Schwank S100 Operating instructions

S100-F / ITB-F I&O Manual
IM101230
RD: JAN 2014
RL: 9A
INSTALLATION / OWNER’S MANUAL
Improper installation, adjustment, alteration, service or
maintenance can cause property damage, injury or death.
Read the installation and operating and maintenance instruc-
tions thoroughly before installing or servicing this equipment.
SAFETY ALERT:
This heater must be installed and serviced only by a trained gas service techni-
cian. Failure to comply could result in personal injury, death, fire and/or property
damage.
Do not store or use gasoline or other flammable vapours and liquids in the
vicinity of this or any other gas fired appliance.
IF YOU SMELL GAS:
 Extinguish any open flame
 Do not attempt to light this or any other appliance
 Don’t touch any electrical switch, or telephone
 Immediately call your gas supplier from a neighbor’s phone
 Follow any and all instruction from your gas supplier
 If your gas supplier is not available, call the fire department
WARNING
FIELD CONVERTIBILITY:
This appliance is field con-
vertible to LP gas.
Keep this manual in a secure place .
Record for future reference:
Model #:
Serial #:
(located on heater rating label)
Model
S100 - S100U &
Model
ITB - ITBU
LOWINTENSITYTUBETYPE INFRARED HEATERS

2
S100-F / ITB-F I&O Manual
IM101230
RD: JAN 2014
RL: 9A
NOTICE:
This manual is current for this product. Occasional revision of the product Certification Stan-
dard may require changes to the product and/or this manual.
This publication, or parts thereof, may not be reproduced in any form, without prior written
consent from The Manufacturer. Unauthorized use or distribution of this publication is strictly
prohibited.
Schwank Group
Schwank and InfraSave brands
5285 Bradco Boulevard
Mississauga, Ontario,L4W 2A6
PO Box 988, 2 Schwank Way
Waynesboro, Georgia 30830
Customer & Technical Services
Phone: [phone]
Fax: [phone]
e-mail: [email protected]
www.schwankgroup.com
www.infrasave.com

3
S100-F / ITB-F I&O Manual
IM101230
RD: JAN 2014
RL: 9A
TABLE OF CONTENTS
TOPIC .........PAGE
INSTALLATION
IMPORTANT INFORMATION - READ FIRST
APPLICATION..............................................4
HEATER EXPANSION ...........................5, 31
GAS CONNECTION ...............................5, 31
VENTING.................................................5, 26
START UP ‘SMOKE’....................................5
THERMOSTAT SETTING / COMFORT .......5
TUBE ‘GLOW’ ..............................................6
CLEARANCE TO COMBUSTIBLES............6
Clearances Figure & Table ........................7
STACKING HEIGHT SIGN ..........................8
1. LABOR REQUIREMENTS ...............................9
2. INSTALLATION IN AIRCRAFT HANGARS .....9
3. INSTALLATION: COMMERCIAL
GARAGES........................................................9
4. INSTALLATIONS OTHER THAN
SPACE HEATING.............................................9
5. PRE-INSTALLATION SURVEY......................10
6. MOUNTING CLEARANCES...........................11
SERVICE CLEARANCE.................................11
HEATER PLACEMENT GUIDELINES...........12
7. SYSTEMS WITH 90° & 180° ELBOWS .........12
ELBOW KIT DIMENSIONS .……….... …..13
8. SUSPENDING THE SYSTEM........................14
9. BURNER & TUBE INSTALLATION
STRAIGHT TUBE SYSTEM........................15
‘U’ TUBE SYSTEM......................................17
SPECIAL COUPLING -100,175 & 200 Mbh..20
9.4 SESMIC RESTRAINT ....................................22
9.5 HIGH WIND RESTRAINT...............................22
9.6 SEISMIC RESTRAINT ‘U’-TUBE....................23
10. REFLECTOR INSTALLATION......................24
TOPIC ……...PAGE
12. FLUE VENTING...............................................26
12A. MIN./MAX. SYSTEM LENGTHS....................29
13. COMBUSTION AIR DUCT...............................30
14. GAS SUPPLY ..................................................31
HEATER EXPANSION.....................................32
FLEXIBLE GAS CONNECTION.......................33
15. ELECTRICAL AND THERMOSTAT.................34
16. HIGH ALTITUDE INSTALLATION...................34
17. LIGHTING INSTRUCTIONS ...........................34
18. RECOMMENDED MAINTENANCE.................34
19. WIRING DIAGRAM: FENWAL DSI
24V or 120V THERMOSTAT........................35
OR - HONEYWELL S87J DSI ........... 59 - 61
OR - CHANNEL MICRO 50N DSI..... 62 - 65
19A. WIRING DIAGRAM: MULTIPLE HEATERS
PER THERMOSTAT......36
20. FENWAL SEQUENCE OF OPERATION.........38
SPARK IGNITER SET UP ...............................39
FENWAL DSI SERVICE CHECK ...................39
21-A TROUBLESHOOTING GUIDE: DSI ..............40
21-B TROUBLESHOOTING GUIDE: HEATER......41
22. START– UP / COMMISSIONING SHEET.......43
WARRANTY STATEMENT ...................BACK PAGE
DSI CONTROL ADDENDUM: PREVIOUS MODELS
HONEYWELL S87J DSI............................ 59 - 61
CHANNEL MICRO 50N DSI...................... 62 - 65
PRODUCT DIMENSIONS & DATA
23. BURNER / TUBE KIT ASSEMBLY CHART
23A. STRAIGHT TUBE SYSTEM ………….......45
23B. ‘U’ TUBE SYSTEM ………………………...46
24. MODEL INPUTS, DIMENSIONS, WEIGHTS ..47
INSTALLATION DIMENSIONS ………. ..48
25A. TURBULATORS - Straight Tube....................49
25B. TURBULATORS - ’U’- Tube...........................50
26. HIGH ALTITUDE & ORIFICE CHART...... 50 - 51
27. OPTIONAL ACCESSORIES..................... 52 - 55
28. BURNER PARTS LIST ............................ 56 - 57
29. TUBE SYSTEM PARTS LIST...........................58
S100 - S100U and ITB - ITBU SERIES
GAS FIRED INFRARED
LOW INTENSITY TUBE TYPE

