SCHUNK RM-W Series User instructions

Original operating manual
Assembly and Operating Manual
RM-W
Rotary module

Imprint
2
06.00 | RM-W | Assembly and Operating Manual | en | 389388
Imprint
Copyright:
This manual is protected by copyright. The author is SCHUNK GmbH & Co. KG. All rights
reserved. Any reproduction, processing, distribution (making available to third parties),
translation or other usage - even excerpts - of the manual is especially prohibited and
requires our written approval.
Technical changes:
We reserve the right to make alterations for the purpose of technical improvement.
Document number: 389388
Version: 06.00|05/02/2019|en
© SCHUNK GmbH & Co. KG
All rights reserved.
Dear Customer,
thank you for trusting our products and our family-owned company, the leading
technology supplier of robots and production machines.
Our team is always available to answer any questions on this product and other solutions.
Ask us questions and challenge us. We will find a solution!
Best regards,
Your SCHUNK team
SCHUNK GmbH & Co. KG
Spann- und Greiftechnik
Bahnhofstr. 106 – 134
D-74348 Lauffen/Neckar
Tel. [phone]
Fax [phone]
[email protected]
schunk.com

Table of contents
06.00 | RM-W | Assembly and Operating Manual | en | 389388
3
Table of contents
1 General.................................................................................................................... 5
1.1 About this manual ................................................................................................ 5
1.1.1 Presentation of Warning Labels ...............................................................5
1.1.2 Applicable documents ..............................................................................6
1.1.3 Sizes ..........................................................................................................6
1.1.4 Variants.....................................................................................................6
1.2 Warranty .............................................................................................................. 6
1.3 Scope of delivery .................................................................................................. 6
1.4 Accessories ........................................................................................................... 7
1.4.1 Sealing kit .................................................................................................7
1.4.2 Sensors .....................................................................................................7
2 Basic safety notes ................................................................................................... 8
2.1 Intended use......................................................................................................... 8
2.2 Not intended use.................................................................................................. 8
2.3 Constructional changes ........................................................................................ 8
2.4 Environmental and operating conditions ............................................................. 9
2.5 Personnel qualification......................................................................................... 9
2.6 Personal protective equipment.......................................................................... 10
2.7 Notes on safe operation ..................................................................................... 10
2.8 Transport ............................................................................................................ 10
2.9 Malfunctions....................................................................................................... 11
2.10 Disposal .............................................................................................................. 11
2.11 Fundamental dangers......................................................................................... 11
2.11.1 Protection during handling and assembly ..............................................11
2.11.2 Protection during commissioning and operation ...................................12
2.11.3 Protection against dangerous movements.............................................12
2.12 Notes on particular risks..................................................................................... 13
3 Technical data.........................................................................................................14
4 Assembly and settings ............................................................................................15
4.1 Mechanical connection ...................................................................................... 15
4.2 Air connections................................................................................................... 16
4.3 Adjusting the end positions................................................................................ 16
4.4 End position monitoring ..................................................................................... 18
5 Start-up ..................................................................................................................19

Table of contents
4
06.00 | RM-W | Assembly and Operating Manual | en | 389388
6 Troubleshooting .....................................................................................................20
6.1 Product does not move ...................................................................................... 20
6.2 Product does not travel through the rotating angle .......................................... 20
6.3 End position signal not present .......................................................................... 20
6.4 Torque is diminishing ......................................................................................... 20
6.5 Product rotates abruptly .................................................................................... 21
6.6 Product does not move smoothly to the end positions ..................................... 21
7 Maintenance ..........................................................................................................22
7.1 Shock absorber ................................................................................................... 22
7.2 Maintenance interval ......................................................................................... 22
7.3 Lubricants/Lubrication points (basic lubrication) .............................................. 22
7.4 Dismantling the product..................................................................................... 23
7.5 Assembling the product...................................................................................... 23
8 Assembly drawing...................................................................................................24
9 Translation of original declaration of incorporation ................................................25
10 Annex to Declaration of Incorporation....................................................................26

General
06.00 | RM-W | Assembly and Operating Manual | en | 389388
5
1 General
1.1 About this manual
This manual contains important information for a safe and
appropriate use of the product.
This manual is an integral part of the product and must be kept
accessible for the personnel at all times.
Before starting work, the personnel must have read and understood
this operating manual. Prerequisite for safe working is the
observance of all safety instructions in this manual.
Illustrations in this manual are provided for basic understanding and
may differ from the actual product design.
In addition to these instructions, the documents listed under
Applicable documents [}6] are applicable.
1.1.1 Presentation of Warning Labels
To make risks clear, the following signal words and symbols are
used for safety notes.
DANGER
Danger for persons!
Non-observance will inevitably cause irreversible injury or death.
WARNING
Dangers for persons!
Non-observance can lead to irreversible injury and even death.
CAUTION
Dangers for persons!
Non-observance can cause minor injuries.
NOTICE
Material damage!
Information about avoiding material damage.

