SeaLevel HazPAC 10-15 User manual

1
© Sealevel Systems, Inc. H1400811-15 Manual | SL93645/2022
HazPAC 10-15 Touchscreen Computer
User Manual | H1400811-15

2
© Sealevel Systems, Inc. H1400811-15 Manual | SL93645/2022
Contents
CONTENTS............................................................................................................................................................................................................................2
INTRODUCTION...................................................................................................................................................................................................................4
Overview................................................................................................................................................................4
Features .................................................................................................................................................................4
BEFORE YOU GET STARTED..............................................................................................................................................................................................5
What’s Included.....................................................................................................................................................5
Advisory Conventions.............................................................................................................................................5
Optional Items .......................................................................................................................................................6
Cables ....................................................................................................................................................................6
Power Supply .........................................................................................................................................................7
TECHNICAL DESCRIPTION................................................................................................................................................................................................8
Memory .................................................................................................................................................................8
Ethernet .................................................................................................................................................................8
USB.........................................................................................................................................................................9
Display and Touchscreen .....................................................................................................................................10
Serial Communications ........................................................................................................................................11
Input Power .........................................................................................................................................................14
RS-485 Termination and Pull-up/Pull-down Resistors .........................................................................................15
Open Collector Outputs........................................................................................................................................16
SATA CFAST Type I, II memory .............................................................................................................................19
Reset and Power buttons.....................................................................................................................................20
HARDWARE INSTALLATION............................................................................................................................................................................................21
SOFTWARE INSTALLATION .............................................................................................................................................................................................21
SEAMAX APPLICATION SUITE........................................................................................................................................................................................21
MaxSSD Configuration & Diagnostics Utility .......................................................................................................22
Host PC Configuration Tab...................................................................................................................................22
Digital I/O Tab .....................................................................................................................................................23
Troubleshooting - SeaMAX ..................................................................................................................................24
APPENDIX A – TROUBLESHOOTING SERIAL COMMUNICATION ISSUES.............................................................................................................25
Troubleshooting/Verification for Asynchronous Serial Products .........................................................................25
APPENDIX B – HOW TO GET ASSISTANCE..................................................................................................................................................................31
APPENDIX D – COMPLIANCE NOTICES........................................................................................................................................................................33
Federal Communications Commission (FCC) Statement ...............................................................................................33

3
© Sealevel Systems, Inc. H1400811-15 Manual | SL93645/2022
EMC Directive Statement .........................................................................................................................................33
China Compulsory Certification Statement ...............................................................................................................33
United Kingdom Conformity Assessed Statement .......................................................................................................33
WARRANTY ........................................................................................................................................................................................................................35

4
© Sealevel Systems, Inc. H1400811-15 Manual | SL93645/2022
Introduction
Overview
The HazPAC 10-15 is an application-ready platform for your next product design. The system is
based on the Intel Atom™ E3845 1.91 GHz Quad-Core Processor. With 8GB of DDR3 RAM and a
64GB CFast SSD port, the unmatched I/O features of the HazPAC 10-15 extend the possible uses
beyond traditional Embedded applications.
To provide the fastest time to market, Windows 10 IoT Enterprise LTSC and low-level drivers for
system I/O are included.
The HazPAC 10-15 is housed in a rugged, small enclosure suitable for mounting in hazardous
locations (see Installation Guide for details) and is rated for a –30°C to +60°C operating
temperature range. The HazPAC 10-15 power input accepts an absolute operating voltage range
of 9-30VC.
Features
•15” 1024x768 400 nit TFT LCD with LED backlight
•Durable resistive 5-Wire touchscreen
•Intel© Atom™ E3845 1.91GHz 2MB L2 cache
•8GB DDR3 SO-DIMM
•(3) 10/100/1000 BaseT Ethernet Ports
•(1) 64GB CFast Flash Storage
•(1) Mini PCIe (no cut-out) – half-size card only
•(4) USB 2.0 charging Ports
•(2) Isolated RS-485 serial ports
•(2) RS-232 serial port
•(4) Open-collector digital outputs
•(9-30VDC) input power via removable terminal block
•25W Nominal Power usage, 40W Max power usage
•Compatible with Windows 10 IoT Enterprise LTSC (Intel Atom)

