2022 ADDICT eRIDE | ENGLISH 1
|
2022 S COT T
ADDICT eRIDE
MANUAL

2022 ADDICT eRIDE | ENGLISH 2
|
GEOMETRY & TECHNICAL DATA 03
DROPOUTS & AXLES 04
REAR BRAKE DISC MOUNTING 06
CONTROL & RANGE EXTENDER 07
CHARGER & DISPLAY 08
HEADSET OPTIONS 09
STEM / SEATPOST / CABLE GUIDE OPTIONS 10
MANUFACTURE’S GUARANTEE 11
CONTENT
THE ADDICT ERIDE SHOULD BE ADJUSTED EXACTLY TO THE RIDER FOR MAXIMUM SAFETY
AND RIDEABILITY.
Please contact your authorized SCOTT dealer for advice in order to avoid technical problems or
any harm.
ADDICT eRIDE
APPLE STORE GOOGLE PLAY
T2
10Nm
TORQUE REQUIRED TORX TOOL SIZE
HEX TOOL SIZE
TORQUE AMOUNT
TASK DIFFICULTY
NO GREASE REQUIRED
GREASE REQUIRED
THREADLOC REQUIRED
BEARING FIT REQUIRED
Before taking delivery of your new Addict eRIDE, please make sure you understand how the bike
functions in regard to the drive system, battery, and controls.
Your Authorized Scott Dealer can explain how the bike functions, and how the consumer APP
(ITunes & Android) is connected to the system.

2022 ADDICT eRIDE | ENGLISH 3
|
ADDICT eRIDE
GEOMETRY & TECHNICAL DATA
MY22 ADDICT eRIDE XS SM MED LG XL
AHead tube angle 71° 72° 72.5° 73° 73.3°
BHead tube length 105 mm 125 mm 145 mm 165 mm 185 mm
CTop tube horizontal 515 mm 530 mm 545 mm 560 mm 575 mm
Dstandover height 752 mm 776 mm 799 mm 822 mm 843 mm
EBB offset -70 mm -70 mm -70 mm -70 mm -70 mm
FBB height 279 mm 279 mm 279 mm 279 mm 279 mm
G Wheelbase 995.1 mm 997 mm 1002.6 mm 1007.5 mm 1014.8 mm
HBB center to top tube center 435 mm 460 mm 485 mm 510 mm 535 mm
IBB center to top of seat tube 490 mm 520 mm 540 mm 560 mm 580 mm
JSeat angle 75° 74.5° 74° 73.5° 73.1°
K Chainstay 422 mm 422 mm 422 mm 422 mm 422 mm
L Reach 373.2 mm 377 mm 380.9 mm 384.3 mm 388.6 mm
Stack 529.1 mm 551.6 mm 572.4 mm 593.3 mm 613.6 mm
Fork Rake 45° 45° 45° 45° 45°
Max/Min Rotor Size:
- Front 160mm Only
- Rear 160mm Only
Max Rotor bolt size:
10mm (standard disc bolt length)
Max Tyre Size:
32mm
Ⓑ
Ⓐ
Ⓒ
Ⓕ
Ⓘ
Ⓓ
Ⓗ
Ⓖ
Ⓔ
Ⓙ
Ⓛ
Ⓚ

2022 ADDICT eRIDE | ENGLISH 4
|
DROPOUTS & AXLES
10Nm
ADDICT eRIDE
T103 Nm
The X20 features a new rear hub
motor with a 12x142 mm axle.
The X20 features an easy slip in
system of the wheel. This means the
motor auto connects with the system
when the rear wheel is inserted into
the dropout.
Make sure the hub sensor is
clean & located correctly into
the dropout.
290053 SCO eRIDE Mahle Addict
Dropout L/H/S 22
For the right-hand side drop out
hanger the frame features the same
dropouts’ options as the Addict RC.
The new frame now as well share
the same rear axle as Addict RC, this
means the bike can now be used with
a standard non-motorised 12x142mm
wheel.
277030 SCO Axle rear Addict RC/
Plasma 6 20

