SCANTRONIC LTD

Glossary of T
erms
Access Code User private code (4 Digit) used to set, unset and
programme the system.
Automatic An optional automatic dialling unit fitted within the
Signalling Device alarm control unit and connected via your telephone
line to your alarm company central station.
Bell-Walk Test A routine test of all alarm detectors and warning
devices.
Chime (optional) Opening a zone programmed as Chime will cause the
internal speaker(s) to emit a warning tone
(programmed by the engineer).
Day State Normal unset system condition.
Deferred Set System function (programmed by engineer), which
(optional) delays the system setting when on ‘Part
Set’ if a zone is opened during exit time.
Duress Applicable only when a remote signalling device is
fitted. Duress code entered at the keypad will unset
the system but transmit a ‘Duress’ code to the alarm
company central station.
Entry Time A preset time delay to allow the user to reach the
control panel and unset the system.
Exit Time A preset time delay to allow the user time to leave the
premises after setting.
Exit Terminator A push button located on the outside of the premises
(optional) which is used to finally set the system.
Event Log The system memory which stores a record of alarm
events.
Final Door The last door closed by the user on exit.
Instant Set A system function (programmed by the engineer)
which over-rides the exit time when the user is
remaining on the premises with the system Part Set.
LED (Light Emitting Diode) indicator or display.
Non-Omit An alarm circuit which cannot be omitted by the user.
Numeric Keypad Part of the operator panel comprising number keys.
Omit Intentionally setting the system with alarm zone(s) not
included. Only zones programmed by the engineer for
‘Omit Enable’ can be omitted.
PA (Panic Alarm). Emergency buttons used to set off the
alarm. Will result in instantaneous transmission of
alarm signal if remote signalling is fitted.
Part Set To set only part of the alarm system.
Programme To select the system functions or options.
Set To arm the system.
Unset To disarm the system.
Valid Code A user code which has been programmed to be
accepted by the system.
24Hr Circuit An alarm circuit which has been programmed to be
armed continuously whether the system is set or not.

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
Contents
Section Title Page
INTRODUCTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
OPERATOR CODES AND DISPLAYS . . . . . . . . . . . . . . . .3
OPERATOR CODES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
NORMAL SETTING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
FINAL OR TIMED SETTING . . . . . . . . . . . . . . . . . . . . . . .4
SETTING WITH ZONES OPEN . . . . . . . . . . . . . . . . . . . . . .5
KEYSWITCH SETTING . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
PART SETTING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
SETTING WITH ZONES OMITTED . . . . . . . . . . . . . . . . . .9
OMITTING A 24HR ZONE . . . . . . . . . . . . . . . . . . . . . . . . .10
UNSETTING THE SYSTEM . . . . . . . . . . . . . . . . . . . . . . . .11
EXCEEDING THE ENTRY TIME . . . . . . . . . . . . . . . . . . . .11
STRAYING FROM THE ENTRY ROUTE . . . . . . . . . . . . .12
REMOTE RESET . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
UNSETTING AFTER AN ALARM . . . . . . . . . . . . . . . . . . .15
CHIME SETTING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
CHANGING ACCESS CODES . . . . . . . . . . . . . . . . . . . . . .17
REVIEWING THE EVENT LOG . . . . . . . . . . . . . . . . . . . . .18
SOUNDER, BELL & STROBE TEST . . . . . . . . . . . . . . . . .19
SYSTEM WALK TEST . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
SYSTEM FAULTS AND ALARM CONDITIONS . . . . . . .21
DAYTIME TAMPER ALARM . . . . . . . . . . . . . . . . . . . . . . .23
EXPLANATION OF CODES . . . . . . . . . . . . . . . . . . . . . . . .24
YOUR CIRCUIT DESCRIPTION . . . . . . . . . . . . . . . . . . . . .25
SERVICE RECORD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26
SERVICE CONTACT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27
1

