SATO M-5900RVe Series User manual

PN 9001121B
M5900RVe PRINTER
PARTS LIST

SATO America, Inc.
10350A Nations Ford Road
Charlotte, NC 28273
Main Phone: [phone]
Technical Support Hotline: [phone]
Technical Support Fax: [phone]
E-Mail: satosale[email protected]
www.satoamerica.com

SATO M5900RVe Parts List PN 9001121B Page 1
FRAME ASSEMBLY WITH DRIVE TRAIN
Figure PL1a, Frame Assembly
Figure PL1b, Frame Assembly

SATO M5900RVe Parts List PN 9001121B Page 2
FRAME ASSEMBLY WITH DRIVE TRAIN
ITEM PART NUMBER PART DESCRIPTION QTY
1 PA2520600 LEFT FRAME MEMBER 1
2 PB2520200 COLLAR 1
3 MA0401021 PAN HEAD SCREW 1
4 PV9720200 BUSH 1
5 PA2520700 RIGHT FRAME MEMBER 1
6 PB2520200 COLLAR 1
7 MA0401021 PAN HEAD SCREW 1
8 PA3522500 LOWER BRACKET 1
9 MH4300821 PAN HEAD SCREW, S-TIGHT 4
11 PA3522600 PAPER RAMP 1
12 MH4300821 PAN HEAD SCREW, S-TIGHT 4
13 PE1570801 SENSOR WINDOW 2
14 PA3523700 FRONT BRACE 1
15 MH4300621 PAN HEAD SCREW, S-TIGHT 3
16 PE3520400 SPACER 2
17 PE3520500 ROLLER 2
18 MA0301022 PAN HEAD SCREW 2
21 PE2520300 KNOB CAP 1
22 PC1520200 SPRING 1
23 PE3520101 KNOB 1
24 PM6401200 BUSH 1
25 PT9520400 WASHER 1
26 MH0300821 PAN HEAD SCREW, P-TIGHT 1
27 PE1520300 LABEL GUIDE, BLACK PLASTIC 1
28 MH0300821 PAN HEAD SCREW, P-TIGHT 1
31 PR7520100 MOTOR, STEPPER 1
32 PR7520200 MOTOR PULLEY 1
33 PT8122064 TIMING BELT 1
34 PA3522700 SENSOR BRACKET 1
35 MD4300621 PAN HEAD SCREW W/LARGE FLAT & LOCK WASHER 2
36 MD4401421 PAN HEAD SCREW W/LARGE FLAT & LOCK WASHER 2
37 PA1190000 PLATE NUT 2
40 RJ3520000 SENSOR 1
41 RH1523300 HEAD OPEN SWITCH 1
42 MD3201221 PAN HEAD SCREW W/NARROW FLAT & LOCK WASHER 2
43 PR1520300 PLATEN ROLLER 1
45 PA1680200 RETAINING CLAMP 1
46 MD4300621 PAN HEAD SCREW W/LARGE FLAT & LOCK WASHER 1
47 MD4300821 PAN HEAD SCREW W/LARGE FLAT & LOCK WASHER 5

SATO M5900RVe Parts List PN 9001121B Page 3
HOUSING AND ELECTRONICS ASSEMBLIES
Figure PL2a, Housing Cover Assembly
Figure PL2b, Housing Cover Assembly

SATO M5900RVe Parts List PN 9001121B Page 4
Figure PL2c, Housing cover Assembly
Figure PL2d, Housing Cover Assembly

SATO M5900RVe Parts List PN 9001121B Page 5
Figure PL2e, Housing Cover Assembly
Figure PL2f, Housing Cover Assembly

SATO M5900RVe Parts List PN 9001121B Page 6
HOUSING AND ELECTRONICS ASSEMBLIES
ITEM PART NUMBER PART DESCRIPTION QTY
1 P00893000 BASE ASSEMBLY 1
2 P00796000 BOOT, RUBBER 3
3 P00319010 CENTER FRAME 1
4 MH4300821 PAN HEAD SCREW 3
5 PH1523300 FRONT PLATE 1
6 MH4300821 PAN HEAD SCREW 5
7 PV9520300 BUSH 1
8 P00316000 REAR HOUSING COVER 1
9 MD4300621 PAN HEAD SCREW W/LARGE FLAT & LOCK WASHER 2
10 MD4300621 PAN HEAD SCREW W/LARGE FLAT & LOCK WASHER 3
11 PE6771001 MEMORY CARD 1
12 PB5A20001 THUMB SCREW, KNURLED 1
13 PV2760100 BOOT, RUBBER 1
15 PE1720300 LABEL GUIDE 1
16 PA3524000 LABEL SUPPLY BRACKET 1
17 PA4520300 LABEL GUIDE SPRING 1
18 NA1003022 FLAT WASHER 1
19 MH0300821 PAN HEAD SCREW, P-TIGHT 1
20 MD4300621 PAN HEAD SCREW W/LARGE FLAT & LOCK WASHER 4
23 PE1520600 REWIND SHAFT BRACKET, PLASTIC, BLACK 1
24 MH4300821 PAN HEAD SCREW 3
25 PE2520101 SPACER 1
26 MA0401621 PAN HEAD SCREW 1
27 P00321000 CIRCUIT BOARD BRACKET 1
28 MD4300621 PAN HEAD SCREW W/LARGE FLAT & LOCK WASHER 4
31 KA500631A POWER BOARD ASSEMBLY 1
32 HD100321A CERAMIC FUSE, 250V/3.15A 1
33 MD4300621 PAN HEAD SCREW W/LARGE FLAT & LOCK WASHER 2
36 MD4300821 PAN HEAD SCREW, P-TIGHT 2
37 RH1775100 POWER/HEAD WIRING HARNESS 1
39 Q00128000 ADHESIVE LABEL 1
40 PH0520700 FRONT HOUSING COVER (A), PLASTIC, GREY 1
41 MH0300821 PAN HEAD SCREW, P-TIGHT 5
42 PH0520800 DIP SWITCH COVER, PLASTIC, GREY 1
43 PH2520700 PANEL, CLEAR PLASTIC 1
44 PE1520800 SWITCH BUTTON 1
46 P00532000 FRONT HOUSING COVER (B), PLASTIC, GREY 1
47 MH0300821 PAN HEAD SCREW, P-TIGHT 4
48 PH1523500 RIGHT HOUSING COVER 1

