SCHUNK VERO-S WDM-5X User instructions

Translation of Original Operating Manual
Superior Clamping and Gripping 01.00|WDM 80 |de
VERO-S
Modular system for manual
Workpiece direct clamping
WDM-5X
Assembly and Operating Manual

Imprint
01.00|WDM 80 |en
2
Imprint
Copyright:
This manual is protected by copyright. The author is SCHUNK GmbH & Co. KG. All rights
reserved. Any reproduction, processing, distribution (making available to third parties),
translation or other usage –even excerpts –of the manual is especially prohibited and
requires our written approval.
Technical changes:
We reserve the right to make technical improvements.
Document number: 1404624
Version: 01.00 |28.05.2019|de
© H.-D. SCHUNK GmbH & Co.
All rights reserved
Dear Customer,
Thank you for putting your trust in our products and our family-owned company, the
leading technology supplier of robots and production machines.
Our team is always available to answer any questions concerning this product or other
solutions. We look forward to your challenging questions. We will find a solution!
Best regards,
Your SCHUNK team
H.-D. SCHUNK GmbH & Co.
Spanntechnik KG
Lothringer Str. 23
D-88512 Mengen
Tel. [phone]
Fax [phone]
[email protected]nk.com
schunk.com

Table of Contents
01.00|WDM 80 |en
3
Table of Contents
1General 5
1.1 About this Manual 5
1.1.1 Illustration of warning signs 5
1.1.2 Applicable documents 6
1.2 Warranty 6
1.3 Scope of Delivery 6
1.4 Accessories 7
2Basic safety instructions 8
2.1 Appropriate use 8
2.2 Inappropriate use 8
2.3 Structural changes 8
2.4 Spare parts 9
2.5 Ambient conditions and operating conditions 9
2.6 Personnel qualification 9
2.7 Personal protective equipment 10
2.8 Note on safe operation 11
2.9 Transport 12
2.10 Malfunctions 12
2.11 Disposal 12
2.12 Fundamental dangers 13
2.12.1 Protection during handling and assembly 13
2.12.2 Protection during commissioning and operation 13
2.12.3 Protection against dangerous movements 14
2.12.4 Notes on particular risks 14
3Technical data 16
4Screw tightening torques 17

Table of Contents
01.00|WDM 80 |en
4
5Assembly 17
5.1 Pre-assembly measures 17
5.2 General Installation Notes 18
5.3Clamping pins SPA 40, SPB 40, SPC 40, SPG 40 18
5.3.1 Standard clamping pins 19
5.3.2 Clamping pins without collar 21
5.3.3 Clamping pins with position balancing SPD-B, SPD-C 22
6Functional description 23
6.1 WDM-5X basic module 23
6.1.1 WDM-5X-BM 80-75 and WDM-5X-BM 80-100 23
6.1.2 WDM-5X-BM 80-125, WDM-5X-BM 80-150, WDM-5X-BM 80-175 24
6.1.3 WDM-5X-BDM 80-125 24
6.2 WDM-5X Basic heigh extension 25
6.3 WDM-5X Add-on module 26
6.3.1 WDM-5X-SM 80-75 26
6.3.2 WDM-5X-SDM 80-125 (double clamping module) 27
6.4 WDM-5X Reduction adapter 28
6.4.1 Reduction adapter SBA-VL 28
6.4.2 Height-adjustable adapter SBA-HE 29
6.4.3 Plane grip adapter SBA-VLK 30
6.4.4 Collet chuck adapter SBA-SEZ 30
7Operation 31
8Maintenance and care 32
9Troubleshooting 33
10 Parts lists 34
10.1 Basic modules 34
10.2 Height extension for basic module 36
10.3 Add-on modules 36
10.4 Reduction adapter 37
11 Assembly drawings 39

General
01.00|WDM 80 |en
5
1 General
1.1 About this Manual
This manual contains important information for the safe, correct use of the product.
The manual is an integral part of the product and must be kept accessible by personnel at
all times.
Personnel must have read and understood this manual before beginning any work.
The observance of all safety notes in this manual is the precondition for all safe working.
The illustrations in this manual are intended to provide a basic understanding and may
deviate from the actual version.
Besides this manual, other documents which apply are those listed under
1.1.1 Illustration of warning signs
To make risks clear,the following signal words and symbols are used for safety notes.
DANGER
Danger to individuals!
Ignoring a safety note such as this will lead to certain irreversible
injury and even death.
WARNING
Danger to individuals!
Ignoring a safety note such as this can lead to irreversible injury
and even death.
CAUTION
Danger to individuals!
Non-observance can cause minor injuries.
CAUTION
Material damage!
Information about avoiding material damage.