General
6
06.00 | RM-W | Assembly and Operating Manual | en | 389388
1.1.2 Applicable documents
• General terms of business*
• Catalog data sheet of the purchased product *
• "GEMOTEC TOOLBOX Rotation" program *
The documents marked with an asterisk (*) can be downloaded on
our homepage schunk.com
1.1.3 Sizes
This operating manual applies to the following sizes:
• RM-W 50
• RM-W 110
• RM-W 200
• RM-W 310
1.1.4 Variants
This operating manual applies to the following variations:
• RM-W with soft shock absorbers (-1)
• RM-W with hard shock absorbers (-2)
1.2 Warranty
If the product is used as intended, the warranty is valid for 24
months from the ex-works delivery date under the following
conditions:
• Observe the specified maintenance and lubrication intervals
• Observe the ambient conditions and operating conditions
Parts touching the workpiece and wear parts are not included in
the warranty.
1.3 Scope of delivery
The scope of delivery includes
• Swivel unit RM in the version ordered
• Exhaust air throttles
• Accessory pack

General
06.00 | RM-W | Assembly and Operating Manual | en | 389388
7
1.4 Accessories
The following accessories, which must be ordered separately, are
required for the product:
• End-position monitoring
• Sensors
For information regarding which accessory articles can be used
with the corresponding product variants, see catalog data sheet.
1.4.1 Sealing kit
ID.-No. of the seal kit
Seal kit for ID number
RM 50 0313437
RM 110 0313438
RM 200 0313439
RM 310 0313441
1.4.2 Sensors
Overview of the compatible sensors
Designation Type
Inductive proximity switches IN, NI
Monitoring set GMNS...
• Exact type designation of the compatible sensors see catalog.
• Information on handling sensors is available at schunk.com or
from SCHUNK contact persons.

Basic safety notes
8
06.00 | RM-W | Assembly and Operating Manual | en | 389388
2 Basic safety notes
2.1 Intended use
The product may only be used for swiveling permissible
attachment parts or workpieces.
• The product may only be used within the scope of its technical
data, Technical data [}14].
• When implementing and operating components in safety-
related parts of the control systems, the basic safety principles
in accordance with DIN EN ISO 13849-2 apply. The proven safety
principles in accordance with DIN EN ISO 13849-2 also apply to
categories 1, 2, 3 and 4.
• The product is intended for installation in a machine/system.
The applicable guidelines must be observed and complied with.
• The product is intended for industrial and industry-oriented use.
• Appropriate use of the product includes compliance with all
instructions in this manual.
2.2 Not intended use
It is not intended use if the product is used, for example, as a
pressing tool, stamping tool, lifting gear, guide for tools, cutting
tool, clamping device or a drilling tool.
• Any utilization that exceeds or differs from the appropriate use
is regarded as misuse.
2.3 Constructional changes
Implementation of structural changes
By conversions, changes, and reworking, e.g. additional threads,
holes, or safety devices can impair the functioning or safety of the
product or damage it.
• Structural changes should only be made with the written
approval of SCHUNK.