SATO M5900RVe Parts List PN 9001121B Page 7
49 MD4300621 PAN HEAD SCREW W/LARGE FLAT & LOCK WASHER 7
50 P00317000 LEFT HOUSING COVER 1
52 PV3520700 FRONT HOUSING COVER (C) 1
55 RH1745700 LCD BOARD W/WIRING HARNESS 1
56 RJ2522020 PANEL BOARD 1
57 RH1770500 PANEL BOARD WIRING HARNESS 1
58 MH0300821 PAN HEAD SCREW, P-TIGHT 1
62 R00459000 MAIN CIRCUIT BOARD 1
63 CJ058651A EEPROM 1
64 RJ7770200 MEMORY CARD 1
65 PA3739900 CONNECTOR LOCK 1
66 PC9730100 LOCK SPRING 1
67 CV617431A REAL-TIME CLOCK (OPTION) 1
68 MD4300621 PAN HEAD SCREW 3
69 RJ7770300 4MB MEMORY CARD (OPTION) 1
80 RJ4770100 EXPANSION BOARD (OPTION) 1
HOUSING AND ELECTRONICS ASSEMBLIES
ITEM PART NUMBER PART DESCRIPTION QTY

SATO M5900RVe Parts List PN 9001121B Page 8
PRINT ASSEMBLY
Figure PL3a, Print Assembly
Figure PL3b, Print Assembly

SATO M5900RVe Parts List PN 9001121B Page 9
PRINT ASSEMBLY
ITEM PART NUMBER PART DESCRIPTION QTY
1 PA3522800 LOWER PRINT ASSEMBLY BRACKET 1
2 PC1520100 HEAD BALANCE SPRING 2
3 PA2520300 PRINT HEAD PLATE 1
4 MP7300522 HEX HEAD SCREW W/LARGE FLAT & LOCK WASHERS 2
5 PA3525200 LABEL TEAR BAR 1
6 QC6521400 ADHESIVE LABEL, CUTTER CAUTION 1
7 GH000741A THERMAL PRINT HEAD 1
9 QC6522100 ADHESIVE LABEL, CUTTER CAUTION 1
12 PR1521100 PRINT HEAD MOUNT PLATE 1
14 MD4300821 PAN HEAD SCREW W/LARGE FLAT & LOCK WASHERS 1
17 R00437000 PRINT HEAD WIRING HARNESS 1
20 PA3523300 GAP SENSOR BRACKET, METAL 1
21 PE1631200 GAP SENSOR BRACKET, PLASTIC, BLACK 1
22 MD4300621 PAN HEAD SCREW W/LARGE FLAT & LOCK WASHERS 2
23 MH250621 PAN HEAD SCREW, P-TIGHT 1
24 JG100011A CABLE TIE 1
25 RH1522200 GAP SENSOR ASSEMBLY 1
26 PA4520200 PAPER PRESSURE PLATE 1
27 MD4300621 PAN HEAD SCREW W/LARGE FLAT & LOCK WASHERS 2
31 PA3523000 UPPER PRINT ASSEMBLY BRACKET 1
32 PB0520800 PRINT ASSEMBLY SHAFT 1
33 MA1300422 FLAT HEAD SCREW 1
34 MH4300821 PAN HEAD SCREW, S-TIGHT 1
35 NA1003022 FLAT WASHER 1
36 ND0070030 SNAP RING, TYPE E 1
37 PA3523400 LATCH LEVER 1
38 PC2520100 TORQUE SPRING (A) 1
39 PC2520201 TORQUE SPRING (B) 1
41 PB2520200 COLLAR (A) 1
42 PB2520300 COLLAR (B) 1
43 MJ9401021 THIN HEAD SCREW 2
44 PA2521000 ADJUSTMENT PLATE 1
45 PB5550100 ECCENTRIC NUT 1
46 MD4300621 PAN HEAD SCREW W/LARGE FLAT & LOCK WASHERS 2
47 MD4300821 PAN HEAD SCREW W/LARGE FLAT & LOCK WASHERS 1
48 PE1520100 LEVER HANDLE, PLASTIC, GREEN 2
50 QC6524200 ADHESIVE LABEL, CAUTION HOT 1

