Scantronic 808 Installation guide

HARDWIRED CONTROL
PANEL
INSTALLATION AND
PROGRAMMING GUIDE
Scantronic
Leading the way in security
808
cover.p65 9/8/98, 10:57 AM1

808 Hardwired Control Panel Installation and Programming Guide.
© Scantronic Ltd. 1998
Every effort has been made to ensure that the contents of this book are correct. However, neither the authors nor
Scantronic accept any liability for loss or damage caused or alleged to be caused directly or indirectly by this
book. The contents of this book are subject to change without notice.
Printed and published in the U.K.
cover.p65 9/8/98, 10:57 AM2

Contents
1. Overview
2. Technical Specification
3. Installation
4. Programming
5.Programming Reference
6. Testing
7. Fault Finding
Index
808 table of contents.p65 9/8/98, 10:56 AM1

2 496234
HowToUse ThisBook
This book is divided into the following sections:
1: Overview gives a brief introduction to the 808.
2: Technical Specification lists the physical capabilities of the system, and
gives part numbers for compatible equipment.
3: Installation provides step by step instructions for physically installing the
808 end station and its keypads, wiring 2-wire Fully Supervised Loop (FSL)
sensors or 4-wire Closed Circuit sensors, and connecting sounders.
4: Programming describes how to enter and leave programming mode on
the 808, and gives a set of programming examples for standard applications.
5: Programming Reference lists the factory defaults for programming, and
gives detailed information about the meaning of other programming param-
eters, for example zone types and output types.
6: Testing gives step by step instructions for using the in-built testing
commands.
7: Fault Finding lists common error messages that may be encountered
during programming, and suggests causes and corrective actions.
If you have not installed an 808 before, read sections 1, 3
and 4 before starting.
808 table of contents.p65 9/8/98, 10:56 AM2

496234 3
Contents
1. Overview .................................................................................................7
EndStation ............................................................................................................................ 8
The927LCD Keypad............................................................................................................. 8
2. Technical Specification..........................................................................9
General .................................................................................................................................. 9
PowerSupply ......................................................................................................................... 9
OutputProtection............................................................................................................. 9
Battery............................................................................................................................. 9
KeypadWiring ........................................................................................................................ 9
ZoneWiring.......................................................................................................................... 10
SoftwareLimits .................................................................................................................... 10
CompatibleEquipment ......................................................................................................... 10
3. Installation ............................................................................................11
InstallationOverview............................................................................................................ 11
Fitting the End Station................................................................................12
Battery ................................................................................................................................. 13
Wiringto the Mains .............................................................................................................. 13
Keypads .....................................................................................................14
ProgrammingKeypads ......................................................................................................... 14
927KeypadAddress ..................................................................................................... 14
Enabling/DisablingKeys,DisplayandSounder ............................................................. 14
DisplayTest (Optional)................................................................................................... 15
Fittingthe927Keypad ......................................................................................................... 15
Wiring .........................................................................................................17
Wiring927Keypads ............................................................................................................. 18
WiringDetectorZones ......................................................................................................... 18
Wiring FSLzones .......................................................................................................... 19
Using a 927 FSL Zone................................................................................................... 20
WiringClosed Circuit Zones .......................................................................................... 21
WiringExternalSounders .................................................................................................... 21
UsingProgrammableOutputs .............................................................................................. 22
WiringKeyswitches..............................................................................................................22
ConnectingaPrinter ............................................................................................................24
Initial Power Up ..........................................................................................25
Power-UpWithMains........................................................................................................... 25
4. Programming ........................................................................................29
ProgrammingMode.............................................................................................................. 29
FindingMenuItems ....................................................................................................... 29
ChangingMenuItems .......................................................................................................... 30
Correctingmistakes....................................................................................................... 30
ZoneProgramming ........................................................................................................ 30
To select a zone number: ........................................................................................ 31
To select the zone type: .......................................................................................... 31
To allocate the zone to an area: .............................................................................. 31
808 table of contents.p65 9/8/98, 10:56 AM3

