Sealey AK3992 User manual

SWIVEL HEAD 2-IN-1 RIVETER
MODEL NO: AK3992
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these
instructions, and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURYAND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
1. SAFETY
WARNING! Ensure Health & Safety, local authority and general workshop practice regulations are adhered to when using this
equipment.
9Familiarise yourself with the application and the limitations of the riveter, as well as the potential hazards.
9Maintain the riveter in good condition (use an authorised service agent).
9Replace or repair damaged parts. Use genuine parts only. Unauthorised parts may be dangerous and will invalidate the warranty.
9Keep the work area clean, uncluttered and ensure there is adequate lighting.
9Keep the riveter clean for best and safest performance.
9Check moving parts alignment on a regular basis.
8DO NOT hold the workpiece by hand. Secure unstable workpiece with a clamp, vice or other adequate holding device.
9Ensure the workpiece is correctly secured before using the riveter.
8DO NOT use the riveter for any purpose other than that it was designed for.
8DO NOT operate the riveter if any parts are damaged or missing, as this may cause failure and/or personal injury.
9When not in use store in a safe, dry, childproof location.
2. INTRODUCTION
360° Swivel head gives greatly improved accessibility. Four nozzles for standard rivets and four mandrels for rivet nuts. Pressed steel body
with cast swivel head and Chrome Molybdenum steel jaws. Rubber grip handle for added comfort. Supplied with nozzle spanner.
3. SPECIFICATION
Model no.:................................................................AK3992
Includes: Four nozzles for standard rivets (2.4mm(3/32”),
3.2mm(1/8”), 4mm(5/32”) and 4.8mm(3/16”) and four mandrels
For rivet nuts. (M3, M4, M5, M6)
Length:.......................................................................275mm
Rivet Types: Aluminium -Yes, Steel -Yes, Stainless Steel - Yes
AK3992 Issue 1 15/03/22
Original Language Version
© Jack Sealey Limited
Refer to
instructions Wear eye
protection

4. OPERATION
4.1. RIVETING (g.3)
4.1.1. Screwcollet(g.3.1)rmlyintoRiveterbody(g.1).
4.1.2. Screwsleeve(g.3.2)rmlyintoRiveterbody(g.1).
4.1.3. Selecttheappropriatenosepiecetosuitthesizeofrivetbeingusedandscrewintosleeve(g3.2).
4.2. RIVET NUT (g.2)
4.2.1. Insertnutsleeve(g.2.1)intoRiveterbody(g.1).
4.2.2. Screwsleevexingnut(g.4)rmlyintoRiveterbody(g.1).
4.2.3. Selecttheappropriaterivetnutpullrod(g.2.2)tosuitthesizeofrivetnutbeingusedandinsertintorearofRiveterbody.
1
2
1
2
Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR
01284 757500 01284 703534 [e-mail] www.sealey.co.uk
ENVIRONMENT PROTECTION
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be sorted, taken to
a recycling centre and disposed of in a manner which is compatible with the environment. When the product becomes completely
unserviceable and requires disposal, drain any fluids (if applicable) into approved containers and dispose of the product and fluids
according to local regulations.
Note: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts without prior
notice.
Important: No Liability is accepted for incorrect use of this product.
Warranty: Guarantee is 12 months from purchase date, proof of which is required for any claim.
g.3
g.2
g.1
g.4
