Sealey EH2001 User manual

INSTRUCTIONS FOR
INDUSTRIAL FAN HEATER 2KW
MODEL NO: EH2001
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these
instructions, and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
1. SAFETY
1.1. ELECTRICAL SAFETY
WARNING! It is the responsibility of the owner and the operator to read, understand and comply with the following:
You must check all electrical products, before use, to ensure that they are safe. You must inspect power cables, plugs, sockets and
any other connectors for wear or damage. You must ensure that the risk of electric shock is minimised by the installation of
appropriate safety devices. A Residual Current Circuit Breaker (RCCB) should be incorporated in the main distribution board. We also
recommend that a Residual Current Device (RCD) is used. It is particularly important to use an RCD with portable products that are
plugged into a supply which is not protected by an RCCB. If in any doubt consult a qualified electrician. You may obtain a Residual
Current Device by contacting your Sealey dealer.
You must also read and understand the following instructions concerning electrical safety.
9The Electricity at Work Act 1989 requires that all portable electrical appliances, if used on business premises, are tested by a qualified
electrician, using a Portable Appliance Tester (PAT), at least once a year.
9The Health & Safety at Work Act 1974 makes owners of electrical appliances responsible for the safe condition of those appliances
and the safety of the appliance operators. If in any doubt about electrical safety, contact a qualified electrician.
9Ensure that the insulation on all cables and on the appliance is safe before connecting it to the power supply. See 1.1.1. and 1.1.2.
and use a Portable Appliance Tester.
Ensure that cables are always protected against short circuit and overload.
9Regularly inspect power supply cables and plugs for wear or damage and check all connections to ensure that none are loose.
9Important: Ensure that the voltage marked on the appliance matches the power supply to be used and that the plug is fitted with the
correct fuse - see fuse rating at right.
8DO NOT pull or carry the appliance by the power cable.
8DO NOT pull the plug from the socket by the cable.
8DO NOT use worn or damaged cables, plugs or connectors. Immediately have any faulty item
repaired or replaced by a qualified electrician. When a BS 1363/A UK 3 pin plug is damaged, cut
8the cable just above the plug and dispose of the plug safely.
Fit a new plug according to the following instructions (UK only).
a) Connect the GREEN/YELLOW earth wire to the earth terminal ‘E’.
b) Connect the BROWN live wire to the live terminal ‘L’.
c) Connect the BLUE neutral wire to the neutral terminal ‘N’.
d) After wiring, check that there are no bare wires, that all wires have been connected correctly, that the
cable outer insulation extends beyond the cable restraint and that the restraint is tight.
Double insulated products, which are always marked with this symbol , are fitted with live (brown)
and neutral (blue) wires only. To rewire, connect the wires as indicated above.
8DO NOT connect either wire to the earth terminal.
9If an extension reel is used it should be as short as possible and fully unwound before connection. A reel with an RCD fitted is preferred
since any appliance plugged into it will be protected. The cable core section is important and should be at least 1.5mm², but to be
absolutely sure that the capacity of the reel is suitable for this product and for others which may be used in the other output sockets, we
recommend the use of 2.5mm² section cable.
1.2. GENERAL SAFETY
WARNING! Disconnect the heater from the mains power supply, before servicing or performing any maintenance. Servicing or
maintenance must only be carried out by an authorised service agent.
9Check that the heater is in sound condition and good working order. Take immediate action to repair or replace damaged parts.
9Use recommended parts only. Unapproved parts may be dangerous and will invalidate the warranty.
9Position the heater at least a minimum of 0.5mtr at the rear and sides, and 2mtr at the front, from any walls or objects.
WARNING! DO NOT use the heater near ammable material, liquids, solids, gases or compressed gas cylinders etc.
8DO NOT obstruct the air inlet and outlet sections of the heater.
8DO NOT cover the heater.
8DO NOT operate the heater when you are tired or under the influence of alcohol, drugs or intoxicating medication.
8DO NOT touch the heater casing or grill when rst switched off, as these will be very hot and will take time to cool.
8DO NOT use the heater for anything other than its intended purpose. It is designed to provide heat in enclosed areas larger than 4m³,
such as workshops and other industrial areas. It is not suitable for drying clothes or laundry.
RECOMMENDED
FUSE RATING - 13AMP
EH2001 | Issue 5 22/02/17
Original Language Version
© Jack Sealey Limited
Refer to
instructions
Indoor Use
Only
8DO NOT place the heater close to a bath, wash basin, shower, swimming pool or any other water-filled area or wet surface.
8DO NOT get the heater wet or use in areas of high condensation.
8DO NOT place the heater up against any surface such as a wall, door or furniture etc.
8DO NOT place the heater immediately below any electrical outlet.
8DO NOT allow the power lead to touch the radiator surface.
8DO NOT attempt to repair a damaged heater, contact an authorised service agent.
8DO NOT stand on the heater.