4
S100-F / ITB-F I&O Manual
IM101230
RD: JAN 2014
RL: 9A
APPLICATION
A gas-fired radiant tube heater may be installed for heating of commercial / industrial non-
residential spaces. It is beyond the scope of these instructions to consider all conditions that
may be encountered. Installation must conform with all local building codes or, in the absence
of local codes, with the National Fuel Gas Code, ANSI Z223.1/NFPA 54 in the U.S.A. or the
Natural Gas and Propane Installation Code, CSA B149.1 in Canada. The latest edition Electri-
cal Code ANSI/NFPA N0 70 in the U.S.A. and PART 1 CSA C22.1 in Canada must also be ob-
served.
Installation of a gas fired tube heater must conform to all heating installation design procedures
including clearance to combustibles, connection to the gas and electrical supplies, and ventila-
tion.
This heater is not for installation in a Class 1 or Class 2 explosive environment, nor a resi-
dence. If installation of this equipment is in question, consult with local authorities having juris-
diction (Fire Marshall, labor department, insurance underwriter, or others).
Revisions to codes and/or standards, may require revision to equipment and installation proce-
dures. In case of discrepancy, the latest codes, standards, and installation manual will take pri-
ority over prior releases.
Models S100 and ITB may be installed for heating of commercial / industrial non-
residential indoor spaces.
MODELS AVAILABLE FOR OTHER APPLICATIONS:
Models SPW-JZ and IWP have a powder coated water resistant burner enclosure
and may be installed for heating of commercial / industrial non-residential outdoor
spaces and wet indoor environments.
Models STW-JZ and IW have a stainless steel water resistant burner enclosure and
may be installed for heating of commercial / industrial non-residential outdoor
spaces and harsh wet indoor environments.
Improper installation, adjustment, alteration, service or maintenance can cause
property damage, injury or death. Read and understand this installation and op-
eration manual thoroughly prior to assembly, installation, operation or service to
this appliance.
This heater must be installed and serviced only by a trained gas service techni-
cian.
Do not store or use gasoline or other flammable vapours and liquids in the vicinity
of this or any other gas fired appliance.
Failure to comply could result in personal injury, death, fire and/or property dam-
age.
Do not store or use gasoline or other flammable vapours and liquids in the vicinity
of this or any other gas fired appliance.
This appliance may have sharp edges and corners. Wear protective clothing such
as gloves and protective eye wear when servicing this or any other appliance.
WARNING

5
S100-F / ITB-F I&O Manual
IM101230
RD: JAN 2014
RL: 9A
Heater Expansion
It is a normal condition that during heat-up and cool-down a tube
heater will expand and contract. Allowances for heater expansion
must be made in the gas connection, venting and combustion air
ducting. Improper installation, alteration, or adjustment can result in
property damage, injury or death. Refer to Section 13
WARNING
Venting
Inadequate venting of a heater may result in asphyxiation, carbon
monoxide poisoning, injury or death. This heater may be directly or
indirectly vented from the space. Venting must be in accordance with
all local, state, provincial, and national codes (ANSI Z223.1/NFPA 54
in USA; B149.1 in Canada) and as indicated in this manual. Refer to Sections 11 & 12
Gas Connection
Improper installation, connection, or adjustment can result in property
damage, toxic gases, asphyxiation, injury or death. Using an ap-
proved flexible gas connector in the USA or Type 1 hose connector in
Canada, the gas supply to the heater must be connected and tested
in accordance with all local, state, provincial, and national codes (ANSI Z223.1/NFPA 54 in
USA; B149.1 in Canada) and as indicated in this manual. Refer to Section 13
WARNING
WARNING Start-Up ‘SMOKE’ Condition
During start up, the heating of material coatings used in the production process of tubes and
reflectors will create smoke during the initial period of operation. This condition is normal and
temporary .
Ensure that there is sufficient ventilation to adequately clear any smoke from the space.
Notify site and safety personnel to ensure that alarm systems are not unduly activated.
IMPORTANT THERMOSTAT SETTING FOR COMFORT
Infrared radiant (IR) heating system provide comfort with the effect of radiant heat and ambient
air heat.
If your IR system is controlled with a thermostat (TruTemp or ThermoControl Plus) that senses
radiant heat, then set the thermostat to the desired comfort temperature (ie: 65°; 68°; 20°C).
If your IR system is controlled with a standard 24V or 120V thermostat that senses only air tem-
perature, then start with a thermostat setting that is 5° to 7°F (3° to 5°C) lower than the desired
comfort temperature. Some trial and error setting may be required to ‘fine tune’ the comfort tem-
perature that best suits your site and provides most economical operation.
WARNING

