SCANCLIMBER LT500 User manual

LT500 SERIAL NO:________
INSTRUCTION MANUAL
OY SCANINTER NOKIA LTD
• Turkkirata 26 • FI-33960 PIRKKALA, FINLAND •
• TEL. [phone] • FAX. [phone] •
V24_06.04
Lifting table
LT500

2
I n s t r u c t i o n m a n u a l
LT500 V24_06.04

I n s t r u c t i o n m a n u a l
LT500
V24_06.04
1
TABLE OF CONTENTS
LIFTING TABLE LT500 .................................................................
1. General information .................................................. 3
2. Technical data ........................................................... 4
2.1 Capacity .............................................................................4
2.2 Technical measures and weights .....................................4
2.3 Electrical data ....................................................................4
2.4 Technical data of electrical chain winch, optional ........4
3. Components ............................................................... 5
4. Instruction and warning decals ................................ 6
5. Electric drawing ......................................................... 8

2
I n s t r u c t i o n m a n u a l
LT500 V24_06.04

I n s t r u c t i o n m a n u a l
LT500
V24_06.04
3
The lifting table LT500 can be used for transporting material to a height of 0,3
- 1,6 meters. The maximum load capacity is 500 kg.
The lifting table is set to a desired position with jacks (4). The loading procedu-
re is carried out through a loading bridge. The table is lifted up and lowered
with an electrical chain winch (optional).
LIFTING TABLE LT500
1. General information
DO NOT ENTER UNDER THE
LIFTING TABLE
☞
PERSONNEL TRANSPORT IS
FORBIDDEN ON THE
LIFTING TABLE
☞

4
I n s t r u c t i o n m a n u a l
LT500 V24_06.04
Loading capacity 500 kg
Lifting height 300 - 1600 mm
2. Technical data
Table l x w 1600 x 1200 mm
Railing height 1100 mm
Weight (without chain winch) 369 kg
Power supply
3- phase +N+PE , socket CCE
400 VAC
16 Amp
Power supply 400 VAC, 50 Hz
Motor power 0,64 kW
Current 1,14 A
Lifting speed 0,1 m/s
2.1. Capacity
2.2. Technical measures and weights
2.3. Electrical data
2.4 Technical data of electrical chain winch, optional

I n s t r u c t i o n m a n u a l
LT500
V24_06.04
5
9
11
8
10
7LT500_4
PARTS LIST LT500
6
300 - 1600
2450
LT500_2
1 Frame PG104992
2 Telescopic beam PG104648
3 Platform complete PG104995
4 Wheel complete PG104639
5 Jack 07010100
6 Electrical chain winch, optional
CPM 6-6 YALE 50723096
7 Loading bridge PG105091
8 Railing PG105020
9 Roller complete PG104994
10 Grid PG105086
11 Grid PG104553
3. Components

6
I n s t r u c t i o n m a n u a l
LT500 V24_06.04
4. Instruction and warning decals
LIFTING TABLE
T01_LT500
500 kg
kg
T02_LT500

I n s t r u c t i o n m a n u a l
LT500
V24_06.04
7
T03_LT500

8
I n s t r u c t i o n m a n u a l
LT500 V24_06.04
5. Electric drawing
CHAIN WINCH
POWER SUPPLY
-PLUG (BALS 2624) 16 A
Q MAIN SWITCH (TELEMECANIQUE VCF0GE)
SCANCLIMBER®