4 496234
Contents
Toallocatezone attributes:...................................................................................... 31
To store the changesyou have made: ..................................................................... 32
EnteringText.................................................................................................................. 32
LeavingProgrammingMode ................................................................................................ 33
ToReturn to the User ModeFromProgramming ........................................................... 33
EngineerReset .................................................................................................................... 34
ResettingCustomer and Installer Codes(First stage reset)................................................. 34
Returnto Factory Defaults (Secondstage reset) ................................................................. 34
Example 1: Full Set and Three Part Sets ...................................................36
Example 2: Zone Circuit Types ...................................................................41
Example 3: Keyswitches.............................................................................42
Example 4: Zone Omission ........................................................................43
User Facilities.............................................................................................44
OperatingtheSystem .......................................................................................................... 44
InstallerSetting.............................................................................................................. 45
5. Programming Reference......................................................................46
FactoryDefaults................................................................................................................... 46
System Users ......................................................................................................... 46
Installerprogramming.............................................................................................. 46
Menu Options .............................................................................................47
01-PANELVERSION ........................................................................................................... 47
04-TESTOPTIONS ............................................................................................................. 47
09-PRINTOPTIONS............................................................................................................ 47
11-EDITNAME ....................................................................................................................47
21-EDITZONETYP............................................................................................................. 47
31-ZONE NAMES ................................................................................................................ 47
32-ZONEOPTIONS ............................................................................................................ 48
Menu32-ZoneTypes ................................................................................................... 48
Menu 32 -Allocating Zones toAreas ............................................................................. 49
Menu32 - ZoneAttributes ............................................................................................. 49
41-LEVELALLOCATE ......................................................................................................... 50
42-LEVELEXTMODE......................................................................................................... 50
43-LEVELENTTIME ........................................................................................................... 51
44-FLEXZONES ................................................................................................................. 51
45-LEVEL ALM RSP ............................................................................................................ 52
46-REARMOPTIONS ......................................................................................................... 52
47-KEYPAALLOCN............................................................................................................. 52
51-PROGOPUTTYP .......................................................................................................... 52
52-PROGSOUNDERS ....................................................................................................... 54
53-BELLTIMES ...................................................................................................................54
B DALWS ..................................................................................................................... 55
B D OVER ..................................................................................................................... 55
61-INSTCODE ....................................................................................................................55
62-PARESPONSE .............................................................................................................. 55
63-LFRESPONSE .............................................................................................................. 55
64-ALLOW Z OMIS .............................................................................................................. 56
65-SYSRESET ................................................................................................................... 56
66-PRINTOPTIONS............................................................................................................ 57
67-MISCOPTIONS ............................................................................................................. 57
808 table of contents.p65 9/8/98, 10:56 AM4

496234 5
Contents
6. Testing ...................................................................................................60
PanelVersionNumber(Menu01)......................................................................................... 60
Test Options (Menu 04)........................................................................................................ 60
To Select aTest: ............................................................................................................ 60
WalkTest .......................................................................................................................61
OutputTest .................................................................................................................... 61
PrinterOptions(Menu 09) .................................................................................................... 62
UsingtheTestZoneAttribute ............................................................................................... 62
7. Fault Finding ........................................................................................63
GeneralFaults...................................................................................................................... 63
Noresponse from the keypadkeys. .............................................................................. 63
Noexit/entry tones from remotekeypad ........................................................................ 63
ConfigurationCheckingErrorMessages.............................................................................. 63
Index .......................................................................................................... 65
808 table of contents.p65 9/8/98, 10:57 AM5

6 496234
Contents
808 table of contents.p65 9/8/98, 10:57 AM6

496234 7
1. Overview
The 808 is a programmable Alarm System suitable for domestic or small
commercial premises.
The system comprises an end station in a shielded case, and up to four
separate keypads. The end station provides:
• Connections for up to eight Fully Supervised Loop (FSL) or Closed
Circuit zones (selectable during programming).
• Three outputs, two fully programmable.
• Pins for fitting a plug-on communication device. Any device that
complies with the Scantronic plug-on footprint can be fitted.
The installer can program the system from the keypad, which provides an
eight character Liquid Crystal Display (LCD). The programming interface is
arranged into a set of numbered menus that lead the installer through the
installation process.
The 808 software provides a flexible installation that can meet many differ-
ent needs. The system can provide for up to 8 identified users. The 808
allows users to set the system to four different security Levels (for example
full set and three part sets) which can be programmed by the installer.
Individual zones can be programmed as Flexi-Zones™, which change
behaviour depending on which security Level is set.
Before installing a 808 system make sure you are fully familiar with the
functions of the panel and the installation procedures described in this
manual.
808 sect 1 overview.p65 9/8/98, 10:26 AM7

