Sealey RPS2KD User manual

UNIVERSAL MOTORCYCLE WHEEL STANDS
(FRONT AND REAR) WITH RUBBER SUPPORTS KD
MODEL NO: RPS2KD (REAR), FPS1KD (FRONT)
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these instructions,
and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURYAND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
1. SAFETY
WARNING! Before use, ensure that there is nothing attached to the front forks, the fairing, or the rear end of the motorcycle, that
will foul the stand.
8DO NOT mount the stand on tarmacadam, as the surface may be unstable.
8DO NOT start the motorcycle when mounted on the stand.
8DO NOT sit on the motorcycle when mounted on the stand.
8DO NOT use the stand for a purpose it is not designed to perform.
8DO NOT operate the stand if it is damaged or parts are missing.
8DO NOT use the stand when you are tired or under the influence of alcohol, drugs or intoxicating medication.
8DO NOT allow untrained persons to operate the stand.
8DO NOT make any modifications to the stand.
8DO NOT operate the stand if parts are missing or damaged.
9Maintain the stand in a good clean condition for the best and safest performance.
9Locate the stand and motorcycle in a suitable area. Keep area clean, tidy and free from unrelated materials and ensure that there is
adequate lighting.Also ensure that the floor/ground is level and strong enough (preferably concrete) to take the weight of the stand
and the motorcycle.
9Maintain correct balance and footing whilst positioning the motorcycle on the stand, DO NOT over reach.
9Ensure that the floor is not slippery, wear non-slip footwear.
9Keep children and unauthorised persons away from the work area.
9Before loading or removing a motorcycle to/from the stand, ensure that there are no obstructions or persons around the motorcycle.
9Always support bike to prevent falling.
9Although the stand can be operated by one person, we advise seeking the assistance of a second person when mounting / dismounting
the stand.
9Always use in conjunction with another suitable rear stand to ensure full stability.
9When not in use, store in a safe, dry, childproof location.
WARNING: The warnings, cautions and instructions in this manual cannot cover all possible conditions and situations that may occur.
It must be understood that common sense and caution are factors which cannot be built into this product, but must be applied
by the operator.
2. INTRODUCTION
RPS2KD (Rear Stand)
Lifts and stabilises any dual swing arm motorbike quickly and easily. Fitted with width and angle adjustable rubber support pads. Rubber supports
mounted on heavy-duty box section for continuous professional use. Bobbin Supports available as an optional extra - Model No. RPS1BS.
Delivered in knock-down form to reduce freight costs, some self-assembly required. Min./Max. Width: 220-350mm.
FPS1KD (Front Stand)
Features width adjustment from 180 to 255mm, making it suitable for almost all motorbikes. Design ensures rim and tyre protection at all times.
Once the bike is supported, allows easy removal and cleaning of front wheel. Please note all front paddock stands need to be used in conjunction
with a suitable rear stand to ensure bike stability (See Model No. RPS2KD). Delivered in knock-down form to reduce freight costs, some self-
assembly required.
RPS2KD
RPS2KD, FPS1KD Issue 1 19/07/22
Original Language Version
© Jack Sealey Limited
Refer to
instruction
manual
Wear protective
gloves Wear protective footwear
FPS1KD

3. SPECIFICATION
Model No: ...........................................RPS2KD (Rear Stand)
Model No: .......................................... FPS1KD (Front Stand)
4. ASSEMBLY
4.1. Ensure all parts are present and in good order. DO NOT use parts other than those supplied.
4.2. Ensure all xings are correctly tightened and that frame members are securely tted.
5. OPERATION
9 Ensure all xings are correctly tightened and that frame members are securely tted before each use.
5.1. Adjust wheel supports to suit bike being loaded by loosening the thumb wheels. Retighten rmly when the correct width is set.
5.2. If using FPS1KD then the suitable Rear stand should be used rst to ensure the bike is supported
6. MAINTENANCE
6.1. Clean with soft dry or lightly damped cloth.
6.2. DO NOT use solvents or chemical cleaners.
6.3. When the stand is not in use, store in dry, clean environment.
6.4. Keep the stand clean and wipe off any oil or grease. Lubricate all moving parts with oil e.g. roller wheels.
6.5. Before each use check all parts. If any part of the stand is damaged or defective, remove the stand from service and take the
necessary action to remedy the problem.
8DO NOT use the stand if it is believed to have been subjected to abnormal load or shock. Inspect and take appropriate action.
Original Language Version
© Jack Sealey Limited
Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR
01284 757500 01284 703534 [e-mail] www.sealey.co.uk
ENVIRONMENT PROTECTION
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be sorted, taken to
a recycling centre and disposed of in a manner which is compatible with the environment. When the product becomes completely
unserviceable and requires disposal, drain any fluids (if applicable) into approved containers and dispose of the product and fluids
according to local regulations.
Note: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts
without prior notice.
Important: No Liability is accepted for incorrect use of this product.
Warranty: Guarantee is 12 months from purchase date, proof of which is required for any claim.