5
© Sealevel Systems, Inc. H1400811-15 Manual | SL93645/2022
Before You Get Started
What’s Included
The HazPAC 10-15 is shipped with the following items. If any of these items are missing or damaged,
please contact Sealevel for replacement.
•HazPAC 10-15 Intel Atom™ E3845 Quad-Core COM Express Type-6 8GB RAM
•KT140 - 6-32 Stainless Hex KEP Nut and Washer (QTY of 16)
•Installation instructions including compliance and rating
information
•Preinstalled - Windows 10 IoT Enterprise 64-bit license
Advisory Conventions
Warning
The highest level of importance used to stress a condition where damage could result to the
product, or the user could suffer serious injury.
Important
The middle level of importance used to highlight information that might not seem obvious or a
situation that could cause the product to fail.
Note
The lowest level of importance used to provide background information, additional tips, or other
non-critical facts that will not affect the use of the product.

6
© Sealevel Systems, Inc. H1400811-15 Manual | SL93645/2022
Optional Items
Depending upon your application, you are likely to find one or more of the following items useful with the
HazPAC 10-15. All items can be purchased from our website (www.sealevel.com) or by calling our sales
team at [phone].
Cables
SeaLatch USB Type A to USB Type B, 72" Length - Device Cable (Item# CA355)
The CA355 is a 72" standard USB device cable. The metal
thumbscrew on the type A
connector ensures secure
connection. The CA355 is USB 2.0 compliant and is
compatible with USB 1.1 and 1.0 devices.
SeaLatch USB Type A to USB Type B, 5 Meter Length - Device Cable (Item#
CA355-5M)
The CA355-5M is a 5 meter (16 feet) USB device cable
with Sealevel’s SeaLatch locking USB type A connector
and standard type B connector. The metal thumbscrew
on the type A connector provides a secure metal-to-metal
connection to devices with SeaLatch USB ports.
SeaLatch USB Type A to SeaLatch USB Type B, 72” Length - Device Cable,
(Item# CA332)
The CA332 is a 72” USB device cable with Sealevel’s
SeaLatch locking USB type A and type B connectors. The
metal thumbscrew on each connector provides a secure
metal-to-metal connection to devices with SeaLatch USB
ports.

7
© Sealevel Systems, Inc. H1400811-15 Manual | SL93645/2022
OPTIONAL ITEMS, CONTINUED
SeaLatch USB Type A to SeaLatch USB Type B, 5 Meter Length - Device Cable
(Item# CA332-5M)
The CA332-5M is a 5 meter (16 feet) USB device cable
with Sealevel’s SeaLatch locking USB Type A and B
connectors. The metal thumbscrew on the type A
connector ensures secure connection.
USB Type A to SeaLatch USB Type B, 72” Length – Device Cable (Item# CA356)
The CA356 is a 72” USB device cable that securely
connects USB device port (metal thumbscrew lock) to a
host computer. The CA356 is USB 2.0 compliant and is
compatible with USB 1.1 and 1.0 devices.
CAT5 Patch Cable, 7' in Length – Blue (Item# CA246)
Standard 7' CAT5 UTP Patch Cable (RJ45).
Power Supply
100-240VAC to 12VDC @ 4.0A LPS, Desktop Power Supply (Item# TR135)
The TR135 is a desktop (brick style) power supply rated
for 100-240VAC input and 12VDC output at 4.0 amps
LPS. The cable has tinned leads for use with products
that have screw terminals for input power.