2022 ADDICT eRIDE | ENGLISH 5
|
DROPOUTS & AXLES cont.
10Nm
ADDICT eRIDE
T20
1 Nm
2 Nm
part number:
277544 SCO Dropout Addict RC 20
277545 SCO Dropout Addict RC direct
mount 20
part number:
277028 SCO Axle Front Addict
RC/Plasma 6 TP 20

2022 ADDICT eRIDE | ENGLISH 6
|
ADDICT eRIDE
REAR BRAKE DISC MOUNTING
PLEASE TAKE EXTRA CARE WHEN INSTALLING THE REAR DISC ROTOR AS THE ROTOR WILL
HAVE A TIGHT FIT WHEN INSTALLING IT OVER THE MOTOR CONNECTOR.
TAKE NOTE OF THE CORRECT DISC ROTOR POSITION AS HIGHLIGHTED BELOW.
ONCE THE CONNECTOR IS BEHIND THE ROTOR, THE END CAP CAN GO THROUGH THE BRAKE
DISC HOLE.

2022 ADDICT eRIDE | ENGLISH 7
|
CONTROL & RANGE EXTENDER
ADDICT eRIDE
Control Button
On/O _ Assistance Level_Light On/
O
Ambient Light Sensor
Adaptation of the bicycle components
(lights etc).
RGB Dynamic Line
Battery Level (area filled)
Assist Level (by colour)
System Info (animation of the line)
GREY: No
Assistance
GREEN: Level 1
ORANGE: Level 2
RED: Level 3
BLUE: Automatic
Assistance Mode
The new X20 Range Extender is a second
battery (185 Wh) and direct power supply
to the X20 system. This means the Range
Extender can support the bike even if the
internal battery has been drained of power.
The X20 and X35 are not cross compatible.
The X20 Range Extender has as a new smaller
size to fit any standard bottle cage on the
market, no special Range Extender cage from
Mahle is needed.
288538 SCO RIDE Mahle Addict Booster 2
battery

2022 ADDICT eRIDE | ENGLISH 8
|
CHARGER & DISPLAY
ADDICT eRIDE
The X20 system is compatible with the
PulsarONE display.
285950 SCO eRIDE Mahle Addict
PULSARONE display
The new Active Charger includes CAN BUS
for real time communication with the
battery.
This direct communication combined with a
more powerful converter allows the
battery to be charged at dierent intensities
from 0 to 4.5A making the charging
process faster and more ecient.
The micro USB port on the charger provides
an additional connecting point which allows
future updates to be made to the full eBike
system directly.
The charger is not cross compatible with
dierent systems !
294434 SCO eRIDE Mahle Addict Charger 2

2022 ADDICT eRIDE | ENGLISH 9
|
HEADSET OPTIONS
ADDICT eRIDE
part number:
277547 SCO STEM SPACER KIT SY CREST IC
part number:
275466 SYN HEADSET IS52/31.8 - IS52/42
part number:
277548 SCO STEM SPACER KIT SY RR IC
part number:
277549 SCO STEM STEERER CAP SY RR IC
part number:
277550 SCO STEM STEERER CAP SY CREST IC

2022 ADDICT eRIDE | ENGLISH 10
|
STEM / SEATPOST / CABLE GUIDE OPTIONS
T20
T206 Nm
3 Nm 4 Nm
6 Nm
ADDICT eRIDE
part number:
275472 SCO Stem hardware kit Fras
iC, Crest iC
part number:
277042 SCO Stem top cover SY RR iC
part number:
277543 SCO Seatclamp Addict RC 20
Use carbon grease on the
seatpost.
Cable guide kit part number:
277025 SCO Cableguide kit Addict
RC D 20
part number:
275431 SYN Stem RR 1.5