6
S100-F / ITB-F I&O Manual
IM101230
RD: JAN 2014
RL: 9A
Clearance to combustibles
Location of flammable or explosive objects, liquids or vapors close to the heater may cause fire
or explosion and result in property damage, injury or death. Do not use, store or locate flamma-
ble or explosive objects, liquids or vapors in proximity of the heater.
The clearance to combustible material represents the minimum dis-
tance that must be maintained between the outer heater surface and
a nearby surface. The stated clearance to combustibles represents a
surface temperature of 90F° (50C°) above room temperature. It is the
installer’s responsibility to ensure that building materials with a low
heat tolerance which may degrade at lower temperatures are pro-
tected to prevent degradation. Examples of low heat tolerance mate-
rials include vinyl siding, fabrics, some plastics, filmy materials, etc.
In locations used for the storage of combustible materials, signs must be posted to specify the
maximum permissible stacking height to maintain the required clearances from the heater to
the combustibles. Such signs must either be posted adjacent to the heater thermostats or in
the absence of such thermostats in a conspicuous location. In addition to stored or stationary
material, consideration must also be given to moveable objects such as cranes, vehicles, and
overhead doors, and structural objects such as sprinkler heads, electrical and gas lines, and
electrical fixtures.
It is beyond the scope of these instructions to consider all conditions that may be encountered.
Consult local authorities such as the Fire Marshall, insurance carrier, or safety authorities if you
are uncertain as to the safety or applicability of the proposed installation.
Refer to Figure 1 and Table 1 for the certified clearances to combustibles for the appro-
priate model input/size.
WARNING
WARNING Tube “GLOW”
It is a normal condition that the combustion tube (1st tube) can appear to “glow red”. For inputs
up to 150,000 Btuh, the top surface of the tube can appear red where heat is trapped between
the reflector and the tube. The stainless steel tube used for inputs 175,000 and greater can ap-
pear to entirely glow red. The tube material is designed into the heater because it can with-
stand the high temperature of combustion, and the “red glow” is a normal occurrence.

7
S100-F / ITB-F I&O Manual
IM101230
RD: JAN 2014
RL: 9A
TABLE 1 MINIMUM CLEARANCES TO COMBUSTIBLES*
FIGURE 1 MINIMUM CLEARANCES TO COMBUSTIBLES* - refer to Table 1 for values
*NOTE: Clearances are measured from the reflector.
The clearance to combustible materials represents the minimum distance that must be main-
tained between the heater and a nearby surface. The stated clearance to combustibles
NOTE: A ‘PEEL & STICK’ SIGN IS SUPPLIED: USE AN INDELIBLE MARKER TO
ENTER VALUES ‘H’, ‘S’, ‘F’, & ‘B’ ON .
POST THE SIGN ADJACENT TO THE HEATER THERMOSTAT OR IN A
PROMINENT LOCATION. See next page for details.
S S
FLOOR
H
T
H
Maximum
Stack Height
H= T- C
‘T’ is meas-
ured on site,
‘C’ is in Table
FLOOR
MODEL
BOTH “STRAIGHT”
& “U-TUBE
SUSPENDED AT AN ANGLE
UP TO 45 DEGREES SUSPENDED HORIZONTALLY
D
inches (cm) B inches (cm) F inches (cm) C inches (cm) A inches (cm) S inches (cm) C inches (cm)
S100(U)/ITB(U) 200 13 (33) 6(15.2) 74 (188) 70 (178) 14 (36) 44 (112) 76 (193)
S100(U)/ITB(U) 175 12 (31) 6(15.2) 72 (183) 68 (172) 13 (33) 42 (107) 74 (188)
S100(U)/ITB(U) 155 10 (26) 4(10) 50 (112) 64 (163) 11 (28) 34 (87) 64 (163)
S100(U)/ITB(U) 130 9(23) 3(8) 40 (102) 56 (142) 10 (26) 32 (81) 60 (152)
S100(U)/ITB(U) 110 9(23) 3(8) 36 (92) 54 (137) 9(23) 30 (76) 60 (152)
S100(U)/ITB(U) 80 7(18) 2(5) 31 (79) 38 (97) 7 (18) 24 (61) 42 (107)
S100(U)/ITB(U) 60 7(18) 2(5) 25 (64) 34 (86) 7 (18) 20 (51) 34 (86)
S100(U)/ITB(U) 45 7(18) 2(5) 29 (74) 32 (81) 7 (18) 16 (41) 32 (81)
S100 /ITB 100 10 (26) 4(10) 57 (145) 68 (172) 11 (28) 32 (81) 68 (172)
T
C
Maximum
Stack Height
H= T- C
‘T’ is meas-
ured on site,
‘C’ is in Table
B
F
D
Suspended at an
angle up to 45°
C
Suspended
horizontally
A