1
Introduction
The 9800 Electronic Intruder Alarm system uses the latest microprocessor
technology to provide a simple to operate, yet highly flexible system,
suitable for a wide range of small to medium sized protection applications.
The system comprises a main control unit, housing the system control
printed circuit board and power supplies. Up to four remote keypads can be
connected to the system. The main control unit is normally located out of
sight and the keypad(s) fitted at appropriate locations within the premises.
The keypad(s) provide the operator with the facility to set and unset the
sytem and to programme the various operator functions described in this
manual.
The system keypads are provided with a two digit LED display providing
the user with a coded description of the system status and any system error
messages. A full list and explanation of keypad codes is provided at the back
of this manual.
Your system will have been programmed by the engineer on installation to
permit certain functions, e.g., Chime and Omit Enable. The eight available
alarm circuits will have been allocated, together with the zone allocation for
Part Set ‘B’ and ‘C’. A full description of your system is provided at the
back of this manual.
2

2
Operator Controls and Displays
A
B
C
OMITday
Prog log
chime bell-test-walk
POWER
CLEAR
FAULT
9800
1 2 3
4 5 6
7 8 9
0
Complete System
Selector Button
Mains LED
Sounder
Indicators
Day LED Omit Button
Chime Button Clear Button
Log Button
Numeric
Keypad
Program Button
OMIT
SERVICE
Fault LED Service LED LED Display Omit LED
Keypad
System
Part Set Selector Buttons Bell & Walk Test Buttons
3
Operator Codes
Setting, unsetting and access to the system functions are normally inhibited
unless a four digit security code is entered via the remote keypad.
The system is designed to recognise up to four different security codes
which may be changed by the user at any time.
An optional keyswitch may be fitted to your system. While this facility
permits the keyholder to set and unset the system without entering a code at
the operator keypad, it does not permit access to the other system functions.
Each time the user enters a code at the keypad, the user code is recorded in
the system event memory.
3

- -
4
Normal Setting
Ensure that all doors and windows are secure, check that movement
detectors are not obstructed and proceed as follows:
(a) (b)
A
B
C
OMITday
Prog log
chime bell-test-walk
POWER
CLEAR
FAULT
9800
1 2 3
4 5 6
7 8 9
0
A
B
C
OMITday
Prog log
chime bell-test-walk
POWER
CLEAR
FAULT
9800
1 2 3
4 5 6
7 8 9
0
OMIT
SERVICE OMITSERVICE
Enter access code. Press ‘A’. Sounder emits a
continuous tone. ‘A’ indicator
flashes during exit time and
remains on when set.
(c) Leave the premises by the prescribed exit route. System will set
when final door is closed or on expiry of exit timer, or, where applicable, on
locking the final door, or pressing the exit terminator.
5
Final or Timed Setting
The alarm system will normally set after satisfactory completion of the
setting procedure and on closing the final door on exit. However, where the
user is remaining on the premises with the alarm set, the system will
automatically set on expiry of the exit timer.
In some installations, the system will not set unless the final door is locked
or an exit terminator button is pressed.
INSTANT SETTING
In certain circumstances, where an exit route is not required, your alarm
system may have been programmed at installation for ‘Instant Setting’.
Instant Setting applies only when the system is Part Set. Where Instant
Setting is programmed, the selected part of the system will set immediately
unless an alarm zone has been left open. (See Part Setting procedure.)
4

- -
- -
6
Setting With Zones Open
Should the user attempt to set the system with one or more zones open, the
system will not set. The internal sounder will emit an interrupted tone and
the LED display will indicate the open zone, proceed as follows:
(a) (b)
A
B
C
OMITday
Prog log
chime bell-test-walk
POWER
CLEAR
FAULT
9800
1 2 3
4 5 6
7 8 9
0
A
B
C
OMITday
Prog log
chime bell-test-walk
POWER
CLEAR
FAULT
9800
1 2 3
4 5 6
7 8 9
0
4
OMIT
SERVICE OMITSERVICE
Enter access code. Press ‘A’. Open zone displayed.
‘A’ indicator flashes. Sounder
emits intermittent tone.
(c) (d)
A
B
C
OMITday
Prog log
chime bell-test-walk
POWER
CLEAR
FAULT
9800
1 2 3
4 5 6
7 8 9
0
OMIT
SERVICE
Reset the system. If no other
zones are open, the system will
set. If other zones are displayed,
repeat steps (a) to (c).
If unable to set call engineer.
Enter access code. System returns
to ‘Day’ state. Close open zone.
Note: If a detector is fitted by the keypad or the final door is known to be
open, the appropriate LED will be displayed. The system will set when clear
of the detection. If the user is not clear by the end of the exit time an exit
fault will occur (internal sounder only).
5

