Sealey MK51.V4 User manual

PANEL STAND - DOOR, WING, BONNET & BUMPER
MODEL NO: MK51.V4
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these
instructions, and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
1. SAFETY
9Only use on firm, level, unobstructed surfaces which are capable of supporting the stand and body panels.
8DO NOT overload.
9Always load evenly with the centre of gravity of the load as near the centre as possible.
9Apply the brakes before commencing work.
8DO NOT stand/ride on the stand, or allow others to do so.
9Replace or repair damaged parts. Use only recommended parts. Unauthorised parts may be dangerous and will invalidate the warranty.
WARNING! Failure to comply with these instructions may result in loss of load, damage to the stand or other property and/or personal
injury.
WARNING! The warnings, cautions and instructions discussed in this instruction manual cannot cover all possible conditions
and situations that may occur. It must be understood that common sense and caution are factors which cannot be built into this
product, but must be applied by the operator.
2. INTRODUCTION
Features fully adjustable arms to t many styles of bonnets, wings, doors and bumpers. Main frame can adjust through 180°, to give required
angle. Fitted with two xed Ø180mm wheels and two braked Ø100mm castors for manoeuvrability.
3. SPECIFICATION
Model No........................................MK51.V4
Overall Arm Width.............................890mm
Base Dimensions...................850 x 900mm
4. ASSEMBLY
Assemble panel stand according to the parts diagram attached.
MK51.V4 | Issue 1 11/12/19
Original Language Version
© Jack Sealey Limited
Refer to
instructions
Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR
01284 757500 01284 703534 [e-mail] www.sealey.co.uk
Note: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts without prior
notice. Please note that other versions of this product are available. If you require documentation for alternative versions, please email or call
our technical team on [e-mail] or 01284 757505.
Important: No Liability is accepted for incorrect use of this product.
Warranty: Guarantee is 12 months from purchase date, proof of which is required for any claim.
ENVIRONMENT PROTECTION
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be sorted, taken to
a recycling centre and disposed of in a manner which is compatible with the environment. When the product becomes completely
unserviceable and requires disposal, drain any fluids (if applicable) into approved containers and dispose of the product and fluids
according to local regulations.

MK51.V4 Issue 1 27/11/19
Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR
01284 757500 01284 703534 [e-mail] www.sealey.co.uk
Page 1 of 1
NOTE: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts without prior notice.
There may be alternative versions of this product, please contact us should you require this information.
IMPORTANT: No liability is accepted for incorrect use of product. Spare parts must be fitted by a competent person
WARRANTY: Guarantee is 12 months from purchase date, proof of which will be required for any claim.
Parts Information:
Panel Stand - Door, Wing, Bonnet &
Bumper
Model No: MK51.V4
Item Part No. Description
1 MK.V Frame for Wheel (L)
2 MK.V Fixed Wheel
3 SS.S Hex Head Set Screw M10 X 50 Zinc
4 MK.V Base Support (for Wheel Frame)
5 FWM.S Flat Washer M10 Zinc
6 NLN.S Nyloc Nut M10 Zinc
7 MK.V Base Support (for Castor Frame)
8 MK.V Securing Knob
9 MK.V Bottom Vertical Frame
10 MK.V Base Frame for Castors
Item Part No. Description
11 MK.V Swivel Castor Wheel
12 FWM.S Flat Washer M12 Zinc
13 NLN.S Nyloc Nut M12 Zinc
14 MK.V Top Vertical Frame
15 MK.V Cross Frame
16 MK.V Adjustable Angle Bracket
17 MK.V Bent Upright Frame
18 MK.V Upright Side Frame
19 MK.V Hook Holder
20 MK.V Rotation Collar
