Scantool 25A User manual

Ma
nu
a
l
SCANTOOL
DRILL PRESS
25A
Industrivej 3-9
DK-9460 Brovst
Tel.: [phone]
Fax: [phone]

EU declaration of conformity
SCANTOOL A/S
Industrivej 3-9
9460 Brovst
Denmark
Website: www.scantool-group.dk
Ph.: [phone]
Fax.: [phone]
hereby declares that
Scantool DRILL PRESS 25A is manufactured in accordance with the
provisions of the COUNCIL DIRECTIVE of 17. May 2006 (2006/42/EC) – The
Machinery Directive (order no. 561 of 25 June 1994 with subsequent
amendments)
Also on accordance with:
•
The council directive of 19 February 1973 (73/23/EEC) – The Low
Voltage Directive – with later amendments (order no. 797 of 30 August
1994)
•
The council directive of 3 May 1989 (89/336/EEC) – The EMC Directive
– with later amendments (order no. 796 of 5 December 1991 with
subsequent amendments)

Table of Contents
General safety instructions for Power Tools………………….…………….1-4
Main specification………………………………………………………………...5
Unpacking and checking contents……………………………………………5
List of loose parts in the box and bags………………………………………6
Getting to know your drill press……………………………………………….7
Assembly…………………………………………………………………………..8
Lubrication………………………………………………………………………...9
Maintenance……………………………………………………………………….9
Wire diagram……………………………………………………………………9-10
Trouble shooting………………………………………………………………….11
Repair parts……………………………………………………………………12-16
Warranty……………………………………………………………………………17
General safety instructions for Power Tools
1: KNOW YOUR POWER TOOL
Read and understand the owner’s manual and labels affixed to the tool. Learn its
application and limitations as well as the specific potential hazards peculiar to
this tool.
2. GROUND ALL TOOLS
This tool is equipped with an approved 3 conductor and a 3 prong grounding
type plug to fit the proper grounding type receptacle.
3. KEEP GUARDS IN PLACE
In working order and in proper adjustment and alignment.
4. WEAR PROPER APPAREL
Do not wear loose clothing,gloves,neckties,or jewelry (rings,wrist,watches) to
get caught in moving parts. Wear protective hair covering to contain long hair.
Roll long sleeves above the elbow.
5. USE SAFETY GOGGLES
6. KEEP WORK AREA CLEAN
Cluttered areas and benches invite accidents. Floor must not be slippery due to
wax or sawdust.
7. KEEP CHILDREN AWAY
.1.

General Safety Rules
WARNING: When using electric tools basic safety precautions should
always be followed to reduce the risk of fire, electric shock and personal
injury.
Safety rules for stationary power tools.
Follow them to achieve best results and full benefit from your new machine.
The good craftsman
respects the tools with which
he works. He knows they
represent years of
constantly improved design.
He also knows that they are
dangerous if misused.
The safetyrules are based
on approved practices in industrial and home
shops.
1. Know
your power
tool. Read
the owner’s
manual
carefully.
Learn its
applications
and limitations, as well as the specific
potential hazards peculiar to this tool.
2. Keep guard in
place and in working
order.
3. Ground all tools. If tool is equipped with
three-prong plug, it should be plugged into a
three-hole
electrical
receptacle. If
an adapter is
used to
accommodate
a two-prong receptacle, the adapter wire
must be attached to a known ground. Never
remove the third prong.
4. Remove adjusting
keys and wrenches.
Form habit of
checking to see that
keys and adjusting
wrenches is
removed before
turning it on.
5. Cluttered
areas and
benches invite
accidents.

6. Avoid dangerous
environment. Don’t use
power tools in damp or
wet locations or expose
them to rain. Keep your
work area well lighted.
6. Keep
children away.
All visitors
should be kept
in a safe
distance from
work area.
8. Make
workshop kid
proof with
padlocks, master
switches, or by
removing starter
keys.
9. Don’t force tool. It will do the job better
and be safer at the rate for which it was
designed.
.
10. Use right
tool. Don’t
force tool or
attachmentto
do a job it
was not
designed for.
11. Wear proper apparel. Wear no loose
clothing, gloves, neckties, rings, bracelets,
or other jewellery which may get caught in
moving parts.
Non-slip
footwear is
recommended.
Wear protective
hair covering to
contain long
hair.
12. Always use safety
glasses.Also use face
or dust mask if cutting
operation is dusty.
Everyday eyeglasses
only have impact
resistant lenses. They
are NOT safety glasses.
13. Secure works. Use clamps or vices to hold
works, when
practical. It’s safer
than using your
hands and it frees
both hands to
operate tool.