7
Keyswitch Setting
Your system may be fitted with an optional two-position keyswitch which
permits keyholders to set and unset the alarm only. This facility must be
programmed into your system at the time of installation. The keyswitch does
not provide access to the other system functions, which continue to be
accessible only by entering a valid access code at the remote keypad.
NORMAL KEYSWITCH SETTING
The following describes setting the system using the keyswitch and the
response of the keypad.
(a) (b)
A
B
C
OMITday
Prog log
chime bell-test-walk
POWER
CLEAR
FAULT
9800
1 2 3
4 5 6
7 8 9
0
OMIT
SERVICE
Turn the keyswitch.
(c) (d)
A
B
C
OMITday
Prog log
chime bell-test-walk
POWER
CLEAR
FAULT
9800
1 2 3
4 5 6
7 8 9
0
OMIT
SERVICE
Leave the premises via the
prescribed exit route, the alarm
system will automatically set on
expiry of the exit timer.
Sounder emits continuous tone.
6

7
Keyswitch Setting (Cont.)
KEYSWITCH SETTING WITH ZONES OPEN
Should the user attempt to set the system with the keyswitch when one or
more zones are open, the system will not set. The internal sounder will emit
an interrupted tone and the LED display will indicate the open zone. Proceed
as follows:
(a) (b)
A
B
C
OMITday
Prog log
chime bell-test-walk
POWER
CLEAR
FAULT
9800
1 2 3
4 5 6
7 8 9
0
OMIT
SERVICE
Turn the keyswitch on. Sounder
emits intermittent tone.
(c) (d)
A
B
C
OMITday
Prog log
chime bell-test-walk
POWER
CLEAR
FAULT
9800
1 2 3
4 5 6
7 8 9
0
4
OMIT
SERVICE
Turn keyswitch off and close open
zone indicated on keypad.
(e) Turn the keyswitch on. If no other zones are open, the system will set.
Repeat step (d) if required.
Note: If a detector is fitted at the keypad or the final door is known to be
open, the appropriate LED will be displayed. The system will set when clear
of the detection. If the user is not clear by the end of the exit time an exit
fault will occur (internal sounder only).
7

- -
8
Part Setting
The Part Set function provides the user with the facility to set the system
with only the detection allocated to Group B or C being armed. Circuits not
allocated to a Part Set group will not be armed when setting, allowing
normal access.
(a) (b)
A
B
C
OMITday
Prog log
chime bell-test-walk
POWER
CLEAR
FAULT
9800
1 2 3
4 5 6
7 8 9
0
A
B
C
OMITday
Prog log
chime bell-test-walk
POWER
CLEAR
FAULT
9800
1 2 3
4 5 6
7 8 9
0
OMIT
SERVICE OMITSERVICE
Enter access code. Select area ‘B’ or ‘C’ for setting
and press appropriate button.
(c) (d)
A
B
C
OMITday
Prog log
chime bell-test-walk
POWER
CLEAR
FAULT
9800
1 2 3
4 5 6
7 8 9
0
OMIT
SERVICE
If open zone is indicated, enter
codc, close zone and repeat steps
(a) to (c). If unable to Part Set,
call engineer.
Note: If a detector is fitted at the keypad or the final door is known to be
open, the appropriate LED will be displayed. The system will set when clear
of the detection. If the user is not clear by the end of the exit time an exit
fault will occur (internal sounder only).
8

- -
9
Setting With Zones Omitted
The user can set or part set the system with selected alarm zones omitted
from the system. (If zone is programmed by engineer for ‘Omit Enabled’.)
However certain zones, classified as ‘Non Omit’ cannot be omitted. To set
the system with zone(s) omitted, proceed as follows:
(a) (b)
A
B
C
OMITday
Prog log
chime bell-test-walk
POWER
CLEAR
FAULT
9800
1 2 3
4 5 6
7 8 9
0
A
B
C
OMITday
Prog log
chime bell-test-walk
POWER
CLEAR
FAULT
9800
1 2 3
4 5 6
7 8 9
0
OMIT
SERVICE OMITSERVICE
Enter access code. Select ‘A’ for whole system, or
‘B’ or ‘C’ for part setting.
(c) (d)
A
B
C
OMITday
Prog log
chime bell-test-walk
POWER
CLEAR
FAULT
9800
1 2 3
4 5 6
7 8 9
0
o2
OMIT
SERVICE
To re-instate an omitted zone,
press the ‘Omit’ key followed by
the ‘Clear’ key. All circuits
omitted are re-instated when the
system is unset.
Press ‘Omit’ key within 5
seconds, followed by zone
number(s) to be omitted.
(e) Repeat step (c) for other zones to be omitted. The system will set as
normal. Omit LED will extinguish when system sets.
9

