SCHUNK HLM Series User instructions

Translation of the original manual
Assembly and operating manual
HLM
Stroke module

Imprint
2
02.00 | HLM | Assembly and operating manual | en | 389497
Imprint
Copyright:
This manual is protected by copyright. The author is SCHUNK GmbH & Co. KG. All rights
reserved. Any reproduction, processing, distribution (making available to third parties),
translation or other usage - even excerpts - of the manual is especially prohibited and
requires our written approval.
Technical changes:
We reserve the right to make alterations for the purpose of technical improvement.
Document number: 389497
Version: 02.00|14/02/2019|en
© SCHUNK GmbH & Co. KG
All rights reserved.
Dear Customer,
thank you for trusting our products and our family-owned company, the leading
technology supplier of robots and production machines.
Our team is always available to answer any questions on this product and other solutions.
Ask us questions and challenge us. We will find a solution!
Best regards,
Your SCHUNK team
SCHUNK GmbH & Co. KG
Spann- und Greiftechnik
Bahnhofstr. 106 – 134
D-74348 Lauffen/Neckar
Tel. [phone]
Fax [phone]
[email protected]
schunk.com

Table of contents
02.00 | HLM | Assembly and operating manual | en | 389497
3
Table of contents
1 General.................................................................................................................... 5
1.1 About this manual ................................................................................................ 5
1.1.1 Presentation of Warning Labels ...............................................................5
1.1.2 Definition of Terms...................................................................................6
1.1.3 Applicable documents ..............................................................................6
1.1.4 Sizes ..........................................................................................................6
1.2 Warranty .............................................................................................................. 6
1.3 Scope of delivery .................................................................................................. 6
1.4 Accessories ........................................................................................................... 7
1.4.1 Sensors .....................................................................................................7
1.4.2 Rod lock ....................................................................................................7
2 Basic safety notes ................................................................................................... 8
2.1 Intended use......................................................................................................... 8
2.2 Not intended use.................................................................................................. 8
2.3 Constructional changes ........................................................................................ 8
2.4 Spare parts ........................................................................................................... 9
2.5 Environmental and operating conditions ............................................................. 9
2.6 Personnel qualification......................................................................................... 9
2.7 Personal protective equipment.......................................................................... 10
2.8 Notes on safe operation ..................................................................................... 11
2.9 Transport ............................................................................................................ 11
2.10 Malfunctions....................................................................................................... 11
2.11 Disposal .............................................................................................................. 12
2.12 Fundamental dangers......................................................................................... 12
2.12.1 Protection during handling and assembly ..............................................12
2.12.2 Protection during commissioning and operation ...................................13
2.12.3 Protection against dangerous movements.............................................13
2.12.4 Protection against electric shock............................................................13
2.13 Information about special dangers..................................................................... 14
3 Technical Data ........................................................................................................15
4 Assembly and Installation .......................................................................................16
4.1 Mechanical connection ...................................................................................... 17
4.2 Air connection .................................................................................................... 18
4.3 Setting the speed................................................................................................ 19
4.4 Adjustment of the shock absorber strocke ........................................................ 20
4.5 End positions ...................................................................................................... 21
4.5.1 Rod lock ..................................................................................................22
4.5.2 Stroke adjustment ..................................................................................24
4.6 Damping adjustment .......................................................................................... 24

Table of contents
4
02.00 | HLM | Assembly and operating manual | en | 389497
5 Commissioning .......................................................................................................26
6 Troubleshooting .....................................................................................................27
6.1 Module does not move ...................................................................................... 27
6.2 End position signal not present .......................................................................... 27
6.3 Linear module proposes at the end positions .................................................... 27
6.4 Payload swings in the final position?.................................................................. 27
7 Maintenance and care ............................................................................................28
8 Spare parts .............................................................................................................29
8.1 HLM 25 ............................................................................................................... 29
8.2 HLM 50, 100 and 200.......................................................................................... 30
9 Translation of original declaration of incorporation ................................................31
10 Annex to Declaration of Incorporation....................................................................32