General
01.00|WDM 80 |en
6
1.1.2 Applicable documents
•General terms and conditions *
•Catalog data sheet for purchased product *
The documents labeled with an asterisk (*) can be downloaded
from schunk.com.
1.2 Warranty
The warranty is valid for:
•24 months from delivery date from the production facility or
•50,000 cycles for VERO-S clamping systems WDM -5X for use as intended under the
following conditions:
•Observance of the applicable documents
•Observance of the ambient conditions and operating conditions
•Observance of the specified care and maintenance instructions
Parts touching the workpiece and wearing parts are not part of the warranty.
* One cycle comprises one complete clamping procedure (“opening”and “closing”).
1.3 Scope of Delivery
•Direct workpiece clamping module
oBasic module WDM-5X_BM 80-75
oBasic module WDM-5X_BM 80-100
oBasic module WDM-5X_BM 80-125
oBasic module WDM-5X_BM 80-150
oBasic module WDM-5X_BM 80-175
oBasic module WDM-5X_BDM 80-125
oBasic height extension WDM-5X—BP 235-235-50
oBasic height extension WDM-5X—BP 270-250-36
oStacking module WDM-5X-SM 80-75
oStacking module WDM-5X-SM 80-100
oStacking module WDM-5X-SM 80-125
oStacking module WDM-5X-SDM 80-125
oReduction adapter SBA-VL-P 50-M16
oReduction adapter SBA-VL-PA 50-M16
oReduction adapter SBA-VL 25-M12
oHeight-adjustable adapter SBA-HE 50-75
oPlane grip adapter SBA-VLK 75-M10
oCollet chuck adapter SBA-SEZ ER50-100

General
01.00|WDM 80 |en
7
•Assembly and Operating Manual (ID no. 1404624)
•Accessory pack
oWDM-5X_BM 80-75: 2 mounting screws M12 x 35
oWDM-5X_BM 80-100: 2 mounting screws M12 x 35
oWDM-5X_BM 80-125: 2 mounting screws M12 x 45
oWDM-5X_BM 80-150: 2 mounting screws M12 x 45
oWDM-5X_BM 80-175: 2 mounting screws M12 x 45
oWDM-5X_BDM 80-125: 2 mounting screws M12 x 45
oWDM-5X—BP 235-235-50: (without accessory kit)
oWDM-5X—BP 270-250-36: (without accessory kit)
oWDM-5X-SM 80-75: (without accessory kit)
oWDM-5X-SM 80-100: (without accessory kit)
oWDM-5X-SM 80-125: (without accessory kit)
oWDM-5X-SDM 80-125: (without accessory kit)
oSBA-VL-P 50-M16: (without accessory kit)
oSBA-VL-PA 50-M16: (without accessory kit)
oSBA-VL 25-M12: 1 clamping pin SBA 16, 1 mounting screw M12 x 75
oSBA-VL 50-M12: 1 clamping pin SBA 16, 1 mounting screw M12 x 100
oSBA-HE 50-75: 1 clamping pin SBA 20
oSBA-VLK 75-M10: (without accessory kit)
oSBA-SEZ ER50-100: clamping pin SBA 20
1.4 Accessories
(see catalog or data sheets when ordering separately)
Clamping pin type SBA 40, SBB 40, SBC 40
swing bolt PDSC M16
fitting screw PSC Ø12 and PSC Ø16
clamping pin type SPA 40, SPB 40, SPC 40, SPG 40
positioning arbor
Allen wrench
torque wrench