SATO M5900RVe Parts List PN 9001121B Page 10
DISPENSER ASSEMBLY
Figure PL4a, Dispenser Assembly
Figure PL4b, Dispenser Assembly

SATO M5900RVe Parts List PN 9001121B Page 11
Figure PL4c, Dispenser Assembly
DISPENSER ASSEMBLY
ITEM PART NUMBER PART DESCRIPTION QTY
1 PA3523100 DISPENSER BRACKET 1
2 PT9690500 TCV CAP 1
3 PB0521300 SPRING POST (A) 2
4 PB0521500 DISPENSER BRACKET SHAFT 1
5 ND0060030 SNAP RING, TYPE E 2
6 PB5550100 ECCENTRIC NUT 1
7 MD4300821 PAN HEAD SCREW W/LARGE FLAT & LOCK WASHERS 2
8 PB0521600 DISPENSER ROLLER SHAFT 1
9 PE3520600 DISPENSER ROLLER 5
10 ND0020030 SNAP RING, TYPE E 1
11 PR1520200 PRESSURE ROLLER 1
12 PB0521800 PRESSURE ROLLER SHAFT 1
13 ND0040030 SNAP RING, TYPE E 2
15 PA3523200 SENSOR BRACKET, METAL 1
16 PE1570300 SENSOR BRACKET, PLASTIC, BLACK 2
17 MH0250621 PAN HEAD SCREW, P-TIGHT 2
18 RH1522900 DISPENSER SENSOR ASSEMBLY 1

SATO M5900RVe Parts List PN 9001121B Page 12
19 MH4300821 PAN HEAD SCREW, S-TIGHT 2
22 PA2520800 PEELER BAR 1
23 MD4300621 PAN HEAD SCREW W/LARGE FLAT & LOCK WASHERS 1
24 PB0521400 SPRING POST (B) 2
25 MD4300621 PAN HEAD SCREW W/LARGE FLAT & LOCK WASHERS 2
26 PC2520300 PRESSURE SPRING 2
29 PB0522401 PAPER REWINDER SHAFT 1
30 PA0520300 PAPER REWINDER MOUNTING PLATE 1
31 PA1520500 TENSION PLATE 1
32 PE2520500 GUIDE COLLAR 1
33 PC1520400 REWINDER SPRING 1
34 PA0770100 FLANGE 1
35 PJ4770100 FACING, 9x26x2 2
36 PE8770400 PULLEY, 50 TOOTH 1
37 PE7770100 FLANGE, 8x26 1
39 PA3525300 REWIND FRAME 1
40 PT1112080 BALL SUPPORTER 2
41 PT8134064 MINI PITCH BELT 1
42 ND0060030 SNAP RING, TYPE E 2
43 MD4300621 PAN HEAD SCREW W/LARGE FLAT & LOCK WASHERS 2
44 MA0300621 PAN HEAD SCREW 2
45 PE4770100 REWINDING CORE 1
46 PE4770200 REWINDING BOSS 1
47 PE1520700 REWINDING HANDLE 1
48 MD4301221 PAN HEAD SCREW W/LARGE FLAT & LOCK WASHERS 1
49 MD4401021 PAN HEAD SCREW W/LARGE FLAT & LOCK WASHERS 1
51 MH4300821 PAN HEAD SCREW, S-TIGHT 3
52 MD4401021 PAN HEAD SCREW W/LARGE FLAT & LOCK WASHERS 1
54 PA3525401 TENSION BRACKET 1
55 PA3525500 PLATE NUT 1
56 PE3720100 TENSION ROLLER 1
57 PB2720600 COLLAR, 4x6x9.2 1
58 MD4401621 PAN HEAD SCREW W/LARGE FLAT & LOCK WASHERS 1
DISPENSER ASSEMBLY
ITEM PART NUMBER PART DESCRIPTION QTY

SATO M5900RVe Parts List PN 9001121B Page 13
CUTTER ASSEMBLY
Figure PL5, Cutter Assmbly
CUTTER ASSEMBLY
ITEM PART NUMBER PART DESCRIPTION QTY
1 PR7522100 CUTTER ASSEMBLY 1
2 MD4300621 PAN HEAD SCREW W/NARROW FLAT & LOCK WASHERS 2
3 MH4300821 PAN HEAD SCREW, S-TIGHT 2
4 RJ4520100 CUTTER CIRCUIT BOARD 1
5 MD4300621 PAN HEAD SCREW W/NARROW FLAT & LOCK WASHERS 2
6 RH1683400 GROUND CABLE 1
7 RH1522600 CUTTER WIRING HARNESS 1
