GEOMETRY & TECHNICAL DATA 03
SEAT CLAMP ADJUSTMENT 04
SEATPOST ASSEMBLY FOR DUNCAN SL AERO & AERO COMFORT 06
CABLE ROUTING 07
SPARE PARTS 08
MANUFACTURE’S GUARANTEE 11
FOIL RC
LEGEND
T2
10Nm
TORQUE REQUIRED TORX TOOL SIZE
HEX TOOL SIZE
TORQUE AMOUNT
TASK DIFFICULTY
NO GREASE REQUIRED
GREASE REQUIRED
CARBON GREASE REQUIRED
THREADLOC REQUIRED
CONTENT
THE ADDICT ERIDE SHOULD BE ADJUSTED EXACTLY TO THE RIDER FOR MAXIMUM SAFETY
AND RIDEABILITY.
Please contact your authorized SCOTT dealer for advice in order to avoid technical problems or
any harm.
BEARING FIT REQUIRED

2022 FOIL RC | 3
|
FOIL RC
GEOMETRY & TECHNICAL DATA
MY22 FOIL RC 47 XXS 49XS 52 S 54 M 56 LG 58 XL 61 XXL
AHead tube angle °70.5 71 72 72.5 73 73.3 73.3
BHead tube length mm 103 108 121 141 161 181 199
CTop tube horizontal mm 520 530 540 550 565 580 600
Dstandover height mm 746.4 759.6 779.4 801 820 838 853.3
EBB offset mm -70 -70 -70 -70 -70 -70 -70
FBB height mm 274.5 274.5 274.5 274.5 274.5 274.5 274.5
G Wheelbase mm 987.7 993.7 990.7 992.6 999.9 1008.6 1022.7
HBB center to TTC mm 450.8 480.9 501.4 521.6 541.4 558.8 571.4
IBB center to TST mm 451.8 481.9 502.4 522.6 542.4 559.8 572.4
JSeat angle °74.5 74.5 74 73.6 73.3 73 72.5
K Chainstay mm 412 412 412 412 412 412 412
L Reach mm 380 388 389 389 394.5 400 409
M Stack mm 505 511 527 548 568 589 606
Fork Rake mm 45 45 45 45 45 45 45
Trail mm 73.5 70.3 64 60.8 57.7 55.8 55.8
Max/Min Rotor Size:
Front Max/Min 180mm / 140mm
Rear Max/Min 160mm / 140mm
Headset:
Top: 44x35x5.5 / 36°-45°
Bottom: 40x52x7 / 45° - 45°
Max Tyre Size:
30mm
BB Housing:
41 x 86.5mm
Fork Steerer:
1 - 1 1/2 inch
Axle Dimensions:
Front: 100mm Rear: 142mm

2022 FOIL RC | 4
|
FOIL RC
FOIL RC
SADDLE CLAMP ADJUSTMENT
01
03 04
02
T25
OR
MAX
5MM
T25

2022 FOIL RC | 5
|
FOIL RC
FOIL RC
SADDLE CLAMP ADJUSTMENT *CONTINUED
07
06
05
T25
16Nm
T25

2022 FOIL RC | 6
|
FOIL RC
FOIL RC
SEATPOST ASSEMBLY FOR DUNCAN SL AERO & AERO COMFORT
10Nm
01 02
03
MOLYKOTE 111
1000 KMS
Carbon Grease
292895 SYN S.post Duncan SL Aero CFT, 0mm
292896 SYN S.post Duncan SL Aero CFT, 15mm
292893 SYN S.post Duncan SL Aero, 0mm
292894 SYN S.post Duncan SL Aero, 15mm
For XXS, XS, and Small sized
frames the seatpost may need
to be cut down in length to
accomomdate the rider’s leg
length and position.
Please contact your authorised
Scott Dealer for assitance as you
could damage your frame if carried
out incorrectly.
* Duncan SL Aero Comfort & Duncan SL Aero
* Duncan SL Aero Comfort

2022 FOIL RC | 7
|
FOIL RC
FOIL RC
CABLE ROUTING
Mechnical Cable and Brake Hose
routing.
Di2 Wire Routing.

2022 FOIL RC | 8
|
FOIL RC
FOIL RC
SPARE PARTS
296235 SCO Stem
steerer cap Creston
IC Aero 23
296236 SCO Stem
hardware kit Creston
IC Aero 23
296234 SCO Headset
expander Foil 23
297669 SCO Headset
top cap Foil 23
297731 SCO Axle Foil
3/Plasma 7 F 23
297732 SCO Axle Foil
3/Plasma 7 R 23
296233 SCO Headset
Spacer Creston IC
Aero 23
10Nm
8 Nm
5 Nm
grease
bolt
thread
only
6
5
T25

2022 FOIL RC | 9
|
FOIL RC
FOIL RC
SPARE PARTS
296238 SCO Bar
Rubber Creston 1.0
Aero 23
296239 SCO Seatpost
clamp Foil 23
296241 SCO Seatpost
rubber cover Foil 23
296240 SCO Seatpost
saddle clamp kit Foil 23
296237 SCO Stem
Hardware Kit Creston
Ic Aero 23
10Nm
16Nm
3 Nm
2 Nm
T25
2.5
3
296242 SCO BB DI2
battery mount Foil 23 2 Nm T20
bolt
only

2022 FOIL RC | 10
|
FOIL RC
FOIL RC
SPARE PARTS
296243 SCO FD-Mount
and blank Foil 23
296605 SCO Dropout Foil /Plasma DM 23
277544 SCO Dropout Addict RC 20
3 Nm
2 Nm
T20
2 Nm T25

2022 FOIL RC | 11
|