General
02.00 | HLM | Assembly and operating manual | en | 389497
5
1 General
1.1 About this manual
This manual contains important information for a safe and
appropriate use of the product.
This manual is an integral part of the product and must be kept
accessible for the personnel at all times.
Before starting work, the personnel must have read and
understood this operating manual. Prerequisite for safe working is
the observance of all safety instructions in this manual.
Illustrations in this manual are provided for basic understanding
and may differ from the actual product design.
In addition to these instructions, the documents listed under
Applicable documents [}6] are applicable.
1.1.1 Presentation of Warning Labels
To make risks clear, the following signal words and symbols are
used for safety notes.
DANGER
Danger for persons!
Non-observance will inevitably cause irreversible injury or death.
WARNING
Dangers for persons!
Non-observance can lead to irreversible injury and even death.
CAUTION
Dangers for persons!
Non-observance can cause minor injuries.
NOTICE
Material damage!
Information about avoiding material damage.

General
6
02.00 | HLM | Assembly and operating manual | en | 389497
1.1.2 Definition of Terms
The term "product" replaces the product name on the title page in
this manual.
1.1.3 Applicable documents
• General terms of business*
• Catalog data sheet of the purchased product *
• Assembly and operating manuals of the accessories *
The documents marked with an asterisk (*) can be downloaded on
our homepage schunk.com
1.1.4 Sizes
This operating manual applies to the following sizes:
• HLM 25
• HLM 50
• HLM 100
• HLM 200
1.2 Warranty
If the product is used as intended, the warranty is valid for 24
months from the ex-works delivery date under the following
conditions:
• Observe the ambient conditions and operating conditions,
Environmental and operating conditions [}9]
• Observe the specified maintenance intervals, Maintenance and
care [}28]
Parts touching the workpiece and wear parts are not included in
the warranty.
1.3 Scope of delivery
The scope of delivery includes
• Stroke Module HLM in the version ordered
• Shock absorber
• Assembly and Operating Manual

General
02.00 | HLM | Assembly and operating manual | en | 389497
7
1.4 Accessories
A wide range of accessories are available for this product
For information regarding which accessory articles can be used
with the corresponding product variants, see catalog data sheet.
1.4.1 Sensors
Overview of the compatible sensors
Size Designation Type
HLM 25 - 50 Inductive proximity
switches
IN
HLM 100-200 Inductive proximity
switches
NI
Exact type designation of the compatible sensors see catalog.
1.4.2 Rod lock
The rod lock prevents the drop of the mass in case of energy loss,
such as emergency stop situations. The rod can be fitted
subsequently, but this reduces the effective stroke.
NOTICE
Damage to the rod lock due to incorrect actuation / overload!
•The rod lock may only be triggered and unlocked when the
product has been shut down.
•See the data on static holding force in the catalog. The forces
occurring in a clamped condition must not exceed the holding
force.
•In the event of a dynamic load or overload (e.g. drop in
pressure during movement), the clamping cartridge must be
checked and replaced if necessary.
WARNING
The Rod lock is not a safety component for personal protection
in accordance with the Machinery Directive.
Exact specifications and ordering data ☞ catalog.

Basic safety notes
8
02.00 | HLM | Assembly and operating manual | en | 389497
2 Basic safety notes
2.1 Intended use
The product is exclusively designed for linear movement of useful
loads into any desired position.
• The product may only be used within the scope of its technical
data, Technical Data [}15].
• When implementing and operating components in safety-
related parts of the control systems, the basic safety principles
in accordance with DIN EN ISO 13849-2 apply. The proven safety
principles in accordance with DIN EN ISO 13849-2 also apply to
categories 1, 2, 3 and 4.
• The product is intended for installation in a machine/system.
The applicable guidelines must be observed and complied with.
• The product is intended for industrial and industry-oriented use.
• Appropriate use of the product includes compliance with all
instructions in this manual.
2.2 Not intended use
It is not intended use if the product is used, for example, as a
pressing tool, stamping tool, lifting gear, guide for tools, cutting
tool, clamping device or a drilling tool.
• Any utilization that exceeds or differs from the appropriate use
is regarded as misuse.
2.3 Constructional changes
Implementation of structural changes
By conversions, changes, and reworking, e.g. additional threads,
holes, or safety devices can impair the functioning or safety of the
product or damage it.
• Structural changes should only be made with the written
approval of SCHUNK.