8
S100-F / ITB-F I&O Manual
IM101230
RD: JAN 2014
RL: 9A
VENT END CLEARANCE: Clearances from the vent pipe are determined by local or national
installation codes, but must not be less than 6 inches (15 cm). For ‘unvented’ installation, a
minimum distance of 24 inches (61 cm) is required from the end of heater to a combustible
surface.
In locations used for the storage of combustible materials: Signs
must be posted specifying the maximum permissible stacking height to
maintain the required clearances from the heater to the combustibles.
The signs must be posted either adjacent to the IR heating system thermostats or in the ab-
sence of such thermostats, in a conspicuous place.
For your convenience a “peel and stick” sign
is provided with this heater. Use a permanent
marker to record the required dimensions on
the sign.
To calculate the value ‘H’: (H= T- C)
 Measure the on site distance between bottom of
the heater and the floor = ‘T’ inches (cm).
 Refer to Table 1 to get the value ‘C’ that corre-
sponds to the model you are installing
 Subtract the clearance below the heater ‘C’ from
‘T’ to get value ‘H’.
 Enter this value ‘H’ on the sign.
Refer to the information for the heater model
being installed in Figure 1 and Table 1 to get
the values for dimensions ‘S’, ‘F’ and ‘B’.
WARNING
Post this sign as instructed above.
represents a surface temperature of 90F° (50C°) above room temperature. contin-
ued ...
It is the installer’s responsibility to ensure that building materials with a low heat tol-
erance which may degrade at lower temperatures are protected to prevent degrada-
tion. Examples of low heat tolerance materials include vinyl siding, fabrics, some
plastics, filmy materials, etc.

9
S100-F / ITB-F I&O Manual
IM101230
RD: JAN 2014
RL: 9A
2. INSTALLATION IN COMMERCIAL AIRCRAFT HANGARS
Low intensity radiant tube heaters are suitable for use in aircraft hangars when installed in ac-
cordance with the latest edition of the Standard for Aircraft Hangars, ANSI/NFPA No 409 in the
USA, or the Canadian Natural Gas and Propane Installation Code, B149.1.
A. A minimum clearance of 10 ft (3 m) above either the highest fuel storage compartment or
the highest engine enclosure of the highest aircraft which may occupy the hangar. The
clearance to the bottom of the heater shall be measured from the upper surface of either
the fuel storage compartment or the engine enclosure, whichever is higher from the floor.
B. A minimum clearance of 8 ft (2.4 m) must be maintained from the bottom of the heater to
the floor in other sections of the aircraft hangar, such as offices and shops, which communi-
cate with areas for servicing or storage. Refer to Section 1 for proper mounting clearances
to combustibles.
C. Heaters must be located so as to be protected from damage by aircraft and other objects,
such as cranes and movable scaffolding.
D. Heaters must be located so as to be accessible for servicing and adjustment.
1. LABOR REQUIRMENTS
Two persons are required to safely install this equipment. Wear gloves and other required
safety protection.
3. INSTALLATION IN COMMERCIAL GARAGES AND PARKING STRUCTURES
Low Intensity Heaters are suitable for use in commercial garages when installed in accordance
with the latest edition of the Standard for Parking Structures, ANSI/NFPA 88A, or the Standard
for Repair Garages, ANSI/NFPA No. 88B, or the Canadian Natural Gas and Propane Installa-
tion Code, B149.1.
An overhead heater shall be located high enough to maintain the mini-
mum distance to combustibles, as shown on the heater rating plate, from
the heater to any vehicles parked below the heater.
Overhead heaters shall be installed at least 8 ft (2.4 m) above the floor.
4. INSTALLATIONS OTHER THAN SPACE HEATING
Use for process or other applications that are not space heating will void the C.S.A. certification
and product warranty. Process application requires field inspection and/or certification by local
authorities having jurisdiction.
WARNING

10
S100-F / ITB-F I&O Manual
IM101230
RD: JAN 2014
RL: 9A
WARNING
Improper installation, adjustment, alteration, service or maintenance can cause
property damage, injury or death. Read and understand this installation and
operation manual thoroughly prior to assembly, installation, operation or service to
this appliance.
This heater must be installed and serviced only by a trained gas service technician.
Do not store or use gasoline or other flammable vapours and liquids in the vicinity
of this or any other gas fired appliance.
Failure to comply could result in personal injury, death, fire and/or property damage.
Do not store or use gasoline or other flammable vapours and liquids in the vicinity
of this or any other gas fired appliance.
5. PRE INSTALLATION SURVEY
It is recommended that a full heating design including heat loss calculation be conducted on
the structure or area to be heated. Heater sizing and placement must consider available
mounting height, sources of greatest heat loss, and the certified clearances to combustibles
with respect to stored material, moveable objects (cranes, vehicles, lifts, overhead doors, etc),
sprinkler system heads, and other obstructions on the site. Consideration must also be given to
vent / duct placement and the allowable combined lengths of vent and duct. Carefully survey
the area to be heated, and for best results place burner and combustion chamber in the coldest
area(s) .
Installation must conform with all local, state, provincial and national code requirements includ-
ing the current latest edition ANSI Z223.1 (NFPA 54) in the U.S.A. and B149.1 installation
code in Canada, for gas burning appliances and equipment. The latest edition Electrical Code
ANSI/NFPA N0 70 in the U.S.A. and PART 1 CSA C22.1 in Canada must also be observed.
The heating system must have gas piping of the correct diameter, length, and arrangement to
function properly. For this reason, a layout drawing is necessary.