Basic safety instructions
01.00|WDM 80 |en
8
2 Basic safety instructions
2.1 Appropriate use
The clamping systems VERO-S WDB 80 are intended for clamping workpieces and devices
on machine tools and other suitable technical devices. This is implemented via modular
components that can be combined for workpiece direct clamping, taking into account the
defined technical data.
•The clamping systems may only be used on the basis of their technical data.
•The clamping systems are intended for industrial applications.
•Appropriate use of the product includes compliance with all instructions in
this manual.
2.2 Inappropriate use
The VERO-S WDM 80 clamping system is not being used as intended if, for example:
•it is used as a pressing tool, a toolholder, a load-handling device or as lifting
equipment.
•It is used for turning applications without consulting SCHUNK.
•It is used in working environments that are not permissible.
•People work on machines or technical equipment that do not comply with the
EC Machinery Directive 2006/42/EC, disregarding the applicable safety regulations.
•The technical data specified by the manufacturer are exceeded during usage.
2.3 Structural changes
Implementation of structural changes
Modifications, changes or reworking, e.g. additional threads, holes, or safety devices due to
conversions, could damage the product or impair its functionality or safety.
•Structural changes should only be made with the written approval of SCHUNK.

Basic safety instructions
01.00|WDM 80 |en
9
2.4 Spare parts
Use of unauthorized spare parts
Using unauthorized spare parts can endanger personnel and damage the product or cause
it to malfunction.
•Use only original spare parts or spares authorized by SCHUNK.
2.5 Ambient conditions and operating
conditions
Required ambient conditions and operating conditions
Incorrect ambient and operating conditions can make the product unsafe, leading to the
risk of serious injuries, considerable material damage and/or a significant reduction to the
product's life span.
•Make sure that the product is only used within its defined application parameters.
•Make sure that the product is a sufficient size for the application.
•Make sure that the contact surfaces of the interface are always clean. Make
absolutely sure that no chips of any kind can enter the interface and that the
interface does not fill with cooling emulsion, which is particularly possible with
vertical alignment of the clamping pin axis. The best way to ensure both of these
requirements is to use the SDE protection covers. If the interface should fill with
cooling emulsion, the interface can be dried out in opened state.
•Only use high-quality cooling emulsions with anti-corrosive additives during
processing.
2.6 Personnel qualification
Work on the product by inadequately qualified personnel can lead to serious injuries and
considerable material damage.
•Order all work to be performed only by appropriately qualified personnel.
•Personnel must have read and understood the complete manual before beginning
any work on the product.
•Observe national accident prevention regulations and the general safety notes.

Basic safety instructions
01.00|WDM 80 |en
10
The following personnel qualifications are required for the various types of work on the
product:
Qualified electrician:
Electricians have professional training, knowledge, and experience that equip them to work
on electrical systems, recognize and avoid potential dangers, and they know the relevant
standards and regulations.
Specialist personnel:
Specialist personnel have the specialized training, knowledge, and experience to perform
the tasks entrusted to them, to recognize and avoid potential dangers, and know the
relevant standards and instructions.
Instructed person:
Instructed persons have been instructed by the user regarding the tasks entrusted to them
and the potential dangers of inappropriate behavior.
Manufacturer's service personnel:
The manufacturer's service personnel have the specialized training, knowledge, and
experience to perform the work entrusted to them and to recognize and avoid potential
dangers.
2.7 Personal protective equipment
Use of personal protective equipment
Personal protective equipment serves to protect staff against danger which may interfere
with their health or safety at work.
•When working on and with the product, observe the occupational health and safety
regulations and wear the required personal protective equipment.
•Observe the valid safety and accident prevention regulations.
•Wear protective gloves to guard against sharp edges and corners or rough surfaces.
•Wear heat-resistant protective gloves when handling hot surfaces.
•Wear protective gloves and safety goggles when handling hazardous substances.
•Wear close-fitting protective clothing and also wear long hair in a hairnet when
dealing with moving components.