Basic safety notes
02.00 | HLM | Assembly and operating manual | en | 389497
9
2.4 Spare parts
Use of unauthorized spare parts
Using unauthorized spare parts can endanger personnel and
damage the product or cause it to malfunction.
• Use only original spare parts or spares authorized by SCHUNK.
2.5 Environmental and operating conditions
• Make sure that the product is used only in the context of its
defined application parameters, Technical Data [}15].
• Make sure that the product is not exposed to excessive
vibrations and/or strokes.
• Make sure that the environment is free from splash water and
vapors as well as from abrasion or processing dust. Exceptions
are products that are designed especially for contaminated
environments.
• Make sure that the environment is clean and the ambient
temperature corresponds to the specifications per the catalog.
• Ensure that no strong magnetic fields impair the function of the
product.
Contact your SCHUNK partner if the product is to be used in
strong magnetic fields.
2.6 Personnel qualification
Inadequate qualifications of the personnel
If the personnel working with the product is not sufficiently
qualified, the result may be serious injuries and significant
property damage.
• All work may only be performed by qualified personnel.
• Before working with the product, the personnel must have read
and understood the complete assembly and operating manual.
• Observe the national safety regulations and rules and general
safety instructions.

Basic safety notes
10
02.00 | HLM | Assembly and operating manual | en | 389497
The following personal qualifications are necessary for the various
activities related to the product:
Trained electrician Due to their technical training, knowledge and experience, trained
electricians are able to work on electrical systems, recognize and
avoid possible dangers and know the relevant standards and
regulations.
Qualified personnel Due to its technical training, knowledge and experience, qualified
personnel is able to perform the delegated tasks, recognize and
avoid possible dangers and knows the relevant standards and
regulations.
Instructed person Instructed persons were instructed by the operator about the
delegated tasks and possible dangers due to improper behaviour.
Service personnel of
the manufacturer
Due to its technical training, knowledge and experience, service
personnel of the manufacturer is able to perform the delegated
tasks and to recognize and avoid possible dangers.
2.7 Personal protective equipment
Use of personal protective equipment
Personal protective equipment serves to protect staff against
danger which may interfere with their health or safety at work.
• When working on and with the product, observe the occupa-
tional health and safety regulations and wear the required per-
sonal protective equipment.
• Observe the valid safety and accident prevention regulations.
• Wear protective gloves to guard against sharp edges and
corners or rough surfaces.
• Wear heat-resistant protective gloves when handling hot surfaces.
• Wear protective gloves and safety goggles when handling
hazardous substances.
• Wear close-fitting protective clothing and also wear long hair in
a hairnet when dealing with moving components.

Basic safety notes
02.00 | HLM | Assembly and operating manual | en | 389497
11
2.8 Notes on safe operation
Incorrect handling of the personnel
Incorrect handling and assembly may impair the product's safety
and cause serious injuries and considerable material damage.
• Avoid any manner of working that may interfere with the
function and operational safety of the product.
• Use the product as intended.
• Observe the safety notes and assembly instructions.
• Do not expose the product to any corrosive media. This does not
apply to products that are designed for special environments.
• Eliminate any malfunction immediately.
• Observe the care and maintenance instructions.
• Observe the current safety, accident prevention and environ-
mental protection regulations regarding the product's applica-
tion field.
2.9 Transport
Handling during transport
Incorrect handling during transport may impair the product's
safety and cause serious injuries and considerable material
damage.
• When handling heavy weights, use lifting equipment to lift the
product and transport it by appropriate means.
• Secure the product against falling during transportation and
handling.
• Stand clear of suspended loads.
2.10 Malfunctions
Behavior in case of malfunctions
• Immediately remove the product from operation and report the
malfunction to the responsible departments/persons.
• Order appropriately trained personnel to rectify the
malfunction.
• Do not recommission the product until the malfunction has
been rectified.
• Test the product after a malfunction to establish whether it still
functions properly and no increased risks have arisen.