11
S100-F / ITB-F I&O Manual
IM101230
RD: JAN 2014
RL: 9A
6. MOUNTING CLEARANCES
This heater must be mounted with at least the minimum clearances between the heater and
combustibles as shown in FIG-1, TABLE 1, Page 7. It is the installer’s responsibility to ensure
that building materials with a low heat tolerance which may degrade at lower temperatures are
protected to prevent degradation. Examples of low heat tolerance materials include vinyl sid-
ing, fabrics, some plastics, filmy materials, etc.
Positioning of lights, sprinkler heads, overhead doors, storage areas, gas and electrical lines,
parked vehicles, cranes and any other possible obstruction or hazard must be evaluated prior
to installation.
Ensure adequate clearance around the air intake at the burner to allow sufficient com-
bustion air supply to the heater.
6A. SERVICE CLEARANCE: The lower ‘jaw’ of the burner cabinet swings down to provide
convenient service access to burner components. Provide a minimum clearance from any wall
or obstruction of 6 inches (15 cm) to the access end of the burner housing, and a minimum of
24 inches (61 cm) to any ONE side to allow servicing of burner, blower and controls. (see Fig-
ure 2) - the minimum clearances to combustibles must always be maintained.
For guidelines to heater placement refer to TABLE 2 (below).
FIGURE 2

12
S100-F / ITB-F I&O Manual
IM101230
RD: JAN 2014
RL: 9A
*RECOMMENDED MOUNTING HEIGHTS are typical to provide optimum comfort in general
space heating applications. Variance to these typical heights can occur in some applications:
 Higher mounting heights due to structure or application requirements
 Lower mounting heights for area or ‘spot’ heat, or in areas with greater infiltration losses
(near overhead doors, etc)
IMPORTANT: Single or multiple heater placement must be such that continu-
ous operation of heater(s) will not cause combustible material or materials in
storage to reach a temperature in excess of ambient temperature plus 90F°
(50C°).
It is the installer’s responsibility to ensure that building materials with a
low heat tolerance which may degrade at lower temperatures are pro-
tected to prevent degradation. Examples of low heat tolerance materials
include vinyl siding, fabrics, some plastics, filmy materials, etc.
Refer to “Clearance to Combustibles” information on pages 6 to 8, and
Figure 1 and Table 1.
MOUNTING
HEIGHT
ft (m)
MAXIMUM
DISTANCE
BETWEEN
HEATERS
ft (m)
DISTANCE – OUTSIDE WALL
TO HEATER LONG AXIS
(PARALLEL TO WALL) IN “FEET”
HORIZONTAL
ft (m) ANGLE
S100 / ITB 200 18 – 25 (6 - 8) 50 (15) 17 – 25 (5 - 8)
COMBUSTIBLE
CLEARANCE
BEHIND
(refer to Table 1)
S100 / ITB 175 18 – 25 (6 - 8) 50 (15) 17 – 25 (5 - 8)
S100 / ITB 155 16 – 21 (5 - 7) 45 (14) 15 – 20 (5 - 7)
S100 / ITB 130 15 – 21 (5 - 7) 40 (12) 15 – 20 (5 - 7)
S100 / ITB 110 13 – 19 (4 - 6) 35 (11) 13 – 18 (4 - 6)
MODEL
“Straight” or
“U-Tube”
S100 / ITB 80 10 – 16 (3 - 5) 30 (9) 12 – 16 (4 - 5)
S100 / ITB 60 8 – 14 (2.5 - 5) 25 (8) 11 – 15 (3.4 - 5)
S100 / ITB 45 8 – 12 (2.5 - 4) 20 (6) 8 – 12 (2.5 - 4)
S100 / ITB 100 13 – 19 (4 - 6) 35 (11) 13 – 18 (4 - 6)
TABLE 2: GUIDELINES FOR HEATER PLACEMENT
7. SYSTEMS INCORPORATING 90° ELBOWS AND 180° ELBOWS
The radiant tube heater can be installed in configurations as illustrated in FIGURE 4. (below)
with a maximum of two 90° elbows per heater. The use of elbows reduces the total maximum
vent allowable. (See Section 11 : Flue venting)

