INSTRUCTIONS FOR:
GALVANIZED STEEL FLOOR CABINET
5 SHELF wITH FREE STANDING STORAGE
MODEL No: GSC110385SP
Thank you for purchasing a Sealey product. Manufactured to a high standard this product will, if used according to these instructions and
properly maintained, give you years of trouble free performance.
1. SAFETY INSTRUCTIONS
1. SAFETY INSTRUCTIONS
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, wARNINGS & CAUTIONS.
USE THE PRODUCT CORRECTLY AND wITH CARE FOR THE PURPOSE FOR wHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE
DAMAGE AND/OR PERSONAL INJURY AND wILL INVALIDATE THE wARRANTY. PLEASE KEEP INSTRUCTIONS SAFE FOR FUTURE USE.
2. INTRODUCTION
3. CONTENTS
1.1. GENERAL SAFETY
wARNING! Ensure Health & Safety, local authority, and
general workshop practice regulations are adhered to when
using this cabinet.
Locate cabinet in a suitable work area.
Keep the work area clean, uncluttered and ensure there is
adequate lighting.
wARNING! Use cabinet on level and solid ground,
preferably concrete.
Keep the cabinet clean and tidy in accordance with good
workshop practice.
Keep children and unauthorised persons away from the work
area.
DO NOT use the cabinet for any purpose other than that
for which it is designed.
DO NOT use the cabinet outdoors.
DO NOT place the cabinet in a damp or wet location or an
area where there is condensation.
DO NOT clean the cabinet with any solvents which may
damage the surfaces or the protective coating.
 DO NOT move the cabinet when there are items placed
inside.
 DO NOT step on the shelves.
 DO NOToverload the cabinet.
Extra wide, oor standing galvanized steel cabinet with
lockable double doors. Right side includes an open
space for taller items such as brooms, mops and
ladders. Left side features ve shelves, four of which
are adjustable. Supplied with two keys. Ideal for factory,
workshop or home use.
Dimensions:
Width: 1100mm, Depth: 330mm, Height: 1810mm.
Shelf size: 565 x 328 x 50mm.
Part No. Part Name No.
GSCSP.A4 Top Panel 1
GSCSP.B7 Left Side Panel 1
GSCSP.B8 Right Side Panel 1
GSCSP.C5 Left Back Panel 1
GSCSP.C8 Right Back Panel 1
GSCSP.D6 Shelf 5
GSCSP.E3 Front Base Bracket 1
GSCSP.F3 Back Base Bracket 1
GSCSP.H2 Middle Panel 1
GSCSP.L3 Left Door 1
GSCSP.R3 Right Door 1
GSC110385SP.I Shelf Support 20
GSC110385SP.J Self Tapping Screw 21
Unpack the contents of the box and check against the
parts list/diagram. If there are any parts missing,
contact your local Sealey dealer.