- -
Omitting a 24Hr Zone
If necessary, the user can omit a 24hr circuit when the system is unset. (If
zone is programmed by engineer for ‘Omit Enable’.) To omit a 24hr circuit
proceed as follows:
(a)
A
B
C
OMITday
Prog log
chime bell-test-walk
POWER
CLEAR
FAULT
9800
1 2 3
4 5 6
7 8 9
0
OMIT
SERVICE
Enter valid code.
(c)
A
B
C
OMITday
Prog log
chime bell-test-walk
POWER
CLEAR
FAULT
9800
1 2 3
4 5 6
7 8 9
0
o6
OMIT
SERVICE
Display clears after 10 seconds.
10
(b)
A
B
C
OMITday
Prog log
chime bell-test-walk
POWER
CLEAR
FAULT
9800
1 2 3
4 5 6
7 8 9
0
OMITSERVICE
Press ‘Omit’ within 5 seconds
followed by 24hr circuit numbers
to be omitted.
(d)
To return the 24hr circuit to
normal operation, enter access
code and press ‘Omit’ then
‘Clear’ keys within 5 seconds.

- -
Unsetting the System
On entering the premises the sounder will be emitting a continuous tone. The
user should proceed immediately to the keypad via the prescribed entry route
and unset the alarm as follows:
(a) (b)
A
B
C
OMITday
Prog log
chime bell-test-walk
POWER
CLEAR
FAULT
9800
1 2 3
4 5 6
7 8 9
0
A
B
C
OMITday
Prog log
chime bell-test-walk
POWER
CLEAR
FAULT
9800
1 2 3
4 5 6
7 8 9
0
OMIT
SERVICE OMITSERVICE
Enter access code within the
preset entry time. System unset.
Note: If unsetting from Part Set, the ‘B’ or ‘C’ LED will be illuminated at
step (a). If zones have been omitted on setting, the omitted zone number will
be displayed at step (a). If a keyswitch is fitted, the system is unset by turning
the keyswitch off.
Exceeding the Entry T
ime
If the alarm system is not unset before the expiry of the preset entry time, the
internal sounder will change to emit a high pitched tone. You have not
caused a full alarm and still have the time of a second stage timer (30
seconds).
On expiry of the second stage timer, the system will enter into a full alarm
state. If your system is fitted with a remote signalling device, a signal will be
transmitted automatically to your alarm company central station, and the
police authority will be contacted.
IMPORTANT NOTE
If the full alarm condition has been caused by a delay in unsetting the
system and an automatic signalling device is fitted to your alarm system,
you must contact your alarm company immediately in order that the police
call can be cancelled.
11

Straying From the Entry Route
If the user should stray from the prescribed entry route on normal entry to
the premises, a full alarm condition will occur, (external bells and internal
sounder). If your system is fitted with a remote signalling device, a signal
may be automatically transmitted to your alarm company central station.
Your system may be programmed with an ‘Abort’ feature, which works as
follows: The 9800 gives a full alarm if the user leaves the entry route or
exceeds the entry time. The 9800 sends a ‘Restore’ signal to the central
station if the user enters a valid access code at the keypad within 90 seconds
of the alarm (avoiding Police action). If the user fails to disarm the system
within 90 seconds the 9800 witholds the ‘Restore’ signal and full Police
action will be taken. After either situation, the system will require to be reset
by the engineer, or by following the ‘Remote Reset’ procedure (if
programmed).
IMPORTANT NOTE
If your system is fitted with a remote signalling device and a full alarm
condition has been caused by accidental deviation from the entry route
and you have been able to unset the system during the second stage timer
(if applicable), it is important that you immediately contact your alarm
company central station in order that action can be cancelled.
12