13
S100-F / ITB-F I&O Manual
IM101230
RD: JAN 2014
RL: 9A
FIGURE 3 SYSTEM ELBOW KIT - see page 50 for 180° elbow dimensions
90° elbows (JS-0528-SM) are shipped as a kit with one coupler, and two reflector end caps.
The S100 / ITB is available in a “U-Tube” model - S100U / ITBU - using a 180° turn box. A
double wide reflector covers the double tube run. Alternately, for a 180° elbow, order 2 x 90°
kits that connect to create a 180°.
IMPORTANT: Models with input 100 Mbh x 20 ft (30 kW x 6 m) must only be installed as a
straight system with no elbows allowed at the 10 ft (3 m) location.
Elbow Location / Input: A minimum run of straight radiant tube must be con-
nected to the burner before any elbow as follows: Inputs 200 (60 kW) and 175
Mbh (50 kW) = 25 ft (7.6 m); Input 155 Mbh (45 kW) = 20 ft (6 m); Inputs 130
Mbh (38 kW) and 110 Mbh (32 Kw) = 15 ft (4.6 m); and Inputs 80 Mbh (23 kW),
60 Mbh (18 kW), and 45 Mbh (13 kW) a minimum of 10 ft (3 m) straight tube be-
fore elbow.
5 900Elbow
6 Tube Coupler
7 Unswaged end of elbow and tube (swage
of previous tube or elbow inserted).
1 End-Cap
2 Reflector
3 End Cap Flange OVER Reflector
4 End Cap Flange UNDER Reflector
1
2
2
3 3
44
5
6
7
FIGURE 4 90° ELBOW INSTALLATION

14
S100-F / ITB-F I&O Manual
IM101230
RD: JAN 2014
RL: 9A
8. SUSPENDING THE SYSTEM - GENERAL
Inadequate or improper suspension of the tube heater can result in collapse of
the system, property damage, and personal injury or death.
It is the installer’s responsibility to ensure that the hardware and structural sup-
ports from which the heater is suspended are sound and of adequate strength
to support the weight and expansion forces of the heater.
Consider that the heater will expand in length as much as 1/2 inch (12.5 mm) or more for every
10 ft (3 m) of system length – typically the greater the firing rate, the greater the expansion.
Refer to Sections 13 & 14
1) Survey the available structural supports, considering the system configuration and heat re-
quirements of the area to establish the optimum heater location.
a) Locating a heater directly under joists or beams, or installing supplemental steel support
rail or angle iron can substantially reduce labor and materials
2) Hardware with a minimum 60 lb. (30 kg) work load must be used at each heater suspension
point. A #8 Jack Chain or equivalent is typically used for suspending the heater.
a) Connect to the structure using typical hardware as illustrated in FIGURE 6 (below) or by
other mechanically sound means
b) If rigid devices such as 3/8” threaded rods are used for suspension, swing joints or other
means must be provided to allow for system expansion - approximately ½ inch to 1 inch
for every 10 ft (1 cm to 2.5 cm for every 3 m) of system length.
3) Tube system hangers must be located:
i: Straight in line
ii: At a common height (level)
NOTE: It is important that the
tubes in the system are in-
stalled in alignment horizon-
tally (level) and vertically (in
line) – this will ensure system
integrity
HOOK OR EYE
BOLT THROUGH
BEAM CLAMP
WITH HOOK OR
EYE HOOK OR
EYE PIPE RING OR CLEVIS
BAR-JOIST
CLAMP
FIGURE 6 TYPICAL MOUNTING HARDWARE
NOTE: It is the installer’s responsibility to ensure that mounting hardware and
fastening to structure are of sufficient strength to support the system.
FIGURE 5 SYSTEM CONFIGURATIONS
STRAIGHT TUBE SYSTEM
‘U’ TUBE SYSTEM
90° ELBOW

15
S100-F / ITB-F I&O Manual
IM101230
RD: JAN 2014
RL: 9A
9.1 S100 / ITB STRAIGHT TUBE SYSTEM ~ BURNER AND TUBE INSTALLATION
For “U-Tube” Systems S100U / ITBU refer to section 9.2 page 17
IMPORTANT SPECIAL NOTES: READ FIRST
1. S100/ITB 100 x 20 ft: Special Tube Coupling - Refer to Section 9.3, Fig 15
2. S100/ITB 175 & 200:Special Tube Coupling -Refer to Section 9.4, Fig 16
These input rates have an unpainted titanium alloy stainless steel first tube with a flange
(painted “white”), and an unpainted aluminized steel tube as the second tube; all subse-
quent tubes are hot rolled steel. The first tube (titanium alloy stainless steel ) will “glow
red” while heater is in operation - THIS IS A NORMAL CONDITION
3. IF a 90° elbow is to be installed in the system, refer NOW to Section 7 and the Elbow Kit
installation instructions supplied with the kit
4. TURBULATORS: Also refer to Table page 46
155 Models (150,000 Btuh): 2 ft turbulator is supplied in the Burner Kit and field installed:
 155 x 40 ft heater: Insert 2 ft turbulator in end of third tube, prior to the 10 ft turbu-
lator that is factory installed in the last tube (total 12 ft turbulator)
 155 x 50 ft heater: Insert in the vent end of the last tube in the system.
 All other turbulators are factory installed inside tube(s) that are clearly labeled with
instruction as to where the tube(s) must be installed - Also see page 46
1) Install Hangers:
i: No closer than 3” (5 cm) and no further than 5” (10 cm) from the burner/tube flange
ii: No closer than 6” (15 cm) either side of a tube connection in the system
iii: No further than 24” (61 cm) either side of a tube connection in the system
2) With all hangers in alignment and suspended at the same height, insert first aluminized tube
section, through 4" hole into first two wire hangers.
NOTE: INSTALL THE FIRST AND SECOND TUBES (FROM BURNER END) WITH THE WELDED SEAM
ALONG THE TUBE LENGTH FACING DOWNWARD
3) Bolt burner to flange on first tube section, SEE FIGURE 8.
IMPORTANT NOTE: Models with inputs 100,000, 175,000 & 200,000 refer to section 9.3
4) Slide a Torctite tube coupler over the swaged end of the first tube, then join the second tube
over the swage in the first tube
5) Slide the Torctite coupler into position across the center of the joint - SEE FIGURE 9
6) IMPORTANT: TOURQUE THE COUPLER BOLTS TO 40 ft-lbs
7) Subsequent lengths of tube can then be installed, by joining them together swaged portion
inside the next tube and locking the joints using the Torctite coupler. SEE FIGURE 9.
8) If there is a 90° elbow in the system refer to Section 7 and Figures 3 & 4
9 INSTALLATION OF HANGERS, TUBES AND BURNER

