SC&T AE01-T User manual

Smart Cabling & Transmission Corp. V1.0
Audio Extender Series
User Manual
Model : AE01-T
Analog Audio CAT5e Extender - Terminal Termination
2pcs/1set

1
User Manual
AE01-T
Introduction
AE01-T is an audio extender designed to use a twisted pair cable to carry the signal, with the transmission
distance up to 600M. It can be perfectly used in home theatre systems, schools, auditoriums and
convention halls…etc.
Features
Extends audio signal over a twisted pair cable.
Signal extension up to 600M.
No power required...
Installation View

2
User Manual
AE01-T
Specification
ITEM NO.
AE01-T
Support
Audio Bandwidth
20Hz to 20Khz
Max. Transmission Distance
600M over a Twisted Pair CAT5 (AWG24)
Ports & Interfaces
Audio Input/ Output
1 x RCA (2V p-p, 75 Ohms)
Audio Interface
1 x 2-pin Screw Terminal
Power
Power Supply
5V 1A
Power Consumption
80mA (Typical), 110mA (Max)
Ambient Temperature
Operation
0 to 55℃
Storage
-20 to 85℃
Humidity
Up to 95%
Physical Characteristics
Dimensions
59.3 x 25 x 20.7mm
Weight
25g