- -
Remote Reset
Many local police authorities are concerned about the rising number of false
alarms raised at central stations by user error or system malfunction. The
police now ask installers to program systems fitted with remote signalling to
be ‘Engineer Reset’. This means that after a user silences an alarm, they
must call their alarm company to reset the system or make any repairs.
The ‘Remote Reset’ facility (if enabled), allows a user to reset the system
under alarm company supervision over the telephone, without calling out an
engineer. This ensures that the user contacts the central station to
acknowledge accidental alarms or system problems.
If the alarm has activated following a genuine intrusion, procedural error or
for other reasons, proceed as follows:
(a)
A
B
C
OMITday
Prog log
chime bell-test-walk
POWER
CLEAR
FAULT
9800
1 2 3
4 5 6
7 8 9
0
c2
OMIT
SERVICE
Go to a system keypad, then key-
in your valid access code. The
display will show the circuit
which first caused the alarm, plus
the ‘Fault’ and ‘Service’ lights.
(c)
A
B
C
OMITday
Prog log
chime bell-test-walk
POWER
CLEAR
FAULT
9800
1 2 3
4 5 6
7 8 9
0
OMIT
SERVICE
Press the ‘Clear’ key. The
display will show ‘--’ (Function
Required).
(b)
A
B
C
OMITday
Prog log
chime bell-test-walk
POWER
CLEAR
FAULT
9800
1 2 3
4 5 6
7 8 9
0
rr
OMIT
SERVICE
Key in your access code
again.The display will show ‘RR’
(Reset Required).
(d)
A
B
C
OMITday
Prog log
chime bell-test-walk
POWER
CLEAR
FAULT
9800
1 2 3
4 5 6
7 8 9
0
45
OMIT
SERVICE
Press the ‘6’ key. The display will
show a 4-digit ‘Control Code’ as
two pairs of numbers, e.g. ‘45’ then
‘68’. The ‘Control Code’ will be
displayed 7 times, write down code.
13

Remote Reset (Cont.)
(e)
Call your alarm company central
station, follow the verification
procedure (usually a code name or
number) and give the ‘Control
Code’. You will then be given a 4-
digit ‘Reset Code’.
(g)
A
B
C
OMITday
Prog log
chime bell-test-walk
POWER
CLEAR
FAULT
9800
1 2 3
4 5 6
7 8 9
0
OMITSERVICE
Key-in the 4-digit ‘Reset Code’.
The display will clear and the
‘Fault’ and ‘Service’ lights will go
out.
Your system is now Reset.
14
(f)
A
B
C
OMITday
Prog log
chime bell-test-walk
POWER
CLEAR
FAULT
9800
1 2 3
4 5 6
7 8 9
0
c2
OMIT
SERVICE
The display will have returned to
the first circuit to alarm, e.g.,
‘c2’. Note: If you fail to write
down the ‘Control Code’, repeat
procedure (a) to (f)

- -
Unsetting After an Alarm
On entering the premises following an intrusion, a full alarm condition will
exist. To cancel the alarm, the user should proceed directly to the remote
keypad via the prescribed entry route and proceed as follows:
(a) (b)
A
B
C
OMITday
Prog log
chime bell-test-walk
POWER
CLEAR
FAULT
9800
1 2 3
4 5 6
7 8 9
0
A
B
C
OMITday
Prog log
chime bell-test-walk
POWER
CLEAR
FAULT
9800
1 2 3
4 5 6
7 8 9
0
c1
OMIT
SERVICE OMITSERVICE
Enter access code. The instruction which first caused
the alarm condition will be
displayed. The ‘Fault’ LED will
also be be illuminated.
(a) (b)
A
B
C
OMITday
Prog log
chime bell-test-walk
POWER
CLEAR
FAULT
9800
1 2 3
4 5 6
7 8 9
0
A
B
C
OMITday
Prog log
chime bell-test-walk
POWER
CLEAR
FAULT
9800
1 2 3
4 5 6
7 8 9
0
c1
OMIT
SERVICE OMITSERVICE
Enter access code. Display will clear only if
programmed for customer reset.
Note: If the system is programmed for Engineer Reset and an alarm
condition has occurred, the service LED will also be illuminated.
IMPORTANT NOTE
If a remote signalling device is fitted, you must contact your alarm service
company for resetting the system.
15