Basic safety instructions
01.00|WDM 80 |en
11
2.8 Note on safe operation
Incorrect manner of working by personnel
Working in an incorrect manner can make the product unsafe and risk the danger of
serious injuries and considerable material damages.
•Avoid any manner of working that may interfere with the function and operational
safety of the product.
•Use the product as intended.
•Observe the safety notes and assembly instructions.
•Do not expose the product to any corrosive media. Products for special ambient
conditions are excluded.
•Rectify malfunctions as soon as they occur.
•Observe the care and maintenance instructions.
•Observe the current safety, accident prevention, and environmental protection
regulations for the application field of the product.
Maintenance instructions
Observe the care and maintenance instructions. These instructions are based on a normal
working environment. If the product is to be operated in an environment with abrasive dusts
or corrosive or aggressive fumes or fluids, prior approval must be obtained from SCHUNK.
Safety during assembly and maintenance
During assembly, connection, adjustment, start-up and testing, make sure that no accidental
operation of the system by the fitter or other persons is possible.
Holding force and screw strength
The holding force of the system is limited essentially by the tightness of the screw
connection which connects the clamping pin to the pallet or the device. This is why only
screws of strength class 12.9 may be used.
Only original SCHUNK clamping pins may be used.
If the clamping pins are to be used in customer-owned devices, the customer must provide
sufficiently dimensioned threaded holes or a sufficiently thick mounting material.

Basic safety instructions
01.00|WDM 80 |en
12
2.9 Transport
Handling during transport
Incorrect handling during transport can make the product unsafe and risk serious injuries
and considerable material damage.
•When handling heavy weights, use lifting equipment to lift the product and
transport it by appropriate means.
•During transport and handling, secure the product to prevent it from falling.
•Do not walk under suspended loads.
2.10 Malfunctions
Behavior in case of malfunctions
•Immediately remove the product from operation and report the malfunction to the
responsible departments/persons.
•Order appropriately trained personnel to rectify the malfunction.
•Do not recommission the product until the malfunction has been rectified.
•Test the product after a malfunction to establish whether it still functions properly and no
increased risks have arisen.
2.11 Disposal
Handling of disposal
Incorrect handling during disposal can make the product unsafe and risks serious injuries
and considerable material and environmental harm.
•Follow local regulations on dispatching product components for recycling or orderly
disposal.

Basic safety instructions
01.00|WDM 80 |en
13
2.12 Fundamental dangers
General
•Observe safety distances.
•Never deactivate safety devices.
•Before commissioning the product, take appropriate protective measures to secure
the danger zone.
•Disconnect power sources before installation, modification, maintenance, or
calibration. Ensure that no residual energy remains in the system.
•Do not reach into the open mechanism or movement area of the product during
operation.
2.12.1 Protection during handling and assembly
Incorrect handling and assembly
Incorrect handling and assembly can make the product unsafe and risk the danger of serious
injuries and considerable material damage.
•Order all work to be performed only by appropriately qualified personnel.
•For all work, secure the product against accidental operation.
•Observe the relevant accident prevention regulations.
•Use suitable assembly and transport equipment and take precautions to prevent
jamming and crushing.
Incorrect lifting of loads
Falling loads can cause serious injuries and even death.
•Stand clear of suspended loads and do not step within their swiveling range.
•Never move loads without supervision.
•Do not leave suspended loads unattended.
2.12.2 Protection during commissioning and operation
Falling or violently ejected components
Falling and violently ejected components can cause serious injuries and even death.
•Take appropriate protective measures to secure the danger zone.
•Never step into the danger zone during operation.