16
S100-F / ITB-F I&O Manual
IM101230
RD: JAN 2014
RL: 9A
FIGURE 7 STRAIGHT TUBE TYPICAL HANGER & SUPPORT SPACINGS
6 - ALUMINIZED TUBE WITH FLANGE
7 - TORCTITE TUBE COUPLER
8 - STEEL TUBE(S)
9 - REFLECTOR
10 - FLUE VENT TERMINAL
11 - BURNER SUPPORT CHAIN
12 - HANGER SUPPORT CHAINS
1 - END CAP
2 - WIRE HANGER
3 - BURNER ASSEMBLY
4 - COMBUSTION AIR OPTIONS:
4A - JS-0532-SE 4” INTAKE ADAPTER
4B - JS-0532-VC 4” WALL CAP
4C - JA-0528-XX 4” ROOF CAP
5 - SIGHT GLASS
SUSPEND ALL TUBES BY TWO (2) HANGERS PER 10’ LENGTH, LOCATED BETWEEN 6” to 24”
FROM EACH TUBE CONNECTION.
INSTALL FIRST AND SECOND TUBES (FROM BURNER END) WITH WELDED SEAM FACING
DOWNWARD.
1 Eye Bolt
2 Fifth Nut (Holds Inner Burner to Housing -
Do Not Remove or Loosen)
3 Lock Washers (4) Four
4 Nuts (4) Four Note: Nuts may be shipped
c/w lock-washers as one piece
 Insert four burner bolts through the tube
flange, secure tightly with lock washers and
nuts.
 Note: A Flange Gasket is not required for
this application
 Secure suspension chain to eye bolt to sta-
bilize burner
 Align the four burner bolts through flange on
tube, secure tightly with lock washers and
nuts
FIGURE 8
BOLTING BURNER TO FLANGED TUBE

17
S100-F / ITB-F I&O Manual
IM101230
RD: JAN 2014
RL: 9A
9.2 S100U / ITBU ‘U’-TUBE SYSTEM ~ BURNER AND TUBE INSTALLATION
For “Straight-Tube” Systems S100 / ITB refer to section 9.1 page 15
IMPORTANT SPECIAL NOTES: READ FIRST
1. S100U/ITBU 175 & 200:Special Tube Coupling -Refer to Section 9.4, Fig 16
These input rates have an unpainted titanium alloy stainless steel first tube with a
flange (painted “white”), and an unpainted aluminized steel tube as the second tube; all
subsequent tubes are hot rolled steel. The first tube (titanium alloy stainless steel ) will
“glow red” while heater is in operation - THIS IS A NORMAL CONDITION
2. TURBULATORS: Also refer to Table page 47
155 Models (150,000 Btuh): 2 ft turbulator is supplied in the Burner Kit and field installed:
 155 x 20 ft U heater: Insert 2 ft turbulator in end of third tube in the system (1st
tube after turn box), prior to the 10 ft turbulator that is factory installed in the last
tube (total 12 ft turbulator)
 155 x 30 ft U heater: Discard 2 ft turbulator - not required.
 All other turbulators are factory installed inside tube(s) that are clearly labeled with
instruction as to where the tube(s) must be installed - Also see page 47
FIGURE 9 COUPLER (NOTE: See Section 9.3 for ‘Special Couplers’ at first tube
joint: 100,000 x 20 ft & 175 / 200,000 models)
1 Tube
2 Tube Coupler
3 Swaged section of upstream tube
4 End of downstream tube
5 Place the centre of the coupler over
the line of the tube joint (end of down-
stream tube)
6 Tighten bolts to 40 ft-lbs.
1
1
2 3
4
FIGURE 10 HANGER / REFLECTOR ORIENTATION HORIZONTAL TO 450
FOR ANGLE LESS
THAN 45° USE
CHAIN TO BOTH
EYES ON
HANGER
45° 45°