- -
- -
- -
Chime Setting
The chime function is only available if programmed during installation and
can only be selected if the system is unset. When set to chime, the internal
sounder will emit a ‘Chime’ tone if any normal alarm, entry route or final
door zone is opened. Where an exit terminator is fitted, this will act as a door
bell when the system is set to chime. To set the system to chime, proceed as
follows:
(a) (b)
A
B
C
OMITday
Prog log
chime bell-test-walk
POWER
CLEAR
FAULT
9800
1 2 3
4 5 6
7 8 9
0
A
B
C
OMITday
Prog log
chime bell-test-walk
POWER
CLEAR
FAULT
9800
1 2 3
4 5 6
7 8 9
0
OMIT
SERVICE OMITSERVICE
Enter access code. Press chime key (No. 7).
(c) (d)
A
B
C
OMITday
Prog log
chime bell-test-walk
POWER
CLEAR
FAULT
9800
1 2 3
4 5 6
7 8 9
0
OMIT
SERVICE
To return to the normal ‘Day’
state press the clear button.
System set on chime.
To disable Chime, repeat steps a) to d).
16

- -
Changing Access Codes
The system will accept up to four different user access codes, the first of
which is pre-programmed. The user can allocate or amend all four codes at
any time, or amend the ‘Duress’ code as follows:
(a)
A
B
C
OMITday
Prog log
chime bell-test-walk
POWER
CLEAR
FAULT
9800
1 2 3
4 5 6
7 8 9
0
OMIT
SERVICE
Enter access code.
(a)
A
B
C
OMITday
Prog log
chime bell-test-walk
POWER
CLEAR
FAULT
9800
1 2 3
4 5 6
7 8 9
0
oc
OMIT
SERVICE
Display will ask for old code (oc).
Enter old code.
(b)
A
B
C
OMITday
Prog log
chime bell-test-walk
POWER
CLEAR
FAULT
9800
1 2 3
4 5 6
7 8 9
0
OMIT
SERVICE
Press ‘Prog’ key (No. 4 key).
(b)
A
B
C
OMITday
Prog log
chime bell-test-walk
POWER
CLEAR
FAULT
9800
1 2 3
4 5 6
7 8 9
0
nc
OMIT
SERVICE
Display will ask for new code
(nc). Enter new four digit code
(see note).
(e) Press the ‘Clear’ button to register the new code in the system memory
and to return the system to the ‘Day’ state.
(f) Repeat steps (a) to (e) to allocate or amend the other three codes if
required. The user can also change the ‘Duress’ code in the same way,
by entering the old code, new code and pressing ‘Clear’.
Note: If you are adding a 2nd, 3rd or 4th code for the first time, enter AAAA
for second code, BBBB for third code, CCCC for the fourth code and OMIT
OMIT OMIT OMIT for the Duress code when asked for the old code (oc).
This is the only time that these keys are used as an access code. When and
existing code is to be changed, the user must enter the old four-digit code.
17

- -
Reviewing the Event Log
With the alarm system in the ‘Day’ state, the user can scan the coded event
log to obtain a record of system events. The event log will display events
chronologically, with the most recent event first. To scan the event log,
proceed as follows:
(a) (b)
A
B
C
OMITday
Prog log
chime bell-test-walk
POWER
CLEAR
FAULT
9800
1 2 3
4 5 6
7 8 9
0
A
B
C
OMITday
Prog log
chime bell-test-walk
POWER
CLEAR
FAULT
9800
1 2 3
4 5 6
7 8 9
0
u1
OMIT
SERVICE OMITSERVICE
Enter access code. Press ‘Log’ key (No 5 key).
Display shows user number.
(a) (b)
A
B
C
OMITday
Prog log
chime bell-test-walk
POWER
CLEAR
FAULT
9800
1 2 3
4 5 6
7 8 9
0
A
B
C
OMITday
Prog log
chime bell-test-walk
POWER
CLEAR
FAULT
9800
1 2 3
4 5 6
7 8 9
0
EA
OMIT
SERVICE OMITSERVICE
Press 1 key to move log back to
previous events or 3 key to move
log forward to more recent events.
Press ‘Clear’ key twice to end log
review and to return to the ‘Day’
state.
18
