Sealey AK395 User manual

HEAVY DUTY LAZY TONGS RIVETER
MODEL NO: AK395
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these instructions,
and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
1. SAFETY
WARNING! Ensure health & safety, local authority, and general workshop practice regulations are adhered to when using this
equipment.
9 Familiariseyourselfwithapplicationandlimitations,aswellasthespecicpotentialhazardspeculiartotheriveter.
9 Replaceorrepairdamagedparts.Usegenuinepartsonly.Nonauthorisedpartsmaybedangerousandwillinvalidatethewarranty.
9 Keeptherivetercleanforbestandsafestperformance.
9 Locateriveterinanadequateworkingareaforitsfunction,keepareaclean&tidyandfreefromunrelatedmaterialsandensurethere
is adequate lighting.
9Keep children and unauthorised persons away from the working area.
9 Removeillttingclothing.Removeties,watches,rings,andotherloosejewellery,andcontainand/ortiebacklonghair.
WARNING!Alwayswearapprovedeyeorfaceprotectionwhenoperatingtheriveter.
9 Keepngers,handsandbodyclearofallworkingpartsanddo not placeanyitemswithintheriveterlattice.
9Familiarise yourself with the push action to ensure you do not accidentally wrench your wrist when pushing sharply.
9 Maintaincorrectbalanceandfooting.Ensuretheoorisnotslipperyandwearnonslipshoes.
9 Securenonstableworkpiecewithaclamp,viceorotheradequateholdingdevice.
9 Ensurethatallusedrivetendsaredisposedofinasafemanner.
8DO NOTgettheriveterwetoruseinwetlocations.
8DO NOTusetheriveterforanypurposeotherthanforwhichitisdesigned.
8DO NOToperatetheriveterwhenyouaretired,undertheinuenceofalcohol,drugsorintoxicatingmedication.
8DO NOTallowuntrainedpersonstooperatetheriveter.
8DO NOToperatetheriveterifanypartsaredamagedormissingasthismaycausefailureorpossiblepersonalinjury.
2. INTRODUCTION
Precisionmade,highgradealloysteeljawswithstrongaluminiumbody.Forgedalloysteelpinsandboltswithdoublehandlebearingsfor
longlifeanddurability.Suitableforblindaluminium,steelandstainlesssteelrivets.IncludesChromeMolybdenumspecialprolenozzlesfor
structuralrivetsupto6.4mm(1/4”).
3. SPECIFICATION
Nozzles: .....................................4.8/5.0mm,6.0mm,6.4mm.
StructuralNozzles:....................................... 4.8mm,6.4mm.
4. OPERATION
 TheAK395issuitableforaluminium,steelandstainlesssteelrivets.ThetoolincludesChromeMolybdenumnozzlesforstructural
 rivets.
4.1. Nozzles
4.1.1. Selecttheappropriatenozzle.Di󰀨ering
 sizesarelocatedatpoints(A)(g1).
4.1.2. Toremovenozzleathead(B)usethe 
wrench supplied. Ensure the replacement
 nozzleiscompletelyscrewedinalightly
tighten with wrench.
4.2. To Operate.
4.2.1. Holdthehead(C)andpullthehandleso
 thatthelattice(D)iscompletelyextended.
WARNING!Ensureyourngersareclearofmovingparts.Insertrivetshaftallthewayintothenozzle(B).
4.2.2. Insertrivetheadcompletelyintothepreparedworkpiecehole.
4.2.3. Holdtheriveterrmlyandpushonthehandletocompletelyclosethelatticewhichwillxtherivetinplaceandcuttheshaft.Should
 rivetingnotbeachievedonthersttrythenre-extendthelatticeandpushoncemore.
4.2.4. Oncecompleted,pullthehandletoextendthelatticeagaintoejecttheshaftendfromthenozzle.Safelydiscardofshaftends.
5. MAINTENANCE
5.1.  Keeptheriveterclean.
AK395Issue2(HF)11/04/18
Original Language Version
© Jack Sealey Limited
Refer to
instructions
g.1
Wear eye
protection
Crushingof
hands

5.2.  Uselightmachineoiltooccasionallylubricatethelatticepivotpins.
5.3.  Tocleanandchangetheriveterjaws,loosenandremoveoutercollar(E).Loosenandremovetheinnersleeve.Takecareasthe
 internaljawsarespringload.Cleanorreplacethejawsandre-assembleaccordingly.
5.4.  Whennotinuse,storetheriveterinasafe,dry,childprooflocation.
Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR
01284 757500 01284 703534 [e-mail] www.sealey.co.uk
ENVIRONMENT PROTECTION
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be sorted, taken to
arecyclingcentreanddisposedofinamannerwhichiscompatiblewiththeenvironment.Whentheproductbecomescompletely
unserviceableandrequiresdisposal,drainanyfluids(ifapplicable)intoapprovedcontainersanddisposeoftheproductandfluids
according to local regulations.
Note:Itisourpolicytocontinuallyimproveproductsandassuchwereservetherighttoalterdata,specificationsandcomponentpartswithoutprior
notice.
Important: No Liability is accepted for incorrect use of this product.
Warranty:Guaranteeis12monthsfrompurchasedate,proofofwhichisrequiredforanyclaim.
Partssupportisavailableforthisproduct.
www.sealey.co.uk,email[e-mail]ortelephone01284757500