14.
Don’t
overreach. Keep proper footing and balance at
all times.
15. Maintain tools
with care. Keep tools
sharp and clean for
best and safest
performance. Follow
instructions for
lubricating and
changing
accessories.
16. Disconnect tools
before servicing and
when changing
accessories such as
grinding wheels, polishing
mops, grinding belts,
blades, bits, cutters, etc.
Never leave a running
machine, wait till the Machine has stopped. If
parts of the machine are out of order the
Machine should not be used before it has been
repaired.
17. Reduce the
risk of
unintentional
starting. Make
sure switch is in
off position
before plugging
in.
18. Use recommendedaccessories. Consult
owner’s manual for recommended accessories.
Use of improper accessoriesmay cause risk of
injury to persons.
19. Never work in a way that can hurt you.
Do not stand in a bent position. Stand
straight.Alcohol and other drugs are not to
be taken while working with the machine.

Main Specification
Chuck Capacity 20mm
Distance, Spindle to column 254mm
Max.Spindle travel 120mm
Max.distance chuck to table 595mm
Max.distance chuck to base 1075mm
Overall dimensions (LXMXH) 1727x760x475mm
Net Weight 125KGS
Range of spindle speeds
12 speeds
Motor SpeedSpindle Speeds (min-1)
50Hz 1400 min-1 120 200 250 360 400 450 9501280 1520 1840 2240 3480
60Hz 1700 min-1 150 260 300 440 490 540 1150 1550 1840 2220 2950 4200
Unpacking and checking contents
1. Unpacking and checking contents
Separate all the parts from packaging materials and check each item make
sure all items are accounted for before discarding any packing material.
Item Description Qty
A Table (square or Round )………………………………….1
B Column Support Asm………………………………………1
C Owner's Manual……………………………………..………1
D Box of Loose Parts………………………………………….1
E Bag of Loose Parts………………………………………….*
F Base……………………………………………………………1
G Head Asm………..……………………………………………1
2. Remove the protective oil that is applied to the table and column. Use any
ordinary household type grease and spot remover
3. Apply a coat of paste wax to the table and column to prevent rust. Wipe all
parts thoroughly with clean dry cloth.
.5.

List of Loose Parts in the box and bags
.6.

.7.

Assembly
Refer to the figure install all parts correctly,
tighten the screw and bolts securely.
1 Collar-Rack
2. Screw-Hex Soc Set M6*1.0-10
3 Support Table w/Indicator
4 Crank
5 Handle-Crank
6 Rack
7 Screw-Hex Soc Set M10*1.5-12
8 support Column
9 Screw-Hex Hd M12*1.75-40
10 Base
11 Tube-Column
12 Table Lock
13 Worm-Elevation
14 Table w/Scale
15 Key Chuck
16 Head Asm
.8.

Lubrication
All of the BALL BEARING are packed with grease at the factory. They require no
further lubrication. Periodically lubricate the table elevation mechanism, the
SPLINES (grooves) in the spindle, and the RACK (teeth of the quill), see
"Getting to know your drill press."
Maintenance
Frequently blow out any dust that may accumulate inside the motor.
A coat of automotive type paste was applied to the table and column will help to
keep the surfaces clean.
Wire diagram
.9.

.10.

Trouble Shooting
TROUBLEPROBABALE CAUSE REMEDY
Noisy Operation
1. Incorrect belt tension.
2. Dry Spindle.
3.Loose spindle pulley
4.Loose motor pulley
1. Adjust tension.
2. Lubricate spindle.
3. Checking tightness of retaining nut on
pulley, and tighten if necessary.
4. Tighten setscrews in pulleys.
Drill bit burns
1. Incorrect speed.
2. Chips not coming out of hole.
3.Dull drill bit
4.Feeding too slow
5.Not lubricated
1. Change speed.
2. Retract drill bit frequently to clear chips.
3. Resharpen drill bit.
4. Faster the speed.
5. Lubricate drill bit.
Drill bit leads off…
hole not round
1.Hard grain in wood or
lengths of cutting lips
and/or angles not equal
2.Bent drill bit
1. Resharpen drill bit correctly.
2. Replace drill bit.
Wood splinters on
underside 1. No "back up material" under work piece.
1.Use "back-up material"
Work piece turn
loose from hand 1. Not supported or clamped properly.
1. Support working or clamp it.
Drill bit binds in
work piece
1. Workpiece pinching drill bit or
excessive feed pressure.
2. Improper belt tension.
1. Support working or clamp it.
2. Adjust tension.
Excessive drill bit
run out or wobble
1.Bent drill bit
2. Worn spindle bearings.
3.Drill but not properly
installed in chuck
4. Chuck not properly installed.
1. Use a straight drill bit.
2. Replace bearings.
3. Install drill bit properly.
4. Install chuck properly.
Quill Returns too
slow or too fast
1. Spring has improper tension. 1. Adjust spring tension.
Chuck will not stay
attached to spindle
if falls off when
trying to install it.
1. Dirty, grease, or oil on the
tapered inside surface of chuck or
on the spindles tapered surface.
1. Using a household detergent clean the
tapered surface of the chuck and spindle
to remove all dirt, grease and oil.
.11.