8
© Sealevel Systems, Inc. H1400811-15 Manual | SL93645/2022
Technical Description
Memory
The HazPAC 10-15 is offered with 8GB DDR3L SDRAM operational memory and is also designed to support
a SATA CFAST Type I, II memory card for bulk storage.
Ethernet
The HazPAC 10-15 includes 3 Gigabit Ethernet ports.
Pin Signal GbE Signal
1 TX+ BI_DA+
2 TX- BI_DA-
3 RX+ BI_DB+
4 C+ BI_DC+
5 C- BI_DC-
6 RX- BI_DB-
7 D+ BI_DD+
8 D- BI_DD-
3 Gigabit Ethernet Ports

9
© Sealevel Systems, Inc. H1400811-15 Manual | SL93645/2022
TECHNICAL DESCRIPTION, CONTINUED
USB
The HazPAC 10-15 provides 4 SeaLATCH USB 2.0 ports
Connector: Rugged USB 2.0 Type A vertical right angle receptacle
Manufacturer: Samtec
Description: Rugged USB Type A, Exceeds retention force of 15N
Mates with: SeaLATCH USB Type A, or Standard USB Type A
4 SeaLATCH USB 2.0 Ports

10
© Sealevel Systems, Inc. H1400811-15 Manual | SL93645/2022
TECHNICAL DESCRIPTION, CONTINUED
Display and Touchscreen
The HazPAC 10-15 features a bright 8.4” TFT LCD with LED backlight, and a durable 5-wire resistive
touchscreen with glass top. The 5-wire resistive touchscreen is rated for >200 million presses (touches).
The touchscreen is calibrated at the factory. If recalibration is necessary, please use the calibration tool
included with existing PenMount driver.
Below are images of the screen from a frontal view and the display screen face down. With the display face
down, you can see all external input and output ports.
Display Screen Face Down

11
© Sealevel Systems, Inc. H1400811-15 Manual | SL93645/2022
Serial Communications
You can connect to a variety of serial peripherals via the HazPAC 10’s serial ports. To start with, there are
two isolated RS-485 serial ports which are provided via a 6 position, 3.5mm pitch terminal block with screw
retention.
The RS-485 serial port has adjacent DIP switches to Pull-up/Pull-Down the data lines and to add
Termination across each data pair.
Finally, two RS-232 serial ports with full modem control are provided, which interface via DB9 male
connectors.

12
© Sealevel Systems, Inc. H1400811-15 Manual | SL93645/2022
TECHNICAL DESCRIPTION, CONTINUED
Connectors: RS-485 port 1 and RS-485 port 2
Description: 6 Position 3.5mm Terminal Block
PIN RS-485 Isolated
1 ISOGND1
2 DATA1+
3 DATA1-
4 ISOGND2
5 DATA2+
6 DATA2-
123456
RS-485 Port 1 and RS-485 Port 2

13
© Sealevel Systems, Inc. H1400811-15 Manual | SL93645/2022
TECHNICAL DESCRIPTION, CONTINUED
Connectors: RS-232 port 1 and RS-232 port 2
Description: DB-9 Male
PIN RS-232
1 DCD
2 RXD
3 TXD
4 DTR
5 GND
6 DSR
7 RTS
8 CTS
9 RI
RS-232 Port 1 and RS-232 Port 2

14
© Sealevel Systems, Inc. H1400811-15 Manual | SL93645/2022
Input Power
The HazPAC 10-15 can operate from 9-30VDC. The power source must be appropriately listed ITE
Power Supply Limited Power Source, or LPS, suitable for the maximum ambient temperature at the
installation.
9-30VDC Input Power
The voltage applied here is also present on the Open Collector output VIN pin and can be used to
power the open collector outputs.
Absolute Operating Range: 9-30VDC
Rated Voltage: 12-27VDC 4A– 1.5A, respectively
Power Usage: 25W nominal / 40W max