8DO NOT connect the heater to a timer device or other equipment than can automatically switch the heater on or off.
9Only use the heater in an upright position.
9Ensure that the heater is correctly turned off when not in use and store in a safe, dry, childproof location.
NOTE: Children of less than 3 years should be kept away unless supervised continuously.
Children aged from 3 years and less than 8 years shall only switch on/off the appliance provided that it has been placed or installed
in its intended normal operating position and they have been given supervision or instruction concerning use of the appliance in a safe
way and understand the hazards involved. Children aged from 3 years and less than 8 years shall not plug in, regulate and clean the
appliance or perform user maintenance.
CAUTION: Some parts of this product can become very hot and cause burns. Particular attention has to be given where children and
vulnerable people are present.
2. INTRODUCTION
Electric fan heater for industrial applications. One heat setting with thermostat control, plus fan only setting. A totally dry heat with no
condensation, no gas, no fumes, so no smell. Ideal for workshops, garages etc.
3. SPECIFICATION
Model No: .....................................................................EH2001
Voltage: ............................................................................ 230V
Power Rating:................................................................ 2000W
Heat Setting:.................................................................. 2000W
Dimensions (W x D x H): ............... 215mm x 230mm x 280mm
Fuse Rating: ....................................................................... 13A
IMPORTANT! This unit is designed to raise the ambient temperature of an entire room, the temperature of the air coming out
of the front of the heater will be warmer than the general temperature of the room, but there may not be a signicant increase due
to the large volume of air passing over the element. For the same reason, the element is hot during operation, but does not visibly
glow. The room temperature depends on room size, insulation and the ambient temperature, which will increase as the room gets
warmer.
4. OPERATION
4.1. Position heater in an upright position on a firm surface and at a safe distance from any obstructions, flammable substances etc. Keep
to a minimum of 0.5mtr clearance at the rear and sides, and 2mtr clearance at the front.
4.2. Connect the heater to a suitable mains supply.
4.3. Set the thermostat dial to its maximum setting (fully clockwise).
4.4. The heater will switch on when the power setting dial is set to the heater setting.
NOTE: It will take up to three minutes for the heater to reach optimum temperature.
4.5. Once the room reaches the required temperature, turn the thermostat dial slowly counter-clockwise until the thermostat clicks, leave
the dial in this position to maintain the room temperature at this setting. The heater will continue to operate until the power switch is
turned to the OFF position.
4.6. For fan only operation, turn the power/fan selector to the fan only setting, and set the thermostat to its minimum setting.
4.7. When not in use, disconnect the heater from the mains supply. Store it in a safe, dry, childproof location.
EH2001 | Issue 5 22/02/17
Original Language Version
© Jack Sealey Limited
Fan only setting
OFF
Power / Fan
Selector Thermostat
Power setting (2000W)
g.1
Sole UK Distributor, Sealey Group.
Kempson Way, Suffolk Business Park,
Bury St. Edmunds, Suffolk.
IP32 7AR
www.sealey.co.uk
sales@sealey.co.uk
01284 757500
01284 703534
Sole UK Distributor, Sealey Group.
Kempson Way, Suffolk Business Park,
Bury St. Edmunds, Suffolk.
IP32 7AR
www.sealey.co.uk
sales@sealey.co.uk
01284 757500
01284 703534
Sole UK Distributor, Sealey Group.
Kempson Way, Suffolk Business Park,
Bury St. Edmunds, Suffolk.
IP32 7AR
www.sealey.co.uk
sales@sealey.co.uk
01284 757500
01284 703534
Environmental Protection
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be
sorted, taken to a recycling centre and disposed of in a manner which is compatible with the environment.
When the product becomes completely unserviceable and requires disposal, drain off any fluids (if applicable)
into approved containers and dispose of the product and the fluids according to local regulations.
WEEE Regulations
Dispose of this product at the end of its working life in compliance with the EU Directive on
Waste Electrical and Electronic Equipment (WEEE). When the product is no longer required, it must be disposed
of in an environmentally protective way. Contact your local solid waste authority for recycling information.
NOTE: It is our policy to continually improve products and as such we reserve the right to alter data, specications and component parts without prior notice.
IMPORTANT: No liability is accepted for incorrect use of this product.
WARRANTY: Guarantee is 12 months from purchase date, proof of which will be required for any claim.
EH2001 | Issue 5 22/02/17
Original Language Version
© Jack Sealey Limited
5. MAINTENANCE
WARNING! Before attempting any maintenance, ensure that the unit is unplugged from the mains power supply and that it has cooled down.
5.1. Clean the heater with a soft dry cloth only. DO NOT use abrasives or solvents.
5.2. Periodically check the heater grille to ensure that it is not blocked.
No other maintenance is necessary. If a problem with the heater is experienced, or if the power lead or plug is damaged, contact your
local authorised service agent for repair. DO NOT dismantle or tamper with the heater, as this may be dangerous and will invalidate the
warranty.