Basic safety notes
12
02.00 | HLM | Assembly and operating manual | en | 389497
2.11 Disposal
Handling of disposal
The incorrect handling of disposal may impair the product's safety
and cause serious injuries as well as considerable material and en-
vironmental harm.
• Follow local regulations on dispatching product components for
recycling or proper disposal.
2.12 Fundamental dangers
General
• Observe safety distances.
• Never deactivate safety devices.
• Before commissioning the product, take appropriate protective
measures to secure the danger zone.
• Disconnect power sources before installation, modification,
maintenance, or calibration. Ensure that no residual energy
remains in the system.
• If the energy supply is connected, do not move any parts by
hand.
• Do not reach into the open mechanism or movement area of
the product during operation.
2.12.1 Protection during handling and assembly
Incorrect handling and assembly
Incorrect handling and assembly may impair the product's safety
and cause serious injuries and considerable material damage.
• Have all work carried out by appropriately qualified personnel.
• For all work, secure the product against accidental operation.
• Observe the relevant accident prevention rules.
• Use suitable assembly and transport equipment and take
precautions to prevent jamming and crushing.
Incorrect lifting of loads
Falling loads may cause serious injuries and even death.
• Stand clear of suspended loads and do not step into their
swiveling range.
• Never move loads without supervision.
• Do not leave suspended loads unattended.

Basic safety notes
02.00 | HLM | Assembly and operating manual | en | 389497
13
2.12.2 Protection during commissioning and operation
Falling or violently ejected components
Falling and violently ejected components can cause serious injuries
and even death.
• Take appropriate protective measures to secure the danger zone.
• Never step into the danger zone during operation.
2.12.3 Protection against dangerous movements
Unexpected movements
Residual energy in the system may cause serious injuries while
working with the product.
• Switch off the energy supply, ensure that no residual energy re-
mains and secure against inadvertent reactivation.
• Never rely solely on the response of the monitoring function to
avert danger. Until the installed monitors become effective, it
must be assumed that the drive movement is faulty, with its
action being dependent on the control unit and the current
operating condition of the drive. Perform maintenance work,
modifications, and attachments outside the danger zone
defined by the movement range.
• To avoid accidents and/or material damage, human access to
the movement range of the machine must be restricted. Limit/
prevent accidental access for people in this area due through
technical safety measures. The protective cover and protective
fence must be rigid enough to withstand the maximum possible
movement energy. EMERGENCY STOP switches must be easily
and quickly accessible. Before starting up the machine or
automated system, check that the EMERGENCY STOP system is
working. Prevent operation of the machine if this protective
equipment does not function correctly.
2.12.4 Protection against electric shock
Possible electrostatic energy
Components or assembly groups may become electrostatically
charged. When the electrostatic charge is touched, the discharge
may trigger a shock reaction leading to injuries.
• The operator must ensure that all components and assembly
groups are included in the local potential equalisation in
accordance with the applicable regulations.
• While paying attention to the actual conditions of the working
environment, the potential equalisation must be implemented
by a specialist electrician according to the applicable regulations.
• The effectiveness of the potential equalisation must be verified
by executing regular safety measurements.

Basic safety notes
14
02.00 | HLM | Assembly and operating manual | en | 389497
2.13 Information about special dangers
WARNING
Risk of injury caused by crushing and impacts when moving the
unit or attachments!
Risk of injury due to attachments breaking or becoming loose!
WARNING
Risk of injury from objects falling and being ejected!
Falling and ejected objects during operation can lead to serious in-
jury or death.
•Take appropriate protective measures to secure the danger
zone.
WARNING
Risk of injury due to unexpected movements!
If the power supply is switched on or residual energy remains in
the system, components can move unexpectedly and cause
serious injuries.
•Before starting any work on the product: Switch off the power
supply and secure against restarting.
•Make sure, that no residual energy remains in the system.
WARNING
Risk of injury when the machine/system moves unexpectedly in
the case of a loss of power supply or control system
malfunction.
Use of a holding brake on the linear axis.