Basic safety notes
06.00 | RM-W | Assembly and Operating Manual | en | 389388
9
2.4 Environmental and operating conditions
Required ambient conditions and operating conditions
Incorrect ambient and operating conditions can make the product
unsafe, leading to the risk of serious injuries, considerable material
damage and/or a significant reduction to the product's life span.
See also Environmental and operating conditions [}9].
• Make sure that the product is not exposed to excessive
vibrations and/or strokes.
• Ensure that no strong magnetic fields impair the function of the
product.
Contact your SCHUNK partner if the product is to be used in
strong magnetic fields.
2.5 Personnel qualification
Inadequate qualifications of the personnel
If the personnel working with the product is not sufficiently
qualified, the result may be serious injuries and significant
property damage.
• All work may only be performed by qualified personnel.
• Before working with the product, the personnel must have read
and understood the complete assembly and operating manual.
• Observe the national safety regulations and rules and general
safety instructions.
The following personal qualifications are necessary for the various
activities related to the product:
Trained electrician Due to their technical training, knowledge and experience, trained
electricians are able to work on electrical systems, recognize and
avoid possible dangers and know the relevant standards and
regulations.
Qualified personnel Due to its technical training, knowledge and experience, qualified
personnel is able to perform the delegated tasks, recognize and
avoid possible dangers and knows the relevant standards and
regulations.
Instructed person Instructed persons were instructed by the operator about the
delegated tasks and possible dangers due to improper behaviour.
Service personnel of
the manufacturer
Due to its technical training, knowledge and experience, service
personnel of the manufacturer is able to perform the delegated
tasks and to recognize and avoid possible dangers.

Basic safety notes
10
06.00 | RM-W | Assembly and Operating Manual | en | 389388
2.6 Personal protective equipment
Use of personal protective equipment
Personal protective equipment serves to protect staff against
danger which may interfere with their health or safety at work.
• When working on and with the product, observe the
occupational health and safety regulations and wear the
required personal protective equipment.
• Observe the valid safety and accident prevention regulations.
• Wear protective gloves to guard against sharp edges and
corners or rough surfaces.
• Wear heat-resistant protective gloves when handling hot surfaces.
• Wear protective gloves and safety goggles when handling
hazardous substances.
• Wear close-fitting protective clothing and also wear long hair in
a hairnet when dealing with moving components.
2.7 Notes on safe operation
Incorrect handling of the personnel
Incorrect handling and assembly may impair the product's safety
and cause serious injuries and considerable material damage.
• Avoid any manner of working that may interfere with the
function and operational safety of the product.
• Use the product as intended.
• Observe the safety notes and assembly instructions.
• Do not expose the product to any corrosive media. This does
not apply to products that are designed for special
environments.
• Eliminate any malfunction immediately.
• Observe the care and maintenance instructions.
• Observe the current safety, accident prevention and
environmental protection regulations regarding the product's
application field.
2.8 Transport
Handling during transport
Incorrect handling during transport may impair the product's safety
and cause serious injuries and considerable material damage.
• When handling heavy weights, use lifting equipment to lift the
product and transport it by appropriate means.
• Secure the product against falling during transportation and
handling.
• Stand clear of suspended loads.

Basic safety notes
06.00 | RM-W | Assembly and Operating Manual | en | 389388
11
2.9 Malfunctions
Behavior in case of malfunctions
• Immediately remove the product from operation and report the
malfunction to the responsible departments/persons.
• Order appropriately trained personnel to rectify the malfunction.
• Do not recommission the product until the malfunction has
been rectified.
• Test the product after a malfunction to establish whether it still
functions properly and no increased risks have arisen.
2.10 Disposal
Handling of disposal
The incorrect handling of disposal may impair the product's safety
and cause serious injuries as well as considerable material and
environmental harm.
• Follow local regulations on dispatching product components for
recycling or proper disposal.
2.11 Fundamental dangers
General
• Observe safety distances.
• Never deactivate safety devices.
• Before commissioning the product, take appropriate protective
measures to secure the danger zone.
• Disconnect power sources before installation, modification,
maintenance, or calibration. Ensure that no residual energy
remains in the system.
• If the energy supply is connected, do not move any parts by
hand.
• Do not reach into the open mechanism or movement area of
the product during operation.
2.11.1 Protection during handling and assembly
Incorrect handling and assembly
Incorrect handling and assembly may impair the product's safety
and cause serious injuries and considerable material damage.
• Have all work carried out by appropriately qualified personnel.
• For all work, secure the product against accidental operation.
• Observe the relevant accident prevention rules.
• Use suitable assembly and transport equipment and take
precautions to prevent jamming and crushing.