Basic safety instructions
01.00|WDM 80 |en
14
2.12.3 Protection against dangerous movements
Unexpected movements
If the system still retains residual energy, serious injuries can be caused while working on
the product.
•Perform maintenance work, modifications, and attachments outside the danger zone
defined by the movement range.
•To avoid accidents and/or material damage, human access to the movement range
of the machine must be restricted. Limit/prevent accidental access for people in this
area through technical safety measures. The protective cover and protective fence
must be rigid enough to withstand the maximum possible movement energy.
EMERGENCY STOP switches must be easily and quickly accessible. Before
commissioning the machine or automated system, check that the EMERGENCY STOP
system is working. Prevent operation of the machine if this protective equipment
does not function correctly.
2.12.4 Notes on particular risks
WARNING
Risk of injury due to falling parts when setting up, fitting and
transporting the workpiece direct clamping module.
Parts that have not been properly secured can come loose and
fall down.
•Use suitable lifting equipment and means of transport.
•When fitting the clamping structure, do not enter the
danger zone.
•Wear personal protective equipment.
WARNING
Risk of injury to the operating personnel when transporting the
direct workpiece clamping module or if the clamping structure,
the device or the workpiece falls.
•Use a crane or a transport truck when transporting.
•During horizontal or overhead applications, the device or
pallet must be secured before loosening to prevent it from
falling.

Basic safety instructions
01.00|WDM 80 |en
15
WARNING
Risk of injury due to falling device, pallet or workpiece if the
clamping pin or the change interfaces on the workpiece direct
clamping modules are loosened erroneously or as a result of
negligence.
•During operation, any loosening of the clamping pin as a result
of negligence must be excluded using appropriate counter
measures.
•The machines and equipment must fulfill the minimum
requirements of the EC Machinery Directive 2006/42/EC;
specifically, they must have effective technical measures to
protect against potential mechanical hazards.
•Wear personal protective equipment.
CAUTION
There is a risk of limbs being crushed by moving parts during
manual loading and unloading and the clamping procedure.
•Do not reach into the clamping pin holder.
•Use loading devices.
•Wear protective gloves.

Technical data
01.00|WDM 80 |en
16
3 Technical data
Installation position
Any
Operating temperature
+ 15°C –+ 60°C
Required level of cleanliness in accordance with
DIN EN 60529
IP 30
Characterization
WDM-5X-BM
80-75
WDM-5X-BM
80-100
WDM-5X-BM
80-125
WDM-5X-BM
80-150
ID
1398160
1398161
1398162
1398163
Height
75 mm
100 mm
125 mm
150 mm
Holding force *
35 kN (M10) / 50 kN (M12) / 75 kN (M16)
Pull-in force
25 kN
Actuation torque
15 Nm
Weight
3.55 kg
4.45 kg
6.65 kg
7.60 kg
Characterization
WDM-5X-BM
80-175
WDM-5X-BDM
80-125
WDM-5X-SM
80-75
WDM-5X-SM
80-100
ID
1398164
1398171
1398181
1398182
Height
175 mm
125 mm
75 mm
100 mm
Holding force *
35 kN (M10) / 50 kN (M12) / 75 kN (M16)
Pull-in force
25 kN
Actuation torque
15 Nm
Weight
8.45 kg
5.00 kg
2.85 kg
3.65 kg
Characterization
WDM-5X-SM
80-125
WDM-5X-SDM
80-125
ID
1398183
1398184
Height
125 mm
125 mm
Holding force *
35 kN (M10) / 50 kN (M12) /
75 kN (M16)
Pull-in force
25 kN
Actuation torque
15 Nm
Weight
4.70 kg
4.50 kg
* Holding force when fastening the clamping pin with cylindrical
screw –DIN EN ISO 4762/12.9

Assembly
01.00|WDM 80 |de
17
4 Screw tightening torques
Screw tightening torques for mounting the base module WDM-5X-80-BM 80 onto the
machine table (screw quality 10.9)
Screw size
M10
M12
M16
Tightening torques MA(Nm)
52
92
224
5 Assembly
5.1 Pre-assembly measures
CAUTION
Risk of injury due to sharp edges and rough or slippery surfaces.
•Wear personal protective equipment, particularly protective
gloves.
Check that the delivery is complete and that there is no transport damage.
Assembly, dismantling and modification work on the workpiece direct clamping module may
only be carried out by specialist personnel.
Disconnect the power supply lines and ensure that there is no residual energy in the
system before performing assembly, modification, maintenance, or adjustment work.
Until the workpiece direct clamping module is assembled, access to the side attachment
screw of the clamping units must be ensured, particularly when the clamping pallets are
clamped.
Before installing, check whether the drive pistons and the attachment screw can be easily
reached for opening and for clamping and loosening the interface connection on the
workpiece direct clamping systems respectively.
WARNING
Risk of injury due to falling when transporting the workpiece
direct clamping module.
•Transport with care.

