Scantool TSX 1060 User manual

Industrivej 3-9
DK-9460 Brovst
Denmark
Tlf.: [phone]
Fax: [phone]
Manual
SCANTOOL TSX 1060
GUILLOTINE SHEAR

2
EC Declaration of Conformity
hereby declares that
SCANTOOL TSX 1060 GUILLOTINE SHEAR are manufactured in accordance with the
provisions of the European Parliament and Council Directive 2006/42 / EC of 17 May
2006
And also in accordance with:
•Low Voltage
•EUROPEAN PARLIAMENT AND COUNCIL DIRECTIVE 2014/35 / EU of
26 February 2014
•EMC
•EUROPEAN PARLIAMENT AND COUNCIL DIRECTIVE 2014/30 / EU of
26 February 2014
SCANTOOL A/S
Industrivej 3-9
9460 Brovst
Denmark
www.scantool.com
Tel: [phone]
Fax.: [phone]

3
TABLE OF CONTENTS
1PRODUCT DESCRIPTION 4
1.1 TECHNICAL CHARACTERISTICS 4
2. CARRIAGE AND LAYOUT CONDITIONS 4
2.1 CARRIAGE CONDITIONS 4
2.2 LAYOUT CONDITIONS 4
3. PUTTING INTO SERVICE 5
3.1 MACHINES RUNNING PLACE 5
3.2 THE MACHINE CALIBRATION ACCORDING
TO ENVIRONEMNTAL CONDITIONS 5
3.3 INSTALLATION OF THE MACHINE 5
4. WORKING CONDITIONS 5
4.1 STARTING THE MACHINE 5
4.2 THE FUNCTIONAL USE OF THE MACHINE 7
4.3 SAFETY MEASURES TO BE TAKEN DURING
THE RUNNIONG OF THE MACHENRY 7
5. PERSONEL PROTECTIVE EQUIPMENT 9
5.1 REQUIREMENTS DURING USE 9
5.2 REQUIREMENTS DURING MAINTENANCE 9
6. TRAINING OF OPERATORS 9
7. WARNINGS 9
8. MAINTENANCE INSTRUCTIONS 10

4
1 PRODUCT DESCRIPTION
1.1 Technical Characteristics
Cutting Capability : 1,5mm
Cutting Length : 1020mm
Platform Width : 600mm
Back Gauge Distance : 625mm
Machinery Width : 1030/1420mm
Machinery Length : 2475/1650mm
Machinery Height : 1080/1360mm
Machinery Weight : 363Kg
2 CARRIAGE AND LAYOUT CONDITIONS
Lift the machine with a crane by using a chain or steel rope. The equipment for the lifting
must be adequate for the machinery weight. Before carriage fix the moveable parts. Fix
the cutting arm and press. The carriage must be done by professional persons. Don’t stay
under the machine during the carriage.
It’s adequate to carry the machine in water resistant foil to protect it from the weather
conditions. Make sure that the machinery is perfectly located after loading on the truck. If
necessary, support the parts which aren’t perfectly located. Fix the machine on the truck
so it can’t be move.
ATTENTION!!!
By taking delivery control if there is any damage on the machine. If there is any damage,
note it on the delivery slip of the transporter and inform the carting agent.
WARNING
The user has to read the operating manual carefully. The user has to act according to the
instructions. Otherwise the manufacturer isn’t responsible for any accidents or damages.
2.2 Layout Conditions
For an accurate, efficient and long working of the machine, it has to be placed on an even
base. The accuracy has to be provided with the water gauge. This accuracy has to be
controlled in specific intervals. The first control has to be done after 24 hours. After the
first control, the control has to be done monthly and yearly.
For doesn’t falling over, the machine has to be installed on the ground. The falling over of
the machine can be responsible for serious damages.

5
3 PUTTING INTO SERVICE
3.1 Machines Running Place
The needed place of the machine is given in Annex-2.
During installation, pay attention to local requirements and environmental factors of the
machine. The place where the machine is going to be located has to be safe and hard.
For safety working before using the machine has to be controlled if it is exactly located or
not. There has to be enough and safety place for making period maintenance.
3.2 The Machine Calibration According to Environmental Conditions
Pay attention to environmental conditions. Don’t let the machine in moistly areas. There
has to be 500mm distance between the movable parts of the machine and the fixed parts
or the stored materials.
3.3 Installation of the Machine
SCANTOOL TSX 1060 GUILLOTINE SHEAR is delivered, ready for use. You can
calibrate the cutting arm stem with a “4 Allen” wrench.
4 WORKING CONDITIONS
4.1 Starting the Machine
You can use the machine after fixing it on hard ground.
During cutting, squeeze the working item with the press arm to block the moves. Move the
gauge hand wheel to right and left to calibrate the gauge distance. For preventing the
move of the gauge, lock up the clamping arm. Movable working items can cause
accidents. You can calibrate the weight for better cutting operation and the metal sheet
plate thickness which will be cut.

