printer display is available in English, German,
French, Spanish, Italian and Portuguese.
Driver: The properties and settings in the printer driver are avail-
able in 9 European languages.
Code Page: The middle European standard character map is avail-
able, as well as Greek, Turkish, Cyrillic, east European and
Hebrew.
Which interfaces can I use?
The printer can be connected using either ECP Parallel (IEEE 1284
bi-directional), Centronics Parallel, RS232 Standard (max
19.200bps), RS232 Highspeed (max 57.600bps), RS422/485,
USB, (12Mbit/s), LAN (TCP/IP Protocol 10/100 Base T) and IBM
Twinax/Coax.

2SATO EUROPE
FAQs CL408e/412e
TOC
Can I work from my Windows ™ environment?
Yes. A SATO printer can work from with any Windows ™ system,
as long as the corresponding driver is used.
Can I work from my SAP™ environment?
Yes. The SATO Dynamic Aviator software includes an option that
makes it possible to export label data to SAP R/3 ™.
Can I work from AS400™?
Every SATO printer can be switched over to non-standard protocol.
Data can then be sent to the printer via an IBM Twinax/Coax inter-
face.
Can I print graphics?
Yes, graphics, which correspond to the printer driver, can be printed
from every windows application. Using the SATO label-design soft-
ware you can also print BMP, PCX, GIF, PUT, WMF and JPEG files.
Can I store label formats or True-Type™ fonts and graphics in
the CL408e/412e?
Yes. A memory card option is available enabling the storage of label
formats, True-type fonts™ and graphics.
Can I print out dates and times?
Yes. Dates and time fields can be printed out when the Real Time
Clock (RTC) option is installed. The RTC option is controlled by pro-
gramming the printer or by using the Dynamic range of software
from SATO.
Can I connect weighing scales and print out the weight of my
goods?
Yes, if you program electric industry scales to send a message to
the printer, using the SATO programming language and also use a
suitable interface.
What is the correct carbon ribbon for the SATO CL408e/412e?
There is not a specific carbon ribbon suitable for SATO printers.
The choice of carbon ribbon must always be made while consider-
ing the label material and application. Your local SATO supplier will
be able to advise you.

CL408e/412eFAQs
SATO EUROPE 3
TOC
How often should I clean my SATO CL408e/412e?
SATO printers need very little maintenance other than the occa-
sional clean. By using the SATO Thermal Printer Cleaning Kit you
will be ensuring the longevity of your printer.
What is a memory card?
A memory card saves information, which can be used again later.
The battery back up means that information cannot be lost.
Why do I need a memory card?
The memory card enables True-Type™ fonts, graphics and formats
to be saved. Should the formats be of a large volume i.e. a large
amount of data, the memory card can shorten the processing time.
Moreover, the memory card can be used to increase the length of
the label printed.
Can memory cards be used with the CL408e/412e?
Yes. This option provides the connectors and interface board for a
PCMCIA memory card slot, accessible on the back panel. The
printer memory can be expanded up to 4MB using a SIM Card and
16 MB with a PCMCIA card
How do I put information on to the memory card?
In order to save information on to the memory card, the SATO
Memory Card Manager or the Dynamic Memory Card Compiler,
which is available as part of the SATO Dynamic Aviator software
package, can be used. It is also possible to put data on to the card
via direct programming using <ESC> codes. Please note that a
SATO Europe PCMCIA MB package is available, which includes a
memory card adaptor board, a PCMCIA memory card and the
SATO Memory Card Manager software.
What is FLASH ROM?
This is the internal printer memory that can be used to save mem-
ory in the same way that the memory card is used. The CL408e/
412e had a standard internal flash rom memory of 2MB