18
S100-F / ITB-F I&O Manual
IM101230
RD: JAN 2014
RL: 9A
1) Install Hangers using chain or other suitable suspension hardware at each side of the
hanger: See Figure 11 next page
i: Two hangers for first section (from burner), and one hanger for each additional section
ii: No closer than 12” (30 cm) and no further than 14” (35 cm) from the burner/tube
flange
iii: No closer than 6” (15 cm) from a tube connection in the system
iv: No further than 18” (61 cm) from a tube connection in the system
v: If angle mounting a ‘U’ Tube model, the vent side must be in the upper position
2) With all hangers in alignment and suspended at the same height (and angle), insert first alu-
minized tube section on to the first two hangers: See Figure 12A next page
 Also lay the vent end tube on to the first two hangers - check tubes for turbulator la-
bel to ensure the correct tube is located at the vent end
NOTE: INSTALL THE FIRST AND SECOND TUBES (FROM BURNER) WITH THE WELDED SEAM
ALONG THE TUBE LENGTH FACING DOWNWARD
3) Fasten flanged tube to hangers with ‘U’ bolts:
 All tubes on the burner-side of the heater are bolted to the hangers with ‘U’ bolts
 Tubes on vent-side simply rest in the hanger notch and do not fasten to the hanger.
4) Bolt burner to flange on first tube section - SEE FIGURE 8 previous page.
IMPORTANT NOTE: Models with inputs 175,000 & 200,000 refer to section 9.3
5) Slide a Torctite tube coupler over the swaged end of the first tube, then join the second tube
over the swage in the first tube -
6) Slide the Torctite coupler into position across the center of the tube joint - SEE FIGURE 9
7) IMPORTANT: TOURQUE THE COUPLER BOLTS TO 40 ft-lbs
8) Subsequent lengths of tube can then be installed on both sides of the hangers by joining
them together swaged portion inside the next tube and locking the joints using the Torctite
coupler. SEE FIGURE 9.
 Note that 155 x 20’U requires field installation of a 2 ft turbulator (packed in Burner Kit carton) in
the swaged end of the third tube in the system (1st tube after turn box on vent run side)
9) Install Turn Box: See Fig 12B
 The Turn Box has “long” and “short” tube legs
 The ‘long’ leg attaches to the burner-run tubes
 The ‘short’ leg attaches to the vent-run tube side - tubes end short of burner for con-
nection of vent pipe

19
S100-F / ITB-F I&O Manual
IM101230
RD: JAN 2014
RL: 9A
FIGURE 11 ‘U’-TUBE TYPICAL HANGER & SUPPORT SPACING
8 - STEEL TUBE(S)
9 - REFLECTOR
10 - FLUE VENT TERMINAL
11 - BURNER SUPPORT CHAIN
12 - HANGER SUPPORT
CHAINS
4B - JS-0532-VC 4” WALL CAP
4C - JA-0528-XX 4” ROOF CAP
5 - SIGHT GLASS
6 - ALUMINIZED TUBE WITH
FLANGE
7 - TORCTITE TUBE COUPLER
1 - END CAP
2 - WIRE HANGER
3 - BURNER ASSEMBLY
4 - COMBUSTION AIR OPTIONS:
4A - JS-0532-SE 4” INTAKE
ADAPTER
SUSPEND FIRST TUBES BY TWO (2) HANGERS, THEN SUBSEQUENT SECTIONS BY ONE HANGER
LOCATE HANGERTS BETWEEN 6” to 18” FROM EACH TUBE COUPLER.
INSTALL FIRST AND SECOND TUBES (FROM BURNER END) WITH WELDED SEAM FACING DOWNWARD.
FIGURE 12 ‘U’ TUBE MODELS
TURN BOX
FIGURE 12B
‘U’ TUBE HANGER
FIGURE 12A
FIGURE 13 ‘U’ TUBE MODEL ORIENTATION

20
S100-F / ITB-F I&O Manual
IM101230
RD: JAN 2014
RL: 9A
SPECIAL COUPLER INSTALLATION
1. Install first tube so that the welded seam
along the tube length is in the lower half of
the tube facing downward
2. Slide the loosened tube coupler on to the
first tube, past the swage
3. The second tube is supplied with a ¼” hole
in the tube at the female end.
4. Slide second tube over swaged end of first
tube so that ¼” hole is located 90° up from
the bottom (3 or 9 o’clock position)
5. Note that the spine of the turbulator should
be oriented in a vertical position
6. Through the existing ¼” hole , drill a ¼”
hole through the wall of the first tube
7. Insert ¼” rivet into the hole
8. Slide coupler into position – half onto each
tube – covering the rivet head
9. Tighten coupler bolts to 40 ft-lb
10.Install reflectors
9.3 SPECIAL COUPLING: 100,000 Btuh x 20 ft
NOTE: The joint of 1ST & 2ND tubes of the 100,000 x 20 ft heater experiences strong
forces of expansion. Follow instructions below for special coupling of the tubes and orien-
tation of the turbulator in the 2nd tube..
FIGURE 15 SPECIAL COUPLING:
 100,000 x 20 ft
- Fasten Second Tube to First Tube -
Steps 2
thru 6
Step 7
Steps 8
& 9
1/4” Rivet
VIEW INSIDE TUBE: Ensure the 8 ft (2.4 m) tur-
bulator installed in the second tube is oriented
with its spine in a vertical position, and located at
the vent end of the tube.
This will result in the best performance and radi-
ant output from the system.
Step 5
NOTE: 100,000 Btuh x 20 ft Heater
TURBULATOR ORIENTATION
with 8 ft turbu-
2 ft
Install tube with turbula-
tor spine in vertical posi-
tion for best performance
Step 1 Welded seam in lower
half of tube, facing
downward
TOOLS REQUIRED: Electric Drill
1/4” Drill Bit (supplied)