8 496234
1. Overview
End Station
Figure 1 below shows the end station PCB
Lid Anti-Tamper
Battery
Connector
21VAC Supply
from Transformer
RST Pins
Plug-on
Communicator pins
Main connector block
Printer Connector
Figure 1. End Station PCB
The 927 LCD Keypad
Figure 2. 927 Operator Controls and Displays
The 927 LCD keypad provides an eight character super twist LCD display, a
green Power LED, and four red Level status LEDs. The 927 also provides
terminals for one zone, in addition to those supplied by the end station.
8 Character Liquid
Crystal Display
Optional programmable
panic alarm keys. Press
keys 1 and 3 together
Optional programmable
control function keys.
Press keys 7 and 9
together.
Menu and Enter keys
Levels A to D LEDs
(Set or Unset)
Scroll and Level
setting keys
Edit Keys
Keyboard with
backlit soft rubber
keys
Power
808 sect 1 overview.p65 9/8/98, 10:26 AM8

496234 9
2. Technical Specification
General
Operatingtemperature = 0º - 40ºC
Humidity = 80% RH
Dimensions (end station) = 300(W) x 300(H) x 80(D)mm
Weight (end station) = Approximately. 5Kg
Power Supply
System Power Supply
(Ambient Temp. 20 º. C) = 900 mA
With the system quiescent, this supply is used as follows:
808 end station = 90 mA
Each Remote Keypad = 60 mA
The remaining current is available for recharging the battery, and supply
attached devices through the 12V Aux terminals on the main connector.
With the system in alarm the battery can supply current additional to the
maximum available from the system power supply.
Output Protection
Self resetting thermal Polyswitches protect outputs at the following levels:
12V Aux =1,350mA
Keypad 12V = 500mA
Siren = 750mA
Batt (reverse connection) = 2,500mA
Bell, Strobe and OP1 are open collector outputs rated at 500mA.
Battery
Standby Battery = 12 Volt, 6.5AH rechargeable lead-acid, Gel
Type battery
Battery Space = 110(W) x 150(H) x 75(D)mm
Keypad Wiring
Recommended maximum distances for the remote keypads from the end
station, using standard alarm cable is 100 metres per branch for the star
configuration.
For a daisy chain configuration the maximum length must take account of the
number of keypads sharing the cable. In general, a single keypad can be
connected at the end of a maximum of 300 meters of standard cable. If you
wish to connect more keypads the cable must be shorter, or the 0V wire must
808 sect 2 tech spec.p65 9/8/98, 10:26 AM9

10 496234
2. Technical Specification
be thicker. The criterion is that at the last keypad the voltage between 0V
and 12V wires must be no less than 10.5V.
Zone Wiring
The recommended maximum distance for FSL zones using standard alarm
cable is 200m - 300m.
Software Limits
The 808 can support:
• One to four Levels.
• Four Areas in total.
• Eight zones provided by the end station PCB plus three zones
provided by the keypad.
• Three outputs provided by the end station PCB.
• Four Flexi-Zones per Level.
• 8 User codes, including one Supervisor.
See the Examples in "5. Programming" for more details.
Compatible Equipment
927 8 character LCD keypad new style case
929 8 character LCD keypad
947 Portable printer ( Battery powered ) and power supply unit
949 Wall Mounted Printer Bracket
951 Printer lead
9040 16 Ohm internal sounder
2081/2 Loudspeaker /Microphones for use with 8450
5148 1 Amp BABT approved Remote Power supply
9056 Plug-on Digital Communicator
Plug-on RedCare STU (manufactured by others)
9076-01/2 SignallingInterfaces
808 sect 2 tech spec.p65 9/8/98, 10:26 AM10

496234 11
3. Installation
Installation Overview
1. Install end station.
2. Address and install at least one keypad.
3. Install all detectors, remaining keypads external and internal sounders,
etc.
4. Connect all system wiring to end station
5. Apply power for the first time.
6. Program system as required
7. Carry out full installer tests
8. Hand over system to User(s)
808 sect 3 installation.p65 9/8/98, 10:27 AM11