Key
No.
Description
10
11
12
13
14
15
16
17
18
19
Base
Tube Column
Pin-Table Lock
Nut-Hex Hd M8*1.25
Screw-Hex Hd M20*2.5-50
Table w/Scale
Pin-Gear
Clamp-Column
Gear-Helical
Worm-Elevation
Repair Parts
FIGURE1
Key
No.
Description
1
2
3
4
5
6
7
8
9
Collar-Rack
Screw-Hex Soc Set
M6*1.0-10
Support-Table w/Indicator
Crank
Handle-Crank
Rack
Screw-Hex Soc Set
M10*1.5-12
Support-Column
Screw-Hex HdM12*1.75-40
.12.

Repair Parts
FIGURE2
Key
No.
Description
1
2
3
4
5
6
7
8
9
10
11
12
13
Nut-Lock M20*1.5
Ring-Locking
Washer
Bearing-Ball 20mm
Washer-Rubber
Tube-Quill
Key-drill
Key-Chuck
Chuck
Arbor
Spindle
Bearing-Ball 30mm
Bearing-Thrust
.13.

Key
No.
Description
11
12
13
14
15
16
17
18
19
20
21
Lock Washer Ext M6
Washer Foam
Guard-Pulley w/Labels
Ring-Retaining
Bearing-Ball 30mm
Spacer-Bearing
Insert-Pulley
Pulley-Spindle
Nut-Pulley
Belt-"V"A33
Knob
Repair Parts
FIGURE3
Key
No.
Description
1
2
3
4
5
6
7
8
9
10
Belt-"V"A29
Bearing-Ball 15mm
Pully-Center
Pivot-Ldler
Pulley-Motor
Screw-Soc Set M8*1.25-12
Screw-Pan HD M5*0.8-12
Clamp-Cord Bushing-
Rubber Screw-RD
Washer Hd M6*1.0-16
.14.

FIGURE4
.15.

Key
No.
Description
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
Screw-Hex HD M8*1.25-16
Lever-Adjusting
Support-Motor Bracket
Mount-Motor
Lockwasher 12mm
Nut-Hex M8*1.25
Motor
Nut-Hex M8*1.25
Washer 8
Cord-Motor
Screw-Hex HD M8*1.25-20
Support-Motor Bracket
knob-Motor Adjusting
Handle-Belt Tension
Screw-Soc Set M10*1.5-12
Lock-Depth Screw
Guide Scale
Knob
Rod
Hub
Ring-Depth Stop W/Scale
Pin-Stop
Screw-Soc Hd Cap
M8*1.25-30
Lock-Washer-Ext M5
Screw-Pan Cr M5*0.8-6
Key
No.
Description
26 Box Switch
27 Screw-Pan Cr M6*1.0-35
28 Switch
29 Screw-Self Tap Pan Hd
M4.2*1.4-8
30 Key-Switch
31 Cover-Switch Plate
32 Switch-Locker
33 Screw-Pan Cr M6*1.0-15
34 Lead-3"
35 Screw-Soc Hd Cap
M8*1.25-25
36 Screw Special Set
M10*1.5-27
37 Nut-Hex M10*1.5
38 Seat-Spring
39 Pin-Roll 6*16
40 Spring-Torsion
41 Cap-Spring
42 Nut-Hex M12*1.5-8
43 Cord-Power
44 Pin-Roll 2.5*10
45 Head w/Pointer and Trim
46 Connector-Wire
47 Screw-Pan Cr M6*1.0-12
48 Socket-Bulb
.16.

Warranty
If within 2 years of purchase this machine supplied by Scantool A/S becomes
defective due to faulty materials or workmanship we guarantee or replace the
machine or defective part or parts free of charge provided that:
1. The product is returned complete to one of our Service Branches or Official
Service Agents.
2. The product has not been misused or carelessly handled and in particular
has not been used in a manner contrary to the operating.
3. Repairs have not been made or attempted by other than our own Service
Staff or the staff of our Official Service Agents.
4. Documentary proof of purchase date is produced when the goods are
handed in or sent for repair.
5. Wear parts are not covered by the warranty.
.17