Assembly
01.00|WDM 80 |de
18
CAUTION
Risk of injury due to crushing.
•Carefully install the workpiece direct clamping systems.
•Ensure that limbs do not enter into the gaps between the
adaptable workpiece direct clamping modules or the base
module and machine.
•Wear protective gloves.
5.2 General Installation Notes
If several clamping pillars with VERO-S NSE plus clamping systems are mounted linked
together, make sure that the interface position deviation does not exceed ± 0.015 mm.
Due to redundancy between several quick-change pallet systems VERO-S NSE plus, the
clamping pins or the clamping pin extensions with positioning accuracy in one direction (SPB
40 / SPB-VLK50) must be used for clamping systems that are more than 160 mm apart or
that do not show a positioning tolerance of ± 0.01 mm. For the clamping areas that are not
intended aligning the device, workpiece or pallet, clamping pins or clamping pin extensions
with centering clearance (SPC 40 / SPC-VLK50) can be used (see also chapter "Clamping pins"
5.3 Clamping pins SPA 40, SPB 40,
SPC 40, SPG 40
The VERO-S clamping pins SPA 40, SPB 40, SPC 40 and SPG 40 are compatible with the direct
clamping module.
These clamping pins are suitable for use on clamping structures with precisely aligned height
supports on the workpiece or the clamping pallet.
If you want to compensate for variable height distances on the workpiece or the clamping
pallet, you can use the height-adjustable adapter SBA-HE 50-75 with manual clamping
device

Assembly
01.00|WDM 80 |de
19
CAUTION
Notes on clamping pins and mounting screws
The holding force of the quick-change pallet system is limited
essentially by the tightness of the screw connection which
connects the clamping pin to the pallet or the device.
•This is why only screws of strength class 12.9 may be used.
•Only original SCHUNK clamping pins may be used.
•If the clamping pins are to be used in customer-owned
devices, the customer must provide sufficiently dimensioned
threaded holes or a sufficiently thick mounting material.
5.3.1 Standard clamping pins
The clamping pins can be attached to the workpiece or pallet in two different ways; the
mounting variants are however numbered in the preferred order.
Clamping pin installation
Screw
Customer-specific pallet or device
Steel
Aluminum
Steel
Aluminum
Screw

Assembly
01.00|WDM 80 |de
20
Tolerances and installation conditions
Type
ID
A
B
C
D
E
F
G*
H
SPA 40 RF
0471151
> 12
> 17
M12
> 15
> 20
M10
15
> 12
SPB 40 RF
0471152
> 12
> 17
M12
> 15
> 20
M10
15
> 12
SPC 40 RF
0471153
> 12
> 17
M12
> 15
> 20
M10
15
> 12
SPG 40 RF
0471154
> 12
> 17
M12
> 15
> 20
M10
25
> 22
SPA 40-16 RF
0471064
> 13
> 18
M16
> 18
> 24
M12
20
> 16
SPB 40-16 RF
0471065
> 13
> 18
M16
> 18
> 24
M12
20
> 16
SPC 40-16 RF
0471066
> 13
> 18
M16
> 18
> 24
M12
20
> 16
*
The length of the screwed thread must not exceed the
dimension “G”under any circumstances!
Usage/arrangement of the different types of clamping pins
(Application: pallet with 6 clamping positions)
Tightening torques for mounting VERO-S clamping pins type SPA / SPB / SPC
(Screw quality 12.9)
Screw size
M10
M12
M14
M16
Tightening torque (Nm)
62
108
170
262
±0.015 for type C
±0.015 for type B
Type A clamping pin with positioning accuracy
Type C clamping pin with centering clearance of 0.1 mm
±0.015 for Type C clamping pin ±0.015 for Type B clamping pin
Type B clamping pin for positioning in one
direction