Basic safety notes
12
06.00 | RM-W | Assembly and Operating Manual | en | 389388
Incorrect lifting of loads
Falling loads may cause serious injuries and even death.
• Stand clear of suspended loads and do not step into their
swiveling range.
• Never move loads without supervision.
• Do not leave suspended loads unattended.
2.11.2 Protection during commissioning and operation
Falling or violently ejected components
Falling and violently ejected components can cause serious injuries
and even death.
• Take appropriate protective measures to secure the danger
zone.
• Never step into the danger zone during operation.
2.11.3 Protection against dangerous movements
Unexpected movements
Residual energy in the system may cause serious injuries while
working with the product.
• Switch off the energy supply, ensure that no residual energy
remains and secure against inadvertent reactivation.
• Never rely solely on the response of the monitoring function to
avert danger. Until the installed monitors become effective, it
must be assumed that the drive movement is faulty, with its
action being dependent on the control unit and the current
operating condition of the drive. Perform maintenance work,
modifications, and attachments outside the danger zone
defined by the movement range.
• To avoid accidents and/or material damage, human access to
the movement range of the machine must be restricted. Limit/
prevent accidental access for people in this area due through
technical safety measures. The protective cover and protective
fence must be rigid enough to withstand the maximum possible
movement energy. EMERGENCY STOP switches must be easily
and quickly accessible. Before starting up the machine or
automated system, check that the EMERGENCY STOP system is
working. Prevent operation of the machine if this protective
equipment does not function correctly.

Basic safety notes
06.00 | RM-W | Assembly and Operating Manual | en | 389388
13
2.12 Notes on particular risks
WARNING
Risk of injury from objects falling and being ejected!
Falling and ejected objects during operation can lead to serious
injury or death.
•Take appropriate protective measures to secure the danger
zone.
WARNING
Risk of injury from rotating components!
In the case of swivel units or rotary tables with a rotary drive,
serious injuries can be caused by rotating components.
•Take appropriate protective measures to secure the danger
zone.

Technical data
14
06.00 | RM-W | Assembly and Operating Manual | en | 389388
3 Technical data
Module type RM50-310 W90 RM50-310 W180
Standard angle of rotation [°] * 90 180
End position adjustability [°] ± 5
Ambient temperature [°C] 5 - 60
IP rating 40
Noise emission [dB(A)] ≤ 70
Pressure medium Compressed air, compressed air quality
according to ISO 8573-1:7 4 4
Min. pressure [bar] 3
Max. pressure [bar] 8
Nominal working pressure [bar] 6
* All other angles of rotation between 5 and 180 degrees can be
selected – specify when ordering – ☞ catalog.
More technical data is included in the catalog data sheet.
Whichever is the latest version.

Assembly and settings
06.00 | RM-W | Assembly and Operating Manual | en | 389388
15
4 Assembly and settings
NOTICE
Material damage due to pressure loss!
On delivery, the lock nuts for end position and absorber
adjustment are only hand-tightened. This could lead to a loss in
pressure and cause considerable material damage.
•Tighten the lock nuts for end position and shock absorber
adjustment before commissioning.
NOTICE
Material damage due to improper assembly!
•When mounting loads, do not allow impermissible forces and
moments to be exerted (see catalog data sheet).
•Select a suitable tightening torque when assembling the
product or loads on the product in accordance with the
generally accepted guidelines for screw connections.
•Secure all screws using a suitable chemical screw lock.
4.1 Mechanical connection
Evenness of the
mounting surface
The values apply to the whole mounting surface to which the
product is mounted.
Requirements for evenness of the mounting surface (Dimensions in mm)
Edge length Permissible unevenness
< 100 < 0.02
> 100 < 0.05
The connection geometries are above, below and at the side of the
rotary module.
Dimensions for the position and size of the connection geometries,
Catalog data sheet of the product .
Mounting ØWhen mounting the product from the rear or on the side,
mount the product using the fixing bores provided.
ØMount the product using the fixing bores provided.

Assembly and settings
16
06.00 | RM-W | Assembly and Operating Manual | en | 389388
4.2 Air connections
NOTICE
Damage to the rotary module possible!
The rotary module can be damaged if it arrives too abruptly in
the end position.
•The rotary motion must reach the end position without jerk or
bounce.
•Therefore, shock absorbers must be used Adjusting the end
positions [}16].
•Please observe the information in the catalog pages.
NOTICE
Pressure medium:
The unit must not under any circumstances be operated with
oiled air before operation with unoiled air (washing out of factory
lubrication).
NOTICE
Observe the requirements for the air supply
Technical data [}14].
Use connecting wires with the same or a larger cross-section as
the connection thread.
See the catalog for precise information about the position and size
of the connection geometries.
4.3 Adjusting the end positions
Adjusting the end positions