4SATO EUROPE
FAQs CL408e/412e
TOC
2. Set-up and Use
How do I connect my printer to my computer?
To connect the SATO printer CL408e/412e to a PC or host, the fol-
lowing interfaces are available: ECP Parallel (IEEE 1284), Centron-
ics Parallel, RS232 Standard, RS232 Highspeed, USB,(12Mbit/s),
LAN (TCP/IP Protocol 10/100 Base T), IBM Twinax/Coax, RS422/
485.
How do I set up my printer?
After connecting the interface, you must plug the AC power cable
provided into the back of the printer and connect it to a suitable
power supply. The labels must be installed and if using the thermal
transfer mode, carbon ribbon must be installed too. Also remember
to confirm that the print head has been closed firmly. A diagram for
loading labels and carbon ribbon is provided on the inside of the
printer cover.
How do I load the labels?
The label rolls are to be placed on the label roll spindle and pushed
into position with the green label roll retainer. The labels must be
wound face-in on the roll and should feed from the bottom. Please
refer to the diagram on the inside of the printer cover
How do I load the carbon ribbon?
Open the door of the printer and open the print head. Referring to
the diagram, on the inside of the CL408e/412e's cover, position the
ribbon roll firmly on to the ribbon supply spindle and place the
empty core on the ribbon take-up spindle. Tape the free end of the
ribbon to the take-up core, so that it will catch when rotating in a
clockwise direction.
How do I select the label sensing method?
The CL408e/412e label sensing method is controlled by the DIP
switches. The DIP function chart has been positioned on the inside
of the cover. The printer however will be delivered set for label gap
sensing (DSW2-2, DSW3-3 both in the OFF position). If you wish
the sensor to read an I-mark please refer to the DIP Switch function
chart.

CL408e/412eFAQs
SATO EUROPE 5
TOC
How do I change the darkness setting?
There are 5 darkness settings. The highest numbers represent the
darker settings and the current setting is indicated by an underline
under one of the range settings. To view the settings you must go
into the User mode by pressing the LINE key once (the printer dis-
play shows OFFLINE). Next, press the FEED and LINE keys simul-
taneously to see "PRINT DARKNESS" on the display. To move the
underline to the desired setting, press the LINE key. Once the cor-
rect setting is underlined press the FEED key to accept and
advance to the next adjustment.
How do I change the print speed?
There are 5 print speed settings (50, 75, 100, 125 and 150mm/s).
To view the settings you must enter the User mode by pressing the
LINE key once (the printer display shows OFFLINE). Next, press
the FEED and LINE keys simultaneously to view "PRINT DARK-
NESS" on the display. Press FEED again to advance to the print
speed setting. Now press the LINE key to move the underline to the
desired setting. Press FEED to confirm it. (NOTE: This setting can
be overwritten by software).
Does the CL408e/412e have a last label reprint feature?
Yes. You must press the FEED key, while in online mode, to reprint
the last label.
How do I feed a blank label?
Press the FEED button while the printer is offline to feed a blank
label. If you have problems check that the print media has been
loaded properly
How do I cancel my print job?
The current print job can be cancelled by using the display: set the
printer offline and press the LINE and FEED buttons simulta-
neously. Next, press the FEED button until the display shows "can-
cel current print job". Use the LINE button to select YES or NO and
FEED to clear.
A command to cancel the print job can also be sent to the driver via
the software. Alternatively, switching the printer off and on again will
also erase all current print jobs.

6SATO EUROPE
FAQs CL408e/412e
TOC
3. Troubleshooting
The display is blank. What is wrong?
• Check that the power switch is turned on.
• Check that all cable connections have been made properly.
• Check that the supply cable is not damaged.
• Make sure the fuse is O.K.
A label is fed but nothing is printed on it. What should I do?
• Confirm that the label is wide enough for the image being
printed.
• If you are using direct thermal mode, make sure you have direct
thermal labels installed.
• If you are using thermal transfer mode, check that the carbon
ribbon is installed properly with the ink (dull side) coming into
contact with the labels. Check that the print head is clean.
• Make sure that the carbon ribbon and label are compatible.
• Check to see if the pitch sensor is dirty or obstructed in some
way.
I sent a print job but nothing has happened. What do I do?
Firstly confirm that the connections have all been made and that
the interface has been connected to the correct port on the PC.
Make sure the printer is on-line and check to see if there are any
error messages in the display. Also make sure that you are sending
the data to the correct printer. The printer listed in the Print Set-up
window should be "CL408e/412e"
The print quality is poor or the barcodes are not readable.
What do I do?
• Make sure the print media is loaded properly and that there is
no side-to-side motion as the paper passes through the printer.
• Check that the software print settings are not set too dark /too
light. Adjust the darkness settings or print speed, via the soft-
ware, if necessary.
• Try different print media. Old or inferior quality material will
degrade the print quality.

