SCORPION RTR-87 User manual

NO. PART NO. DESCRIPTION QTY
1 RSC407 Serket Taper Silencer 1
2 CP954 Connecting Pipe 1
Fit Kit - Z039.10610
3 Z017.10073 M8 x 25mm Cap Head Bolt 1
4 Z026.20068 Alloy Bolt Finisher 1
5 Z015.31323 Mounting Bracket 1
6 Z017.10825 M8 x 25mm Washer 1
7 Z017.10062 M8 Nyloc Nut 1
8 Z028.10030 Rubber Coated Spring 2
9 Z016.10008 43-47mm Clamp 1
Part No.
Fit Kit
dB Killer
Bike
Year
Notes
Triumph Street Triple 765
2017-Current
Where not supplied use original ttings
Fits to S, R & RS models.
RTR-87
Z039.10610
Z038.10043 (TYPE V)
E-MARK e11 00521
DATE 19/07/17
ISSUE 00
AUTHORISED M.Ydlibi
Estimated Fitting Time: 60 Minutes
STAY CONNECTED TO RED POWER.
3
4
1
2
5
6
7
89
Bracket ts behind the original mounting point.
Use original ttings.
FITTING INSTRUCTIONS
//

Part No.
Fit Kit
dB Killer
Bike
Year
Notes
s
s
‘
STAY CONNECTED TO RED POWER.
Note: Retain all original parts and
fittings.
A) Unscrew heat shield bolt and
remove heat shield.
B) Undo original clamp and remove
it from the bike.
C) Unscrew the original silencer
mounting bolt.
D) Unscrew the second original
silencer mounting bolt.
E) Remove the silencer from the
bike.
F) Following the diagram above,
loosely fit the Scorpion system.
G) Check the clearance between
the pipework and the rear tyre,
this requires a minimum spacing
45mm.
H) Check the clearance between
the pipework and the suspension
linkage, this requires a spacing of
at least 20mm.
Instructions continue on the next
page:
A B
C D
E
Triumph Street Triple 765
2017-Current
RTR-87
Z039.10610
Z038.10043 (TYPE V)
F
HG
Where not supplied use original ttings
Fits to S, R & RS models.

Part No.
Fit Kit
dB Killer
Bike
Year
Notes
s
s
‘
STAY CONNECTED TO RED POWER.
I) Looking from the rear of the
bike ensure the silencer does not
protrude past the foot peg.
J) Check the clearance between
the silencer and the swing arm,
this requires a minimum spacing of
15mm.
K) Check the clearance of between
the silencer and brake lever. Press
brake lever down to ensure it does
not touch the silencer at any point
during use.
L) Once happy with the alignment
of your exhaust, tighten all fittings.
Take bike for a short ride. Upon
return allow the system to cool and
check all fittings are still secure.
I J
KL
Triumph Street Triple 765
2017-Current
RTR-87
Z039.10610
Z038.10043 (TYPE V)
Where not supplied use original ttings
Fits to S, R & RS models.

s
s
‘
STAY CONNECTED TO RED POWER.
Thank you for purchasing your Scorpion Silencer.
Care of your exhaust: Please refrain from cleaning silencer with heavy solvents or abrasives!
Vielen Dank Fur den kauf eines Scorpion Schalldampfers! Pflegehinweis: Bitte verwenden Sie niemals Scheuermit-
tel oder aggressive Reiniger zur Pflege Ihres Auspuffes!
Merci d’avoir choisi un echappement Scorpion.
Entretien de votre silencieux: Ne pas utiliser de solvants ou de produits abrasifs!
Muchas gracias por adquirir un Silencioso Scorpion. Le recomendamos no limpiar el silencioso con productos
abrasivos o aquellos que contengan disolventes.
Part No.
Fit Kit
dB Killer
Bike
Year
Notes
Estimated Fitting Time: 60 Minutes
E
Triumph Street Triple 765
2017-Current
RTR-87
Z039.10610
Z038.10043 (TYPE V)
Where not supplied use original ttings
Fits to S, R & RS models.
FITTING INSTRUCTIONS
//