Assembly and settings
06.00 | RM-W | Assembly and Operating Manual | en | 389388
17
The parts listed below are included within the scope of delivery of
every rotary module for angle of rotation fine adjustment and
adjustment of the end position dampening to the mass moment of
inertia occurring in operation.
• Counter nut (10)
• Stop coupling (13)
• Rod (14)
• Shock absorber (22)
• Counter nut (23)
Angle of rotation fine
adjustment
ØRelease counter nut (10).
ØBy twisting the stop coupling (13) with the rod (14) and shock
absorber (22) that are integrated in it, the angle of rotation in
both end positions can be set by ±5° from the nominal angle of
rotation. The nominal rotation angle has to be specified for the
order and can be selected without steps between 5° and 180°.
Standard angles are 90° and 180°.
ØTighten the stop coupling again with the counter nut.
Damping adjustment
NOTICE
Use the shock absorber!
Operation without the shock absorber included within the scope
of delivery is not permitted.
•Observe the maximum mass moment of inertia (☞ catalog
data).
•Adjust the dampening at the mass moment of inertia.
■The desired angle of rotation has been set.
ØRelease counter nut (23).
ØBy turning the shock absorber (22) in and out, the stroke of the
shock absorber (and therefore the shock absorber characteristic
curve) can be adjusted to the mass moment of inertia occurring
in operation. The previously adjusted angle of rotation is not
influenced by this.
ØTighten the absorber again with the counter nut.

Assembly and settings
18
06.00 | RM-W | Assembly and Operating Manual | en | 389388
4.4 End position monitoring
To monitor the end positions, standardized monitoring sets for
direct installation are available.
The stop level that is integrated in the rotary module is directly
monitored.
Proximity switch -
monitoring set:
GMNS-...
Scope of delivery of the monitoring set:
• 1 x retaining plate
• 1 x Inductive proximity switch
• 1 x connection cable
Position of the proximity switches
1 Proximity switch (GMNS-... installation on both sides)
Setting the
monitoring
ØUndo the attachment screw.
ØSet the sensor via the retainer plate.
ØFix the sensor via the attachment screw.

Start-up
06.00 | RM-W | Assembly and Operating Manual | en | 389388
19
5 Start-up
• Check the technical specifications Technical data [}14].
• Check the permissible loading specifications (see catalog).
• Do not use the product until trouble-free operation has been
checked taking all permissible operating parameters into
account.
• Set the speed of the movement in such a way that the
permitted swiveling time is not exceeded. Use the "Gemotec
Toolbox" program for calculation (www.schunk.com).
• The movement speed is ideally regulated via throttle check
valves Air connections [}16]. The speed is always set so that it
starts at a low speed and increases to a higher speed until the
desired operating speed has been reached.
• Operate the device in such a way that the permissible cycle
number per minute is not exceeded. Use the "Gemotec
Toolbox" program for calculation (www.schunk.com).

Troubleshooting
20
06.00 | RM-W | Assembly and Operating Manual | en | 389388
6 Troubleshooting
6.1 Product does not move
Possible cause Corrective action
Pressure drops below minimum. Check air supply., Air connections [}16]
Compressed air lines switched. Check compressed air lines.
Proximity switch defective or set incorrect. Readjust or change sensor.
Unused air connections open. Close unused air connections.
Flow control valve closed. Open the flow control valve.
6.2 Product does not travel through the rotating angle
Possible cause Corrective action
End positions are adjusted incorrectly. Adjust end position.Link Endlagen
Pressure drops below minimum. Check air supply.Air connections [}16]
Mounting surface is not sufficiently flat. Check the evenness of the mounting
surface.Mechanical connection [}15]
Component part defective. Send product with a SCHUNK repair order or
dismantle product.
Shock absorber defective. Check or, if need be, replace the shock
absorber.
Adjust end position.Link Endlagen
6.3 End position signal not present
Possible cause Corrective action
Proximity switch defective or set incorrect. Adjust sensor or if necessary change sensor.,
Link Endlagen
Cable breakage. Change sensor.
6.4 Torque is diminishing
Possible cause Corrective action
Seals of the drive piston defective. Send product with a SCHUNK repair order or
dismantle product.
Replace the seals.
Positioning of the swivel table defective. Send product with a SCHUNK repair order or
dismantle product.
Compressed air lines blocked. Check compressed air lines of damage.
Pressure drops below minimum. Check air supply., Air connections [}16]