CL408e/412eFAQs
SATO EUROPE 7
TOC
• Check for wrinkles on the carbon ribbon.
• Make sure the print head is clean.
• Unreadable barcodes can also occur if the barcode size is too
big or too small. Confirm that they are within barcode specifica-
tions.
• Confirm that the scanner is set up to read the barcode type
printed.
• Make sure you are printing a standard barcode symbology and
that the characters you are trying to encode are legitimate.
• Make sure that the label media and the carbon ribbon are com-
patible. Resin-based ribbons are not always compatible to rough
low quality labels and wax- based ribbons do not always adhere
well to some synthetic label material.
My CL408e/412e does not feed out one label at a time but
feeds 20 inches of blank labels instead. What is wrong?
It is possible that you have the wrong label sensing method
switched on for the media you are using. Check the DIP switches
against the DIP switch function guide on the inside of the top cover
to see if you have selected the appropriate method for you paper.
If you are using the label gap method, check that the gap between
the labels is more than 3mm, or if using the I-mark method, that the
I-mark is bold and also more than 3mm. Finally, confirm that the
label is passing over the sensor.
My printer will not go online. Why not?
Is the power LED illuminated? If not, check the power switch is on
and confirm the power supply and connections. Also confirm that
the print head has been closed properly.
My CL408e/412e will not print and beeps. What's wrong?
The printer is trying to receive incorrect data. Make sure you are
sending data in the correct format.
The LCD displays "SENSOR ERROR". How do I solve the
problem?
Confirm that the sensing method selected matches that of the
media used and that the media has been routed under the sensor.

8SATO EUROPE
FAQs CL408e/412e
TOC
The CL408e/412e should be delivered ready to detect a gap label
(DSW-2-2=OFF). Make sure that the gap between labels is also
more than 3mm; otherwise it will not be detected. If using the I-mark
sensing method (black bar between each label) DSW2 must be ON
and the I-mark must be more than 3mm wide and bold.
The LCD displays "FRAMING ERROR". What should I do?
"Framing Error" appears on the LCD screen when the printer is
unable to interpret the data sent. Confirm that the communication
format between the printer and host are compatible.
The LCD displays "PAPER END". What's wrong?
Confirm that the labels are positioned correctly and have not run
out.
The LCD displays "RIBBON END". What should I do?
• Are you printing on to thermal paper, but have not changed the
DSW2-1 to ON to configure the printer for direct thermal print-
ing?
• Check that the ribbon is not sticking to the label. This can hap-
pen if the darkness setting is too high.
• Confirm that the ribbon spindle is rotating freely on the spindle.
If it is not an error message will appear.
How do I get rid of ribbon wrinkles?
Raise the print head and confirm that the ribbon cores are correctly
positioned on the spindles. Turn the ribbon take-up knob clockwise,
confirming the ribbon runs smoothly. If the ribbon binds, remove the
ribbon cores and examine the spools, spool springs and gears for
damage.

CL408e/412eFAQs
SATO EUROPE 9
TOC
This page is intentionally left blank.

10 SATO EUROPE
FAQs CL408e/412e
TOC
Sato Europe
Halskestr. 15-19
40880 Ratingen
Germany
Tel:[phone]
Fax: [phone]
www.sato-europe.com