6

7
4.2 The functional use of the machine
SCANTOOL TSX 1060 GUILLOTINE SHEAR can be used for metal sheet plates till
1,5mm (st 37)
4.3 Safety measures, which has to be taken during running of the machinery.
Follow them to achieve best results and full benefit from your new machine
The very good craftsman respects the tools with
which he works. He knows they represent years
of constantly improved design. He also knows
that they are dangerous if misused.
This is the theme of a new safe-use program for
stationary power tools. The safety rules are
based on approved practices in industrial and
home shops.
1. Know your power tool. Read
the owner’s manual carefully.
Learn its applications and
limitations, as well as the
specific potential hazards
peculiar to this tool.
2. Keep guard in place
and in working order.
3. Ground all tools. If tool is equipped
with three-prong plug, it should be
plugged into a three-hole electrical
receptacle. If an adapter is used to
accommodate a two-prong
receptacle, the adapter wire must be
attached to a known ground. Never
remove the third prong.
4. Remove adjusting keys
and wrenches. Form habit of
checking to see that keys
and adjusting wrenches is
removed before turning it on.
5. Keep work area clean.
Cluttered areas and benches
invite accidents.
6. Avoid dangerous
environment. Don’t use
power tools in damp or wet
locations or expose them to
rain. Keep your work area
well lighted.
7. Keep children away. All
visitors should be kept in a
safe distance from work
area.
8. Make workshop kid proof with
padlocks, master switches, or by
removing starter keys.
9. Don’t force tool. It will do the job
better and be safer at the rate for
which it was designed.

8
17. Reduce the risk of
unintentional starting. Make sure
switch is in off position before
plugging in.
10. Use right tool. Don’t force
tool or attachment to do a job it
was not designed for.
11. Wear proper apparel. Wear no
loose clothing, gloves, neckties,
rings, bracelets, or other jewellery
which may get caught in moving
parts. Non-slip footwear is
recommended. Wear protective
hair covering to contain long hair.
12. Always use safety
glasses. Also use face or
dust mask if cutting
operation is dusty. Everyday
eyeglasses only have impact
resistant lenses. They are
NOT safety glasses.
13. Secure works. Use clamps
or vices to hold works, when
practical. It’s safer than using
your hands and it frees both
hands to operate tool.
14. Don’t overreach. Keep proper
footing and balance at all times.
16. Disconnect tools before servicing and when
changing accessories such as grinding wheels,
polishing mops, grinding belts, blades, bits,
cutters, etc.
18. Use recommended accessories.
Consult owner’s manual for
recommended accessories. Use of
improper accessories may cause risk
of injury to persons.
15. Maintain tools with
care. Keep tools sharp and
clean for best and safest
performance. Follow
instructions for lubricating
and changing accessories.

9
5 PERSONEL PROTECTIVE EQUIPMENT
5.1 Requirements during use
Under normal conditions no measures has to be taken.
5.2 Requirements during maintenance
The professional employees have to keep the required tools for maintenance and repair in
their own cupboard;
Screwdriver tools,
Wrench tools,
Lubricating gun.
The machine has to be used by learned and trained employees. The machine has to be
used in indoor areas. Keep away from flammable and inflammable substances. The
manufacture isn’t responsible for any damages caused by changing the standard
equipment of the machine. Because of SCANTOOL TSX 1060 GUILLOTINE SHEAR is
cutting with two blades the hands and fingers of the operator can be hurt of careless
working. Pay attention to observe the safety measures. Don’t take out any security parts
for any reason.
6 TRAINING OF OPERATORS
The operator has to confirm that he/she has read this operating manual and understand
everything clearly. In case of incomprehensible or missing cases contact the supplier or
manufacturer.
The operator is responsible for him/herself and other third persons during the work.
7 WARNINGS
DON’T PINCH your hand between the blades.
DON’T PINCH your hand between the press and body.
DON’T PINCH your hand between the working item and gauge.
BE SURE THAT THE MACHINE IS FIXED ON THE GROUND during the installation.

10
8 MAINTENANCE INSTRUCTIONS
Oil the cutting arm stud once a month with thin oil.

11
Oil the press arm once a
month with thin oil.
Oil the geared cogwheel once
a month with grease.
Oil the cutting arm once a
month with grease.
During the oil process move the movable parts to let the oil spread everywhere. Cases of
no oiling can cause defects on the working parts of the machine
