Sealey GSS1515.V3 User manual

GALVANIZED STEEL SHED 1.51 X 1.51 X 2.0M
MODEL NO: GSS1515.V3, GSS1515G.V3
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these
instructions, and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
1. SAFETY
WARNING! Ensure Health & Safety, local authority, and general workshop practice regulations are adhered to when building this
shed.
9Keep the work area clean, uncluttered and ensure there is adequate lighting.
9Keep children and unauthorized persons away from the working area.
8DO NOT use the shed for any purpose other than that for which it is designed.
9Use appropriate safety clothing including eye protection.
Note! The assembly of this product will require assistance.
2. INTRODUCTION
Galvanized steel panels easily assembled to form rigid and secure structure with pent (sloping) roof. Doors are secured by cross bolt
and eyelet which will accept a padlock (not included) for additional security. Supplied with bolt down fixing kits.
3. SPECIFICATION
Model no: .......................GSS1515.V3 ...........................GSS1515G.V3
Colour: ..........................Silver ........................................Green
Weight:..........................45.6kg .......................................45.6kg
Roof: ...........................Pent ..........................................Pent
Doors: ..........................1................................................1
Overall Size (W x D x H*) ...........1.51 x 1.51 x 2.0m ....................1.51 x 1.51 x 2.0m
*Minimum Wall Height:
GSS1515.V3, GSS1515G.V3 Issue 3 (3, 4) 09/05/19
Original Language Version
© Jack Sealey Limited
Refer to
instructions
Wear eye
protection
Wear protective
gloves
Wear safety
footwear

4. ASSEMBLY

      
  





  

  


 

Original Language Version
© Jack Sealey Limited GSS1515.V3, GSS1515G.V3 Issue 3 (3, 4) 09/05/19

Original Language Version
© Jack Sealey Limited GSS1515.V3, GSS1515G.V3 Issue 3 (3, 4) 09/05/19

Original Language Version
© Jack Sealey Limited GSS1515.V3, GSS1515G.V3 Issue 3 (3, 4) 09/05/19

Original Language Version
© Jack Sealey Limited GSS1515.V3, GSS1515G.V3 Issue 3 (3, 4) 09/05/19

Original Language Version
© Jack Sealey Limited GSS1515.V3, GSS1515G.V3 Issue 3 (3, 4) 09/05/19

Original Language Version
© Jack Sealey Limited GSS1515.V3, GSS1515G.V3 Issue 3 (3, 4) 09/05/19

Original Language Version
© Jack Sealey Limited GSS1515.V3, GSS1515G.V3 Issue 3 (3, 4) 09/05/19

Original Language Version
© Jack Sealey Limited GSS1515.V3, GSS1515G.V3 Issue 3 (3, 4) 09/05/19

Original Language Version
© Jack Sealey Limited GSS1515.V3, GSS1515G.V3 Issue 3 (3, 4) 09/05/19

Original Language Version
© Jack Sealey Limited GSS1515.V3, GSS1515G.V3 Issue 3 (3, 4) 09/05/19

Original Language Version
© Jack Sealey Limited GSS1515.V3, GSS1515G.V3 Issue 3 (3, 4) 09/05/19

Original Language Version
© Jack Sealey Limited GSS1515.V3, GSS1515G.V3 Issue 3 (3, 4) 09/05/19

Original Language Version
© Jack Sealey Limited GSS1515.V3, GSS1515G.V3 Issue 3 (3, 4) 09/05/19

WHITEP L
ASTIC
STOPPER
WHIT
EP LASTIC STOPPER
FIXW ITH3 .0*10MMR IVET
Step 6: Assemble the front door (continued)
Turn door over with bracing aligned with holes (make sure the ridges of the door are facing up) and fix the bracing with the provided 3.0 x
10mm rivets through the front of the panel. Then turn door over and insert plastic stoppers at the ends of braces as shown below.
Note: Fix rivets
through the front panel
with ridges facing up.
FIX WITH 3.0MM RIVETS
WHITE PLASTIC STOPPER
WHITE PLASTIC
STOPPER
ROOF TOP EDGE RIDGES FACING UP
RIDGES FACING DOWN
Original Language Version
© Jack Sealey Limited GSS1515.V3, GSS1515G.V3 Issue 3 (3, 4) 09/05/19

Original Language Version
© Jack Sealey Limited GSS1515.V3, GSS1515G.V3 Issue 3 (3, 4) 09/05/19

Original Language Version
© Jack Sealey Limited GSS1515.V3, GSS1515G.V3 Issue 3 (3, 4) 09/05/19

GardenShed 1.5 x 1.5 x 2.1m
Now fit the bolt down kit as per the diagram. Strengthen the mid wall braces by applying part 72 (mid wall brace bracket) to
each corner if necessary.
WALL SHEE
T
BOLT & NUT
SLAB
STEELA NGLE
SLEEVEA NCHORB OLT
DOOR
72
DOOR
BOLT & NUT
STEEL ANGLE
WALL SHEET
SLEEVE ANCHOR BOLT
Original Language Version
© Jack Sealey Limited GSS1515.V3, GSS1515G.V3 Issue 3 (3, 4) 09/05/19

Apply channel safety cover (L type) to part 31 (channel) and channel safety cover (R type) to part 33R (channel). Also apply the
self-tapper covers to screw ends visible in the walls on the inside of the shed as per the diagram below.
33R
31
L
L
R
R
Original Language Version
© Jack Sealey Limited GSS1515.V3, GSS1515G.V3 Issue 3 (3, 4) 09/05/19

GardenShed 1.5 x 1.5 x 2.1m
The door can be hinged on the opposite side as well. Align the door with the edge and make holes using a cordless drill. Remove
the pins from the hinges and reverse their direction before you attach the door. If you are concerned about the visibility of any pre-
drilled holes, you can fill them with rivets. Perform the same procedure for the pad bolt.