Technical Data
02.00 | HLM | Assembly and operating manual | en | 389497
15
3 Technical Data
Size 08 - 200
Ambient temperature [°C] 5 - 60
IP rating 40
Noise emission [dB(A)] ≤ 70
Pressure medium Compressed air, compressed air
quality according to ISO
8573-1:7 4 4
Min. pressure [bar] 3
Max. pressure [bar] 8
Nominal working pressure [bar] 6
More technical data is included in the catalog data sheet.
Whichever is the latest version.

Assembly and Installation
16
02.00 | HLM | Assembly and operating manual | en | 389497
4 Assembly and Installation
NOTICE
Assembly measures
When mounting the module and when mounting loads, do not
allow impermissible forces and moments to be exerted (☞
catalog data)
Select the suitable screw tightening torque when mounting the
module or loads on the module in accordance with the generally
accepted guidelines for screw connections.
Secure all screw connections using a suitable chemical screw lock.
WARNING
Risk of injury due to unexpected movements of the machine/
system!
Switch off energy supply
Ensure that no residual energy remains in the system.

Assembly and Installation
02.00 | HLM | Assembly and operating manual | en | 389497
17
4.1 Mechanical connection
Evenness of the
mounting surface
The values apply to the whole mounting surface to which the
product is mounted.
Requirements for evenness of the mounting surface (Dimensions in mm)
Edge length Permissible unevenness
< 100 < 0.02
> 100 < 0.05
The module is assembled on the base plate. Additional connection
geometries can be found on the front, rear and on the top of the
module:
Assembly / connection geometries
Item Designation Application Standard
A Screw Mounting Module DEI 4762
B Cylindrical pin Centering, module ISO 8734
C * Bore hole Mounting Load
D * Thread Mounting Load
E * Cylindrical pin Centering, load ISO 8734
F * Centering strip Centering, load
For in-depth details regarding dimensions and position, refer to
the current catalog or CAD data.
The customer must provide the fastening materials.

Assembly and Installation
18
02.00 | HLM | Assembly and operating manual | en | 389497
4.2 Air connection
NOTICE
Possible damage to the linear module!
If the module moves too hard against the end positions, the
linear module might be damaged.
•A linear movement alway must reach the end position without
jerk or bounce.
•Therefore flow control valves and shock absorbers must be
used, Setting the speed [}19] and Adjustment of the shock
absorber strocke [}20].
•Please observe the diagrams and information in the catalog
pages.
NOTE
• Use connecting wires with the same or a larger cross-section as
the connection thread.
• Observe the air supply requirementsTechnical Data [}15].
NOTICE
Risk of damage to the linear module when changing pressure
medium.
The unit must not under any circumstances be operated with oiled
air before operation with unoiled air (washing out of factory
lubrication.
air connection * HLM 025

Assembly and Installation
02.00 | HLM | Assembly and operating manual | en | 389497
19
Item 25 50 100 200
A(*) M5 M5 M5 G1/8"
B M5 M5 M5 G1/8"
4.3 Setting the speed
NOTICE
Risk of damage to the product!
If the end position is approached too hard, the product may be
damaged.
•Adjust exhaust throttle valve and shock absorber so that the
movement is braked smoothly.
ØClose exhaust throttle valve completely.
ØOpen exhaust throttle valve until the product starts to move.
ØContinue to open the exhaust throttle valve incrementally until
the movement decelerates smoothly.
✓If the speed is too low, the product will brake too soon and
the end position will be reached too slowly.
✓If the speed is too high, the product will impact against the
end position and the shock absorber will be overloaded.
NOTE
A smooth motion may also be too slow in many use-cases.
Further settings can be made via the shock absorbers, Adjustment
of the shock absorber strocke [}20].

Assembly and Installation
20
02.00 | HLM | Assembly and operating manual | en | 389497
4.4 Adjustment of the shock absorber strocke
Movement
Target position
End position
Target time Time T
Damping
The shock absorber stroke is too long and the end position is
reached too slowly.
Movement
Target position
End position
Target time Time T
Damping
The shock absorber stroke is too short and the unit arrives in the
end position too abruptly.
Movement
Target position
End position
Target time Time T
Damping
Optimal shock absorber stroke.