12 496234
3.Installation
Fitting the End Station
1. Remove the screws from the end station cover and lift the cover off.
Figure 3 shows the inside of the end station.
20 mm
Cable Entries
Lid Tamper Switch
Transformer
Mains Fused terminal
(Euro 20mm type)
Space for a 6.5Ah battery
Trunking knockout
Figure 3. End Station Internal Layout
2. Note the positions of the cable entries as follows:
a) Two plastic knock-outs top and bottom for trunking.
b) One 15mm bottom knock-out for alloy tubing.
c) Two 20mm knock-outs top and bottom.
d) Four 20mm circuit and sounder cable entries in the rear casing
adjacent to the main PCB.
e) One 20mm entry adjacent to the mains fuse terminal in the rear
casing for mains power only.
Warning Do not feed mains cables and low voltage circuit
and sounder cables through the same entry.
Always keep separate.
808 sect 3 installation.p65 9/8/98, 10:27 AM12

496234 13
3.Installation
CautionWhere cables enter directly through a metal enclosure, always
prepare entry with Grommets or suitable cable entry sheath-
ing
3. Position the back box with the printed circuit board to the left. Mark the
centre slotted key-way, then drill and plug the wall.
CautionDo not drill holes with the end station in position. The result-
ant dust and vibration may damage the PCB components and
may invalidate warranty.
4. Screw a pan-head No.10 screw (Twin-fast or normal screw) in to the
plugged hole. Relocate the end station back box on the centre screw
hole, then continue to mark the two lower fixing screws. Remove the
end station, then drill and plug the two bottom holes. Continue to fix the
end station using not less than No. 10 pan head screws.
Battery
The end station has space for a 6.5 Ah (7Ah) sealed Lead Acid battery. See
Figure 3 for location.
CautionDo not connect battery at this point.
Wiring to the Mains
The mains supply to the end station is connected via the 3 way ‘Euro Type’
fuse block located to at the top right hand side of the end station rear casing.
To comply with BS4737, the supply should come from an un-switched, fused
spur unit fitted with a 3A fuse. All electrical connections should be carried
out by a qualified electrician and must comply with the current IEEE Wiring
Regulations: 16 Edition, Appendix 5 - Standard Circuit Arrangement. Ensure
the mains supply has a proven earth, as this protects the end station against
RFI/EMC interference.
To Control Panel
Transformer
315mA
N
(L)P
240Vac
Figure 4. End Station Mains Connection
808 sect 3 installation.p65 9/8/98, 10:27 AM13

14 496234
3.Installation
Keypads
Programming Keypads
Before connecting the keypad(s) to the system, the engineer must program
an identification number into the NVM chip on each keypad. Each keypad in
a system must have a different address number to ensure that the end
station can correctly identify them. The keypad sounder, back-light and LCD
display can also be tested and setup at this stage.
927 Keypad Address
1. Set the ‘Prog’ switch on the keypad PCB to ‘On’ and the ‘Test’ switch to
‘Off’.
2. Connect the 0V and +12v terminals to a 12 volt DC supply, for example
a charged battery.
The display shows the software number of the keypad. Take note for
future reference.
3. Press ‘Enter’ twice.
LED 1 lights and the display shows the current keypad address, for
example: 1- 1
4. If the display does not show the correct keypad address, enter the new
address by entering a 1-digit number between 1 and 4, for example 2
for the second keypad.
The display shows the new keypad address.
Enabling/Disabling Keys, Display and Sounder
5. Press ‘Enter’.
LED 2 lights and the display shows the status of the keypad sounder: 0
for sounder ‘ON’ or 1 for sounder ‘OFF’, for example: 2- 0
6. Change the keypad sounder status as required by entering 0 or 1.
(The keypad sounder is normally left at ON = ‘ZERO”).
7. Press ‘Enter’.
LED 3 lights and the display shows the current status of the keypad
back-light: 0 for timed or 1 for back-light always ‘ON’, for example: 3- 1
8. Change the back light status as required by entering 0 or 1
9. Press ‘Enter’.
LED 4 lights and the display shows current keypad keys status: 0 for
Active or 1 for Inactive, for example: 4- 0
808 sect 3 installation.p65 9/8/98, 10:27 AM14