15
© Sealevel Systems, Inc. H1400811-15 Manual | SL93645/2022
RS-485 Termination and Pull-up/Pull-down Resistors
Each RS-485 Isolated port has selectable line conditioning via the three DIP switches to the side of the RS-
485 terminal block. These switches control whether termination and pull-up/pull-down resistors are active
for the port.
DIP Switch Position Result
TERM OFF (Down or away from screen)
ON (Up or toward screen)
DISABLED - No termination
ENABLED - Terminate between D+ and D-
lines with 120 ohm resistor
PU OFF (Down or away from screen)
ON (Up or toward screen)
DISABLED - No pull-up
ENABLED- Pull-up D+ line to isolated 3.3V
ISO1 plane via 510 ohm resistor
PD OFF (Down or away from screen)
ON (Up or toward screen)
DISABLED - No pull-down
ENABLED - Pull-down D- line to isolated
GND ISO1 plane via 510 ohm resistor
The pull-up and pull-down resistors ensure that the D+ and D- lines are at a known state when not being
driven by the RS-485 bus. The first and last devices in a RS-485 bus should enable line termination, as well
as the pull-up and pull-down resistors.
Pull-up/Pull-down Resistors (DIP Switches)

16
© Sealevel Systems, Inc. H1400811-15 Manual | SL93645/2022
Open Collector Outputs
The HazPAC 10-15 is equipped with 4 open-collector outputs. Each output is rated for 30VDC. The open
collectors can sink up to 100mA per output, up to a maximum of 400mA total.
Connector OPEN COLLECTOR
Manufacturer: MOLEX
Part Number: 39506-1006
Description: 6 Position Right Angle 3.5mm Header
Mates with: MOLEX 39504-0006 6-Position 3.5mm
Pluggable Screw Terminal
Screw Torque: 5.5 in lbs. (0.62 Nm)
Wire gauge: AWG 16-30 (1.31mm2– 0.05mm2)
Wire rating: 85°C or higher
Pin Signal
1 GND
2 Output 1
3 Output 2
4 Output 3
5 Output 4
6 VIN/COM

17
© Sealevel Systems, Inc. H1400811-15 Manual | SL93645/2022
Output Wiring for HazPAC 10-15
The HazPAC 10 supports multiple wiring options for the Open Collectors for maximum flexibility depending
on your power source. Each option is described below.
Each open collector circuit in the array (ULN2803A) contains a suppression diode for inductive
load protection. These diodes are only utilized if VIN is connected.
Internal Voltage Wiring
The HazPAC 10’s internal power supply provides 9-30VDC at VIN to power open-collector outputs. The VIN
pin is diode protected to accept a user provided external 9-30VDC to power the open-collector outputs.
External Voltage Wiring (with Internal Flyback Protection)
Under some scenarios, you can utilize the internal flyback diodes when using an external power source.
This scenario is only possible if your external power source is a higher voltage than the power supply of the
HazPAC 10. See the next section if your external voltage source is lower than that of the HazPAC 10 power
supply.
.
These outputs are polarized but do not have reverse polarity protection. Be mindful of the polarity
when connecting your power source.
Your external power source must have a higher voltage than the power supply of the HazPAC 10.

18
© Sealevel Systems, Inc. H1400811-15 Manual | SL93645/2022
External Voltage Wiring (with and without External Flyback Protection)
Voltage can be provided independently HazPAC 10’s power supply if Vin is not connected. However, this
also removes the integrated flyback protection. You will need to add your own flyback diodes if you are
switching inductive loads.
External flyback diodes are required to protect the outputs when switching inductive loads.

19
© Sealevel Systems, Inc. H1400811-15 Manual | SL93645/2022
SATA CFAST Type I, II memory
Advisory Conventions
When power is removed from the HazPAC 10-15, the CFAST memory card inside can be replaced.
To do this remove all screws from the cover for the memory card port. The existing card can then
be pulled from the port and a new card inserted. Reinstall the port cover before connecting power
to the device.
The existing card can then be pulled from the port and a new card inserted. Reinstall the port cover
before connecting power to the device.
SATA CFast Type I, II Memory Card Port

20
© Sealevel Systems, Inc. H1400811-15 Manual | SL93645/2022
Reset and Power buttons
A full system Hardware Reset is provided by a recessed tactile switch. The Processor and peripherals will
be issued a reset command when the Reset button is pressed and held for 5-6 seconds. Use a blunt non-
conductive instrument to depress the reset button.
Power Button (on the Left) and Reset Button (on the Right)
Just like with the Reset button, the Power button needs to be pressed and held for 5-6 seconds to turn the
device on or off.