496234 15
3.Installation
10. Change the keypad status as required by entering 0 or 1. (The keypad
keys are normally left active = ‘ZERO’.)
11. Repeat 1 to 10 for any other keypads connected.
12. Set the ‘Prog’ switch to OFF and remove power to the keypads to lock
the address and options into the keypad(s).
Display Test (Optional)
1. Set the ‘Test’ switch to ON, and apply 12 volts DC.
2. The display will show 8 black characters and the status LED’s light.
3. Press ‘Enter’.
The display clears and LED three lights.
4. Press all the number keys in turn, then press Menu and Enter followed
by the up and down and left and right arrow keys.
The display shows all number keys as the appropriate number, and the
function keys as A,B,C,D,E and F
5. Repeat 1 to 5 for other keypads connected.
7. Remove the 12 volts DC and set the ‘Test’ and ‘Prog’ switches on all
keypads to OFF.
8. Continue to fit and connect the keypads.
Fitting the 927 Keypad
The backplate of the 927 keypad contains an adjustable cam that you can
use to make sure the tamper switch will operate correctly when the keypad
is mounted on an uneven surface. Figure 5 shows the backplate and the
position of mounting holes.
808 sect 3 installation.p65 9/8/98, 10:27 AM15

16 496234
3.Installation
Figure 5. Exploded View of the 927 Keypad
Scantronic recommend that you mount the keypad as follows:
1. Select which cable entry you are going to use and break out the
appropriate plastic sections.
2. Hold the backplate in place against the wall and mark the position of
the centre hole in the adjustable cam (see Figure 5).
3. Drill and plug the hole, and screw the backplate to the wall through the
adjustable cam. Do not tighten the screw completely home.
4. Make sure the backplate is level and mark, drill and plug at least two
other fixing holes. Screw the backplate to the wall through the fixing
holes.
5. Cut the plastic webs connecting the cam to the remainder of the base
plate.
Note: If you do not cut the webs then the tamper switch will not operate if the
complete keypad is forced off the wall.
6. Mount the front of the keypad (containing the keypad pcb) onto the
backplate and make sure that the tamper switch operates.
7. If the tamper switch does not operate then rotate the cam until the
tamper switch operates correctly when the front of the keypad is
mounted on the backplate.
Rear cable
entry
Side cable
entry
Adjustable
Tamper cam
Wall fixing
holes
Cable
retaining
channel
808 sect 3 installation.p65 9/8/98, 10:27 AM16

496234 17
3.Installation
Wiring
The 808 main PCB has facilities for connecting:
Four keypads.
Eight 2-wire FSL detector zones or eight 4-wire closed circuit zones.
Siren (Loudspeakers)
Three outputs.
Zone 8 CCT 8
A/T 8
Zone 7 CCT 7
A/T 7
Tamper return
Siren
12V
Bell (OP1)
OP2
OP3
+ve
-ve
Outputs
12V Aux
0V
+ve
-ve
SRQ
12V
Sig
0V
Keypads
Zone 6 CCT 6
A/T 6
Zone 5 CCT 5
A/T 5
Zone 4 CCT 4
A/T 4
Zone 3 CCT 3
A/T 3
Zone 2 CCT 2
A/T 2
Zone 1 CCT 1
A/T 1
Figure 6. 808 Main Connector
808 sect 3 installation.p65 9/8/98, 10:27 AM17

18 496234
3.Installation
Figure 6 shows the main connector on the 808 PCB. Subsequent sections
describe how to wire keypads, FSL and closed circuit zones.
Wiring 927 Keypads
All keypads must be connected to Keypad terminals on the main PCB or
"daisy chained" to other keypads. Figure 7 shows the connections for each
keypad:
I/P
SND
SIG
SRQ
+VE
0V
Prog
Test1
2
Vol
Display
Rear of keypad pcb
Tamper
N/O Exit
Terminate
Button or
N/C Lock Set
Switch
End Station
Connections
0V
SIG
+V
SRQ
Extension Piezo
12VDC
E.E. Sounder
25mA Max. +
-
To other
keypad(s)
FEZ
To detector
Figure 7. Wiring the 927 Keypad
Important: Please do not connect other devices (for example SAB, speakers and so
on) in the same cable as the remote keypad wiring.
Wiring Detector Zones
The 808 main connector has terminals for eight detector zones, as shown in
Figure 6. Zones can be wired as either two wire Fully Supervised Loop (FSL)
or four wire Closed Circuit (CC). However, all eight zones must be of the
same circuit type. The factory default is for CC zones. Use Menu 21 to
change between FSL or CC (see "4. Programming - Example 2").
808 sect 3 installation.p65 9/8/98, 10:27 AM18
